GKNG47920DX - GKN67920DX - GKN67920Z
Refrigerator
User manual
EN /
58 4594 0000/AD
1
Contents
1. Safety and environment
instructions 3
1.1. General safety ..................... 3
1.1.1 HC warning ..........................5
1.1.2 For models with water
dispenser ......................................5
1.2. Intended use........................5
1.3. Child safety ..........................5
1.4. Compliance with WEEE
Directive and Disposing of the
Waste Product ..............................5
1.5. Compliance with RoHS
Directive ........................................ 6
1.6. Package information...........6
2. Your Refrigerator 7
3 Installation 8
3.1 Appropriate installation
location .........................................8
3.2 Installing the plastic wedges .9
3.3 Adjusting the feet ....................9
3.4 Electrical connection ..............9
3.5 Reversing the doors .............10
3.6 Reversing the doors .............11
4 Preparation 12
4.1 Things to be done for energy
saving .......................................... 12
4.2 Initial use ..............................13
5 . Using your refrigerator 14
5.1 Indicator panel ......................14
5.2 Ice bucket ..............................17
(This feature is optional)............17
5.3 Egg holder.............................17
5.4 Fan.........................................17
5.5 Vegetable bin ........................17
(This feature is optional)............17
5.6 Zero degree compartment ...17
(This feature is optional)............17
5.7 Using the second crisper of the
product ........................................18
5.8 Moving door rack ..................19
5.9 Sliding storage box ..............19
(This feature is optional)............19
5.10 Moisture controlled
vegetable bin ...............................19
(This feature is optional)............19
5.11 Automatic ice machine ...... 20
(This feature is optional)............20
5.12 Icematic and ice storage
container .....................................21
5.13 Using the water dispenser .21
5.14 Filling the water
dispenser's tank ......................... 22
5.15 Cleaning the water tank ...22
5.16 Drip tray ..............................23
5.17 HerbBox/HerbFresh ........... 24
5.18 Deodoriser Module ............. 24
5.19 Freezing fresh food .............25
5.20 Recommendations for
preserving the frozen food ......... 26
5.21 Deep-freeze information .... 26
5.22 Placing the food .................. 27
5.23 Door open warning ............. 27
5.24 Illumination lamp ...............27
5.25 Vitamin Care Technology ...27
6. Maintenance and cleaning 28
6.1 Avoiding bad odours..........28
6.2 Protecting the plastic
surfaces .....................................28
7. Troubleshooting 30
2
Please read these instructions first before using your appliance
Thank you for choosing a Beko appliance.
Please take some time to read this user manual before using your appliance,
to ensure you know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the
appliance is correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of this
user manual, and store in a safe location close to the appliance for easy future
reference.
This user manual may also be applicable for several other models.
Differences between models will be listed.
If you have any questions or concerns, please call our contact centre or find
help and information online at www.beko.co.uk
Symbols and their descriptions
This instruction manual contains the following symbols:
C Important information or useful usage tips.
A Warning against dangerous conditions for life and property.
B Warning against electric voltage.
A
A
A
C
SUPPLIER’S NAME
MODEL IDENTIFIER
(*)
INFORMATION
C
The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/
3
1. Safety and environment
instructions
This section provides the safety
instructions necessary to
prevent the risk of injury and
material damage. Failure to
observe these instructions will
invalidate all types of product
warranty.
Intended use
A
WARNING:
Keep ventilation openings,
in the appliance enclosure
or in the built-instructure,
clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other means
to accelerate the
defrostingprocess, other
than those recommended
by the manufacturer.
A
WARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside the food
storage compartments
of the appliance, unless
they are of the type
recommended by the
manufacturer.
1.1. General safety
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical,sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved. Children shall not
play with the appliance.
• In case of malfunction, unplug
the device.
• After unplugging, wait at least
5 minutes before plugging in
again.
• Unplug the product when not
in use.
• Do not touch the plug with wet
hands! Do not pull the cable to
plug off, always hold the plug.
