Thank you for choosing a Candy dish
washer. We are confident it will assist you
loyally in washing your daily dishes in full
safety.
Carefully read this manual for correct and
safe appliance use and for helpful tips on
efficient maintenance.
Only use the dish washer
after
carefully reading these instructions. We
recommend you always keep this manual
to hand and in good condition for any
future owner.
Please check that the appliance is
delivered with this instruction manual, the
warranty certificate, the service centre
address and the energy efficiency label.
Each product is identified by a unique 16-
digit code, also called the “serial number”,
printed on the warranty
certificate or on
the serial plate found inside the door, on
the upper right hand side. This code is a
sort of product-specific ID card that you
will need to use to register the product or
if you need to contact the Technical
Assistance Centre.
Fig. A
15
4
32
1. GENERAL SAFETY RULES
2. WATER CONNECTION
3. LOADING THE SALT
4. ADJUSTING THE UPPER BASKET
(ONLY ON SOME MODELS)
5. LOADING DISHES
6. INFORMATION FOR TEST
LABORATORIES
7. LOADING THE DETERGENT
8. TYPES OF DETERGENT
9. LOADING THE RINSE AID
10.
CLEANING THE FILTERS
11.
PRACTICAL HINTS
12.
CLEANING AND MAINTENANCE
13.
DESCRIPTION OF THE CONTROL PANEL
14.
TECHNICAL DATA
15.
PROGRAMME SELECTION AND SPECIAL
FEATURES
16.
REMOTE CONTROL (Wi-Fi)
17.
PROGRAMME LEGEND
18.
WATER SOFTENER UNIT
19.
TROUBLESHOOTING AND WARRANTY
20.
ENVIRONMENTAL CONDITIONS
A.
WIRELESS PARAMETERS (PAG.41)
Contents
!
EN
3
1. GENERAL SAFETY
RULES
!
This appliance is intended to
be used in household and
similar applications such as:
− Staff kitchen areas in
shops, offices and other
working environments;
− Farm houses;
− By clients in hotels, motels
and other residential type
environments;
− Bed and breakfast type
environments.
A different use of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
void the manufacturer’s warranty.
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.
! This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved. Children shall
not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.
! Children should be supervised
to ensure that they do not play
with the appliance.
! Children of aged 3 and under
should be kept away unless
continuously supervised.
! If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard. We
recommend using an original
component, which can be
requested from the Technical
Assistance Centre.
!
Only use the hose-sets
supplied with the appliance for
the water supply connection
(do not reuse old hose-sets).
!
Water pressure must be
between 0.05 MPa and 0.8
MPa.
!
4
!
Make sure carpets or rugs do
not obstruct the base or any of
the ventilation openings.
! After installation, the appliance
must be positioned so that the
plug is accessible.
!
Do not leave the door open in
a horizontal position, in order
to avoid potential dangers (e.g.
tripping).
! For further information on the
product or to consult the technical
data sheet, please refer to the
manufacturer's website.
!
The technical details (supply
voltage and power input) are
indicated on the product rating
plate.
!
Make sure that the electrical
system is earthed and complies
with all applicable laws, and
that the socket is compatible
with the plug of the appliance.
The manufacturer declines all
responsibility for any damage
to people or property due to
non-earthing of the machine.
! Ensure that the dishwasher
does not crush power cables.
! In general it is not advisable to
use adaptors, multiple plugs
and/or extension cables.
! Before cleaning or maintaining
the dishwasher, unplug the
appliance and turn off the
water supply.
! Do not pull on the power cord
or appliance to unplug the
machine.
! Do not leave the appliance
exposed to the elements (rain,
sun, etc.).
! Leaning or sitting on the open
door of the dishwasher could
cause it to tip over.
!
The dishwasher is designed for
normal kitchen utensils. Objects
that have been contamined by
petrol, paint, traces of steel or
iron, corrosive chemicals, acids
or alkalis must not be washed in
the dishwasher.
WARNING:
Knives and other utensils
with sharp points must be
loaded in the basket with
their points down or placed
in a horizontal position.
Electrical connections and
safety instructions
!
EN
5
!
If there is a water softening
device installed in the home
there is no need to add salt to
the water softener fitted in the
dishwasher.
!
If the appliance breaks down or
stops working properly, switch it
off, turn off the water supply and
do not tamper with it. Repair work
should only be carried out by an
approved service agent and only
genuine spare parts should be
fitted. Any failure to follow the
above advice may have serious
consequences for the safety of
the appliance.
! If you need to move the
machine after removing the
packaging, do not try to lift it by
the bottom of the door. Open
the door slightly and lift the
machine by holding it on the top.
By marking this product,
we confirm, under our own
responsibility, full compliance
of this product with all
relevant safety, health and
environmental requirements
under European legislation.
!
Remove all elements of the
packaging.
! Do not install or use the
dishwasher if it is damaged.
!
Follow the instructions supplied
with the product.
Installation
WARNING:
Keep packaging materials
away from children.
!
6
2. WATER CONNECTION
! The inlet and drain hoses can be directed
to left or right.
!
Water pressure must be between 0,08
MPa and 0,8 MPa.
!
The inlet hose must be connected to a tap
so that the water supply can be cut off
when the machine is not in use (fig. 1 B).
! The dishwasher is fitted with 3/4" threaded
connector (fig. 2).
! Connect inlet hose "A" to water tap "B"
with a 3/4" attachment making sure that it
has been properly tightened.
! If it is necessary, the inlet pipe can be
lengthened up to 2,5 m. The extension
pipe is available from the After Sales
Service Centre.
! If the dishwasher is connected to new pipes
or to pipes which have not been inuse for a
long time run water through for a few
minutes before connecting the inlet hose. In
this way no deposits of sand or rust will
clog up the water inflow filter.
1
B
2
B
A
The appliance must be connected to
the water mains using new hose-sets.
The old hose-sets should not be
reused.
The dishwasher can be connected to
either cold or hot water, as long as it
is no hotter than 60°C.
!
EN
7
SOME MODELS may include one or more
of the following features:
! WATERBLOCK (fig. 3)
The waterblock system has been designed
to
improve the safety of your appliance. The
system prevents flooding which might be
caused by a machine malfunction or as a
result of a fracture on the rubber pipes
and in particular on the water supply pipe.
How it works
A sump located on the base of the appliance
collects any possible water leakage and
operates a sensor which activates a valve
placed under the water tap and blocks any
water, even with the tap fully opened.
If box "A" containing the electrical parts is
damaged, remove the plug from the socket
immediately. To ensure perfect operation of
the safety system, the hose with box "A"
should be connected to the tap as shown in
the figure. The water supply hose should
not be cut, as it contains live parts. If the
hose is not long enough for correct
connection, it must be replaced with a longer
one. The hose can be obtained from the
Technical Assistance Centre.
3
A
! AQUASTOP (fig. 4):
A device located on the supply tube that
stops water flow if the tube deteriorates;
in this case, a red mark will appear in the
window "A" and the tube must be
replaced. To unscrew the nut, press the
one-way lock device "B".
B
A
4
!
AQUAPROTECT - SUPPLY TUBE WITH
GUARD
(fig. 5):
Should water leak from the primary internal
tube "A", the transparent containment
sheath "B" will contain water to permit
the washing cycle to complete. At the
end of the cycle, contact the Customer
Service Centre to replace the supply
tube.
B
A
5
Hydraulic safety devices
All the dishwashers are equipped with
an overflow safety device which, if
water exceeds normal levels due to
malfunctions, automatically blocks
water flow and/or drains excess
quantities.
!
8
! The outlet hose should disharge into a
standpipe, making sure that there are no
kinks (fig. 6).
