i
3-868-202-15(1)
FM Stereo/AM
Radio
Operating Instructions
SRF-39FP
©1999 Sony Corporation Printed in China
For customers who purchased this
product in the USA
Please register this product on line at
http://www.sony.com/productregistration.
Proper registration will enable us to
send you periodic mailings about new
products, services, and other important
announcements. Registering your
product will also allow us to contact you
in the unlikely event that the product
needs adjustment or modification.
Thank you.
WARNING
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority
to operate this equipment.
Before You Begin
Thank you for choosing the Sony radio! It
will give you many hours of reliable
service and listening pleasure.
Before operating the radio, please read
these instructions thoroughly and retain
them for future reference.
Installing the
Battery
(See Fig. A)
1 Open the battery compartment lid
at the rear of the radio.
2 Insert one size AA (R6) battery
(not supplied) with the 3 and #
marks aligned correctly.
3 Close the battery compartment lid.
Battery life (JEITA*)
Using Sony alkaline size AA (LR6) battery:
Approx. 110 hours
Using Sony size AA (R6) battery:
Approx. 40 hours
* Measured by JEITA (Japan Electronics
and Information Technology Industries
Association) standards. The actual
battery life may vary depending on the
circumstance of the unit.
When to replace the battery
Replace the battery when the sound
becomes weak or distorted. Remove the
old battery and insert a new one.
Notes on the battery
• Align the battery correctly.
• The dry battery cannot be charged.
• To avoid damage from possible battery
leakage, remove the battery when unit
will not be used for a long time.
Playing the Radio
1 Connect the supplied earphones to
i (earphones) jack and adjust
them to your head.
2 Set POWER to ON to turn on the
radio.
3 Set BAND to select FM or AM.
4 Turn TUNING to tune in a station.
5 Adjust VOL (volume).
• To turn off the radio, set POWER to OFF.
• To improve reception
FM: Extend the earphones cord which
functions as the FM antenna.
AM:Rotate the unit horizontally for
optimum reception. A ferrite bar
antenna is built in the unit.
• Set FM SENS to LOCAL if interference is
prevalent when radio wave intensity is
dramatically stronger.
To listen to stereo programs, set to DX.
Using the Belt
Holder
To detach the belt
holder
Push Detach
Dial scale
TUNING
BAND
FM/AM
FM SENS
DX/LOCAL
Rear
Size AA (R6) x 1
Insert the # side
of the battery first
VOL
POWER
i
3-868-202-15(1)
FM Stereo/AM
Radio
Operating Instructions
SRF-39FP
©1999 Sony Corporation Printed in China
For customers who purchased this
product in the USA
Please register this product on line at
http://www.sony.com/productregistration.
Proper registration will enable us to
send you periodic mailings about new
products, services, and other important
announcements. Registering your
product will also allow us to contact you
in the unlikely event that the product
needs adjustment or modification.
Thank you.
WARNING
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority
to operate this equipment.
Before You Begin
Thank you for choosing the Sony radio! It
will give you many hours of reliable
service and listening pleasure.
Before operating the radio, please read
these instructions thoroughly and retain
them for future reference.
Installing the
Battery
(See Fig. A)
1 Open the battery compartment lid
at the rear of the radio.
2 Insert one size AA (R6) battery
(not supplied) with the 3 and #
marks aligned correctly.
3 Close the battery compartment lid.
Battery life (JEITA*)
Using Sony alkaline size AA (LR6) battery:
Approx. 110 hours
Using Sony size AA (R6) battery:
Approx. 40 hours
* Measured by JEITA (Japan Electronics
and Information Technology Industries
Association) standards. The actual
battery life may vary depending on the
circumstance of the unit.
When to replace the battery
Replace the battery when the sound
becomes weak or distorted. Remove the
old battery and insert a new one.
Notes on the battery
• Align the battery correctly.
• The dry battery cannot be charged.
• To avoid damage from possible battery
leakage, remove the battery when unit
will not be used for a long time.
Playing the Radio
1 Connect the supplied earphones to
i (earphones) jack and adjust
them to your head.
2 Set POWER to ON to turn on the
radio.
3 Set BAND to select FM or AM.
4 Turn TUNING to tune in a station.
5 Adjust VOL (volume).
• To turn off the radio, set POWER to OFF.
• To improve reception
FM: Extend the earphones cord which
functions as the FM antenna.
AM:Rotate the unit horizontally for
optimum reception. A ferrite bar
antenna is built in the unit.
