Caution : You must read this before you proceed
Recliner Chair
Noble House Home Furnishings LLC
Page 1 OF 10
Label Picture Description QTY
A Chair Backrest 1
B1 Right Wing 1
B2 Left Wing 1
C Chair Base 1
D Front Leg 2
E1 Right Hind Leg 1
E2 Left Hind Leg 1
Noble House Home Furnishings LLC
Page 2 OF 10
Label Picture Description QTY
①
Plastic Washer 3
②
Washer (M8) 7
③
Washer (M6) 3
④
Washer Ring 7
⑤
Bolt (M8*25mm) 7
⑥
Bolt (M6*40mm) 3
⑦
Allen Key(M6) 1
⑧
Allen Key(M8) 1
Noble House Home Furnishings LLC
Page 3 OF 10
OVERVIEW
This Recliner Chair has multiple parts and may require up to some 30
minutes to assemble. To give you an overview of the Recliner Chair parts,
the above picture is to help you put the various parts into perspective. Please
read through the instructions herebelow to familiarise the parts and steps
before assembly.
Before
Beginning
Assembly:
x7
x3
x7
x1
x1
x7
x3
x3
Right Wing(B1)
Right Hind Leg(E1)
Chair Backrest (A)
Front Leg (D)
Chair Base(C)
FRONT FACING
Left Wing(B2)
Noble House Home Furnishings LLC
Page 4 OF 10
Step 1
Step 2
Step 3
Place the Chair Base(C) facedown on a clean,non-marring surface.
Take out the four wooden legs and Hardware from inner box,as picture
shown on above.
Then,turn the Chair Base(C) upside down on a clean,non-marring surface.
Extend the Footrest to open.
Carefully take out inner box stowed as shown above.
Open it and you will find Right Wings (B1) & Left Wing(B2).
Stow the Footrest to original position.
Front Leg (D)
Chair Base (C)
Chair Base
Right Wing(B1)
Left Wing(B2)
Inner
Box
Footrest
D
Noble House Home Furnishings LLC
Page 5 OF 10
Step 4
Step 5
Position the Chair Base(C) on its back，as shown above.
Attach the Front Leg(D) to Chair Base(C) with Plastic Washer(①) by turning
the legs clockwise as shown.
Repeat the same step to install the remaining Front Leg(D).
Note: The use of Plastic Washer(①) are OPTIONAL and are especially
useful to help alleviate slight wobbleness. Some Legs may need more
than one Plastic Washer(①) whilst some Legs may not need any .
Attach the Right Hind Leg(E1) and Left Hind Leg(E2) to Chair Base(C) use
Bolt(⑤) ,Washer Ring(④),Washer(②) with Allen Key(⑧)by turning the legs
clockwise as shown.
Position the Chair Backrest(A) on it's right side.
Align the mounting positions of the Left Wing(B2) with left side of Chair
Backrest (A). Then slide Left Wing(B2) forward by hand to make sure it locks
into the position as shown in the picture.
Left Wing(B2)
Chair Backrest(A)
Chair Base (C)
Front Leg (D)
Right Hind Leg (E1)
Left Hind Leg
⑧
④
⑤
②
Noble House Home Furnishings LLC
Page 6 OF 10
Step 6
Step 7
Step 8
Attach Left Wing(B2) to the Chair Backrest(A) using Bolts(⑥) and
Washer(③) with Allen Key(⑦).
Fully tighten it until secure.
Repeat Step 5 and Step 6 to attach Right Wing(B1) to the right side of the
Chair Backrest(A) using Bolts(⑥) and Washer(③) with Allen Key(⑦).
With assistance from your adult partner,hold up the fully assembled backrest
with Wings,stand behind the chair. Insert the small metal arms on the sides
of the Chair Backrest into the prefabricated slide lock gadget on the Chair
Base as shown above.
Firmly but gently,push the Chair Backrest downwards until the Backrest is
fully slotted and locked into position.
Left Wing(B2)
Chair Backrest(A)
B1
Noble House Home Furnishings LLC
Page 7 OF 10
Step 9
Step 10
Step 11
Smooth down the fabric flap on the Chair Backrest.
Run your hands down both sides of the flap,from top to bottom,allowing the
velcro tape to adhere to the flap under the seat of the chair.
Make sure all parts are connected and securely locked into position.
Your Chair is ready for use.
Disassembly Note:Open the flap on the Chair Backrest(A),use a
screwdriver(Don't use fingers) pressing outward on the metal ear on the
preattached Metal Bracket on one side of the Chair Base(C),with assistance
of you adult partner to keep the Chair Base(C) in place, pull out the Chair
Backrest(A) upward at the same time,repeat the same step for another
side.Then the Chair Backrest(A) can be taken out.
C
B2
B
1
C
C
A
Noble House Home Furnishings LLC
Page 8 OF 10
Supervise children, when in use of this Recliner.
Do not allow children to play on the chair.
Always leave the chair in an upright and closed position after use.
Keep hands and feet clear of the footrest mechanism and ANY gaps.
Only the occupant should operate the Chair.
To get into a reclined posture - To Recline backrest
Sit into the seat.
Place your feet apart .
Place your left and right arm onto the armrest.
Synchronise a backward push with your arms.
Use your body weight and push backwards into the seat into a fully reclined
position.
To get out of chair - move Seatback into Upright Position
Tilt your body weight slightly forward and upwards.
The seat back will come up to an upright position.
Where necessary, use either your arms help lift- push yourself out of the
seat.
User Instructions.
Recliner Chair
Please read the Instruction Manual below carefully before use.
This is a Recliner Chair. At anytime in a reclined seat position or in the
upright position. You may enjoy the rocking motion by using your body weight
in a back-front rocking motion.
Noble House Home Furnishings LLC
Page 9 OF 10