! The standpipe must be at least 40 cm
above floor level and it must have an
internal diameter of at least 4 cm.
! It is advisable to fit an anti-odour air trap
(fig. 6X). If necessary the outlet hose can
be extended up to 2,5 m, provided that it
is kept at a maximum height of 85 cm
above floor level. The extension pipe is
available from the After Sales Service
Centre.
! The hose can be hooked over the side of
the sink, but it must not be immersed in
water, in order to prevent water from
being syphoned back to the machine
when this is in operation (fig. 6Y).
! When installing the appliance under a
worktop the hose pipe clamp must be
attached to the wall in the highest
possible position under the worktop
(fig. 6Z).
! Check that there are no kinks in the inlet
and outlet hoses.
6
Z
Y
X
Connecting the outlet hose
!
EN
9
3. LOADING THE SALT
(Fig. A "1")
! The appearance of white stains on dishes
is generally a warning sign that the salt
container needs filling.
! On the bottom of the machine there is a
container for the salt for regenerating the
softener.
! It is important to use only a salt that is
specifically designed for dishwasher.
Other types of salt contain small
quantities of insoluble particles which
over a long period of time may affect and
deteriorate the softener performance.
! To add salt, unscrew the cap of the
container on the bottom and then refill the
container.
! During this operation a little water will
overflow; but keep adding salt until the
container is full. When the container is
full, clean the thread of salt residue and
retighten the tap.
! After loading the salt, it is recommended
running a complete washing cycle, or
COLD RINSE programme.
! The salt dispenser has a capacity of
between 1.5 and 1.8 kg and, for efficient
use of the appliance, it should be refilled
from time to time .
After loading the salt, YOU MUST run
a complete washing cycle, or the
PRE-WASH/COLD RINSE/REFRESH
programme.
(Only for first start up) When the
appliance is used for the first time,
after completely filling the salt
container, it is necessary to add water
until the container overflows.
!
10
4. ADJUSTING THE UPPER
BASKET (ONLY ON SOME
MODELS)
!
If 29 cm to 32.5 cm plates are regularly
used, load them onto the lower basket
after the upper basket has been placed in
its upper position, as detailed below
(according to the model):
Type "A":
1. Turn front blocks "A" outwards;
2. Remove the basket and remount it in
the upper position;
3. Replace blocks "A" in the original
position.
Dishes that are greater than 20 cm in
diameter can no longer be loaded onto the
upper basket, and the mobile supports
cannot be used when the basket is in the
upper position.
Type "A"
A
A
Type "B":
(ONLY MODELS WITH EASY CLICK):
1. Remove the upper basket;
2. Hold the basket on both sides and lift it
upwards (fig. 1).
Dishes that are greater than 20 cm* in
diameter can no longer be loaded onto the
upper basket, and the mobile supports
cannot be used when the basket is in the
upper position.
* In models fitted with a third basket, dishes
measuring more than 14 cm in diameter
can no longer be loaded onto the upper basket.
ADJUSTING THE BASKET TO THE
LOWER POSITION:
1. Hold the basket on both sides and lift it
gently upwards (fig. 1);
2. Then slowly release into the correct
position (fig. 2).
N.B.: NEVER LIFT OR LOWER THE
BASKET FROM ONE SIDE ONLY (fig. 3).
WARNING:
We recommend adjusting the basket before
loading the dishes.
Type "B"
1
3
a
b
a
b
2
!
EN
11
5. LOADING DISHES
! The upper basket is provided with mobile
racks hooked to the sides of the basket,
which can be regulated into 4 positions.
! In the lowered position (A-A1) the racks
may be used for such items as: tea and
coffee cups, kitchen knives and ladles.
Also glasses with stems may be safely
hung on the ends of the racks.
!
In the upright position (B-B1) the racks
allow you to load dinner plates and soup
plates up to a maximum diameter of 19
cm. Plates should be loaded vertically
with the underside of the plate towards
the back of the dishwasher with a space
between each plate to allow water to pass
freely.
!
It is advisable to load large plates slightly
tilted towards the front to facilitate the
introduction of the basket into the machine.
!
The upper basket has been designed to
offer maximum flexibility in use and can be
loaded with glasses, cups, small plates and
small-sized bowls.
A standard daily load is represented in figs. 1
and 2.
Upper basket
(fig. 1)
Upper basket
(fig. 2)
! Saucepans, oven dishes, tureens, salad
bowls, lids, serving dishes, dinner plates
and soup plates can be loaded into the
lower basket.
! Place the cutlery in the plastic cutlery
holder with the handles pointing upwards
and place the cutlery holder on the lower
basket (fig. 6) making sure that the
cutlery does not get in the way of the
rotating arms.
Using the upper basket
Using the lower basket
!
12
! The lower basket is fitted with a special
adjustable central rack (fig. 3 and 4). This
permits stable and optimum loading, even
when the size and/or shape of the dishes
is non-standard.
- POSITION "A": for a standard load, or
one that excludes pans, salad bowls and
the like.
- POSITION "B": for dishes which, although
standard size, have a particular shape
(very deep bowls, square dishes or ones
without borders etc.).
- POSITION "C": for larger than average
flat plates and/or ones with non-standard
shapes (square, hexagonal, oval, pizza
dishes etc.).
3
A
B
4
A
C
! Smaller plates (used for dessert plates for
example), can also be placed into the
lower basket as shown in the figure 5,
with the support flap placed outwards
("E"). For normal or large plates the flap
must be in the position ("D").
Upper basket (fig. 5)
5
E
D
A standard daily load is represented in
fig.6.
Lower basket (fig. 6)
6
Please load the dishwasher sensibly to
ensure the best wash results.
WARNING:
If the small plates are placed in the basket
with the support flap in the incorrect
position, the plates will interfere with the
lower spraying arm preventing it to rotate.
!
EN
13
Cutlery basket
(fig. 7)
The cutlery basket is made with two
detachable parts which will enable various
loading options. The two parts can be
detached by sliding the left section away
from the right section. The top of cutlery
basket can be removed, for enable various
loading options.
7
! The third basket has been designed to
load items such as utensils of small
dimensions or flat and long shaped items.
By freeing the lower baskets from these
objects, loading big-size items becomes
more comfortable and easier, making it
possible for instance to load plates and
pots in the lower basket.
!
The third basket can be loaded with the
following items: coffee cups and side
plates, fruit or dessert cups, small bowls,
saucers, kitchen knives and forks, ladles and
large spoons, graters, and accessories for
small appliances (e.g. food mixer blades).
! In order to obtain optimum washing
results, it is advisable to load items with
their underside towards the ceiling of the
dishwasher (e.g. small plates and bowls).
! The third basket can be easily extracted
from the dishwasher, by removing the
front stops at the beginning of basket
tracks.
! The third basket has been designed to
offer maximum flexibility in use. Due to its
partition in three tilted sections and
absence of fixed racks, it can be loaded
in numerous ways: only coffee cups and
side plates; or coffee cups mixed with
bowls and utensils; or again with side
plates, graters, and spoons.
A standard daily load is represented in fig. 8.
Third basket (fig. 8)
8
The lower basket has a safety-stop
device, for its safe extraction, also
especially useful with a full load. For
loading salt, cleaning filter and for
ordinary maintenance, the complete
extraction of the basket is necessary.
Using the third basket
WARNING:
The third basket is NOT
designed
for
loading cutlery. The absence of racks for
fixing cutlery could involve such items
being found in the lower baskets.
!
14
Lower basket with ZOOM accessories that
allow you to stack dishes of different sizes
and shapes firmly on the left hand side of
the basket. The accessories allow you to
take full advantage of the benefits of the
ZOOM programme.
