LS Model
80
F/X
®
-LS
RT Models
80
F/X
®
-RT
620-RT
2 Polk Audio Customer Service: 1-800-377-7655 (Outside US & Canada: 410-358-3600) Monday-Friday, 9:00 AM-6:00 PM EST, polkcs@polkaudio.com
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ BEFORE OPERATING EQUIPMENT
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources
such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.
9. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
10. WARNING: To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects filled
with liquids, such as vases, should not be
placed on this apparatus.
Product Disposal—Certain interna-
tional, national and/or local laws and/
or regulations may apply regarding
the disposal of this product. For further
detailed information, please contact
the retailer where you purchased this
product or the Polk Audio Importer/
Distributor in your country. A listing of Polk Audio
Importer/Distributors can be found on the Polk Audio
website www.polkaudio.com or by contacting
Polk Audio at 5601 Metro Drive, Baltimore,
Maryland 21215, USA—Phone: +1 410 358-3600.
WARNING: Listen Carefully
Polk Audio loudspeakers and subwoofers are
capable of playing at extremely high volume levels,
which could cause serious or permanent hearing
damage. Polk Audio, Inc. accepts no liability for
hearing loss, bodily injury or property damage
resulting from the misuse of its products.
Keep these guidelines in mind and always use
your own good judgment when controlling volume:
Ê UÊÊ 9ÕÊÃÕ`ÊÌÊ«À}i`ÊiÝ«ÃÕÀiÊÌÊ
volumes that exceed 85 decibels(dB).
For more about safe volume levels, go to the
Occupational Health and Safety Administration
(OSHA) guidelines at http://www.osha.gov/dts/
osta/otm/noise/standards_more.html
TAKE INVENTORY
Inside each speaker container, you should
find the following:
1. One in-ceiling loudspeaker or one set
of loudspeakers for F/X
®
models only.
2. Speaker cutout mounting template
3. One Sheer-Grille (for each speaker)
4. One Owner’s Manual
5. Registration Card
Important Note: If anything is missing or
damaged, or if your speaker fails to operate,
notify Polk Audio Customer Support Services
immediately at 800-377-7655.
INSTALLATION RECOMMENDATION
FOR OPTIMUM PERFORMANCE
Important Note: Vanishing Series Loudspeakers
are not magnetically shielded and should not be
placed closer than 1' (30cm) from a CRT (tube)
television or video monitor.
Important Note:Ê9ÕÊÃÕ`Ê>ÛiÊ>ÊÌÀÕ}Ê
understanding of and adhere to all local building
and fire codes. Also, you should be familiar with
the area behind the wall or ceiling into which
you plan to install your speakers. Always use
wire that meets appropriate building and fire
codes. (Note: Wiring is best performed
by an experienced professional.)
When installing your loudspeakers, be aware of
the weight of your particular model and the sturdi-
ness of the material into which you are installing
the speaker. Be aware of any concealed studs,
electrical wiring or plumbing in the wall or ceiling
into which you are installing the speakers.
If you doubt that you possess the necessary
skills or tools, consult your Polk Audio dealer
or a professional installer.
WIRE RECOMMENDATIONS
(minimum recommended)
Runs Gauge
Lengths up to 25' 18 or 16
Lengths greater than 25' 16 or 14
but less than 50'
Lengths greater than 50' 14 or 12
but less than 75'
Lengths greater than 75' 12
LOUDSPEAKER INSTALLATION
You will need:
Ê UÊÊ *iVÊvÀÊ>À}ÊÌiÊV>ÌÊvÊÃÌ>>Ì°
Ê UÊÊ iÞiÊÃ>Ü]ÊÕÌÌÞÊviÊÀÊ>ÌiÀ>
appropriate tool for cutting drywall
or other wall material.
Ê UÊÊ -VÀiÜ`ÀÛiÀ]Ê«ÀiviÀ>LÞÊ«ÜiÀi`]Ê
with Phillips Head bit.
Ê UÊÊ *ÜiÀÊ`ÀÊÜÌÊ>««À«À>ÌiÊLÌÊ
(optional, for starting wall cut).
