Flip the page over to complete network setup.
Connect the Hardware
Modem
Power adapter
Power adapter
Router
Connect the power adapter
to the router and turn it on.
Note: If the 2.4 GHz LED and 5 GHz LED are off, press and hold the
Wi-Fi On/Off button on the side panel for 2 seconds, then release
the button. Both LEDs will turn solid on.
Check for the following LEDs to confirm
the hardware connection, then refer to the
next section to set up the internet.
Power on the modem,
and then wait about 2
minutes for it to restart.
Unplug your modem, and remove
the backup battery if it has one.
Connect the powered-off
modem to the router’s Internet
port with an Ethernet cable.
* Images may dier from actual products.
Quick Installation Guide
Set up with videos:
Scan the QR code or visit
https://www.tp-link.com/support/setup-video/#wi--routers
to search for the setup video of your product model.
5GHz
On
2.4GHz
On
Power
On
Internet
On
If your internet comes from an Ethernet outlet, connect the router’s Internet port to it, then follow Step 3 and Step 5.
If you want to congure this new router as an access point to extend your network, refer to the Access Point Mode
section on the back page.
