Stereo Headphones
3-289-536-12(1)
Operating Instructions
Manual de instrucciones
© 2008 Sony Corporation Printed in Thailand
MDR-G55LP
English
Features
• Stable and comfortable behind-the-neck design.
• Changeable headphones caps (supplied), in various colors to suit different styles.
• Compact and foldable design for portability.
Specifications
Type: Open air, dynamic
Driver unit: 30 mm, dome type (CCAW adopted)
Power handling capacity: 1,000 mW (IEC*)
Impedance: 24 Ω at 1 kHz
Sensitivity: 105 dB/mW
Frequency response: 16 – 20,000 Hz
Cord: Approx. 1.2 m (47
1
/
4
inches), OFC litz cord
Mass: Approx. 55 g (1.86 oz.) without cord
Plug: Gold plated stereo mini plug
Supplied accessories: 2 pairs of color headphone caps
* IEC = International Electrotechnical Commission
Design and specifications are subject to change without notice.
How to use
Wearing the headphones (see fig. A)
1 Place the neckband with the cord positioned over your left shoulder.
2Wear the headphones with your left ear between the left earpad and neckband, and your right
ear between the right ear pad and neckband.
3 Adjust the angle of the neckband to fit the headphones on your ears.
Folding the headphones (see fig. B)
Fold the headphones toward you as illustrated.
Note
Be careful not to catch your finger as you fold the headphones.
Changing the headphones caps
The right and left caps differ, and are marked R and L accordingly.
1 Slide the headphone caps down (see fig. C-1), and remove it.
2 Attach the 3 claws on the new cap into the slots of the headphones (see fig. C-2).
Confirm that the arrow mark on the cap aligns with the one on the headphone.
3 Slide the headphone caps up to the initial position.
Precautions
• Listening with headphones at high volume may affect your hearing. For traffic safety, do not use
while driving or cycling.
• Do not put weight or pressure on the headphones as it may cause the headphones to deform
during long storage.
• The earpads may deteriorate due to long-term storage or use.
A
B
C
Earpad
Left ear
Headphone
cap
Neckband
1
2
