User manual
Register your product and get support at
www.philips.com/support
Headphones
6000 Series
TAA6606
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your Bluetooth headphones 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless headphones 4
3 Get started 5
Charge the battery 5
Pair the headphones with your
mobile phone 5
4 Use your headphones 6
Connect the headphones to a
Bluetooth device 6
Manage your calls and music 6
5 Technical data 8
6 Notice 9
Declaration of conformity 9
Disposal of your old product
and battery 9
Remove the integrated battery 9
Compliance with EMF 9
Environmental information 10
Notice of compliance 10
7 Trademarks 11
8 Frequently asked questions 12
Contents
1 Important
safety
instructions
Hearing Safety
To avoid hearing damage, limit the time you
use headphones at high volume and set the
volume to a safe level. The louder the
volume, the shorter the safe listening time is.
Be sure to observe the following guide-
lines when using your earpieces.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can't hear what's around
you.
• You should use caution or tempo-
rarily discontinue use in potentially
hazardous situations.
• Excessive sound pressure from
earphones and headphones can
cause hearing loss.
• Using headphones with both ears
covered while driving is not recom-
mended and may be illegal in some
areas while driving.
• For your safety, avoid distractions
from music or phone calls while in
trac or other potentially dangerous
environments.
General information
To avoid damage or malfunction:
Do not expose headphones to excessive heat
Do not drop your headphones.
Headphones shall not be exposed to dripping
or splashing.
Do not allow your headphones to be
submerged in water.
Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
If cleaning is required use a soft doth, if
necessary dampened with a minimum amount
of water or diluted mild soap, to clean the
product.
The integrated battery shall not be exposed to
excessive heat such as sunshine, re or the
like.
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
Danger
Caution
About operating and storage temperatures
and humidity
• Store in a place where temperature is
between -20°C (-4°F) and 50°C (122 °F)
(up to 90% relative humidity.
• Operate in a place where temperature
is between 0°C (32°F) and 45°C (113 °F)
(up to 90% relative humidity.
• Battery life may be shorter in high or
low temperature conditions.
• Replacement of a battery with an
incorrect type that can defeat a
safeguard (for example, in the case of
some lithium battery types);
• Disposal of a battery into re or a hot
oven, or mechanically crushing or
cutting of a battery, can result in an
explosion;
• Leaving a battery in an extremely high
temperature surrounding environment
can result in an explosion or the
leakage of ammable liquid or gas;
• A battery subjected to extremely low
air pressure that may result in an
explosion or the leakage of ammable
liquid or gas.
2 Your
Bluetooth
headphones
What's in the box
Wireless sports headphones
Philips TAA6606
Quick start guide
Other devices
A mobile phone or device (e.g. note-
book, tablet, Bluetooth adapters, MP3
players etc) which supports Bluetooth
and is compatible to the headphones
(see 'Technical data' on page 8).
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at
www.philips.com/support.
With this Philips headphones, you can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
Type-C charging cable (for charging only)
Global Warranty
Safety leaet
Soft pouch
Overview of your
Bluetooth wireless
headphones
Running light
Volume -
Volume +
Power button
Type C charging slot
Microphone
LED indicator
Multi-function button (MFB)
1
2
3
4
5
6
7
8
3 Get started
Charge the battery
Note
Before you use your headphones for the rst
time, place the headphones in the charging
case and charge the battery for 2 hours for
optimum battery capacity and lifetime.
Use only the original USB charging cable to
avoid any damage.
Finish your call before charging the
headphones, as connecting the headphones
for charging will power the headphones o.
Connect the supplied Type C charging
cable to:
• Type C charging slot on the head-
phones and;
• The charger/USB port of a
computer.
Tip
Normally, a full charge takes 2 hours.
Pair the headphones
with your mobile phone
Make sure that the headphones are
fully charged and turned o.
The headphones remain in
pairing mode for 5 minutes.
Before you use the headphones with
your mobile phone for the rst time, pair
it with a mobile phone. A successful
pairing establishes a unique encrypted
link between the headphones and
mobile phone. The headphones store
the last 4 devices in the memory. If you
try to pair more than 4 devices, the
earliest paired device is replaced by the
new one.
LED turns blue during charging and
turns o when the headphones is
fully charged.