9
6. INFORMATION FOR
TEST LABORATORIES
Please ask information required for
comparison testing and measuring noise
levels, according to EN normative, to the
following address:
testinfo-[email protected]
In the request, please specify model name
and number of the dishwasher (see rating
plate).
ZOOM ACCESSORIES (SOME
MODELS ONLY)
The soft rubber mounts may be
removed.
!
EN
15
7. LOADING THE
DETERGENT
(Fig. A "2")
Unsuitable detergents (like those for
washing up by hand) do not contain the
proper ingredients for use in a dishwasher,
and stop the dishwasher from working
correctly.
The detergent container is inside the door
(fig. A "2"). If the lid of the container is
closed, press the button (A) to open. At the
end of every wash cycle the lid is always
open and ready for the next time the
dishwasher is used.
The amount of detergent to be used varies
according to how dirty the dishes are and
on the type of dishes to be washed. We
advise using 20:30 g of detergent in the
wash section of detergent compartment (B).
After pouring the detergent into the
container, close the lid, firstly pushing (1)
and then pressing on it (2) until you hear
the click.
Since not all detergents are the same the
instructions on the boxes of detergent can
vary. We should just like to remind users
that too little detergent does not clean the
dishes properly whilst too much detergent
will not produce better results and is also a
waste.
The detergent
It is essential to use a detergent that is
specifically designed for dishwashers
either in powder, liquid,gel or tablet form.
Filling the detergent container
WARNING
When loading the lower basket, please
ensure that the plates or others do not
obstruct the detergent dispenser.
Do not use an excessive amount of
detergent and help limit damage to the
environment at the same time.
!
16
8. TYPES OF DETERGENT
Detergent tablets of different manufacturers
dissolve at different speeds, for this reason,
during short programmes, some detergent
tablets may be not fully effective, because
they are not completely dissolved. If these
products are used, is recommended to
choose longer programmes to guarantee
the complete use of the detergent.
The concentrated detergents, with reduced
alkalinity and with natural enzymes, in
conjunction with 50°C wash programmes,
have a smaller impact on the environment
and they protect the dishes and the
dishwasher. The 50°C wash programmes
purposely exploit the dirt-dissolving
properties of the enzymes, allowing
therefore, with the use of the concentrated
detergents, to achieve the same results of
the 65°C programmes but at a lower
temperature.
The detergents that also contain the rinse
aid must be placed in the wash section of
the detergent container. The rinse aid
container must be empty (if it is not empty,
set the rinse aid regulator to lowest position
before using combined detergents).
If you are planning to use "TABS" (“3 in
1 “/ “4 in 1”/ “5 in 1”, etc.) combined
detergents i.e. those with built in salt and/or
rinse agent, we would advise the following:
!
read carefully and follow the manufacturer’s
instructions given on the packaging;
! the effectiveness of detergents containing
the built in water softener/salt depends on
the hardness of your water supply. Check
that the hardness of your water supply is
within the effective range given on the
detergent packaging.
If when using this type of product, you
don't get satisfactory washing results,
please contact the detergent manufacturer.
In certain circumstances use of combined
detergents can cause:
! limescale deposits on dishes or in the
dishwasher;
! a reduction in washing and drying
performance.
Please note that using the "TABS"
combined detergents, the rinse aid and
salt indicator lights (only used on
selected models) are superfluous, so
you must ignore the lights.
If washing and/or drying problems occur,
we recommend you return to use traditional
separate products (salt, detergent and rinse
agent). This will ensure that the water
softener in the dishwasher operates
correctly.
In this case, we recommends that you:
! refill both the salt and rinse aid container;
! run one normal washing cycle without a
load.
Please note that on return to the use of
conventional salt, a number of cycles will be
required before the system becomes fully
efficient again.
Detergent tablets
To get satisfactory washing results,
the tablets MUST be placed in the
wash section of the detergent
container and NOT directly in the tub.
Concentrated detergents
Combined detergents
"TABS" combined detergents
Any problems which arise as a direct
result of the use of these products are not
covered by our warranty.
!
EN
17
9.
LOADING THE RINSE AID
(Fig. A "3")
The rinse aid, which is automatically
released during the last rinsing cycle, helps
the dishes to dry quickly and prevents spots
and stains forming.
The rinse aid container can be found to the
left of the detergent container (fig. A "3").
To open the lid, push the reference mark
and, in the same time, pull the tab of
opening. It is always advisable to use rinse
aid that is specifically designed for
dishwasher. Check the rinse aid level
through the indicator eye (C) which is
located on the dispenser.
FULL
EMPTY
dark
light
The regulator (D) is placed under the lid
and can be turned using a coin. The
recommended position is 4.
The limestone content of the water
considerably affects the formation of
limescale and the drying performance.
It is therefore important to regulate the
quantity of rinse aid to achieve good
washing results.
If, after the wash, streaks occur on the
dishes, decrease the amount by one
position. If whitish spots occur, increase the
amount by one position.
The rinse aid
Filling the rinse aid container.
Regulating the rinse aid from
1 to 6
!
18
10. CLEANING THE FILTERS
(Fig. A "4")
The filter system consists of:
A. A central container that traps the larger
particles;
B. A micro filter, located beneath the
gauze, that traps the tiniest particles
ensuring a perfect rinse;
C. A flat gauze that continuously filters the
wash water.
! To achieve excellent results every time,
the filters should be checked and cleaned
after each wash.
! To remove the filter unit, simply turn the
handle anticlockwise (fig. 1).
! For ease of cleaning, the central
container is removable (fig. 2).
! Remove the gauze filter (fig.3) and wash
the whole unit under a jet of water. If
necessary a small brush can be used.
! With the Self-cleaning Micro filter,
maintenance is reduced and the filter unit
need only be checked every two weeks.
Nevertheless, after each wash it is advisable
to check that the central container and the
gauze filter are not clogged.
WARNING
After cleaning the filters, make
sure that
they are correctly reassembled and
that the gauze filter is properly
positioned at the bottom of the
dishwasher. Make sure that the filter
is screwed back, clockwise, into the
gauze, as poor seating of the filter unit
could have an adverse effect on the
efficiency of the appliance.
Never use the dishwasher without the
filters.
!
EN
19
11. PRACTICAL HINTS
! Before placing the dishes in the
dishwasher, remove any remaining food
(bones, shells, pieces of meat or
vegetables, coffee grounds, skin of fruit,
cigarette ash, thoothpicks etc. to avoid
blocking the filters, water outlet and
washing arm nozzles.
! Try not to rinse the dishes before loading
them into the dishwasher.
! If saucepans and oven dishes are
encrusted with the remains of burnt or
roast food, it is advisable to leave them to
soak before washing.
! Place the dishes face downwards.
! Try to place the dishes in such a way that
they are not touching one another. If they
are loaded properly you will get better
results.
! After loading the dishes check that the
washing arms can rotate freely.
! Pans and other dishes that have
particularly stubborn food particles or
remnants of burnt food should be left to
soak in water with dishwasher detergent.
! To wash silver properly:
a) rinse the silver immediately after use,
especially if it has been used for
mayonnaise, eggs, fish etc.;
b) do not sprinkle detergent onto it;
c) keep it separate from other metals.
! If you want the dishwasher to give a
complete wash, place the dishes in the
dishwasher at the end of each meal and if
necessary turn on the COLD RINSE cycle
to soften the food remains and remove
bigger particles of food from the new load
of dishes. When the dishwasher is full
start the complete wash cycle
programme.
! If the dishes are not very dirty or if the
baskets are not very full select an
ECONOMY programme, following the
instructions in the program list.
