SIDE BURNERS
SIDE BURNERS
www.hestanaspire.com phone 888.905.7463
3375 E. La Palma Ave., Anaheim, CA 92806
Model shown AEB121
Model shown AEB122
Stainless Steel Rod Grates
LED Lighting
Sealed Burner Bowl
Stainless Cover
• Natural Gas (NG) or Liquid Propane (LP)
• High altitude kit
• Gas conversion kits (NG/LP)
• Vinyl Cover
• Hestan signature color nishes Red-Matador, Black-Stealth,
Blue-Prince, Orange-Citra
OPTIONS & ACCESSORIES
• Single or double sealed burner congurations
• Double side burners: 20,000 Btu/hour front burner and 10,000 Btu/hour
rear burner
• Single side burner: 20,000 Btu/hour burner
• Stainless steel rod grate
• Stainless steel sealed burner bowl
• Electronic spark ignition system
with re-ignition capability
• LED lighting on front control
panel
• Heavy gauge welded body
construction
• Stainless steel top cover
• 120V, 60Hz, 1 amp
STANDARD FEATURES
SIDE BURNERS
www.hestanaspire.com phone 888.905.7463
3375 E. La Palma Ave., Anaheim, CA 92806CONTACT US:
ELECTRICAL REQUIREMENTS
:
120V, 60Hz, 1 amps
GAS REQUIREMENTS : ⁄” NPT gas connection. Minimum gas supply
is 7” water column for natural gas and 11” for propane. Operating
pressure at the manifold is 4” water column for natural gas and 10”
for propane. All units require a regulated gas supply. (included)
All Models Description Total Btu’s
Cutout Dimensions
W(in.) D(in.) H(in.)
AEB121 NG / -LP Single Side Burner, Built-in, 12”
AEB 122 NG / -LP
11 20,000
30,00011
13-⅞
24
-
11-⁄
11
-⁄
Double Side Burner, Built-In, 12”
Aspire by Hestan products are approved for outdoor use only. Hestan Commercial
Corporation reserves the right to change materials and specications without
notice. Specify type of gas when ordering.
LAYOUT FOR
NON-COMBUSTIBLE
ENCLOSURE (ISLAND)
W
H
4
3
4
" MIN.
2
1
2
"
MIN.
36"
REF.
19"
10 in² MIN.
VENTILATION
OPENING ON
BOTH SIDES
AND REAR
OPENING FOR
ASPIRE
ACCESS DOOR
36"
REF.
ASPIRE
ACCESS DOOR
(SOLD SEPARATELY)
2
1
4
"
1
1
2
"
D
TOP VIEW
3-1/2" X 5-1/2"
OPENING FOR
GAS SUPPLY
& ELECTRICAL
1" MAX.
COUNTERTOP
OVERHANG
9
16
"
NOTCH
015811
REV A
