Connecting Additional Equipment
WARNING
To reduce the risk of fire or electric shock, do not expose the
TV to rain or moisture.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
Note to the CATV Installer
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building as close to the point of
cable entry as practical.
SAFETY PRECAUTIONS
❏ Operate the TV only on 120 V AC.
❏ One blade of the power plug is wider than the other for
safety purposes and will fit into the power outlet only one
way. If you are unable to insert the plug fully into the
outlet, contact your dealer.
❏ If any liquid or solid object falls into the TV, unplug it and
have it checked by qualified personnel before operating it
further.
CAUTION
When using TV games, computers, and similar products
with your TV, keep the brightness and contrast functions at
low settings. If a fixed (non-moving) pattern is left on the
screen for long periods of time at a high brightness or
contrast setting, the image can be permanently imprinted
onto the screen. Continuously watching the same channel
can cause the imprint of station logos onto the TV screen.
These types of imprints are not covered by your warranty
because they are the results of misuse.
NOTIFICATION
This equipment has been tested and found to comply with
the limits for a Class B digital device pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference with radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
❏ Reorient or relocate the receiving antennas.
❏ Increase the separation between the equipment and
receiver.
❏ Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
❏ Consult the dealer or an experienced radio/TV technician
for help.
Protecting the TV
❏ To prevent internal heat build-up, do not block the
ventilation openings.
❏ Do not install the TV in a hot or humid place, or in a place
subject to excessive dust or mechanical vibration.
Note on Caption Vision
This television receiver displays television closed
captioning in accordance with § 15.119 of the FCC rules.
Use of this television for other than private viewing of
programs broadcast on UHF or VHF or transmitted by cable
companies for the use of the general public may require
authorization from the broadcaster-cable company and/or
program owner.
Owner’s Record
The model and serial numbers are located on the front cover
of this manual and at the rear of your TV.
Trademarks and Copyrights
ENERGY STAR is a registered mark.
To reduce the risk of electric shock, do not use
this polarized plug with an extension cord,
receptacle, or other outlet unless the blades can
be fully inserted to prevent blade exposure.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
ATTENTION
CAUTION
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
✍
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.
As an ENERGY STAR
®
Partner, Sony has
determined that this product or product
model meets the ENERGY STAR
®
guidelines
for energy efficiency.
WOW, SRS, and the ( )
®
symbol are trademarks
of SRS Labs, Inc. WOW technology is
incorporated under license from SRS Labs, Inc.
Manufactured under license from BBE Sound, Inc.
Licensed by BBE Sound, Inc. under USP 4638258,
5510752 and 5736897. BBE and BBE symbol are
registered trademarks of BBE Sound, Inc.
WEGA, FD Trinitron, Memory Stick, Steady
Sound, ClearEdge VM, and Caption Vision are
registered trademarks of Sony Corporation.
User Guide
IMPORTANT SAFEGUARDS
For your protection, please read these instructions
completely, and keep this manual for future reference.
Carefully observe and comply with all warnings, cautions
and instructions placed on the set, or described in the
operating instructions or service manual.
WARNING
To guard against injury, the following basic safety
precautions should be observed in the installation, use, and
servicing of the set.
Use
Power Sources
This set should be operated only from
the type of power source indicated on
the serial/model plate. If you are not
sure of the type of electrical power
supplied to your home, consult your
dealer or local power company. For
those sets designed to operate from
battery power, refer to the operating instructions.
Grounding or Polarization
This set may be equipped with a
polarized alternating current line plug
(a plug having one blade wider than
other). This plug will fit into the
power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug still fails to fit, contact
your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarized plug.
For the set with a three-wire grounding type AC plug
This plug will only fit into a
grounding-type power outlet. This is
a safety feature. If you are unable to
insert the plug into the outlet, contact
your electrician to have a suitable
outlet installed. Do not defeat the
safety purpose of the grounding plug.
Overloading
Do not overload wall
outlets, extension
cords or convenience
receptacles beyond
their capacity, since
this can result in fire
or electric shock.
Always turn the set off when it is not to be used. When the
set is left unattended and unused for long periods of time,
unplug it from the wall outlet as a precaution against the
possibility of an internal malfunction that could create a fire
hazard.
Do not disconnect the antenna or the power cord during a
heavy storm. Lightning may strike while you are holding
the cable or cord, causing serious injury. Turn off your TV
and wait for the weather to improve.
Object and Liquid Entry
Never push objects of any kind into the set
through the cabinet slots as they may touch
dangerous voltage points or short out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the set.
Attachments
Do not use attachments not recommended
by the manufacturer, as they may cause
hazards.
Do not place any objects, especially heavy
objects, on top of the set. The object may
fall from the set, causing injury.
Cleaning
Unplug the set from the wall outlet before
cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth
lightly dampened with water for cleaning
the exterior of the set.
If a snapping or popping sound from a TV set
is continuous or frequent while the TV is
operating, unplug the TV and consult your
dealer or service technician. It is normal for
some TV sets to make occasional snapping or
popping sounds, particularly when being
turned on or off.
Installation
Always use two or more people to lift or move the set. The
set is heavy and the bottom surface is flat. Serious injury can
result from trying to move the set by yourself alone, or from
unsteady handling.
Install the set on a stable, level surface.
Water and Moisture
Do not use power-line
operated sets near water —
for example, near a bathtub,
washbowl, kitchen sink, or
laundry tub, in a wet
basement, or near a
swimming pool, etc.
Accessories
Do not place the set on
an unstable cart, stand,
tripod, bracket, table,
or shelf. The set may
fall, causing serious
injury to a child or an
adult, and serious
damage to the set. Use
only a cart or stand recommended by the manufacturer for the
specific model of TV. Any mounting of the product should
follow the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer. An
appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the appliance and cart combination to overturn.
Ventilation
The slots and openings in the cabinet and in the back or
bottom are provided for necessary ventilation. To ensure
reliable operation of the set, and to protect it from
overheating, these slots and openings must never be
blocked or covered.
• Never cover the slots and openings
with a cloth or other materials.
Connecting Additional Equipment
•
Never block the slots and openings
by placing the set on a bed, sofa, rug
or other similar surface.
•
Never place the set in a confined
space, such as a bookcase or built-in
cabinet, unless proper ventilation is
provided.
• Do not place the set near or over a
radiator or heat register, or where it is
exposed to direct sunlight.
Power-Cord Protection
Do not allow anything to rest on or roll over the
power cord, and do not place the set where the
power cord is subject to wear or abuse.
Antennas
Outdoor Antenna Grounding
If an outdoor antenna is installed, follow the precautions
below. An outdoor antenna system should not be located in
the vicinity of overhead power lines or other electric light or
power circuits, or where it can come in contact with such
power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA
SYSTEM, EXTREME CARE SHOULD BE TAKEN TO KEEP
FROM CONTACTING SUCH POWER LINES OR
CIRCUITS AS CONTACT WITH THEM IS ALMOST
INVARIABLY FATAL.
Be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code (NEC) in USA and
Section 54 of the Canadian Electrical Code in Canada
provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
Antenna Grounding According to the NEC
Antenna Grounding According to the National Electrical
Code, ANSI/NFPA 70.
Lightning
For added protection for this television receiver during a
lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the antenna. This will prevent damage to the
receiver due to lightning and power-line surges.
Service
Damage Requiring Service
Unplug the set from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
•
When the power cord or plug
is damaged or frayed.
• If liquid has been spilled
into the set or objects have
fallen into the product.
• If the set has been exposed to
rain or water.
• If the set has been subject to
excessive shock by being
dropped, or the cabinet has
been damaged.
•
If the set does not operate
normally when following the operating
instructions. Adjust only those controls
that are specified in the operating
instructions. Improper adjustment of
other controls may result in damage and
will often require extensive work by a
qualified technician to restore the set to normal operation.
• When the set exhibits a distinct change in
performance — this indicates a need for service.
Servicing
Do not attempt to service the set yourself
since opening the cabinet may expose you
to dangerous voltage or other hazards. Refer
all servicing to qualified service personnel.
Replacement Parts
When replacement parts are required, be
sure the service technician certifies in
writing that he has used replacement
parts specified by the manufacturer that
have the same characteristics as the
original parts. Unauthorized
substitutions may result in fire, electric
shock, or other hazards.
Safety Check
Upon completion of any service or repairs to
the set, ask the service technician to perform
routine safety checks (as specified by the
manufacturer) to determine that the set is in
safe operating condition, and to so certify.
When the set reaches the end of its useful life,
improper disposal could result in a picture
tube implosion. Ask a qualified service
technician to dispose of the set.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRIC CODE
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ARTICLE 250, PART H)
User Guide
Contents
Introduction
Introducing the FD Trinitron WEGA Features........................................................................... 1
About this Manual.......................................................................................................................... 2
Batteries for the Remote Control .................................................................................................. 2
Front Panel Menu Controls ........................................................................................................... 2
Using the Remote Control
Remote Control Description.......................................................................................................... 3
Programming the Remote Control............................................................................................... 5
Using your TV Remote Control with Other Equipment........................................................... 7
Connecting Your TV
TV Rear Panel.................................................................................................................................. 9
Basic Connections ......................................................................................................................... 10
Connecting Additional Equipment............................................................................................ 11
Using Basic Functions
Setting Up the TV.......................................................................................................................... 21
Quick Start to the Menus ............................................................................................................. 22
Using the Memory Stick Viewer
About Memory Stick .................................................................................................................... 25
Inserting and Removing a Memory Stick.................................................................................. 27
Using the Memory Stick Index ................................................................................................... 29
Viewing Photos ............................................................................................................................. 31
Memory Stick Index Menu Bar Options.................................................................................... 33
Notes on Using Memory Stick Media........................................................................................ 35
Using the Menus
How to Access Menus.................................................................................................................. 37
Using the Video Menu......................................................................................................... 38
Using the Audio Menu ....................................................................................................... 39
Using the Channel Setup Menu ........................................................................................ 41
Using the Parental Control Menu ..................................................................................... 43
Parental Control..................................................................................................................... 44
United States: Selecting Custom Rating Options.............................................................. 46
Canada: Selecting Custom Rating Options........................................................................ 48
Using the Timer Menu ........................................................................................................ 49
Using the Setup Menu......................................................................................................... 50
Other Information
Troubleshooting............................................................................................................................ 51
Specifications................................................................................................................................. 56
Index...................................................................................................................................................... 57
1
Introduction
Congratulations on your purchase of the Sony FD Trinitron WEGA
®
.
