ICE MACHINES
Quick Reference Guide
Engineered for Ease
Manitowoc has built its reputation on developing
the most innovative and reliable ice solutions for the
foodservice industry. Solutions you’ll nd no where else.
And, with the largest ENERGY STAR
®
portfolio in the
industry,* our ice machines are not only dependable,
they are energy ecient. No one knows ice better than
Manitowoc. That’s why we are America’s number one
selling ice machine.
Our agship ice machines, the Indigo
®
NXT and NEO
®
are no exceptions. Both Indigo NXT and NEO use
modern advancements in technology to simplify
everything we’ve ever known about making ice. Now
your ice machine can tell you what it is doing and
ensure that you have ice when and where you need it.
I need ice.
That’s why I choose
Manitowoc
®
.
*Based on ENERGY STAR qualifying models list February 12, 2020
3
Features like Indigo
NXT and NEO’s
tool-free foodzone,
patented EasyClean,
programmability or
time delay features,
and service messages
or indicators help
ensure that your ice
machine consistently
meets your demand
for ice. Manitowoc
oers one of the largest portfolios of ice machines
in the foodservice industry. Gourmet, dice, half dice,
ake, nugget, and crushed – from 53 lbs (24 kg) of ice
to 3,200 lbs (1,451 kg) – whatever your ice needs are;
we have the solution.
I
c
e
M
a
k
e
r
s
Manitowoc Ice
Indigo NXT, was awarded the 2019
Kitchen Innovations Award from the
Natioanal Restaurant Association.
This prestigious award recognizes
Indigo NXT for its innovation,
eciencies and productivity.
HALF DICE
Hard, clear ice cube
with unique “rhomboid”
shape 3/8" x 1-1/8" x 7/8"
(0.95 x 2.86 x 2.22 cm) in
dimension, 96 cubes per
pound of ice, maximum
cooling with nearly 100% ice
to water ratio.
DICE
Hard, clear ice cube
with unique “rhomboid”
shape 7/8" x 7/8" x 7/8"
(2.22 x 2.22 x 2.22 cm) in
dimension, 48 cubes per
pound of ice, maximum
cooling with nearly 100% ice
to water ratio.
NUGGET
Perfect for chewing
and blended beverages
while dry enough (85%
ice to water ratio) to be
dispensed. 3/8” to 1/2”
(0.95 to 1.27cm) in
width and length
on average.
FLAKE
Small, soft pieces of ice with
a 73% ice to water ratio.
Ideal for food, presentation,
and preservation as well as
hand scooping into drinks.
5
REGULAR
Hard, clear ice cube with
unique “rhomboid” shape
1-1/8" x 1-1/8" x 7/8"
(2.86 x 2.86 x 2.22 cm) in
dimension, 32 cubes per
pound of ice, maximum
cooling with nearly 100% ice
to water ratio.
GOURMET
Hard, clear individual cube
with unique octagon shape
1-3/8” x 1-3/8” (3.49 x 3.49
cm), maximum cooling with
nearly 100% ice to water
ratio.
CRUSHED
Manitowoc dice or half dice
cubes crushed into small
pieces using a Manitowoc
machine and a beverage
dispenser equipped with
icepic
®
ice crusher.
7
The next generation ice machine
NEXT LEVEL OF SIMPLICITY
Indigo NXT takes the guess work out of owning and
operating an ice machine
• User friendly full color icon based easyTouch
®
display
• Convenient Start up wizard to simplify
installation process
• Visual 24/7 ice machine status
• Easy step by step cleaning instructions
• Eortless one touch access to all machine info
• Multi-language display
• One touch service menu
• No worry screen lock
• Automatic detection of accessories
• Simplied ice programing
• Self exploratory reminder notications
• Three handy water settings
NEXT LEVEL OF SANITATION
Indigo NXT are the industries easiest ice machines to clean
and keep clean
• Front facing evaporator on most models
• Cleaning can be done without removing the top or sides of
the machine
• All white interior including water trough
• Alpha San antimicrobial additive in the foodzone to reduce
bacteria growth
• Rounded food zone corners with no exposed tubes or wires
• Tool-less part removal of all internal components including the
water pump
• One button cleaning function automatically returns to making ice
• Industry's only fully integrated optional LuminIce II Virus and Bacteria
Inhibitor
NEXT LEVEL OF ENERGY EFFICIENCY
Indigo NXT are some of the most energy ecient in the market
• Many use highly ecient and environmental refrigerant which have
48% less the global warming potential than industry
standard models
• All models are AHRI certied for performance and energy eciency
• Exceeds stringent DOE 2018 energy standards
• Convenient ice programming to save electricity
• Up to 43% more ecient than our previous standard
• Industry leader in Energy Star 3.0 qualied models
NEXT LEVEL OF RELIABILITY
Indigo NXT are the most reliable ice machines Manitowoc has
ever produced
• More than a half a million hours of testing and validation.
• State of the art reliability methodology and HALT
(Highly Accelerated Life Testing)
• Constant product improvement through 56 years of
ice making experience
9
IT0420
D-320 Bin
IT0620
D-420 Bin
Ice Production* 460 lbs 208 kg 575 lbs 262 kg
Ice Storage Capacity 264 lbs 119 kg 383 lbs 173 kg
Height with Bin 59.50" 151.1 cm 71.50" 181.6 cm
Width 22.00" 55.9 cm 22.00" 55.9 cm
Depth with Bin 34.00" 86.4 cm 34.00" 86.4 cm
22" Wide Cubers
The Indigo NXT series ice machine oers some of the
industries lowest prole ice makers for venues where
real estate is scarce. These slender 22" (56 cm) wide
models produce up to 575 lbs (262) kg, and can be
installed on a variety of bins, hotel dispensers, and
counter top beverage dispensing systems—ensuring
that you have ice no matter the space constraints.
