Fulgor Milano F7IBW24O1L 24 Inch Dual Zone Wine Cellar with User Manual

F7PBW24S1 - R

F7PBW24S1 - L

F7IBW24O1 - R

F7IBW24O1 - L

EN USER MANUAL

FR MODE D’EMPLOI

ES MANUAL DE USUARIO

WINES CELLARS

CAVE À VINS

ENFRIADOR DE

BOTELLAS DE VINO

INDEX

1.1

1.2

1.3

IMPORTANT INSTRUCTIONS FOR SAFETY AND THE ENVIRONMENT

For your safety..................................................................................................................................................

Important information when using the appliance......................................................................................

Respect for the environment..........................................................................................................................

2.1

2.2

INSTALLATION

Installation..........................................................................................................................................................

Connection to the electrical mains...............................................................................................................

3.1

3.2

3.3

3.4

3.5

BEFORE STARTING

Getting to know the appliance.......................................................................................................................

Main components..............................................................................................................................................

Electronic Control.............................................................................................................................................

Main control panel............................................................................................................................................

Secondary control panel..................................................................................................................................

4.1

4.2

4.3

TURNING THE APPLIANCE ON AND OFF

Turning on and off............................................................................................................................................

How to adjust the temperature to suit various needs..............................................................................

Information and malfunction signals on the display................................................................................

5.1

5.2

5.3

SETTINGS AND SPECIAL FUNCTIONS

Customization and Language Settings.........................................................................................................

Special functions activated through the Menu..........................................................................................

Basic settings of the Menu.............................................................................................................................

6.1

6.2

INTERNAL LAYOUT

Internal Layout (positioning, adjustment, removal)...................................................................................

Maximum cabinet depth over “Integrated” refrigerator with single door panel.................................

7.1

LIGHTING

Lighting...............................................................................................................................................................

8.1

USE OF THE FRESH ZONE COMPARTMENT

Use of the fresh zone compartment............................................................................................................

9.1

9.2

9.3

9.4

9.5

CONSERVATION OF WINES

General directions............................................................................................................................................

Conservation temperature..............................................................................................................................

Time of conservation.......................................................................................................................................

Consumption temperature.............................................................................................................................

Position of bottles.............................................................................................................................................

10.1

10.2

10.3

CARE AND CLEANING

Care and Cleaning.............................................................................................................................................

Condenser cleaning.............................................................................................................

.............................

Internal cleaning...............................................................................................................................................

11.1

11.2

TROUBLESHOOTING GUIDE

Troubleshooting guide......................................................................................................................................

Malfunction indications appearing on the display.....................................................................................

12.1

12.2

MENU MAP

Functions............................................................................................................................................................

Settings...............................................................................................................................................................

1.1 For your safety

> If this appliance is replacing an existing appliance

which must be removed or disposed of, make sure

that it does not become a dangerous trap for children

by cutting its power supply cable and rendering it im-

possible to close the door. Use the same caution at

the end of the lifespan of the new appliance.

> This appliance is designed to refrigerate beverages

and foods and is destined for domestic use.

> The appliance must be installed by following the

instructions in the Installation Guide, particular care

should be taken not to obstruct the vent openings of

the appliance and of the built-in units.

> The appliance features a concentrated lighting sys-

tem with LED lamps. Do not stare into these lamps

when they are on to avoid possible eyesight damage.

This warning is also contained on the label attached

to the inside of the refrigerator door.

> When the freezer is functioning do not touch the

inner surfaces in stainless steel with wet or damp

hands, since skin may stick to the very cold surfaces.

> Do not use any type of electrical equipment inside

of the food conservation compartments.

> When positioning the shelves, do not place ﬁngers

in the shelf slide guides.

> Do not position containers of ﬂammable liquids

near the appliance.

> Completely switch o the appliance and unplug the

power supply cable during cleaning operations. If the

plug is not easily reached, it is a good idea to discon-

nect the omnipolar switch that controls the socket

that the appliance is connected to.

> The packaging parts can be dangerous for chil-

dren: do not allow children to play with the plastic

bags, plastic ﬁlm or Styrofoam.

> Any repairs must be performed by a qualiﬁed Ser-

vice technician.

> This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or lack of experience and knowledge unless they

have been given supervision or instruction concern-

ing use of the appliance by a person responsible for

their safety. Children should be supervised to ensure

that they do not play with the appliance.

