140424
2 Zone
Expander Panel
Installer Guide
140424-100-05
Warning
Read all of the instructions before proceeding
Can cause electrical shock or equipment damage. Always turn off power to the heating/air
conditioning system prior to installing or adjusting the Zone Panel Expander. Complete the
wiring for the main panel and expansion panel before applying transformer power.
This panel is designed for professional installation, and is to be installed and configured as
described in this manual. Any other use is not recommended and will void the warranty.
Install disconnect and overload protection on circuits as required by code authorities having
jurisdiction for the installation.
Voltage Hazard
Caution
For Use with Braeburn
Model 140404
Store this manual for future reference.
PREMIER
SERIES
