Write the model and serial
numbers here:
Model # _________________
Serial # _________________
You can
the rating label on
the front behind the range drawer.
OWNER’S MANUAL
RANGES
Electric Induction Slide-In
295D3313P011 Pub. Num. 29-6397
SAFETY INFORMATION .......... 3
USING THE RANGE
Surface Units . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cookware for Induction Cooktop . . . . . . . . .10
Oven Controls . . . . . . . . . . . . . . . . . . . . . . . . . .12
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Sabbath Mode . . . . . . . . . . . . . . . . . . . . . . . . . .16
Oven Racks . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Aluminum Foil and Oven Liners ...........18
Cookware ..............................18
Cooking Modes . . . . . . . . . . . . . . . . . . . . . . . . .19
Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Cooking Guide . . . . . . . . . . . . . . . . . . . . . . . . .21
CARE AND CLEANING
Cleaning the Range – Exterior . . . . . . . . . . . 22
Cleaning the Range – Interior . . . . . . . . . . . 23
Cleaning the Glass Cooktop . . . . . . . . . . . . . 24
Probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Oven Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Oven Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
TROUBLESHOOTING TIPS....... 27
WARRANTY .......................30
ACCESSORIES .....................31
CONSUMER SUPPORT ........... 32
PCHS920
GE is a trademark of the General Electric Company. Manufactured under trademark license.
2
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.
3
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
ANTI-TIP DEVICE
To reduce the risk of tipping the range,
the range must be secured by a properly
installed anti-tip bracket. See installation
instructions shipped with the bracket for
complete details before attempting to install.
For Free-Standing and Slide-In Ranges
To check if the bracket is installed and
engaged properly, look underneath the
range to see that the rear leveling leg is
engaged in the bracket. On some models, the storage drawer or kick panel
can be removed for easy inspection. If visual inspection is not possible,
slide the range forward, confirm the anti-tip bracket is securely attached to
the floor or wall, and slide the range back so the rear leveling leg is under
the anti-tip bracket.
If the range is pulled from the wall for any reason, always repeat this
procedure to verify the range is properly secured by the anti-tip bracket.
Never completely remove the leveling legs or the range will not be secured
to the anti-tip device properly.
WARNING
Read all safety instructions before using the product. Failure to follow these instructions may result
in fire, electrical shock, serious injury or death.
• A child or adult can tip the range and be killed.
• Install the anti-tip bracket to the wall or floor.
•
Engage the range to the anti-tip bracket by sliding the
e
range back such that the foot is engaged.
• Re-engage the anti-tip bracket if the range is moved.
• Failure to do so can result in death or serious burns
to children or adults.
Tip-Over Hazard
WARNING
Anti-Tip
Bracket
Leveling Leg
Free-Standing and Slide-In Ranges
WARNING
GENERAL SAFETY INSTRUCTIONS
This unit has been tested and found to comply with the limits for a class B digital device, pursuant to Part 18
of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This unit generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this unit does cause harmful
interference to radio or television reception, which can be determined by turning the unit off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
CAUTION
Persons with a pacemaker or similar medical device should exercise caution when
using or standing near an induction unit while it is in operation. The electromagnetic field may affect the
working of the pacemaker or similar medical device. It is advisable to consult your doctor or the pacemaker
manufacturer about your particular situation.
described in this Owner’s Manual.
grounded by a qualified installer in accordance with
the provided installation instructions.
range unless it is specifically recommended in this
manual. All other servicing should be transferred to
a qualified technician.
4
WARNING
KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE
Failure to do so may result in fire or personal injury.
or near the cooktop, including paper, plastic, pot
holders, linens, wall coverings, curtains, drapes and
gasoline or other flammable vapors and liquids.
using the appliance. These garments may ignite if
they contact hot surfaces causing severe burns.
materials accumulate in or near the range. Grease
in the oven or on the cooktop may ignite.
not be allowed to accumulate on the hood or filter.
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
WARNING
IN THE EVENT OF A FIRE, TAKE THE FOLLOWING
STEPS TO PREVENT INJURY AND FIRE SPREADING
a flaming pan. Turn the controls off. Smother a
flaming pan on a surface unit by covering the pan
completely with a well-fitting lid, cookie sheet or flat
fire extinguisher.
the fire by closing the oven door and turning the
oven off or by using a multi-purpose dry chemical or
foam-type fire extinguisher.
the oven off and wait for the fire to go out.
force the door open. Introduction of fresh air at self-
clean temperatures may lead to a burst of flame
from the oven. Failure to follow this instruction may
result in severe burns.
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
GENERAL SAFETY INSTRUCTIONS (Cont.)
or disconnect the power supply at the household
distribution panel by removing the fuse or switching
off the circuit breaker.
be left alone or unattended in an area where an
appliance is in use. They should never be allowed
to climb, sit or stand on any part of the appliance.
CAUTION
children above a range or on the backguard of a
items could be seriously injured.
holders on hot surfaces may result in burns from
other bulky cloth in place of pot holders.
the room.
or the interior surface of the oven. These surfaces
may be hot enough to burn even though they are
or let clothing or other flammable materials contact
the surface units, areas nearby the surface units or
any interior area of the oven; allow sufficient time
for cooling first. Other surfaces of the appliance
may become hot enough to cause burns. Potentially
hot surfaces include the cooktop, areas facing the
cooktop, oven vent opening, surfaces near the
opening and crevices around the oven door.
could build up and the container could burst,
causing an injury.
oven bottom or anywhere in the oven, except as
described in this manual. Oven liners can trap heat
or melt, resulting in damage to the product and risk
of shock, smoke or fire.
glass. Shock, fire or cuts may occur.
an internal temperature of 160°F and poultry to at
least an internal temperature of 180°F. Cooking
to these temperatures usually protects against
foodborne illness.
5
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
COOKTOP SAFETY INSTRUCTIONS
or high heat settings. Boilovers cause smoking and
greasy spillovers that may catch on fire.
to heat beyond its smoking point, oil may ignite
resulting in fire that may spread to surrounding
possible to monitor oil temperature.
amount of oil when shallow pan-frying and avoid
cooking frozen foods with excessive amounts of ice.
earthenware or other glazed containers are suitable
for cooktop service; others may break because of
the sudden change in temperature.
flammable materials and spillage, the handle of a
container should be turned toward the center of the
range without extending over nearby surface units.
the fan on.
WARNING
GLASS COOKTOP SAFETY INSTRUCTIONS
surface of the cooktop will retain heat after the
controls have been turned off.
should break, cleaning solutions and spillovers
may penetrate the broken cooktop and create a
risk of electric shock. Contact a qualified technician
immediately.
can be scratched with items such as knives, sharp
instruments, rings or other jewelry, and rivets on
clothing.
®
ceramic Cooktop Cleaner
and CERAMA BRYTE
®
Cleaning Pad to clean
the cooktop. Wait until the cooktop cools and the
indicator light goes out before cleaning. A wet
sponge or cloth on a hot surface can cause steam
burns. Some cleaners can produce noxious fumes if
applied to a hot surface. NOTE: Sugar spills are an
exception. They should be scraped off while still hot
using an oven mitt and a scraper. See the Cleaning
the glass cooktop section for detailed instructions.
cleaning cream label.
fire on the glass cooktop, even when it is not being
used. If the cooktop is inadvertently turned on, they
may ignite. Heat from the cooktop or oven vent after
it is turned off may cause them to ignite also.
spoons and lids on the cooktop surface since they
can get hot.
WARNING
OVEN SAFETY INSTRUCTIONS
door. Hot air or steam which escapes can cause
a glowing spot during use or shows other signs
of damage. A glowing spot indicates the heating
element may fail and present a potential burn, fire,
or shock hazard. Turn the oven off immediately and
have the heating element replaced by a qualified
service technician.
the oven may ignite.
cool. If rack must be moved while oven is hot, do not
let pot holder contact hot heating element in oven.
follow the manufacturer’s directions.
6
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
SELF-CLEANING OVEN SAFETY INSTRUCTIONS
The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.