Introducing the FD Trinitron WEGA Features
Some of the features you will enjoy include:
❏ FD Trinitron Flat CRT — Delivers a picture with uncompromising accuracy and
outstanding image detail via a technologically advanced tube.
❏ Memory Stick
®
Viewer — Lets you watch digital photo (JPEG) files that are stored on
Memory Stick media.
❏ Y, PB, PR Inputs — Provides component video inputs for superior picture quality
(480i only).
❏ WOW — Provides a dramatic presence with a full, deep bass sound. When WOW is
enabled, BBE is directly activated to further enhance the audio performance.
❏ BBE — Gives sound more impact by using audio technology to compensate for phase
effects in speakers.
❏ SRS — Produces a dynamic three-dimensional sound for stereo programs.
❏ Parental Control (V-Chip) — Helps parents monitor what their children watch on TV by
establishing rating limits.
❏ ClearEdge VM — Sharpens picture definition to give objects a crisp, clean edge.
❏ Favorite Channels — Provides instant access to your favorite channels with the touch of a
button.
❏ Info Banner — Displays the name and the remaining time of the current program viewed,
if available.
❏ Universal Remote Control — Operates your connected cable box, VCR, digital satellite
receiver, DVD player, or DVD/VCR combination unit.
❏ Energy Star
®
— Meets the Energy Star guidelines for energy efficiency.
❏ Front Panel Controls — Allows access to the on-screen menus without the use of a remote
control.
❏ Front A/V Inputs — Lets you quickly connect video games, camcorders, or stereo/mono
equipment.
®
2
About this Manual
This manual provides instructions to help you enjoy your new TV. It shows you how to
connect to an antenna or cable, cable box, VCR, DVD, satellite receiver, stereo system, or
camcorder. Once your TV is connected, follow the instructions and use the remote control to
access the on-screen menus.
Batteries for the Remote Control
Insert two AA (R6) batteries (supplied) into the remote control using the following illustration
as a guide.
Front Panel Menu Controls
The front Audio/Video panel controls allow you to access the menu without the remote
control.
❏ Press to display the on-screen menu.
❏ Use the and buttons on the front Audio/Video panel instead of your remote
control.
❏ Use the button on the front Audio/Video panel to navigate through the menus, then
select an item. The front panel controls also allow you to change your channels (CH+/-),
adjust the volume (VOL +/-), and change video inputs.
✍ Under normal conditions, batteries will last up to six months. If the remote control does not operate
properly, the batteries might be worn out.
✍ If you will not be using the remote control for an extended period of time, remove the batteries to
avoid possible damage from battery leakage.
✍ To navigate the menus with your remote control, see “Using the Menus” on page 37.
3
Remote Control
Using the Remote Control
Remote Control Description
Button Description
1
MUTING Press to turn off the sound. Press again or press
to restore sound.
2
SYSTEM OFF Press to turn off the equipment programmed into
the remote control. See “Programming the Remote
Control” on page 5. This button does not work with
DVD/VCR combo units, and may not work with
older Sony equipment.
3
TV/VCR/DVD Press to change the VHF/UHF output of the VCR
(or DVD/VCR combination unit). If you have a
non-Sony VCR or DVD, you will need to program
the remote control to recognize your VCR. For
details, see “Programming the Remote Control” on
page 5.
4
TV/SAT Press to switch between the TV and SAT (satellite)
inputs when in SAT FUNCTION mode.
Press for a direct selection of Effect settings
(Simulated, SRS, WOW, Off) when the remote is in TV
FUNCTION mode.
See “Using the Audio Menu” on page 39 for
details.
5
PICTURE MODE Press repeatedly to step through the available video
picture modes: Vivid, Standard, Movie, and Pro.
Also available in the Video menu. See “Using the
Video Menu” on page 38 for details.
6
SLEEP Press repeatedly until the TV displays the time in
minutes (15, 30, 45, 60, or 90) that you want the TV
to remain on before shutting off automatically.
Cancel by pressing until Sleep Off appears.
7
JUMP Press to jump back and forth between two channels.
The TV alternates between the current channel and
the last channel that you selected. JUMP will not
work if any FUNCTION Mode (VCR/DVD, SAT/
CABLE, TV) is activated.
8
MEMORY STICK Press to enter or exit the Memory Stick Viewer. For
details, see “Using the Memory Stick Viewer” on
page 25.
9
RESET Press to return to factory settings while in an
on-screen menu.
q;
VOL (volume) Press (+) or (-) to adjust the volume.
qa
CODE SET Press to program your remote control to operate
connected video equipment. See “Programming the
Remote Control” on page 5.
A
B
C
5
F
G
M
N
O
P
Q
R
H
I
J
K
L
S
T
U
V
D
4
Remote Control
qs
POWER buttons Press to turn on and off the TV and other audio/
video equipment you have programmed into the
remote control. For instructions, see “Programming
the Remote Control” on page 5.
qd
FUNCTION buttons Press to select the equipment (VCR/DVD, SAT/
CABLE, TV) that you want to operate with the
remote control. The indicator (LED) lights up
momentarily when pressed to show which device
the remote control is operating.
qf VCR/DVD
(operating)
Press to operate your VCR or DVD. The VCR or
DVD must be programmed into the remote control.
For instructions, see “Programming the Remote
Control” on page 5.
and
(to record)
Press the button and the button at the same
time to record programs with your VCR. The
remote control must be programmed before you
can use REC.
m Rewind.
M Fast-forward.
Play.
x Stop.
X
Pause. Press again to resume normal playback.
qg
TV/VIDEO Press to cycle through available video inputs.
qh
DISPLAY Press once to display the current time (if set) and
the program status such as channel number,
Channel Label (if set), video input, Video Label (if
set), and Info Banner (if set). Press again to turn off
the display.
qj
MTS/SAP Press to cycle through the Multi-channel TV Sound
(MTS) options: Stereo, Auto SAP (Second Audio
Program), and Mono.
qk
and
ENTER
Press to change channels. The channel changes after
two seconds.
ql
GUIDE Press to display the program guide of your satellite
receiver.
w;
Press the arrow buttons to move the cursor in the
on-screen menus. Press the center button to select
an option.
To use Favorite Channels, exit all menus and press
. Press
F or f to move the cursor to the desired
channel number and press . See “Favorite
Channels” on page 41 for details.
wz
MENU Press to display the on-screen menu. Press again to
exit the menu at any time.
wx
CH (channel)
Press to change channels. To scan rapidly through the
channels, press and hold down the CH+ or CH- button.
✍ If you lose your remote control, see page 52.
Button Description
0 9
5
Remote Control
Programming the Remote Control
If you have video equipment other than Sony brand (or if you have a Sony DVD/VCR
combination unit) that you want to control with the TV’s remote control, use the following
procedure to program the remote control.
1 Check the list of “Manufacturer’s Codes” on page 6 and find the three-digit code number
for the manufacturer of your component. If more than one code number is listed, use the
number listed first.
2 Press .
3 Press or FUNCTION button to indicate the type of component you want to
program with the remote control.
4 Use the buttons to enter the three-digit manufacturer’s code number.
5 Press .
6 To check if the code number works, aim the TV’s remote control at the component and
press the green POWER button (VCR/DVD, SAT/CABLE) that corresponds with that
component. If it responds, you are done. If not try using another code listed for that
manufacturer.
✍ The and FUNCTION button will flash when you press .
✍ You must do step 4 within 10 seconds of step 3, or you must redo steps 2 and 3.
✍ If you have problems programming your remote control, see “Troubleshooting” on page 52.
0 9
6
Remote Control
Manufacturer’s Codes
VCRs
Manufacturer Code
Sony 301, 302, 303
Admiral
(M. Ward)
327
Aiwa 338, 344
Audio Dynamic 314, 337
Broksonic 319, 317
Canon 309, 308
Citizen 332
Craig 302, 332
Criterion 315
Curtis Mathes 304, 338, 309
Daewoo 341, 312, 309
DBX 314, 336, 337
Dimensia 304
Emerson 319, 320, 316, 317,
318, 341
Fisher 330, 335
Funai 338
General Electric 329, 304, 309
Go Video 322, 339, 340
Goldstar 332
Hitachi 306, 304, 305, 338
Instant Replay 309, 308
JC Penney 309, 305, 304, 330,
314, 336, 337
JVC 314, 336, 337, 345,
346, 347
Kenwood 314, 336, 332, 337
LXI (Sears) 332, 305, 330, 335,
338
Magnavox 308, 309, 310
Marantz 314, 336, 337
Marta 332
Memorex 309, 335
Minolta 305, 304
Mitsubishi/
MGA
323, 324, 325, 326
Multitech 325, 338, 321
NEC 314, 336, 337
Olympic 309, 308
Optimus 327
Panasonic 308, 309, 306, 307
Pentax 305, 304
Philco 308, 309
Philips 308, 309, 310
Pioneer 308
Quasar 308, 309, 306
RCA/PROSCAN 304, 305, 308, 309,
311, 312, 313, 310,
329
Realistic 309, 330, 328, 335,
324, 338
Sansui 314
Samsung 322, 313, 321
Sanyo 330, 335
Scott 312, 313, 321, 335,
323, 324, 325, 326
Sharp 327, 328
Shintom 315
Signature 2000
(M. Ward)
338, 327
SV2000 338
Sylvania 308, 309, 338, 310
Symphonic 338
Tashiro 332
Tatung 314, 336, 337
Teac 314, 336, 338, 337
Technics 309, 308
Toshiba 312, 311
Wards 327, 328, 335, 331,
332
Yamaha 314, 330, 336, 337
Zenith 331
Laserdisc Players
Manufacturer Code
Sony 701
Panasonic 704, 710
Pioneer 702
DVD/VCR Combination
Units
Manufacturer Code
Sony 601
Broksonic 605
JVC 604
Panasonic 609
Samsung 603
Toshiba 602
DVD Players
Manufacturer Code
Sony 751
Hitachi 758
JVC 756
Magnavox 757
Mitsubishi 761
Onkyo 762
Oritron 759
Panasonic 753
Philips 757
Pioneer 752
RCA 755
Samsung 758
Toshiba 754
Zenith 760
Cable Boxes
Manufacturer Code
Sony 230
Hamlin/Regal 222, 223, 224, 225,
226
Jerrold/G.I./
Motorola
201, 202, 203, 204,
205, 206, 207, 208,
218
Oak 227, 228, 229
Panasonic 219, 220, 221
Pioneer 211, 214, 215
Scientific Altanta 209, 210, 211
Tocom 216, 217
Zenith 212, 213
Satellite Receivers
Manufacturer Code
Sony 801
DIRECT TV 809
Dish Network 810
Echostar 810
General Electric 802
Hitachi 805
Hughes 804
Mitsubishi 809
Panasonic 803
RCA/PROSCAN 802, 808
Toshiba 806, 807
7
Remote Control
Using your TV Remote Control with Other Equipment
Operating a VCR
Press To
Activate the remote control to operate the VCR (FUNCTION button)
Power on/off the VCR (VCR/DVD green button)
or , ENTER
(using tuner)
Change channels
Play video tape
Stop
or
Rewind or Fast - forward a video tape
Pause
and
(Simultaneously)
Record
Switch between VCR and TV inputs
Operating a DVD Player
Press To
Activate the remote control to operate the VCR (FUNCTION button)
Power on/off the DVD (VCR/DVD green button)
, ENTER
Select chapters
Search chapters forward or backward
Play DVD
Stop
Pause
or
Search the picture forward or backward during playback
Display the DVD menu
Use the arrow buttons to move the cursor in the menu, and the center button to
select an option
Switch between VCR and TV inputs
0 9
0 9
8
Remote Control
Operating a Cable Box or Satellite Receiver
Press To
Activate the remote control to operate the cable box or satellite receiver
(FUNCTION button)
Power on/off the cable box or satellite receiver (SAT/CABLE green button)
or , ENTER
(using tuner)
Change channels
Change back to previous channel
Display channel number (satellite receiver)
Display SAT Guide (satellite receiver)
Display SAT menu (satellite receiver)
Use the arrow buttons to move the cursor in the menu, and the center button to
select an option (satellite receiver)
Press to switch between the TV and SAT inputs (satellite receiver)
Operating a DVD/VCR Combination Unit
Press To
Activate the remote control to operate the DVD/VCR (FUNCTION button)
Power on/off the DVD/VCR Combination unit (VCR/DVD green button)
When the VCR is not playing, switches between the DVD player and VCR’s
tuner
Display the DVD Menu
Play
Stop
Pause
or
Rewind or fast-forward a video tape (VCR)
Search the picture forward or backward during playback (DVD)
Use the arrow buttons to move the cursor in the menu, and the center button to select
an option (DVD)
and
(Simultaneously)
Record (VCR)
or ,ENTER
(using tuner)
Change channels (VCR)
0 9
0 9
9
Connections
Connecting Your TV
Read this section before setting up your TV for the first time. This section explains how to
make the basic connections and how to connect optional equipment.