Trace around the template.
Cut the hole with the appropriate tool.
IMPORTANT INFORMATION BEFORE
YOU INSTALL YOUR LOUDSPEAKERS
Wall Or Ceiling Surface Preparation
If you’re installing your Vanishing Series speaker
into a heavily textured wall or ceiling (e.g. stucco
or popcorn finish), you must prepare the wall
surface immediately around the speaker
cutout. Sanding and smoothing the wall or
ceiling surface will ensure the speaker and
grille both seat properly and flat to the surface.
For more information visit our website at www.polkaudio.com 3
IMPORTANT INFORMATION SHOULD
YOU CHOOSE TO PAINT YOUR GRILLES
Because of its ultra-thin profile, the Vanishing
Series Sheer-Grille
™
requires a specific painting
procedure to ensure smooth, even coverage.
The grille scrim and perforated grille come
assembled and require no disassembly.
Paint Recommendation
We highly recommend you use a can of spray
paint matched to the ceiling color you want the
Sheer-Grilles to blend with.
Important Note: Never use a brush or roller to
paint the grilles, as this will clog the perf holes.
To paint the Sheer-Grille
1. Elevate the Sheer-Grille off of a flat surface.
This will ensure even coverage of the grille
frame and make it easier to pick up.
Mounting Idea: A single spray can cap
will raise the grille high enough.
2. Hold the spray paint about 12" from
the grille and at a 45° angle.
3. Apply one light, thin coat, moving evenly
side to side over the grille, then work your
way around the perimeter of the grille
to ensure you cover the grille frame.
4. After each application of paint, wait
approximately 1 minute, rotate the
grille 90°, and apply the next thin coat.
Important Note:Ê9ÕÊÕÃÌÊÀÌ>ÌiÊÌiÊ}ÀiÊ
90°. Use your hands to define the next 90°
rotation and always rotate the grille in the
same direction of travel.
5. Three light, even applications should cover
the grille and frame adequately. Remember
to work your way around the grille frame
to cover it evenly and completely.
SURROUND SPEAKER PLACEMENT
Polk Audio F/X
®
surround loudspeakers give you
nearly endless placement options. But remember
that where you place your surround speakers
requires some careful thought, as installation
requires that you cut a hole in your wall or ceiling.
Diagram shows speaker locations for
5.1 and 7.1 systems, when two additional
in-ceiling speakers are installed at back
of the room.
Left/Right Orientation: F/X
®
surround loud-
speakers have a left/right orientation, and each
speaker is clearly marked on the serial number
label on the back of the magnet for installation
on either the right or left. Right and left are
defined from your listening area as you face
your system’s center channel.
Please Note: For more on speaker placement go
to: www.polkaudio.com/education/article.php?id=15
or www.polkaudio.com/downloads/hthandbook.pdf
ROOM ENVIRONMENT CONTROLS
Imaging (80
F/X-LS only)
F/X Surround Loudspeakers offer switchable
“Diffuse” and “Solid” imaging patterns
to create the surround effect you desire.
A “Diffuse” image is defined as one which
creates a “cloud” of sound; think of the effect
as ambient sounds which fill the environment
all around you, but are less localizable.
A “Solid” image is one which creates a more pin-
point sound; sound is more localized. The location
of sounds in the sound field is more identifiable.
Wall Distance Switch (F/X models only)
In-ceiling loudspeakers excel when placed
more than 2' (60cm) from side walls. If position
limitations demand that in-ceiling loudspeakers
be installed closer than 2' (60cm) from side walls,
the proximity of the surface can result in a response
“bump” between 50 and 200Hz. This can cause
in-ceiling speakers to sound “boomy.” The
“Wall Distance” switch flattens response
and eliminates “boominess” without sacrificing
deep bass response, for more lifelike sound.