Follow these instructions for safe operation.
self-cleaning. Failure to follow these instructions
may cause burns.
shiny metal oven racks and other utensils from the
oven. Only gray porcelain-coated oven racks may
other parts, such as drip pans or bowls.
and food soils from the oven. Excessive amount
of grease may ignite leading to smoke damage to
your home.
oven off and disconnect the power supply. Have it
serviced by a qualified technician.
essential for a good seal. Care should be taken not
to rub, damage or move the gasket.
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven.
WARNING
WARMING DRAWER SAFETY INSTRUCTIONS (Some models)
cooked foods at serving temperature. Bacteria will
than 2 hours. Failure to follow these instructions
may result in foodborne illness.
combustible materials in the drawer. They may ignite.
surface of the drawer. These surfaces may be hot
enough to cause burns.
a crack and let hot air or steam escape before
removing or replacing food. Hot air or steam that
drawer. The foil will trap heat below, and upset
the performance of the oven. Foil can melt and
from improper use of aluminum foil is not covered
by the product warranty.
WARNING
OVEN SAFETY INSTRUCTIONS (Cont.)
loading and unloading food from the oven. This
helps prevent burns from touching hot surfaces of
the door and oven walls.
or food in the oven when not in use. Items stored in
an oven can ignite.
or any type of foil or liner on the oven floor. These
items can trap heat or melt, resulting in damage to
the product and risk of shock, smoke or fire.
7
How to Remove Protective Shipping Film and Packaging Tape
Carefully grasp a corner of the protective shipping film
with your fingers and slowly peel it from the appliance
Remove all of the film before using the appliance for the
first time.
To assure no damage is done to the finish of the
product, the safest way to remove the adhesive from
packaging tape on new appliances is an application of
a household liquid dishwashing detergent. Apply with a
soft cloth and allow to soak.
NOTE: The adhesive must be removed from all parts. It
cannot be removed if it is baked on.
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
Remote Enable Equipment
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
The wireless communication equipment installed on this
range has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to:
(a) provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
receiver.
different from that to which the receiver is connected.
technician for help.
(b) accept any interference received, including interference
that may cause undesired operation of the device.
Note that any changes or modifications to the wireless
communication device installed on this oven that are not
expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
8
USING THE RANGE:
Surface Units
How Induction Surface Cooking Works
The elements beneath the cooking surface produce a
magnetic field that generates heat in ferrous metal pans
that are in close proximity.
The cooking surface itself does not heat. Heat is
produced in the cooking pan, and cannot be generated
until a pan is placed on the cooking surface.
When the element is activated, the pan begins to heat
immediately and in turn heats the contents of the pan.
Magnetic induction cooking requires the use of cookware
stick, such as iron or steel.
enough for the element to detect the pan and be able to
deliver full power.
The cooktop will not operate if a very small steel or iron
utensil, such as a steel spatula, cooking spoon, knife
or other small utensil, is placed on the cooking surface
when the unit is turned on.
CAUTION
while turned ON and after they have been turned OFF.
The glass surface may be HOT from residual heat
transferred from the cookware and burns may occur.
with hands. Always use mitts or pot holders to protect
hands from burns.
the ceramic cooktop.
The pan material is correct if a magnet sticks to the bottom.
How to Set
WARNING
FIRE HAZARD: Never leave the
range unattended with the cooktop on medium or
high settings. Keep flammable items away from the
cooktop. Turn off all controls when done cooking.
Failure to follow these instructions can result in fire,
serious injury or death.
Before using the cooktop for the first time, clean it with
CERAMA BRYTE
®
Ceramic Cooktop Cleaner. This helps
protect the top and makes cleanup easier.
Throughout this manual, features and appearance may
vary from your model.
Place your Induction designed cookware on the cooking
surface.
Turn element(s) On: Place your induction designed
cookware on the cooking surface. Touch and hold On/
Off pad about half a second. A chime can be heard with
each touch to any pad.
Power level can be selected in any of the following ways:
1. Swipe the gray arc (on the graphics) to the desired
power level. There is no sensor on the LEDs, or;
2. Touch Anywhere along the gray arc, or;
3. Touch + or - pads to adjust power level, or;
4. Shortcut to Hi: Immediately after turning unit on, touch
the + pad, or;
5. Shortcut to Low: Immediately after turning unit on,
touch the - pad.
Gray Arc
Swipe Area
Lights
Gray Arc Swipe Area
9
USING THE RANGE:
Surface Units (Cont.)
Using the Warming Zone (on some models)
WARNING
FOOD POISON HAZARD: Bacteria may grow in food at
temperatures below 140°F.
heat cold food.
The WARMING ZONE, located in the back center of
the glass surface, will keep hot, cooked food at serving
heat cold food. Placing uncooked or cold food on the
WARMING ZONE could result in foodborne illness.
To turn the WARMING ZONE on, press Warming Zone
ON/OFF, select Lo, Med or Hi with the number pads,
and press Start.
For best results, all foods on the WARMING ZONE
should be covered with a lid or aluminum foil. When
warming pastries or breads, the cover should be vented
to allow moisture to escape.
The initial temperature, type and amount of food, type of
pan, and the time held will affect the quality of the food.
Always use pot holders or oven mitts when removing
food from the WARMING ZONE, since cookware and
plates will be hot.
How To Synchronize Left Elements
To Turn On
Hold the Sync Burners pad for about half a second to
connect the two elements. Operate either element as
described in Operating the Cooktop Elements to adjust
power level.
To Turn Off
1. Touch the On/Off pad on either element to turn off
the Sync Burners.
or
2. Touch the Sync Burners to turn both elements off.
10
Cookware for Induction Cooktop
USING THE RANGE: Cookware for Induction Cooktop
Suitable Cookware
heat distribution and even cooking results. Choose
cookware made of magnetic stainless steel, enamel
coated cast iron, enameled steel or combinations of
these materials.
Some cookware is specifically identified by the
magnet to test if the cookware will work.
Flat-bottomed pans give best results. Pans with rims or
slight ridges can be used.
Round pans give best results. Pans with warped or
curved bottoms will not heat evenly.
wok with a support ring.
NOTE: The warming zone is NOT an induction element
and will work with flat bottomed cookware that is NOT
Using the correct size cookware
Pans that are not ferrous or are too small will not allow
the induction elements to turn on, and the ON indicator
for that element location will flash for 25 seconds and
then turn off. If a pan is removed from the induction coil
or not centered on the coil for more than 30 seconds, the
power for that element will be shut off.
Cookware larger than the element ring may be used;
however, heat will only occur above the element.
with the glass surface.
the surrounding metal cooktop trim.
For best performance, match the pan size to the element
less power at any given setting.
Cookware “Noise”
Slight sounds may be produced by different types
of cookware. Heavier pans such as enameled cast
iron produce less noise than a lighter weight multi-ply
stainless steel pan. The size of the pan, and the amount
of contents, can also contribute to the sound level.
When using adjacent elements that are set at certain power
level settings, magnetic fields may interact and produce
a low whistle or intermittent “hum”. These noises can be
reduced or eliminated by lowering or raising the power
level settings of one or both of the elements. Pans that
completely cover the element ring will produce less noise.
A low “humming” noise is normal particularly on high
settings.
Sounds you may here: You may hear a slight “Buzz”
when cooking with Hi mode. This is normal. The sound
depends on the type of pot being used. Some pots will
“Buzz” louder depending on the material. A “Buzz” sound
may be heard if the pan contents are cold. As the pan
heats, the sound will decrease. If the power level is
reduced, the sound level will go down.
Power Control
If a surface unit is on power level H (high), for an
extended period of time or if multiple surface units are
on, there may be a slight reduction in power to the
surface unit. Water under pans may also cause the
controls to reduce the power delivered to the cookware.
each cooking element.
Size
Size
Pan Size
Pan Size
11
USING THE RANGE: Cookware for Induction Cooktop
Cookware for Induction Cooktop (Cont.)
Cookware not centered on
cooking element surface.
Curved or warped pan bottoms
or sides.
Pan does not meet the minimum
size required for the cooking
element used.
Cookware centered correctly
on cooking element surface.
Flat pan bottom.
Pan size meets or exceeds the
recommended minimum size
for the cooking element used.
INCORRECT
CORRECT
Pan bottom rests on cooktop
trim or does not rest completely
on the cooktop surface.
Heavy handle tilts pan.
Pan is partially magnetic
on the bottom.