> Do not damage the appliance refrigerant circuit

pipes.

> Do not store explosive substances such as aerosol

cans with a ﬂammable propellant in this appliance.

> If the power cord of this appliance is damaged, it

must be replaced by the manufacturer, customer

service or a similarly qualiﬁed person. Improper in-

stallations and repairs may put the user at consider-

able risk.

> Repairs may be performed by the manufacturer,

customer service or a similarly qualiﬁed person only.

Symbols used in the Guide:

Notes

Suggestions for proper use

of the appliance

Important

Instruction to prevent damage

to the appliance

Warning

Instructions for preventing personal injury

1.2 Important information when using

the appliance

> Never use electrical appliances inside the appli-

ance (e.g. heater, electric ice maker, etc.). Explosion

hazard!

> Never defrost or clean the appliance with a steam

cleaner! The steam may penetrate electrical parts

and cause a short-circuit. Risk of electric shock!

> Do not use pointed and sharp-edged implements

to remove frost or layers of ice. You could dam-

age the refrigerant tubes. Leaking refrigerant may

cause eye injuries or ignite.

> Do not store products which contain ﬂammable

propellants (e.g. spray cans) or explosive substanc-

es in the appliance.

Explosion hazard!

> Do not stand on or lean heavily against base of

appliance, drawers or doors, etc.

> Before cleaning the appliance, pull out the power

cord plug or switch o the fuse. Do not pull out the

power cord plug by tugging on the power cord.

> Store high-percentage alcohol tightly closed and

standing up.

> Keep plastic parts and the door seal free of oil and

grease. Otherwise, parts and door seal will become

porous.

> Never cover or block the ventilation openings for

the appliance.

1. IMPORTANT INSTRUCTIONS FOR SAFETY AND THE ENVIRONMENT

1.3 Respect for the environment

> Make sure you dispose properly of all packing

materials.

> The appliance must not be disposed of with ur-

ban waste.

Contact local waste disposal authorities for infor-

mation on the disposal of recyclable waste.

> For disposal, cut the power supply cord and

make it impossible to close the door.

> During disposal, avoid damage to the refrigera-

tion circuit.

> Neither the refrigeration circuit nor the insula-

tion contain substances that are hazardous to the

ozone layer

2.1 Installation

Make sure that installation is performed correct-

ly, adhering to all of the instructions in the specif-

ic installation guide provided with the appliance.

2.2 Connection to the electrical mains

The appliance operates at 115 V AC, 60 Hz and is

equipped with a power supply cord with a 3-prong

grounded plug, which must be connected to a cor-

responding 3-prong (15 Amp) grounding-type wall

receptacle.

Important

Do not use extension cords and/or

multiple adapters for connection.

2. INSTALLATION

3.2 Main components

1 Structure in stainless

steel with aluminium

trim

2 Top Cellar and Fresh

Zone control panels

3 Sliding bottle shelfs,

mounted on wheels

for easy extraction

4 Lower Cellar area

control panel

5 Top Cellar

6 Freezer compartment

that can be transformed

into a refrigerator

or Fresh compartment

(Fresh Zone function)

7 Led lighting

Top Cellar

Fresh Zone Lower Cellar

3.1 Getting to know the appliance

Congratulations for having purchased your new

Fulgor: from now on you can use our innovative

conservation system, which will allow you to keep

all of your food in the best way possible.

This manual will answer most of your questions

about the product’s features. Should you require

further information, please

> call us:

> write us an e-mail at

> our website

Important

Before calling, write down the model

type and serial number which are avail-

able on the warranty certificate and on

the rating plate located on the bottom

left-hand corner of the appliance, behind

the bottom drawer.

3. BEFORE STARTING

123 4 5 6 789

3.3 Electronic Control

The innovative electronic control system designed by maintains constant temperature on the three com-

partments and visualizes it on the control panel display. It also allows user interaction making it possible

to personalize settings of the various functions and to receive sound and/or visual messages should any

malfunction occur in the appliance.

3.4 Main control panel

Unit

Allows complete shutdown and start-up of the appliance

(press for three seconds).

Top Cellar Allows switching on and o only the Top Cellar compartment (press for three seconds).

Menu Allows access to the appliance functions menu.

Up/down

Top Cellar

Using the Up and Down buttons, it is possible to change the set temperature of the refrigerator

and scroll through the interactive menu.

