2021.10
v1.0
User Manual
©
2021 DJI OSMO All Rights Reserved.
2
Searching for Keywords
Search for keywords such as “battery” and “install” to find a topic. If you are using Adobe Acrobat
Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to begin a search.
Navigating to a Topic
View a complete list of topics in the table of contents. Click on a topic to navigate to that section.
Printing this Document
This document supports high resolution printing.
Not nal
3
©
2021 DJI OSMO All Rights Reserved.
Using this Manual
Legend
Important Hints and Tips
Read Before First Use
Read the following documents before using DJI Action
TM
2:
1. User Manual
2. Safety Guidelines
3. Quick Start Guide
It is recommended to watch all tutorial videos on the ocial DJI website (www.dji.com/action-2) or in
the DJI Mimo app and read the safety guidelines before using for the rst time. Make sure to review the
quick start guide before using for the rst time and refer to this user manual for more information.
Downloading the DJI Mimo App
Scan the QR code or search for "DJI Mimo" on the App Store.
The iOS version of DJI Mimo is compatible with iOS v12.0 and later. The Android version of DJI
Mimo is compatible with Android v8.0 and later.
Watching the Tutorial Videos
Watch tutorial videos and other videos on the ocial DJI website (https://www.dji.com/
action-2/video) or scan the QR code before using for the rst time.
©
2021 DJI OSMO All Rights Reserved.
4
Contents
Using this Manual
3
Legend 3
Read Before First Use 3
Downloading the DJI Mimo App 3
Watching the Tutorial Videos 3
Product Prole
5
Introduction 5
DJI Action 2 Camera Unit 5
Accessories 6
Preparing
9
Activation 9
Charging DJI Action 2 10
Usage
10
Power/Record Button 10
Touchscreen 11
Storing Photos and Videos 14
Status LED Descriptions 14
DJI Mimo App 15
Maintenance
17
Firmware Update 17
Underwater Usage Notes 17
Cleaning Notes 18
Connecting to a Computer 18
Using Other Accessories (Excluded) 18
Specications
20
After-Sales Information
22
DJI Action 2 User Manual
Not nal
5
©
2021 DJI OSMO All Rights Reserved.
Product Prole
Introduction
DJI Action 2 is capable of shooting sharp 12MP photos and capturing smooth video at up to
4K/120 fps. With an innovative magnetic design, you can quickly swap accessories such as the front
touchscreen module that enables you to see the live view and operate the camera while taking seles.
Users can also record super smooth footage thanks to DJI’s latest EIS technology. HorizonSteady keeps
footage level no matter the situation while RockSteady 2.0 ensures stabler footage than ever before.
Get the most out of DJI Action 2 by wirelessly connecting it to DJI Mimo using a mobile device and display
high-quality video in real time. The camera unit is also waterproof at depths of up to 10 m and can be
connected to the waterproof case to reach as deep as 60 m.
Users can enjoy the full range of DJI Action 2 features with other accessories such as the front touchscreen
module, power module, magnetic adapter mount, magnetic ball-joint adapter mount, magnetic clip,
remote control extension rod, waterproof case, and macro lens.
DJI Action 2 Camera Unit
1. Power/Record Button
2. Status LED
3. Lens
4. Color Temperature Photo Sensor
5. Microphone
6. Lanyard Hole
1
3
7
8
4
5
2
6
9
10
7. Touchscreen
8. Expansion Port
9. Lock Hole
10. Air Pressure Balance Hole
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
6
1
4
5
10
2
6
7
23
Accessories
DJI Action 2 Front Touchscreen Module
9
8
1. Lock Clip
2. Microphone
3. Status LED
4. microSD Card Slot
5. Lock Hole
6. Power/Record Button
7. Speaker
8. Expansion Port
9. Front Screen
10. USB-C Charging Port
The front touchscreen module can be magnetically attached to the camera unit. Make sure the
expansion ports are properly aligned before attaching the magnetic lock clips to the magnetic lock
holes on the camera unit and press both clips before removing.