TV
Solid / Diffuse
Imaging
4 Polk Audio Customer Service: 1-800-377-7655 (Outside US & Canada: 410-358-3600) Monday-Friday, 9:00 AM-6:00 PM EST, polkcs@polkaudio.com
DIMENSIONS
Model 80F/X-LS 80F/X-RT 620-RT
A. Overall Dimensions
11 1/8" (282.6mm) 11 1/8" (282.6mm) 9 5/8" (244.5mm)
B. Cutout Dimensions
9 3/8" (238.1mm) 9 3/8" (238.1mm) 8 3/16" (208mm)
C. Product Depth
5 1/8" (130.2mm) 4 3/4" (120.7mm) 4 1/4" (108mm)
D. Mounting Depth
(using 1/2" drywall)
4 5/8" (117.5mm) 4 1/4" (108mm) 3 3/4" (95.3mm)
A
B
C D
SPECIFIATIONS
For complete Vanishing Series specifications, visit www.polkaudio.com
For more information visit our website at www.polkaudio.com 11
Limited Lifetime Warranty for Polk Audio-
Branded In-Wall and In-Ceiling Speakers
Important Note:
This lifetime warranty applies only to in-wall and in-ceiling
loudspeakers, and passive CSW subwoofers sold after September 9, 2009.
Polk Audio, Inc., (“Polk”) warrants to the original retail purchaser that Polk Audio branded
in-wall and in-ceiling speakers, including passive CSW series subwoofers (collectively
“product”), will be free from defects in materials and workmanship for the life of the
product, under normal use and conditions. Should this product prove to be defective
in material or workmanship, Polk will, at its option, (a) repair the product, or (b) replace
the product. If the product model is no longer available and cannot be repaired
effectively, or replaced with an identical model, Polk may, at its sole and absolute
option, replace the unit with a current model of equal or greater value.
To obtain warranty service, you may refer to the instructions in your owner’s manual
ÀÊÛÃÌÊÌiÊ*ÊÕ`ÊÜiLÃÌiÊ>ÌÊÜÜÜ°«>Õ`°V°Ê9ÕÊ>ÞÊ>ÃÊVÌ>VÌÊ*ÊÕ`Ê
ÕÃÌiÀÊ-iÀÛViÊ>ÌÊ£nääÎÇÇÇÈxxÊvÀÊÃÌÀÕVÌÃÊÊÜiÀiÊÌÊÃi`ÊÌiÊ«À`ÕVÌ°Ê9ÕÊ
will be required to provide an original receipt or bill of sale, identifying you as the original
«ÕÀV>ÃiÀÊ>`Ê`iÌvÞ}ÊÌiÊ«ÕÀV>ÃiÊ>`iÊÌÀÕ}Ê>Ê>ÕÌÀâi`Ê*ÊÀiÌ>iÀ°Ê9ÕÊÜÊ
need to ship the product, prepaid and insured, together with the proof of purchase to Polk
Audio, Inc. 1 Viper Way, Vista, CA 92081. Risk of loss or damage in transit shall be borne
by the purchaser. Freight collect shipments will be refused.
This warranty is non-transferable and does not apply to any product that has been modi-
fied or used in a manner contrary to its intended purpose, and does not cover damage
to the product caused by installation or removal of the product. If modification(s) to a
mounting surface are made to product(s) that have been substituted under warranty, Polk
assumes no responsibility or liability for any modification made to the mounting surface
or otherwise. This limited warranty is void if the product has an altered or missing serial
number, or if the product was purchased from someone other than an authorized dealer.
This limited warranty is void if the product has been damaged by accident or unreason-
able use, neglect, improper service or other causes not arising out of defects in material
or construction. Product(s) which are found to be damaged by abuse resulting in thermally
damaged voice coils are not covered by this warranty but may be replaced at the sole and
absolute discretion of Polk. This warranty terminates if you sell or otherwise transfer the
product to another party. This limited warranty does not cover cosmetic damage, paint
damage, damage to other components, parts or premises, or any consequential damages
which may result for any reason. This limited warranty does not cover labor costs
for the removal and/or reinstallation of the product.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY HAVE
OTHER RIGHTS THAT VARY FROM STATE TO STATE. ALL WARRANTIES,
INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
EXPRESSLY EXCLUDED AND DISCLAIMED TO THE MAXIMUM EXTENT ALLOWED
BY LAW, AND POLK NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO
ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE SALE OF THE
PRODUCT. POLK HAS ABSOLUTELY NO LIABILITY FOR ANY ACTS OF THIRD
PARTIES. SOME STATES DO NOT ALLOW THE EXCLUSION OF CERTAIN IMPLIED
WARRANTIES, OR CONDITIONS ON AN IMPLIED WARRANTY, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU. POLK DOES NOT ACCEPT LIABILITY FOR
SPECIAL, INDIRECT, INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES,
LOST PROFITS, LOST SAVINGS OR DAMAGES RESULTING FROM IMPROPER USE,
OR THE INABILITY TO USE THE PRODUCT. THE MAXIMUM LIABILITY FOR WHICH
POLK MAY BE RESPONSIBLE SHALL NOT EXCEED THE PURCHASE PRICE OF THE
PRODUCT. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSIONS MAY NOT APPLY TO YOU.