Display

Displays the temperature of the Top Cellar and Fresh Zone compartments, the date and time,

Menu functions and visual messages.

Up/Down

(Fresh Zone)

By selecting Up/Down the preset temperature can be changed according to the selected function

mode (freezer, refrigerator, Fresh) and scroll through the interactive menu.

Enter Conﬁrms activation or deactivation of the selections made in the Menu.

Alarm

Blinks to signal user alerts such as door left open, also in combination with a sound signal which

can be deactivated by pressing the button.

Light

Allows illumination of the Top Cellar and Lower Cellar compartments also when the door is

closed. Once activated, the light of the top compartment will automatically shut o after 6 hours.

10 11 12 13

Display Shows the temperature of the Lower Cellar compartment.

Up/Down

Lower cellar

Using the Up and Down keys, it is possible to change the set temperature for the Lower Cellar

compartment.

Lower cellar

Allows switching on and off only the Lower Cellar compartment on or off

(press for three seconds).

Humidity

Allows adjustment of humidity in the Top Cellar and Lower Cellar compartments to three le-

vels: High, Medium, and Low.

3.5 Secondary control panel

4.1 Turning on and o

First start-up

When the appliance is connected to the electrical

power supply but has not yet been turned on, the

display shows the message

This is a safety message to warn that power is

supplied to the appliance, while all of the keys on

the panel are off.

To switch on all the appliance compartments,

press the Unit button

for three seconds.

Turning off the Top Cellar compartment

Once you have turned on all of the compartments

of the appliance, you can turn off only the Top Cel-

lar compartment by pressing the relevant key for

three seconds.

The Fresh Zone compartment is always on and

cannot be turned off except by completely turn-

ing off the appliance.

Turning the Top Cellar compartment on again

Press again for three seconds the relevant key.

Complete shutdown

To shut down the unit completely for cleaning or

maintenance, press the Unit key

for three sec-

onds.

Also take the plug out of the socket and turn off

the omnipolar switch that powers it.

Lengthy shutdown periods

After you have completely shut down the appli-

ance and unplugged it, empty it of all its contents,

clean it and dry it. Leave the doors and the draw-

ers ajar to prevent the formation of unpleasant

odours.

Note

To prevent accidental modiﬁcation of set-

tings, the keypad locks automatically after a

certain period of time and the display shows

the message “keypad locked”. To re-activate

it, simultaneously press the keys Menu and

Up/Down (Down) for three seconds or Menu.

At the ﬁrst start-up, if the message Standby

does not appear, it means that the appliance

has already started the cooling process. If this

is the case, deactivate any possible acoustic

signals by pressing the Alarm key

, close

the door and wait until the set temperature is

reached.

During the ﬁrst start-up, you will not be able

to use the Menu to modify factory settings un-

til the default temperature has been reached.

It is however possible to set the time and date

immediately; these parameters are required

to activate some of the special functions.

If only the Lower Cellar or Top Cellar compart-

ment is turned o, the corresponding fan will

continue to run independently to prevent the

formation of unpleasant odours and mould.

4.2 How to adjust the temperature

for suit various needs

To adjust the temperature in the various com-

partments, use the up/down key for that com-

partment (see chapter 3.5).

If the “keypad locked” message appear, simul-

taneously press the keys Menu and Up/Down

(Down) for 3 seconds or Menu .

Wines compartment

Each model has been carefully tested before

leaving the factory and is adjusted so as to en-

sure high performance and low consumption.

The ideal temperature for wine conservation does

however depend on the types of wine you want to

conserve, the method of conservation (Top Cel-

lar for conservation and consumption, or Lower

Cellar for the conservation and aging of prized

bottles).

It also varies according to personal taste.

Please refer to the guide on wine conservation

included further ahead in this manual.

As needed, you can reset the temperatures as

follows:

> Top Cellar Compartment:

from +4° C to +18° C (from 39° F to 64° F).

The default temperature is +12° C (53° F).

> Lower Cellar compartment:

from +4° C to +18° C (from 39° F to 64° F).

The default temperature is +10° C (50° F).

Fresh Zone compartment

The Fresh Zone compartment is default set to

freezer mode but it can also be set to run as a

refrigerator or cooler compartment.

Instructions for conversion are provided in the

paragraph on special functions and settings.