DJI Action 2 User Manual
Not nal
7
©
2021 DJI OSMO All Rights Reserved.
DJI Action 2 Magnetic Lanyard
The magnetic lanyard can be used to carry the camera unit conveniently. The length can be adjusted
and it is recommended to attach the camera unit so it hangs below the collarbone.
1
2
3
The DJI Action 2 Power Module can be magnetically attached to the camera unit to supply power and
extend the operating time. Users can also insert a microSD card to increase the external storage of the
camera. Make sure the expansion ports are properly aligned before attaching the magnetic lock clips to
the magnetic lock holes on the camera unit and press both clips before removing.
1
2
3
5
6
4
7
1. Expansion Port
2. Status LED
3. microSD Card Slot
4. Power/Record Button
DJI Action 2 Power Module
5. Lock Hole
6. USB-C Charging Port
7. Lock Clip
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
8
DO NOT attach the adhesive base to surfaces that are rough, powdered, peeling, covered in dust
or sand, or have oil or water stains. Otherwise, the adapter mount may not be attached rmly.
It is recommended to use the magnetic adapter with the OSMO Action Mounting Kit when recording
during strenuous exercise.
DJI Action 2 Magnetic Ball-Joint Adapter Mount
The DJI Action 2 Magnetic Ball-Joint Adapter Mount can be magnetically attached to the camera unit,
the front touchscreen module, or the power module. Make sure the magnetic lock clips are properly
attached to the magnetic lock holes on the camera unit or module on both sides and press both clips
before removing. Make sure to press the adhesive base for at least 10 seconds after attaching it to a
surface. Otherwise, the adapter mount may not attach rmly. The adhesive base on the bottom of the
adapter mount can be used repeatedly after washing and air drying.
DJI Action 2 Magnetic Adapter Mount
The magnetic adapter mount can be magnetically attached to the camera unit, the front touchscreen
module, or the power module. Make sure the magnetic lock clips are properly attached to the
magnetic lock holes on the camera unit or module on both sides and press both clips before removing.
DO NOT use when wearing thick clothes such as sweaters or jackets. Otherwise, the magnetic
connection may be too weak and the camera unit will fall o.
DO NOT use when performing strenuous exercise such as jumping and running.
Make sure to keep the magnetic sheet of the magnetic lanyard inside the clothing. Otherwise, the
magnetic connection may be too weak and the camera unit will fall o.
Only attach the camera unit to the magnetic lanyard. DO NOT connect any other accessories.
DJI Action 2 User Manual
Not nal
9
©
2021 DJI OSMO All Rights Reserved.
Warnings
1. DJI Action 2 contains magnets. Keep the camera away from magcards, IC cards, hard disks, RAM
chips, implantable medical devices such as pacemakers, and other devices to avoid interference.
2. The lens cap and expansion port may become hot during use. To avoid scalding, DO NOT touch.
3. DO NOT attach the camera unit to the front touchscreen module when there is any dust or liquid on
the expansion ports. Otherwise, the camera may corrode or short-circuit.
4. The front touchscreen module and the power module are not waterproof. The waterproof case is
required when using the front touchscreen module or the power module with the camera unit under
water.
5. Charge DJI Action 2 when the battery level is low. Storing the DJI Action 2 for more than four months
with low battery will reduce the battery life. Charge or discharge the DJI Action 2 battery to 40-60%
if it will not be used for 10 days or more.
6. When attaching DJI Action 2 to the roof or window of a car, the DJI Action 2 may fall off if the
car travels too fast, the surface is not clean, or there is bad weather such as high winds or a
thunderstorm.
7. For better audio quality, DO NOT block the microphone when recording video.
8. Connect the camera unit to the front touchscreen module to enable audio during playback. DO NOT
block the speaker. Otherwise, the audio performance may be aected.
Preparing
Activation
When using the camera unit, activation is required through DJI Mimo. Follow the steps below to activate.