Pan is completely magnetic
on the bottom.
Pan bottom rests completely on
the cooktop surface.
Pan is properly balanced.
Cookware recommendations
Cookware must fully contact the surface of the cooking
element.
and also to the amount of food being prepared.
Induction interface disks are NOT recommended.
12
USING THE RANGE: Oven Controls
Oven Controls
1. Convection Cooking Modes: Convection
cooking mode uses increased air circulation to
improve performance. See the Cooking Modes
section for more information.
2. Traditional Cooking Modes: Your oven
has the following traditional cooking modes: Bake
and Broil. See the Cooking Modes section for more
information.
3. Warm: Will keep hot, cooked foods at serving
temperature. See the Cooking Modes section for
more information.
4. Clean: Your oven has two cleaning modes: Self
Clean and Steam Clean. See the Cleaning the Oven
section for important information about using these
modes.
5. Start/Enter: Must be pressed to start any
cooking, cleaning, or timed function.
6. Cancel/Off: Cancels ALL oven operations
except the clock, timer and warming drawer.
7. Timer: Works as a countdown timer. Press the
Timer pad and use the number pads to program the
time in hours and minutes. Press the Start/Enter
pad. The oven will continue to operate when the
timer countdown is complete. To turn the timer off,
press the Timer pad.
8. Oven Light: Turns the oven light on or off.
9. Lock Controls: Locks out the control so that
pressing the pads does not activate the controls.
Press the Lock Controls pad, for three seconds
to lock or unlock the control. Cancel/Off is always
active, even when the control is locked.
10.
Remote Enable:
Allows you to control
your oven remotely. To be able to start the oven
remotely, press the Remote Enable pad, and
“Remote” will be lit in the display. The oven can
now be remotely started with a connected device.
Opening the oven door or pressing the Remote
Enable pad will remove “Remote” from the display
and prevent you from being able to turn the oven on
remotely. If “Remote” is not shown in the display,
you are still able to change the oven settings or
turn the oven off. After using the oven, remember
to verify that the “Remote” icon is displayed if you
wish to start the oven remotely in the future. For
instructions on how to connect your oven, see the
WiFi Connect section of this manual.
11. Settings: See the Settings section for more
information.
12. Options: See the Options section for more
information.
1
8
23
7546
9
10 11
12
Hold 3 Sec
Maintenir 3 sec
Options
Paramètres
Settings
Activer commande
à distance
Remote Enable
Warm
Chaud
Broil
Griller
Minuterie
Timer
Autonettoyer/
Nettoyage Vapeur
Clean
Bake
Cuire
Verrouillage des
contrôles
Lock Controls
Conv.
Roast
Conv. Rôtir
Conv.
Bake
Conv. Cuire
Start/Enter
Départ/Entrée
Cancel /
Anuler/arrêt
Lampe du Four
Oven Light
13
Settings
USING THE RANGE: Settings
The Options and Settings pads open up more detailed menus in the display that allow access to additional
functions. For each you select the function in the display using the associated number pad. You can exit at
any time by pressing the Options or Settings pad again.
Clock
This setting sets the oven clock time. Press the Settings
pad and select Clock. Select Set Clock and follow the
instructions to set the clock. This feature also specifies
how the time of day will be displayed. You can select
a standard 12-hour clock (12H), 24-hour military time
display (24H), or no clock displayed (Off). Press the
Settings pad, select Set Clock and select either 12/24 hr
or On/Off.
WiFi
Select Settings and WiFi. It is necessary to turn on WiFi
before using Remote Enable on your oven.
Bluetooth
®
- Chef Connect
This is a pairing feature for use with other compatible
Chef Connect enabled products like an over-the-
range microwave oven or range hood. To pair those
products to the range Press the Settings pad and select
Bluetooth
®
. Select Pair and follow the corresponding
instructions included with the mating Chef Connect
enabled product. The range will cancel pairing mode
after two minutes if no mating device is detected. Select
Remove to confirm product is paired or to un-pair from
range. The Precision Cooking Probe can also be paired
using the Bluetooth
®
feature.
Sabbath
See the Sabbath Mode section.
Auto Conversion
When using Convection Bake and Convection Roast
cooking, Auto Recipe Conversion will automatically
convert the regular baking temperatures entered to
convection bake cooking temperatures when turned
on. Note that this option does not convert convection
bake cooking times, it only converts temperatures. This
feature may be turned On or Off. Select Settings, Auto
Conversion is 5th option and shows up on first display of
settings, and Auto Conversion then follow the prompts
to turn this feature on or off.
Auto Off
This feature shuts the oven down after 12 hours of
continuous operation. It may be enabled or disabled.
Select Settings, More, and Auto Off to turn this feature
on or off.
Sound
You can adjust the volume and type of alert your appliance
uses. Select Settings, More, and Sound. Follow prompts
for making volume adjustments or for changing between
continuous and single alert tones. A continuous setting
will continue to sound a tone until a button on the control
is pressed. The oven tone volume can be adjusted. The
control will sound the oven tone at the new volume level
each time the sound level is changed.
F/C (Fahrenheit or Celsius)
The oven control is set to use Fahrenheit temperatures
(F), but you can change it to use Celsius temperatures
(C). Select Settings, More, and F/C to alter between
temperature scales displayed.
Adjust the Oven temperature
This feature allows the oven baking and convection
baking temperature to be adjusted up to 35ºF hotter
your oven temperature is too hot or too cold and wish to
change it. This adjustment affects Bake and Convection
Settings and Oven Adjust to add More Heat or
Less Heat and then press Save.
Oven Info
Select Settings, More, and Oven Info to turn this
feature on or off. This setting displays Model Number and
Select
14
Options
USING THE RANGE: Options
The Options and Settings pads open up more detailed menus in the display that allow access to additional
functions. For each you select the function in the display using the associated number pad. You can exit at
any time by pressing the Options or Settings pad again.
Proof, Frozen Snacks, Frozen Pizza & Baked Goods, are not available on model PCHS920. See
the cooking modes section for more information.
You must first select a mode (bake, convection bake, convection roast) and then select Options to get to the
following functions.
Cook Time
Counts down cooking time and turns off the oven when
the cooking time is complete. Select a desired cooking
temperature. Press the Options pad and select Cook
Time
and minutes. Then press Start/Enter.
Delay Time
time when you want the oven to start. Select a desired
temperature. Press the Options pad and select Delay
Time
for the oven to turn on, and then press Start/Enter
Time is not available with all modes.
NOTE:
spoil easily – such as milk, eggs, fish, stuffing, poultry,
and port – should not be allowed to sit for more than
1 hour before or after cooking. Room temperature
promotes the growth of harmful bacteria. Be sure that the
oven light is off because heat from the bulb will speed
harmful bacteria growth.
Oven Probe
Monitors internal food temperature and turns the oven
off when the food reaches the programmed temperature.
Insert the probe, press the desired cooking mode, and
program the probe temperature. See the Cooking Modes
Section for more information. The probe can only be used
with Bake, Convection Bake, and Convection Roast.
* Compatible Apple or Android devices and home WiFi network required.
Settings (Some models)
The Options and Settings pads open up more detailed menus in the display that allow access to additional
functions. For each you select the function in the display using the associated number pad. You can exit at
any time by pressing the Options or Settings pad again.
WiFi Connect/Remote Enable
Your oven is designed to provide you with two-way
communication between your appliance and smart
device. By using the WiFi Connect features, you will
be able to control essential oven operations such as
temperature settings, timers and cooking modes using
your smartphone or tablet.*
Select Settings then Wifi - follow the instructions on your
oven display and phone app. It is necessary to turn on
WiFi before using Remote Enable on your oven.
Connecting your WiFi Connect Enabled Oven
What you will need
Your GE Appliances oven uses your existing home WiFi
network to communicate between the appliance and
your smart device. In order to setup your GE Appliances
oven, you will need to gather some information:
1. Each GE Appliances oven has a connected appliance
information label that includes an Appliance Network
Name and Password. These are the two important
details that you will need to connect to the appliance.
The label is typically located inside the door of the
oven or drawer.
2. Have your smart phone or tablet ready with the ability
to access the internet and download apps.
3. You will need to know the password of your home
WiFi router. Have this password ready while you are
setting up your GE Appliances oven.