• Do not plug in the refrigerator
if the socket is loose.
• Unplug the product during
installation, maintenance,
cleaning and repair.
• If the product will not be used
for a while, unplug the product
and remove any food inside.
• Do not use the product when
the compartment with circuit
cards located on the upper
back part of the product
(electrical card box cover) (1) is
open.
4
1
1
• Do not use steam or steamed
cleaning materials for
cleaning the refrigerator and
melting the ice inside. Steam
may contact the electrified
areas and cause short circuit
or electric shock!
• Do not wash the product by
spraying or pouring water on
it! Danger of electric shock!
• In case of malfunction, do not
use the product, as it may
cause electric shock. Contact
the authorised service as
soon as possible.
• Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
• If the product has LED
type lighting, contact the
authorised service for
replacing or in case of any
problem.
• Do not touch frozen food with
wet hands! It may adhere to
your hands!
• Do not place liquids in bottles
and cans into the freezer
compartment. They may
burst.
• Place liquids in upright
position after tightly closing
the lid.
• Do not spray flammable
substances near the product,
as it may burn or explode.
• Do not keep flammable
materials and products with
flammable gas (sprays, etc.)
in the refrigerator.
• Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of fire.
• Exposing the product to rain,
snow, sunlight and wind
will cause electrical danger.
When relocating the product,
do not pull by holding the
door handle. The handle may
come off.
• Take care to avoid trapping
any part of your hands or
body in any of the moving
parts inside the product.
• Do not step or lean on the
door, drawers and similar
parts of the refrigerator. This
will cause the product to fall
down and cause damage to
the parts.
• Take care not to trap the
power cable.
5
1.1.1 HC warning
If the product comprises a
cooling system using R600a gas,
take care to avoid damaging
the cooling system and its pipe
while using and moving the
product. This gas is flammable.
If the cooling system is
damaged, keep the product
away from sources of fire and
ventilate the room immediately.
C
The label on the inner
left side indicates the
type of gas used in the
product.
1.1.2 For models with
water dispenser
• Pressure for cold water inlet
shall be maximum 90 psi (6.2
bar). If your water pressure
exceeds 80 psi (5.5 bar), use
a pressure limiting valve in
your mains system. If you
do not know how to check
your water pressure, ask for
the help of a professional
plumber.
• If there is a risk of water
hammer effect in your
installation. Consult a
plumber.
• Do not install on the hot
water inlet. Take precautions
against of the risk of
freezing of the hoses. Water
temperature operating
interval shall be 33°F (0.6°C)
minimum and 100°F (38°C)
maximum.
• Use drinking water only.
1.2. Intended use
• This product is designed for
home use. It is not intended
for commercial use.
• The product should be used
to store food and beverages
only.
• Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes
no responsibility for any
damage due to misuse or
mishandling.
1.3. Child safety
• Keep packaging materials
out of children’s reach.
• Do not allow the children to
play with the product.
• If the product’s door
comprises a lock, break off
the lock when eventually
disposing of the product.
1.4. Compliance with WEEE
Directive and Disposing
of the Waste Product
This product complies with
EU WEEE Directive (2012/19/EU).
This product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
6
This product has been
manufactured with high
quality parts and
materials which can be
reused and are suitable
for recycling. Do not
dispose of the waste
product with normal domestic and
other wastes at the end of its
service life. Take it to the collection
center for the recycling of electrical
and electronic equipment. Please
consult your local authorities to
learn about these collection
centers.
1.5. Compliance with
RoHS Directive
• This product complies with EU
WEEE Directive (2011/65/EU).
It does not contain harmful
and prohibited materials
specified in the Directive.
1.6. Package information
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes.
Take them to the packaging
material collection points
designated by the local
authorities.
7
C
* optional:Figures in this user manual are schematic and
may not match the product exactly. If the subject parts are not
included in the product you have purchased, then those parts
are valid for other models.
