Color
television
OWNER'S
MANUAL
Please
read
this
manual
carefully
and
completely
before
operating
your
TV.
Retain
this
manual
for
future
reference.
Record
model
number
and
serial
number
of
the
TV
in
the
spaces
provided
below.
See
the
label
attached
on
the
back
cover
and
relate
this
information
to
your
dealer
if
you
require
service.
Model
Number
:
Serial
Number
:
MODELS:
30FS4D
32FS4D-UC
R
TruSurround
XT
Internet
Home
Page
:
http://www.lg.ca
PAGE
2
WARNING/CAUTION:
TO
REDUCE THE
RISK
OF
ELECTRIC
SHOCK
DO
NOT
REMOVE
COVER
(OR
BACK).
NO
USER
SERVICEABLE
PARTS
INSIDE.
REFER
TO
QUALIFIED
SERVICE
PERSONNEL.
The
lightning
flash
with
arrowhead
symbol,
within
an
equilateral
triangle,
is
intended
to
alert
the
user
to
the
presence
of
uninsulated
"dangerous
voltage"
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute
a
risk
of
electric
shock
to
persons.
The
exclamation
point
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
important
operating
and
maintenance
(servicing)
instructions
in
the
literature
accompanying
the
appliance.
WARNING/CAUTION:
TO
PREVENT
FIRE
OR
SHOCK
HAZARDS,
DO
NOT
EXPOSE
THIS
PRODUCT
TO
RAIN
OR
MOISTURE.
POWER
CORD
POLARIZATION:
CAUTION:
TO
PREVENT
ELECTRIC
SHOCK,
MATCH
WIDE
BLADE
OF
PLUG
TO
WIDE
SLOT,
FULLY
INSERT.
ATTENTION:
POUR
EVITER
LES
CHOCS
ELECTRIQUES,
INTRODUIRE
LA
LAME
LA
PLUS
LARGE
DE
LA
FICHE
DANS
LA
BORNE
CORRESPONDANTE
DE LA
PRISE
ET
POUSSER
JUSQU'AU
FOND.
NOTE
TO
CABLE/TV
INSTALLER:
This
reminder
is
provided
to
call
the
CATV
system
installer's
attention
to
Article
820-40
of
the
National
Electric
Code
(U.S.A.).
The
code
provides
guidelines
for
proper
grounding
and,
in
particular,
specifies
that the
cable
ground
shall
be
connected
to
the
grounding
system
of
the
building,
as
close
to
the
point
of
the
cable
entry
as
practical.
REGULATORY
INFORMATION:
This
equipment
has
been
tested
and
found
to
comply
with the
limits for
a
Class
B
digital
device,
pursuant
to
Part
15
of
the
FCC
Rules.
These
limits
are
designed
to
provide
reasonable
protection
against
harmful
interference
when
the
equip-
ment
is
operated
in
a
residential
installation.
This
equipment
generates,
uses
and
can
radiate
radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instruction
manual,
may
cause
harmful
interference
to
radio
com-
munications.
However,
there
is
no
guarantee
that
interference
will
not
occur
in
a
particular
installation.
If
this
equip-
ment
does
cause
harmful
interference
to
radio
or
television
reception,
which
can
be
determined
by
turning
the
equip-
ment
off
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
the
following
measures:
?
Reorient
or
relocate
the
receiving
antenna.
?
Increase
the
separation
between
the
equipment
and
receiver.
?
Connect
the
equipment
into
an
outlet
on
a
circuit
different
from
that
to
which
the
receiver
is
connected.
?
Consult
the
dealer
or
an
experienced
radio/TV
technician
for
help.
Any
changes
or
modifications
not
expressly
approved
by
the
party
responsible
for
compliance
could
void
the
user's
authority
to
operate
the
equipment.
CAUTION:
Do
not
attempt
to
modify
this
product
in
any
way
without
written
authorization
from
Zenith
Electronics
Corporation.
Unauthorized
modification
could
void the
user's
authority
to
operate
this
product.
WARNING/CAUTION
Manufactured
under
license
from
BBE
Sound,
Inc.
PAGE
3
IMPORTANT
SAFETY
INSTRUCTIONS
Important
safety
instructions
shall
be
provided
with
each
apparatus.
This
information
shall
be
given
in
a
separate
booklet
or
sheet,
or
be
located
before
any
operating
instructions
in
an
instruction
for
installation
for
use
and
supplied
with
the
appa-
ratus.
This
information
shall
be
given
in
a
language
acceptable
to
the
country
where
the
apparatus
is
intended
to
be
used.
The
important
safety
instructions
shall
be
entitled
"Important
Safety
Instructions".
The
following
safety
instructions
shall
be
included
where
applicable,
and,
when
used,
shall
be
verbatim
as
follows.
Additional
safety
information
may
be
included
by
adding
statements
after
the
end
of
the
following
safety
instruction
list.
At
the
manufacturer's
option,
a
or
drawing
that
illustrates
the
intent
of
a
specific
safety
instruction
may
be
placed
immediately
adjacent
to
that
safety
instruction
:
(Continued
on
next
page)
1.
Read
these
instructions.
2.
Keep
these
instructions.
3.
Heed
all
warnings.
4.
Follow
all
instructions.
5.
Do
not
use
this
apparatus
near
water.
6.
Clean
only
with
dry
cloth.
7.
Do
not
block
any
ventilation
openings.
Install
in
accordance
with
the
manufacturer's
instructions.
8.
Do
not
install
near
any
heat
sources
such
as
radiators,
heat
registers,
stoves,
or
other
apparatus
(including
ampli-
fiers)that
produce
heat.
9.
Do
not
defeat the
safety
purpose
of
the
polarized
or
grounding-type
plug.
A
polarized
plug
has
two
blades
with
one
wider
than
the
other.
A
grounding
type
plug
has
two
blades
and
a
third
grounding
prong,
The
wide
blade
or
the
third
prong
are
provided
for
your
safety.
If
the
provided plug
does
not
fit
into
your
outlet,
consult
an
elec-
trician
for
replacement
of
the
obsolete
outlet.
10.
Protect
the
power
cord
from
being
walked
on
or
pinched
particularly
at
plugs,
convenience
receptacles,
and
the
point
where
they
exit
from
the
apparatus.
11.
Only
use
attachments/accessories
specified
by
the
manufacturer.
12.
Use
only
with
the
cart,
stand,
tripod,
bracket,
or
table
specified
by
the
manufacturer,
or
sold
with
the
appara-
tus.
When
a
cart
is
used,
use
caution
when
moving
the
cart/apparatus
combination
to
avoid
injury
from
tip-over.
PORTABLE
CART
WARNING
PAGE
4
13.
Unplug
this
apparatus
during
lightning
storms
or
when
unused
for
long
periods
of
time.
14.
Refer
all
servicing
to
qualified
service
personnel.
Servicing
is
required
when
the
apparatus
has
been
damaged
in
any
way,
such
as
power-supply
cord
or
plug
is
damaged,
liquid
has
been
spilled
or
objects
have
fallen
into
the
apparatus,
the
apparatus
has
exposed
to
rain
or
moisture,
does
not
operate
normally,
or
has
been
dropped.
15.
CAUTION
concerning
the
Power
Cord
:
Most
appliances
recommend
they
be
placed
upon
a
dedicated
circuit;
that
is,
a
single
outlet
circuit
which
powers
only
that
appliance
and
has
no
additional
outlets
or
branch
circuits.
Check
the
specification
page
of
this
owner's
manual
to
be
certain.
Do
not
overload
wall
outlets.
Overloaded
wall
outlets,
loose
or
damaged
wall
outlets,
extension
cords,
frayed
power
cords,
or
damaged
or
cracked
wire
insulation
are
dangerous.
Any
of
these
conditions
could
result
in
electric
shock
or
fire.
Periodically
examine
the
cord
of
your
appliance,
and
if
its
appearance
indicates
damage
or
deterioration,
unplug
it,
discontinue
use
of
the
appliance,
and
have
the
cord
replaced
with
an
exact
replacement
part
by
an
authorized
servicer.
Protect
the
power
cord
from
physical
or
mechanical
abuse,
such
as
being
twisted,
kinked,
pinched,
closed
in
a
door,
or
walked
upon.
Pay
particular
attention
to
plugs,
wall
outlets,
and
the
point
where
the
cord
exits
the
appliance.
16.
Outdoor
Use
Marking
:
WARNING
-
To
Reduce The
Risk
Of
Fire
Or
Electric
Shock,
Do
Not
Expose
This
Appliance
To
Rain
Or
Moisture.
17.
Wet
Location
Marking
:
Apparatus
shall
not
be
exposed
to
dripping
or
splashing
and
no
objects
filled
with
liquids,
such
as
vases,
shall
be
placed
on
the
apparatus.
IMPORTANT
SAFETY
INSTRUCTIONS
Manufactured
under
license
from
Dolby
Laboratories.
"Dolby"
and
the
double-D
symbol
are
trademarks
of
Dolby
Laboratories.
is
a
trademark
of
SRS
Labs,
Inc.
TruSurround
XT
technology
is
incorporated
under
license
from
SRS
Labs,
Inc.
Manufactured
under
license
from
Dolby
Laboratories.
"Dolby"
and
the
double-D
symbol
are
trademarks
of
Dolby
Laboratories.
R
TruSurround
XT
HDMI
TM
,
the
HDMI
logo
and
High-Definition
Multimedia
Interface
is
a
trademark
or
registered
trademark
of
HDMI
Licensing."
High-definition
television.
High-resolution
digital
television
broadcast
and
playback
system
composed
of
roughly
a
million
or
more
pixels,
16:9
aspect-ratio
screens,
and
AC3
digital
audio.
A
subset
of
digital
television,
HDTV
formats
include
1080i
and
720p
resolution.
LG's
own
special
digital
generator.
It
consists
of
full
digital
processor,
APM
mode &
6
different
main
quality
factors.
R
TruSurround
XT
PAGE
5
SafetyWarnings............................2
ImportantSafetyInstructions.................3-4
Step
1.
Hook
Up
TV
FrontPanelControls.........................6
RearConnectionsPanel.......................7
SideConnectionsPanel(FRONTVIDEO).
. . . . . . . . . . .
.8
Antenna/CableServiceHookup..................9
CableBoxConnections.......................10
VCRConnections...........................11
DVDPlayer..............................12
Set-topBoxHookup........................13
MonitorOutSetup.........................14
DigitalAudioOutput........................15
HDMI..................................16
RemoteControlFunctionsinTVMode
. . . . . . . . . .
.17-18
TurningtheTVon..........................19
On-ScreenDisplays.........................19
Step
2.
Customize
your
TV's
Features
SETUP
Menu
EZScan(ChannelSearch)....................20
ChannelEdit............................21
DTVSignal..............................22
Degaussingthescreen......................22
InputSourceSelection.....................23
InputLabel............................23
VIDEO
Menu
EZPicture..............................24
ManualVideoControl.......................25
ColorTemperature.........................26
XD...................................26
VideoPreset............................26
AUDIO
Menu
AudioLanguage..........................27
EZSoundRite............................27
Stereo/SAPBroadcastsSetup..................28
EZSound..............................28
ManualSoundControl......................29
TVSpeakeron/off.........................29
FrontSurround...........................30
TIME
Menu
AutoClockSetup.........................31
ManualClockSetup........................32
TVTurnOffTimeSetup.....................33
TVTurnOnTimeSetup......................34
SleepTimerSetup.........................35
Autooff...............................36
OPTION
Menu
AspectRatioControl.......................37
Captions...............................38
Caption/Text............................39
CaptionOptionMenu.......................40
On-ScreenMenuLanguages...................41
VelocityModulation........................42
Tilt..................................42
Cinema3:2ModeSetup.....................43
EZDemo...............................44
LOCK
Menu
ParentalLockSetup.....................45-46
Step
3.
