Features:
• high performance Coyote Burners™
• One infrared rear burner
• One Coyote RapidSear™ infrared burner
• sq. in. cooking area
• Up to 0,000 BTU
•
• Complete 304 stainless steel construction
• Interior grill lighting
• LED illuminated knobs
• Rotisserie kit and smoker box included
• Integrated wind guard
Dimensions:
• Cutout: (H) 10 1/4” X (W) 2 X (D) 20 1/2”
• Overall: (H) 23” X (W) 3” X (D) 25 1/2”
Accessories:
• Laser-Cut Signature Grates (CSIGRATE12)
• Charcoal trays (CCHTRAY12)
• 14” stainless steel griddle (C1GRDL)
• Stainless steel cart (C1S36CT)
• Custom fi t, weather resistant cover
• Insulated jacket
• Gas conversion kit
2
www.coyoteoutdoor.com
DIMENSIONAL RENDERINGS
Model No. Gas Supply BTU's Regulator WC Pressure Max PSI Electrical Requirements
C2SL30LP Propane 70,000
1/2" Female Pipe
11" .5 PSI Qty 1 - 120 VAC 60 Hz Grounded Plug
C2SL30NG Natural Gas 70,000
20 lb Tank Regulator
4" .5 PSI Qty 1 - 120 VAC 60 Hz Grounded Plug
Model No. Height Width Depth
Model No. Height Width Depth
C2SL30
C2SL30
23"
CJAKTCS30
11"
CJAKTCS30
23"
C
utout Dimensions for Island
Overall Product Dimensions
When using a Coyote insulated jacket, you will want to build your island to the jackets Cutout and Overall Dimensions
listed above. Once the jacket is installed, the grill will rest on/inside the insulated jacket
30
3
/4"
20
1
/2"
25
1
/2"
10
1
/4"
11"
32
3
/8"
22
1
/8"
27"
30"
Important Note to Installer This file is not intended to replace your Owners' Manual which contains specific safety
requirements and consumer guidelines. Please refer to your Owners' Manual prior to installing or operating your builtin grill.
C2SL30 PRODUCT SPECS