4. TURNING THE APPLIANCE ON AND OFF

As needed, you can reset the temperatures as

follows:

> Freezer compartment: from -13° C to -23° C

(from 9° F to -11° F), the default temperature,

which is recommended, is -18° (0° F)

> Refrigerator compartment: from +1° C to +7°

C (from 34° F to 46° F), the default temperature,

which is recommended, is +5° C (41° F).

> Fresh compartment: from -2° C to +2° C (from

28° F to 36° F), the default temperature, which is

recommended, is 0° C (32° F).

Warning

If the “keypad locked” message appear, si-

multaneously press the keys Menu

and

Up/Down (Down)

for 3 seconds.

Note

The displayed temperature may vary

slightly with respect to the set tempera-

ture if the doors are continuously opened

or insertion of room temperature food or

large quantities of food.

It takes 6 to 12 hours to reach the select-

ed temperature.

4.3 Information and malfunction

signals on the display

An integrated control system provides informa-

tion through luminous signals or text messages

shown on the display.

The information signal is always displayed with a

fixed text message, while a malfunction signal is

shown with blinking text.

The acoustic signal that accompanies some mal-

function signals can be deactivated by pressing

the Alarm key

on the main control panel.

The list of malfunction signals is located in the

back of this manual.

How to activate:

How to deactivate:

How to program timed activation:

5. SETTINGS AND SPECIAL FUNCTIONS

5.1 Customization and Language

Settings

Note

To prevent an inadvertent change to the

settings the keypad is automatically

locked after a certain period of time.

To re-activate the Menu function, press si-

multaneously the Menu button and the

Down button

for at least three seconds

or just press the Menu

button again for

3 seconds.

The key lock can be disabled through the

specific function in the Settings menu.

It is possible to customized the functions of your

to adapt it to diverse usage needs, resetting the

main parameters (Settings) or activating special

functions (Functions).

Functions are visualized on the main display by

pressing the Menu button .

The Up/Down buttons permit scrolling the avail-

able functions, which can be selected by press-

ing the Enter button

. The display visualizes the

current functioning status.

Using the Up/Down buttons

, it is also possible

to scroll through the selected function, activating

or deactivating by pressing the Enter button

Once the function is confirmed, the display will

automatically visualize the main menu to select

other functions.

At any time it is possible to return to the previous

selection through the Menu button

The language of the messages appearing on the

display can be changed by operating as follows:

Enter the Menu by pressing the Menu button

select Settings via the Up/Down buttons

and

confirm via Enter

Then select the Language function and the de-

sired language.

5.2 Special functions activated through

the Menu

To use special functions, select the Menu key and

use the Up/Down key to access the menu, con-

ﬁrming the selection

Max Cool Fresh Zone

This function must be activated at least 24 hours

before inserting room temperature items into the

freezer, or several hours before placing into the

freezer previously frozen items which have been

subject to a slight temperature rise. This func-

tion is automatically deactivated when the pro-

grammed time period expires.

It is possible o program timed activation of the

function.

After a prolonged interruption of the electrical

power, it is necessary to reactivate the function.

Holiday Fresh Zone

This function (recommended in case of prolonged

absences since it allows considerable energy sav-

ings) brings the Fresh Cellar compartment temper-

ature to - 18°C (46.4°F).

It is possible to program the duration, or it can be

manually deactivated upon re-entry after a period

of absence.

This function remains active even if during the pe-

riod of absence there is a prolonged interruption of

electrical power.

It is possible to program a period from 1 to 90 days.

Beverage Cooler

This function can be activated when it is necessary

to cool o beverages quickly, by placing them inside

the freezer compartment.

It is possible to select a duration of 1 to 45 minutes.

A sound signal will indicated when the optimal tem-

perature has been reached.

After removing the beverages, deactivate the sound

signal by pressing the Alarm button .

Sabbath Mode (Optional)

The function makes it possible to comply to certain

religious observances requiring that the operation

of the appliance is not aected by the opening or

closing of the doors (the thermostatic control, the

inner lighting and the ice maker are deactivated).

How to activate:

How to deactivate:

How to program the duration:

How to activate:

How to deactivate:

How to program the duration:

How to activate:

How to deactivate:

5.3 Basic settings of the Menu

Select the Menu button and used the Up/Down

button

to select .

