INSTALLATION INSTRUCTION
VT-704
WEEE Number: 80133970
INTRODUCTION
Thank you for selec�ng and buying V-TAC LED wall light. V-TAC will serve you the best.
Please read these instruc�ons carefully before star�ng the installa�on and keep this
manual handy for future reference. If you have any other query, please contact our
dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best.
TECHNICAL PARAMETERS
Model No
VT-704
Power
4W
Input Voltage
AC220-240V, 50/60 Hz
Lumens
440lm
Beam Angle
360
°
CRI
>80
Protec�on Ra�ng
IP 20
INSTALLATION REQUIREMENT
• Install only by cer�fied electrician.
• Please connect with the driver properly before connec�ng main supply.
• Proper grounding should be ensured throughout installa�on.
• The ligh�ng should be located in dry area
INSTALLATION INSTRUCTIONS
• Switch off the power.
• Cut appropriate size hove on the wall. Put the rubber plug into the hole. Fix
the bracket on the ceiling with screw.
• Connect the AC wires.
• Install the lamp body into the bracket and �ghten the screw safely and solidly.
In case of any query /issue with the product please reach out to us at [email protected]