Miscellaneous
ProgrammingtheRemote.....................47
ProgrammingCodes......................48-50
Maintenance...........................51-52
Troubleshooting.........................53-54
Glossary..............................55-56
ProductSpecifications......................57
Note:
Design
and
specifications
are
subject
to
change
without
prior
notice.
PAGE
6
Front
Panel
Controls
ON/OFF
Standby
indicator
(Illuminates
brightly
when
the
TV
is
in
standby
mode.
Dims
when
the
TV
is
switched
on.)
Remote
control
sensor
TV/VIDEO
MENU
VOL
left/
right
Volume(G)
button
increases
the
sound
level
and
vol-
ume(F)
button
decreases
the
sound
level.
CH
(Channel)
up
/
down
1
2
3
4
These
buttons
work
just
as
they
do
on
your
remote
control.
5
6
7
ON/OFF
MENU
VOL
CH
TV/
VIDEO
1
2
3
4
5
6
7
PAGE
7
Rear
Connections
Panel
Mini
glossary
JACK
A
connection
on
the
back
of
a
TV,
VCR,
or
any
other
A/V
device.
This
includes
the
RF
jack
and
the
Audio/Video
jacks
that
are
color-
coded.
SIGNAL
and
sound
traveling
through
cable,
or
over
the
air,
to
your
television
screen.
VIDEO
AUDIO
L(MONO)
R
PR
PB
Y
(L)
(R)
AUDIO
PR
PB
Y
(L)
(R)
AUDIO
OO
8 8 8
OO
OO
O
OO
O
O
DIGITAL
AUDIO
OUTPUT
OPTICAL
DIGITAL
AUDIO
INPUT
OPTICAL
(DVI)
HDMI
/DVI
C
A
L
I
B
R
A
T
I
O
N
CABLE
ANTENNA
+75
Ω
+75
Ω
COMPONENT1
(480i/480p/720p/1080i)
COMPONENT2
DVD/DTV
INPUT
S-VIDEO
INPUT
MONITOR
OUTPUT
IN1
IN2
S-Video
In
A
connection
available
with
some
high-end
equipment
that
provides
even
better
quality
for
Video
1,
Front
Video.
RF
Connectors:
Cable,
Antenna
Used
to
connect
cable
or
antenna
sig-
nals
to
the
television,
either
directly
or
through
your
cable
box.
Video
1
and
2
Inputs
Connects
the
video
signals
from
various
types
of
equipment.
Y,
PB,
PR
DVD
Component
Video
and
HD
Component
Video
Some
top-of-the-line
DVD
players
use
what
is
called
"component
video,"
for
extremely
accurate
reproduc-
tion.
Refer
to
your
DVD
manual
for
further
information.
Connecting
external
equipment
to
your
TV.
Monitor
Out
Connects
to
a
second
TV
or
Monitor.
Left/Right
Audio
Used
for
stereo
sound
from
various
types
of
equipment.
Component
Left/Right
Audio
Used
for
stereo
sound
from
various
types
of
equipment.
HDMI/DVI
Used
to
connect
from
a
DTV
source.
Digital
Audio
Output
Optical
Connects
to
external
audio
equipment
like
a
home
theater
system.
Digital
Audio
Input
Optical
Connects
to
digital
audio
from
various
types
of
equipment.
PAGE
8
Side
Connections
Panel
(FRONT
VIDEO)
FRONT VIDEO
Panel
S-VIDEO
VIDEO IN
L/MONO
AUDIO
R
FRONT
VIDEO
There
are
four
jacks
on
the
lower-right
front
side
of
your
TV
that
make
connecting
Audio/Video
devices
like
video
games
and
camcorders
very
simple.
The
jacks
are
like
those
found
on
the
back
jack
connection
panel.
This
means
that
most
equipment
that
connects
to
those
types
of
jacks
on
the
rear
jackpack,
may
be
connected
to
the
Side
connection
panel
(FRONT
VIDEO).
To
use
the
Side
jacks
as
the
signal
source,
select
them
using
Input
source
menu
as
described
on
page
23.
They
will
be
named
"FRONT
VIDEO"
in
the
Input
source
menu.
Left/Right
Audio
Used
for
stereo
sound
from
various
types
of
equipment.
Video
in
Connects
the
video
signals
from
any
piece
of
equipment.
S-Video
A
connection
available
on
some
very
high-end
equipment
that
provides
better
quality
than
video
input.
When
you
select
Front
Video
or
Front
S-Video,
the
Front
Audio
inputs
are
automatically
selected
as
well.
Do
not
connect
to
both
Video
and
S-Video
at
the
same
time.
Connect
either
Video
or
S-Video
only.
Mini
glossary
A/V
CABLES
Audio/Video
cables.
Three
cable
connector---Right
audio
(red),
Left
audio
(white),
and
Video
(yellow).
A/V
cables
are
used
for
stereo
playback
of
videocassettes
and
for
higher
quality
and
sound
from
other
A/V
devices.
A/V
DEVICE
Any
device
that
produces
video
(picture)
and/or
audio
(sound)
(VCR,
DVD,
cable
box,
or
television).
PAGE
9
Antenna
/
Cable
Service
Hookup
1
Connect
an
antenna
and/or
cable
service
to
your
TV
as
shown.
Turn
to
page
20
to
do
a
channel
search
with
EZ
Scan.
For
best
signal
reception,
it
is
recommended
to
have
your
Antenna
professionally
adjusted.
2
If
you
receive
your
RF
signal
through
an
antenna
that
is
several
years
old
and
con-
nects
with
two
small
prongs,
you
will
need
to
purchase
a
300
to
75
ohm
adapter.
It
should
be
available
from
your
local
electronics
dealer.
We
recommend
using
a
75
ohm
cable
for
your
antenna
connection
in
order
to
prevent
interference.
CABLE
ANTENNA
+75
Ω
+75
Ω
DIGITAL
AUDIO
OUTPUT
OPTICAL
DIGITAL
AUDIO
INPUT
OPTICAL
(DVI)
C
A
L
I
B
R
A
T
I
O
N
Antenna
Cable
TV
Wall
jack
RF
coaxial wire
(75
ohm)
RF
coaxial wire
(75
ohm)
Mini
glossary
TV
OVER-THE-AIR
SIGNALS
DTV
DIGITAL
OVER-THE-AIR
SIGNALS
CATV
CABLE
SIGNALS
CADTV
DIGITAL
CABLE
SIGNALS
Combined
signals
TV/CATV/DTV
Over-the-air,
cable,
and
digital
over-the-air
signals
TV/CATV/CADTV
Over-the-air,
cable,
and
digital
cable
signals
CAUTION
:
If
you
are
not
sure
of
the
type
of
signal(s)
you
are
receiving,
let
EZ
Scan
complete
all
the
channel
signal-type
searches.
The
TV
will
let
you
know
when
the
analog,
cable,
and
digital
channel
scans
are
complete.
PAGE
10
Cable
Box
Connections
If
you're
using
a
cable
box,
leave
the
TV
on
channel
3
or
4
and
use
your
cable
box
to
change
channels.
Locate
the
output
jack
on
the
back
of
your
cable
box.
Connect
this
to
the
Cable
jack
on
the
back
of
your
TV.
Or
find
the
composite
video
and
audio
jacks
on
the
back
of
your
cable
box,
and
connect
them
following
the
instructions
provided
with
your
equipment.
This
can
be
combined
with
any
other
equipment
you
may
want
to
hook
up.
1
In
Output
Switch
Out
Audio
TV
VCR
L
R
Video
34
VIDEO
L(MONO)
R
PR
PB
Y
L
R
AUDIO
PR
PB
Y
L
R
AUDIO
+75
Ω
+75
Ω
COMPONENT1
(480i/480p/720p/1080i)
COMPONENT2
DVD/DTV
INPUT
S-VIDEO
INPUT
MONITOR
OUTPUT
IN1
IN2
CABLE
ANTENNA
AUDIO
Cable
box
RF
coaxial wire
(75
ohm)
Cable
box
Back
AV
panel
PAGE
11
VCR
Connections
1
Locate
the
Cable
jack
on
the
back
of
your
TV.
Connect
this
to
out
jack
on
the
back
of
your
VCR.
Or
find
the
composite
video
and
audio
jacks
on
the
back
of
your
VCR,
and
connect
them
following
the
instructions
provided
with
your
equipment.
You
may
connect
either
the
com-
posite
video
or
the
S-Video
cables
to
your
TV.
(Do
not
connect
BOTH
the
composite
and
the
S-
Video
cables.
In
the
event
that
you
con-
nect
both
composite
and
the
S-
Video
cables,
only
the
S-Video
will
work.)
To
hear
stereo
sound
from
cable
or
your
VCR,
you
will
need
to
connect
A/V
cables
as
well
as
the
wire
that
runs
from
the
VCR
to
your
TV.
If
you
want
to
receive
your
signals
on
Channel
3
or
4,
locate
the
Out
to
TV
jack
on
your
VCR.
Connect
a
cable
from
the
Out
to
TV
jack
to
the
Antenna
jack
on
the
back
of
your
TV.
In
Out
Audio
L
R
Video
34
S-Video
Output
Switch
VIDEO
L(MONO)
R
PR
PB
Y
L
R
AUDIO
PR
PB
Y
L
R
AUDIO
+75
Ω
+75
Ω
COMPONENT1
(480i/480p/720p/1080i)
COMP
NENT2
DVD/DTV
INPUT
S-VIDEO
INPUT
MONITOR
OUTPUT
IN1
IN2
CABLE
ANTENNA
AUDIO
RF
coaxial
wire
(75
ohm)
A/V
cables
not
included
with
TV
or
VCR
Back
AV
panel
PAGE
12
DVD
Player
Mini
glossary
COMPONENT
VIDEO
Some
video
equipment
uses
three
separate
lines
(Y,
PB,
PR)
to
more
precisely
reproduce
images.
Your
manual
will
explain
how
this relates
to
your
equipment.
1
2
Audio
L
R
S-Video
VIDEO
L(MONO)
R
PR
PB
Y
L
R
AUDIO
PR
PB
Y
L
R
AUDIO
CABLE
ANTENNA
+75
Ω
+75
Ω
COMPONENT1
(480i/480p/720p/1080i)
COMPONENT2
DVD/DTV
INPUT
S-VIDE
INPU
MONITOR
OUTPUT
IN1
IN2
AUDIO
DIGITAL
AUDIO
OUTPUT
OPTICAL
DIGITAL
AUDIO
INPUT
OPTICAL
(DVI)
HDMI
/DVI
C
A
L
I
B
R
A
T
I
O
N
Component
input
jacks
on
the
TV
YPB
PR
Video
output
jacks
of
DVD
player
Y
Y
Y
Y
Pb
B-Y
Cb
PB
Pr
R-Y
Cr
PR
?
Component
Input
ports
You
can
get
better
picture quality
if
you
connect
a
DVD
player
using
the
component
input
ports
as
shown
below.
A/V
cables
not
included
with
TV
DVD
player
Back
AV
panel
or
Back
AV
panel
Find
the
component
or
S-Video
jacks
for
video
connections,
depending
on
your
DVD
connec-
tors.
Then
make
the
correspond-
ing
audio
connections.
See
the
diagram
for
either
set
up.
You
may
connect
either
the
composite
video
or
the
S-Video
cables
to
your
TV.
Do
not
con-
nect
both
the
composite
and
the
S-Video.
Some
high-end
DVD
players
use
a
reproduction
system
called
"component
video."
If
your
DVD
player
has
component
output,
use
the
connectors
marked
"Component
1
or
2"
on
the
jack
panel.