Press and hold for 4 seconds
until the blue LED ashes quickly.
Philips TAA6606
Make sure that the mobile phone is
turned on and its Bluetooth feature
is activated.
The following example shows you how
to pair the headphones with your mobile
phone.
Pair the headphones with the
mobile phone. For detailed infor-
mation, refer to the user manual of
your mobile phone.
Activate the Bluetooth feature of your
mobile phone, select Philips TAA6606
Enter the headphones password
“0000” (4 zeros) if prompted. For
those mobile phones featuring
Bluetooth 3.0 or higher, no need to
enter a password.
4 Use your
headphones
Connect the headphones
to your Bluetooth device
Turn on your mobile phone/
Bluetooth device.
Press and hold the on/o button to
turn the headphones on.
The blue LED is on 1s.
The headphones are recon-
nected to the last connected
mobile phone/ Bluetooth
device automatically. If the last
one is not available, the
headphones will be in pairing
mode.
Manage your calls and
music
On/o
Task
Button
Operation
Turn the
head-
phones on.
Power
button
Press and hold
for 2 seconds.
Turn the
head-
phones o.
Power
button
Press and hold
for 4 seconds.
The blue
LED is on
1 second.
Music control
Task
Button
Operation
MFB
Play or
pause music.
Press once.
Press once.
Long press.
Long press.
Adjust volume.
Next track.
Previous track.
Call control
Task
Button
Operation
Answer /
hang up a
call.
Reject a
call
MFB
MFB
Press once.
Long press.
Switch
caller
during a
call.
MFB
Press twice.
Tip
If you turn on the mobile phone/Bluetooth
device or activate the Bluetooth feature
after turning on the headphones, you have
to reconnect the headphones and mobile
phone/Bluetooth device manually.
If the headphones fail to connect to any
Bluetooth device within range in 5 minutes,
it will switch o automatically to save the
battery life.
Note
Other headphones indicator status
Headphones status
Indicator
The headphones
are connected
to a Bluetooth
device, while the
headphones in
standby mode
or while you are
listening to music.
The blue LED
ashes once for
every 4 seconds.
The headphones
are ready for
pairing.
The LED ashes
blue quickly.
The headphones
are on but not
connected to a
Bluetooth device.
The blue LED
ashes twice for
every 3 seconds.
If no connection
can be made, the
headphones will
turn itself o within
5 minutes.
Low battery level. The blue LED
ashes 3 times for
every minute until
it is out of power.
Battery is fully
charged.
The blue LED is o.
Running light
Task
Button
Operation
Running
light on
Slow blinking-->
Fast blinking -->
Constant On -->
Constant O
Press once.
Press once.
5 Technical data
Note
Specications are subject to change without
notice.
Music time: 9 hours
Talk time: 8 hours
Standby time: 80 hours
Charging time: 2 hours
Rechargeable lithium polymer battery
(155 mAh)
Bluetooth version: 5.2
Compatible Bluetooth proles:
• HFP (Hands-Free Prole-HFP)
• A2DP (Advanced Audio Distribu-
tion Prole)
• AVRCP (Audio Video Remote
Control Prole)
Supported audio codec: SBC
Frequency range: 2.402-2.480 GHz
Transmitter power: < 10 dBm
Operating range: Up to 10 meters (33
feet)
2 mic environmental noise cancellation
Auto power o
USB-C port for charging
Low battery warning: available
Remove the integrated battery
6 Notice
Hereby, MMD Hong Kong Holding Limited
declares that this product is in compli-
ance with the essential requirements and
other relevant provisions of Directive
2014/53/EU. You can nd the Declaration
of Conformity on www.p4c.philips.com.
Declaration of conformity
Disposal of your old
product and battery
Your product is designed and manufac-
tured with high quality materials and
components, which can be recycled and
reused.
This symbol on a product means that
the product is covered by European
Directive 2012/19/EU.
This symbol means that the product
contains a built-in rechargeable battery
covered by European Directive
2013/56/EU which cannot be disposed
of with normal household waste. We
strongly advise you to take your product
to an ocial collection point or a Philips
service centre to have a professional
remove the rechargeable battery.