TV Rear Panel
Jack Description
1 VHF/UHF This input connects to your VHF/UHF antenna or cable.
2 S VIDEO This input connects to the S VIDEO OUT jack on your VCR or
other video equipment that has S VIDEO. S VIDEO provides
better picture quality than the VHF/UHF jacks or the video
input jack. S VIDEO does not provide sound, so you still must
connect the audio cables.
3 VIDEO/AUDIO
L(MONO), R
This input connects to the AUDIO/VIDEO output jacks on your
VCR or other video equipment. A third video input jack
(VIDEO 2) is located on the front panel of the TV. These
AUDIO/VIDEO input jacks provide better picture quality than
the VHF/UHF jack.
4
Y, P
B
, P
R
/ L, R
This input connects to the component video Y, PB, PR, and
AUDIO L, R jacks on your DVD player or digital set-top box
(480i only).
5 AUDIO OUT
(VAR/FIX)
L(MONO), R
This jack connects to the AUDIO input jacks on your audio
equipment. You can listen to your TV’s audio through your
stereo system.
1
3
4
VIDEO
L L
(MONO)
R
S VIDEO
Y
PB
PR
5
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
1
2
54
3
10
Connections
Basic Connections
TV with Cable, Indoor, or Outdoor Antenna
Depending on the cable system available in your home, choose one of the connections below:
Use option B to connect the TV to a dipole antenna, also known as a “rabbit ears antenna”
(usually found in older homes).
✍ Converter EAC-25 is commercially known as a 300-to-75 ohm antenna adapter.
✍ If you are connecting to an indoor or outdoor antenna, you may need to adjust the orientation of the
antenna for the best reception.
Use option A to connect the TV to a cable system or an antenna with a 75-ohm cable
(usually built into newer homes).
11
Connections
Connecting Additional Equipment
Connecting a TV and VCR
1 Connect the coaxial cable from your TV antenna or cable service to the IN jack on your
VCR.
2 Connect a coaxial cable (not supplied) from the OUT jack on your VCR to the VHF/UHF
jack on the TV.
Optional connection
❏ If your VCR is equipped with video outputs, you can get better picture quality by
connecting audio/video cables (not supplied) from AUDIO/VIDEO OUT on your VCR to
AUDIO/VIDEO IN on your TV.
❏ For better picture quality, use S VIDEO instead of the yellow video cable. S VIDEO does
not provide sound, so you still must connect the audio cables.
Using your TV with this connection
❏ Program your Sony remote control to operate your VCR (see page 5).
❏
To activate your remote, press (FUNCTION button) to operate your VCR. In order to do
this, first program your remote control, then use the Channel Fix feature to set your TV to
channel 3 or 4 (see page 41).
❏ Press repeatedly to switch between VCR input (VIDEO input) and VHF/UHF
(local channels).
Optional connection
1
3
4
VIDEO
LL
(MONO)
R
S VIDEO
Y
P
B
P
R
5
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
VIDEO
LINE
IN
LINE
OUT
AUDIO L AUDIO R
Audio R (red)
Video (yellow)
Audio L (white)
Rear of TV
VCR
2
1
From
cable/antenna
12
Connections
TV and Cable Box
Some cable TV systems use scrambled or encoded signals that require a cable box to view all
channels. If you subscribe to such type of service, use this connection.
1 Connect the coaxial cable from your cable service to the IN jack on your cable box.
2 Connect a coaxial cable (not supplied) from the OUT jack on your cable box to the
VHF/UHF jack on your TV.
Using your TV with this connection
❏ Program your Sony remote control to operate your cable box (see page 5).
❏ To activate your remote, press (FUNCTION button) to operate your cable box. Then
use the
buttons or CH+/- buttons to change the channels. In order to do this, first
program your remote control, then use the Channel Fix feature to set your TV to channel 3
or 4
(see page 41).
1
3
VIDEO
L
(MONO)
R
S VIDEO
VIDEO
LINE
OUT
AUDIO L AUDIO R
1
2
Rear of TV
Cable box
From cable/
antenna
0 9
13
Connections
Connecting a TV, VCR, and Cable Box
Use this connection if you subscribe to a cable system that scrambles some channels (pay
channels), but not all of them. This setup allows you to:
❏ change channels through your cable box or VCR when you are receiving a
scrambled signal
❏ change channels through your TV
1 Connect the single input jack of the splitter (not supplied) to your incoming cable
connection.
2 Using coaxial cables (not supplied), connect the two output jacks of the splitter
(not supplied) to:
a) the IN jack on your cable box
b) the VHF/UHF jack on the TV
3 Using a coaxial cable (not supplied), connect the OUT jack on your cable box to the IN jack
on your VCR.
4 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your VCR to
AUDIO/VIDEO IN on your TV.
5 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your cable
box to AUDIO/VIDEO IN on your TV.
✍ DIGITAL CABLE BOX USERS: If you are connecting a digital cable box, you will need a special bi-
directional splitter (5-900 Mhz minimum) that is designed to work with your digital cable box.
1
3
4
VIDEO
L
(MONO)
R
S VIDEO
Y
PB
PR
5
VIDEO
LINE
IN
LINE
OUT
AUDIO L AUDIO R
VIDEO
LINE
OUT
AUDIO L AUDIO R
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
VCR
Rear of TV
2a
1
4
Video (yellow)
Audio L (white)
Audio R (red)
Cable
3
2b
Splitter
5
Cable box
14
Connections
Optional connection
❏ For better picture quality, use S VIDEO instead of the yellow video cable. S VIDEO does
not provide sound, so you still must connect the audio cables.
Using your TV with this connection
❏ Program your Sony remote control to operate your VCR or cable box (see page 5).
❏ To activate your remote, press (FUNCTION button) to operate your VCR or
(FUNCTION button) to operate your cable box. In order to do this, first program your
remote control, then use the Channel Fix feature to set your TV to channel 3 or 4 (see page
41
).
❏ Press repeatedly to switch between VCR input (VIDEO input), VHF/UHF (local
channels or unscrambled), or cable box (cable system or scrambled channels).
15
Connections
Connecting a TV and Satellite Receiver
1 Connect the cable from your satellite antenna to SATELLITE IN on your satellite receiver.
2 Connect the coaxial cable from your cable service or antenna to the VHF/UHF jack on
your TV.
3 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your satellite
receiver to AUDIO/VIDEO IN on your TV.
Using your TV with this connection
❏ Program your Sony remote control to operate your satellite receiver (see page 5).
❏ To activate your remote, press (FUNCTION button) to operate your satellite
receiver. See page 7 for instructions on how to operate other functions.
❏ Press repeatedly to switch to satellite receiver input (VIDEO input).
1
3
4
VIDEO
L L
(MONO)
R
S VIDEO
Y
PB
PR
5
L
R
L
R
Y
B
P
P
R
VIDEO 1
VIDEO 2
VIDEO 1
VIDEO 2
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
Satellite receiver
Satellite
antenna
cable
1
2
3
From
cable/
antenna
Audio R (red)
Video (yellow)
Audio L (white)
Rear of TV
16
Connections
Connecting a TV, VCR, Cable/Antenna, and Satellite Receiver
using Composite Video (VIDEO/AUDIO L(MONO), R)
1 Connect the cable from your satellite antenna to SATELLITE IN on your satellite receiver.
2
Connect the single input jack of the splitter (not supplied) to your incoming cable/antenna
(optional connection to view local channels or broadcast).
3 Using coaxial cables (not supplied), connect the two output jacks of the splitter
(not supplied) to:
a) the IN jack on your satellite receiver
b) the VHF/UHF jack on the TV
4 Using a coaxial cable (not supplied), connect the OUT jack on your satellite receiver to the
VHF/UHF IN on your VCR.
5 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your VCR to
AUDIO/VIDEO IN on your TV.
6 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your satellite
receiver to AUDIO/VIDEO IN on your TV.