Connect your GE Appliances oven
1. On your smart phone or tablet visit
connected appliance features and to download the
appropriate app.
2. Follow the app onscreen instructions to connect your
GE Appliances oven.
3. Once the process is complete, the connection light
located on your GE Appliances oven display will stay
on solid and the app will confirm you are connected.
FCC: ZKJ-WCATA001
Network: GE_XXXXXX_XXXX
Password: XXXXXXXX
PT. NO. 229C6272G001-0
IC: 10229A-WCATA001
MAC ID: XX - XX - XX - XX - XX - XX
Connected Appliance Information
Sample Label
(Available on some models)
15
USING THE RANGE: Settings
Settings (Cont.)
WiFi Connect and Remote Enable (cont.)
4. If the connection light does not turn on or is blinking,
follow the instructions on the app to reconnect. If
issues continue, please call the Connected Call
Center 1.866.626.2000 and ask for assistance
regarding oven wireless connectivity.
To connect additional smart devices, repeat steps 1 and 2.
Note that any changes or modifications to the remote
enable device installed on this oven that are not
expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
REMOTE STARTING YOUR OVEN
To be able to start the oven remotely once connected to
WiFi, press the Remote Enable pad and the icon will
turn on in the display. The oven can now be remotely
started with a connected device. Opening an oven door or
turning off the oven will turn off the
icon. The icon must
be lit to start the oven remotely. The icon is not required
to change the oven temperature while it is running, set a
timer or to turn the oven off from the phone app while the
icon shows it is Wifi Connected.
After using the oven, remember to verify that the icon
is lit if you wish to start the oven remotely in the future.
NOTE:
sit for more than 1 hour before or after cooking. Room
temperature promotes the growth of harmful bacteria. Be
sure that the oven light is off because heat from the bulb
will speed harmful bacteria growth.
Clock
This setting sets the oven clock time. Press the Settings
pad and select Clock. Select Set Clock and follow the
instructions to set the clock. This feature also specifies
how the time of day will be displayed. You can select a
standard 12-hour clock (12H), 24-hour military time display
(24H), or no clock displayed (Off). Press the Settings pad,
select Set Clock and select either 12/24 hr or On/Off.
Bluetooth
®
- Chef Connect
This is a pairing feature for use with other compatible
Chef Connect enabled products like an over-the-
range microwave oven or range hood. To pair those
products to the range Press the Settings pad and select
Bluetooth
®
. Select Pair and follow the corresponding
instructions included with the mating Chef Connect
enabled product. The range will cancel pairing mode
after two minutes if no mating device is detected. Select
Remove to confirm product is paired or to un-pair from
range. The Precision Cooking Probe can also be paired
using the Bluetooth
®
feature.
Auto Conv (Auto Conversion)
When using Convection Bake and Convection Roast
cooking, Auto Recipe Conversion will automatically
convert the regular baking temperatures entered to
convection bake cooking temperatures when turned
on. Note that this option does not convert convection
bake cooking times, it only converts temperatures. This
feature may be turned On or Off. Select Settings, Auto
Conversion is 5th option and shows up on first display of
settings, and Auto Conversion then follow the prompts
to turn this feature on or off.
Auto Off
This feature shuts the oven down after 12 hours of
continuous operation. It may be enabled or disabled.
Select Settings, More, and Auto Off to turn this feature
on or off.
Sound
You can adjust the volume and type of alert your appliance
uses. Select Settings, More, and Sound. Follow prompts
for making volume adjustments or for changing between
continuous and single alert tones. A continuous setting
will continue to sound a tone until a button on the control
is pressed. The oven tone volume can be adjusted. The
control will sound the oven tone at the new volume level
each time the sound level is changed.
F/C (Fahrenheit or Celsius)
The oven control is set to use Fahrenheit temperatures
(F), but you can change it to use Celsius temperatures
(C). Select Settings, More, and F/C to alter between
temperature scales displayed.
Adjust the Oven temperature
This feature allows the oven baking and convection
baking temperature to be adjusted up to 35ºF hotter
your oven temperature is too hot or too cold and wish to
change it. This adjustment affects Bake and Convection
Select Settings and Oven Adjust to add More Heat or
Less Heat and then press Save.
Oven Info
Select Settings, More, and Oven Info to turn this
feature on or off. This setting displays Model Number and
16
USING THE RANGE: Sabbath Mode
by the consumer include the disabling of tones, disabling of oven lights, and delays of about 30 seconds to one
minute on display changes. Only continuous baking or timed baking is allowed in the Sabbath mode. Cooking in the
Sabbath mode is a two-step process, first the Sabbath mode must be set and then the bake mode must be set.
Setting the Sabbath Mode
Press the Settings pad, select Sabbath, and select
Turn on. A single bracket “]” will appear in the display
indicating that the Sabbath mode is set. The clock will not
be displayed. Continuous bake or timed bake can now be
programmed.
Starting a Continuous Bake
1. Press the Bake pad.
2. If the desired temperature is 350F, press Start/
Enter. If a different cooking temperature is desired,
use the 1 through 5 number pads to select a preset
cooking temperature, then press Start/Enter. Refer
to the graphic below to determine which pad sets the
desired cooking temperature.
After a delay, a second bracket “] [“ will appear in the
display indicating that the oven is baking.
Adjusting the Temperature
1. Press Bake, use the 1 through 5 number pads to
select a different preset cooking temperature, and
press Start/Enter.
2. Since no feedback is given during temperature
change, an oven thermometer can be used to confirm
temperature changes.
Starting a Timed Bake
1. Press the Bake pad.
2. If the desired temperature is 350F, use the 6 through
0 number pads to select a cooking time. If a cooking
temperature other than 350F is desired, use the 1
through 5 number pads to select a preset cooking
temperature, then select the cooking time. Refer to
the graphic on this page to determine which pad sets
the desired cooking temperature and cooking time.
3. Press .
After a delay, a second bracket “] [“ will appear in the
display indicating that the oven is baking. When the cook
time expires, the display will change back to a single
bracket “]” indicating that the oven is no longer baking.
No tone will sound when the cook time is complete.
Exit the Sabbath Mode
Exiting the Sabbath mode should be done after the
Sabbath is over.
1. Press Cancel/Off to end any bake mode that may be
running.
2. Press and hold Settings pad until Sabbath Mode off
is displayed.
Sabbath Mode Power Outage Note
If a power outage occurs while the oven is in Sabbath
Mode, the unit will return to Sabbath Mode when power
is restored, however the oven will return to the off state
even if it was in the middle of a bake cycle when the
power outage occurred.
Temperature (°F)
Time (hours)
200
325
2.5h
250
400
3h
4h
300
2h
3.5h
1 = 200°F, 2 = 250°F, 3 = 300°F, 4 = 325°F, 5 = 400°F
6 = 2 hours, 7 = 2.5 hours, 8 = 3 hours, 9 = 3.5 hours, 0 = 4 hours
Sabbath Mode
Start/Enter
After a delay, a se
display indicatin
time expires,
bracket “]”
No tone
17
USING THE RANGE: Oven Racks
The number of rack positions may vary by model.
Rail
Fully Open Position
Grasp here
Oven Racks
Recommended rack positions for various types of
foods are provided in the Cooking Guide. Adjusting
rack position is one way to impact cooking results. For
example, if you would prefer darker tops on cakes,
muffins, or cookies, try moving food one rack position
higher. If you find foods are too brown on top try moving
them down next time.
When baking with multiple pans and on multiple racks,
ensure there is at least 1½" between pans to allow
sufficient space for air to flow.
flat racks.
To avoid possible burns, place the racks in the desired
position before you turn the oven on.
Extension Racks
Always pull the rack out by its upper front rail to its fully
open position, when placing or removing cookware.
If extension racks are difficult to extend, lubricate the
racks with the graphite lubricant provided with your
oven. Remove the rack from the oven, remove debris in
the side tracks with a paper towel, shake the graphite
lubricant and place 4 small drops on the two bottom
tracks of the left and right sides. Open and close the
rack several times to distribute the lubricant.
To order additional graphite lubricant, see the
Accessories and Consumer Support sections at the end
of this manual.