Please
refer
to
your
DVD
manual
for
proper
installation.
Audio
L
R
Digital
Audio
Optical
Component
Video
PR
PB
Y
L
R
AUDIO
PR
PB
R
AUDIO
CABLE
ANTENNA
+75
Ω
+75
Ω
COMPONENT1
(480i/480p/720p/1080i)
COMPONENT2
DVD/DTV
INPUT
DIGITAL
AUDIO
OUTPUT
OPTICAL
DIGITAL
AUDIO
INPUT
OPTICAL
(DVI)
HDMI
/DVI
C
A
L
I
B
R
A
T
I
O
N
DVD
player
A/V
cables
not
included
with
TV
PAGE
13
Set-top
box
Hookup
Find
the
audio
and
Y,
PB,
PR
jacks
or
HDMI/DVI
output
port
on
the
back
of
your
set-top
box and
connect
them
fol-
lowing
the
instructions
provided
with
your
equipment.
Connect
these
cables
to
your
TV
as
shown.
1
2
Digital
Audio
Optical
Output
Audio
LR
Component
Out
YPbPr
PR
PB
Y
L
R
AUDIO
P
P
Y
L
R
AUDIO
CABLE
ANTENNA
+75
Ω
+75
Ω
COMPONENT1
(480i/480p/720p/1080i)
COMPONENT2
DVD/DTV
INPUT
DIGITAL
AUDIO
OUTPUT
OPTICAL
DIGITAL
AUDIO
INPUT
OPTICAL
(DVI)
HDMI
/DVI
C
A
L
I
B
R
A
T
I
O
N
Set-top
Box
Set-top
Box
The
DTV
shows
the
sharpest
in
720p/1080i
mode.
1920x1080i
1280x720p
720x480p
HDMI/DVI
or
Component
1
(or
2)
Input
YPBPR
1920X1080i
1280X720p
720X480p
720X480i
or
DIGITAL
AUDIO
INPUT
OPTICAL
(DVI)
HDMI
/DVI
Set-top
Box
PAGE
14
Monitor
Out
Setup
Your
TV
has
a
special
signal
output
capa-
bility
which
allows
you
to
hook
up
a
sec-
ond
TV
or
monitor.
Just
connect
the
second
TV
or
monitor
to
the
Monitor
output
Audio/Video
jacks
located
on
the
back
of
your
TV.
See
the
Operating
Manual
of
the
second
TV
or
monitor
for
further
details
regarding
that
device's
input
settings.
1
2
Audio
input
Video
input
S-Video
R
L
VIDEO
L(MONO)
R
S-VIDEO
INPUT
MONITOR
OUTPUT
IN1
IN2
AUDIO
A/V
cables
not
included
with
TV
Second
TV
DTV,
Component
1
-
2
and
HDMI/DVI
input
sources
cannot
be used
for
Monitor
Out.
PAGE
15
Digital
Audio
Output
Connect
one
end
of
an
optical
cable
to
the
TV
Digital
Audio
Optical
Output
port.
Connect
the
other
end
of
the
optical
cable
to
the
digital
audio
optical
input
on
the
audio
equipment.
See
the
external
audio
equipment
instruc-
tion
manual
for
operation.
1
2
Digital
Audio
Optical
Input
CABLE
ANTENNA
+75
Ω
+75
Ω
DIGITAL
AUDIO
OUTPUT
OPTICAL
DIGITAL
AUDIO
INPUT
OPTICAL
(DVI)
HDMI
/DVI
C
A
L
I
B
R
A
T
I
O
N
Send
the
TV's
audio
out
to
external
audio
equipment
(stereo
system)
via
the
Digital
Audio
Output
Optical
port.
Caution:
Do
not
look
into
the
optical
output
port.
Looking
at
the
laser
beam
may
damage
your
vision.
Digital
Audio
Equipment
PAGE
16
HDMI
-
HDMI
TM
,
the
HDMI
logo
and
High-Definition
Multimedia
Interface
are
trademarks
or
registered
trademarks
of
HDMI
Licensing
LLC."
-
This
DTV
can
receive
the
High-Definition
Multimedia
Interface(HDMI)
or
Input
of
Digital
Visual
Interface(DVI).
-
This
DTV
supports
HDCP(High-bandwidth
Digital
Contents
Protection)
Protocol
for
DTV(480p,
720p,
1080i)
modes.
-
When
you
Connect
with
HDMI
Source
Devices
(DVD
Player
or
Set
Top
Box)
supporting
Auto
HDMI
function,
automatically,
support
Plug
&
Play
and
then
set
the
HDMI
Source
Devices(1920
x
1080i).
After
reading
in
HDMI
Source
Devices
using
Display
Data
Channel(DDC)
Protocol,
EDID
stored
in
DTV
is
used.
If
HDMI
Source
Devices
not
supported
Auto
HDMI/DVI
is
been,
the
Resolution
is
set,
manually.
-
To
get
the
best
quality,
adjust
the
DVD
Player
or
Set
Top
Box
output
resolution
to
1920
x
1080i.
-
When
Source
Devices
have
DVI
Output
Connector,
you
must
connect
audio
with
separated
cable.
(Refer
to
<How
to
connect>)
-
The
HDMI
is
not
supported
in
480i
source.
How
to
connect
1.
When
Source
Devices(DVD
Player
or
Set
Top
Box)
support
HDMI.
-
If
Source
Devices
have
HDMI
Output
Connector,
Source
Devices
connect
to
DTV
with
HDMI
Cable
.(not
supplied
with
the
product).
-
If
Source
Devices
support
Auto
HDMI,
automatically,
Source
Devices
divert
output
resolution
in
1920
x
1080i.
But
if
not,
resolution
divert
Manually
Setting
for
reference
Manual
of
Source
Devices.
-
To
get
the
best
quality,
adjust
the
DVD
Player
or
Set
Top
Box
output
resolution
to
1920
x
1080i.
-
Because
HDMI
sends
Digital
Video
and
Audio
with
one
cable,
need
not
especial
Audio
Cable
for
using
HDMI
Cable.
2.
When
Source
Devices(DVD
Player
or
Set
Top
Box)
supports
DVI.
-
If
Source
Devices
have
DVI
Output
Connector,
Source
Devices
connect
to
DTV
with
HDMI
to
DVI
Cable
(not
supplied
with
the
product).
-
If
Source
Devices
support
Auto
DVI,
automatically,
Source
Devices
divert
output
resolution
in
1920
x
1080i.
But
if
not,
resolution
divert
Manually
Setting
for
reference
Manual
of
Source
Devices.
-
To
get
the
best
quality,
adjust
the
DVD
Player
or
Set
Top
Box
output
resolution
to
1920
x
1080i.
-
In
this
case,
Audio
use
other
cable.
When
Source
Devices
have
Fiber
Optic
Digital
Audio
Output
Connector,
Digital
Audio
DVI
Input(DVI)
of
DTV
connect
to
Fiber
Optic
Digital
Audio
Cable
(not
supplied
with the
product)
or
when
Source
Devices
have
Analog
Audio
Output
Connector,
RGB/DVI
Audio
Input
of
DTV
connect
to
Audio
Cable
(not
supplied
with
the
product).
And
then
you
can
listen
to
normal
Audio.
How
to
use
1.
Connect
the
HDMI
Source
Devices
(DVD
Player
or
Set
Top
Box)
and
the
TV
set.
2.
Turn
on
the
display
by
pressing
the
ON/OFF
button
on
the
TV
set
and
HDMI
Source
Devices
remote
control.
3.
Check
the
on
your
TV
set.
There
may
be
noise
associated
with the
resolution,
vertical
pattern,
contrast
or
brightness
in
HDMI
Source
Devices.
If
noise
is
present,
change
the
HDMI
Source
Devices
to
another
resolution,
change
the
refresh
rate
or
adjust
the
bright-
ness
and
contrast
on
the
menu
until
the
is
clear.
Reference
Cable
sample
HDMI
Cable
(not
supplied
with the
product)
HDMI
to
DVI
Cable
(not
supplied
with
the
product)
PAGE
17
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE
SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
FAV
Use
to
scroll
the
FAV
channel
list.
MENU
Brings
up
the
main
menu
to
the
screen.
EXIT
Clears
all
on-screen
displays
and
returns to
TV
viewing
from
any
menu.
CC
Lets
you
select
a
closed
caption
mode
for
displaying
captioning
information
when
provided
for
DTV/Analog
signal.
EZ
PIC
Adjusts
the
factory
preset
depending
on
the
viewing
environment.
SAP
Selects
MTS
sound:
Mono,
Stereo,
and
SAP
in
analog
mode.
Change
the
audio
language
in
DTV
mode.
SURROUND
Selects
:
Off,
3D
EchoSound
System
and
SRS
TruSurround
XT.
MUTE
Switches
the
Mute
or
the
EZ
mute.
Mute:
The
sound
is
off.
EZ
mute:
Turns
the
sound
off,
and
displays
the
caption.
THUMBSTICK
(UP/DOWN/LEFT/RIGHT/
)
Allows
you
to
navigate
the
on-screen
menus
and
to
adjust
the
system
settings
and
prefer-
ences,
by
moving
to
an
option
withF
G
and
selecting
the
highlighted
option
with
.
TV
INPUT
Switches
TV
mode
or
CATV
mode.
MODE
Selects
the
remote
operating
mode:
TV,
VCR,
Cable,
DVD
or
Satellite.
Select
other
operating
modes,
for
the
remote
to
operate
external
devices.
TV/VIDEO
Selects:
Antenna,
Cable,
Video1,
Video2,
Front
video,
Component
1-2
and
HDMI/DVI
input
sources.
COMP1
Selects
the
Component
1
input
source.
EZ
SOUND
Selects
the
sound
appropriate
for
the
program's
category.
FREEZE
Captures
and
freezes
the
currently-viewed
picture.
RATIO
Changes
the
aspect
ratio.
MODE
INDICATOR
LIGHTS
Show
active
remote
mode
every
time
any
button
is
pressed.
D
E
PAGE
18
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE
SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
POWER
Turns
your
TV
or
any
other
programmed
equipment
on
or
off,
depending
on
mode.
CHANNEL
UP/DOWN
Scrolls
through
available
channels
present
in
EZ
Scan
memory.
NUMBER
KEYPAD
For
direct
channel
selection
and
programming
functions.
ENTER
When
in
the
menu
system
and
other
on-screen
displays,
selects
highlighted
options.
RECORD,
PAUSE,
REW,
FF,
PLAY,
STOP
Control
the
functions
on
your
VCR.
VOLUME
UP/DOWN
Increases/decreases
the
sound
level.
INFO
When
you
watch
the
TV,
dis-
plays
information
on
top
of
the
screen.
Not
available
in
Component
1-2
and
HDMI/DVI.
SKIP
LEFT/RIGHT
Playing
CDs:
Selects
songs.
Playing
DVDs:
Selects
movie
chapters.
COMP2
Selects
the
Component
2
input
source.
HDMI
Selects
the
HDMI
input
source.
DASH(-)
Is
used
to
enter
a
program
num-
ber
for
multiple
program
channels
such
as
2-1,2-2,etc.
FLASHBK
Tunes
to
the
previous
channel
viewed.
TIMER
Lets
you
select
the
amount
of
time
before
your
TV
turns
itself
off
automatically.
SIGNAL
Displays
the
digital
signal
strength.
FRONT
Selects
the
front
video
input
source.
PAGE
19
Turning
the
TV
On
On-Screen
Displays
This
page
describes
your
on-screen
display
and
information
banner
options.
10
Mute
TV
2-0
MONO
10:00
AM
First,
connect antenna
cable
and
power
cord
correctly.
At
this
moment,
the
TV
switches
to
standby
mode.