* Half dice pounds produced per day. Approximate ice-making capacity based on air-cooled condenser
unit at 70°F/21°C air and 50°F/10°C water. Ice machine and bin ordered separately.
HALF DICE
REGULAR
DICE
Available on iT0620
IT0300
D-400 Bin
IT0450
D-400 Bin
IT0500
D-400 Bin
IF0600N
D-570 Bin
0.443 IN
IT0750
D-570 Bin
IF0900N
D‑570Bin
IT0900
D‑570Bin
IT1200
D‑570Bin
Ice Production* 310 lbs 141 kg 490 lbs 222 kg 550 lbs 249 kg 655 lbs 292 kg 715 lbs 324 kg 830lbs 376 kg 865lbs 392 kg 1,213 lbs 550 kg
Ice Storage Capacity 365 lbs 166 kg 365 lbs 166 kg 365 lbs 166 kg 532 lbs 241 kg 532 lbs 241 kg 532 lbs 241 kg 532 lbs 241 kg 532 lbs 241 kg
Height with Bin 54.50" 138.4 cm 59.50" 151.1 cm 59.50" 151.1 cm 71.50" 181.6 cm 71.50" 181.6 cm 76.50" 194.3 cm 76.50" 194.3 cm 79.50" 202 cm
Width 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm
Depth with Bin 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm
IT0300 available in April 2020
11
30" Wide Cubers
By far the most popular size ice machine in the
industry— The Indigo NXT 30” (76cm) platform oers
the widest array of daily production, cube types, and
condensing options available on the market today. With
production capacities ranging from 310 lbs (141 kg)
to 1,660 lbs (753 kg), three available cube types, and
condensing options that include air, water, traditional
air remote, and Manitowoc’s patented QuietQube
®
CVD
®
remote technology (see pages 14-17), this series has an
ice machine for just about every situation whether in a
full-service restaurant, a fast-food chain, a convenience
or grocery store, or in the world’s nest hotel. Manitowoc
ensures that you have ice when and where you need it.
IT0300
D-400 Bin
IT0450
D-400 Bin
IT0500
D-400 Bin
IF0600N
D-570 Bin
0.443 IN
IT0750
D-570 Bin
IF0900N
D‑570Bin
IT0900
D‑570Bin
IT1200
D‑570Bin
Ice Production* 310 lbs 141 kg 490 lbs 222 kg 550 lbs 249 kg 655 lbs 292 kg 715 lbs 324 kg 830lbs 376 kg 865lbs 392 kg 1,213 lbs 550 kg
Ice Storage Capacity 365 lbs 166 kg 365 lbs 166 kg 365 lbs 166 kg 532 lbs 241 kg 532 lbs 241 kg 532 lbs 241 kg 532 lbs 241 kg 532 lbs 241 kg
Height with Bin 54.50" 138.4 cm 59.50" 151.1 cm 59.50" 151.1 cm 71.50" 181.6 cm 71.50" 181.6 cm 76.50" 194.3 cm 76.50" 194.3 cm 79.50" 202 cm
Width 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm
Depth with Bin 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm
* Half dice pounds produced per day. Approximate ice-making capacity based on air-cooled condenser unit at 70°F/21°C
air and 50°F/10°C water. Ice machine and bin ordered separately. Ice storage application capacity is measured at 90%
of the total volume in cu. ft x 33lbs/ft3.
HALF DICE
REGULAR
DICE
Available
on
IT0500
and
IT0900
IT1500
D-970 Bin
IT1900
D-970 Bin
ST3000WH
F-1650 Bin
Ice Production*
1,660 lbs 753 kg 1,965 lbs 891 kg 3,200 lbs 1,451 kg
Ice Storage Capacity
882 lbs 400 kg 882 lbs 400 kg 1,494 lbs 678 kg
Height with Bin
79.50" 201.90 cm 79.50" 201.9 cm 99.50" 252.73 cm
Width 48.00" 121.9 cm 48.00" 121.9 cm
48.00" 152.4 cm 60.00” 121.9 cm
WITHOUT BIN WITH BIN
Depth with Bin
34.00" 86.4 cm 34.00" 86.4 cm
31.00" 78.74 cm
SNOUT ADDS 8” / 20 CM
13
Large Capacity Cubers
When you need a lot of ice and space isn’t as big a
concern Manitowoc also has a range of large capacity
cubers that oer daily production rates from 1660 lbs
(752 kg) to 2910lbs (1,320kg). These machines are
popular in fast-food outlets, full-service restaurants,
institutional kitchens, cafeterias, and other large venues
like stadiums and casinos. When you need ice, and you
need a lot of it Manitowoc has your solution.
* Half dice pounds produced per day. Approximate ice-making capacity based on air-cooled condenser unit at 70°F/21°C air
and 50°F/10°C water. Ice machine and bin ordered separately.
Ice storage application capacity is measured at 90% of the total volume in cu. ft x 33lbs/ft3.
