User Manual
- Owner's manual - (English)
- Installation instructions - (English)
User manual of Bosch PIM611T16E/02 (20 pages)
Table of contents
- [en] Instructions for installation and use: Page 1
- Ú Table of contents[en] Instructions for installation and use: Page 2
- Installation instructions: Page 3
- Assembly: Page 3
- Important notes: Page 5
- Assembly over drawer (figure 2a): Page 5
- Assembly over oven (figure 2b): Page 5
- Assembly over dishwasher (figure 2c): Page 5
- Installing and connecting the hob - Figure 1/2/ 3/4/5: Page 5
- Connection drawing - Figure 5: Page 5
- 1. Brown: Page 5
- 2. Blue: Page 5
- 3. Yellow and green: Page 5
- Changing the connection current 13 / 16 / 20 Amps - Figure 6: Page 5
- 1. Turn on the hob with the main switch. Do not place any pans on the hotplates: Page 5
- 2. Within the following 60 seconds, adjust all hotplates to the desired power level according to the required connection current (see table).: Page 5
- 3. Turn off all the hotplates in sequence, starting from the lower right and continuing counter-clockwise.: Page 5
- 4. The selected connection current is indicated in the display of the right-hand lateral hotplates.: Page 5
- 5. Turn off the hob with the main switch.: Page 5
- Removing the hob: Page 5
- Instruction manual: Page 6
- Produktinfo: Page 6
- m Safety precautions: Page 6
- Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.: Page 6
- Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will los...: Page 6
- ...