Garantie à vie limitée des haut-parleurs
«In-Wall» et «In-Ceiling» de marque Polk Audio
Note importante:
Cette garantie à vie ne s’applique qu’aux haut-parleurs «In-Wall»
et «In-Ceiling» et aux subwoofers CSW vendus après le 9 septembre 2009.
Polk Audio Inc., («Polk»), garantit à l’acheteur au détail original que les haut-parleurs
«In-Wall» et «In-Ceiling» de marque Polk Audio, incluant les subwoofers passifs de la
série CSW (nommément «le produit»), seront exempts de défectuosités imputables aux
pièces d’origine et à la fabrication pour la vie du produit dans des conditions normales
d’usage. En cas de défectuosités imputables aux pièces d’origine et à la fabrication,
Polk, à sa discrétion, (a) réparera le produit ou (b) remplacera le produit. Si le modèle
du produit n’est plus disponible et ne peut être réparé efficacement, ou remplacé par
un modèle identique, Polk pourra, à sa seule et entière discrétion, remplacer le produit
avec un modèle de valeur égale ou supérieure.
Pour obtenir du service sous garantie, consultez les instructions contenues dans votre
manuel d’utilisation ou visitez le site web de Polk Audio: www.polkaudio.com. Vous pou-
vez aussi communiquer avec le Service à la Clientèle de Polk Audio au 1-800-377-7655
pour savoir où expédier le produit. Vous devrez fournir le reçu original de la vente, vous
identifiant comme l’acheteur original du produit et attestant que vous avez acheter
le produit d’un revendeur autorisé Polk Audio. Vous devrez expédier le produit, franc
de port et dûment assuré, avec la preuve d’achat, à Polk Audio, 1 Viper Way, Vista,
California 92081. Le propriétaire du produit doit assumer tout risque de perte
ou de dommage en transit. Tout fret payable à destination sera refusé.
Cette garantie n’est pas transférable et ne s’applique pas à un produit qui a été modifié
ou utilisé de façon non conforme, et ne couvre pas les dommages causés par l’installation
ou le démontage du produit. Si des modifications ont été apportées à la surface de mon-
tage pour accepter un produit substitué sous garantie, Polk n’assume aucune responsabil-
ité pour toute modification qui aura été apportée à la surface. Cette garantie est annulée
si le numéro de série sur le produit a été retiré, altéré ou falsifié ou si le produit a été
acheté d’un revendeur non autorisé. Cette garantie est annulée si le produit a été endom-
magé par accident ou par usage abusif, négligence, service inapproprié ou toute autre
cause non imputable aux pièces d’origine et à la fabrication. Les produits dont la bobine
mobile a subi des dommages thermiques causés par un usage abusif ne sont pas couverts
par cette garantie mais pourraient être remplacés à la seule et entière discrétion de Polk.
La garantie sera automatiquement annulée si l’acheteur original vend ou transfère le
produit à tout autre parti. Cette garantie ne couvre pas les dommages à la peinture ou au
décor, les dommages d’autres composants, les dommage à la pièce ou aux lieux, ou tout
dommage conséquent qui pourrait être causé pour toute autre raison. Cette garantie limi-
tée ne couvre pas la main d’oeuvre pour le démontage et/ou la réinstallation du produit.