1. Press and hold the power/record button to power on.
2. Enable Wi-Fi and Bluetooth on the mobile device.
3. Launch DJI Mimo, tap , and follow the instructions to activate the camera unit.
Device
DISCOVERY
ACADEMY
Ronin-SC - Longboard Danc…
Warren Davidson #Pano Mode
FOR YOU
MORE
9:41
TEMPLATE
SUPPORT
COMMUNITY
Home Edit MeAlbum
发现
学院
Device
9:41
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
10
Charging DJI Action 2
1. Connect a USB adapter (not included) to the USB-C port using the power cable (included).
2. The status LED on the front touchscreen module or the power module turns on during charging
when powered off. The battery is fully charged when the status LED displays solid green for six
seconds and turns o. It takes approximately 90 minutes to fully charge both the camera unit and
the front touchscreen module or the power module when they are connected.*
* Measured using a 5V/2A USB adapter in a laboratory environment. Use as a reference only.
Charge DJI Action 2 when the battery level is low. Storing the DJI Action 2 for more than four
months with low battery will reduce the battery life.
The camera unit will be charged first if the front touchscreen module or the power module is
connected to the camera unit during charging.
Usage
Power/Record Button
* Coming soon.
1. When powered o:
A. Press to power on.
B. Press and hold to quickly power on and begin shooting. The shooting mode will depend on the
SnapShot* settings.
2. When powered on:
A. Press to take photos or to start or stop recording. In settings or playback, press to return to
camera view.
B. Press and hold to enter sleep mode and press again to exit sleep mode. The camera will
automatically power o after 60 minutes in sleep mode. In QuickClip mode, press and hold to
extend recording time while recording.
C. Press twice to switch shooting mode.
DJI Action 2 User Manual
Not nal
11
©
2021 DJI OSMO All Rights Reserved.
If the camera unit is not working properly, press and hold the power/record button for 20 seconds
to restart the camera unit.
When the front touchscreen module is disconnected from the camera unit, the front touchscreen
displays the battery level and connection tips when the power/record button is pressed.
When the power module is disconnected from the camera unit, the status LED indicates the battery
level when the power/record button is pressed.
When the front touchscreen module or the power module is connected to the camera unit, the
power/record button of the front touchscreen module or the power module functions the same as
the button on the camera unit.
After connecting to the camera unit, the front touchscreen module displays and functions the same
as the touchscreen on the camera unit.
Touchscreen
The touchscreen displays the live view after the camera is powered on as well as the shooting mode,
battery level, and microSD card information.
4:15
1.0X
04:15
1.0x
1080P30
89%
Camera View
1. Storage Capacity Information
: displays either the remaining number of photos that can be taken or the duration of video that
can be recorded according to the current shooting mode. will be displayed if a microSD card is
inserted.
2. Playback
: tap or swipe to the right from the left edge of the screen to preview photos and videos as soon
as they are captured.
3. Shooting Mode
: displays the current shooting mode and parameters. Swipe up or tap to set the shooting
mode and parameters.
4. Zoom
: tap to set the zoom ratio. Zoom is unavailable in slow motion and timelapse.
5. Parameters
: tap or swipe to the left from the right edge of the screen to adjust image and audio parameters.
6. Battery Level
: displays current battery level of DJI Action 2. Tap the icon to view more detailed information
1
6
5
4
2
3
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
12
about the battery level.
Swipe Down
Swipe down on the touchscreen to enter settings.
1 5
4 8
3 7
2 6
1. Screen Settings
Tap the icon to switch between full-screen and letterbox display.
2. Storage
Tap to switch the storage media, format the microSD card, format the built-in storage, or export the
photos and videos from the built-in storage to the microSD card*.
3. System Settings
Tap to enter system settings.
Voice Control: enable voice control to use the camera with voice commands. Simplied Chinese and
English are supported. Voice commands include Start Recording, Stop Recording, Take Photo, and
Shut Down.
Vibration Notication: tap to enable or disable. Vibration notication is enabled by default.
SnapShot: use SnapShot to quickly power on and begin shooting when the camera is powered o
or in sleep mode. Supported shooting modes include Video, QuickClip, and Timelapse.
Wireless Connection: tap to check the camera name and password, set the Wi-Fi frequency, and
reset connections.
Video Compression: tap to switch video encoding format between Compatibility and Efficiency
mode. When Compatibility is selected, video will be encoded in H.264 with higher compatibility. When
Eciency is selected, video will be encoded in HEVC with a smaller le size. Only Eciency videos
are available in the following situations:
a. Video: 4K (4:3) and supported fps
b. Video: 4K (16:9) 120/100fps* or 1080p 240fps*
c. Slow-Mo: 4K 4x* or 1080p 8x*.