HALF DICE
DICE
IT1500
D-970 Bin
IT1900
D-970 Bin
ST3000WH
F-1650 Bin
Ice Production*
1,660 lbs 753 kg 1,965 lbs 891 kg 3,200 lbs 1,451 kg
Ice Storage Capacity
882 lbs 400 kg 882 lbs 400 kg 1,494 lbs 678 kg
Height with Bin
79.50" 201.90 cm 79.50" 201.9 cm 99.50" 252.73 cm
Width 48.00" 121.9 cm 48.00" 121.9 cm
48.00" 152.4 cm 60.00” 121.9 cm
WITHOUT BIN WITH BIN
Depth with Bin
34.00" 86.4 cm 34.00" 86.4 cm
31.00" 78.74 cm
SNOUT ADDS 8” / 20 CM
15
IBF0620C IBF0820C IBT1020C
Ice Production* 675 lbs 306 kg 825 lbs 374 kg 1,206lbs 547 kg
Height 24.00" 61 cm 26.50" 67.3 cm 30.50" 77.5 cm
Width 22.00" 55.9 cm 22.00" 55.9 cm 22.00" 55.9 cm
Depth 14.00" 35.6 cm 14.00" 35.6 cm 14.00" 35.6 cm
Ice/Beverage Series
The Indigo NXT IB series is home of one of the highest
producing 22" (56 cm) ice machine in the industry. The
IB series’ narrow 14" depth provides operators with
easy access to the beverage dispenser for manual ll,
cleaning, sanitizing, and other maintenance. This unique
capability is made possible by Manitowoc’s patented
CVD
®
technology which results in an compact design
allowing the ice machine to run with virtually no noise
or heat exhaust. With the proper adapter Manitowoc’s
IB machine can be installed on almost any beverage
dispenser. Just another way that Manitowoc is making
sure you have ice.
* Half dice pounds produced per day. Approximate ice-making capacity based on air-cooled condenser
unit at 70°F/21°C air and 50°F/10°C water. Ice machine and dispenser ordered separately.
Ice/Beverage Series on
Beverage Dispenser
HALF DICE
IF0600C IF0900C IT1200C IF1400C IF1800C SF3000C
Ice Production* 600 lbs 272 kg 816 lbs 370 kg 1,215 lbs 551 kg 1,425 lbs 646 kg 1,660 lbs 753 kg 2,910 lbs 1,320 kg
Height 21.50" 54.6 cm 26.50" 67.3 cm 29.50" 75 cm 25.00" 63.5 cm 29.50" 74.9 cm 36.00" 91.4 cm
Width 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 48.00" 121.9 cm
Depth 24.50" 62.2 cm 24.50" 62.2 cm 24.50" 62.2 cm 24.50" 62.2 cm 24.50" 62.2 cm 31.00" 78.7 cm
* Half dice pounds produced per day. Approximate ice-making capacity based on air-cooled condenser
unit at 70°F/21°C air and 50°F/10°C water. Ice machine and bin ordered separately.
17
QuietQube
75% quieter than a self-contained or standard remote
ice machine. Our patented CVD
®
technology uses cool
vapor rather than hot gas to harvest ice. It not only
makes QuietQube ice machines the quietest ever; it
makes them more reliable, makes them more ecient,
and provides high levels of ice production too. Consider
how much noise customers and employees face in your
operation and how much more inviting it will be with a
quiet ice machine.
IF0600C IF0900C IT1200C IF1400C IF1800C SF3000C
Ice Production* 600 lbs 272 kg 816 lbs 370 kg 1,215 lbs 551 kg 1,425 lbs 646 kg 1,660 lbs 753 kg 2,910 lbs 1,320 kg
Height 21.50" 54.6 cm 26.50" 67.3 cm 29.50" 75 cm 25.00" 63.5 cm 29.50" 74.9 cm 36.00" 91.4 cm
Width 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 30.00" 76.2 cm 48.00" 121.9 cm
Depth 24.50" 62.2 cm 24.50" 62.2 cm 24.50" 62.2 cm 24.50" 62.2 cm 24.50" 62.2 cm 31.00" 78.7 cm
*** CVD Condenser for IF0600C to IF1800C 34" W x 24.13" D x 25.75"H 86.4 x 61.3 x 65.4 cm CVD
Condenser for IF2100C & SF3000C 53" W x 26" D x 25.75" H 134.6 x 66.0 x 65.4 cm
CVD Condensing Unit***
HALF DICE
DICE
IT0420
SFA-191
IT0420
SPA-160
IT0450
SFA-291
IT0450
SPA-310
Ice Storage 120 lbs 54 kg 120 lbs 54 kg 180 lbs 82 kg 180 lbs 82 kg
Height with Dispenser 75.50" 191.8 cm 75.50" 191.8 cm 82.00" 208.3 cm 82.00" 208.3 cm
Width 22.00" 55.9 cm 22.00" 55.9 cm 30.00" 76.2 cm 30.00" 76.2 cm
Depth with Dispenser 31.00" 78.7 cm 31.00" 78.7 cm 32.00" 81.3 cm 32.00" 81.3 cm
19
IT0420
SFA-191
IT0420
SPA-160
IT0450
SFA-291
IT0450
SPA-310
Ice Storage 120 lbs 54 kg 120 lbs 54 kg 180 lbs 82 kg 180 lbs 82 kg
Height with Dispenser 75.50" 191.8 cm 75.50" 191.8 cm 82.00" 208.3 cm 82.00" 208.3 cm
Width 22.00" 55.9 cm 22.00" 55.9 cm 30.00" 76.2 cm 30.00" 76.2 cm
Depth with Dispenser 31.00" 78.7 cm 31.00" 78.7 cm 32.00" 81.3 cm 32.00" 81.3 cm
Ice Dispensers
These automatic-ll, oor-standing ice dispensers meet
the strict sanitary needs of the lodging, foodservice,
and healthcare industries. Capable of providing 635
lbs. (289 kg) of dispensed ice in a 24 hour period, the
SPA dispensers feature a patented push for ice or
touchless lever activated ice dispense mechanism and
paddle wheel ice delivery. The SFA models add a built-in
water valve for lling buckets, cups or rellable bottles.