CETTE GARANTIE VOUS ACCORDE DES DROITS LÉGAUX SPÉCIFIQUES; VOUS
POURRIEZ ÉGALEMENT AVOIR D’AUTRES DROITS QUI POURRAIENT VARIER
D’ÉTAT EN ÉTAT. TOUTES GARANTIES, INCLUANT MAIS NON LIMITÉES AUX
GARANTIES EXPRESSES ET AUX GARANTIES ÉNONCÉES DE COMMERCIALITÉ
ET DE COMPATIBILITÉ POUR UTILISATION PARTICULIÈRE, SONT EXPRESSÉ-
MENT EXCLUES ET DÉCLINÉES CONFORMÉMENT À LA PORTÉE MAXIMALE
PRÉVUE PAR LA LOI. POLK N’ACCEPTE AUCUNE RESPONSABILITÉ RELATIVE
À LA VENTE DU PRODUIT ET N’AUTORISE AUCUNE PERSONNE À ACCEPTER
CETTE RESPONSABILITÉ EN SON NOM. POLK N’ACCEPTE ABSOLUMENT AUCU-
NE RESPONSABILITÉ POUR TOUTE ACTION D’UN TIERS PARTI. CERTAINS ÉTATS
NE PERMETTANT PAS L’EXCLUSION OU LA LIMITATION DES DOMMAGES INDI-
RECTS, LES LIMITATIONS ET EXCLUSIONS EXPRIMÉES CI-DESSUS POURRAIENT
NE PAS S’APPLIQUER DANS VOTRE CAS. POLK N’ACCEPTE AUCUNE RESPON-
SABILITÉ POUR TOUT DOMMAGE PARTICULIER, INDIRECT, ACCESSOIRE OU
PUNITIF, PROFITS PERDUS, ÉPARGNES PERDUES, OU TOUT DOMMAGE CAUSÉ
PAR UN USAGE ABUSIF OU PAR L’INCAPACITÉ D’UTILISER LE PRODUIT.
LA RESPONSABILITÉ MAXIMALE DE POLK NE DÉPASSERA PAS LE PRIX
D’ACHAT DU PRODUIT. CERTAINS ÉTATS NE PERMETTANT PAS L’EXCLUSION
OU LA LIMITATION DES DOMMAGES INDIRECTS OU ACCESSOIRES, LES
LIMITATIONS ET EXCLUSIONS EXPRIMÉES CI-DESSUS POURRAIENT
NE PAS S’APPLIQUER DANS VOTRE CAS.
5601 Metro Drive
Baltimore, Maryland 21215
800-377-7655 (outside usA & CANADA: 410-358-3600)
www.polkaudio.com
HBP2144
speaker
for
every
in·wall
and
in-ceiling
application-including
the
world's
first
THX·
UltraZ
Certified
ifl·ceiling
speaker
and
maximum
performance
in-floor
and
in·wall
subwoofers.
Our
award-winning
buill-in
products
feature
lhe
same
lech-
nologies
and
quality
standards
as
our
free-
standing
speakers
and
subs
for
performance
that
will
amaze
you
and
your
guests.
www.polkalldio.com/customalldio
Built-lnSolutions
Custom
Installed Multi-Room
Audio
And
Home
Theater
Now
you
can
have
big
speaker
sound
from
speakers
that
you
can
barely
see.
Polk
Audio
offers
a
huge
selection
of
built·in
speakers
and
subwoofers
for
multi·room
audio
systems
and
built-in
home
theater
systems.
Whether
you
are
looking
for
a
Simple
do-it-yourself
two·room
system
or
a
professionally
Installed
whole-house
system,
Polk
Audio
has
a
built-in
-:::=::-
wireless"
iTunes
Tagging
Technology
with
other
spatial
algorithms
to
create
a
bigger
and
a
bigger
sense
of
envelopment.
And
unlike
most
sound
bar
systems
that
must
bounce
sound
off
walls
to
create
their
surround
effect.
the
Instant
Home
Theater's
surround
effects
are
created
independent
of
the
walls.
