PerfektT‐24P,PerfektT‐30P
RangeHoodInstructionManual
Thankyouforthepurchaseofthisproduct.Pleasereadthe
manualcarefullybeforeoperatingtheappliance.
1|Page
Contents
ImportantSafetyInstructions 2
Introduction 3
Features 3
Installation 4‐5
HowtoUse 6
GroundingInstructions 7
SafetyInformation 8
TroubleShooting 9
ElectricalDiagram 10
Specifications 10
Cleaning&Maintenance 11
InstallationDiagram 12
Warranty 13
13|Page
Warranty
AEGAppliancesareimportedanddistributedinNorth
AmericabyEuro‐LineAppliancesInc.
Formoreinformationvisitwww.euro‐line‐appliances.com
orcontact:
2278SpeersRoad
Oakville,ONL6L2X8
Canada
1‐800‐421‐6332–Euro‐LineAppliancesInc.
1‐800‐ELA‐WEST–Euro‐LineAppliancesWest
marketing@euro‐line‐appliances.com
AllAEGAppliancesarebackedbyacomprehensive2‐year
partandlabourwarranty.Informationonserviceandparts
availablefromEuro‐Partsat1‐800‐678‐8352
2|Page
ImportantSafetyInstructions
○Readandsavetheseinstructions
○Warning‐Toreducetheriskoffireorelectricshock,do
notusethisfanwithanyso lid ‐statespeedcontroldevice.
○ CAUTION: For general ventilating use only. Do not use
toexhausthazardousorexplosivematerialsandvapors.
○Warning‐Toreduce
theriskofarangetopgreasefire:
Neverleavesurfaceunitsunattendedathighsettings.
Boil overs cause smoking and greasy spillovers that
mayignite.Heatoilsslowlyonlowormediumsettings.
Always turn hood ON when cooking at high heat or
when flambéing food (i.e.
Crepes Suzette, Cherries
Jubilee,PeppercornBeefFlambé)
Cleanventilatingfansfrequently.Greaseshouldnotbe
allowedtoaccumulateonfanorfilter.
Useproperpansize.Alwaysusecookwareappropriate
forthesizeofthesurfaceelement.
○Warning‐Toreducetheriskofinjurytopersonsinthe
eventofarangetopgreasefire,observethefollowing:
Smotherflameswithaclose‐fittinglid,bakingsheet,or
metaltray,andthenturnofftheburner.Becarefulto
preventburns.Iftheflamesdonotgooutimmediat ely,
evacuateandcallthefiredepartment.
Never
pickupaflamingpan‐you maybeburned.
Do notusewater,includingwetdishclothsortowelsa
violentsteamexplosionmayresult.
Use an extinguisher ONLY if: A) You know you have a
class ABC extinguisher, and you already know how to
operate it. B) The fire
is small and contained in the
areawhereitstarted. C)Thefiredepartment is being
called. D) You can fight the fire with your back to an
exit.
3 | P a g e
Introducon
o This appliance has been manufactured with materials
and processes that respect the environment. We hope
that you will connue this important consideraon in
the operaon of this appliance and the disposal of the
packaging materials – thank you.
o The installaon work must be undertaken by a
qualified technician experienced in range hood
installaon. Please connect the correct power rang
(see page 10)
o The manufacturer disclaims all liability for any damage
or injury caused as a result of not following
instrucons for installaon contained in the following
text
o The appliance is not intended for use by young
children or infirm persons without supervision
o Young children should be supervised to ensure that
they do not play with the appliance
o The maximum number of burners covered by a range
hood should not exceed 5
o Any modificaons to the appliance, electric wire and
plug is dangerous and voids the warranty
Features
o This appliance is manufactured from top quality
materials, and offers superb streamlined effects
o With high sucon power and low noise, it is designed
to remove cooking fumes from your kitchen quietly
and effecvely
12 | P a g e
Installaon Diagram
Perfekt T-24P
Perfekt T-30P
12”
305mm
12”
305mm
12”
305mm
12”
305mm
11|Page
Cleaning&Maintenance
1. Cleanthesurfaceofthehoodeveryweekwithmild
soapordetergent.Avoidsolvents,acid,alkali,scouring
padsorpowderthatcouldirreparablydamagethe
stainlesssteelsurface
2. Thegreasefiltersmaybewashedusingmildsoap,
detergentordegreasingagents
3. Thecharcoalfilterscannotbecleaned
andmustbe
generallyreplacedafter6monthsofuse
4|Page
Pic1
Installation(ductisnotsupplied)
1. Therangehoodshouldbemountedata
distanceof600mmfromanelectricor
inductioncooktop,and762mmabovea
gascooktopforsafetyandoptimum
performance.Iftheinstructionsfor
installationofthegascooktopspecifya
greaterdistance,thishastobetaken
intoaccount.(seepic
1)Theexhaustair
mustnotbedischargedintoaflue
whichisusedforexhaustingfumesfrom
otherappliancesburninggasorotherfuels
2. Toinstallontothewall,drill2holesofØ8mmona
sturdywallandinlinewiththehood
3. Insertexpandingscrews
intotheholes
4. Fixdrillingtemplateonthewall(seepic 2)
5. Addthesoottube(alternativepart)totheoneway
valve,andconnectittothekitchenoutletvent.(seepic
3)
6. Inserttheouterchimney,theouterchimneyshouldbe
fixedonthemainbody
byscrews.Thenmountthe
bracketandinserttheinnerchimneyandscrewitto
tighten.(seepic4)
600
–
762mm
5|Page
7. Ensurethatthewallthehoodistobeinstalledonis
sufficientlysturdytocarrytheweightofthehood.It
shouldbemountedlevelforbestperformance
8. Donotconnecttoacommonventwithanyother
appliancessuchasagasheater,water
heater,
washer/dryer,etc.