Using your TV with this connection
❏
Program your Sony remote control to operate your VCR or satellite receiver (
see page 5
).
❏ To activate your remote, press (FUNCTION button) to operate your VCR or
(FUNCTION button) to operate your satellite receiver.
❏ Press repeatedly to switch between VCR input (VIDEO input), VHF/UHF
(local channels or unscrambled), or your cable box (cable system or scrambled channels).
1
3
4
VIDEO
L L
(MONO)
R
S VIDEO
Y
PB
PR
5
VIDEO
LINE
OUT
AUDIO L AUDIO R
LINE
IN
L
R
L
R
Y
B
P
P
R
VIDEO 1
VIDEO 2
VIDEO 1
VIDEO 2
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
Satellite receiver
1
2
Satellite antenna
cable
VCR
4
5
6
3b
3a
Splitter
From
cable or
antenna
Rear of TV
Video (yellow)
Audio R (red)
Audio L (white)
For Viewing
For Recording
For Playback
For Viewing
Optional
17
Connections
Connecting a TV, VCR, and Satellite Receiver using Component Video
(Y, PB, PR)
1 Connect the coaxial cable from your satellite antenna to SATELLITE IN on the satellite
receiver.
2 Connect the coaxial cable from your cable service or antenna to the IN jack on your VCR.
3 Using a coaxial cables (not supplied), connect the OUT jack on your VCR to the
VHF/UHF jack on your TV.
4 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your satellite
receiver to AUDIO/VIDEO IN on your VCR.
5 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your VCR to
AUDIO/VIDEO IN on your TV.
6 Using component video cables (not supplied), connect Y, PB, PR OUT on your satellite
receiver to Y, P
B, PR IN on your TV.
7 Connect AUDIO OUT on your satellite receiver to AUDIO IN on your TV.
Using your TV with this connection
❏
Program your Sony remote control to operate your VCR or satellite receiver (
see page 5
).
❏ Turn on your VCR to enable your satellite receiver to work with this connection.
❏ To activate your remote, press (FUNCTION button) to operate your VCR or
(FUNCTION button) to operate your satellite receiver.
❏ Press repeatedly to switch between VCR input (VIDEO input), VHF/UHF
(local channels or unscrambled), or your cable box (cable system or scrambled channels).
1
3
4
VIDEO
L L
(MONO)
R
S VIDEO
Y
PB
PR
5
VIDEO 1
VIDEO 2
L
R
L
R
Y
B
P
P
R
VIDEO 1
VIDEO 2
VIDEO
LINE
IN
LINE
OUT
AUDIO L AUDIO P
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
4
2
From
cable/
antenna
VCR
Rear of TV
3
5
7
6
1
Video (yellow)
Audio L (white)
Audio R (red)
Audio L
Audio R
Satellite
Receiver
P
R
(red)
P
B
(blue)
Y (green)
(red)
(white)
18
Connections
Connecting a DVD Player using Composite Video (VIDEO/AUDIO L(MONO),R)
Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on your DVD player
to AUDIO/VIDEO IN on your TV.
Optional connection
❏ For better picture quality, use S VIDEO instead of the yellow video cable. S VIDEO does
not provide sound, so you still must connect the audio cables.
Connecting a DVD Player using Component Video (Y, PB, PR/R, L)
If your DVD player is equipped with component video outputs (Y, PB, PR), you can improve
the picture quality by using component video cables (480i only).
1 Make sure your DVD player is set up (see page 51). Using component video cables (not
supplied), connect Y, P
B, PR OUT on your DVD player to Y, PB, PR IN on your TV.
2 Connect AUDIO OUT on your DVD player to AUDIO IN on your TV.
Using your TV with this connection
❏ Program your Sony remote control to operate your DVD (see page 5).
❏ To activate your remote, press (FUNCTION button) to operate your DVD.
❏ Press repeatedly to switch to the DVD player's input (VIDEO input).
✍ The Y, PB, PR outputs on your DVD player are sometimes labeled Y, CB, and CR or Y, B-Y, and R-Y. If so,
connect the cables to like colors.
1
3
4
VIDEO
L L
(MONO)
R
S VIDEO
Y
PB
PR
5
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
Rear of TV
Rear of DVD Player
Audio R (red)
Audio L (white)
Video (yellow)
Optional connection
1
3
4
VIDEO
L
(MONO)
R
S VIDEO
Y
PB
PR
5
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
Rear of DVD Player
2
1
Rear of TV
Audio L (white)
Audio R (red)
P
R
(red)
P
B
(blue)
Y (green)
19
Connections
Connecting an Audio System
1 Using audio/video cables (not supplied), connect AUDIO OUT on your TV to one of the
unused line inputs (e.g. TV, AUX, TAPE2) on your stereo.
2
Set the Speaker option to Off. For more instructions, see “Using the Audio Menu” on
page 39.
3 After you connect the audio system, you can control the volume level from your TV or
audio system.
❏ To control the volume from the TV, use the front panel controls or the VOL +/- buttons on
the remote.
❏ To control the volume through the connected audio system, open the Audio Out option on
the Audio Menu and select Fixed. For more instructions,
see “Using the Audio Menu” on
page 39.
Connecting a Camcorder (for playback)
To connect your camcorder, you can use the Audio/Video inputs on either the front or rear
panel of the TV. Using the audio/video cables (not supplied), connect AUDIO/VIDEO OUT
on your camcorder to AUDIO/VIDEO IN on your TV.
✍ If you are connecting a Home Theater, please refer to your Home Theater manual for additional
connections.
1
3
4
VIDEO
L L
(MONO)
R
S VIDEO
Y
PB
PR
5
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
Rear of TV
AUDIO-L (white)
AUDIO-R (red)
Line
input
A/V output
Audio R (red)
Audio L (white)
Video (yellow)
Front A/V Panel
20
Connections
Connecting for Video Tape Editing (VCR and Camcorder)
1 For video tape editing, connect the VCR to the following sources:
❏ If you are connecting a VCR, use audio/video cables (not supplied) to connect
AUDIO/VIDEO OUT on your first VCR to AUDIO/VIDEO IN on your second VCR
(option 1a).
❏ If you are connecting a camcorder, use audio/video cables (not supplied) to connect
AUDIO/VIDEO OUT on your camcorder to AUDIO/VIDEO IN on your VCR
(option 1b).
2 Using audio/video cables (not supplied), connect AUDIO/VIDEO OUT on the second
VCR to AUDIO/VIDEO IN on your TV.
Using your TV with this connection
❏
Program your Sony remote control to operate your VCR (
see page 5
).
❏ To activate your remote, press (FUNCTION button) to operate your VCR. See page 7
for instructions on how to operate other functions.
1
3
4
VIDEO
L
(MONO)
R
S VIDEO
Y
PB
PR
5
VIDEO
LINE
IN
LINE
OUT
AUDIO L AUDIO RVIDEO
LINE
IN
LINE
OUT
AUDIO L AUDIO R
AUDIO OUT
(VAR/FIX)
L
R
(MONO)
Rear of TV
Video (yellow)
Audio L (white)
Audio R (red)
2
1a
1b
A/V output
Camcorder
(for playback)
VCR (for recording)
VCR (for playback)
or
21
Basic Functions
Using Basic Functions
Setting Up the TV
After you have finished connecting your TV, you can use Auto Program to set up your
channels. During Auto Program, the TV will automatically search for available channels and
program receivable channels.
1 Press to turn on the TV. The Initial Setup screen appears.
2 Press on the remote control or on the TV front panel to start Auto Program, or press
to exit.
To perform Auto Program again
1 Press .
2 Press g to highlight Channel Menu.
3 Press f to highlight Cable. Press to select.
4 Press F or f to highlight On or Off according to how you connected your TV. Press to
select.
5 Press f to highlight Auto Program. Press to search for channels.
6 After Auto Program finishes, press to exit.
To reset the TV to factory settings
1 Turn the TV on.
2 Hold down on the remote control.
3 Press and release the POWER button on the TV front panel. The TV will turn itself off,
then back on.
4 Release .
✍ When you start Auto Program wait until it is finished; otherwise it will skip over channels that are
available. Perform Auto Program again to program receivable channels.
✍ The Initial Setup screen appears each time you turn on the TV until you perform Auto Program.
Initial Setup
First please connect
cable/antenna
Auto Program
[CH+]
[CH–]
Exit
22
Basic Functions
Quick Start to the Menus
The following settings are available in your on-screen menus. For more details on how to use
the menus, see “Using the Menus” on page 37.
Menu Allows you to
Adjust your picture settings.
Change your audio settings.
Customize your channel settings.
Set rating limits on your TV based on
program rating or content.
Mode:Vivid
Brightness
Color
Hue
Sharpness
C
olor
Temp:Cool
Video
ClearEdge
VM:High
Move Select End
Treble
Balance
Steady Sound:Off
Effect:WOW
MTS:Stereo
Speaker:On
Bass
Audio
Audio Out:Fixed
Move Select End
Favorite Channels
Channel Fix:Off
Auto Program
Channel Skip/Add
Channel Label
Cable:On
Channel Setup
Move Select End
Password:
Parental Control
Move Select End
23
Basic Functions
Set the clock on your TV and program
scheduled viewing using Timer 1 and Timer 2.
Select closed captioning options (Caption
Vision), display the name of the current
program and its remaining time (Info Banner),
label video inputs, adjust tilt correction,
enhance DVD picture resolution (16:9
Enhanced), or select menu language.
Menu Allows you to
Timer 1:Set
Current Time
Timer 2:Set
Timer
Move Select End
Caption Vision:Off
Info Banner:Off
Setup
Video Label
Tilt Correction
Language:English
16:9 Enhanced:Off
Move Select End
25
Memory Stick
Using the Memory Stick Viewer
About Memory Stick
Memory Stick (sold separately) is a new, compact, portable, and versatile Integrated Circuit
recording medium with a data capacity that exceeds that of a floppy disk. Memory Stick is
specially designed for sharing digital data among Memory Stick compatible products such as
digital cameras and digital video cameras. Because it is removable, Memory Stick can also be
used for external data storage.
The Memory Stick Viewer on your TV allows you to view digital photos (JPEG files) that are
stored on Memory Stick media.
You can also play slide show background music using MP3 files stored on your Memory Stick.