! It should be remembered that not all
dishes are suitable for washing in a
dishwasher. We advise against using the
dishwasher to wash items in
thermoplastic, cutlery with wooden or
plastic handles, saucepans with wooden
handles, items in aluminum, crystal
leaded glass unless otherwise stated.
! Certain decorations may fade. It is
therefore a good idea before loading the
whole batch to wash just one of the items
first so as to be sure that others like it will
not fade.
! It is a good idea not to put silver cutlery
with non-stainless steel handles into the
dishwasher as there could be a chemical
reaction between them.
! In order to avoid any dripping from the top
rack, remove the lower rack first.
! If the dishes are to be left in the machine
for some time, leave the door ajar, to let
some air circulate and to improve the
drying performance.
How to get really good wash
results.
How to make savings.
What not to wash.
When buying new crockery or cutlery
always make sure that they are
suitable for washing in a dishwasher.
Useful hints
!
20
12. CLEANING AND
MAINTENANCE
(Fig. A “5”)
! To clean the dishwasher outside, do not
use solvents (degreasing action) neither
abrasives, but only a cloth soaked with
water.
! The dishwasher does not require special
maintenance, because the tank is self-
cleaning.
! Regularly wipe the door gasket with a
damp cloth to remove any food remains
or rinse aid.
! Dishwasher cleaning is recommended, in
order to remove limestone deposits or
dirt. We suggest you run a washing cycle
periodically with specialist dishwasher
cleaning products. For all cleaning
operations the dishwasher must be
empty.
! If, in spite of the routine cleaning of the
filters, you notice that the dishes or pans
are not properly washed or rinsed, check
that all the spray heads on the rotor arms
(fig. A “5”) are clear.
If they are blocked, clean them in the
following way:
1) to remove the upper rotor arm, turn it
until it lines up with the stop marked by
the arrow (fig. 1b). Push it upwards
(fig. 1) and, keeping it pushed in,
unscrew it in a clockwise direction (to
reassemble it repeat the same
operation, but turn it anticlockwise).
The lower rotor arm can be removed
simply by pulling it upwards (fig. 2);
2) wash the rotor arms under a jet of water
to clear any blockage in the spray
heads.
3) when you have finished, refit the rotor
arms in the same position,
remembering to re-align the arrow and
screw into position.
! Both the door lining and the tank lining
are in stainless steel; however, should
spots caused by oxidation occur, this is
probably due to a high level of iron salts
presents in the water.
! The spots can be removed with a mild
abrasive agent; never use chlorine based
materials, steel wool, etc.
1
1b
2
After every wash it is essential to turn off
water supply and to switch off the machine
by pressing the On/Off button to the off
position.
Do not use tools that can deform the
spray heads.
WHEN CYCLE IS FINISHED.
!
EN
21
If the machine is not going to be used for
some time, it is advisable to follow these
rules:
1. do an empty wash with detergent in
order to clean the machine of any
deposits;
2. pull out the electric plug;
3. turn off the water tap;
4. fill the rinse aid container;
5. Ieave the door ajar;
6. keep the inside of the machine clean;
7. If the machine is left in places where the
temperature is below 0°C any water left
inside the pipes may freeze. Wait until
the temperature rises above zero and
then wait for about 24 hours before.
!
22
13. DESCRIPTION OF THE
CONTROL PANEL
G F+H CHILD LOCK
H "SMART DOOR" option button
I "START/RESET" button (start/cancel programme)
L DISPLAY
A ON/OFF Button
B "REMOTE CONTROL (Wi Fi)" button
C "HALF LOAD" option button
D "PROGRAMME SELECTION" button
E "START DELAY" button
F "TABS" option button
14. TECHNICAL DATA
SIZE
BUILT-IN
FULL-INTEGRATED
59,8x81,8 ÷ 89,8x55
117
TECHNICAL DATA (See rating plate)
16
9 people
Min. 0,08 – Max. 0,8
See rating plate
HALF-INTEGRATED
59,8x81,8 ÷ 89,8x57
117
15
9 people
FREE-STANDING
WITHOUT
WORKTOP
59,8x82x58
117
13
8 people
WITH
WORKTOP
60x85x60.9
120
Place settings (EN 50242)
Capacity with pans and dishes
Water supply pressure (MPa)
Fuse / Power input / Supply voltage
DATA
Width x Height x Depth (cm)
Depth with door open (cm)
!
EN
23
15.
PROGRAMME SELECTION
AND SPECIAL FEATURES
The display keeps you constantly informed
on the operation of the appliance.
1) TEMPERATURE DISPLAY
Indicates the washing temperature of
each programme selected.
2) PROGRAMME DISPLAY
Indicates set wash programmes,
provides information on set options,
reports any faults and so on.
3) TIME REMAINING DISPLAY
Indicates the wash time for each
selected programme and provides the
time remaining to the end of the
programme.
4) WATER SUPPLY CLOSED INDICATOR
LIGHT
Indicates any fault in the inflow of water
between the tap and the dishwasher
(see "TROUBLESHOOTING AND
WARRANTY").
5) "SALT EMPTY" INDICATOR LIGHT
6)
"RINSE AID EMPTY" INDICATOR LIGHT
7)
Wi-Fi CONNECTION INDICATOR LIGHT
8) "HALF LOAD" OPTION INDICATOR
LIGHT
9) PROGRAMME INDICATOR LIGHTS
10) "ZOOM" PROGRAMME INDICATOR
LIGHT
When the "ZOOM" e programme is
enabled, the corresponding indicator
light comes on.
11) "TABS" OPTION INDICATOR
LIGHT
12) "SMART DOOR" OPTION
INDICATOR LIGHT
13) "ADDISH" indicator light
! To turn the appliance on and off, press
the "ON/OFF" button (for at least 3
seconds).
! Connect the machine to the power
supply.
! Open the door, put the dishes to be
washed inside, and close the door again.
! Press the "ON/OFF" button and hold for
about 3 seconds.
DISPLAY Description
WARNING
Touching the display in the first few
seconds after you have plugged in
the appliance could interrupt its self-
calibration procedure, thus jeopardising
the appliance's proper functioning. In
this case, take out the plug and repeat
the operation.
ON/OFF button
At the end of the cycle, remember to
switch off the appliance using the
ON/OFF button, then remove the plug
and close the water supply
.
First time you switch on the
appliance and language
!
24
! In this phase only the "HALF LOAD"
"TABS" and "START/RESET" buttons
will remain active. The message "BRAVA"
will appear on the display and all the
indicator lights will turn on for 3 secs.
! The message "ENGLISH" will appear on
the display.
! Pressing the "HALF LOAD" and "TABS"
buttons you can select the preferred
language.
! To accept the language selection press
the "START/RESET" button Immediately
afterwards the "WELCOME" message
will scroll on the display once and the
indicator lights will all be off.
! The message of the "ECO 2:50" or
"ECO 3:25" programme (with SMART
DOOR option activated)
The dishwasher is regulated with certain
factory settings. Nevertheless, from the
Settings menu, you can adjust various
parameters to suit your washing
requirements.
Accessing the Settings Menu
! Turn on the dishwasher by holding the
"ON/OFF" button down for about 3 secs.
! Hold down the "Progr." and "ON/OFF"
buttons for about 5 secs.
! The message "SETTINGS" will appear
on the display and the indicator lights of
the "SMART DOOR" and "TABS" buttons
will be on.
! Pressing the "Progr.", You can select the
parameters to be adjusted in succession
(LANGUAGE → SOFTENER →
BUZZER → MEMO FUNCTION).
! Parameter adjustment is performed by
pressing the "SMART DOOR" (-) and
"TABS" (+) buttons.
