Product Description and Measurements
15MM Tempered Glass Vessel
Exclusive Kraus Collection
15MM Glass
21 7/8’’ X 13 7/8’’ Rectangular Vessel Sink
Tempered Natural Glass
For Counter Top Installation
Contact us toll-free at kraususa.com. 1-800-775-0703; or visit our website at www.
Prior To Installation Steps
1. Unpack your new product and ensure that all the parts are contained in the packaging.
Keep the product in its original box until you ready to install it.
2. The counter top must be flat.
3. Shut off the water supply if replacing a previously-installed vessel sink.
4. Observe all plumbing and building codes in your area.
5. It is recommended that installation of the product be done by a professional plumber.
Thank You
Dear Valued Customer,
Kraus would like to take this opportunity to thank you for this purchase. It is our sincere hope that
you are completely satisfied with your new product. We welcome any questions or comments that you
may have and look forward to assisting you with your accessory needs in the future.
Sincerely,
Kraus customer service department.
R U
K
A
S
Roughing-In Dimensions
Diagram
4 ’’
4 ’’
21 7/8’’
Countertop
Floor
-------------
------------
1 3/4 Drain Hole
32’’ Suggested
28’’
Top View
13 7/8’’
Contact us toll-free at kraususa.com. 1-800-775-0703; or visit our website at www.
Top View
Finished Wall
Top View
----------------
2’’ Suggested
5’’ Suggested
Fitting Line
3’’
Faucet Opening Suggested
R U
K
A
S
15MM Tempered Glass Vessel
STEP 2
STEP 2
Installation Instructions
STEP 1
STEP 1
Prepare counter top by drilling a 1 3/4 diameter drain hole at desired location.
Place vessel sink on mounting ring or counter top as shown below.
Pop Up Drain Installation (ONLY IF INCLUDED)
DRAIN
DRAIN TOP
RUBBER SEAL
NUT
TAIL PIPE
DO NOT OVER TIGHT THE DRAIN!!!
Counter Top
Vessel Sink
1 3/4
(Suggested)
Contact us toll-free at kraususa.com. 1-800-775-0703; or visit our website at www.
R U
K
A
S
15MM Tempered Glass Vessel
Installation Instructions
STEP 3
STEP 3
NOTE: FAUCET AND WATER SUPPLY ARE NOT INCLUDED
Vessel Sink
Counter Top
Rubber Seal + Nut
Tail Pipe