To Remove An Extension Rack:
1. Make sure the rack is pushed all the way into the
oven so that side paddles on the rack disengage from
the oven support.
2. Slide the rack toward you to the bump (stop position)
on the rack support.
3. Firmly grasp both sides of the rack frame and the
sliding rack, tilt the front end up and pull it out.
To Replace An Extension Rack:
1. Firmly grasp both sides of the rack frame and the
sliding rack.
2. Place the curved end of the rack (stop-locks) onto the
oven supports, tilt up the front of the rack and push it
in as far as it will go.
If extension racks are difficult to replace or remove, wipe
on the rack slides.
To Lubricate the Paddle:
Shake lubricant and apply to the moving parts of the
paddle mechanisms as shown.
18
USING THE RANGE: Aluminum Foil and Oven Liners / Cookware
Cookware
Cookware Guidelines
The material, finish, and size of cookware affect baking
performance.
than light, shiny pans. Pans that absorb heat more
readily can result in a browner, crisper, and thicker crust.
If using dark and coated cookware check food earlier
than minimum cook time. If undesirable results are
obtained with this type of cookware consider reducing
oven temperature by 25°F next time.
Shiny pans can produce more evenly cooked baked
goods such as cakes and cookies.
Glass and ceramic pans heat slowly but retain heat well.
These types of pans work well for dishes such as pies
and custards.
Air insulated pans heat slowly and can reduce bottom
browning.
CAUTION
Do not use any type of foil or oven liner to cover the oven bottom. These items can trap heat
or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use of
these items is not covered by the product warranty.
to prevent poor heat circulation.
Aluminum Foil and Oven Liners
19
USING THE RANGE: Cooking Modes
Your oven has a variety of cooking modes to help you get the best results. These modes are described below. See
the Cooking Guide for rack position and other recommendations for specific modes and foods.
Bake
The bake mode is for baking and roasting. When
preparing baked goods such as cakes, cookies and
pastries, always preheat the oven first. To use this
mode press the Bake pad, enter a temperature with the
number pads, and then press Start/Enter.
Broil
placing food close to the broil element or burner
increases smoking, spattering and the possibility of fats
igniting. It is not necessary to preheat when using the
Broil modes.
The Broil High mode uses intense heat from the upper
a seared surface and rare interior. To use this mode
press the Broil pad once and then press Start/Enter.
The Broil Low mode uses less intense heat from the
upper element or burner to cook food thoroughly while
way through. To use this mode press the Broil
and then press Start/Enter.
Convection Bake Multi Rack
The Convection Bake mode is intended for baking
on multiple racks at the same time. This mode uses
air movement from the convection fan to enhance
cooking evenness. Your oven is equipped with Auto
Recipe Conversion, so it is not necessary to adjust the
temperature when using this mode. Always preheat
when using this mode. Baking times may be slightly
longer for multiple racks than what would be expected
for a single rack. To use this mode press the Conv Bake
pad, enter a temperature with number pads, and then
press Start/Enter.
Convection Roast
The Convection Roast mode is intended for roasting
whole cuts of meat on a single rack. This mode uses air
movement from the convection fan to improve browning
and reduce cooking time. Check food earlier than the
recipe suggested time when using this mode, or use the
probe (see the Probe section for more information). It is
not necessary to preheat when using this mode. To use
this mode press the Conv Roast pad, enter a temperature
with the number pads, and then press Start/Enter.
Warm
Warm modes are designed to keep hot, cooked foods hot
.
Cover foods that should remain moist and do not cover
not use Warm to heat cold food. It is recommended that
food not be kept warm for more than 2 hours.
Some models may also have warming drawers. Three
settings are available - use High for items such as
stews, meats, and potatoes; use Medium for items such
as casseroles and pizzas; use Low for items such as
breads, waffles, and also for warming oven-safe dishes.
Cooking Modes
(Available on some models)
20
USING THE RANGE: Probe
Proper Probe Placement
After preparing the meat and placing it on the cooking
pan follow these instructions for proper probe placement.
probe will rest in the center of the thickest part of
the food. For best performance the probe should
be fully inserted into the food. If the probe is not
located properly, it may not accurately measure the
temperature of the coolest portion of the food. Some
foods, particularly small items, are not well suited for
cooking with the probe due to their shape or size.
part of the breast.
of the roast.
center of the lowest large muscle or joint.
probe into the center of the dish.
the meatiest area, parallel to the backbone.
Probe Usage
To use the probe with preheating:
1. Set the desired cook mode (Bake, Convection Bake,
or Convection Roast).
2. Insert the probe into the food (see Proper Probe
Placement).
3. Once the oven is preheated, place the food in the
oven and connect the probe to the probe outlet,
walls and probe outlet are hot.
4. Program the probe temperature by pressing the
Options pad, selecting the probe option, and entering
the desired food temperature. The maximum internal
food temperature that you can set is 200°F.
To use the probe without preheating:
1. Insert the probe into the food (see Proper Probe
Placement).
2. Place the food in the oven and connect the probe into
the probe outlet in the oven.
3. Set the desired cook mode (Bake, Convection Bake,
or Convection Roast).
4. Program the probe temperature by pressing the
Options pad and selecting the Probe option and
entering the desired food temperature. The maximum
internal food temperature that you can set is
200°F
.
Probe Care Guidelines
product may result in damage to the probe outlet.
and removing them from the meat and outlet
pull on the cable when removing it.
completely defrosted before inserting the probe.
from the outlet until the oven has cooled.
steam clean cycle.
Probe (Some models)
WARNING
Consuming undercooked food can result in foodborne illness. Use probe according to
the following instructions to ensure all portions of the food reach minimum safe cooking temperatures.
Recommendations for minimum safe food temperatures can be found at
www.foodsafety.gov or www.IsItDoneYet.gov.
Internal food temperature is frequently used as an indicator of doneness, especially for roasts and
poultry. The Probe mode monitors the internal food temperature and turns the oven off when the internal
food temperature reaches the programmed temperature.
Always check the temperature at multiple locations in the food with a food thermometer after cooking to
ensure that all portions of the food have reached the minimum safe internal temperature for that food.
21
USING THE RANGE: Cooking Guide
Cooking Guide
FOOD TYPE
RECOMMENDED
MODE(S)
RECOMMENDED
RACK POSITION(S) ADDITIONAL SUGGESTIONS
Baked Goods
Layer cakes, sheet cakes,
bundt cakes, muffins, quick
breads on a Single Rack
4ekaB
Layer cakes* on Multiple
Racks
5 dna 3ekaB
Ensure adequate airflow
(see illustration below).
Chif 1ekaB)doof legna( sekac nof
Cookies, biscuits, scones on
a Single Rack
4ekaB
Cookies, biscuits, scones on
Multiple Racks
Bake
Convection Bake
3 and 5
2, 4, and 6 (3 rack
recommended only for
Convection Bake)
Ensure adequate airflow.
Beef & Pork
6iH liorBsregrubmaH
For best performance center food below the broil heating element.
6iH liorBspohC & skaetS
For best performance center food below the broil heating element.
4 ro 3ekaBstsaoR
Poultry
4 ro 3ekaBnekcihc elohW
Bone-in chicken breasts,
legs, thighs
.tsrif nwod edis niks liorB .sedom iH liorB diova ecuas ni detaoc ro dedaerb fI2iH liorB
lower oven. For best performance when broiling, center food below the broil
heating element.
Broil Lo
Bake
2 or 3
Boneless chicken breasts
Broil Lo
Bake
broiling. For best performance when broiling, center food below the broil
heating element.
2ro1ekaByekrut elohW
3or2ekaBtsaerB yekruT
Fish Broil Lo
broiling. For best performance center food below the broil heating element.
Casseroles 4 ro 3ekaB
Frozen Convenience Foods
Pizza, french fries, tator tots,
chicken nuggets, appetizers
on a Single Rack
4 ro 3ekaB
Pizza, french fries, tator tots,
chicken nuggets, appetizers
on Multiple Racks
Bake
Convection Bake
3 and 5
*When baking four cake layers at a time, use racks 3
and 5. Place the pans as shown so that one pan is not
directly above another.
Cook food thoroughly to help protect against food
borne illness. Minimum safe food temperature
recommendations for food safety can be found at
www.IsItDoneYet.gov. Make sure to use a food
thermometer to take food temperatures.
