Quick Installation Guide
©2019 TP-Link
7106508440 REV1.1.0
Plug the extender into a power outlet next to your router. Wait until its
Power LED turns solid on.
Power On
1
Set Up
Method 3: Via the WPS Button
1. Press the WPS button on your router.
The WPS button might
look like one of these:
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the
extender’s network TP-Link_Extender. If you are
using a computer, unplug the Ethernet cable if any.
Method 1: Via the Tether App
1. Get the up-to-date Tether app.
2. Connect your smartphone to the extender’s
network TP-Link_Extender.
3. Launch the Tether app, and select your extender.
Create a password to log in.
Range Extender
Blinking Solid On
Note: If the LED does not turn solid on, try again or use Method 1
or 2.
2. Within 2 minutes, press the WPS button on the
extender for 1 second. The LED should change
from blinking to solid on, indicating successful
connection.
2. Launch a web browser, and enter
http://tplinkrepeater.net or http://192.168.0.254
in the address bar. Create a password to log in.
Note: If the login window does not appear, refer to FAQ > Q1.
http://tplinkrepeater.net
Start
Conrm Password
Create Password
Low Middle High
Solid On
Next to
4. Follow app instructions to complete the setup.
The LED should turn solid on, indicating
successful connection to your router.
Note: If the LED does not turn solid on, refer to FAQ > Q2.
Solid On
3. Follow app instructions to complete the setup.
The LED should turn solid on, indicating
successful connection to your router.
Note: If the LED does not turn solid on, refer to FAQ > Q2.
Solid On
Solid On
Connections are available
Wireless Network Connection
Connect automatically Connect
√
TP-Link_Extender
Wi-Fi
Wi-Fi
TP-Link_Extender
CHOOSE A NETWORK...
Other...
< Settings
My Devices
Local Device
REXXX
XX-X X-X X-XX-X X-XX
Need setup videos?
Scan the QR code, or visit
https://www.tp-link.com/support/setup-video/
and search for the setup video of your model.
*Images may dier from actual product.
2
Scan for Tether Tether
or
3. If the extender connects to a dual band router,
repeat steps 1 and 2 above to connect to the
other band.
Extended Network Names:
Router’s network name with
_EXT
at the end
Passwords:
Same as your router
Note:
If you want to change the extended network
names, refer to Manage the Extender on the back
page.
If you cannot find the network names with _EXT in
your Wi-Fi network list, this means that the
extender has been connected to a OneMesh router
and automatically copied its Wi-Fi settings. See
back for more information.
Relocate
3
1. Plug in the extender about halfway between your router and the Wi-Fi dead
zone. The location you choose must be within the range of your router.
2. Wait for about 2 minutes until the LED turns solid green. If it doesn't,
relocate the extender closer to the router to achieve better signal quality.
Enjoy the internet!
Tip: For more intuitive location assistant, access extender settings via the Tether app and go to Tools > Location Assistant.
Router Devices
Halfway
Green: Suitable location
Red: Too far from router
