PURVEYORS OF HANDCRAFTED FRENCH RANGES SINCE 1908
CORNUFÉ SERIES HOODS
CORNUFÉ 90 ALBERTINE: H 9
& CORNUFÉ 110: H1
lacornueusa.com
CORNUFÉ 90 HOOD: H9
900 W x 650 D x 700 H (mm)
35.4 W x 25.6 D x 27.5 H (inches)
Traditional wall-mounted chimney hood
Available in all color and trim options
4-Speed Variable Motor
One 600 CFM blower – unobstructed air flow with Ø6” duct
Remote Control and In-Hood Activation Controls
Three 20W high-intensity lights
2 dishwasher-safe baffle filters with grease capture system
Voltage: 120v; 60Hz, total rating: 425W, 3.6 AMP
Telescopic flue cover extends to maximum hood height of 39.3” (1000 mm)
Standard Color Retail: $4,770
Suzanne Kasler Color Collection Retail: $5,150
CORNUFÉ 110 HOOD: H1
1100 W x 650 D x 700 H (mm)
43.3 W x 25.6 D x 27.5 H (inches)
Traditional wall-mounted chimney hood
Available in all color and trim options
4-Speed Variable Motor
One 600 CFM blower – unobstructed air flow with Ø6” duct
Remote Control and In-Hood Activation Controls
Three 20W high-intensity Halogen lights
2 dishwasher-safe baffle filters with grease capture system
Voltage: 120v; 60Hz, total rating: 425W, 3.6 AMP
Telescopic flue cover extends to maximum hood height of 39.37” (1000 mm)
Standard Color Retail: $4,885
Suzanne Kasler Color Collection Retail: $5,250
Eight Standard Body Colors: Gloss Black, Matte Black, Stainless Steel, Ivory, Pure White, Dark Navy Blue, Royal Blue and Provence Blue
Four Suzanne Kasler’s Collection Colors: Liberte, Blanc, Tapestry and Roquefort
Three Trim Options: Stainless Steel with Satin Chrome accents, Stainless Steel with Polished Brass accents, Stainless Steel with Polished Chrome accents
* Side panels are stainless steel for all colors except Gloss Black, Matte Black and Dark Navy Blue ranges have flat black side panels.