In
standby
mode
to
turn
TV
on,
press
the
POWER,
CH
+/-,
TV/VIDEO,
FRONT
or
number
buttons
on
the
remote
control
or
TV/VIDEO
or
CH
D
/
E
on
the
TV.
Select
the
viewing
source
by
using
TV/VIDEO,
COMP,
FRONT
or
HDMI
button
on
the
remote
control.
This
TV
is
programmed
to
remember
which
mode
it
was
last
set
to,
even
if
you
turn
the
TV
off.
Note:
See
page
21
if
you
have
not
auto
programmed
the
TV
to
receive
channels
in
your
local
broadcast
area.
When
finished
using
the
TV,
press
the
POWER
button
on
the
remote
control.
The
TV
reverts
to
standby
mode.
1
2
3
If
you
will
be
away
on
vacation,
disconnect
the
power
plug
from
the
wall
power
outlet.
Volume
Volume
level
is
displayed
while
adjusting
the
sound.
Mute
Appears
when
sound
is
muted.
Time
Appears
when
pressing
the
enter
button
on
remote
control.
Channel
Display
Displays
current channel
number.
PAGE
20
EZ
Scan
(Channel
Search)
Use
pages
9-16
to
connect
external
equipment
to
your
TV.
If
you
have
done
so,
plug
in
your
TV
to
a
standard
120V,
60Hz
power
outlet.
If
you
have
done
so,
remove
the
back
of
the
remote
and
install
in
two
AA
batter-
ies.
Make
sure
batteries
are
properly
installed
(check
the
+/--
symbols).
With
the
remote
control
in
hand,
press
the
POWER
button
to
turn
your
TV
on.
1
2
3
Press
the
MENU
button
on
the
remote
con-
trol,
then
use
the
UP/DOWN
arrow
button
to
select
the
SETUP
menu.
Press
the
RIGHT
arrow
button
to
access
the
SETUP
menu.
Press
ENTER
button
to
begin
the
channel
search.
Note:
Allow
EZ
Scan
to
complete
the
channel
search
cycle
for
TV,
DTV,
CATV,
CADTV,
etc.
4
5
6
Automatically
finds
all
channels
available
through
antenna
or
cable
inputs,
and
stores
them
in
memory
on
the
channel
list.
back
of
remote
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
4
6
3
Run
EZ
Scan
again
after
any
Antenna/Cable
connection
changes.
4
4
5
PAGE
21
Channel
Edit
Create
two
different
types
of
channel
lists
in
memory:
"Custom
list"
and
"Favorite
channel
list"
from
the
default
channel
list
made
in
the
EZ
scan
menu.
A
custom
list
can
be
created
by
toggling
each
channel
on
or
off
with
the
(Enter)
key.
Once
a
channel
is
highlighted,
you
will
be
able
to
see
whether
the
channel
is
currently
added
or
deleted
by
referring
to
the
small
window
at
the
top-left
corner
of
the
screen.
You
can
create
your
own
favorite
channel
list
with
up
to
20
chan-
nels.
Use
the
FAV
button
on
the
remote
control
when
a
channel
is
high-
lighted,
to
add
or
delete
the
channel
in
the
favorite
channel
list.
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
SETUP
menu.
Press
the
RIGHT
arrow
button
to
access
the
SETUP
menu.
Use
the
UP/DOWN
arrow
button
to
select
Ch.Edit
and
then
press
the
RIGHT
arrow
button.
You
will
now
see
a
screen
filled
with
channel
numbers
and
a
preview
picture.
Use
the
UP/DOWN
and
LEFT/RIGHT
arrow
button
to
select
a
channel,
then
use
the
button
to
add
or
delete
it.
Press
FAV
to
add
the
channel
to
the
Fav
List.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
2
1
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
4
5
4
2/3/4
1/3/4
1/3/4
4
CATV
is
available
for
1-135
channel.
PAGE
22
DTV
Signal
1
2
Press
the
SIGNAL
button
on
the
remote
control.
View
the
on-screen
signal
strength
moni-
tor
to
see
the
quality
of
the
signal
being
received.
Press
exit
button
to
return
to
TV
viewing.
3
Lets
you
know
how
strong
your
DTV
signal
is
and
whether
you
need
to
adjust
your
antenna
or
digital
cable
input.
The
higher
the
signal
strength,
the
less
likely
you
are
to
experience
degradation.
NOT
all
areas
or
programs
are
currently
available
with
Digital
DTV
signals.
Select
the
DTV
in
Input
Source
on
the
menu,
to
check
the
DTV
signal.
Using
the
SIGNAL
button
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
SETUP
menu.
Press
the
RIGHT
arrow
button
to
access
the
SETUP
menu.
Use
the
UP/DOWN
arrow
to
select
the
DTV
Signal.
Current
signal
strength
is
shown
on
menu.
Press
EXIT
button
to
return
to
TV
viewing.
3
4
Using
the
menu
Degaussing
the
Screen
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
SETUP
menu.
Press
the
RIGHT
arrow
button
to
access
the
SETUP
menu.
Use
the
UP/DOWN
arrow
button
to
select
Degauss,
then
press
the
RIGHT
arrow
button
to
perform
the
Degauss
function.
Press
EXIT
button
to return to
TV
viewing
or
press
MENU
button
to return to
the
previous
menu.
1
2
3
4
The
magnetic
field
of
the earth
may
affect
the
color
puri-
ty
of
the
and
other
magnetic
influences
nearby
may
also
have
an
affect
on
color
purity.
Even
the
installa-
tion
direction
of
the
TV
set
may
affect
color
purity.
Stripes
may
appear
on
the
screen
or
the
color
may
not
be
equal
in
the
corners.
You
can
restore
color
quality
by
operating
the
Degauss.
If
you
are
unable
to
correct
problem
by
degaussing,
try
again
after
about
4
minutes.
PAGE
23
Input
Source
Selection
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
SETUP
menu.
Press
the
RIGHT
arrow
button
to
access
the
Setup
menu.
Use
the
UP/DOWN
arrow
to
select
the
Input
Source
option.
Press
the
RIGHT
arrow
to
access
the
Input
Source
menu,
then
use
the
UP/DOWN
arrow
button
to
select
the
source.
Your
Main
source
options
are
:
Antenna,
Cable,
Video1,
Video2,
Front
video,
Component1,
Component2,
and
HDMI/DVI.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
Note:
Changes
the
source
for
the
screen
so
you
can
watch
your
on-air
TV,
cable
TV,
VCR,
DVD,
or
any
other
devices
that
are
connected
to
your
TV.
Using
the
menu
1
Use
the
TV/VIDEO,
FRONT,
COMP1-2,
and
HDMI
button
to
select
the
input
source.
Each
time
you
press
TV/VIDEO
button,
you
toggle
between
Antenna,
Cable,
Video1,
Video
2,
Front
Video,
Component1,
Component
2,
and
HDMI/DVI.
Using
the
TV/VIDEO,
FRONT,
COMP1-2
and
HDMI
button
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
SETUP
menu.
Press
the
RIGHT
arrow
button
to
access
the
SETUP
menu.
Use
the
UP/DOWN
arrow
to
select
the
Input
label
option.
Press
the
RIGHT
arrow
to
access
the
Input
label
menu,
then
use
the
UP/DOWN
arrow
button
to
select
the
source:
Video1,
Video2,
Front
video,
Component1,
Component2,
and
HDMI/DVI.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
Input
label
PAGE
24
VIDEO
Menu
Use
the
EZ
PIC
button
to
select
EZ
option.
Each
press
of
the
EZ
PIC
button
change
the
EZ
option:
Off,
Normal,
Digital
Preset,
Night
Time,
Movie,
Weak
Signal,
Video
Game,
and
Sports.
Press
EXIT
to
save
and
return
to
TV
viewing.
1
2
This
function
adjusts
the
TV
to
the
best
appear-
ance.
Select
the
preset
value
in
the
EZ
menu
based
on
the
program
category.
Normal,
Digital
Preset,
Night
Time,
Movie,
Weak
Signal,
Video
Game,
and
Sports
are
preset
for
good
quali-
ty
at
the
factory
and
cannot
be
changed.
When
adjusting
video
options
(Contrast,
Brightness,
Color,
Sharpness,
and
Tint)
manually,
EZ
automatically
changes
to
'Off'.
EZ
Choose
the
Digital
Preset
option
to
reset
the
EZ
options
to
their
factory
preset
values,
or
use
your
own
settings
with
Off.
Using
the
EZ
PIC
button
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
VIDEO
menu.
Press
the
RIGHT
arrow
button
to
access
the
VIDEO
menu.
Use
the
UP/DOWN
arrows
to
select
the
EZ
option.
Press
the
RIGHT
arrow
to
access
the
EZ
menu,
then
use
the
UP/DOWN
arrow
button
to
select
the
options:
Off,
Normal,
Digital
Preset,
Night
Time,
Movie,
Weak
Signal,
Video
Game,
and
Sports.
?
Off:
Allows
you
to
adjust
the
the
way
you
want.
?
Digital
Preset:
Resets
all
the
options
to
their
preset
values.
?
Other
options
adjust
the
to
the
source's
image.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
Using
the
menu
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
2/4
5
1/3/4
1/3/4
Each
video
menu
adjustment
doesn't
effect
other
input
sources.
Readjust
Video
menu
for
each
input
source.
PAGE
25
VIDEO
Menu
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
VIDEO
menu.
Press
the
RIGHT
arrow
button
to
access
the
VIDEO
menu.
Use
the
UP/DOWN
arrow
button
to
select
one
of
the
following
options:
Contrast,
Brightness,
Color,
Sharpness,
or
Tint,
then
press
the
RIGHT
arrow
button.
?
Contrast:
Adjusts
the
difference
between
the
light
and
dark
levels
of
the
picture.
?
Brightness:
Adjusts
the
white
or
light
level
of
the
overall
picture.
?
Color:
Adjusts
the
intensity
of
all
col-
ors.
?
Sharpness:
Adjusts
the
level
of
crisp-
ness
in
the
edges
between
the
light
and
dark
areas
of
the
picture.
The
lower
the
level,
the
softer
the
image.
?
Tint:
Adjusts
the
balance
between
the
red
and
green
levels.
Use
the
LEFT/RIGHT
arrow
button
to
adjust
the
option
to
your
preference.
Use
the
UP/DOWN
arrow
button
to
select
another
option.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
You
can
manually
adjust
the
levels
of
quality
settings,
such
as
Contrast,
Brightness,
Sharpness,
etc.
Adjust
the
appearance
to
suit
your
preference
and
viewing
situations.
4
5
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
4
5
2/3/4
1/3/4
1/3/4
Manual
Video
Control
PAGE
26
VIDEO
Menu
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
VIDEO
menu.
Press
the
RIGHT
arrow
button
to
access
the
VIDEO
menu.
Use
the
UP/DOWN
arrow
button
to
select
Video
Preset.
Use
the
RIGHT
arrow
button
to
preset
the
video
config-
uration.
1
2
3
This
is
the
function
to
quickly
reset
every
Video
menu
option
to
their
factory
preset
values.
4
Video
Preset
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
VIDEO
menu.
Press
the
RIGHT
arrow
button
to
access
the
VIDEO
menu.
Use
the
UP/DOWN
arrow
button
to
select
XD,
and
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
Off
or
On.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to return to
the
previous
menu.
1
2
3
4
5
XD
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
VIDEO
menu.
Press
the
RIGHT
arrow
button
to
access
the
VIDEO
menu.
Use
the
UP/DOWN
arrow
button
to
select
Color
Temperature,
and
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
Warm,
Medium,
or
Cool.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to return to
the
previous
menu.
1
2
3
Lets
you
choose
one
of
three
automatic
color
adjustments.