Features
With the Memory Stick Viewer, you can:
❏ View photo (JPEG) files in a thumbnail index or Slide Show
❏ Set customized Slide Show options, including background audio
❏ Lock (protect) or delete files on the Memory Stick
Memory Stick Compatibility
This television is compatible with the following Memory Stick media types:
❏ Memory MagicGate
❏ Memory Stick Media
❏ Memory Stick Duo Media
❏ Memory Stick PRO Media
❏ Memory Stick PRO Duo Media
❏ Memory Stick Media with Memory Select Function
✍ Memory Stick Viewer only supports 128 Kbps fixed rate MP3 files.
✍ For more information about handling Memory Stick media, see “Notes on Using Memory Stick
Media” on page 35.
✍ The Memory Stick slot on your TV has been designed to accommodate standard and compact
versions of Memory Stick. It is not necessary to use an adapter for Memory Stick Duo and Memory
Stick PRO Duo. If you use an adapter it may damage the adapter and Memory Stick slot.
26
Memory Stick
About Memory Stick PRO Media
Memory Stick PRO media features vary by and are dependent upon the design of host hard-
ware devices. Memory Stick PRO in this television has been tested to support up to 1 GB
media capacity and does not support high-speed transfer, MagicGate copyright protection
technology, or access control security features.
Memory Stick Functionality
Sony cannot guarantee or assure the Memory Stick functionality on this television in the fol-
lowing cases:
❏ You are using non-Sony brand Memory Stick media.
❏ You are using audio clips that have been processed on a computer.
❏ You are using files that were modified on a computer, obtained from the internet, or from
a printed film processing center.
❏ The Memory Stick has been formatted on a personal computer.
Sony recommends that you back up all data stored on Memory Stick media prior to use with
the TV’s Memory Stick Viewer, to avoid any potential data loss. Sony cannot accept responsi-
bility in the event that data recorded to Memory Stick media is lost or damaged. For certain
non-Sony brand Memory Stick media, you can view images, but you cannot rotate, delete or
protect/unprotect images on the television. This is a result of the unique file directory struc-
ture on these particular flash memory media and is not malfunction of the television.
File Compatibility
The Memory Stick Viewer is compatible with JPEG images taken with Sony digital still
cameras. In order to be viewable in the Memory Stick Viewer, the files must have the
following file name extensions:
Trademark Information
Memory Stick, Memory Stick PRO, Memory Stick Duo, Memory Stick PRO Duo and
MagicGate are trademarks of Sony Corporation.
File Type Supported File Name Extensions
JPEG .jpg
.jpeg
27
Memory Stick
Inserting and Removing a Memory Stick
Inserting a Memory Stick
Locate the Memory Stick slot and insert the Memory Stick into the Memory Stick slot as
illustrated below. When inserted properly, it should slide in with little resistance and click into
place.
To remove the Memory Stick, see “Removing a Memory Stick” on page 28.
✍ The Memory Stick slot on your TV has been designed to accommodate standard and compact
versions of Memory Stick. It is not necessary to use an adapter for Memory Stick Duo and Memory
Stick PRO Duo. If you use an adapter it may damage the adapter and Memory Stick slot.
✍ Be sure to insert the Memory Stick in the correct direction. If the Memory Stick is forced in the wrong
way, it may become damaged.
Insert only Memory Stick media into the Memory Stick slot. Attempting to insert other objects into
the slot may damage the TV.
STD/DUO
STD/DUO
Memory Stick Slot
Indicator light
Label side
28
Memory Stick
Removing a Memory Stick
To remove a Memory Stick
1 Check that the Memory Stick indicator light is off. When the light is on, this indicates that
the TV is reading data from the Memory Stick.
2 Push the Memory Stick gently into the slot, and then release it. The Memory Stick media is
ejected.
3 Pull the Memory Stick completely out of the slot.
✍ Removing the Memory Stick while a file is being accessed (when the Memory Stick indicator light on
the TV’s front panel is lit) may damage the Memory Stick or its contents.
✍ Do not pull out the Memory Stick without first pushing it in; otherwise, the TV’s locking mechanism
may become damaged.
✍ To protect small children from injury from Memory Stick media, remove all Memory Stick media from
the TV’s Memory Stick slot and store it in a safe location when it is not in use.
29
Memory Stick
Using the Memory Stick Index
Turn on the TV and insert a Memory Stick that contains the photo files you want to view. For
details, see page 27.
The Memory Stick Index appears and displays thumbnail images of the files stored on the
Memory Stick.
About the Lock Icons on the Thumbnail Images
About caution displays
✍ If the Memory Stick Index does not appear, press the MEMORY STICK button on the remote control.
Indicates the thumbnail is locked. Locked files cannot be changed or deleted. For
details, see “Protect“ on page 32.
Indicates the thumbnail (JPEG file) is not valid.
Indicates the thumbnail (JPEG file) is unreadable (full screen picture does not decode
properly).
Thumbnails of photos
Memory Stick menu bar
Highlighted thumbnail
30
Memory Stick
Using the Memory Stick Index
The following describes how to use the Memory Stick Index.
To Do This ... Do This ...
Move the highlight to a
photo thumbnail
Use the arrow buttons (
F, f, g, G).
Display the highlighted
photo file full screen
Press . For details, see “Viewing Photos” on page 31 and
“Memory Stick Index Menu Bar Options” on page 33.
Display the next page of
thumbnails
1 Use the
f button to select V.
2 Use the
f button to display the next page of thumbnails.
Display the previous or
next page of thumbnails
1 Use the
f button to select V.
2 Use the
G button to select .
3 To go to the previous page, press the
F button.
To go to the next page, press the
f button.
Use the Memory Stick
menu bar to access
additional options
1 Use the f button to select V.
2 Use the
G or g buttons to select Slide Show, Contents or
Memory Stick.
3 Use the
F or f buttons to select the option you want to
change.
For details on these options, see “Memory Stick Index Menu
Bar Options” on page 33.
Move the highlight from
the Memory Stick menu
bar back to the
thumbnails
1 Use the
G or g buttons to select V.
2 Use the
F button to return to the currently displayed
thumbnails, or
f button to display the next page of
thumbnails.
Exit Memory Stick
Viewer
Press the MEMORY STICK button on the remote control.
Y
31
Memory Stick
Viewing Photos
When you select a photo from the Memory Stick Index (described on page 29), it appears as
shown below, with the following controls.
Photo Controls
✍ JPEGs captured using a digital video camera may appear to display motion in full screen. This is a
result of the way digital video cameras record still images, and is not a result of a TV malfunction.
✍ When the menu is hidden, use the arrow buttons G or g to go to the previous or next photo.
To Do This ... Do This ...
Display the next or previous file
on the Memory Stick
Use the arrow buttons (F, f, g, G) to highlight the
(Previous/Next) button. Then press the
G button to go to
the previous file, or the
g button to go to the next file.
Hide the Photo menu bar,
displaying only the photo
With the highlight in the Photo menu bar, press the f
button.
Display the hidden Photo menu
bar
Press the
F button.
Display the Memory Stick Index
again
Use the arrow buttons (
F, f, g, G) to highlight Index in
the Photo menu bar and press .
For details on the Memory Stick Index, see page 29.
Access additional options in the
Photo menu bar
See “Photo Menu Bar Options” on page 32.
Exit Memory Stick Viewer Press the MEMORY STICK button on the remote control.
Photo menu bar
Information about
selected photo
Selected photo
Previous/next buttons
32
Memory Stick
Photo Menu Bar Options
The Photo menu bar lets you access additional photo viewing options.
To access the Photo menu bar
1 Use the G or g buttons to select Slide Show, View, or File.
2 Use the arrow buttons (F, f, g, G) to select the desired option.
Using Rotate
To rotate a photo
1 In the Photo menu bar, use the arrow buttons (F, f, g, G) to highlight View and press
.
2 Use the arrow buttons (F, f, g, G) to highlight Rotate and press .
3 To rotate clockwise, use the arrow buttons (F, f, g, G) to highlight Clockwise and press
.
To rotate counterclockwise, use the arrow buttons (
F, f, g, G) to highlight
Counterclockwise and press .
Option Description
Index Displays the Memory Stick Index, with the highlight on the thumbnail of
the currently displayed photo. For details, see “Using the Memory Stick
Index” on page 29.
Slide Show Displays the Slide Show menu. For details, see “Slide Show Menu Options”
on page 33.
View Rotate Allows you to rotate the photo in 90 degree increments
clockwise or counterclockwise. For details, see “Using
Rotate” on page 32.
File Protect Allows you to the protect the JPEG file from any
changes. When a JPEG file is protected, it cannot be
rotated or deleted. Select On or Off.
✍ JPEG files that are protected are indicated by the Lock icon.
Delete Deletes the JPEG file from the Memory Stick.You cannot
delete a JPEG file if it has been protected or the Memory
Stick is locked. Select OK or Cancel.
✍ The photo rotates 90 degrees each time you press .
33
Memory Stick
Memory Stick Index Menu Bar Options
Slide Show Menu Options
The Slide Show menu includes the following options:
Option Description
Start Starts the slide show.
✍ The Slide Show menu is the same whether you select it from the Memory Stick Index (page 29), or
Photo (page 32) menus.
Music Allows you to select background audio to play during the Slide Show.
Off No additional background audio is played during the Slide Show.
Audio that is associated with the JPEG files will play.
Play
Memory
Stick
Play all MP3 files currently listed in your screen; select Complete
List to display MP3 files stored within folders on Memory Stick.
The Piano (Built-in music) MP3 file will not be played.
Piano
(Built-in
music)
Plays the MP3 file stored in the TV’s internal memory.
Complete
List
Displays a list of all available MP3 files found on your Memory
Stick. The list is sorted in alphabetical order.
✍ When you select Complete List, it may take a moment to display the list of all MP3 files.
Slide
Advance
Advances the slide after a selected time interval.
Fast Slide advances after about 3 seconds.
Medium Slide advances after about 6 seconds.
Slow Slide advances after about 12 seconds.
Manual
advance
Slide advances only after you press
G or g.
✍ Some JPEG files may take longer to display than others, lengthening the interval between slides.
File
I
nformation
Determines whether file information is displayed. Select On or Off.
Repeat On Slide Show continuously loops.
Off Slide Show plays once through all files and ends.
34
Memory Stick
Contents Menu Options
The Folder menu includes the following options:
Memory Stick Menu
The Memory Stick menu displays the current status of the Memory Stick, including total
capacity, used capacity, and free capacity.
Option Description
Select Folder Allows you to select different folders to view in the Memory Stick Viewer.
Digital
Camera
Folders
Selects all folders within the directories defined by the
DCF rules used by Sony digital cameras (see page 35).