Rack position for baking 4 layer cakes.
b
2 or 3
22
Cleaning the Range – Exterior
CARE AND CLEANING: Cleaning the Range – Exterior
WARNING
If your range is removed for cleaning, servicing or any reason, be sure the
anti-tip device is reengaged properly when the range is replaced. Failure to
take this precaution could result in tipping of the range and can result in death
or serious burns to children or adults.
Be sure all controls are off and all surfaces are cool before cleaning any part of the range.
Control Lockout
If desired, the touch pads may be deactivated before
cleaning.
See Lock Controls in the Oven Controls section in this
manual.
Clean up splatters with a damp cloth.
You may also use a glass cleaner.
abrasives of any kind.
Reactivate the touch pads after cleaning.
Control Panel
It’s a good idea to wipe the control panel after each use.
Clean with mild soap and water or vinegar and water,
rinse with clean water and polish dry with a soft cloth.
plastic scouring pads or oven cleaners on the control
Stainless Steel.
Oven Exterior
liquid cleansers, steel wool, plastic scouring pads, or
cleaning powders on the interior or exterior of the oven.
Clean with a mild soap and water or vinegar and water
solution. Rinse with clean water and dry with a soft cloth.
When cleaning surfaces, make sure that they are at
room temperature and not in direct sunlight.
If stain on the door vent trim is persistent, use a mild
abrasive cleaner and a sponge-scrubber for best results.
Spillage of marinades, fruit juices, tomato sauces and
basting liquids containing acids may cause discoloration
and should be wiped up immediately. Let hot surfaces
Painted Surfaces
Painted surfaces include the sides of the range and the
door, top of control panel and the drawer front. Clean
these with soap and water or a vinegar and water solution.
powders, steel wool or harsh abrasives on any painted
surface, including Black Stainless Steel.
Stainless Steel excluding Black Stainless Steel (on some models)
To clean the stainless steel surface, use warm sudsy
water or a stainless steel cleaner or polish. Always wipe
the surface in the direction of the grain. Follow the cleaner
instructions for cleaning the stainless steel surface.
To inquire about purchasing cleaning products
including stainless steel appliance cleaner or polish,
see the Accessories and Consumer Support sections
at the end of this manual.
23
The interior of your new oven can be cleaned manually or by using Steam Clean or Self Clean modes.
Spillage of marinades, fruit juices, tomato sauces and basting liquids containing acids may cause discoloration and
should be wiped up immediately. Let hot surfaces cool, then clean and rinse.
Manual Cleaning
liquid cleansers, steel wool, scouring pads, or cleaning
powders on the interior of the oven. Clean with a mild
soap and water or vinegar and water solution. Rinse with
clean water and dry with a soft cloth. When cleaning
surfaces, make sure that they are at room temperature.
CARE AND CLEANING: Cleaning the Range – Interior
Cleaning the Range – Interior
Steam Clean Mode
Steam clean is intended to clean small spills using water
and a lower cleaning temperature than Self-Clean.
To use the Steam Clean feature, wipe grease and soils
from the oven. Pour one cup of water into the bottom
of the oven. Close the door. Press the Clean pad twice
to select Steam and then press Start/Enter. The oven
door will lock. You can not open the door during the
30 minute steam clean as this will decrease the steam
clean performance. At the end of the steam clean cycle
the door will unlock. Wipe out any excess water and
any remaining soil.
Self Clean Mode
Read Self-Cleaning Oven Safety Instructions at the
beginning of this manual before using Self Clean Mode.
Self clean uses very high temperatures to clean the oven
interior. The oven door will lock when using this feature.
Before operating the self-clean cycle, wipe up grease and
soils from the oven. Remove all items from the oven other
than enameled (dark color) racks. Shiny or silver racks
and any cookware or other items should all be removed
from the oven before initiating a self-clean cycle. Close
the door. Press the Self Clean pad and a default self-
clean time is displayed. The clean time can be changed
to any time between 3:00 and 5:00 hours by using the
number pads to enter a different time and pressing
Enter. For heavily soiled ovens, the maximum 5 hour
clean time is recommended. If you wish to use the default
time, press the Start/Enter pad. The oven will turn off
automatically when the self-clean cycle is complete. The
door will stay locked until the oven has cooled down. After
the oven has cooled down wipe any ash out of the oven.
We recommend venting your kitchen with an open
window or using a ventilation fan or hood during the first
self-clean cycle.
Soil on the front frame of the range and outside the
gasket on the door will need to be cleaned by hand.
Clean these areas with hot water, soap-filled steel-wool
pads or cleansers such as Soft Scrub
®
. Rinse well with
clean water and dry.
the oven door gasket cannot withstand abrasion. It is
essential for the gasket to remain intact. If you notice it
becoming worn or frayed, replace it.
Make sure the oven light bulb cover is in place and the
oven light is off.
IMPORTANT: The health of some birds is extremely
sensitive to the fumes given off during the self-cleaning
cycle of any range. Move birds to another well-
ventilated room.
The surface units are automatically disabled during the
self-clean cycle. Wait until the self-clean cycle is finished
to set and use the surface units.
To stop a self clean cycle press the Cancel/Off pad.
The door will unlatch once the oven has cooled below
the locking temperature. You will not be able to open the
door right away unless the oven has cooled below the
locking temperature.
Racks
All racks can be washed with warm, soapy water.
Enameled (not shiny) racks can be left in the cavity
during self clean.
Racks may be more difficult to slide, especially after
a self-clean. Put some vegetable oil on a soft cloth or
paper
towel and rub onto the left and right edges.
Oven Heating Elements
soil will burn off when the elements are heated.
The bake element is not exposed and is under the oven
floor. Clean the oven floor with warm, soapy water.
Wipe up heavy soil on the oven bottom.
24
Normal Daily Use Cleaning
ONLY use CERAMA BRYTE
®
Ceramic Cooktop
Cleaner on the glass cooktop. Other creams may not
be as effective.
To maintain and protect the surface of your glass cooktop,
follow these steps:
1. Before using the cooktop for the first time, clean it
with CERAMA BRYTE
®
Ceramic Cooktop Cleaner.
This helps protect the top and makes cleanup easier.
®
Ceramic Cooktop
Cleaner will help keep the cooktop looking new.
3. Shake the cleaning cream well. Apply a few drops of
CERAMA BRYTE
®
Ceramic Cooktop Cleaner directly
to the cooktop.
CERAMA BRYTE
®
Cleaning
Pad for Ceramic Cooktops
to clean the entire cooktop
surface.
towel to remove all cleaning
residue. No need to rinse.
NOTE: It is very important that
until it has been cleaned
thoroughly.
Burned-On Residue
NOTE:
use scrub pads other than those recommended.
1. Allow the cooktop to cool.
2. Spread a few drops of CERAMA BRYTE
®
Ceramic
Cooktop Cleaner on the entire burned residue area.
®
Cleaning Pad
for Ceramic Cooktops, rub the residue area, applying
pressure as needed.
4. If any residue remains, repeat the steps listed above
as needed.
5. For additional protection, after all residue has been
removed, polish the entire surface with CERAMA
Ceramic Cooktop Cleaner and a paper towel.
Heavy, Burned-On Residue
1. Allow the cooktop to cool.
a 45° angle against the glass surface and scrape the
soil. It will be necessary to apply pressure to the razor
scraper in order to remove the residue.
3. After scraping with the razor scraper, spread a few drops
of CERAMA BRYTE
®
Ceramic Cooktop Cleaner on the
®
Cleaning Pad to remove any remaining residue.
4. For additional protection, after all residue has been
removed, polish the entire surface with CERAMA
BRYTE
®
Ceramic Cooktop Cleaner and a paper towel.
Clean your cooktop after each
®
Ceramic Cooktop Cleaner.
The CERAMA BRYTE
®
Ceramic Cooktop Scraper and all
recommended supplies are available through our Parts Center.
See the Accessories and Consumer Support sections at the
end of this manual.
NOTE:
CARE AND CLEANING: Cleaning the Glass Cooktop
Cleaning the Glass Cooktop
®
Cleaning
Pad for Ceramic Cooktops.