No
matter
what
lhe
shape
or
size
of
the
room,
walls
or
no
walls.
www.polkaudio.com/homealldiofiht
[li!iPOd
I
H»Radio'
player
inputs.
This
is
a
high
performance
audio
system
in
a
convenient,
compact
tabletop
configuration.
With
an
IES2,
you
can
enjoy
the
widest
range
of
music.
movies
and
news
available
today
and
tomorrow.
www.polkaudio.com/homealldiotisonic
(AvailalH
"'
uslDl
~
ontv)
SurroundBar'*SDA-lnstant
Home
Theater
The
Pol~
SurroundBa"SDA"
Instant
Home
Theater'"
is
the
simplest
way
yet
to
make
your
flat
panel
TV
sound
beller.
The
system
is
com-
posed
of
a
self·contained
powered
SUffoundBar
SDA
loudspeaker
and
companion
wireless
pow-
ered
subwoofer.
We
designed
it
for
anyone
who
wants
a
quick,
easy-to·
use
system
to
upgrade
a
TV's
buitHn
speakers
to
home
theater
sound
quality.
The
IHT
employs
our
patented
SDA-
I-Sonic·Entertainment
System
2
Polk
Audio's
I·SoniC-
is
the
first
all--digital
format
entertainment
system
using
the
latest
digital
technologies.
Connect
an
iPhone·
or
iPOO-
and
stream
videos
direttly
to
your
TV
and
enjoy
the
full
experience
of
an
entertainment
system.
Enjoy
CD
quality
HO
RadiO-
with
multicasting.
iTunes
Tagging.
an
iPhone/iPod
dock
and
MP3
home,
in
your
car
and
even
on
your
boat
or
out
by
the
pool.
learn
more
about
OUf
personal
dedication
to
great
sound.
and
why
we're
called
"The
Speaker
Specialists:"
www.polklludio.comlthespeakerspecialists
The
PSWi225's
cabinet
is
made
from
heavv-
duty.
non-resonant
MDf
...
is
internally
braced
and
ported
...
and
combines
an
8"
Dynamic
Balance-
floor·firing
driver
with
a
J-port
design
to
reduce
turbulence
at
the
port
mouth
and
optimize
bass
performance.
www.polk811dio.com/homealldioipswfpswi225
Freestanding
loudspeakers
Polk
Audio
offers
a
complete
line
of
loudspeakers
for
virtually
every
application.
from
floorstanding
and
bookshelf
models,
to
centers,
surrounds,
subwoofers
and
on-wall
designs,
we've
got
them
all.
With
Polk
Audio
you
can
create
the
audio
system
that
meets
your
exact
needs
to
deliver
a
stereo
or
home
theater
experience
that
will
thrill
you
for
years
to
come.
www.polkaudio.com/homeaudiolrtia
HomeAudio
From
the
very
beginning,
OUf
mission
has
been
to
provide
excellent
sound
at
reasonable
prices.
Almost
forty
years
later,
we're
still
committed
to
providing
products
that
enhance
the
value
of
your
entertainment,
in
your
PSWi225
Wireless Subwoofer
The
PSWi225Wireless
Subwoofer
is
the
must-have
upgrade
for
TV
sound.
This
compact
subwoofer
adds
no
cluner
to
your
room
at
all.
taking
up
tess
than
a
cubic
fOOl
of
space
and
adding
no
unsightly
wires.
Yet
it
irlstantly
adds
a
dimension
of
deep
bass
impact
to
your
other-
wise
two·dimensional
TV·watching
experience.
JJl_tLSpe_akeLSpecialislsc-® ,
Visit www.polkaudio.com for information
on
Polk Audio loudspeakers
and
electronic
products. Enter to
win
a
FREE
subwoofer
at www.polkaudio.com/insert
the speaker
speCialists'
~b;-
~,
There's more for you
at
Polk Audio.
polkaudio·
MM6501
If
you're
a
boater.
a
wide
range
of
Polk
Audio
mobile
products
are
marine
certified.
which
means
every
component
is
rugged
enough
to
withstand
marine
environments.