Attractively styled to complement
any decor.
Ice machine and dispenser ordered separately.
HALF DICE
REGULAR
DICE
21
Performance
• Manitowoc reliability
• Industry leading 24 hour ice production
Intelligence
• Universally recognizable, easy-to-read display icons
with bright, neon blue indicator lights
• Time delayed ice production
Convenience
• Removable bin, for front service access
• EZ glide, angled bin door
• LuminIce II accessory compatible
• Improved scoop & holder inside the bin
The anywhere you need ice machine.
For more information visit www.manitowocice.com/NEO
UDE0065 UDE0080 UF0140 UF0190 UF0240 UF0310
Ice Production* 57 lbs 26 kg 102 46 kg 137 lbs 62 kg 198 lbs 90 kg 219 lbs 99 kg 290 lbs 132 kg
Ice Storage Capacity 31 lbs 14 kg 31 lbs 14 kg 90 lbs 40 kg 90 lbs 40 kg 90 lbs 40 kg 119 lbs 54 kg
Height 36.00" 91.4 cm 36.00" 91.4 cm 38.50" 97.8 cm 38.50" 97.8 cm 38.50" 97.8 cm 38.50" 97.8 cm
Width 19.69" 50 cm 19.69" 50 cm 26.00" 66 cm 26.00" 66 cm 26.00" 66 cm 30.00" 76.2 cm
Depth 22.34” 56.7 cm 22.34” 56.7 cm 28.5” 72.4 cm 28.5” 72.4 cm 28.5” 72.4 cm 28.5” 72.4 cm
23
UDE0065 UDE0080 UF0140 UF0190 UF0240 UF0310
Ice Production* 57 lbs 26 kg 102 46 kg 137 lbs 62 kg 198 lbs 90 kg 219 lbs 99 kg 290 lbs 132 kg
Ice Storage Capacity 31 lbs 14 kg 31 lbs 14 kg 90 lbs 40 kg 90 lbs 40 kg 90 lbs 40 kg 119 lbs 54 kg
Height 36.00" 91.4 cm 36.00" 91.4 cm 38.50" 97.8 cm 38.50" 97.8 cm 38.50" 97.8 cm 38.50" 97.8 cm
Width 19.69" 50 cm 19.69" 50 cm 26.00" 66 cm 26.00" 66 cm 26.00" 66 cm 30.00" 76.2 cm
Depth 22.34” 56.7 cm 22.34” 56.7 cm 28.5” 72.4 cm 28.5” 72.4 cm 28.5” 72.4 cm 28.5” 72.4 cm
Undercounter Cubers
These compact ice cube machines are ideal for small-
volume ice production, for limited use needs, or as
back-ups for larger machines. Specically designed to
t beneath counters or in areas where oor space or
height restrictions prohibit use of larger equipment.
The petite size makes any of these models ideal for
on-the-spot installations at coee shops, stadium boxes,
refreshment/break areas, or wherever limited ice needs
require equipment with a small footprint.
* Pounds produced per day. Approximate ice-making capacity based on air-cooled condenser
unit at 70°F/21°C air and 50°F/10°C water. Ice storage application capacity is measured at
90% of the total volume in cu. ft x 33lbs/ft3.
HALF DICE
REGULAR
DICE
Available on all
undercounters
Available on UF0140
and UF0310
Available on all
undercounters
CNF0201 CNF0202 UNF0200 UNF0300
RNF0320
D-420 Bin
RNF0620
D-420 Bin
RNF1100
D-570 Bin
RNF1020C
D-420 Bin
RNF2000C
D-570 Bin
Ice Production* 315 lbs 143 kg 315 lbs 143 kg 213 lbs 97 kg 300 lbs 136 kg 308 lbs 140 kg 591 lbs 268 kg 1078lbs 489 kg 1078 lbs 489 kg 1915 lbs 868 kg
Ice Storage Capacity 10 lbs 4.5 kg 20 lbs 9.1 kg 30 lbs 14 kg 60 lbs 27 kg 383 lbs 173 kg 383 lbs 173 kg 532 lbs 241 kg 383 lbs 173 kg 532 lbs 241 kg
Height with Bin 35.00" 89.9 cm 42.00" 106.7 cm 33.17" 84.24 cm 39.52" 100.4 cm 76" 193 cm 76" 193 cm 77.4" 196.5 cm 77.4" 196.5 cm 77.4" 196.5 cm
Width with Bin 16.25" 41.3 cm 16.25" 41.3 cm 19.69" 50 cm 29.06" 73.81 cm 22" 55.8 cm 22" 55.8 cm 30" 76.2 cm 22" 55.8 cm 30" 76.2 cm
Depth with Bin 24.00" 61 cm 24.00" 61 cm 25.98" 66 cm 27.17" 69 cm 34" 86.4 cm 34" 86.4 cm 34" 86.4 cm 34" 86.4 cm 34" 86.4 cm
25
Nugget Ice Machines
Manitowoc nugget machines provide a high quality,
chewable ice that boasts a 85% ice content—one of the
industry’s highest ice/water ratios. This means minimal
drink dilution, and a nugget ice that is perfect for use with
drink dispensing applications. Manitowoc nugget is also
ideal for specialty blended beverages, as well as lling
many uses in healthcare from ice/water needs to
cold therapy.