2. Your Refrigerator
1. Cooler compartment door
shelf
2. Water dispenser filling tank
3. Egg section
4. Water dispenser reservoir
5. Bottle shelf
6. Sliding storage containers
7. Adjustable legs
8. Deep freezer compartment
9. Quick freeze compartment
10. Ice cube tray & Ice bank
11. Vegetable bin
12. Zero degree compartment
13. Interior light
14. Cooler compartment glass shelf
15. Temperature adjustment button
16. Cooler compartment
17. Freezer compartment
*1
*2
*3
*4
*5
*5
*6
*8
*9
7
*11
*12
13
*15
16
17
*14
*10
*4
8
3 Installation
3.1 Appropriate installation
location
In order to prepare the product for
use, refer the information in the user
manual and ensure that electrical
installation and water installation are
appropriate. If not, call a qualified
electrician and technician to have
any necessary arrangements carried
out.
B
WARNING:
Manufacturer shall not be
held liable for damages
that may arise from
procedures carried out by
unauthorized persons.
B
WARNING: Product
must not be plugged
in during installation.
Otherwise, there is the
risk of death or serious
injury!
A
WARNING: If the door
clearance of the room
where the product shall
be place is so tight to
prevent passing of the
product, remove the door
of the room and pass the
product through the door
by turning it to its side;
Alternatively, carefully
remove the product doors
• Place the product on an even floor
surface to prevent jolts.
• Install the product at least 30 cm
away from heat sources such as
hobs, heater cores and stoves and
at least 5 cm away from electrical
ovens.
• Product must not be subjected to
direct sun light and kept in humid
places.
• Appropriate air ventilation must
be provided around your product
in order to achieve an efficient
operation. If the product is to be
placed in a recess in the wall, pay
attention to leave at least 5 cm
distance with the ceiling and side
walls.
• Do not install the product in places
where the temperature falls below
-5°C.
• Your product requires adequate
air circulation to function
efficiently. If the product will be
placed in an alcove, remember
to leave at least 5 cm clearance
between the product and the
ceiling, rear wall and the side
walls.
• If the product will be placed in
an alcove, remember to leave at
least 5 cm clearance between
the product and the ceiling,
rear wall and the side walls.
Check if the rear wall clearance
protection component is
present at its location (if
provided with the product). If
the component is not available,
or if it is lost or fallen, position
the product so that at least 5 cm
clearance shall be left between
the rear surface of the product
and the wall of the room.
The clearance at the rear is
important for efficient operation
of the product.
9
3.4 Electrical connection
A
WARNING:Do not make
connections via extension
cables or multi-plugs.
B
WARNING: Damaged
power cable must
be replaced by the
Authorized Service Agent.
C
If two coolers are to be
installed side by side,
there should be at least
4 cm distance between
them.
• Our company shall not be
liable for any damages that will
arise when the product is used
without grounding and electrical
connection in accordance with
the national regulations.
• Power cable plug must be within
easy reach after installation.
• Do not extension cords or
cordless multiple outlets
between your product and the
wall outlet.
C
Hot Surface Warning!
Side walls of your product
is equipped with refrigerant
pipes to improve the cooling
system. Refrigerant with
high temperatures may
flow through these areas,
resulting in hot surfaces
on the side walls. This is
normal and does not need
any servicing. Please pay
attention while touching
these areas.
3.2 Installing the
plastic wedges
Plastic wedges supplied with the
product are used to create the
distance for the air circulation
between the product and the rear
wall.
1. To install the wedges, remove the
screws on the product and use the
screws supplied together with the
wedges.
2. Insert the 2 plastic wedges onto
the rear ventilation cover as
illustrated in the figure.
3.3 Adjusting the feet
If the product stands unbalanced
after installation, adjust the feet
on the front by rotating them to the
right or left.
10
3.5 Reversing the doors
Proceed in numerical order .
45
11
10
3
9
9
2
1
5
6
7
8
12
13
14
15
17
18
19
16
21
4
20
20
11
3.6 Reversing the doors
Proceed in numerical order .