That
means
you
can
expect
the
same
outstanding
performance
on
the
water
as
our
speakers
are
known
for
on
land
www.polk&udio.com/caraudio/mm
blend
legendary
Polk
Audio
performance
with
incredibly
easy
installation.
M
Auo:lio.1'lll,
The
Spe<tW
Spegahm.
PowerI'on.
C¥-llaltonat.
FIX.
Amum,
Big
Speal:er
$/lund
Wtlhwt
The
Big
Spe<tW,
H9I
VelocllY
Compreuoon
011'1'9.
AccustJc
ReSG'\aII'lClI
Conlrol,
ARC
Port
Casbl
llaskeI.
I~
Suntudlar &
SOA
n
ragoSlerad
lrlldernl!r'<s
oIllllll!nnllllrM!stmern
Coqu8lHln
usedlJldlrficensebyPoillAOOoo.klcorporlled
../C~~'b
Polk
Audio's
mobile
products
are
truly
loud·
speakers
for
serious
listeners.
Our
db
Series
offers
Incredible
Sound.
Affordable
Price
in
a
full
range
of
loudspeakers,
component
groups
and
subwoofers.
Our
SR
Signature
Series
loudspeakers
and
ultra·performance
subwoofers
are
for
those
who
desire
audio-
phile
high
performance.
And
our
new
light-
weight
high
performance
MM
Series
loud-
speakers,
component
groups
and
subwoofers
Car&MarineAudio
5601
Metro
Drive
Baltimore.
MD
21215
800-31].7655
(US
&
Canada)
Outside
US
&
Canada
410·358·360(1
www.polkaudio.com
poIkaudio'
on
decks.
in
lhe
yard.
the
Atrium
Sub/Sat
System
gives
you
maximum
placement
flexibility
for
the
ultimate
in
all-weather
high
performance
sound.
www.potkaudio.comlhomeaudio/outdoor
Atrium-
SatJO
and
SublO
The
ingenious
Arrium
SublSat
System
leIs
you
blend
a
true
high-performance
speaker
system
into
your
landscape
or
transitional
outdoor
space,
With
endless
options
for
placement
and
mounting.
under
eaV1lS,
polkaudio®
This
is
your
Product
Model
and
Serial
Number.
Enter
this
number
in
the
"Serial
Number"
space
when
registering
your
product
online.
Keep
this
card
handy
for
Model
and
Serial
Number
reference
when
calling
Polk
Customer
Service.
Register
Your
New
Polk
Audio
Product
Online
NOW
for
a
Chance
to
win
$500
of
Polk
Product
www.polkaudio.com/registration/
~
Creates
a
permanent
record
of
your
purchase,
in
case
you
misplace
your
original
receipt.
~
Enters
you
in
our
monthly
FREE
drawing
for
$500-worth
of
Polk
Audio
Speakers.
~
Allows
you
to
enroll
in
Club
Polk:
for
informative
Polk
Website
Forums,
special
discounts
in
the
Polk
Webstore,
advance
notice
of
Polk
Promos,
and
discounts
on
Authorized
Polk
Audio
parts.
~
Keeps
you
up
to
date
when
there
is
news
and
announcements
about
your
product.
~
Gives
you
the
option
to
"opt-in" for
Polk
Audio's
Audio
Enjoyment
Enhancers:
Our
Monthly
Emails,
with
news,
reviews
and
tips
on
everything
audio.
We
take
your
privacy
seriously.
Polk
Audio
does
not
share
or
sell
infonnation
to
any
other
parties,
unless
directed
by
court
order.
Registering
your
product
has
no
effect
on
your
warranty.
Warranties
apply
as
stated
in
your
product
manual.
Please
be
sure
to
keep
your
original
purchase
receipt.
No
Internet
access?
Call
Polk
Audio
Customer
Service
800-371-7655
(US
&
Canada
only),
Outside
the
US
&
Canada,
call
410-358-3600.
We'll
walk
you
through
the
simple
registration
process!
Questions?
Concerns?
Contact
Polk
Audio
Customer
Service,
gam
-
5:30pm,
M-F,
EST
(USA)
800-311-7655
US
&
Canada
only
•
410-358-3600
outside
US
&
Canada
•
RM0320-8