* Pounds produced per day. Approximate ice-making capacity based on air-cooled condenser unit at
70°F/21°C air and 50°F/10°C water. Ice storage application capacity is measured at 90% of the total
volume in cu. ft x 33lbs/ft3.
NUGGET
CNF0201 CNF0202 UNF0200 UNF0300
RNF0320
D-420 Bin
RNF0620
D-420 Bin
RNF1100
D-570 Bin
RNF1020C
D-420 Bin
RNF2000C
D-570 Bin
Ice Production* 315 lbs 143 kg 315 lbs 143 kg 213 lbs 97 kg 300 lbs 136 kg 308 lbs 140 kg 591 lbs 268 kg 1078lbs 489 kg 1078 lbs 489 kg 1915 lbs 868 kg
Ice Storage Capacity 10 lbs 4.5 kg 20 lbs 9.1 kg 30 lbs 14 kg 60 lbs 27 kg 383 lbs 173 kg 383 lbs 173 kg 532 lbs 241 kg 383 lbs 173 kg 532 lbs 241 kg
Height with Bin 35.00" 89.9 cm 42.00" 106.7 cm 33.17" 84.24 cm 39.52" 100.4 cm 76" 193 cm 76" 193 cm 77.4" 196.5 cm 77.4" 196.5 cm 77.4" 196.5 cm
Width with Bin 16.25" 41.3 cm 16.25" 41.3 cm 19.69" 50 cm 29.06" 73.81 cm 22" 55.8 cm 22" 55.8 cm 30" 76.2 cm 22" 55.8 cm 30" 76.2 cm
Depth with Bin 24.00" 61 cm 24.00" 61 cm 25.98" 66 cm 27.17" 69 cm 34" 86.4 cm 34" 86.4 cm 34" 86.4 cm 34" 86.4 cm 34" 86.4 cm
27
Undercounter Flakers
When it comes to food preservation, a cool presentation
can lead to cold, hard prots. Not only does your product
need to look good and stay fresh, the ice needs to look
good too. Manitowoc ake ice machines oer quick
cooling, moldable akes. Small, soft pieces of ice with
a 73% ice to water ratio form around objects without
bruising and hold in place without tipping or spilling.
Perfect for food and beverage presentation and hand
scooping into drinks.
* Pounds produced per day. Approximate ice-making capacity based on air-cooled condenser unit at
70°F/21°C air and 50°F/10°C water. Ice storage application capacity is measured at 90% of the total
volume in cu. ft x 33lbs/ft3.
UFF0200 UFF0350
Ice Production* 257 lbs 117 kg 350 lbs
159 kg
Ice Storage 50 lbs 23 kg 60 lbs
27 kg
Height 37.50" 95.24 cm 39.52"
100.4 cm
Width 19.69" 50 cm 29.06"
73.81 cm
Depth 25.98" 66 cm 27.17"
69 cm
FLAKE
RFF0320
D-420 Bin
RFF0620
D-420 Bin
RFF1300
D-570 Bin
RFF1220C
D-420 Bin
RFF2200C
F-1650 Bin
Ice Production* 370 lbs 168 kg 730 lbs 331 kg 1,264 lbs 573 kg 1,092 lbs 495 kg 2,063 lbs 936 kg
Ice Storage Capacity 383 lbs 173 kg 383 lbs 173 kg 532 lbs 241 kg 383 lbs 173 kg 1,494 lbs 678 kg
Height with Bin 76" 193 cm 76" 193 cm 77.40" 196.60 cm 76" 193 cm 91" 231 cm
Width with Bin 22" 55.90 cm 22" 55.90 cm 30" 76.20 cm 22" 55.90 cm 60" 152.40 cm
Depth with Bin 34" 86.36 cm 34" 86.36 cm 34" 86.36 cm 34" 86.36 cm
31" 78.74 cm
SNOUT ADDS 8” / 20 CM
29
Modular Flakers
When it comes to food preservation, a cool presentation
can lead to cold, hard prots. Not only does your product
need to look good and stay fresh, the ice needs to look
good too. Manitowoc ake ice machines oer quick
cooling, moldable akes. Small, soft pieces of ice with
a 73% ice to water ratio form around objects without
bruising and hold in place without tipping or spilling.
Perfect for food and beverage presentation and hand
scooping into drinks.
* Pounds produced per day. Approximate ice-making capacity based on air-cooled condenser unit at
70°F/21°C air and 50°F/10°C water. Ice machine and bin ordered separately. Ice storage application
capacity is measured at 90% of the total volume in cu. ft x 33lbs/ft3.