Set
this
to
warm
for
hotter
colors
such
as
red,
or
set
to
cool
for
less
intense
colors
with
more
blue.
4
5
Color
Temperature
-
XD
is
LG
Electronic's
unique
improving
technology
to
display
a
real
HD
source
through
an
advanced
digital
signal
processing
algorithm.
-
When
selecting
EZ
PIC
options
(Normal,
Digital
Preset,
Night
Time,
Movie,
Weak
Signal,
Video
Game,
and
Sports),
XD
is
automatically
change
to
On.
PAGE
27
AUDIO
Menu
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
AUDIO
menu.
Press
the
RIGHT
arrow
button
to
access
the
AUDIO
menu.
Use
the
UP/DOWN
arrow
button
to
select
Audio
Language,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
the
language
you
wish.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
Other
languages
may
be
available
only
if
a
digital
signal
is
being
sent
by
the
broadcasting
station.
4
5
Audio
Language
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
AUDIO
menu.
Press
the
RIGHT
arrow
button
to
access
the
AUDIO
menu.
Use
the
UP/DOWN
arrow
button
to
select
EZ
SoundRite,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
On
or
Off.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
Scans
for
changes
in
sound
level
during
commercials,
then
adjusts
the
sound
to
match
the
current
audio
level.
This
will
make
sure
that
the
volume
level
will
be
consistent
whether
you
are
watching
a
commercial
or
a
regular
TV
program.
4
5
EZ
SoundRite
PAGE
28
AUDIO
Menu
1
2
This
function
lets
you
enjoy
the
best
sound
without
any
special
adjustment
because
the
TV
automatically
selects
the
appropriate
sound
option
based
on
the
program
content.
Normal,
Stadium,
News,
Music
and
Theater
are
preset
for
good
sound
quality
at
the
factory
and
cannot
be
changed.
When
adjusting
audio
options
(treble,
bass
and
Front
Surround)
manually,
EZ
Sound
automatically
changes
to
Off.
This
TV
can
receive
MTS
stereo
programs
and
any
SAP
(Secondary
Audio
Program)
that
accompanies
the
stereo
program;
if
the
station
transmits
an
additional
sound
signal
as
well
as
the
original
one.
Use
the
SAP
button
to
select
your
desired
MTS
mode
in
analog
signal.
Each
time
you
press
the
SAP
button,
MONO,
STEREO,
or
SAP
appear
in
turn.
Press
EXIT
to
save
and
return
to
TV
viewing.
EZ
Sound
Stereo/SAP
Broadcasts
Setup
Choose
the
NORMAL
option
in
EZ
Sound
to
quickly
reset
the
Audio
Menu
options
to
their
original
pre-
set
values,
or
use
your
own
settings
with
Off.
Stereo
or
SAP
can
be
received
only
when
the
TV
station
transmits
those
signals
even
though
you
have
selected
STEREO
or
SAP.
Mono
sound
is
automatically
received
if
the
broadcast
is
only
in
Mono;
even
though
STEREO
or
SAP
has
been
selected.
Select
MONO
if
you
want
to
listen
to
the
mono
sound
in
remote
fringe
areas
during
stereo/SAP
broadcasting.
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
AUDIO
menu.
Press
the
RIGHT
arrow
button
to
access
the
AUDIO
menu.
Use
the
UP/DOWN
arrow
to
select
the
EZ
Sound
option.
Press
the
RIGHT
arrow
to
access
the
EZ
Sound
menu,
then
use
the
UP/DOWN
arrow
button
to
select
the
options:
Off,
Normal,
Stadium,
News,
Music
and
Theater.
?
Off:
Allows
you
to
adjust
the
sound
the
way
you
want.
?
Normal:
Resets
all
the
options
to
their
preset
values.
?
Other
options
adjust
the
TV's
audio
out-
put
to
the
source's
sound.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
Use
the
EZ
SOUND
button
to
select
EZ
Sound
option.
Each
press
of
the
EZ
SOUND
button
change
the
EZ
Sound
option:
Off,
Normal,
Stadium,
News,
Music
and
Theater.
Press
EXIT
button
to
save
and
return
to
TV
viewing.
1
2
Using
the
EZ
SOUND
button
Using
the
menu
PAGE
29
AUDIO
Menu
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
AUDIO
menu.
Press
the
RIGHT
arrow
button
to
access
the
AUDIO
menu.
Use
the
UP/DOWN
arrow
button
to
select
one
of
the
following
options:
Balance,
Treble,
or
Bass,
then
press
the
Right
arrow
button.
?
Balance:
Lets
you
adjust
the
left
to
right
balance
of
the
TV
speakers.
?
Treble:
Increases
or
decreases the
higher
frequency
sounds
from
the
TV
speakers.
?
Bass:
Increases
or
decreases
the
lower
frequency
sounds
from
the
TV
speakers.
Use
the
LEFT/RIGHT
arrow
button
to
adjust
the
option
to
your
preference.
Use
the
UP/DOWN
arrow
to
select
another
option.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
Adjust
the
sound
to
suit
your
taste
and
room
situations.
Turns
the
TV
Speaker
option
On
or
Off.
4
5
Manual
Sound
Control
TV
Speaker
On/Off
Setup
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
AUDIO
menu.
Press
the
RIGHT
arrow
button
to
access
the
AUDIO
menu.
Use
the
UP/DOWN
arrow
button
to
select
TV
Speaker,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
On
or
Off.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
PAGE
30
AUDIO
Menu
Front
Surround
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
AUDIO
menu.
Press
the
RIGHT
arrow
button
to
access
the
AUDIO
menu.
Use
the
UP/DOWN
arrow
button
to
select
Front
Surround,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
Off,
3D
EchoSound
System
or
SRS
(Sound
Retrieval
System)
TruSurround
XT.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
is
a
trademark
of
SRS
Labs,
Inc.
TruSurround
XT
technology
is
incorporated
under
license
from
SRS
Labs,
Inc.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
2/3
5
1/3/4
1/3/4
Manufactured
under
license
from
Dolby
Laboratories.
"Dolby"
and
the
double-D
symbol
are
trademarks
of
Dolby
Laboratories.
Mini
glossary
SRS
TruSurround
XT
Takes
advantage
of
any
multi-channel
format
without
needing
to
add
extra
speakers
or
equip-
ment.
Dialog
clarity,
bass
enrichment
and
the
addition
of
stereo
audio
enhancement
that
pro-
duces
an
immersive
sound
experience
from
stan-
dard
stereo
material.
3D
EchoSound
System
Creates
a
stunning
simulated
stereo
effects
from
any
mono
sound
and
a
realistic
three-dimensional
sound
with
a
very
wide
and
deep
sound
stage
into
stereo
sound.
Use
the
SURROUND
button
to
select
Front
Surround
option.
Each
press
of
the
SURROUND
button
change
the
Front
Surround
option:
Off,
3D
EchoSound
System
or
SRS
(Sound
Retrieval
System)
TruSurround
XT.
Press
EXIT
to
save
and
return
to
TV
viewing.
1
2
Using
the
SURROUND
button
Using
the
menu
PAGE
31
Auto
Clock
Setup
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
TIME
menu
option.
Press
the
RIGHT
arrow
button
to
go
to
the
TIME
menu.
Use
the
UP/DOWN
arrow
button
to
choose
Auto
Clock,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
choose
On,
then
use
the
RIGHT
arrow
button
to
select
Time
Zone.
Use
the
UP/DOWN
arrow
button
to
adjust
Time
Zone.
?
Select
the
time
zone
for
your
viewing
area.
Your
options
are:
Eastern,
Central,
Mountain,
Pacific,
Alaska,
Hawaii,
New
F.land,
Atlantic.
Use
the
UP/DOWN
arrow
button
to
adjust
Daylight
Saving.
?
Select
Auto,
Off,
On,
depending
on
whether
or
not
your
viewing
area
observes
Daylight
Saving
time.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
5
6
Sets
the
time
automatically
through
the
digital
channel
signal.
The
digital
channel
signal
includes
information
for
the
current
time
provided
by
the
broadcasting
station.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/6
6
2/3/4
1/3/4/5
1/3/4/5
Set
the
clock
manually
again
if
the
current
time
is
incorrect
with
auto
clock
function.
7
PAGE
32
Manual
Clock
Setup
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
TIME
menu
option.
Press
the
RIGHT
arrow
button
to
activate
the
Time
menu.
Use
the
UP/DOWN
arrow
button
to
choose
Manual
Clock,
then
press
the
RIGHT
arrow
button.
Use
the
LEFT/RIGHT
arrow
button
to
select
either
the
year,
date
or
time
option.
Once
selected,
use
the
UP/DOWN
arrow
button
to
set
the
year,
date
or
time
option.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
5
If
current
time
setting
is
erased
by
a
power
failure
or
if
TV
is
unplugged,
reset
the
clock.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
5
2/3/4
1/3/4
1/3/4
4
PAGE
33
TV
Turn
Off
Time
Setup
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
TIME
menu.
Press
the
RIGHT
arrow
button
to
to
go
to
the
TIME
menu.
Use
the
UP/DOWN
arrow
button
to
choose
Off
Timer,
then
press
the
RIGHT.
Use
the
UP/DOWN
arrow
button
to
choose
On,
then
press
the
RIGHT
arrow
button.
Use
the
LEFT/RIGHT
arrow
button
to
select
the
hour
or
minutes
options,
then
use
the
UP/DOWN
arrow
button
to
set
the
hours
or
minutes.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
5
Lets
you
set
an
automatic
daily
turn
off
time
for
your
TV.
Off
Timer
function
overrides
On
Timer
function
if
they
are
both
set
to
the
same
time.
You
must
set
the
current
time
on
the
clock
before
using
on/off
timers.
6
To
cancel
Off
Timer
function,
use
the
UP/DOWN
arrow
button
to
select
Off
in
step
4.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/6
5
6
1/3/4/5
2/3/4/5
1/3/4/5
PAGE
34
TV
Turn
On
Time
Setup
Lets
you
set
an
automatic
daily
turn
on
time
for
your
TV.
Off
timer
function
overrides
on
timer
function
if
they
are
both
set
to
the
same
time.
Unless
a
button
is
pressed
within
two
hours
after
the
TV
is
turned
on
by
the
On
Timer
function,
the
TV
will
auto-
matically
turn
off.
TV
must
be
in
standby
mode
for
the
On
Timer
to
work.
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
TIME
menu.
Press
the
RIGHT
arrow
button
to
activate
the
TIME
menu.
Use
the
UP/DOWN
arrow
button
to
choose
On
Timer,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
to
choose
On,
then
press
the
RIGHT
arrow
button.
Use
the
LEFT/RIGHT
arrow
button
to
select either
Time,
Channel,
or
Volume.
Once
selected,
use
the
UP/DOWN
arrow
button
to
set
either
the
Time,
Channel,
or
Volume
options.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
5
6
To
cancel
On
Timer
function,
use
the
UP/DOWN
arrow
button
to
select
Off
in
step
4.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/6
5
6
1/3/4/5
2/3/4/5
1/3/4/5
PAGE
35
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
TIME
menu.
Press
the
RIGHT
arrow
button
to
go
to
the
Time
menu.
Use
the
UP/DOWN
arrow
button
to
choose
Sleep
Timer
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
to
choose
a
pre-
set
turn
off
time.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
5
Sleep
Timer
Setup
Press
the
TIMER
button
on
the
remote
control
repeatedly
to
select
the
number
of
minutes.
First
the
Off
option
will
appear
on
the
screen,
followed
in
sequence
10, 20, 30,
60,
90,
120,
180,
and
240.
The
timer
begins
to
count
down
from
the
number
of
minutes
selected.
