4] The Steel Foundations center
channel stand has included a pair of
adjustable studs (j) and 1/4" rubber stud
covers (k). These are for use if you re-
quire your speaker to angle upwards.
Thread the adjustable stud through the
top plate with the allen wrench to the
desired height. Using a machine nut,
lock the threaded stud into place. Photo
5 - Thread the rubber stud covers over
the top of the adjustable stud to protect
your speaker from being scratched. Three Neoprene Isolation pads
should be placed at the rear of the top plate between the top plate and the
speaker to ensure the speaker does not slide off the back of the stand.
*NOTE: The ends of the spiked feet and
steel speaker studs are very sharp and
may scratch floors or furniture. All sharp
objects can be hazardous to children.
For this reason large rubber feet and
rubber isolation pads are provided as
an option. Sanus Systems will not be
liable for damage or injury.
Page 4
Page 1
STEEL FOUNDATIONS® SFC
INSTRUCTION MANUAL
Every effort has been made to ensure that your stands are perfect. If you
have any questions or feel that there is a problem of any kind, please call
our Customer Assistance number. We can assist with questions or damaged/
Photo 4
Photo 5
Sanus Systems 2221 Highway 36 W St. Paul MN 55113 11.22.04
800.359.5520 www.sanus.com