RFF0320
D-420 Bin
RFF0620
D-420 Bin
RFF1300
D-570 Bin
RFF1220C
D-420 Bin
RFF2200C
F-1650 Bin
Ice Production* 370 lbs 168 kg 730 lbs 331 kg 1,264 lbs 573 kg 1,092 lbs 495 kg 2,063 lbs 936 kg
Ice Storage Capacity 383 lbs 173 kg 383 lbs 173 kg 532 lbs 241 kg 383 lbs 173 kg 1,494 lbs 678 kg
Height with Bin 76" 193 cm 76" 193 cm 77.40" 196.60 cm 76" 193 cm 91" 231 cm
Width with Bin 22" 55.90 cm 22" 55.90 cm 30" 76.20 cm 22" 55.90 cm 60" 152.40 cm
Depth with Bin 34" 86.36 cm 34" 86.36 cm 34" 86.36 cm 34" 86.36 cm
31" 78.74 cm
SNOUT ADDS 8” / 20 CM
FLAKE
D-320 D-400 D-420 D-570 D-970
Application Capacity 264 lbs 119 kg 365 lbs 165 kg 383 lbs 173 kg 532 lbs 241 kg 882 lbs 400 kg
Height 38.00" 96.5 cm 38.00" 96.5 cm 50.00" 127 cm 50.00" 127 cm 50.00" 127 cm
Width 22.00" 55.9 cm 30.00" 76.2 cm 22.00" 55.9 cm 30.00" 76.2 cm 48.00" 121.9 cm
Depth 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm
31
Ice Storage Bins
Internal scoop holder
stays above ice line,
promoting easy access
and better sanitation.
Bin door holds open
while in use via a
patented hinge
pin design.
PVC Base Molding
Protects metal from
dents and scratches
when cleaning
beneath bin.
Duratech™ Exterior
This clear-coated
aluminum alloy resists
ngerprints, looks better
and lasts longer than
Stainless 304.
D-model bin leg
D-320 D-400 D-420 D-570 D-970
Application Capacity 264 lbs 119 kg 365 lbs 165 kg 383 lbs 173 kg 532 lbs 241 kg 882 lbs 400 kg
Height 38.00" 96.5 cm 38.00" 96.5 cm 50.00" 127 cm 50.00" 127 cm 50.00" 127 cm
Width 22.00" 55.9 cm 30.00" 76.2 cm 22.00" 55.9 cm 30.00" 76.2 cm 48.00" 121.9 cm
Depth 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm 34.00" 86.4 cm
Ice machine and adapters ordered separately. Ice storage application capacity is measured at 90% of
the total volume in cu. ft x 33lbs/ft3.
F-700 F-1300 F-1325 F-1650 FC-1350
Ice Storage Capacity 639 lbs 290 kg 1194 lbs 542 kg 1,238 lbs 562 kg 1,494 lbs 678 kg 1,304 lbs 591 kg
Height 58.50" 148.59 cm 63.50" 161.29 cm 54.50" 138.43 cm 63.50" 161.29 cm 73.50" 186.69 cm
Width 30.00" 76.20 cm 48.00" 121.90 cm 60.00" 152.40 cm 60.00" 152.40 cm 60.00" 152.40 cm
Depth 31.00" 78.74 cm 31.00" 78.74 cm 31.00" 78.74 cm 31.00" 78.74 cm 40.00" 101.60 cm
33
Large Capacity
Bins
F-Style large capacity ice storage bins are
equipped with an ice gate for increased
employee safety, easier ice removal, and
reduced spillage. 3-year parts and labor
warranty on bins. Carts oer a 2-year parts
and labor warranty.
F-700 F-1300 F-1325 F-1650 FC-1350
Ice Storage Capacity 639 lbs 290 kg 1194 lbs 542 kg 1,238 lbs 562 kg 1,494 lbs 678 kg 1,304 lbs 591 kg
Height 58.50" 148.59 cm 63.50" 161.29 cm 54.50" 138.43 cm 63.50" 161.29 cm 73.50" 186.69 cm
Width 30.00" 76.20 cm 48.00" 121.90 cm 60.00" 152.40 cm 60.00" 152.40 cm 60.00" 152.40 cm
Depth 31.00" 78.74 cm 31.00" 78.74 cm 31.00" 78.74 cm 31.00" 78.74 cm 40.00" 101.60 cm
Ice machine and adapters ordered separately. Ice storage application capacity is measured at 90% of
the total volume in cu. ft x 33lbs/ft3.
35
*Pounds produced per day. Approximate ice-making capacity based on air-cooled condenser unit at
70°F/21°C air and 50°F/10°C water. Ice storage application capacity is measured at 90% of the total
volume in cu. ft x 33lbs/ft3.
Gourmet Cube
Hard, clear individual cube for maximum cooling with
nearly 100% ice to water ratio. Perfect Premium Beverage
Companion with its crystal-like appearance. The SM-50 is
a compact, small capacity ice machine designed for use in
undercounter settings next to traditional cabinetry. It is the
ideal ice machine for the boardroom, conference rooms,
or kitchen lunch areas. The unit is designed to be installed
into a standard 15” 38 cm cabinet opening or can be free-
standing. Features include a multi-function control panel
with unique “delay-start mode”, lighted and over-sized bin
opening, and a built-in innovative water ltration system.
Produces individual octagon shaped cubes.