JPEG files in those directories are recognized even if they
do not conform to the DCF file naming rules.
Select a
Folder
Allows you to access individual folders on the Memory
Stick.
File Order Allows you to change the order in which the Memory Stick files are
displayed.
Date Order Displays files in chronological order by modification
date.
✍ The Rotate and Protect functions do not change the file’s modification date.
Date Order
Reverse
Displays files in reverse chronological order by
modification date.
Alphabetical Displays files in alphabetical order by file name.
35
Memory Stick
Notes on Using Memory Stick Media
About DCF File Names
Most Sony brand digital still and video cameras automatically record still photo and movie
files using DCF-compliant directory and file names.
If you selected the Digital Camera Folders option, as described on page 34, you might want
to have your digital camera’s instruction manual handy in order to check how files and
directories are organized for your specific model of digital camera.
DCF stands for “Design Rules for Camera File Systems,” which are specifications established
by the Japan Electronic Industry Development Association (JEIDA).
Memory Stick Precautions
When using Memory Stick media, follow these precautions:
❏ To avoid permanent damage to still image data, do not turn off the TV or remove Memory
Stick media from the insertion slot while data is being read (as indicated by the Memory
Stick indicator light being on).
❏ Avoid touching the terminal of Memory Stick media or bringing it into contact with a
metal object.
❏ Do not drop, bend, or submit Memory Stick media to external shock.
❏ Do not disassemble or modify Memory Stick media.
❏ Avoid getting liquid on Memory Stick media.
❏ Apply labels only within the designated label area.
❏ To avoid permanent damage to still image data, do not use or store Memory Stick media
in a location subject to:
❏ High temperature (such as near a heater or inside a hot car)
❏ High humidity
❏ Direct sunlight
❏ Corrosive substances
❏ Magnetic fields
❏ Excessive dust
❏ Static electricity or electric noise
❏ Electric surges
❏ Store and carry Memory Stick media in its original case to ensure protection of stored
data.
❏ Save a backup of stored data.
✍ The Memory Stick slot on your TV has been designed to accommodate standard and compact
versions of Memory Stick. It is not necessary to use an adapter for Memory Stick Duo and Memory
Stick PRO Duo. If you use an adapter it may damage the adapter and Memory Stick slot.
Label Area
37
Menus
Using the Menus
This section shows the options available for setting up and adjusting the TV.
Using the Remote Control to Navigate the On-Screen Menus
To navigate on the on-screen menus, use the arrow buttons (
F , f , G , g) to move the cursor.
Pressing these arrows will cause the cursor to move in the corresponding direction. Press the
center button (
) to select an option.
How to Access Menus
To Access Menus
1 Press to display the on-screen menu.
2 Use the G or g buttons to highlight the desired menu icon. Press to select it.
3 Use the F or f buttons to scroll up and down through the features.
4 Follow the instructions on the screen.
5
For instructions on using a specific menu, see the page in this section that talks about that menu.
6 Press to exit the menu.
✍ Press once to display the on-screen menu, and press again to return to normal viewing. If no
buttons are pressed, the menu closes automatically after about 90 seconds.
Move
Select
38
Menus
Using the Video Menu
Mode
Customized
picture viewing
Use the F or f buttons to highlight one of the following options, then
press to select it.
Vivid: Select for enhanced picture contrast and sharpness.
Standard:
Select for a standard picture.
Movie:
Select for a finely detailed picture.
Pro:
Select for natural picture and sharpness.
Press G to decrease the contrast. Press g to increase the contrast.
Brightness
Press G to darken the picture. Press g to brighten the picture.
Color
Press G to decrease color saturation. Press g to increase color saturation.
Hue
Press G to increase the red tones. Press g to increase the green tones.
Sharpness
Press G to soften the picture. Press g to sharpen the picture.
Color Temp.
White tint
adjustment
Use the F or f buttons to highlight one of the following options, then
press to select it.
Cool: Gives white colors a blue tint.
Neutral: Gives white colors a neutral tint.
Warm: Gives white colors a red tint.
ClearEdge
VM
Sharpens picture definition to give objects a crisp, clean edge. Use the
F
or f buttons to highlight High, Low, or Off, then press to select it.
Mode:Vivid
Brightness
Color
Hue
Sharpness
C
olor
Temp:Cool
Video
ClearEdge
VM:High
Move Select End
To Display To Select
To access the Video menu, use the following steps:
Press
f to highlight an option, then press .
✍ Press on the remote control for direct access to the picture modes (Vivid, Standard, Movie, Pro).
39
Menus
Using the Audio Menu
Treble Press G to
decrease the higher pitched sounds. Press
g to increase the
higher pitched sounds.
Bass Press
G to decrease the lower pitched sounds. Press g to increase the
lower pitched sounds.
Balance Press
G to
emphasize the left speaker. Press
g to emphasize the right
speaker.
Steady Sound
Stabilizes
volume
Use the F or f buttons to highlight one of the following options, then
press
to select it.
On: Select to stabilize the volume when changing channels.
Off: Select to turn Steady Sound off.
Effect Use the
F or f buttons to highlight one of the following options, then
press
to select it.
Simulated: Simulates theater-quality sound for mono programs.
SRS: Produces a dynamic three-dimensional sound for stereo
programs.
WOW: Provides a dramatic presence with a full, deep bass
sound. When WOW is enabled, BBE is directly activated
to further enhance the audio performance.
Off: Normal stereo or mono reception.
Treble
Balance
Steady Sound:Off
Effect:WOW
MTS:Stereo
Speaker:On
Bass
Audio
Audio Out:Fixed
Move Select End
To access the Audio menu, use the following steps:
To Display To Highlight To Select
Press f to highlight an option, then press .
✍ Press to directly select Effect settings (Simulated, SRS, WOW, Off).
40
Menus
MTS
Multi-Channel
TV Sound
Use the F or f buttons to highlight one of the following options, then
press
to select it.
Stereo: Select when viewing a broadcast in stereo.
Auto SAP: Select to have the TV automatically switch to a Second
Audio Program (SAP) when a signal is received.
Mono: Select to reduce noise in areas of poor reception.
Speaker
Custom
selection of
audio output
source
Use the F or f buttons to highlight one of the following options, then
press
to select it.
On: Select to listen to the sound from the TV speakers with or
without a separate stereo system.
Off: Select to turn off the TV speakers and listen to the TV’s sound
only through external audio system speakers.
Audio Out
Use to control
the TV’s volume
through a stereo
Use the F or f buttons to highlight one of the following options, then
press
to select it.
Variable: Adjust the volume through your TV.
Fixed: Adjust the volume through a connected stereo.
✍ Press to directly select MTS settings (Stereo, Auto SAP, Mono).
✍ If your TV is set to Auto SAP, some programs may be muted or distorted. If your TV does not output
sound, change your Audio MTS setting to Stereo or Mono.
✍ You can only set Audio Out settings when you have set Speaker to Off.
41
Menus
Using the Channel Setup Menu
Favorite
Channels
Quick access
to favorite
channels
1 Use the F or f buttons to highlight the position (1-5) where you want
to set a favorite channel, then press .
2 Use the
F or f buttons to find the channel you want to add to your
favorite channels.
3 Press to select the channel. The TV will automatically change to
the selected channel and assign it to the selected position (1-5).
4 Press
G to return to the Channel Setup menu or press to exit.
Cable Use the
F or f buttons to highlight one of the following options, then press
to select it.
On: Select if you are receiving cable channels with a CATV cable.
Off: Select if you are using a TV antenna.
Channel Fix Use the
F or f buttons to highlight one of the following options, then
press to select it.
Off:
Channel Fix is not set.
2-6: Select when you want to control all channel selection through
a cable box or VCR. Select the appropriate channel (usually 3
or 4) and use the cable box’s or VCR’s remote control for
channel selection.
Video 1: Select from available video inputs when you have connected
video equipment (e.g., a satellite receiver) and you want your
TV fixed to it.
Favorite Channels
Channel Fix:Off
Auto Program
Channel Skip/Add
Channel Label
Cable:On
Channel Setup
Move Select End
To access the Channel Setup menu, use the
following steps:
To Display To Highlight To Select
Press f to highlight an option, then press .
✍ To use Favorite Channels, exit all menus and press . Press F or f to move the cursor to the
desired channel number and press .
✍ After changing your cable settings, you will need to perform Auto Program. See “To perform Auto
Program again” on page 21.
✍
You cannot use Favorite Channels, Cable, Channel Skip/Add, or Channel Label when Channel Fix is set.
42
Menus
Auto Program Perform Auto Program whenever setting up your TV.
Auto Program will search for available channels and program receivable
channels.
Channel
Skip/Add
Use this feature after you run Auto Program to skip unwanted channels or
add new ones.
1 Use the
F or f buttons to highlight the position of the desired channel,
then press .
2 Use the
F or f buttons to highlight Skip or Add, then press .
3 Press
G to return to the Channel Setup menu or press to exit.
Channel
Label
Label up to 40
channels with
their call letters
1 Press , then use the F or f buttons until you reach the desired
channel number.
2 Press to activate the channel.
3 Press
f to highlight Label, then press . Use the F or f buttons to
display the first call letter or number of the label. Press to select.
Repeat this process until you finish selecting all the call letters.
4 When finished, press to activate.
5 Press
G to return to the Channel Setup menu or press to exit.
✍ Press CH + or CH - to skip over channels that have been skipped. You can still use the --9 buttons
to directly tune to skipped channels.
43
Menus
Using the Parental Control Menu
The Parental Control feature helps parents monitor what their children watch on television.
To use the Parental Control Menu
When you select the Parental Control menu, you are prompted to set a 4-digit password. You
cannot access the Parental Control menu settings without this password.
1 Use the buttons to enter a 4-digit password.
2 Confirm your password by entering it again.
✍ Keep this manual in a safe place. You need your password for any future access to the Parental
Control menu. If you forget your password, see page 51.
To access the Parental Control menu, use the following steps:
To Display To Highlight To Select
Password:
Parental Control
Move Select End
Use [0-9] buttons to
enter new password
0 9
44
Menus
Parental Control
Setting the Rating
You can change the Rating by selecting one of the Parental Lock options.
1 With Lock highlighted, press .
If you are not familiar with Parental Guideline rating system, use one of the following preset
categories to simplify the rating selection: Child, Youth, Young Adult.