1
1
7
1
20
11
13
9
2
10
5
3
20
20
8
18
17
19
45 °
180°
(8) (13)
14
6
4
12
16
15
12
4 Preparation
4.1 Things to be done for
energy saving
A
Connecting the product to
electronic energy-saving
systems is harmful, as it
may damage the product.
• For a freestanding appliance;
‘this refrigerating appliance is
not intended to be used as a
built-in appliance.
• Do not keep the refrigerator
doors open for long periods.
• Do not place hot food or
beverages into the refrigerator.
• Do not overfill the refrigerator;
blocking the internal air flow
will reduce cooling capacity.
• In order to store the maximum
amount of food into the
cooler compartment of your
refrigerator, you should take
out the upper drawers and
place it onto the glass rack. The
declared energy consumption
of your refrigerator was
determined by taking out the
cooler, ice tray and upper
drawers in a way that will
enable maximum storage. Using
the below drawer when storing
is strongly recommended.
Energy saving function should
be activated for best energy
consumption.
• You should not block the airflow
by putting food in front of the
cooler fan. A space of minimum
3cm must be left in front of the
protective fan wire when placing
food.
• Depending on the product’s
features; defrosting frozen foods
in the cooler compartment
will ensure energy saving and
preserve food quality.
• Food should be stored using
the drawers in the cooler
compartment in order to ensure
energy saving and protect food
in better conditions.
• Food packages should not be
in direct contact with the heat
sensor located in the cooler
compartment. If they are in
contact with the sensor, energy
consumption of the appliance
might increase.
• Make sure the foods are not
in contact with the cooler
compartment temperature
sensor described below.
13
4.2 Initial use
Before using your refrigerator,
make sure the necessary
preparations are made in line with
the instructions in “Safety and
environment instructions” and
“Installation” sections.
• Keep the product running with
no food inside for 6 and do not
open the door, unless absolutely
necessary.
C
A sound will be heard
when the compressor is
engaged. It is normal to
hear sound even when the
compressor is inactive,
due to the compressed
liquids and gasses in the
cooling system.
C
Front edges of the
product might heat up.
This is normal. These
areas are designed to
warm up in order to
prevent condensation.
C
In some models indicator
panel turns off automatically
5 minutes after the door
closes. It will be reactivated
when the door is open or any
button is pressed.
• Since hot and humid air will not
directly penetrate into your product
when the doors are not opened,
your product will optimize itself in
conditions sufficient to protect your
food. Functions and components
such as compressor, fan, heater,
defrost, lighting, display and so on
will operate according to the needs
to consume minimum energy under
these circumstances.
14
1. Economy
This symbol is illuminated when
the freezer compartment is set to
-18°C’ye as the most economical
setting value ( ). Economy
indicator is turned off when quick
cooling or quick freeze functions
are selected.
2.Power Failure / High
temperature / Error status
indicator
This indicator ( ) illuminates
in case of power failure, high
temperature and error warnings.
When the temperature of the
freezer compartment is heated
up to a critical level for the frozen
5.1 Indicator panel
Indicator panel allows you to set the temperature and control the other
functions related to the product without opening the door of the product.
Just press the inscriptions on relevant buttons for function settings.
food, the maximum value reached
by the freezer compartment
temperature flashes on the digital
indicator.
Check the food in the freezer
compartment.
This is not a malfunction. The
warning may be deleted by
pressing any button or on high
temperature alarm off button.
(Cancelling by pressing any button
is not applicable for every model.)
This indicator ( ) illuminated
when a sensor failure occurs, too.
When this indicator is illuminated,
“E” and figures such as “1,2,3...”
C
Figures in this user manual are schematic and may not match
the product exactly. If the subject parts are not included in the
product you have purchased, then those parts are valid for other
models.
May not be available in all models
*1
2
568
*7.1
*7.2
910 4
3
11
5 . Using your refrigerator
15
are displayed alternatively on
the temperature indicator. These
figures on the indicator inform the
service personnel about the error.