Press
EXIT
button
to
save
and
return
to
TV
viewing
1
2
Lets
you
select
the
amount
of
time
if
you
want
your
TV
to
turns
itself
off,
automatically.
When
the
sleep
time
you
want
is
displayed
on
the
screen,
don't
press
the
timer
button
again.
To
check
the
remaining
sleep
time,
press
the
TIMER
button
once.
To
change
sleep
time
setting,
press
the
TIMER
button
repeatedly
to
select
time
set-
ting
you
want.
If
you
turn
the
TV
off
after
setting
the
sleep
timer,
the
setting
will
be
erased.
Using
the
TIMER
button
Using
the
menu
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
2/3
5
1/3/4
1/3/4
PAGE
36
Auto
Off
If
there
is
no
input
signal,
the
TV
can
be set
up
to
switch
to
standby
mode
automatically
after
10
minutes.
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
TIME
menu.
Press
the
RIGHT
arrow
button
to
go
to
the
TIME
menu.
Use
the
UP/DOWN
arrow
button
to
choose
Auto
Off
then
press
the
RIGHT
arrow.
Use
the
UP/DOWN
arrows
to
choose
On
or
Off.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
5
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
2/3
5
1/3/4
1/3/4
PAGE
37
Aspect
Ratio
Control
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
go
to
the
OPTION
menu.
Use
the
UP/DOWN
arrow
to
choose
the
Aspect
Ratio
option,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
the
desired
format.
?
Use
the
UP/DOWN
arrow
button
to
adjust
the
enlarge
proportion
of
Cinema
Zoom.
The
adjustment
of
range
is
1~16.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
5
Use
the
RATIO
button
to
select
the
desired
for-
mat.
Each
press
of
the
RATIO
button
changes
the
for-
mat.
Your
options
are:
Set
By
Program,
4:3,
16:9,
Horizon,
Zoom1,
Zoom2,
and
Cinema
Zoom.
Press
EXIT
to
save
and
return
to
TV
viewing.
1
2
Lets
you
choose
the
way
that
an
analog
with
a
4:3
aspect
ratio
is
displayed
on
your
TV
with
a
16:9
ratio.
When
you
receive
an
analog
with
a
4:3
aspect
ratio
on
your
16:9
TV,
you
need
to
specify
how
the
is
to
be
displayed
according
to
your
preference.
Using
the
RATIO
button
Using
the
menu
Mini
glossary
Set
By
Program
Select
the
proper
proportion
to
match
the
source's
image.
(4:3
→
4:3,
16:9
→
16:9)
4:3
Choose
when
you
want
to
view
a
with
an
original
4:3
aspect
ratio,
with
black bars
appearing
at
both
the
left
and
right
sides.
16:9
Choose
when
you
want
to
adjust
the
horizontally,
in
a
linear
proportion
to
fill
the
entire
screen.
Horizon
Choose
when
you
want
to
adjust
the
in
a
non-linear
proportion,
that
is,
more
enlarged
at
both
sides,
to
create
a
spectacu-
lar
view.
Zoom1
Choose
when
you
want
to
view
the
without
any
alteration.
However,
the
top
and
bottom
portions
of
the
will
be
cropped.
Zoom2
Choose
when
you
want
the
to
be
altered,
both
vertically
extended
and
vertically
cropped.
The
taking
a
halfway
trade
off
between
alteration
and
screen
coverage.
Cinema
Zoom
Choose
when
you
want
to
enlarge
the
in
correct
proportion.
When
enlarging
or
reducing
the
picture,
the
may
become
distorted.
When
you
receive
a
with
a
16:9
aspect
ratio,
you
can't
specify
horizon
aspect
ratio.
If
you
select
a
horizon
during
receiving
a
4:3
aspect
ratio,
16:9
aspect
ratio
is
worked
as
set
by
program.
PAGE
38
Captions
1
2
3
4
5
Mini
glossary
CAPTIONS
The
term
for
the
words
that
scroll
across
the
bot-
tom
of
the
TV
screen;
usually
the
audio
portion
of
the
program
provided
for
the
hearing
impaired.
TEXT
The
term
for
the
words
that
appear
in
a
large
black
frame
and
almost
cover
the
entire
screen;
usually
messages
provided
by
the
broadcaster.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
2/3
5
1/3/4
1/3/4
Select
a
caption
mode
for
displaying
captioning
informa-
tion
when
provided
on
the
program.
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
activate
the
OPTION
menu.
Use
the
UP/DOWN
arrow
button
to
choose
Caption,
then
press
the
Right
arrow
button.
Use
the
UP/DOWN
arrow
to
choose
On
or
Off.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
This
TV
is
programmed
to
remember
the
caption
mode
it
was
last
set
to,
when
you
turn
the
POWER
off.
PAGE
39
Captions/Text
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
activate
the
OPTION
menu.
Use
the
UP/DOWN
arrow
button
to
choose
Caption,
then
press
the
Right
arrow
button.
Use
the
UP/DOWN
arrow
button
to
make
your
caption
selection.
Your
choices
are:
CC1,CC2,CC3,CC4,Text1,Text2,Text3,
or
Text
4.
Press
EXIT
button
to return to
TV
viewing
or
press
MENU
button
to return
to
the
previous
menu.
1
2
Use
the
CC
button
to
select
caption.
Each
press
of
the
CC
button
changes
the
caption
option;
Off,
CC1,
CC
2,
CC
3,
CC
4,
Text
1,
Text
2,
Text
3,
or
Text
4.
Press
EXIT
to
save
and
return
to
TV
view-
ing.
3
4
5
Analog
caption
displays
information
at
any
position
on
the
screen
usually
the
program's
dialog.
Text
displays
information,
usually
at
the
bottom
position
and
is
used
for
a
data
service,
generally
not
program
related.
Caption/Text,
if
provided
by
the
broadcaster,
would
be
available
for
both
digital
and
analog
channels
on
the
Antenna/Cable
source.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
2/3
5
1/3/4
1/3/4
Using
the
CC
button
Using
the
menu
PAGE
40
Caption
Option
Menu
6
Customize
the
DTV/CADTV
captions
that
will
appear
on
your
screen.
1
2
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
access
the
OPTION
menu.
Use
the
UP/DOWN
arrow
to
select
the
Caption
Option,
then
press
the
RIGHT
arrow
button.
Use
the
LEFT/RIGHT
arrow
button
to
select
Custom.
Use
UP/DOWN
arrow
button
to
customize
the
Style,
Font,
etc.,
to
your
preference.
Your
Caption options
are:
?
Size:
Set
the
size
the
words
will
appear
in.
?
Font:
Select
a
typeface
for
the
words.
?
Text
Color:
Choose
a
color
for
the
text.
?
Text
Opacity:
Specify
the
opacity
for
the
text
color.
?
Bg
(Background)
Color: Select
a
back-
ground
color.
?
Bg
(Background)
Opacity:
Select
the
opacity
for
the
background
color.
?
Edge
Type:
Select
an
edge
type.
?
Edge
Color:
Select
a
color
for
the
edges.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
3
4
5
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
5
4
1/3/4
2/3/4
1/3/4
A
preview
icon
is
provided
at
the
bottom
of
the
screen,
use
it
to
see
the
caption
language.
PAGE
41
On-Screen
Menu
Languages
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
go
to
the
OPTION
menu.
Use
the
UP/DOWN
arrow
to
choose
the
Language,
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
the
language
you
want
the
on
screen
menus
to
appear
in.
Press
EXIT
button
to return to
TV
viewing
or
press
MENU
button
to return
to
the
previous
menu.
1
2
3
4
5
Select
your
preferred
language
for
the
menus:
English,
Espanol
(Spanish),
or
Francais
(French).
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/5
5
1/3/4
2/3
1/3/4
PAGE
42
Velocity
Modulation
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
access
the
Option
menu.
Use
the
UP/DOWN
arrow
button
to
select
Tilt,
then,
use
the
VOL
button
on
the
set
to
adjust
and
correct
any
Tilt.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previous
menu.
1
2
3
4
The
on
the
TV
screen
may
be
tilted
to
the
left
or
right
if
the
set
is
moved
to
a
different
place
or
direction.
Tilt
should be used
to correct
any
tilt.
Tilt
Press
the
MENU
button
on
the
remote
con-
trol,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
access
the
OPTION
menu.
Use
the
UP/DOWN
arrow
button
to
select
VM,
and
then
press
the
RIGHT
arrow
button.
Use
the
UP/DOWN
arrow
button
to
select
Off,
Low,
or
High.
Press
EXIT
button
to
return
to
TV
viewing
or
press
MENU
button
to
return
to
the
previ-
ous
menu.
1
2
3
4
5
Use
this
function
to
improve
the
outline
distinction
of
the
picture's
edges.
If
you
select
VM
'Off',
the
TV
will
automatically
return
the
pictures'
edge
appearance
to
factory
settings.
PAGE
43
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
access
the
OPTION
menu.
Use
the
UP/DOWN
arrow
to
choose
Cinema
3:2
Mode,
then
press
the
Right
arrow
button.
Use
the
UP/DOWN
arrow
to
choose
On
or
Off.
Press
EXIT
button
to return to
TV
viewing
or
press
MENU
button
to return to
the
previous
menu.
1
2
3
4
Cinema
3:2
Mode
Setup
Most
movies
are
24
frames/sec,
but
TV
signal
is
30
frames/sec.
This
option
lets
the
TV
do
3:2
pull-down
operation
for
you
to
watch
movies
at
the best
motion
appearance.
5
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
2/3
1/5
5
1/3/4
1/3/4
PAGE
44
EZ
Demo
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
OPTION
menu.
Press
the
RIGHT
arrow
button
to
access
the
OPTION
menu.
Use
the
UP/DOWN
arrow
button
to
select
EZ
Demo,
then
press
the
RIGHT
arrow
button.
Press
EXIT
button
on
the
remote
to
stop
EZ
Demo.
1
2
3
4
Shows
you
how
to
navigate
the
TV's
on-screen
menus.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/3
2/3
1/3
1
4
PAGE
45
Parental
Lock
Setup
Press
the
MENU
button
on
the
remote
control,
then
use
the
UP/DOWN
arrow
button
to
select
the
LOCK
Menu
option.
Press
the
RIGHT
arrow
button
to
activate
the
LOCK
Menu.
Use
the
UP/DOWN
arrow
to
choose
from
the
following
Lock
Menu
options.
Once
the
options
are
selected,
change
the
settings
to
your
pref-
erences.
?
Lock
System:
Activates
or
disables
the
blocking
scheme
you
set
up
previously.
?
Set
Password:
Change
the
password
by
inputting
a
new
password
twice.
?
Block
Ch.:
Blocks
any
channels
that
you
do
not
want
to
watch
or
that
you
do
not
want
your
chil-
dren
to
watch.
?
English:
To
prevent
the
children
from
looking
at
certain
tele
programs
for
the
programs
intended
for
the
children.
This
dimension
does
not
apply
to
the
other
tele
programs.
Unless
locking
certain
programs
intended
for
the
older
spectators
with
the
general
menu;
tele
dimension,
the
children
can
look
at
these
emissions
?
French:
To
lock
certain
tele
programs
which
one
does
not
want
to
look
according
to
the
dimen-
sions.
?
Aux.
Block:
Enables
you
to
select
a
source
for
blocking
among
the
source
devices
you
have
hooked
up.
Press
EXIT
button
to return to
TV
viewing
or
press
MENU
button
to
return to
the
previous
menu.
1
2
3
4
Lets
you
set
up
blocking
schemes
to
block
specific
channels,
ratings,
and
viewing
sources.
A
password
is
required
to
gain
access
to
this
menu
if
the
Lock
System
is
activated.
If
the
lock
is
already
set,
enter
the
password
as
requested.