Fresh Zone Options

The freezer compartment can, if required, be con-

verted to the refrigeration o Fresh operating mode.

How to set the Fridge function:

How to set the Fresh function:

How to revert to the Freezer function:

How to reset default settings:

Default Setting

This oers the possibility to reset default factory

settings and cancels any previous changes.

Attention

If the default settings are restored, it is nec-

essary to reactivate the choice of operation

of the Fresh Zone compartment in case it

was previously set as Fridge or Fresh.

DATE

Set date

The display will visualize the date in the format

dd:mm:yy (day:month:year), the day will blink. Use

the Up/Down buttons

to modify the setting, con-

ﬁrm with Enter

to go on to the next setting; once

the year is conﬁrmed the date will be set.

How to set the date:

Keypad lock

Through this function it is possible to activate/de-

activate the keypad lock.

LANGUAGE

The function allows selection of the language for

the display messages.

Set °C/°F

This function permits visualizing the temperature

in Centigrade or Fahrenheit degrees. Normally, the

appliance is set for visualization in centigrade de-

grees.

How to set the temperature in Centigrade:

How to set the temperature in Fahrenheit:

How to activate:

How to deactivate:

Italian

English

French

German

Spanish

Show Date

Using this function it is possible to deactivate/acti-

vate the date visualization on the display.

How to activate the date:

How to deactivate the date:

TIME

Set time

The display visualizes the hours and minutes in the

format hh:mm and with hh: blinking. Use the Up/

Down buttons

to modify the setting and then con-

ﬁrm by pressing Enter to go on to the next setting.

Once the minutes are conﬁrmed, the time will be

set.

How to set the time:

Set 12/24

This function selects the display at 12 or 24 h.

How to set the display to 12 h:

How to set the display to 24 h:

Show Time

Through this function it is possible to activate/de-

activate the constant visualization of the time.

How to activate the permanent time:

How to deactivate:

6. INTERNAL LAYOUT

6.1 Internal Layout

(positioning, adjustment, removal)

Wine shelf

The shelves can be easily removed for cleaning.

Remove the bottles, completely extract the shelf,

tilt it upward until the wheels are free of their

seat and extract it.

Fresh Zone drawer

Fixed to the slide guides with two locking nuts

> to remove the drawer, unscrew the locking nuts

and remove the drawer.

> to remove the inner Fresh Zone drawer unscrew

the locking nuts.

6.2 Maximum cabinet depth over “In-

tegrated” refrigerator with single door

panel

It is possible that the design of the kitchen and, in

particular, of the niche where the “Integrated” refrig-

erator is going to be ﬁtted includes a cabinet right

above the refrigerator itself that must be closed with

the same panel mounted on the Integrated refrigera-

tor door.”

In this case, the total depth of the cabinet without

the door (above the refrigerator) must not exceed

the total depth of the refrigerator itself. [1]

This will allow the panel attached to the refrigerator

door to open correctly without interference during its

rotation up to 105°.

585 (23”)

650 (25 ⅝”)

47 (1 ⅞”) + front panel thickness

FRI

NIT

7-8. LIGHTING

7.1 Lighting

To provide optimum interior lighting, LED strips

illuminate the refrigerator compartment from the

top and sets of LED lights directly illuminate dif-

ferent areas of the refrigerator compartment, of

the Fresh drawers and the freezer drawer.

In case of malfunction and/or failure of the light-

ing system, you should contact an authorized

Service Agent.

Note

Once activated, the light of the top com-

partment will automatically shut off after

6 hours.

8.1 Use of the Fresh Zone compartment

The Fresh Zone compartment, used in conjunc-

tion with the Top Cellar and Lower Cellar com-

partment, allows great flexibility in the use of the

appliance.

Some possible uses:

Freezer mode

> Liquors, such as vodka, gin, tequila, schnapps,

limoncello and the glasses to serve them

> Rapid cooling of beverages, by activating the

beverage cooler function

> Storage of large amounts of ice.

Refrigerator mode

> As expansion of the Top Cellar or of the Lower

Cellar

> For refrigeration of beer and soft drinks

> For storage of cold dishes and snacks.

Fresh mode

> For conservation of ham, salmon

> Gourmet preparations.

It comes without saying that, the compartment can

be used in a traditional manner. Suggestions and

instructions are provided to oer you best conser-

vation of your food over time in complete safety.