! To adjust the SOFTENER see the specific
Chapter of the manual.
! To adjust the BUZZER see the specific
paragraph.
! To adjust the MEMO FUNCTION see the
specific paragraph.
Press the START/RESET button; the "ECO"
programme will appear on the display.
! Press the the TABS and HALF LOAD
buttons together for 5 seconds.
! "ENGLISH" appears on the display.
! Follow the steps detailed in the
"LANGUAGE SETTING" paragraph.
WARNING
In the event that the machine remains
switched on without selecting or
starting any program, after 5 mins. the
dishwasher will switch off automatically.
Settings Menu
The dishwasher must ALWAYS be off
before you start this procedure.
Next time you switch on the
appliance
If memo mode is enabled, the last used
programme will appear on the display.
Changing language
WARNING
This procedure will cancel all stored
settings, and the appliance will be
reset to the default factory settings.
!
EN
25
!
Open the door and place dirty dishes
inside the appliance.
! Either "ECO" programme will appear on
the display, or the programme that was
previously stored.
! The duration of the programme will be
displayed to the left of the square, while
the programme temperature will be
displayed to the right.
!
Select the desired programme by pressing
the "PROGR." button several times.
! Icons will light up on the display upon
enabling certain programmes.
! To select an option, press the
corresponding button (the indicator light
will turn on).
! Press the "START/RESET" button.
When the door is shut, after an audible signal
has sounded, the programme will start
automatically. The display will show the
time remaining to the end of the wash cycle.
Models with Smart Loading Sensor (Only
on some models).
The "AUTO DAILY WASH" programme,
thanks to an algorithm that analyses the
degree of dirtiness of the dishes in real
time,
automatically sets the ideal temperature
and
washing time, optimising water and electricity
consumption
Models with dirt sensor
(Only on some models).
The dishwasher is equipped with a dirt
sensor, capable of analysing water murkiness
during all "AUTOMATIC" programme phases
(see programme legend).
Thanks to this device, the wash cycle
parameters are automatically adapted to
the real quantity of dirt on dishes.
This is because water murkiness is linked to
the quantity of dirt on dishes.
Thus, excellent washing results are
guaranteed while optimising water and
energy consumption.
The "IMPULSE" programmes use an
impulse washing technology, which reduces
consumption and noise, and improves
performance.
When the programme starts, you should
only open the door and add more dishes
when the "ADDISH" indicator light is
switched on.
The appliance will stop automatically and
the time remaining to the end of the cycle
will flash on the display.
Close the door, without pressing any
buttons.
Programme settings
After switching on the dishwasher,
wait a few seconds for the programme
to start running.
"AUTOMATIC" programmes
"IMPULSE" programmes
The “intermittent” working of the
washing pump is NOT to be
considered a malfunction; it is a
characteristic of impulse washing,
and therefore should be considered a
normal feature of the programme.
"ADDISH" (possibility of adding
dishes after the programme has
started)
!
26
The cycle will start from where it left off.
When the relating indicator light switches
off, it is no longer advisable to add further
dishes.
Proceed as follows to change or cancel a
running programme:
! Hold the "RESET" button down for at least
3 seconds. "START/RESET" will appear
on the display and audible signals will
sound.
! The running programme will be cancelled.
! At this point a new programme can be set
using the "PROGR." button.
If there is any break in the power supply
while the dishwasher is operating, a
special memory stores the selected
programme and, when the power is
restored, it continues from where it left off.
While a programme is running, the display
shows the name of the programme chosen,
the relating temperature and the time
remaining to the end of the cycle, which is
automatically updated.
A 5 second buzzer will sound (if not muted)
3 times at 30 second intervals to signal that
the programme has ended.
The "PERFECT RAPID ZONE" is identified
by the left side of the tub, in which two extra
washing arms will be activated during Rapid
programs (ZOOM 39ʼ and Rapid 24') and
programs (UNIVERSAL, SANITISING,
UNIVERSAL PLUS and ECO PLUS) to
provide an extra washing force, more water,
in that zone.
Open the door slowly and carefully, to
avoid getting wet with splashes of
washing water
.
Adding dishes after the ADDISH
indicator light has switched off is
strongly discouraged as this could
affect the wash performance.
WARNING
If you open the door during the drying
cycle, an intermittent audio signal
advises you that the drying cycle has
not yet finished.
Changing a running programme
WARNING
Before starting a new programme, you
should check that there is still detergent
in the dispenser. If necessary, top up the
detergent.
Programme operations
(only for free-standing models)
Programme end
Only for models with the "SMART
DOOR" option, during the drying
phase the door will open automatically
and you will have to wait until for the
end-of-cycle signal before removing
the dishes.
"PERFECT RAPID ZONE"
(only on some models)
!
EN
27
The option buttons provide you with further
wash options, allowing you to customise the
wash programmes (see the table in chapter
17 for a list of programmes on which each
option can be enabled).
Options are enabled (or disabled) before
starting the programme, using the appropriate
buttons.
The relevant indicator lights will appear (or
disappear) on the display.
The option button should be enabled after
you have chosen the wash programme.
"SMART DOOR" button
(AUTOMATIC DOOR OPENING) (only on
some models)
This option enables a special device that
opens the door by a few centimetres during
or at the end of the drying cycle (depending
on the programme).
This ensures the natural and efficient drying
of dishes. The duration of the selected cycle
will automatically change to obtain the
optimal temperature for the rinse cycle; this
significantly reduces energy consumption.
The automatic door opening during the last
drying phase enables the air to circulate,
removing the risk of bad odours.
When the door opens, the message
"SMART DOOR" will appear on the
display.
"HALF LOAD" button
If you need to wash just a few dishes (e.g.
glasses, cups, plates), you can enabled the
"HALF LOAD" option.
In this way, you can save water, energy and
time. With the "HALF LOAD" option, use
less detergent than for a full load.
"TABS" button
This option optimises the use of "TABS"
("3 in 1"/"4 in 1"/"5 in 1", ecc.) combined
detergents. By pressing this button, the
selected washing programme is modified to
get best performance from combined
detergents (furthermore, the salt and rinse
aid shortage lights are de-activated).
When the indicator light comes on, fill the
salt container.
Option buttons
If an option is selected that is not
compatible with the selected programme
then the option indicator light first flashes
and then goes off.
This option is automatically enabled
in the "ECO" programme. In any case,
it is possible to disable it. The
"SMART DOOR" eature is not
available in the "RAPID 24’", "ZOOM
39’" and "PREWASH" programmes.
WARNING
With this option selected, you must not in
any way prevent the door from opening or
force it shut, as this would damage the
mechanism. Ensure that there is free space
in front of the door and, before closing, wait
for the opening device to complete its activity.
WARNING
Once selected, this option keeps being
on (light on) also for next washing
cycles and it can be de-activate (light
off) only by pressing the button once
again.
This option is recommended when
using the RAPID 24' program, the
duration of which will be extended for
about 15 minutes, allowing the
detergent tablets to achieve a better
performance.
"SALT EMPTY" indicator light
!
28
When the indicator light comes on, the rinse
aid is running out and needs to be topped
up.
Dishwasher start time can be set with this
button, delaying start from 00:30 to 23:30
hours. Proceed as follows to set a delayed
start:
! Press the START DELAY button ("0:00"
will appear on the display).
! Press the button again to increase the
delay (on each press the delay is
increased by 30 mins., up to a
mBRAVAmum of 23:30).
! To start the countdown, press the
"START/RESET" button. The display will
show the time remaining to the end of the
programme. At the end of the countdown,
the programme will start automatically.