3. Energy saving function (display
off)
If the product doors are kept
closed for a long time energy
saving function is automatically
activated and energy saving symbol
is illuminated.When energy saving
function is activated, all symbols
on the display other than energy
saving symbol will turn off. When
the Energy Saving function is
activated, if any button is pressed
or the door is opened, energy
saving function will be canceled
and the symbols on display will
return to normal.
4. Quick cool
Quick cooling indicator
( ) is illuminated when quick
cooling function is activated and
fridge compartment temperature
indicator value is displayed as
1. To cancel this function press
Quick cooling button again. Quick
cooling indicator will turn off
and refrigerator will return to its
normal settings. Quick cooling
function is canceled automatically
in 1 hour if you do not cancel it
before. If you want to cool large
amounts of fresh food, press
the Quick cooling button before
putting the food into the fridge
compartment.
5. Vacation function
In order to activate vacation
function, press the button no.
(5) ( ) for 3 seconds, and the
vacation mode indicator activates.
When the vacation function is
activated, “- -” is displayed on the
fridge compartment temperature
indicator and no active cooling
is performed on the fridge
compartment. It is not suitable
to keep the food in the fridge
compartment when this function
is activated. Other compartments
shall be continued to be cooled as
per their set temperature.To cancel
this function press Vacation
function button again.
6. Fridge compartment tempera-
ture setting
When the button no. (6) is pressed,
you may set the temperature of the
fridge compartment to 8,7,6,5,4,3,2
and 1 respectively ( ).
7.1. Energy saving function (disp-
lay off):
Energy saving symbol ( ) is
illuminated and Energy saving
function is activated when you
press this button ( ). When energy
saving function is activated, all
symbols on the display other than
energy saving symbol will turn off.
When the Energy Saving function is
activated, if any button is pressed or
the door is opened, energy saving
function will be canceled and the
symbols on display will return to
normal. Energy saving symbol
is turned off and energy saving
function is deactivated when you
press this button ( ) again.
7.2.Alarm off warning:
In case of power failure/high
temperature warning, you may
delete the warning ( ) by pressing
any button on the indicator or high
temperature alarm off button for
1 second after checking the food
inside the freezer compartment.
Note: Cancelling by pressing any
button is not applicable for every
model.
16
8. Key lock
Press key lock button ( )
simultaneously for 3 seconds. Key
lock symbol ( ) will light up and
key lock mode will be activated.
Buttons will not function if the
Key lock mode is active. Press key
lock button simultaneously for 3
seconds again. Key lock symbol
will turn off and the key lock mode
will be exited.
Press the key lock button if
you want to prevent changing of
the temperature setting of the
refrigerator ( ).
9. Eco fuzzy
Press and hold eco fuzzy button
for 1 seconds to activate eco fuzzy
function. Refrigerator will start
operating in the most economic
mode at least 6 hours later and the
economic usage indicator will turn
on when the function is active (
). Press and hold eco fuzzy function
button for 3 seconds to deactivate
eco fuzzy function.
This indicator is illuminated after 6
hours when eco fuzzy is activated.
10. Freezer compartment tempe-
rature setting
Temperature setting for freezer
compartment is performed here.
When button no. 9 is pressed,
you may set the temperature of
the freezer compartment to -18,
-19, -20, -21, -22, -23 and -24
respectively.
11. Fast freeze
Press button no. (11) for fast
freeze operation, quick freeze
indicator
( ) shall be activated.
Quick freeze indicator is
illuminated when quick freeze
function is activated and fridge
compartment temperature
indicator is displayed as -27. To
cancel this function press quick
freeze button ( ) again.
Quick freeze indicator will turn
off and refrigerator will return to
its normal settings. Quick freeze
function is canceled automatically
in 24 hour if you do not cancel it
before. If you want to freeze large
amounts of fresh food, press
the quick freeze button before
putting the food into the freezer
compartment.
17
5.2 Ice bucket
(This feature is optional)
• Take the ice bucket from the
freezer compartment.
• Fill the ice bucket with water.
• Place the ice bucket into the
freezer compartment.
• The ice will be ready after
approximately two hours. Take
the ice bucket from the freezer
compartment and bend in
sightly over the holder that you
are going to serve. Ice will easily
pour into the serving holder.