9. Theductshouldnotbebentmorethan120°fromthe
onewayvalveoutletinthekitchenvent
10. Checktomakesurethattheelectricalcordisnotin
contactwithsharpedgesoftheappliance
11. Besurethattheplugisaccessibleafterinstallation
Pic2 Pic3 Pic4
Pic5
10|Page
ElectricalDiagrams
PerfektT‐24P,PerfektT‐30P
Specifications
PerfektT‐24P,PerfektT‐30P
PowerSupply 115V,60Hz
RatedInputPower 99W
LightingPower 2x2W
MotorPower 95W
Airflow 500CFM
OutletDiameter 150mm
115V,60Hz
L2
9|Page
TroubleShooting
Ifanyproblemoccurs,pleasedetachtheplugfromthe
socketandcontactEuro‐Partsorasimilarlyqualified
personinordertoavoidahazard.
Problem Cause Solution
Lighton,but
motordoesnot
work
Theoutletvalveis
blocked
Detachflueandduct
thenturnonthehood
tocheckifthevalves
open
Thecapacitorhas
failed
Callfortechnical
service
Thecontrolswitch
hasbroken
Callfortechnical
service
Lightdoesnot
work,motor
doesnotwork
Nopowersupply
Pluganotherappliance
intothesocketto
confirmthereispower
supply
Fusehasblown
Openuptheplugand
replacehe13Afuse
Vibration
Thepropelleris
damagedor
unbalanced
Callfortechnical
service
Thehoodisnot
installedcorrectly
Reviewtheinstallation
instructionsandcheck
theinstallationagain
forloosescrews,
bracketsor
connections
Insufficient
suctioneffect
Thedistance
betweenthehood
andcooktopistoo
great
Checkthatthe
distanceisbetween
600mmand762mm
Thefiltersare
saturated
Cleanthefiltersfrom
greaseresidueand
replaceaftercleaning
6|Page
HowtoUse
3speedadjustment(seepic6)
o Pushthe1button,andthemotorwillrunatthelowest
speed
o Pushthe2button,andthemotorwillrunatmedium
speed
o Pushthe3button,andthemotorwillrunatthe
highestspeed
o Pushthe
Lightbutton,andthelightinglampswill
illuminate.Pushitagainandthelightswillturnoff
o Onanyspeed,the“T”andthedelaytimerwillswitch
offafter5minutes
o Toturnoffthemotor,push“T”buttontwice.
Pic
6
7|Page
GroundingInstructions
o Thisappliancemustbegrounded.Intheeventofan
electricalshortcircuit,groundingreducestheriskof
electricshockbyprovidinganescapewireforthe
electriccurrent.Thisapplia nceisequippedwithacord
havingagroundingwirewithagroundi ngplug.The
plugmustbepluggedinto
anoutletthatisproperly
installedandgrounded.
o Warning‐Impropergroundingcanresultinariskof
electricshock.
o Consultaqualifiedelectricianifthegrounding
instructionsarenotcompletelyunderstood,orifdoubt
existsastowhethertheapplianceisproperly
grounded.
o Donotusean
extensioncord.Ifthepowersupply cord
istooshort,havingaqualifiedelectricianinstallan
outletneartheappliance.
WARNING:TOREDUCETHERISKOFFIRE,USEONLYMETAL
DUCTWORK.
8|Page
SafetyInformation
o Theremustbepermanentandadequateventilationofthe
roomwhenoperatingtherangehoodwithappliances
burninggasorotherfuels
o Donotcheckthestatusofthefilterswhentherangehood
isoperating–waitatleast30minutesafterswitchingoff
toavoidscalding
o
DonottouchtheLEDlightwithin30minutesafter
applianceuse
o Avoidoperatingagascooktopwhenthereisnopanonthe
stove.Itisafirehazardandmaycausedamagetothe
hoodfilters
o Disconnecttheelectricalplugpriortoanymaintenance
o This
applianceisnotintendedforusebyyoungchildren
unlesstheyhavebeenadequatelysupervisedbya
reasonablepersontoensurethattheycanusethe
appliancesafely
o Therangehoodisforhomeuseonlyandisnotsuitablefor
outdoor,barbeque,andothercommercialapplications
o Therange
hoodanditsfiltershouldbecleanedregularly
forbestperformance
o Beforecleaning,pleaseconfirmthatthepowerisswitched
off
o Buildingregulationsconcerningthedischargeofexhaust
airhavetobefulfilled
o Don’tcookwithanopenflameundertherangehood
o Foranytechnical
issuesensurethatasuitablyqualified
personhandlesanyrepairsorinspections