The
TV
is
set
up
with the
initial
password
'0', '0', '0',
'0'.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
1/3
1/4
1/3
4
2
PAGE
46
E(Exempt)
C(Children)
C8+(Children
eight
years
and
older)
G(General
programming,
suitable
for
all
audiences)
PG(Parental
Guidance
)
14+(Viewers
14
years
and
older)
18+(Adult
programming)
Blocking
Off(Permits
all
programs)
E(Exempt)
G(General)
8
ans+(General-Not
convenient
for
little
children)
13
ans+(Not
convenient
for
children
of
13
years
and
younger)
16
ans+(Not
convenient
for
children
of
16
years
and
younger)
18
ans+(This
programs
is
only
for
adults)
Blocking
Off(Permits
all
programs)
Parental
Lock
Rating
Descriptions
Parental
Lock
Setup
(Continued)
PAGE
47
Test
your
remote
control.
To
find
out
whether
your
remote
control
can
operate
the
component
without
programming,
turn
on
the
component
such
as
a
VCR
and
press
the
corresponding
mode
button
(VCR)
on
the
remote
control,
while
pointing
at
the
compo-
nent.
Test
the
POWER
and
CH
+/-
buttons
to
see
if
the
component
responds
properly.
If
not,
the
remote
requires
programming
to
operate
the
device.
Turn
on
the
component
to
be
programmed,
then
press
the
corresponding
mode
button
on
the
remote
control.
Press
the
POWER
and
MUTE
buttons
simultane-
ously,
the
remote
control
is
ready
to
be
pro-
grammed
for
the
code.
There
are
two
ways
to
find
the
right
code
for
the
component.
A.
If
you
press
the
CH
+/-
buttons
repeatedly,
the
codes
will
change
one
at-a-time.
Press
the
POWER
button
after
each
code
change.
If
the
right
code
is
found,
the
device
will
turn
off.
B.
Enter
a
code
number
using
the
number
but-
tons
on
the
remote.
Programming
code
num-
bers
for
the
corresponding
component
can
be
found
on
the
following
pages.
Again,
if
the
code
is
correct,
the
device
will
turn
off.
Press
the
EXIT
button
to
store
the
code.
Test
the
remote
control
functions
to
see
if
the
component
responds
properly.
If
not,
repeat
from
step
2.
123
456
789
0
TV
MODE
*
POWER
TV
INPUT
COMP1
FRONT
VCR
CABLE
DVD
SAT
MUTE
SURROUND
FREEZE SAP
RATIO
INFO
RECORD
STOP
PAUSE
REW
PLAY
FF
MENU
EXIT
TIMER
CC
SIGNAL
VOL
CH
FAV
EZ
SOUND
EZ
PIC
HDMI
COMP2
TV/VIDEO
SKIP
DASH(-)
FLASHBK
The
remote
control
for
your
HD
receiver
is
a
multi-
brand
or
universal
remote
control.
It
can
be
pro-
grammed
to
operate
most
remote-controllable
devices
of
other
manufacturers.
Note
that
the
remote
control
may
not
control
all
models
of
other
brands.
PAGE
48
Brand
Codes
AIWA
034
AKAI
016
043 046
124
125 146
AMPRO
072
ANAM
031
033
103
AUDIO
DYNAMICS
012
023 039
043
BROKSONIC
035
037
129
CANON
028
031 033
CAPEHART
108
CRAIG
003 040
135
CURTIS
MATHES
031
033 041
DAEWOO
005
007
010
064
065
108
110
111 112
116
117 119
DAYTRON
108
DBX
012
023 039
043
DYNATECH
034
053
ELECTROHOME
059
EMERSON
006
017 025
027
029 031
034
035 036
037
046
101
129
131
138
153
FISHER
003 008
009
010
FUNAI
034
GE
031
033 063
072
107 109
144
147
GO
VIDEO
132
136
GOLDSTAR
012
013
020
101
106
114
123
HARMAN
KARDON
012
045
HITACHI
004
018
026
034
043 063
137 150
INSTANTREPLAY
031
033
JCL
031
033
JCPENNY
012
013 015
033 040
066
101
JENSEN
043
JVC
012
031 033
043 048 050
Brand
Codes
055
060
130
150
152
KENWOOD
014 034
039
043 047 048
LG
255
LLOYD
034
LXI
003 009
013
014
017 034
101 106
MAGIN
040
MAGNAVOX
031 033 034
041 067 068
MARANTZ
012 031
033
067 069
MARTA
101
MATSUI
027
030
MEI
031 033
MEMOREX
003 010 014
031 033 034
053 072
101
102
134
139
MGA
045 046
059
MINOLTA
013
020
MITSUBISHI
013 020
045
046 049
051
059 061
151
MTC
034 040
MULTITECH
024 034
NEC
012 023
039
043
048
NORDMENDE
043
OPTONICA
053
054
PANASONIC
066
070
074
083
133 140
145
PENTAX
013
020
031
033 063
PHILCO
031
034
067
PHILIPS
031 033 034
054
067
071
101
PILOT
101
PIONEER
013
021
048
PORTLAND
108
PULSAR
072
QUARTZ
011
014
QUASAR
033 066
075
145
RCA
013
020
033
Brand
Codes
034
040
041
062
063
107
109
140 144
145
147
REALISTIC
003
008 010
014 031 033
034
040
053
054
101
RICO
058
RUNCO
148
SALORA
014
SAMSUNG
032
040
102
104 105 107
109
112 113
115
120
122
125
SANSUI
022
043
048
135
SANYO
003
007
010
014
102
134
SCOTT
017
037
112
129
131
SEARS
003
008
009
010 013
014
017
020
031
042
073 081
101
SHARP
031
054
149
SHINTOM
024
SONY
003
009 031
052
056 057
058 076 077
078
149
SOUNDESIGN
034
STS
013
SYLVANIA
031
033
034
059
067
SYMPHONIC
034
TANDY
010
034
TATUNG
039
043
TEAC
034 039 043
TECHNICS
031
033 070
TEKNIKA
019
031 033
034
101
THOMAS
034
TMK
006
TOSHIBA
008 013 042
047
059 082
112
131
Brands
Codes
TOTEVISION
040
101
UNITECH
040
VECTOR
RESEARCH
012
VICTOR
048
VIDEO
CONCEPTS
012
034
046
VIDEOSONIC
040
WARDS
003 013
017
024
031
033
034 040 053
054
131
YAMAHA
012
034 039
043
ZENITH
001
034
048
056
058 072
080
101
PAGE
49
Brand
Codes
ALPHASTAR
DSR
123
AMPLICA
050
BIRDVIEW
051
126 129
BSR
053
CAPETRONICS
053
CHANNEL
MASTER
013
014
015
018
036 055
CHAPARRAL
008
009 012
077
CITOH
054
CURTIS
MATHES
050
145
DRAKE
005 006 007
010
011 052
112 116 141
DX
ANTENNA
024
046 056
076
ECHOSTAR
038 040
057
058
093
094
095 096 097
098
099
100
122
ELECTRO
HOME
089
EUROPLUS
114
FUJITSU
017 021 022
Brand
Codes
027
133
134
GENERAL
INSTRUMENT
003
004
016
029 031 059
101
HITACHI
139
140
HOUSTON
TRACKER
033 037 039
051 057
104
HUGHES
068
HYTEK
053
JANIEL
060
147
JERROLD
061
KATHREIN
108
LEGEND
057
LG
255
LUTRON
132
LUXOR
062
144
MACOM
010
059 063
064
065
MEMOREX
057
NEXTWAVE
028
124
125
NORSAT
069
070
PACE
SKY
SATELLITE
143
PANASONIC
060
142
PANSAT
121
Brand
Codes
PERSONAL
CABLE
117
PHILIPS
071
PICO
105
PRESIDENT
019
102
PRIMESTAR
030
110
111
PROSAT
072
RCA
066
106
REALISTIC
043
074
SAMSUNG
123
SATELLITE
SERVICE
CO
028
035 047
057 085
SCIENTIFIC
ATLANTA
032
138
SONY
103
STARCAST
041
SUPER
GUIDE
020
124
125
TEECOM
023 026 075
087
088 090
107
130
137
TOSHIBA
002
127
UNIDEN
016 025 042
043
044
045
048
049
078
079
080
086
101 135 136
Brand
Codes
VIEWSTAR
115
WINEGARD
128
146
ZENITH
001
081 082
083 084
091
120
Brand
Codes
APEX
DIGITAL
022
DENON
020 014
GE
005 006
GOLDSTAR
010
016
025
HARMAN
KARDON
027
JVC
012
LG
001
010
016
Brand
Codes
025
MAGNAVOX
013
MARANTZ
024
MITSUBISHI
002
NAD
023
ONKYO
008
017
PANASONIC
003 009
Brand
Codes
PHILIPS
013
PIONEER
004
026
PROCEED
021
PROSCAN
005 006
RCA
005 006
SAMSUNG
011 015
SONY
007
Brand
Codes
THOMPSON
005 006
TOSHIBA
019
008
YAMAHA
009
018
ZENITH
010
016 025
PAGE
50
Brand
Codes
ABC
003
004
039
042
046 052
053
ANTRONIK
014
ARCHER
005
007
014
024
CABLE
STAR
026
CENTURION
092
CENTURY
007
CITIZEN
007
COLOUR
VOICE
065
090
COMBANO
080 081
COMTRONICS
019
030
DIAMOND
023
EAGLE
020
030 040
EASTERN
057
062
066
ELECTRICORD
032
GE
072
GEMINI
008 022 025
054
GI
052
074
GOLDEN
CHANNEL
030
HAMLIN
049
050
055
HITACHI
052
055
HOSPITALITY
070 077
JERROLD
002
003
004
Brand
Codes
008
009
010
052 069
074
LG
255
M-NET
037
MACOM
033
MAGNAVOX
010
012
064
079
MEMOREX
001
MOVIE
TIME
028 032
NSC
015
028
038
071 073
OAK
016 031
037
053
PANASONIC
044 047
PARAGON
001
PHILIPS
006 012
013
020
065
085
090
PIONEER
034
051
052
063 076
POST
NEWS
WEEK
016
PRUCER
059
PTS
011
048 071
072 073
074
PULSAR
001
RCA
047
Brand
Codes
REGAL
049
050
REGENCY
057
REMBRANT
025
RK
091
SAMSUNG
030 068
SCIENTIFIC
ATLANTA
003 011 041
042 043 045
046
SHERITECH
022
SIGNAL
030
SIGNATURE
052
SL
MARX
030
SPRUCER
047
078
STARCOM
002
004 008
009
STARGATE
008 030
SYLVANIA
067
TADIRAN
030
TANDY
017
TEXSCAN
029 067
TOCOM
039
040
056
TOSHIBA
001
UNIKA
007
014 024
UNITED
CABLE
004
053
UNIVERSAL
005 007
014
024
026 027
Brand
Codes
032 035
VIEWSTAR
012 015
018
086 087
088
089
ZENITH
001
060
093
PAGE
51
1. Here's
a
great
way
to
keep
the
dust
off
your
screen
for
a
while.
Wet
a
soft
cloth
in
a
mixture
of
lukewarm
water
and
a
little
fabric
softener
or
dish
washing
detergent.
Wring
the
cloth
until
it's
almost
dry,
and
then
use
it
to
wipe
the
screen.
2.
Make
sure
the
excess
water
is
off
the
screen,
and
then
let
it
air-dry
before
you
turn
on
your
TV.
1.
Use
a
soft
cloth
with
a
mild
soap
solution
to
wipe
the
cabinet.
2.
Rinse
the
cloth
and
wipe
the
cabinet
again.
3.
Let
the
cabinet
air-dry
before
turning
the
TV
on.