2 Use the F or f to highlight the desired rating and press .
Changing your Password
1 Use the F or f buttons to highlight Change Password and press .
2 Follow steps 1 and 2 for “Using the Parental Control Menu” on page 43.
Select a Country
Select U.S.A. to use US ratings (see pages 46-47) or select Canada to use Canadian ratings (see
page 48). If you select a Country (U.S. or Canada) that is not where you live, the rating you
select will not be activated.
1 Press f to highlight Country, then press .
2 Use the F or f to highlight the desired country and press .
Country:U.S.A.
Change Password
Parental Control
Lock:Off
Move Select End
Rating TV will allow a maximum rating of
Off No rating limit
Child TV-Y, TV-G , G (U.S.), G , C (Canada)
Youth TV-PG , PG (U.S.), 8 ans + (Canada)
Young Adult TV-14, PG-13 (U.S.), 14+ (Canada)
Custom Select to set more restrictive ratings (see next section)
45
Menus
Information for Parents
To view a program that exceeds the TV rating
❏ Press , then use the buttons to enter your password.
Using the Custom Menu
Follow the instructions on the screen to make your custom settings. Select the country desired
for your TV’s rating limit. For more information, see page 46 (U.S. models) or page 48
(Canadian models).
✍ Entering your password to view a blocked program will temporarily turn Lock to Off. To reactivate
your Lock settings, turn the TV off then back on; the TV will return to the settings that you have
selected.
✍
Once you have blocked a rating or content, all higher ratings or content will be automatically blocked.
0 9
46
Menus
United States: Selecting Custom Rating Options
For the United States, the Custom Rating menu includes the following options: Movie Rating,
TV Rating, and Unrated. (For Canada, see page 48.)
Movie Rating
This system defines the rating levels of movies shown in theaters and on prime cable
channels.
TV Rating
The TV rating is divided into two groups: age-based and content-based.
✍ The content ratings increase depending on the level of the age-based rating. For example, a program
with a TV-PG V (Violence) rating may contain moderate violence, while a TV-14 V (Violence) rating
may contain intense violence.
R:
PG-13:
Movie Rating
Return
PG:
X:
NC-17:
Press to block
G:
Select End
Rating Defined as
G General audience
PG Parental guidance suggested
PG-13 Parents strongly cautioned
R Restricted
NC-17 No one 17 and under admitted
X Adult audience only
TV-PG:
TV-G:
TV Rating
Return
TV-Y7:
TV-MA:
TV-14:
Press to block
TV-Y:
FV
D
D
L
L
S
S
V
V
L
S
V
Select End
Age
Content
A
ge Defined as
T
V-Y All children
T
V-Y7 Directed to older children
T
V-G General audience
T
V-PG Parental guidance
suggested
T
V-14 Parents strongly cautioned
T
V-MA Mature audience only
Content Defined as
FV Fantasy violence
D Suggestive dialogue
L Strong language
S Sexual situations
V Violence
47
Menus
Unrated
You have the option of blocking TV programs or movies that are not rated.
✍ If you choose to block unrated TV programs, please be aware that the following programs may be
blocked: emergency broadcasts, political programs, pro, news, public service announcements,
religious programs, and weather.
Allow Allows all unrated programs
Block Blocks all unrated programs
Custom Rating
Return
TV Rating
Unrated: Allow
Movie Rating
Select End
48
Menus
Canada: Selecting Custom Rating Options
For Canada, the Custom Rating menu includes the following options: English Rating, French
Rating, and U.S.A. Rating.
English Rating
These ratings are for Canadian programs that are broadcast in English.
French Rating
These ratings are for Canadian programs that are broadcast in French.
U.S.A. Rating
For programs from the United States, see “TV Rating” on page 46.
PG:
G:
English Rating
Return
C8+:
18+:
14+:
Press to block
C:
Select End
Rating
Defined as
C Children
C8+ Children 8 years and older
G General programming
PG Parental guidance
14+ Viewers 14 and older
18+ Adult programming
Rating Defined as
G General
8 ans+ Not recommended for
younger children
13 ans+ Not recommended for
children under age 13
16 ans+ Not recommended for ages
under 16
18 ans+ This program is restricted to
adults
16 ans+:
13 ans+:
French Rating
Return
8 ans+:
18 ans+:
Press to block
G:
Select End
49
Menus
Using the Timer Menu
Current Time Set your TV to the current day and time. Press
to open the Current
Time menu:
1
Use the
F
or
f
buttons to enter the correct day and time, then press .
2 Press to exit the menu.
Timer 1 and
Timer 2
Scheduled
viewing
Use the timers to program your TV to turn on and off by day, time,
duration, and channel. The timer duration is a maximum of six hours.
When the channel is fixed, it is not necessary to set the channel.
1 Use the
F or f
buttons
to highlight Timer 1 or Timer 2, then press
.
2 Use the
F or f
buttons
to enter the desired day, start time, duration,
and channel, then press . The timer status should be On when the
Timer has been set, and the timer light on the front panel of the TV
should be on.
3 Press to exit the menu.
✍ When you perform Auto Program, Timer 1 and Timer 2 settings will be cleared. Also, in the event of
any loss of power, Current Time, Timer 1, and Timer 2 settings will be cleared.
Timer 1:Set
Current Time
Timer 2:Set
Timer
Move Select End
To access the Timer menu, use the following steps:
To Display To Highlight To Select
✍ You must set the Current Time before you can use Timer 1 or Timer 2.
✍ Select Off to turn off the Timer. Your previous settings will be saved.
50
Menus
Using the Setup Menu
Caption
Vision
Closed-
Captioning
Allows you to select from three closed-caption modes for programs that are
broadcast with closed captioning.
Use the
F or f
buttons
to highlight one of the following options, then press
to select it.
Off:
Caption Vision is not activated.
CC1, 2, 3, 4:
Displays printed dialogue and sound effects of a program.
Text1, 2, 3, 4:
Displays network/station information.
Info Banner Displays the name of the current program and its remaining time (if
available) when you change the channel or press the DISPLAY button. Use
the
F or f buttons to highlight On, or Off. Then press .
Video Label
Label
connected
equipment
Allows you to identify the video components connected to the TV: VCR,
DVD, etc. When you press TV/VIDEO to switch inputs, the Video Label
appears on-screen.
1 Press the
F or f
buttons
to highlight the input you want to label and
press .
2 Press the
F or f
buttons
to highlight a label and press .
3
Press G to
return to the Setup menu or press
to exit.
Tilt
Correction
Use the
F or f buttons to set the tilt of the picture from –5 to +5, then press
to activate.
Language Display all menus in the language of your choice.
Use the
F or f buttons to select from one of the following options: English,
Español (Spanish) and Français (French). Then press .
16:9
Enhanced
Provides enhanced picture resolution for wide-screen sources such as DVD.
This is only available when the TV is in Video mode.
Caption Vision:Off
Info Banner:Off
Setup
Video Label
Tilt Correction
Language:English
16:9 Enhanced:Off
Move Select End
To access the Setup menu, use the following steps:
To Display To Highlight To Select
Press f to highlight an option, then press .
51
Other Information
Other Information
Troubleshooting
If you have a problem with your TV, try the suggestions below. If the problem persists, see
“Contacting Sony” at the end of this section.
General
Problem Possible Remedies
I want to reset the TV
to the factory
settings
❏ Turn on the TV. While holding down the RESET button on the
remote control, press the POWER button on the TV front panel.
The TV will turn itself off, then back on again. Release the
RESET button.
The TV is dirty
❏ Clean the TV with a soft dry cloth. Never use strong solvents
such as thinner or benzine, which might damage the finish of
the cabinet.
I lost the parental
control password
❏ In the password screen, enter the following master password:
4357. After using the master password, you must create a new
password. You cannot use the master to unlock currently
blocked channels.
There is a black box
on the screen
❏ You have selected a text option in the Setup menu (page 50) and
no text is available. To turn off this feature, select Off in the
Caption Vision option. If you were trying to select closed
captioning, select CC1-4 instead of Text1-4.
There was a blackout
or power outage, and
now the TV won't turn
on and the timer LED
is flashing
❏ Press the POWER button on your remote control or on the TV
front panel.
The digital cable box
does not work
❏ If you are connecting a VCR and digital cable box using a
splitter, as described in page 13, you must use a special bi-
directional splitter (5-900 Mhz mininum) that is designed to
work with your digital cable box.
I can’t connect the
DVD player using
component video
outputs (Y, P
B, PR)
❏ You must set up your DVD player before you can connect it
using component video outputs (Y, PB, PR). Disconnect the DVD
player and set it up, referring to the DVD manual for
instructions. Then, connect it to the TV again following the
instructions in “Connecting a DVD Player using Component
Video“ on page 18.
52
Other Information
Remote Control
Programming The Remote Control
Problem Possible Remedies
I cannot operate the
remote control
❏ Press TV (FUNCTION) when operating your TV.
❏ Check the orientation of the batteries.
❏ Batteries could be weak. Replace them (page 2).
❏ Move the TV three to four feet away from fluorescent lights.
I cannot change
channels with the
remote control
❏ Make sure you have not inadvertently switched your TV from
the channel 3 or 4 setting if you are using another device to
change channels.
❏ If you are using another device to control channels, be sure that
you have pressed the FUNCTION button for that device. For
example, if you are using your VCR to control channels, be sure
to press the VCR/DVD FUNCTION button (page 4).
I lost the remote
control
❏ You can use the front panel controls to access your menus,
change channels, adjust the volume, or change video inputs
(page 2). Contact your nearest Sony Dealer to order a
replacement. To find out the nearest dealer please call our Sony
Direct Accessory and Part Center at 1-800-488-7669 (U.S.
residents only).
Problem Possible Remedies
More than one code
is listed
❏ Try entering them one by one until you come to the correct code
for your component.
I entered the wrong
code number
❏ If you enter a new code number, the code number you
previously entered at that setting is erased. To reenter the
correct code number you must reprogram the remote control
(page 5).
I cannot operate a
component with the
remote control
❏ Use the component's own remote control.
When I changed the
batteries, the code
numbers changed
back to the factory
settings
❏ Reprogram the remote control (page 5).
53
Other Information
Video
Audio
Problem Possible Remedies
No picture, no
sound
❏ Make sure the power cord is plugged in.
❏ If a red light flashes on the front of your TV for more than a few
minutes, disconnect and reconnect the power cord. If the
problem continues, call your local service center.
❏ Check the TV/VIDEO setting. When watching TV, set it to TV;
when watching video equipment, set it to VIDEO 1, 2, 3 or 4
(page 4).
