PACKAGE CONTENTS
• VGA to HDMI Adapter with Audio
• Quick Setup Guide
FEATURES
• A simple way to connect your VGA-capable
device to an HDMI display
• Supports resolutions up to 1920 × 1080 at
60 Hz for high-quality video
• Plug-and-play design requires no additional
software for easy setup
• Integrated USB cable sends audio from your
computer to the display
• Mirrors or extends your screen to a second
monitor for better presentations and
multitasking
SYSTEM REQUIREMENTS
Devices (include, but are not limited to):
VGA source devices: Desktops or laptops
HDMI display devices: Projectors, display
monitors, or TVs
Cable: HDMI male-to-male cable
TROUBLESHOOTING
My monitor won't extend or mirror my
computer's display.
• Make sure that all of the cables are connected
securely and correctly.
• Make sure that the cables are not damaged.
• Change the display settings on your
computer.
SPECIFICATIONS
• Dimensions (W × H × D): 1.4 × .5 × 3.1 in.
(35 × 12.5 × 79 mm)
• Weight: 0.13 lbs. (60 g)
• Cable length:
VGA: 4.6 in. (118 mm)
USB 2.0: 5.3 in. (135 mm)
• Converter Type: Signal Converter
• Audio: Yes
• Max resolution: 1920 × 1080
• Wide Screen Supported: Yes
V1 ENGLISH 20-0252
Before using your new product, please read these instructions to prevent any damage.
QUICK SETUP GUIDE
VGA to HDMI™
Adapter with Audio
NS-PCAVH / NS-PCAVH-C
SETTING UP YOUR ADAPTER
1 Plug the adapter into the VGA port on your
source device. Then plug the adapter's USB
cable to your source device's USB port for
audio and power.
2 Plug an HDMI cable (not included) into the
HDMI port on the adapter and into your HDMI
display.
NOTE: Select HDMI input mode when using a TV.
LEGAL NOTICES
FCC Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
ICES-003
This Class B digital apparatus complies with Canadian ICES-003;
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
HDMI Display
HDMI port
(Not included)
HDMI cable
(Not included)
USB port
VGA port
Source device
ONE-YEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 877-467-4289 (U.S. and
Canada) or 01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2020 Best Buy. All rights reserved.
Flat size (W×H): 18.9 × 4.7 in. (480 × 120 mm.)
Final folded size: 3.2 × 4.7 in. (80× 120 mm.)