9.1 General directions

As is known, wine can be stored for long periods

of time if this is done under the following condi-

tions:

> Suitable temperature without appreciable vari-

ations over time

> Controlled level of humidity

> Protection from light

> Absence of noise and vibrations

> Absence of odours

> Bottle kept horizontal.

All of these conditions are fully met in the Top

Cellar.

9.2 Conservation temperature

The space offered by the Top Cellar and Lower

Cellar compartments, which can be expanded as

necessary by using the Fresh Zone compartment

as a wine cellar, allows conservation of your best

wines at three different temperatures.

The three compartments are initially set to the

following temperatures:

> Lower Cellar compartment

+12° C (53 ° F) - adjustable from +4° C to +18° C

(from 39° F to 64° F)

> Top Cellar compartment

+10° C (50° F) - adjustable from +4° C to +18° C

(from 39° F to 64° F)

> Fresh Zone drawer

-18° (0° F) - adjustable from -13° C to -23° C

(from 9° F to -11° F) (freezer mode)

To transform the Fresh Zone compartment into

a Top Cellar space, you must access the Menu,

set it as a refrigerator compartment, and adjust it

to a temperature between +4° C and +8° C (from

39.2° F to 46.4° F).

All the temperatures can be modified accord-

ing to the characteristics of the wines and per-

sonal preferences. However, you should attempt

to keep the temperature as constant as possible

over time.

Rapid and large-scale temperature variations

can in fact cause dilation of the liquid and early

aging of the wine.

You should also avoid very low temperatures (be-

low 1° C - 34° F ) which may lead to the formation

of deposits and damage the aesthetic qualities of

the wine.

All the compartments offer optimal conditions

and take into account all these needs. It should

however be noted that the Lower Cellar compart-

ment, in particular, is thermostatically controlled

in a very precise manner and ensures the utmost

care and attention over time of your most prized

bottles. When the Lower Cellar compartment is

set below +10° C (50° F) the Top Cellar must not

be set beyond +12° C (53° F).

Models with Lower Cellar and Top Cellar

Top Cellar

Lower Cellar

Fresh Zone

> Top Cellar compartment

+12° C (53.6° F)

- adjustable from +4° C to +18° C

(from 39° F to 64° F)

> Lower Cellar compartment

+10° C (50° F)

- adjustable from +4° C to +18° C

(from 39° F to 64° F)

> Fresh Zone drawer

-18° (0° F)

- adjustable from -13° C to -23° C

(from 9° F to -11° F)(freezer mode)

9. CONSERVATION OF WINES

9.3 Time of conservation

Improvement of wine over time and its duration usually depends on the character of the variety and its

type. The following chart shows the best period of conservation and aging for various types in ideal con-

servation conditions offered by your appliance.

However, you should always follow the instructions of the winemaker, especially for fine wines.

TYPE OF WINE CONSERVATION TEMPERATURE TIME OF CONSERVATION

New wines (Vin Nouveau) from 12° to 14° C 6 months

Sweet sparkling wines from 8° to 10° C 1 year

Rosé from 10° to 14° C 1 year

Semi-sparkling wines from 10° to 12° C 1 - 2 years

Normal white wines from 10° to 14° C 1 - 2 years

Light red wines from 12° to 14° C 2 years

Dry sparkling wines from 8° to 10° C 2 years

Classic sparkling wines from 8° to 10° C 3 - 4 years

Barrique and Vigorous white wines from 8° to 12° C 3 - 5 years

Normal red wines from 14° to 16° C 3 - 5 years

Barrique and Vigorous red wines from 14° to 18° C 7 - 10 years

Straw wines or Liquorous wines from 16° to 18° C 10 - 15 years

9.4 Consumption temperature

As a general rule, white wines should be served

at a temperature between 10 and 12° C (50 and

53,6°F) and red wines between 12 and 14° C (53,6

and 57,2°F).

Some wines may however be best enjoyed at

higher or lower temperatures.

You should also keep in mind that, during the

summer, wine is generally enjoyed at lower tem-

peratures than during the winter.

You should also consider the following:

White wines

White wines are normally not served at high tem-

peratures, since they are generally more acidic

that red wines and not very tannic. Therefore they

are more enjoyable at low temperatures.

