User Manual LG LSU120HXV2 Air Condition

Documents for LG Electronics LSU120HXV2

The following documents are available:
User Manual

User Manual - (English) Read Online | Download pdf

Other Documents

Submittal Sheet - (English) Download
Engineering Manual - (English) Download
Owner's Manual - (English) Download
Warranty - (English) Download

Specification

Spec Sheet (web) - (English) Read Online

Photos

Photos: View Photos

User Manual

For LSU120HXV2. Also, The document are for others LG Electronics models: LS090HEV2, LS120HEV2, LS180HEV2, LS090HXV2, LS120HXV2

Single Zone Mega: LS090HEV2, LS120HEV2, LS180HEV2, LS240HEV2

Single Zone Mega 115V: LS090HXV2, LS120HXV2

SINGLE ZONE MEGA AND MEGA 115V

WALL MOUNTED

INSTALLATION MANUAL

Loading ...

File type: PDF

File name: 55798446_lsu120hxv2.pdf

File size: 13.37 MB

File Language: English

Pages: 72

Author: LG Electronics

File created: 2020-04-17

Published: 2021-11-14

Updated: 2023-05-16

Verified by Shany D'Amore on 2023-05-16

Download File

Specifications

Brand: LG Electronics

Model: LSU120HXV2

Category: Air Conditioners

Width: 28 1/4 Inch

Depth: 9 1/16 Inch

Height: 19 1/2 Inch

Net Weight: 58.4 Lbs.

Shipping Weight: 60 Lbs.

Heating Capacity: 12,000 BTU

Liquid Line Outer Diameter: 1/4 Inch

Suction Line Outer Diameter: 3/8 Inch

Piping Length: 24.6 Ft.

Min. Line Length Total: 9.8 Ft.

Max. Line Length Total: 49.2 Ft.

Max. Height Diff. btwn. Indoor and Outdoor Units: 23 Ft.

Operation: Cooling with Heat Pump

Compressor Noise Level Cooling: 50 dB

Compressor Noise Level Heating: 50 dB

Drain Line Outer Diameter: 27/32 Inch

Drain Line Inner Diameter: 5/8 Inch

Outside Temperature Range for Cooling Min.: 14 °F

Outside Temperature Range for Cooling Max.: 118 °F

Outside Temperature Range for Heating Min.: 14 °F

Outside Temperature Range for Heating Max.: 65 °F

Sleep Mode: Yes

Parts Warranty: 5 Year

Min No. of Connectible Indoor Units: 1

Max No. of Connectible Indoor Units: 1

Power Source V / Hz / Ø: 115/60/1

Power Input Cooling Rated: 1,142 Watts

Power Input Heating Rated: 1,000 Watts

Rated Amps: 11.4 Amps

Power and Communication Cable No.: 4

Power and Communication Cable AWG: 14

Refrigerant Charge: 1.88 Ft.

Voltage: 115 Volts

Refrigerant Control: EEV