• Set FM SENS to LOCAL if interference is
prevalent when radio wave intensity is
dramatically stronger.
To listen to stereo programs, set to DX.
Using the Belt
Holder
To detach the belt
holder
Push Detach
Dial scale
TUNING
BAND
FM/AM
FM SENS
DX/LOCAL
Rear
Size AA (R6) x 1
Insert the # side
of the battery first
VOL
POWER
Precautions
• Operate the unit only on 1.5 V DC.
• Do not leave the unit in a location near
heat sources, or in a place subject to
direct sunlight, excessive dust, or
mechanical shock.
• When the case becomes soiled clean it
with a soft cloth dampened with a mild
detergent solution. Never use abrasive
cleansers or chemical solvents, as they
may mar the case.
• In vehicles or in buildings, radio
reception may be difficult or noisy.
Try listening near a window.
Notes on Earphones
Road safety
Do not use earphones while driving,
cycling, or operating any motorized
vehicle. It may create a traffic hazard and is
illegal in many areas. It can also be
potentially dangerous to play your
earphones at high volume while walking,
especially at pedestrian crossings. You
should exercise extreme caution or
discontinue use in potentially hazardous
situations.
Preventing hearing damage
Avoid using earphones at high volume.
Hearing experts advise against continuous,
loud and extended play. If you experience
a ringing in your ears, reduce volume or
discontinue use.
Caring for others
Keep the volume at a moderate level. This
will allow you to hear outside sounds and
to be considerate to people around you.
Warning
If there is lightning when you are using the
unit, take off the earphones immediately.
If you have any questions or problem
concerning your unit, please consult the
nearest Sony dealer.
Specifications
Frequency range
FM: 87.5 – 108 MHz
AM: 530 – 1 710 kHz
Output
i (Earphones) jack (ø 3.5 mm stereo
minijack)
Power output
3.6 mW + 3.6 mW (at 10% harmonic
distortion) with earphones having
impedance of 32 Ω at DC operation
Power requirements
1.5 V DC, one size AA (R6) battery
Dimensions
Approx. 63 × 91.5 × 26 mm
(w/h/d) (2
1
/
2
× 3
5
/
8
× 1
1
/
16
in)
(not incl. belt holder)
Mass
Approx. 82g (2.9 oz) incl. a battery
Accessories supplied
Stereo earphones (1)
Belt holder (1)
Design and specifications are subject to
change without notice.
Precautions
• Operate the unit only on 1.5 V DC.
• Do not leave the unit in a location near
heat sources, or in a place subject to
direct sunlight, excessive dust, or
mechanical shock.
• When the case becomes soiled clean it
with a soft cloth dampened with a mild
detergent solution. Never use abrasive
cleansers or chemical solvents, as they
may mar the case.
• In vehicles or in buildings, radio
reception may be difficult or noisy.
Try listening near a window.
Notes on Earphones
Road safety
Do not use earphones while driving,
cycling, or operating any motorized
vehicle. It may create a traffic hazard and is
illegal in many areas. It can also be
potentially dangerous to play your
earphones at high volume while walking,
especially at pedestrian crossings. You
should exercise extreme caution or
discontinue use in potentially hazardous
situations.
Preventing hearing damage
Avoid using earphones at high volume.
Hearing experts advise against continuous,
loud and extended play. If you experience
a ringing in your ears, reduce volume or
discontinue use.
Caring for others
Keep the volume at a moderate level. This
will allow you to hear outside sounds and
to be considerate to people around you.
Warning
If there is lightning when you are using the
unit, take off the earphones immediately.
If you have any questions or problem
concerning your unit, please consult the
nearest Sony dealer.
Specifications
Frequency range
FM: 87.5 – 108 MHz
AM: 530 – 1 710 kHz
Output
i (Earphones) jack (ø 3.5 mm stereo
minijack)
Power output
3.6 mW + 3.6 mW (at 10% harmonic
distortion) with earphones having
impedance of 32 Ω at DC operation
Power requirements
1.5 V DC, one size AA (R6) battery
Dimensions
Approx. 63 × 91.5 × 26 mm
(w/h/d) (2
1
/
2
× 3
5
/
8
× 1
1
/
16
in)
(not incl. belt holder)
Mass
Approx. 82g (2.9 oz) incl. a battery
Accessories supplied
Stereo earphones (1)
Belt holder (1)
Design and specifications are subject to
change without notice.