Inform yourself about the local separate
collection system for electrical and
electronic products and rechargeable
batteries. Follow local rules and never
dispose of the product and rechargeable
batteries with normal household waste.
Correct disposal of old products and
rechargeable batteries helps prevent
negative consequences for the environ-
ment and human health.
If there is no collection/recycling system
for electronic products in your country,
you can protect the environment by
removing and recycling the battery
before disposing the headphones.
• Make sure the headphones is
disconnected from the charging
case before removing the battery.
Compliance with EMF
This product complies with all applica-
ble standards and regulations regarding
exposure to electromagnetic elds.
Environmental information
All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
foam (buer) and polyethylene (bags,
protective foam sheet.)
Your system consists of materials which
can be recycled and reused if disassem-
bled by a specialized company. Please
observe the local regulations regarding
the disposal of packaging materials,
exhausted batteries and old equipment.
Notice of compliance
The device complies with the FCC rules,
Part 15. Operation is subject to the
following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause
undesired operation.
FCC rules
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part
15 of the FCC Rules. These limits are
designed to provide reasonable protec-
tion against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed
and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or
television reception, which can be
determined by turning the equipment o
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between
equipment and receiver
Connect the equipment into an outlet
on a circuit dierent from that to which
the receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
Canada:
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence- exempt
RSS(s). Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) This device must accept any interfer-
ence received, including interference
that may cause undesired operation of
the device.
CAN ICES-3(B)/NMB-3(B)
IC Radiation Exposure Statement:
This equipment complies with Canada
radiation exposure limits set forth for
uncontrolled environments.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
Caution:
The user is cautioned that
changes or modications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.
7 Trademarks
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by MMD Hong Kong Holding
Limited is under license. Other trade-
marks and trade names are those of
their respective owners.
Bluetooth
Siri is a trademark of Apple Inc., regis-
tered in the U.S. and other countries.
Siri
8 Frequently
asked
questions
My Bluetooth headphones don’t turn on.
The battery level is low. Charge the
headphones.
I cannot pair my Bluetooth headphones
with my Bluetooth device.
The Bluetooth is disabled. Enable the
Bluetooth feature on your Bluetooth
device and turn on the Bluetooth device
before you turn on the headphones.
The Bluetooth device cannot nd the
headphones.
• The headphones may be connected to
a previously paired device. Turn o the
connected device or move it out of
range.
• Pairing may have been reset or the
headphones has been previously
paired with another device. Pair the
headphones with the Bluetooth device
again as described in the user manual.
(see ‘Pair the headphones with your
Bluetooth device at the rst time’ on
page 5).
My Bluetooth headphones is connected to
a Bluetooth stereo enabled mobile phone,
but music only plays on the mobile phone
speaker.
Refer to the user manual of your mobile
phone. Select to listen to music through
the headphones.
The audio quality is poor and crackling
noise can be heard.
• The Bluetooth device is out of range.
Reduce the distance between your
headphones and Bluetooth device, or
remove obstacles between them.
• Charge your headphones.
The audio quality is poor when streaming
from the mobile phone is very slow, or
audio streaming does not work at all.
Make sure your mobile phone not only
supports (mono) HFP but also supports
A2DP and is BT4.0x (or higher) compatible
(see ‘Technical data’ on page 8).
I hear but cannot control music on my
Bluetooth device (e.g. play/pause/skip
forward/backward).
Make sure the Bluetooth audio source
supports AVRCP (see ‘Technical data’ on
page 8).
The volume level of the headphones is too
low.
Some Bluetooth devices cannot link the
volume level with the headphones through
volume sync. In this case, you have to
adjust the volume on your Bluetooth
device independently to achieve an
appropriate volume level.
I cannot connect the headphones to
another device, what do I do?
• Make sure the Bluetooth function of the
previous paired device is turned o.
• Repeat the pairing procedure on your
second device (see ‘Pair the head-
phones with your Bluetooth device at
the rst time’ on page 5).
For further support, visit www.philips.com/support.
Philips and the Philips Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used under license. This product has been
manufactured by and is sold under the responsibility of MMD Hong Kong
Holding Limited or one of its aliates, and MMD Hong Kong Holding
Limited is the warrantor in relation to this product.
UM_TAA6606_00_EN_V1.0