Proceed as follows to cancel a delayed
start:
! Hold the "START/RESET" button down
for at least 3 seconds. "00" will appear on
the display "RESET" and audible signals
will sound.
! The delayed start and the selected
programme will be cancelled. The "ECO"
programme or the programme previously
stored in memory will appear on the
display.
! At this point, to set off the dishwasher, a
new programme and any option buttons
must be selected, as indicated in the
"PROGRAMME SETTINGS" paragraph.
The product is set in the factory with the
audio signal enabled.
The audio signal may be muted as follows:
1. Hold the "Progr." button down and, at
the same time, switch on the
dishwasher using the "ON/OFF" button.
2. "SETTING" appears on the display.
3.
Press the Progr. button until "BUZZER"
appears on the display.
4. Then press either the button "HALF
LOAD" or "TABS" to change the value
from Yes to No
.
5. Switch off the dishwasher by pressing
the "ON/OFF" button to confirm the
new setting
.
To turn the alarm on again, follow the same
procedure.
1. Hold the "Progr." button down and, at
the same time, switch on the
dishwasher using the "ON/OFF" button.
2. “SETTING” appears on the display.
3. Press the Progr. button until “MEMO
FUNCTION” appears on the display.
"RINSE AID EMPTY" indicator
light
"START DELAY" button
If you do not want a delayed start,
press the "START DELAY" button
repeatedly until 0:00 appears on the
display (the appliance will start
immediately).
(Only for free-standing models)
The length of the selected cycle will
be shown on the display. At the end of
the countdown, the programme will
automatically start and the length of
the selected cycle will be shown on
the display.
Muted END-OF-PROGRAMME signal
The dishwasher must ALWAYS be off
before you start this procedure.
MEMO FUNCTION (Memorising
the last programme used)
!
EN
29
4. Then press either the "HALF LOAD" or
"TABS" button to change the programme.
5. Switch off the dishwasher by pressing
the "ON/OFF" button to confirm the new
setting.
To change the stored programme, follow
the same procedure.
Enabling
1.Turn on the appliance using the
ON/OFF button.
2.Press the Progr. and "START DELAY"
buttons together for 5 seconds.
3. "DEMO MODE ACTIVATED" will
appear on the display.
4.If no button is pressed for 30 seconds,
the programme will start, simulating the
start of a wash programme.
Disabling "Demo mode"
1. Turn on the appliance using the ON/OFF
button
.
2. Press the Progr. and "START DELAY"
buttons together for 5 seconds
3. "DEMO MODE DISABLED" will appear
on the display.
4. Switch off the appliance.
! Close the door.
! Start the appliance.
! Pressing the "TABS" and "SMART
DOOR" buttons at the same time for
about 3 seconds allows you to lock all
keys. In this way, you can prevent any
unwanted or accidental changes.
! The key lock can be cancelled by simply
pressing the "TABS" and "SMART
DOOR" buttons again or by switching off
the appliance.
Should power go out when the
dishwasher is running, a special
memory feature saves the settings and,
when power returns, the appliance
resumes the cycle from where it left off.
Enabling or disabling DEMO
MODE (be used exclusively in
stores)
The dishwasher must ALWAYS be off
before you start this procedure.
The PROGR./OPTIONS/START DELAY
options are enabled, and by pressing
these buttons you can simulate the
product's functioning without starting
a wash.
WARNING
Once installed, if the appliance works
correctly but the wash cycle does not
start upon pressing the Start button,
"Demo mode" may not have been
disabled.
The dishwasher must ALWAYS be off
before you start this procedure.
CHILD LOCK
!
30
16.
REMOTE CONTROL (WI-FI)
This appliance is equipped with Wi-Fi
technology that allows the machine to be
remote controlled via an app.
! Download the Candy simply-Fi app onto
your device.
! Make sure the router is turned on and
your smartphone/tablet is connected to
your home Wi Fi network.
! Turn on BLUETOOTH on your
smartphone/tablet (if available).
! Open the app, create a user profile and
enroll the appliance, following the
instructions appearing on the device’s
display.
! Turn on the dishwasher by pressing the
ON/OFF button for 3 seconds when
instructed to do so in the app.
! Press "Progr. 3sec WiFi" for 3 secs "
the message "ENROLLMENT" will scroll
on the display and the "Wi-Fi" indicator
light will be off.
!
Within 60 secs. keep the "TABS"
button
pressed for 3 secs., and the message
"EASY" will appear on the display for
5 mins, the Wi-Fi indicator light will start
to flash slowly 3 times and then turn off
for 2 seconds.
! Enter the password of your home WiFi
network in the App and complete the
procedure.
Successful enrollment
! The message "CONNECTED" will appear
on the display once, after which the message
"REMOTE CONTROL" will appear and
the "Wi-Fi" indicator light will be steady on.
! You can now check the machine from the
App.
Unsuccessful enrollment
If enrolment fails (or does not succeed
within 5 mins.):
! "TRY AGAIN" will appear on the display.
! The machine will not be connected.
! Repeat the enrolment procedure from the
App.
For more information, refer to the
“Enrollment App - Quick Guide" that
comes with your machine, also accessible
at
the link: go.candy-group.com/bm-dw
Repeat the enrolment procedure, removing
the product from the APP, in the event of
problems or a change in your home router
password.
Whenever you want to use the machine
with remote control:
! Fill the dishwasher, add detergent, and
close the door.
! Turn on the dishwasher.
! Press "WiFi" " The message "REMOTE
CONTROL" will appear on the display.
! You can now check the machine from the
App.
Pairing the machine with the app
The Candy simply-Fi app is available
both for Android and for iOS tablets
and smartphones.
To discover all the details of the Wi-Fi
features, explore the app menus in
DEMO mode.
Reset WiFi
ENABLING REMOTE CONTROL
!
EN
31
! To exit remote control, press "Progr. 3sec
WiFi".
! When no cycle is under way:
The Wi-Fi indicator light will start to flash
slowly and the message "REMOTE
CONTROL OFF" will appear on the
display. The display will then show the
last programme completed by the
machine (or the "ECO" programme).
! When a cycle is under way:
The Wi-Fi indicator light will start to flash
slowly and the message "REMOTE
CONTROL OFF" will appear on the
display. The display will then show the
remaining time.
The cycle will be completed without
control from the App.
Alternative way to exit remote control.
! Press the "Start/Reset" button for 3 secs
If there is a cycle under way, it will be
cancelled, and the machine will exit
REMOTE CONTROL mode.
The "Wi-Fi" indicator light will flash
slowly. It is now possible to set a new
wash cycle from the control panel.
! Press the "ON/OFF" button for 3 secs
(or power off)
If there is a cycle under way, it will be
paused and the machine will exit
REMOTE CONTROL mode.
On switching on again, the "Wi-Fi"
indicator light will flash slowly and any
cycle under way will continue from the
point of interruption.
! Indicates the connection status of the
product to the home Wi-Fi network. It can
be:
- FIXED ON: remote control enabled.
- SLOW FLASHING: remote control
disabled.
- QUICK FLASHING FOR 3 SECONDS,
THEN OFF: the machine cannot
connect to the home Wi-Fi network or
has not yet been enrolled on the App.
- SLOWLY FLASHING 3 TIMES, THEN
OFF FOR 2 SECONDS: enrolment
procedure on the App in progress.
- ON FOR 1 SECOND, THEN OFF FOR
3 SECONDS: the door is open. Remote
control cannot be enabled. .
DISABLING REMOTE CONTROL
Opening the door, any REMOTE
CONTROL will be disabled. To resume
control from the App, close the door.
"Wi-Fi" indicator light
!