GOURMET
SM-50
Ice Production* 53 lbs 24 kg
Ice Storage Capacity 25 lbs 11 kg
Height 33.5" 85.0 cm
Width 14.8" 37.5 cm
Depth 22.8" 57.8 cm
UGP-20 UGP-30 UGP-40 UGP-50 UGP-80
Ice Production* 22 kg 31 kg 53 kg 57 kg 76 kg
Ice Storage 5.5 kg 5.5 kg 14 kg 14 kg 30 kg
Height 65 cm 65 cm 80 cm 80 cm 90 cm
Width 45 cm 45 cm 55 cm 55 cm 70 cm
Depth 47.5 cm 47.5 cm 55 cm 55 cm 60 cm
37
UGP-20 UGP-30 UGP-40 UGP-50 UGP-80
Ice Production* 22 kg 31 kg 53 kg 57 kg 76 kg
Ice Storage 5.5 kg 5.5 kg 14 kg 14 kg 30 kg
Height 65 cm 65 cm 80 cm 80 cm 90 cm
Width 45 cm 45 cm 55 cm 55 cm 70 cm
Depth 47.5 cm 47.5 cm 55 cm 55 cm 60 cm
Undercounter Spray
Cubers
Sotto™ is the perfect solution for venues where just a few
large cubes in the glass is preferred restaurants, bars,
cafes, coee shops, and delis. Specically designed for
the international market (not available in North America),
Sotto provides a robust 20 gram Gourmet style cube with
a unique octagonal shape. Sotto produces 22 to 86 kg of
ice daily and provides up to 44 kg of ice storage.
* Pounds produced per day. Approximate ice-making capacity based on air-cooled condenser unit at
70°F/21°C air and 50°F/10°C water. Sotto Products are not available in North America.
GOURMET
The clear and simple choice.
Vertical Discharge
Remote Condensers
Remote air-cooled condenser systems improve
eciency, increase ice production, and conserve
energy. Remote systems for Series 500, 600,
900, 1200, 1500 and 1900 ice machines consist
of ice maker, bin, remote condenser, and
interconnecting refrigerant lines. (Each ordered
separately.)
Arctic Pure
®
Water Filter
with QUICK DISCONNECT DESIGN
Conditions incoming water, reduces machine cleaning
frequency and service costs, maximizes equipment
performance, and improves ice quality. Features
include replaceable lters and compact size. All
systems carry a 3-year parts-and-labor warranty
(excluding lter cartridge).
LuminIce II Virus and Bacteria Inhibitor
Creates “active air” by recirculating the air around the ice machine
foodzone components to inhibit the growth of viruses, yeast,
bacteria, mold and other common micro-organisms. For use with
Indigo NXT and
NEO series.
Options & Accessories
LuminIce II runs quietly 24/7 keeping your
ice machine cleaner while helping reduce
cleaning frequency; which ultimately can
save money spent on routine maintenance
and PM programs. Space-saving design ts
inside the ice machine. With the Indigo NXT,
the easyTouch
®
display sanitation icon will
show the unit is working and indicate when
it is time to change the bulb.
Ice machine without LuminIce IIIce machine equipped with LuminIce II
39
Optional, Automatic
Cleaning System (iAuCS)
Eliminates routine maintenance.
iAuCS counts the number of ice-making
cycles and, at a frequency you select,
initiates a cleaning or sanitizing cycle...
AUTOMATICALLY. Choose from 2-, 4-, or
12-week settings. Use with
Indigo NXT modulars.
Multi Mount
External Scoop Holder
This NSF approved commercial grade
scoop holder is assembled without
tools. The K00461 holder can be
mounted 7 dierent ways: bin mount
left or right side, horizontal or vertical
and wall mount : horizontal or
vertical. Works with Manitowoc D-Bin
scoop or optional new metal scoop
iAuCS (External Mounting)
Metal Scoop
New NSF approved holder
D-Bin Scoop
Scale Ice
*
Scale ice is extremely hard and cold
with sizes ranging from 1.5 mm to
3 mm in thickness. Ice pieces resemble
a shattered sheet of ice. Scale is
perfect for industrial applications,
food processing and display such as
sh, dairy products, meat cutting, and
baking companies.
Gourmet Spray
*
Gourmet spray cubes are oered in a
variety of cube sizes and production
capacities. Perfect for cafés, bars
and restaurants in countries where
demand for ice in beverages is
reduced.
*Currently not available in North America
Additional Oerings
Options & Accessories
41
You’ve purchased the best ice
machine available – keep it that
way with Welbilt KitchenCare
®
Every new piece of equipment comes with Welbilt KitchenCare
and you choose the level of service that meets your operational
needs from one restaurant to multiple units.
StarCare – Our network of Factory Authorized Servicers are
factory trained and performance audited, with locations in
over 130 countries to meet your warranty and lifetime service,
installation, start-up and planned maintenance needs. With
genuine OEM parts certied for heavy-duty use, they keep your
equipment running in the most demanding kitchens.
• Warranty and life time service
• Certied OEM parts
• Global parts inventory
• Performance audited
ExtraCare – Fringe benets at your
ngertips, ExtraCare oers all
the little conveniences that someone
who understands and cares
about your operation provides.
• CareCode
• 24/7 Support
• Online/Mobile Product Information
LifeCare – The ultimate level of worry
free protection
and support for multi-unit operators. We work together
to determine the right level of service for your units, then
customize a program to manage your operation.