It is preferable to serve these wines between

10° C and 14° C (50°F and 57,2°F). Young, fresh

and aromatic wines can also be served at 10° C

(50°F), while less aromatic ones are served at

12° C (53,6°F).

Temperatures between 12° C and 14° C (53,6°F

and 57,2°F) are for soft, mature white wines that

have been aged for some years in the bottle.

Higher temperatures would favour the exaltation

of the sweet character of the wine, at the expense

of the acidity and flavour, which are considered

pleasant and desirable characteristics of this

type of wine.

Rosé

Rosé wine is served at the same temperature as

white wines. It should be noted that these wines

may include a certain amount of tannin and may

therefore be preferable at higher temperatures.

Therefore, they are served between 10° C and

12° C (50°F and 53,6°F), if young and fresh, and

between 12° C and 14° C (53,6°F and 57,2°F) if

robust and mature.

New wines (Vin Nouveau)

Due to the special processing they undergo, new

vintage wines contain a low tannin content and

are therefore more enjoyable if served between

12° C and 14° C (53,6 and 57,2°F).

Red wines

Since they contain more tannin and are less acid-

ic, red wines are normally served at higher tem-

peratures.

Younger wines with less tannin are normally

served between 14° C and 16° C (57,2 and 60,8°F),

while more full-bodied ones that are more tan-

nic may be served at up to 18° C (64,4°F). Some

wines that have aged for years in the bottle, still

full-bodies and tannic, may be served at 18°C

(64,4°F) or even 20° C (68°F).

Young red wines with little tannin and slightly

structured may be enjoyable at lower tempera-

tures, between 12° C and 14° C (53,6 and 57,2°F).

Sparkling wines

It is difficult to provide instructions to cover the

wide variety of sparkling wines in available.

As a general rule, sweeter and more aromatic

sparkling wines should be served at lower tem-

peratures, down to 8° C (46,4°F), whereas more

tannic sparkling wines may be served at higher

temperatures, up to 14° C (57,2°F).

Dry sparkling wines are usually served between

8° C and 10° C (46,4 and 50°F).

“Classic” sparkling wines are normally served

at these temperatures, which may be as high as

12° C (53,6°F) for sparkling wines that have been

aged for some time.

It is however advisable, especially for finer wines,

to follow the suggestions and recommendations

of the winemaker on the bottle.

Liqueur and straw wines

These types of wines can be served at tempera-

tures between 16° C and 18° C (60,8 and 64,4°F),

depending on personal tastes, to attenuate the

sweet taste of straw wines, it can also be served

at 10° C (50°F).

9.5 Position of bottles

The sliding shelves are made of fine wood and

contoured so as to hold bottles of the most clas-

sical traditional shape or of the most modern

design.

Whether your collection holds fine bouteilles or

petit bouteilles, they will be right at home in the

Top Cellar. A special accessory, available on re-

quest, will let you place them in an inclined posi-

tion, in order to display the labels of your most

prized items.

Also Magnum bouteilles can be stored, provided

you remove the shelf just above the one that will

hold them.

Warning

After a prolonged interruption of electri-

cal power, once the electrical power is re-

activated, an audible signal will indicate if

the temperature has raised above normal

levels. In addition to this the display will

show for one minute the highest temper-

ature detected inside the compartments,

to allow the user to decide how to better

use the food items.

After one minute the display will resume

normal operation, while the Alarm button

will continue to blink.

Press the Alarm button

to display the

highest recorded temperatures.

10. CARE AND CLEANING

10.1 Care and Cleaning

To clean the parts made of steel use a microfib-

er cloth and the sponge provided in the kit with

the appliance. Always use the cloth and sponge

in the direction of the steel’s satin finish.

Every now and then, to polish the steel, wipe

with a slightly damp microfiber cloth.

Do not use the sponge on aluminium parts, such

as the handles and the profiles of the glass

shelves.

You should use special care to keep the ventila-

tion openings in the appliance or in the cabinet

that houses it free of obstructions.

Scrupulously follow the detailed direc-

tions that can be found in the provided kit

and never use abrasive or metallic prod-

ucts which could scratch and damage the

satin finishing on the appliance perma-

nently.

Before performing any sort of cleaning,

disconnect the appliance from the electri-

cal power supply.

Make sure you do not damage the refrig-

erant circuit in any way.

Warning

The use of chlorine-based detergents or

similar that contains it should be avoided

(bleach, hypochlorite, etc).