If
you
expect
to
leave
your
TV
dormant
for
a
long
time
(such
as
a
vacation),
unplug
the
power
cord
from
the
wall
power
outlet
to
protect
against
possible
damage
from
lightning
or
power
surges.
If
you
use
an
off-air
antenna,
you
may
also
want
to
disconnect
it
from
the
back
of
your
TV
before
leaving.
SCREEN
CLEANING
EXTENDED
ABSENCE
CABINET
CLEANING
Early
malfunctions
can
be
prevented.
Careful
and
regular
cleaning
can
extend
the
amount
of
time
you
will
have
your
new
TV.
Be
sure
to
turn
the
power
off
and
pull
out
the
power
cord
before
you
begin
any
cleaning.
PAGE
52
Even
though
you
may
be
getting
cable,
the
signal
may
be
weak,
which
means
the
quality
of
your
may
suffer
due
to
other
factors.
If
there
are
problems
with
the
on
your
TV,
consult
the
Troubleshooting
guide
on
the
following
pages.
You
may
also
want
to
contact
your
cable
service
provider
to
determine
if
the
problem
is
from
the
cable
service.
If
you
use
your
TV
to
play
video
games
or
for
other
uses
that
involve
single,
fixed
images,
such
as
a
photo-CD
player,
you
should
avoid
setting
the
Brightness
level
too
high.
If
static
images,
like
network
identification
icons
or
patterns,
are
left
on
the
screen
for
a
long
time
period,
they
may
leave
a
permanent
impression
on
the
TV
screen.
You
can
reduce
the
chance
of
this
happening
by
limiting
the
amount
of
time
you
use
the
fixed-image
display,
and
by
reducing
the
contrast
and
brightness
levels.
VIDEO
GAMES
AND
OTHER
FIXED-PATTERN
DISPLAYS
INTERFERENCE
If
you
unplug
your
TV,
you
may
have
to reset
the
clock
using
the
Time
menu
described
earlier.
PAGE
53
SYMPTOM
Snowy
and
unclear
sound.
Multiple
images
or
'ghost
shadows.'
Interference:
Sharp
lines
across
the
screen
and
unclear
sound.
Normal
but
no
sound.
No
and
unclear
sound.
No
or
sound.
No
color,
but
the
sound
is
okay.
has
a
big
black
box
on
it,
but the
sound
is
okay.
has
two
horizontal
black
bars,
one
on
top
and
one
on
bottom.
Missing
Secret
Lock
Code
Some
quick
and
easy
tips
for
fixing
problems
yourself.
POSSIBLE
SOLUTIONS
?
Check
your
antenna
connection
or
location.
?
Check
your
cable
input.
?
Check
to
see
if
the
TV/VCR
button
on
your
VCR
has
the
TV
selected.
?
Check
your
antenna
direction
and/or
location.
?
Check
your
cable
input.
?
Make
sure
the
cable
from
your
antenna
to
your
TV
is
properly
connected.
The
following
may
cause
problems
or
distortion:
Electrical
appliances,
powerful
lights,
cars,
trucks;
computers
or
portable
phones;
medical
equipment
?
If
possible
increase
the
distance
between
your
TV
and
the
offending
appliance,
or
shut
one
of
them
off.
?
Check
volume
levels.
?
Make
sure
the
TV
is
not
Muted.
?
Try
another
channel.
The
problem
may
be
with
the
broadcast,
not
your
TV.
?
Are
the
Audio
cables
installed
properly?
?
Are
the
wires
for
external
speakers
(if
you
have
external
speakers)
installed
properly?
?
Make
sure
your
speakers
are
turned
on
in
the
Audio
menu.
?
If
your
audio
mode
is
set
to
SAP,
the
program
may
not
have
SAP.
?
Are
you
in
TV
or
cable
tuning
mode,
and
should
be
in
the
other?
?
Make
sure
output
channels
on
all
A/V
equipment
are
on
the
same
channel
(3
or
4).
?
Check
that
all
connections
are
tight.
?
Is
the
AC
power
plugged
in?
?
Check
that
your
AC
power
cord
outlet
works.
(Test
it
by
plugging
in
something
else
or
try
another
power
outlet.)
?
Make
sure
your
brightness
and
audio
controls
are
set
properly.
?
Try
another
channel.
The
problem
may
be
with
the
broadcast.
?
Check
the
color
settings
in
the
Video
menu.
?
Try
another
channel.
The
problem
may
be
with
the
broadcast.
?
The
analog
caption
option
may
be
in
Text
mode.
Select
CC
1,
in
the
analog
cap-
tion
menu.
?
Select
correct
Aspect
Ratio
in
Option
menu
?
If
you
forgot
your
password,
when
the
display
asks
you
to
enter
the
secret
code,
press
'7',
'7',
'7',
'7'
on
the
remote
control.
PAGE
54
SYMPTOM
Remote
control
doesn't
work.
Menu
options
can't
be
changed
or
selected.
No
or
sound
when
any
non-cable
source
is
selected.
Weak
or
no
Stereo
Sound
when
using
a
stereo
VCR.
Time
is
incorrect.
POSSIBLE
SOLUTIONS
?
Make
sure
the
batteries
are
fresh
and
installed
properly.
?
Try
unplugging
your
TV
for
a
few
minutes,
then
plug
it
back
in.
?
Check
to
see
if
the
source
equipment
has
been
turned
on.
?
Make
sure
that
the
connections
are
secure
on
the
back
of
your
TV
and
on
the
source
equipment.
?
Check
to
see
if
all
the
connections
are
secure.
?
Look
in
the
Audio
mode
menu
to
see
if
all
the
settings
are
correct.
?
If
you
are
using
channel
3
or
4
to
view
your
VCR,
stereo
sound
will
not
be
available.
?
Make
sure
the
time
was
set
initially.
Probably
power
was
lost.
?
Reset
clock
manually.
PAGE
55
A
list
of
definitions
for
some
of
the
words
found
in
this
guide.
75
OHM
RF
CABLE
The
round
cable
that
comes
from
an
off-air
antenna
or
cable
service
provider.
Each
end
looks
like
a
hex
shaped
nut
with
a
wire
sticking
through
the
middle,
and
it
screws
onto
the
threaded
jack
on
the
back
of
your
TV.
A/V
CABLES
Audio/Video
cables.
Three
cables
-
Right
audio
(red),
Left
audio
(white),
and
Video
(yellow).
A/V
cables
are
used
for
stereo
playback
of
videocas-
settes
and
for
higher
quality
and
sound
from
other
A/V
devices.
A/V
DEVICE
Any
device
that
produces
video
or
sound
(VCR,
DVD,
cable
box,
or
television).
ADD
This
function
lets
you
add
new
channels
to
the
channel
list
in
memory
that
you'll
scroll
through
when
using
your
remote.
AMPLIFIER
An
external
device
that
amplifies
sound
from
a
television,
CD
player,
VCR,
DVD
or
other
A/V
device.
ANALOG
TV
Traditional
method
of
representing
a
television
signal
as
a
replica
(analog)
of
the
original
and
sound.
ANTENNA
The
physical
receiver
of
television
signals
sent
over
the
air.
A
large
metal
piece
of
equipment
does
not
always
have
to
be
visible
for
your
home
to
be
using
an
antenna.
ASPECT
RATIO
The
ratio
of
the
horizontal
dimension
to
the
vertical
dimension
of
a
pic-
ture.
Standard
television
in
the
U.S.
today
is
generally
transmitted
and
displayed
in
a
4:3
aspect
ratio.
High-Definition
television
will
normally
be
formatted
in
a
wider
aspect
ratio,
assumed
to
be
16:9.
CAPTIONS
A
form
of
subtitling
that
writes
out
the
dialog
for
your
program
on
the
screen.
DELETE
This
function
lets
you
remove
channels
that
you
don't
watch
from
the
channel
list
in
memory.
DIGITAL
TV
(DTV)
A
new
method
of
representing
a
television
signal
as
a
series
of
binary
numbers
(1s
and
0s).
This
method
allows
the
signal
to
be
manipulated
to
eliminate
redundancy
and
dramatically
increase
and
sound
quality.
DOLBY
DIGITAL
Dolby
Digital
Cinema
Sound
is
made
possible
by
a
new
digital
coding
tech-
nique
called
Dolby
AC-3.
Dolby
AC-3
produces
high-quality,
5.1
channel
surround
sound
which
is
six
discrete
separate
channels
for
a
full
range
of
sound.
Each
channel
can
carry
a
different
signal
simultaneously
(front
center,
front
left,
front
right,
surround
left,
surround
right
and
subwoofer).
PAGE
56
A
list
of
definitions
for
some
of
the
words
found
in
this
guide.
FAVORITE
CHANNELS
This
function
created
a
customized
list
of
your
favorite
chan-
nels.
You
can
access
this
group
of
channels
with
the
FAV
but-
ton
on
the
remote
by
pressing
FAV
repeatedly.
INPUT
Refers
to
the
jack
that
receives
a
signal
into
the
TV,
VCR
or
other
A/V
device.
JACK
A
connection
on
the
back
of
a
TV,
VCR,
or
any
other
A/V
device.
This
includes
the
RF
jacks
and
the
Audio/Video
jacks
that
are
color-coded.
MODE
The
mode
determines
the
type
of
device
(TV,
VCR,
Cable,
etc.)
that
the
remote
is
controlling;
remote
operating
mode.
MONO
SOUND
Mono
(monaural)
sound
is
one
channel
of
sound.
On
more
than
one
speaker,
all
the
speakers
play
the
same
audio.
OUTPUT
Refers
to
the
jack
that
sends
a
signal
out
of
a
VCR,
DVD,
or
other
A/V
device.
SECOND
AUDIO
Second
Audio
Programming
(SAP)
is
another,
separate,
audio
channel
available
with
some
programming.
Choosing
SAP
often
refers
to
listening
to
audio
in
another
language,
such
as
Spanish
or
French.
SIGNAL
and
sound
traveling
through
cable,
or
over
the
air,
to
your
television
screen.
SOURCE
The
term
for
the
equipment
that
provides
audio
and
video
information
to
your
TV.
Antenna,
VCR,
DVD
players,
and
Cable
Boxes
are
examples
of
sources.
STEREO
SOUND
Stereo
(stereophonic)
sound
refers
to
audio
that's
divided
into
right
and
left
sides.
TUNER
Any
device
that
picks
up
broadcast
signals
and
turns
them
into
and
sound.
PROGRAMMING/SAP
PAGE
57
Model
32FS4D-UC
Horizontal
Size
(inches)
35.35
Height
(inches)
22.63
Thickness
(inches)
15.88
Weight
(pounds)
113.54
Power
requirement
AC
120V~
60Hz
Television
system
American
TV
Standard,
NTSC-M,
Integrated
ATSC
tuner,
64
&
256
Clear
QAM
Television
Channel
VHF:2-13
UHF:14-69
CATV:
1
-
135
CADTV:
1
-
135
DTV:2-69
Power
consumption
(W)
180W
Antenna
75
ohm
external
terminal
for
VHF/UHF
Audio
Output
(W)
7.5Wx2
Supplied
accessories
Remote
control,
batteries
2
size
AA
(Alkaline
battery)
Screen
Aspect
Ratio
16:9
External
input
ports
Video/Audio
input
(3
set)
Video
output
(1
set)
S-Video
input
(2)
Component
input
(2
set)
HDMI/DVI
input
(1)
Digital
audio
optical
input
(DVI)(1)
Digital
audio
optical
output
(1)
Calibration
port
(1)
Cable/Antenna
port
ⓒ
Copyright
2003,
Zenith
Electronics
Corporation
Design
and
specifications
are
subject
to
change
without
prior
notice.
PAGE
58