Sounds: tap to enable or disable sounds.
Grid: tap to enable or disable grid.
Anti-Flicker: tap to enable or disable anti-flickering. Anti-flickering detects flickering and times
shooting so it will have less of an impact.
Auto-Stop Rec Temp: tap to set auto-stop recording temperature to standard or high. Standard is
set by default. Auto-stop recording temperature can not be set to high due to local regulations and
policies in some countries and regions.
Scrn O When Locked: tap to enable so that the screen turns o when the screen is locked.
Scrn O When Rec: tap to set the timer for when the screen will turn o after recording has started
and there has been no operation.
* Coming soon.
DJI Action 2 User Manual
Not nal
13
©
2021 DJI OSMO All Rights Reserved.
Auto Power O: tap to set the time that the camera will automatically power o.
LED: tap to enable or disable the LED of the camera unit and the front touchscreen module or the
power module when connected.
Continue Last Livestream: tap to enable so the camera unit can continue from last livestream after
livestream has stopped.
Language: tap to set the language to English, Simplied Chinese, Traditional Chinese, Japanese,
Korean, Thai, German, Spanish, French, Italian, Russian, Brazilian Portuguese, Turkish, Indonesian,
or Polish.
Factory Reset: tap to reset default settings.
Device Info: tap to view name, serial number, rmware version, and quick start guide.
Compliance Info: tap to view compliance information.
4. Screen Lock
Tap to lock screen. Swipe up on the touchscreen to unlock the screen.
5. Pro Switch
Tap to switch to Pro mode and be able to adjust Format, Exposure, and WB settings.
6. Orientation Lock
Tap to switch between automatic orientation and locked orientation.
7. Brightness
Tap and slide to adjust the brightness.
8. Voice Control Switch
Tap to enable voice control so the user can control the camera with set voice commands.
Swipe Up
Swipe up and then swipe left or right to set parameters such as aspect ratio, countdown timer, and
resolution.
1. In Photo mode:
Set the aspect ratio and countdown timer.
2. In Video mode:
Set the resolution and frame rate. Tap the upper left corner to set the duration of the loop recording.*
Tap on the upper right corner to turn o electronic image stabilization, enable RockSteady, or enable
HorizonSteady. Electronic image stabilization is unavailable when using certain resolutions and frame
rates.
3. In QuickClip mode:
Set the resolution and frame rate. Tap the upper left corner to set the duration of the QuickClip. Tap
on the upper right corner to turn off electronic image stabilization, enable RockSteady, or enable
HorizonSteady. Electronic image stabilization is unavailable when using certain resolutions and frame
rates.
4. In Slow Motion mode:
Set the resolution and speed ratio.
5. In Timelapse mode:
Select Hyperlapse or Timelapse mode. The speed ratio can be set in Hyperlapse mode. The scene,
interval time, and shooting time can be set in Timelapse mode. Tap the upper right corner to set the
resolution of Timelapse mode.
* Coming soon.
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
14
Blinking Pattern Description
Solid green Ready to use
O
No microSD card detected or insucient microSD card
storage
Temporarily o While taking photo
Blinks red once every second
While taking video, loop recording*, slow motion,
timelapse, hyperlapse, or QuickClip
During countdown:
10 to 4 s: blinks red once every second
3 to 2 s: blinks red twice every second
1 to 0 s: solid red
After countdown: temporarily o
Countdown to take photo
Blinks red three times Camera powering o
Blinks red and green alternately Updating rmware
Status LED Descriptions
If the front touchscreen module or the power module is connected to the camera unit, their status
LED blinking pattern descriptions will be the same as the camera unit. The status LED blinking pattern
descriptions is as below.
Swipe Left or Right
Swipe left or right on the center of the touchscreen to switch between Photo, Video, QuickClip, Slow
Motion, and Timelapse shooting modes.