10.2 Condenser cleaning

A ventilation grille is located either at the top of

the appliance or at the bottom according to the

model type.

To clean it use a vacuum cleaner with a soft

brush attachment at maximum power, sweep-

ing it along the vent slits. In case of a significant

dust build up, the ventilation grille can be re-

moved to allow a more accurate cleaning of the

filter.

Every 6 months the display shows the message

“Check Cond”, clean the condenser and press for

5 seconds the Enter

button to reset.

Operate as follows:

> Switch off the appliance by pressing the Unit

button on the main control panel for approx 3

seconds.

> Wait approx 30 minutes, until the finned con-

denser cools down to room temperature.

> On models with ventilation at the base remove

the grille at the bottom (magnetically attached)

and take it off. On models with ventilation lift the

grille as shown in the picture.

> Thoroughly clean the grille and the foam fil-

ter, by means of a vacuum cleaner and the soft

brush attachment.

> Clean it thoroughly from any dust build up as

shown in the picture, taking care not to damage

it.

> Start up the appliance again, by pressing the

Unit button

on the main

Warning

The edges of the condenser are sharp,

therefore use adequate protection for the

hands and arms when cleaning the con-

denser.

10.3 Internal cleaning

Clean the internal and removable parts by wash-

ing them with a solution of lukewarm water, a

small amount of dishwashing detergent.

Rinse and dry right away.

Do not use mechanical devices or other methods

to speed up defrosting.

Warning

Do not use water on the electrical parts,

lights and control panel.

Warning

The use of chlorine-based detergents or

similar that contains it should be avoided

(bleach, hypochlorite, etc).

11. TROUBLESHOOTING GUIDE

Note

Do not bring cold glass parts into contact

with boiling water.

Do not wash any parts of the refrigerator

in a dishwashing machine since this could

damage or irreparably deform the parts.

11.1 Troubleshooting guide

If you notice malfunctions in your appliance, use

this guide before calling Service. This guide may

help you resolve the problem yourself or could

provide important information to ensure rapid

and effective service.

Malfunction message

A malfunction is usually indicated on the display.

Problems that cannot be resolved by the user are

signalled through a malfunction code.

The appliance does not work

Is the appliance connected to the electrical pow-

er supply?

Does electrical power arrive at the electrical

socket?

Is the Unit key

activated?

Is the condenser clean?

The internal temperatures are

higher than normal

Does the display show a malfunction code?

Is the temperature adjusted correctly?

Is the condenser clean?

Were the doors or drawers open for a long period

of time?

Were large quantities of food recently inserted?

The appliance remains in function for a long

time period

Bear in mind that during a very hot weather and

with very high temperatures in the room it is nor-

mal that the compressor remains in operation for

prolonged periods of time.

Were the doors or drawers open for a long period

of time?

Were large quantities of food recently inserted?

Is the condenser clean?

Check that the doors are closed and that the food

or containers do not obstruct the perfect closure

of the door.

If you hear strange noises

It is normal to hear noise from the fans or com-

pressors during the defrost phase.

Noise could be louder depending on the position

of the appliance and the surrounding environ-

ment.

Condensation forms both inside and out

If the climate is very humid, the formation of con-

densation is normal. Opening the door or draw-

ers for prolonged periods of time can contribute

to the formation of condensation.

In any case, make sure that the doors are always

perfectly closed.

The Refrigerator or Freezer has frost or ice

Did you leave the doors open for a long period of

time?

Do the doors close perfectly?

If the doors do not close perfectly, contact your

installer.

Unpleasant odours inside the refrigerator

Clean the appliance completely as indicated in

this manual.

Hermetically cover all the food. Do not conserve

food for prolonged periods of time.

The doors are difficult to open

The appliance was designed to permit hermetic

closure.

When the door is closed, a vacuum situation can

occur: in this case it is necessary to wait a few

seconds until the pressure balances before open-

ing the door.

11.2 Malfunction indications appearing on the display

Display message Malfunction description

Power Failure

Prolonged interruption of electrical power

The appliance starts up again automatically and indicates

the highest recorded temperatures

Door open

this message appears few minutes from the door opening

Drawer open

this message appears few minutes from the drawer opening

Cellar too warm

Lower Cellar compartment too warm

See the troubleshooting guide

Cellar too cold

Lower Cellar compartment too cold