32
17. PROGRAMME LEGEND
Programme
Description
P1
ECO
Programme for normally soiled tableware (the
most efficient in terms of its combined energy and
water consumption for that type of tableware).
Programme standardised to EN 50242.
P2
INTENSIVE
Once a day - for heavily soiled pans and any
other items that have been left all day for
washing.
P3
UNIVERSAL
Once a day - for normal soiled pans and any
other items that have been left all day for
washing.
P4
ZOOM 39’
Programme suitable for washing in a single
cycle the most delicate dishes such as
glassware and porcelain in Washing Class A.
P5
RAPID 24’
Quick wash for dishes which are to be washed
immediately after the meal. Wash load of 6
persons.
P6
PREWASH
Short cold pre-wash for items that are stored in
the dishwasher until you are ready to wash a full
load.
P7
SANITISING
An antibacterial cycle, intended for washing and
sterilising dishes (even heavily stained ones)
babies’ bottles etc.
P8
INTENSIVE RAPID
Intended for rapid washing of very dirty dishes.
P9
UNIVERSAL PLUS
Intended for everyday dishwashing. Two final
rinses ensure a high level of hygiene and
cleanliness.
P10
AUTO DAILY WASH
Fast cycle, for “normally” dirty dishes – intended
for frequent washes and normal loads. This
programme is optimised thanks to a smart
sensor that adapts washing parameters to actual
dish load.
P11
ECO PLUS
A medium temperature programme, intended for
washing pans and dishes that are “normally”
dirty, using detergents which contain enzymes.
P12
DELICATE
Suitable for delicate crockery and glassware.
Also for less soiled items excluding pans.
Programmes with prewash
For wash programmes with prewash, it is advisable to add a second dose of detergent (max. 10 g)
directly in the machine.
!
EN
33
Options
Programme
Detergent for soaking
(Prewash)
"IMPULSE" programmes
"PERFECT RAPID ZONE"
active
Washing temperature (°C)
Average washing time¹ (min.)
"SMART DOOR"
Button
"HALF LOAD"
Button
"TABS" Button
P1
ECO
●
■
-
45
205
YES
YES
YES
P2
INTENSIVE
●
■
-
75
130
YES
YES
YES
P3
UNIVERSAL
-
■
60
120
YES
YES
YES
P4
ZOOM 39’
-
-
60
39
N/A
N/A
YES
P5
RAPID 24’
-
-
50
24
N/A
N/A
YES
P6
PREWASH
-
-
-
-
5
N/A
N/A
P7
SANITISING
●
-
75
140
YES
N/A
YES
P8
INTENSIVE RAPID
●
■
-
65
85
YES
YES
YES
P9
UNIVERSAL PLUS
-
-
70
125
YES
N/A
YES
P10
AUTO DAILY
WASH
-
■
-
55
-
65
75
-
95
YES
YES
YES
P11
ECO PLUS
-
-
55
190
YES
N/A
YES
P12
DELICATE
-
■
-
45
85
YES
YES
YES
!
34
● = Detergent for soaking (Prewash)
■ = "IMPULSE" programmes
= "PERFECT RAPID ZONE" active
N/A= OPTION NOT AVAILABLE
1) With cold water (15°C) – Tollerance ±10%!
With hot water the time remaining until the end of the programme is automatically displayed while
the programme is running.!
*Values are measured in a laboratory according to European Standard EN 50242 (consumption
may vary according to conditions of usage).!
!
EN
35
18.
WATER SOFTENER UNIT
Depending on the source of the supply,
water contains varying amounts of
limestone and minerals which are deposited
on the dishes leaving whitish stains and
marks. The higher the level of these
minerals present in the water, the harder
the water is. The dishwasher is fitted with a
water softener unit which, through the use
of special regenerating salt, supplies
softened water for washing the dishes. The
degree of hardness of your water can be
obtained from your water supply company.
The water softener can treat water with a
hardness level of up to 90 °fH (French grading)
or 50 °dH (German grading) through 8 settings.
The settings are listed in the table below,
with the relative mains water to be treated.
Level
Water hardness
Use of
Regenerating salt
Water softener
setting
°fH
(Franch)
°dH
(German)
0
0-5
0-3
NO
S0
1
6-10
4-6
YES
S1
2
11-20
7-11
YES
S2
3
21-30
12-16
YES
S3
4*
31-40
17-22
YES
S4
5
41-50
23-27
YES
S5
6
51-60
28-33
YES
S6
7
61-90
34-50
YES
S7
* The softener unit is set in the factory at
level 4 (S4) as this satisfies the requirements
of the majority of users.
Regulate the setting of your water softener
unit according to the degree of hardness of
your water, as follows:
1. Turn on the dishwasher by pressing the
"ON/OFF" button for about 3 secs.
2. Hold the "Progr." and "ON/OFF"
buttons down for about 5 secs.
3. The message "SETTINGS" will appear
on the display and the indicator lights of
the "SMART DOOR/EXPRESS" and
"TABS" buttons will be on.
4.
Press the "Progr." button until you select
“SOFTENER S4" (S4 factory level).
5. Parameter adjustment is performed by
pressing the "SMART DOOR/EXPRESS"
(S7 →" S0) and "TABS" (S0 →" S7
)
buttons to increase or decrease the
previously set level.
6. Switch off the dishwasher by pressing
the "ON/OFF" for 3 secs. button to
confirm the new setting.
To change the water softener setting again,
follow the same procedure.
Regulating the water softener
The dishwasher must ALWAYS be off
before start of this procedure.
WARNING
If you cannot complete the
procedure,
turn the dishwasher off by pressing
the
"ON/OFF" button and start the
procedure again from the beginning
(STEP 1).
!
36
19. TROUBLESHOOTING AND WARRANTY
If you believe the dishwasher is not working correctly, consult the quick guide provided
below with some practical tips on how to fix the most common problems. If the
malfunction continues or recurs, contact the Technical Assistance Centre.
Error displayed
Meaning and solutions
"CHECK WATER"
with a short audio signal
(only on some models).
E2 (with display) with a
short audio signal
The dishwasher does not fill with water
Make sure the water supply is open.
Make sure the water supply hose is not bent or crushed.
Make sure the drain pipe is at the proper height (see installation
section).
Close the water supply, unscrew the drain pipe from the back of the
dishwasher and check that the "sand" filter is not clogged.
E3 (with display) with a
short audio signal
The dishwasher does not drain water
Make sure the drain pipe isn’t bent, trapped or blocked, and the filter
is not clogged.
Make sure the siphon is not clogged.
E4 (with display) with a
short audio signal
Water leak
Make sure the drain pipe isn’t bent, trapped or blocked, and the filter
is not clogged.
Make sure the siphon is not clogged.
E8-Ei (with display)
with a short audio signal
The water heating element is not working correctly or the filter
plate is clogged
Clean the filter plate.
Any other code
(with display)
Turn off and unplug the dishwasher, wait a minute. Turn on the
machine and restart a program. If the error occurs again contact an
Authorised Customer Service Centre directly.
BUG REPORTS
! Models with a display: errors are reported by a number preceded by the letter "E"
(e.g. Error 2 = E2) and a short audio signal.
! Models without a display: an error is shown by a sequence of flashes of every
LED. The error code is shown by the number of flashes followed by a pause of 5
seconds (example: two flashes – pause 5 seconds – two flashes – repeating = Error 2).
Only models with a display
!
EN
37
If malfunctions or faults occur when a programme is running, the indicator light that
corresponds to the selected cycle will blink rapidly, and an intermittent audio signal will
sound. In this case, turn the dishwasher off by pressing the "ON/OFF" button.
After checking to make sure the water supply is open, that the drain pipe is not bent
and that the siphon or filters are not clogged, set the selected program again.