❏ Make sure you have inserted the batteries correctly into the
remote control (page 2).
❏ Try another channel to rule out station trouble.
Poor or no picture,
good sound
❏ Adjust the Picture setting in the Video menu (page 38).
❏ Adjust the Brightness setting in the Video menu (page 38).
❏ Check the antenna and/or cable connections (page 10).
No color ❏ Adjust the Color setting in the Video menu (page 38).
Snow on the screen ❏ Check the Cable setting in the Channel menu (page 41).
❏ Check the antenna and/or cable connections (page 10).
❏ Make sure the channel selected is currently broadcasting.
Dotted lines or
stripes
❏ Adjust the antenna.
❏ Move the TV away from other electronic equipment. Some
electronic equipment creates electrical noise, which can interfere
with TV reception.
Double images or
ghosts
❏ Check your outdoor antenna or call your cable service.
Problem Possible Remedies
Good picture, no
sound
❏ Press so that Muting disappears from the screen (page 3).
❏ Check your Audio settings. Your TV may be set to Auto SAP in
the MTS feature (page 39).
❏ Make sure the speaker option is set to On in the Audio Menu.
❏ Press to adjust your TV's volume.
Low or no audio
(TV and cable box)
❏ Some cable boxes have volume level controls. Check and see if
your cable box remote has a volume control.
54
Other Information
Memory Stick
Problem Possible Remedies
Image does not
display/Cannot see
all files
❏ Make sure the image file is a JPEG (.jpg, .jpeg) file.
❏ Make sure the Memory Stick is inserted properly (see page 27).
❏ Check the Select Contents setting (see page 34) and ensure that
files are either in DCF directories if Digital Camera Folders is
selected (see page 34), or in the currently selected folder if Select
a Folder is selected (see page 34).
❏ The maximum number of files the Memory Stick Viewer can
display is 4,000 JPEG files, contained in the maximum of 500
folders.
❏ If you are using a Memory Stick with the Memory Select
function, try changing the position of the A/B select switch.
❏ Some images that were modified on a computer may not
display corrected on the Memory Stick Viewer.
❏ Progressive JPEG files are not supported.
Memory Stick Index
is not visible
❏ Press the Memory Stick button on the remote control.
❏ Reinsert the Memory Stick, confirm that the Memory Stick is
inserted properly (see page 27).
❏ Try a different Memory Stick.
❏ Reset the Memory Stick Viewer by turning the TV off for 5
seconds.
JPEG image displays
undesirable motion
or flicker in full
screen
❏ JPEGs captured using a digital video camera may appear to
display motion in full screen. This is a result of the way digital
video cameras record still images, and is not a result of a
malfunction with the TV.
Rotation not saved
after Memory Stick is
ejected or Memory
Stick Viewer is closed
❏ The Memory Stick might be locked. Unlock the Memory Stick
and try rotating the image again.
❏ The file might not have information (EXIF data) that is usually
generated when a digital camera records a photo. In this case, it
is not possible to save the rotation.
❏ There might be insufficient space on the Memory Stick to save
the rotated file. Try deleting one or more files and rotating the
image again.
Cannot show (or
hide) file information
in full screen or Slide
Show
❏ Set the File Information option to On or Off (see page 33).
Cannot see menu
❏ Move the joystick V to display the menu again.
Cannot hear audio
while using Memory
Stick
❏ Check the TV’s volume or Speaker (page 40) settings.
❏ Check that the Music option is not to set to Off (see page 33).
55
Other Information
Channels
Not all MP3 files on
Memory Stick are
included when the
Music /Complete List
option is selected
(page 33)
❏ The Memory Stick Viewer can support a maximum of 500 MP3
files.
❏ Make sure that the file is named with the file extension (.mp3).
The Slide Show stops
or/and invalid MP3
message shown
❏ The Memory Stick Viewer supports 128 kbps fixed rate encoded
MP3 files. You can try one of the following remedies.
•Select a single MP3 file that has a fixed bit rate of 128 kbps.
•Select Piano (Built-in) or turn Music to Off.
•Delete non-128 kbps fixed rate MP3 files from your Memory
Stick.
❏ The Memory Stick Viewer supports only MP3 files with a fixed
data rate of 128 kbps (kilobits per second).
Cannot see MP3 list
to play music
❏ MP3 files on your Memory Stick only can be played as
background music during a Slide Show (see page 33).
MP3 files on the
Memory Stick are not
listed
❏ Only MP3 files that are named with the file extension (.mp3) are
displayed in the list.
❏ Select Complete List to display files in subfolders.
Error message
is displayed
❏ No Memory Stick There is no Memory Stick in the slot.
❏ Memory Stick is
Locked
The lock mechanism on the Memory
Stick is engaged.
❏ Memory Stick Error The Memory Stick in the slot might be
incompatible or damaged; try a
different Memory Stick.
❏ Format Error The Memory Stick may have been
formatted using a PC or other device
that is not compatible with cameras.
Error icon is
displayed
The file is not a valid JPEG format.
The file is unreadable.
Problem Possible Remedies
I cannot receive
higher number
channels (UHF) when
using an antenna
❏ Make sure Cable is set to Off in the Channel Setup menu
(page 41).
❏ Perform Auto Program to add channels that are not presently in
the memory (page 21).
Problem Possible Remedies
56
Contacting Sony
Before calling our Customer Information Services Center, reset the TV to factory settings (see page 21). Please have
your TV serial number ready. The number is located on the rear of your TV and on the front cover of this manual.
Our Customer Information Services Center phone number is 1-800-222-SONY (7669) (US residents only) or 1-877-899-
SONY (7669) (Canadian residents only).
Cable stations don’t
seem to work
❏ Make sure Cable is set to On in the Channel Setup menu
(page 41).
❏ Perform Auto Program to add channels that are not presently in
the memory (page 21).
Problem Possible Remedies
57
Specifications
For all models (except as noted)
Design and specifications are subject to change without notice.
Television system American TV standard/NTSC
Channel coverage VHF: 2-13/UHF: 14-69/CATV: 1-125
Antenna 75-ohm external antenna terminal for VHF/UHF
Picture tube FD Trinitron
®
tube
Power requirements 120V, 60 Hz
Supplied accessories Size AA (R6) batteries (2)
Remote Control RM-Y196 (1)
Inputs/outputs Inputs 1 video, 1 audio (front) Outputs
2 video, 2 audio (rear) 1 AUDIO OUT
1 S VIDEO
1 RF
2 Y, PB, PR, 2 audio
Optional accessories TV Stand: SU-27F2 for KV-27FS320
SU-32F2 for KV-32FS320
SU-36F2 for KV-36FS320
KV-27FS320
Screen size Visible screen size: 679mm (27 inches) measured diagonally
Actual screen size: 736.6 mm (29 inches) measured diagonally
Speaker output 10 W x 2
Power consumption 180 W
Less than 1 W in standby
Dimensions (W/H/D)
784 x 601.5 x 520 mm (30
7
/
8
x 23
5
/
8
x 20
1
/
2
inches)
Mass 47.4 kg (104 lbs. 8 oz.)
KV-32FS320
Screen size Visible screen size: 803 mm (32 inches) measured diagonally
Actual screen size: 863.6 mm (34 inches) measured diagonally
Speaker output 10 W x 2
Power consumption 190 W
Less than 1 W in standby
Dimensions (W/H/D)
898 x 682 x 584 mm (35
3
/
8
x 26
7
/
8
x 23 inches)
Mass 75.8 kg (167 lbs. 2 oz.)
KV-36FS320
Screen size Visible screen size: 911mm (36 inches) measured diagonally
Actual screen size: 965.2 mm (38 inches) measured diagonally
Speaker output 10 W x 2
Power consumption 190 W
Less than 1 W in standby
Dimensions (W/H/D)
1020 x 760 x 640 mm (40
1
/
8
x 29
7
/
8
x 25
1
/
4
inches)
Mass 101.2 kg (223 lbs. 2 oz.)
59
Index
16:9 Enhanced 50
A
Audio Out 40
Auto Program 21, 42
Auto SAP 40
B
Balance 39
Bass 39
Batteries
Inserting in remote 2
Brightness 38
C
Cable 41
Caption Vision 50
Channel Fix 41
Channel Label 42
Channel Skip/Add 42
ClearEdge VM 38
Color 38
Color Temperature 38
Connections
Cable and antenna
10
Connecting a Camcorder 19
Connecting an Audio System 19
DVD Player using Component Video (Y,
PB, PR/R, L)
18
DVD Player using Composite Video
(VIDEO/AUDIO L(MONO),R)
18
TV and Cable Box 12
TV and Satellite Receiver 15
TV and VCR 11
TV, VCR and Cable Box 13
TV, VCR, and Satellite Receiver using
Component Video (Y, PB, PR)
17
TV, VCR, and Satellite Receiver using
Composite Video (VIDEO/AUDIO
L(MONO), R)
16
Video Tape Editing
(VCR and Camcorder)
20
Current Time 49
D
DISPLAY 4
E
Effect
Off 39
Simulated 39
SRS 39
WOW 39
error messages, Memory Stick 55
F
Favorite Channels 41
Fixed 40
H
Hue 38
I
Info Banner 50
L
Language 50
M
Manufacturer’s Codes 6
Memory Stick
Button
3
DCF 35
Duo 25, 26
Features 25
Index 30
Indicator 27
Inserting 27
Insertion slot 27
MagicGate 25, 26
Media 25, 26
Photo options 32
Precautions 35
PRO 25, 26
PRO Duo 25, 26
Removing 28
Rotating photos 32
Slide show options 33
Troubleshooting 54
Viewer, described 31
Viewing Photos 31
Menus
Audio
39
Channel Setup 41
Parental Control 43
Setup 50
Timer 49
Video 38
Mode
Movie 38
Pro 38
Standard 38
60
Vivid 38
MTS
Auto SAP 40
Mono 40
Stereo 40
P
Parental Control 44
Programming the Remote Control 5
R
Remote Control
Programming
5
S
Setting the Rating
English Rating
48
French Rating 48
Movie Rating 46
TV Rating 46
U.S.A. Rating 48
Unrated 47
Sharpness 38
SLEEP 3
Speaker 40
Specifications 56
Steady Sound 39
T
Tilt Correction 50
Timer 1 and Timer 2 49
Treble 39
Troubleshooting 51
TV Features 1
TV Front Panel 2
TV Rear Panel 9
V
Variable 40
Video Label 50
63