• Install and Equipment Orientation
• Planned Maintenance
• KitchenConnect
®
– Full facility monitoring and diagnostics
• MenuConnect
®
– Automatically upload
recipes and cooking procedures
Sustainability
At Manitowoc we strive to be a responsible
manufacturer, industry leader, and
employer, not only for this generation, but
for future generations. We routinely engage
our customers, industry partners, employees, strategic
suppliers, domestic and international government
agencies and associations, and the communities that we
serve around the world.
Less Energy. Less Water.
Manitowoc machines earn the ENERGY STAR
Commercial ice machines that have earned
the ENERGY STAR are on average 15% more
energy ecient and 10% more water ecient than
standard models. Manitowoc leads the way with dozens
of qualifying ice machines that meet and exceed
ENERGY STAR guidelines.
Visit www.welbiltgreen.com for a complete list of
Welbilt’s ENERGY STAR-qualied ice machines.
The EnerLogic
®
program helps operators
conserve energy and maximize prots.
Look for our EnerLogic mark and you’ll
know you’re getting the most from every
energy dollar spent on Welbilt equipment.
This program incorporates a combination of third-party
standards, including meeting or exceeding California
Energy Commission rebate standards, or meeting criteria
outlined by the Federal Energy Management Program,
including those that:
• Incorporate new energy-saving technology
• Involve renewable energy
• Demonstrate water eciency and/or
• Feature sustainable design and operations
43
Ice Usage Guide
Foodservice Approximate Ice Cube Needs Per Day
Restaurant .........1-1/2 lbs .68 kg per person
Cocktail ...............3 lbs 1.4 kg per person/seat
Water Glass ....... 4 oz 118 ml per 10 oz 296 ml glass
Salad Bar ............ 30 lbs 13.6 kg per cubic foot
Fast Food ...........5 oz 148 ml per 7-10 oz 207-296 ml drink
8 oz 237 ml per 12-16 oz 355-473 ml drink
12 oz 355 ml per 18-24 oz 532-710 ml drink
Lodging
Guest Ice .......... 5 lbs 2.7 kg per room
Restaurant ....... 1-1/2 lbs .68 kg per person/seat
Cocktail ............. 3 lbs 1.4 kg per person/seat
Catering ............ 1 lb .45 kg per person
Convenience Store
Beverage........... 6 oz 177 ml per 12 oz 355 ml drink
10 oz 296 ml per 20 oz 591 ml drink
16 oz 473 ml per 32 oz 946 ml drink
Cold Plate ......... 50% more ice per day
Packaged Ice .... lbs per bag x bags sold per day
Healthcare
Cafeteria ........... 1 lb .45 kg per person
Patient Ice ........ CNF0201: Up to 20 beds
Beverage Service
Drinks ................ 40% ice per drink x number of drinks
served on peak day
For proper sizing assistance,
please reference our ice machine calculator
at manitowocice.com/Sales/Ice-Calculator
Listings
ISO 9001:2015
Quality System Certied
Quality is the #1 consideration
at Manitowoc. Our company-
wide commitment to quality
makes us especially proud of our
certication to ISO 9001:2015
quality standards and our
position as North America’s rst
ISO-certied manufacturer of ice
machines.
Quality Assurance
Before crating and shipment, every
Manitowoc cube machine is operated for a
minimum of two ice-making cycles. During
this testing, inspectors record the serial
number, air and water temperatures,
humidity, freeze times, and harvest times
as part of their nal inspection. Ongoing
reviews of this test data assure that
Manitowoc machines consistently meet
the highest standards of quality.
Certification
9001:2015
UL STD 563
CAN/CSA-C22.2 No. 120
SANITAT ION
NSF/ANSI STD 12
45
Commercial Warranty
Cube Ice Machine
• 5-year parts-and-labor coverage on Indigo NXT, S, U,
QQ and IB-model ice machine evaporators.
• 5-year parts and 3-year labor coverage on Indigo NXT,
S, U, QQ and IB-model ice machine compressor.
• 3-year parts-and-labor coverage on all dispensers,
storage bins, and Indigo NXT, S, U, QQ and ID-model
ice cube machines.
UF0065 / UF0080 Series Ice Machine
• 3-year parts-and-labor coverage on all components.
SM Series Ice Machine
• 3-year parts-and-labor coverage on all components.
UFF/RFF/UNF/RNF Ice Machines
• 3-year parts.
• 3-year labor.
• Compressor parts for 5 years and labor for 2 years.
CNF Countertop Nugget Ice Machine
• 2-year parts-and-labor coverage on all components.
• Compressor parts for 5 years and labor for 2 years.
Residential Warranty
All Ice Machines
• 1-year parts-and-labor
Beverage Dispensers
Manitowoc’s sister company, Multiplex
®
, oers a complete
countertop self-service ice
and beverage product line.
Icepic
®
ice crusher allows the
customer to choose between
cube or crushed ice via a built-
in ice crusher
mechanism
from a single
ice machine
placement.
CRUSHED
47
+1 800.545.5720 | MANITOWOCICE.COM
©2020 Welbilt Inc. All rights reserved.
3516Z 08/2020
Welbilt oers fully-integrated kitchen systems and our
products are backed by KitchenCare
®
aftermarket parts
and service. Welbilt’s portfolio of award-winning brands
includes Cleveland, Convotherm
®
, Crem
®
, Deleld
®
,
tkitchen
®
, Frymaster
®
, Garland
®
, Kolpak
®
, Lincoln,
Manitowoc
®
, Merco
®
, Merrychef
®
and Multiplex
®
.
Bringing innovation to the table • welbilt.com
