Operation Guide 5627
E-9
Digital Time and Date
Use the Timekeeping Mode to set and view a digital display of the current time and
date. When setting the digital time, you can also configure settings for summer time
(Daylight Saving Time or DST).
To set the digital time and date
1. In the Timekeeping Mode, hold down
A
until the
seconds start to flash, which indicates the setting
screen.
2. Press
C
to move the flashing in the sequence shown
below to select the other settings.
Seconds DST Minutes
CC
C
Hour
C
Day
Year
C
C
Month
C
E-8
Timekeeping
This watch features separate digital and analog
timekeeping. The procedures for setting the digital time
(page E-9) and analog time (page E-16) are different.
x The Moon phase indicator (page E-42) shows the
current Moon phase in accordance with the current
date as kept in the Timekeeping Mode.
x The fishing level indicator indicates the times when
fish can be expected to be feeding. For more
information, see “Fishing/Moon Mode” (page E-19).
Important!
x Be sure to configure the current time and date, and
your Home Site data (data for the site where you
use the watch) correctly before using the functions
of this watch. See “Home Site Data” (page E-13) for
more information.
Hour : Minutes Seconds
PM indicator
Fishing level indicator
Day of week Month – Day
Moon phase indicator
E-7
CC
CC
Dual Time Mode Hand Setting Mode
Countdown Timer Mode Alarm Mode
E-6
General Guide
x Press
C
to change from mode to mode.
x In any mode (except when a setting screen is on the display), press
B
to
illuminate the face of the watch.
Timekeeping Mode Stopwatch Mode Fishing/Moon Mode
CCC
E-5
To test the alarm ...................................................................................................E-35
To turn Alarms 2 and 3, and the Hourly Time Signal on and off .......................E-36
To select the operation of Alarm 1 ......................................................................E-37
To set the Dual Time .............................................................................................E-38
To illuminate the face of the watch .....................................................................E-40
To specify the illumination duration .................................................................... E-41
To turn the button operation tone on and off ....................................................E-44
E-4
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the digital time and date .............................................................................E-9
To toggle the Timekeeping Mode digital time
between DST and Standard Time ....................................................................E-12
To configure Home Site data ...............................................................................E-14
To toggle between 12-hour and 24-hour timekeeping ......................................E-16
To adjust the analog time .....................................................................................E-17
To view the current fishing level and Moon data ............................................... E-21
To specify a date ...................................................................................................E-23
To measure times with the stopwatch ................................................................E-26
To use the countdown timer ................................................................................ E-28
To set up the countdown timer ............................................................................ E-29
To set an alarm time .............................................................................................E-33
E-3
Contents
General Guide .......................................................................................................... E-6
Timekeeping ............................................................................................................E-8
Fishing/Moon Mode ..............................................................................................E-19
Stopwatch .............................................................................................................. E-25
Countdown Timer .................................................................................................. E-27
Alarms.....................................................................................................................E-31
Dual Time ...............................................................................................................E-38
Illumination ............................................................................................................. E-40
Reference ............................................................................................................... E-42
Specifications ........................................................................................................E-47
Operating Precautions .......................................................................................... E-50
User Maintenance .................................................................................................E-61
E-2
About This Manual
x Button operations are indicated using the letters
shown in the illustration.
x For the sake of simplicity, the sample displays in this
manual do not show the analog hands of the watch.
x Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the “Reference” section.
x To ensure that this watch provides you with the years
of service for which it is designed, be sure to carefully
read and follow the instructions under “Operating
Precautions” and “User Maintenance”.
E-1
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of
your purchase, be sure to read this manual carefully and keep it on hand for later
reference when necessary.
Important!
The fishing level indicator and moon phase indicator produced by this watch are
all based on calculations that use the watch’s current time, date, and Home Site
settings. Because of this, you should make sure that the current date and time, and
your Home Site data are all correct before using the indicators.
x When fishing, always take proper precautions to ensure your own personal
safety and the personal safety of others around you.
x Note that the fishing level indicator and moon phase indicator are all based on
calculated values. They are provided only for reference purposes.
x See the “Timekeeping” section of this manual for information about setting the
current time and date, and about specifying your Home Site.
MA1909-EA
© 2019 CASIO COMPUTER CO., LTD.