Storing Photos and Videos
The camera unit has a built-in storage capacity of 32 GB*, which can be used to directly store photos
and videos. Footage shot on DJI Action 2 can be stored on a microSD card (not included) when
connected to the front touchscreen module or power module. A UHS-I Speed Grade 3 rating microSD
card is required due to the fast read and write speeds necessary for high-resolution video data. Insert
the microSD card into the microSD card slot as shown.
DJI Action 2 only supports the exFAT le system. FAT32 is not supported.
* Coming soon.
* 22.4 GB of available storage.
DJI Action 2 User Manual
Not nal
15
©
2021 DJI OSMO All Rights Reserved.
DJI Mimo App
Home Screen
1. Discovery: tap to enter the home screen.
2. Academy: tap to watch tutorial videos and view manual documents.
3. AI Editor: tap to select videos to edit. AI Editor will automatically edit videos with music and
transitions that can be shared directly.
4. Home: tap to return to the home screen.
5. Album: tap to view photos and videos.
6. Edit: tap to edit footage from DJI Action 2 or import and edit footage from a mobile device.
7. Prole: register or log in to a DJI account. View works and settings, check likes and followers,
send messages to other users, and connect with the DJI Store.
8. Forum: tap to enter the ocial DJI forum page.
9. DJI Support: tap to enter the ocial DJI product support page.
10. Camera View: tap to enter the camera view.
Device
DISCOVERY
ACADEMY
Ronin-SC - Longboard Danc…
Warren Davidson #Pano Mode
FOR YOU
MORE
9:41
TEMPLATE
SUPPORT
COMMUNITY
Home Edit MeAlbum
1
2
3
10
9
4 5 6 7
8
Blinking Pattern Battery Level
Solid green for 3 seconds and turns o 90%-100%
Blinks green four times 76%-89%
Blinks green three times 51-75%
Blinks green twice 26%-50%
Blinks yellow once 6-25%
Blinks red three times and turn o 0-5%
The table below describes the status LED blinking pattern after pressing the power/record button
without the power module connected to the camera unit.
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
16
The camera view display may dier depending on the shooting mode. This display is for reference only.
1. Home:
: tap to return to the home screen.
2. Wi-Fi
: displays Wi-Fi connection.
3. Battery Level
: displays current battery level of DJI Action 2.
4. EIS
: displays the current electronic image stabilization.
5. microSD Card Information
11:38
: displays either the remaining number of photos that can be taken or the duration of video
that can be recorded according to the current shooting mode.
6. Shutter/Record Button
: tap to take a photo or to start or stop recording video.
7. Shooting Mode
Scroll to select the shooting mode. Choose between Timelapse, Slow Motion, Video, QuickClip, and
Photo.
8. Playback
: tap to preview photos and videos as soon as they are captured.
9. Setting
: choose Basic or Pro mode for the selected shooting mode. Various parameters can be set
when using dierent shooting modes. Video mode is used as an example below:
a. Video Settings
Basic: Loop Recording, FOV, EIS, and Grid are available.
Pro: More settings are available once Pro is enabled including Format, Exposure, and White
Balance.
Camera View
11:38
16:9
16MP
1.0x
1.0x
11:38
1 2 3 4 5
6
7
89
10
11
DJI Action 2 User Manual
Not nal
17
©
2021 DJI OSMO All Rights Reserved.
b. General Settings
View storage management, video compression, anti-flicker, auto-stop recording temperature,
and about settings such as device name, serial number and version info. Users can also select
connected devices and set Wi-Fi name and password and switch Wi-Fi frequency.
10. Recording parameters
16: 9
16MP
: tap to set the resolution and frame rate.
11. Zoom
: tap and drag to set the zoom ratio.
Accessories
The firmware of the front touchscreen module and power module are included in the camera unit
rmware. Follow the steps below to update the rmware:
1. Attach the front touchscreen module or power module and power on the camera unit.
2. Any updates will start automatically if new rmware is available.
Make sure that the battery level of the camera unit is at least 15% before updating rmware.
Contact DJI Support if the rmware is still unable to update.
Underwater Usage Notes
1. The camera unit and waterproof case meet the IP68 waterproof standards of GB/T 4208-2017 and
IEC 60529:2013. The camera unit can be used underwater at depths of up to 10 m. The maximum
depth underwater is 60 m when using the waterproof case.
