ProSafe Plus 8-Port Gigabit Switch
with 4-Port PoE GS108PE
Step 2. Connect power Step 3. Check status
Optional
modem
Step 1. Connect equipment
GS108PE
Optional router
Computer Server
Internet
Installation Guide
Off
On
Power LED
Port LEDs
Activity (blinking)
No link (off)
1000 Mbps link
(both LEDs)
10 Mbps link
(right LED)
100 Mbps link
(left LED)
PoE LEDs
PoE in use
No PoE use (off)
PoE not provided
(slow blinking)
PoE halted
(fast blinking)
Less than 7W of PoE
power is available
PoE Max. LED
PoE ports are
working normally (off)
PoE MAX LED was
active in the previous
2 minutes (blinking)
