Model shown AGB121-LP
Model shown AGB122-LP
Lasered Stainless Steel Grate – 5/16” thick
Sealed Burner Bowl
Bright LED Lighting
Stainless Cover
• Natural Gas (NG) or Liquid Propane (LP)
• Twelve (12) Hestan signature color nishes
• High altitude kit
• Gas conversion kits (NG/LP)
• Carbon Fiber Vinyl Cover
OPTIONS & ACCESSORIES
• Single or double side sealed burner(s) congurations
• Double side burners: 20,000 Btu/hour brass front burner and 10,000 Btu/hour brass
rear burner
• Single side burner: 20,000 Btu/hour brass sealed burner
• 5/16” thick DiamondCut™ grate
• Sealed burner bowl with drain tube for
easy cleaning
• Electronic spark ignition system with re-ignition
capability
• LED lighting on front control panel
• Heavy gauge welded body construction
• Stainless steel drip tray for ease of cleaning
• Stainless steel top cover
• Double side burner is mountable to Tower Carts
• 120V, 60Hz, 1 amp
STANDARD FEATURES
SIDE BURNERS
SIDE BURNERS
www.hestanoutdoor.com phone 888.905.7463
3375 E. La Palma Ave., Anaheim, CA 92806
SIDE BURNERS
www.hestanoutdoor.com phone 888.905.7463
3375 E. La Palma Ave., Anaheim, CA 92806CONTACT US:
ELECTRICAL REQUIREMENTS
:
120V, 60Hz, 6 amps
GAS REQIREMENTS : ⁄” NPT gas connection. Minimum gas supply
is 7” water column for natural gas and 11” for propane. Operating
pressure at the manifold is 4” water column for natural gas and 10”
for propane. All units require a regulated gas supply.
All Models Description Total Btu’s
Cutout Dimensions
W(in.) D(in.) H(in.)
AGB121-NG / -LP Single Side Burner, Built-in, 12”
AGB122-NG / -LP
11 20,000
30,00011
12
12
13-⅞
24
-
Double Side Burner, Built-In or Cart-Attached 12”
Hestan Outdoor products are approved for outdoor use only. Hestan Commercial
Corporation reserves the right to change materials and specications without
notice. Specify type of gas when ordering.
36"
REF.
INSTALL THIS TRIM
AFTER SIDE BURNER
INSTALLATION
HESTAN
ACCESS DOOR
(SOLD SEPARATELY)
2
1
4
"
1
1
2
"
D
TOP VIEW
3-1/2" X 5-1/2"
OPENING FOR
GAS SUPPLY
& ELECTRICAL
1" MAX.
COUNTERTOP
OVERHANG
9
16
"
NOTCH
LAYOUT FOR
NON-COMBUSTIBLE
ENCLOSURE (ISLAND)
W
H
4
3
4
" MIN.
2
1
2
"
MIN.
36"
REF.
19"
10 in² MIN.
VENTILATION
OPENING ON
BOTH SIDES
AND REAR
OPENING FOR
HESTAN
ACCESS DOOR
SHOWN ATTACHED
TO TOWER CART
011024