BRYTE
®
Ceramic
25
Metal Marks and Scratches
1. Be careful not to slide pots and pans across your
cooktop. It will leave metal markings on the cooktop
surface.
These marks are removable using the CERAMA
BRYTE
®
Ceramic Cooktop Cleaner with the CERAMA
BRYTE
®
Cleaning Pad for Ceramic Cooktops.
2. If pots with a thin overlay of aluminum or copper
are allowed to boil dry, the overlay may leave black
discoloration on the cooktop.
This should be removed immediately before heating
again or the discoloration may be permanent.
NOTE: Carefully check the bottom of pans for roughness
that would scratch the cooktop.
Damage from Sugary Spills and Melted Plastic
Special care should be taken when removing hot substances to avoid permanent damage of the glass surface.
Sugary spillovers (such as jellies, fudge, candy, syrups) or melted plastics can cause pitting of the surface of your
cooktop (not covered by the warranty) unless the spill is removed while still hot. Special care should be taken when
removing hot substances.
Be sure to use a new, sharp razor scraper.
1. Turn off all surface units. Remove hot pans.
2. Wearing an oven mitt:
the spill to a cool area on the cooktop.
b. Remove the spill with paper towels.
3. Any remaining spillover should be left until the surface
of the cooktop has cooled.
residue has been completely removed.
If pitting or indentation in the glass surface has
already occurred, the cooktop glass will have to be
replaced. In this case, service will be necessary.
Cleaning the Glass Cooktop (Cont.)
CARE AND CLEANING:
Probe
The temperature probe may be cleaned with soap and
water or a soap-filled scouring pad. Cool the temperature
probe before cleaning. Scour stubborn spots with a soap-
filled scouring pad, rinse and dry.
To order additional temperature probes, see the
Accessories and Consumer Support sections at the end
of this manual.
during a self or steam clean cycle.
NOTE:
26
WARNING
SHOCK OR BURN HAZARD: Before replacing oven light bulb, disconnect the electrical power to the
range at the main fuse or circuit breaker panel. Failure to do so may result in electric shock or burn.
CAUTION
BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot glass with
bare hands or a damp cloth can cause burns.
Oven Light Replacement
To remove:
the tabs of the glass cover clear the grooves of the
socket. Wearing latex gloves may offer a better grip.
2. Remove the bulb by turning it counter-clockwise.
To replace:
1. Replace bulb with a new 40-watt appliance bulb.
Insert the bulb and turn it clockwise until it is tight.
2. Place the tabs of the glass cover into the grooves of
For improved lighting inside the oven, clean the glass
cover frequently using a wet cloth. This should be
done when the oven is completely cool.
3. Reconnect electrical power to the oven.
CARE AND CLEANING:
Oven Light
The door is very heavy. Be careful when removing and lifting the door.
To remove the door:
1. Fully open the door.
2. Pull the hinge locks down toward the door frame, to
the unlocked position. A tool, such as a small flat-
blade screwdriver, may be required.
3. Firmly grasp both sides of the door at the top.
4. Close door to the door removal position. The door
should be open approximately 3" with no obstruction
above the door.
5. Lift door up and out until both hinge arms are clear of
the slots.
To replace the door:
1. Firmly grasp both sides of the door at the top.
2. Starting on the left side, with the door at the same
angle as the removal position, seat the indentation of
the hinge arm into the bottom edge of the hinge slot.
The notch in the hinge arm must be fully seated into
the bottom of the slot. Repeat for right side.
3. Fully open the door. If the door will not fully open, the
indentation is not seated correctly in the bottom edge
of the slot.
4. Push the hinge locks up against the front frame of the
oven cavity, to the locked position.
5. Close the oven door.
Removal position
Hinge lock
Slot
Pull hinge locks down to unlock
Push hinge locks up to lock
Hinge
lock
Hinge
arm
Indentation
Bottom
edge of
slot
Hinge arm
Oven Door
27
TROUBLESHOOTING TIPS
Troubleshooting Tips ... Before you call for service
Save time and money! Review the charts on the following pages first and you may not need to call for service.
Problem Possible Cause What To Do
Surface units do not
work properly or
flashing power setting.
Improper cookware being used.
size for the element being used. See the Pan size and shape section.
Pan is too small. Pan size is below the minimum size for the element. See the Pan size
Pan not positioned correctly. Center the pan in the cooking zone.
Pan is not in full contact with glass
surface.
Pan must be flat.
In some areas, the power (voltage)
may be low.
Cover pan with a lid until desired heat is obtained.
A fuse in your home may be blown
or the circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
Cooktop controls improperly set. Check to see that the control is set properly. Press On then + or -
Surface unit setting
changed or turned off
unexpectedly.
High cooktop temperature. Allow the internal fan to cool the cooktop. Check if pan boiled dry.
Scratches (may appear
as cracks) on cooktop
glass surface.
Incorrect cleaning methods being
used.
Scratches are not removable. Tiny scratches will become less visible in
time as a result of cleaning.
Cookware with rough bottoms being
used or coarse particles (salt or
sand) were between the cookware
and the surface of the cooktop.
Cookware has been slid across the
cooktop surface.
To avoid scratches, use the recommended cleaning procedures. Make
sure bottoms of cookware are clean before use, and use cookware with
smooth bottoms.
Areas of discoloration
on the cooktop.
Food spillovers not cleaned before
next use.
See the Cleaning the glass cooktop section.
Hot surface on a model with a light-
colored cooktop.
This is normal. The surface may appear discolored when it is hot. This
is temporary and will disappear as the glass cools.
Plastic melted to the
surface.
Hot cooktop came into contact with
plastic placed on the hot cooktop.
Cleaning the glass cooktop section.
Pitting (or indentation)
of the cooktop.
Hot sugar mixture spilled on the
cooktop.
Call a qualified technician for replacement.
My new oven doesn't
cook like my old one.
Is something wrong
with the temperature
settings?
Your new oven has a different
cooking system from your old oven
and therefore may cook differently
than your old oven.
For the first few uses, follow your recipe times and temperatures
carefully. If you still think your new oven is too hot or too cold, you
can adjust the temperature yourself to meet your specific cooking
preference. NOTE: This adjustment affects Bake, and Convection Bake
temperatures; it will not affect Broil or Clean.
Food does not bake
properly.
Oven controls improperly set. See the Cooking Modes section.
Rack position is incorrect or rack is
not level.
See the Cooking Modes section and Cooking Guide.
Incorrect cookware or cookware of
improper size being used.
See the Cookware section.
Oven temperature needs adjustment. See the Special Features section.
Ingredient substitution. Substituting ingredients can change the recipe outcome.
Food does not broil
properly.
Oven controls improperly set. Make sure you select the appropriate broil mode.
Improper rack position being used. See Cooking Guide for rack location suggestions.
Food being cooked in a hot pan. Make sure cookware is cool.
Cookware not suited for broiling.
The probe is plugged into the outlet
in the oven.
Aluminum foil used on the broiling
pan and grid has not been fitted
properly and slit as recommended.
If using aluminum foil conform to pan slits.
In some areas the power (voltage)
may be low.
Preheat the broil element for 10 minutes.
Oven temperature too
hot or too cold.
Oven temperature needs adjustment. See the Special Features section.
28
TROUBLESHOOTING TIPS
Troubleshooting Tips ... Before you call for service
Problem Possible Cause What To Do
Oven does not work or
appears not to work.
Plug on range is not completely inserted in
the electrical outlet.
Make sure electrical plug is plugged into a live, properly grounded
outlet.
A fuse in your home may be blown or the
circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
Oven controls improperly set.
Oven is in Sabbath Mode.
Features section.
“Crackling” or “popping”
sound.
This is the sound of the metal heating
and cooling during both the cooking and
cleaning functions.
This is normal.
Why is my range making a
"clicking" noise when using
my oven?
Your range cycles the heating elements by
turning relays on and off to maintain the
oven temperature.
This is normal.
Clock and timer do not work. A fuse in your home may be blown or the
circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
Plug on range is not completely inserted in
the electrical outlet.
Make sure electrical plug is plugged into a live, properly grounded
outlet.
Oven controls improperly set.
Oven door is crooked. The door is out of position. Because the oven door is removable, it sometimes gets out of
position during installation. To straighten the door, re-install the
Cleaning" section.