2. DO NOT use DJI Action 2 in hot springs. DO NOT allow DJI Action 2 to come into contact with
corrosive or unknown liquids.
3. Attach the waterproof case when diving, surng, using underwater for extended periods, or other
situations involving high-impact with water.
4. The front touchscreen module and the power module are not waterproof. Attach the waterproof
case to use them under water.
5. When using the waterproof case, make sure the inside of the waterproof case is dry and clean,
properly locked, and that the waterproof rubber ring is secure. Insert anti-fog inserts to prevent
fogging. It is recommended to place the waterproof case under water for approximately 5 minutes to
ensure it is working properly before using.
6. Avoid jumping into water at high speed with the camera unit. Otherwise, the impact may result in
Maintenance
Firmware Update
DJI Action 2 Camera Unit
The rmware of the camera unit must be updated through DJI Mimo.
A prompt will appear when new rmware is available. Follow the steps below if the update fails.
1. Disconnect and reconnect the Bluetooth and Wi-Fi connection on the mobile device, and restart the
camera unit.
2. Restart DJI Mimo. The rmware update will begin after Mimo and the camera unit are connected.
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
18
water leakage. Make sure the camera unit is waterproof before jumping into water.
7. Rinse the camera unit or waterproof case with clean water after using underwater. Allow it to dry
naturally before using again.
Cleaning Notes
1. Keep the lens glass clean. Sand and dust may damage the lens glass. Clean DJI Action 2 with a
clean, dry cloth.
2. Keep DJI Action 2 away from sand and dust. Wash the camera unit if the holes on DJI Action 2 are
blocked by sand, dust, or any other substance.
3. All the holes on the camera unit have built-in waterproof material. DO NOT remove the waterproof
material or poke the holes. Otherwise, the camera unit will no longer be waterproof.
4. DO NOT poke the holes and speaker on the front screen module.
Connecting to a Computer
After connecting to DJI Action 2 to a PC, File Transfer, Webcam, and Cancel will appear on the
touchscreen of the camera unit. Select Cancel to charge DJI Action 2. Reconnect DJI Action 2 to the
computer if the le transfer is interrupted.
Accessory List Diagram
DJI Action 2 Remote Control
Extension Rod
Using Other Accessories (Excluded)
DJI Action 2 User Manual
Not nal
19
©
2021 DJI OSMO All Rights Reserved.
DJI Action 2 Waterproof Case
DJI Action 2 Macro Lens
DJI Action 2 Magnetic Clip
Scan the QR code or read the
corresponding product information or
user guide on the ocial DJI website
(www.dji.com/action-2).
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
20
Specications
DJI Action 2 Camera Unit
General Settings
Model MC211
Dimensions 39×39×22.3 mm
Waterproof 10 m (60 m when using waterproof case)
Weight 56 g
Camera
Screen
1.76 inches 350 ppi
500±50 cd/m² 446×424
Sensor 1/1.7” CMOS
FOV 155°
Aperture Range f/2.8
ISO Range
Photo: 100-6400
Video: 100-6400
Electronic Shutter Speed
Photo: 1/8000 to 30 s
Video: 1/8000 s to the frames per second limit
Max Photo Resolution 4000×3000
Still Photography Modes
Single photo: 12 MP
Countdown photo: O/0.5/1/2/3/5/10 s
Standard Recording
4K (4:3): 4096×3072 @ 24/25/30/48/50/60 fps
4K (16:9): 3840×2160 @ 100/120 fps
4K (16:9): 3840×2160 @ 24/25/30/48/50/60 fps
2.7K (4:3): 2688×2016 @ 24/25/30/48/50/60 fps
2.7K (16:9): 2688×1512 @ 100/120 fps
2.7K (16:9): 2688×1512 @ 24/25/30/48/50/60 fps
1080p: 1920×1080 @ 100/120/200/240 fps
1080p: 1920×1080 @ 24/25/30/48/50/60 fps
Slow Motion Recording
4K: 4x (120 fps)
2.7K: 4x (120 fps)
1080p: 8x (240 fps), 4x (120 fps)
Timelapse
4K/2.7K/1080:
Shooting interval: 0.5s/1s/2s/3s/4s/5s/6s/7s/8s/10s/13s/15s/20s/25s/30s/40s
Shooting duration: ∞, 5/10/20/30 min, 1/2/3/5 h
Stabilization
①
Electronic Image Stabilization: RockSteady 2.0, HorizonSteady
Max Video Bitrate 130 Mbps
Supported File Formats exFAT
Photo Format JPEG/RAW
Video Format MP4 (H.264/HEVC)
Built-in Storage Capacity 32 G B (22.4 GB of available storage)