If the fault persists, contact the Technical Assistance Centre.
FAULTS
CAUSE
SOLUTION
1. No programme
works
Plug not connected to wall socket
Connect electric plug
O/I button not pressed
Press button
Door is open
Close door
No electricity
Check
2. Dishwasher
does not fill
with water
See point 1
Check
The water tap is closed
Open the water tap
The water supply hose is bent
Eliminate the bends in the hose
The filter of the water supply
hose is clogged
Clean the filter at the end of the
hose
3. Dishwasher
does not
discharge water
Filter is dirty
Clean filter
Drain pipe is bent
Eliminate the bends in the pipe
The drain pipe extension is not
correctly connected
Follow the instructions for connecting
the drain pipe carefully
The outlet connection on the
wall is pointing downwards not
upwards
Call a qualified technician
4. Dishwasher
discharges
water
continuously
Position of the drain pipe is too
low
Lift drain pipe to at least 40 cm
above floor level
Only models without a display
This dishwasher is equipped with an overflow safety device that, in the event of a
problem, automatically discharges any excess water.
WARNING
To ensure the correct operation of the overflow safety
device, we recommend not moving or tilting the dishwasher
during operation. Should it be necessary to tilt or move the
dishwasher, please ensure that the washing cycle is
complete and that no water remains inside the appliance.
Other faults
!
38
FAULTS
CAUSE
SOLUTION
5. Spray arms are
not heard to
rotate
Excessive amount of detergent
Reduce amount of detergent Use
suitable detergent
Item prevents arms from rotating
Check
Filtering plate and filter very dirty
Clean filtering plate and filter
6. On electronic
appliances
without a
display: one or
more indicator
lights flashing
quickly
Water supply tap turned off
Switch off the appliance. Turn on
the tap. Re-set the cycle.
7. Dishes only
partially washed
See point 5
Check
Bottom of saucepans have not
been washed well
Burnt on food remains must be
soaked before putting pans in
dishwasher
Edge of saucepans have not
been washed well
Reposition saucepans
Spray arms are partially blocked
Remove spray arms by unscrewing
ring nuts clockwise and wash under
running water
The dishes have not been
loaded properly
Do not place the dishes too close
together
The end of the drain pipe is
immersed in water
The end of the drain pipe must not
come into contact with the outflow
water
An incorrect amount of
detergent has been measured
out, or the detergent is old and
hard
Increase the measure according to
how dirty the dishes are, or change
detergent
The cap of the salt container is
not closed properly
Choose a more vigorous
programme
The wash programme is not
thorough enough
Tighten it properly
8. Detergent not
dispensed or
partially
dispensed
Cutlery, dishes, pans, etc., stop
the detergent dispenser from
opening
Position dishes so as not to
obstruct the dispenser
9. Presence of
white spots on
dishes
Mains water is too hard
Check salt and rinse aid level and
regulate. Should the fault persist,
contact the Technical Assistance
Centre
10. Noise during
wash
The dishes knock against one
another
Re-check loading of dishes in the
basket
The revolving arms knock
against the dishes
Re-check loading of dishes in the
basket
11. The dishes
are not
completely dry
Inadequate air flow
Leave the dishwasher door ajar at
the end of the wash program to
allow the dishes to dry naturally
Rinse aid missing
Fill the rinse aid dispenser
!
EN
39
N.B.: Should any of the above situations result in a bad wash performance or insufficient
rinsing, remove dirt deposits from the dishes by hand since the final drying cycle hardens
the dirt, making it difficult to remove with a subsequent wash.
If the malfunction continues, contact the Technical Assistance Centre, quoting the model of
the dishwasher. This is found on the plate on the upper section of the inside of the
dishwasher door, or on the warranty. This information will make it possible to take quicker,
more effective action.
It is always recommended to use original spare parts, that are available at our Authorised
Customer Service Centres.
The manufacturer declines all responsibility for any printing errors in this booklet.
Moreover, the manufacturer reserves the right to make any changes deemed useful to its
products without changing their essential characteristics.
Assistance and Warranty
The product is guaranteed under the law, and under the terms and conditions
stated on the warranty certificate included with the product. The certificate
should be stored and shown to an authorized Technical Assistance Centre in
case of need, together with the proof of purchase. You can also check the
warranty conditions on our website.
For assistance, please fill in the online form or contact us at the number
indicated on the support page of our website.
!
40
20. ENVIRONMENTAL CONDITIONS
This appliance is marked a
cording to the European directive
2012/19/EUon Waste Electrical
and Electronic Equipment
(WEEE).
WEEE contains both polluting substances
(which can cause negative consequences
for the environment) and basic components
(which can be re-used).
It is important to have WEEE subjected to
specific treatments, in order to remove
and dispose properly all pollutants,
and recover and recycle all materials.
Individuals can play an important role in
ensuring that WEEE does not become an
environmental issue; it is
!
WEEE should not be treated as
household waste;
!
WEEE should be handed over to the
relevant collection points managed by
the municipality or by registered
companies. In many countries, for large
WEEE, home collection could be
present.
In many countries, when you buy a new
appliance, the old one may be returned to
the retailer who has to collect it free of
charge on a one-to-one basis, as long as
the equipment is of equivalent type and
has the same functions as the supplied
equipment.
!
41
A. WIRELESS PARAMETERS
Wi-Fi
Specifications (Wi-Fi)
Specifications
(Bluetooth)
NFC
Wi-Fi (One Fi/Smart Fi)
A
802.11 b/g/n
Bluetooth v4.2
ISO/IEC 14443 Type A
and NFC Forum Type 4
802.11 b/g/n
B
2,412 GHz. - 2,484 GHz.
2,412 GHz. - 2,484 GHz.
13,553-13,567 MHz (centre
frequency 13,560 MHz)
2,412 GHz. - 2,484 GHz.
C
802.11b, DSSS 1 Mbps =
+19.5 dBm
802.11b, CCK 11 Mbps =
+18.5 dBm
802.11g, OFDM 54 Mbps =
+18.5 dBm
802.11n, MCS7 =
+14 dBm
Basic data Rate:
RF Transmit Power (Typ):
+4 dBm
Enhanced data Rate:
RF Transmit Power (Typ):
+2 dBm
BLE
RF Transmit Power (Typ):
+7.5 dBm
▬
802.11b (11Mbps) +18,5
± 2 dBm
802.11g (54Mbps) +16
± 2 dBm
802.11n (HT20, MCS7) +14
± 2 dBm
D
802.11b = 1024 bytes,
-80 dBm
802.11g = 1024 bytes,
-70 dBm
802.11n = 1024 bytes,
-65 dBm
802.11n HT40 = 1024 bytes,
-65 dBm
Basic data Rate:
Sensivity @ 0.1% BER: -98
dBm
Enhanced data Rate:
Sensivity @ 0.01% BER: -98
dBm
BLE
Sensivity @ 0.1% BER: -98
dBm
▬
802.11b (11Mbps)
-93 dBm
802.11g (54Mbps)
-85 dBm
802.11n (HT20, MCS7)
-82 dBm
E
▬
▬
< 42dBµA/m (at 10 m)
▬
EN
WIRELESS PARAMETERS:
A Wireless Standard - B Frequency range - C Max Transmit Power - D Minimum Receiving Sensitivity -
E Magnetic field limit
With this the Candy Hoover Group Srl, declares that this appliance marked with complies with
the essential requirements of the Directive 2014/53/EU. To receive a copy of the declaration of conformity,
please contact the manufacturer at: www.candy-group.com
hldsk
hldsk
- CDPN S -
19.11 - 41049624.A - IDM s.r.l.