Oven light does not work. Light bulb is loose or defective. Tighten or replace bulb.
Pad operating light is broken.
Oven will not self-clean. The temperature is too high to set a self-
clean operation.
Allow the oven to cool and reset the controls.
Oven controls improperly set. See the Cleaning the Oven section.
The probe is plugged into the outlet in the
oven.
Remove the probe from the oven.
Oven will not steam clean. Display flashes HOT. Allow the oven to cool to room temperature and reset the
controls.
Oven controls improperly set.
Oven door is not closed. Make sure you close the door to start steam clean cycle.
Excessive smoking during
clean cycle.
Excessive soil or grease. Press the Cancel/Off pad. Open the windows to rid the room of
smoke. Wait until the LOCKED light goes off. Wipe up the excess
soil and reset the clean cycle.
Excessive smoking during
broiling.
Food too close to burner element. Lower the rack position of the food.
Oven door will not open after
a clean cycle.
Oven too hot. Allow the oven to cool below locking temperature.
Oven not clean after a clean
cycle.
Oven controls improperly set. See the Cleaning the Oven section.
Oven was heavily soiled. Clean up heavy spillovers before starting the clean cycle.
Heavily soiled ovens may need to self-clean again or for a longer
period of time.
"LOCK DOOR" flashes in the
display.
The self-clean cycle has been selected but
the door is not closed.
Close the oven door.
DOOR LOCK light is on when
you want to cook.
The oven door is locked because the
temperature inside the oven has not
dropped below the locking temperature.
Press the Cancel/Off pad. Allow the oven to cool.
“F— and a number or letter”
flash in the display.
You have a function error code. Press the Cancel/Off pad. Allow the oven to cool for one hour. Put
the oven back into operation.
If the function code repeats.
reconnect power. If the function error code repeats, call for service.
Display goes blank. A fuse in your home may be blown or the
circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
The clock is turned off. See the Special features section.
Oven or cooktop will not stay
set.
Function error.
power. If repeating, call for service.
Call for service.
29
TROUBLESHOOTING TIPS
Troubleshooting Tips ... Before you call for service
Problem Possible Cause What To Do
Power outage, clock flashes. Power outage or surge. Reset the clock. If the oven was in use, you must reset it by
pressing the Cancel/Off pad, setting the clock and resetting
any cooking function.
“Burning” or “oily” odor
emitting from the vent.
This is normal in a new oven and will
disappear in time.
To speed the process, set a self-clean cycle for a minimum of
3 hours. See the Cleaning the Oven section.
Strong odor. An odor from the insulation around the
inside of the oven is normal for the first
few times the oven is used.
This is temporary and will go away after several uses or a
self-clean cycle.
yllacitamotua yam naf noitcevnoc A.esion naF
turn on and off.
This is normal. The fan is designed to operate intermittently to
maximize cooking evenness. The convection fan will operate
during preheat of the bake cycle. The fan will turn off after the
oven is heated to the set temperature. This is normal.
A cooling fan may automatically turn on
and off.
This is normal. The cooling fan will turn off and on to cool
internal parts. It may run after the oven is turned off.
My oven door glass appears
to be "tinted" or have a
"rainbow" color. Is this
defective?
No. The inner oven glass is coated with
a heat barrier to reflect the heat back
into the oven to prevent heat loss and
keep the outer door cool while baking.
tint or rainbow color.
Sometimes the oven takes
longer to preheat to the
same temperature.
Cookware or food in oven. The cookware or food in the oven will cause the oven to take
longer to preheat. Remove items to reduce preheat time.
Number of racks in oven. Adding more racks to the oven will cause the oven to take
longer to preheat. Remove some racks.
Different cooking modes. The different cooking modes use different preheat methods to
heat the oven for the specific cooking mode. Some modes will
take longer than others (i.e. convection bake).
Display flashes. Power failure. Reset the clock.
Control signals after
entering cooking time or
start time.
You forgot to enter a bake temperature
or cleaning time.
Touch the Bake pad and desired temperature or the Self
pad and desired clean time.
Oven racks are difficult to
slide.
The shiny, silver-colored racks were
cleaned in a self-clean cycle.
Apply a small amount of vegetable oil to a paper towel and
spray with Pam
®
or other lubricant sprays.
Steam from the vent. When using the ovens, it is normal
to see steam coming out of the
oven vents. As the number of racks
or amount of food being cooked
increases, the amount of visible steam
will increase.
This is normal.
Warming drawer will not
work.
A fuse in your home may be blown or
the circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
Controls improperly set.
Excessive condensation in
the drawer.
Liquid in drawer. Remove liquid.
Uncovered foods. Cover food with lid or aluminum foil.
Temperature setting too high. Reduce temperature setting.
Food dries out in the
warming drawer.
Moisture escaping. Cover food with lid or aluminum foil.
Drawer not fully closed. Push drawer in until latch engages.
Water remaining on oven
floor after Steam Clean cycle.
This is normal. Remove any remaining water with a dry cloth or sponge.
“Probe” appears in the
display.
This is reminding you to enter a probe
temperature after plugging in the probe.
Enter a probe temperature.
Clean
30
GEAppliances.ca
All warranty service is provided by our Factory Service Centers, or an authorized Customer Care
®
technician. To schedule
service online, visit us at www.GEAppliances.ca, or call 1.800.561.3344. Please have your serial number and your
model number available when calling for service.
Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE Appliances factory
service technician the ability to quickly diagnose any issues with your appliance and helps GE Appliances improve its
products by providing GE Appliances with information on your appliance. If you do not want your appliance data to be
sent to GE Appliances, please advise your technician not to submit the data to GE Appliances at the time of service.
What MC Comercial will not cover:
Service trips to your home to teach you how to use
the product.
modified or used for other than the intended purpose
or used commercially.
cleaners other than the recommended cleaning
creams and pads.
spills of sugary materials or melted plastic that
are not cleaned according to the directions in the
Owner's Manual.
breakers.
floods or acts of God.
blemishes not reported within 48 hours of delivery.
possible defects with this appliance.
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or
the shortest period allowed by law.
For the period of MC Comercial Will Provide:
One year
From the date
of the original
purchase
Any part
limited one-year warranty, MC Comercial will provide, free of charge, all labor and in-home
service to replace the defective part.
Staple your receipt here. Proof of the original purchase
date is needed to obtain service under the warranty.
WARRANTY
GE Appliances Electric Range Warranty
This warranty is extended to the original purchaser and any succeeding owner for products purchased in Canada for
home use within Canada. If the product is located in an area where service by a GE Authorized Servicer is not available,
you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Service location.
Some provinces do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives
you specific legal rights, and you may also have other rights which vary from province to province. To know what your
legal rights are, consult your local or provincial consumer affairs office.
Warrantor: MC Commercial, Burlington, ON, L7R 5B6
31
ACCESSORIES
Looking For Something More?
GE Appliances offers a variety of accessories to
improve your cooking and maintenance experiences!
Refer to the Consumer Support page for phone numbers
and website information.
The following products and more are available:
Accessories
Accessories
Small Broiler Pan (8 ¾ ” x 1 ¼” x 13 ½ “)
Large Broiler Pan (12 ¾ ” x 1 ¼” x 16 ½ “)
Parts
Oven racks
Oven elements
Light bulbs
Cleaning Supplies
CitruShine™ Stainless Steel Wipes
CERAMA BRYTE
®
Stainless Steel Appliance Cleaner
CERAMA BRYTE
®
Cleaning Pads for Ceramic Cooktops
CERAMA BRYTE
®
Ceramic Cooktop Cleaner
CERAMA BRYTE
®
Ceramic Cooktop Scraper
32
Printed in Mexico
Consumer Support
CONSUMER SUPPORT
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day
of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support
GEAppliances.ca
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
GEAppliances.ca
Schedule Service
Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at
GEAppliances.ca or call 1-800.561.3344 during normal business
hours.
Remote Connectivity
For assistance with wireless network connectivity (for models with remote enable),
visit our website at GEAppliances.com/ge/connected-appliances/
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the
details including your phone number, or write to:
MC Comercial | Factory Lane Moncton, New Brunswick E1C 9M3.