DJI Action 2 User Manual
Not nal
21
©
2021 DJI OSMO All Rights Reserved.
Supported SD Cards microSD (Max. capacity 256 GB)
Recommended microSD
Cards
Recommended microSD cards:
Samsung EVO 128GB UHS-I Speed Grade 3 microSDHC
Samsung EVO Plus 128GB UHS-I Speed Grade 3 microSDXC
SanDisk Extreme 64GB V30 A2 UHS-I Speed Grade 3 microSDXC
SanDisk Extreme Pro 32GB UHS-I Speed Grade 3 microSDXC
SanDisk Extreme 16GB UHS-I Speed Grade 3 microSDXC
Lexar 1066x 64GB UHS-I Speed Grade 3 microSDHC
Audio Output 48 kHz, AAC
Built-In Battery
Battery Type LiPo 1S
Capacity 580 mAh
Energy 2.23 Wh
Voltage 3.85 V
Operating Temperature 0 to 40° C (32° to 104° F)
Charging Temperature 5 to 60° C (41° to 140° F)
Operating Time
②
Approx. 70 min
Wi-Fi
Operating Frequency 2.400-2.4835 GHz, 5.150-5.250 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <16 dBm (FCC/CE/SRRC/MIC)
5.1 GHz: <14 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: <14 dBm (FCC/CE/SRRC)
Protocol 802.11a/b/g/n/ac
Bluetooth
Operating Frequency 2.400-2.4835 GHz
Transmitter Power (EIRP) <4 dBm
Protocol BLE 5.0
DJI Action 2 Front Touchscreen Module
Dimensions 39×41.6×24.6 mm
Weight 64 g
Screen
1.76 inch 350 ppi
500±50 cd/m² 446×424
Built-In Battery
Battery Type LiPo 2S
Capacity 1300 mAh
Energy 5 Wh
Voltage 7.7 V
DJI Action 2 User Manual
©
2021 DJI OSMO All Rights Reserved.
22
After-Sales Information
Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and
support.
①
When the video frame rate is 100 fps or above, electronic image stabilization does not support
RockSteady 2.0 and the HorizonSteady can support maximum resolution of 2.7K.
②
Measured using 1080p (Power Reserve), 30fps, with sleep mode set to one minute, and electronic
image stabilization disabled. Use as a reference only.
③
Measured using a 5V/2A USB adapter in a laboratory environment. Use as a reference only.
④
Measured using 1080p (Power Reserve), 30fps, and electronic image stabilization disabled. Use as
a reference only.
Operating Temperature 0 to 40° C (32° to 104° F)
Charging Temperature 5 to 60° C (41° to 140° F)
Operating Time
②
Camera Unit + Front Screen Module: 160 min
Charging Time
③
Camera Unit + Front Screen Module: 90 min
DJI Action 2 Power Module
Dimensions 39×41.6×21.4 mm
Weight 56.6 g
Built-In Battery
Battery Type LiPo 2S
Capacity 1300 mAh
Energy 5 Wh
Voltage 7.7 V
Operating Temperature 0 to 40° C (32° to 104° F)
Charging Temperature 5 to 60° C (41° to 140° F)
Operating Time
④
Camera Unit + Power Module: 180 min
Charging Time
③
Camera Unit + Power Module: 90 min
Not nal
This content is subject to change.
Download the latest version from
www.dji.com/action-2
OSMO is a trademark of DJI OSMO.
Copyright © 2021 DJI OSMO All Rights Reserved.