5.4 Fan
Fan was designed to distribute
circulate the cold air inside your re-
frigerator homogeneously. Operating
time of the fan might vary depending
the features of your product.
While in some products fan only
operates with compressor, in oth-
ers control system determines the
operating time based on the need for
cooling.
5.5 Vegetable bin
(This feature is optional)
• Product’s vegetable bin is
designed to keep vegetables
fresh by preserving humidity.
For this purpose, the overall
cold air circulation is intensified
in the vegetable bin.
5.6 Zero degree compartment
(This feature is optional)
Use this compartment to
keep delicatessen at lower
temperatures or meat products for
immediate consumption.
Zero degree compartment is the
coolest place where foods such
as dairy products, meat, fish and
chicken can be stored in ideal
storage conditions. Vegetables
and/or fruits should not be stored
in this compartment.
5.3 Egg holder
You can put the eggholder on the
door or body rack of your choice. If
you decide to put it on the body rack,
it is recommended to prefer the
shelves below as they are colder.
A
Do not put the eggholder
into the freezer
compartment.
18
5.7 Using the second crisper
of the product
Figure 1.
As shown in the figure, there are
2 stoppers in the second crisper of
K70560 model product.
Figure 3.
With the door is open 90°, pull the
second crisper up to the first stopper
as shown in Figure 3.
In the case that the drawer is more
open, first of all, open the door by
at least 135° degrees. After that, as
shown in Figure 4, lift the second
crisper for about 5 mm so that it is
freed from the first stopper.
Figure 4.
After lifting, pull the second drawer
up to the second stopper as shown in
Figure 2.
The second crisper looks like Figure
2 when closed.
Figure 5.
19
5.8 Moving door rack
(This feature is optional)
Moving door rack can be fixed in 3
different positions.
In order to move the rack, push the
buttons on the side evenly. Rack will
be movable.
Move the rack up or down.
When the rack is in the position that
you want, release the buttons. Rack
will be fixed again in the position
where you have released the buttons.
5.9 Sliding storage box
(This feature is optional)
This accessory has been designed
to increase the usage volume of the
door racks.
Thanks to its ability to move
sideways, it enables you to easily
place long bottle, jar or boxes that you
put in the bottle rack below.
5.10 Moisture controlled
vegetable bin
(This feature is optional)
With moisture control feature,
moisture rates of vegetables and
fruits are kept under control and
ensures a longer freshness period for
foods.
It is recommended to store leafed
vegetables such as lettuce and
spinach and similar vegetables prone
to moisture loss not on their roots
but in horizontal position into the
vegetable bin as much as possible.
When placing the vegetables, place
heavy and hard vegetables at the
bottom and light and soft ones on the
top, taking into account the specific
weights of vegetables.
Do not leave vegetables in the
vegetable bin in plastic bags.
20
Leaving them in plastic bags causes
vegetables to rot in a short time. In
situations where contact with other
vegetables is not preferred, use
packaging materials such as paper
that has a certain porosity in terms of
hygiene.
Do not put fruits that have a high
ethylene gas production such as pear,
apricot, peach and particularly apple
in the same vegetable bin with other
vegetables and fruits. The ethylene
gas coming out of these fruits might
cause other vegetables and fruits to
mature faster and rot in a shorter
period of time.
5.11 Automatic ice machine
(This feature is optional)
Automatic ice machine enables you
to easily make ice in your refrigerator.
In order to obtain ice from the ice
machine, take out the water tank in
the cooler compartment, fill it with
water and fix it back.
First ice will be ready in about 2
hours in the ice machine drawer in
the cooler compartment.
After placing the full water tank, you
can obtain about 60-70 cubes of ice
until it is fully empty.
If the water in the tank has waited
for 2-3 weeks, it should be changed.
C
In products with automatic
ice machine, you might hear
a sound when pouring the ice.
This sound is normal and is not
a sign of failure.
21
5.12 Icematic and ice
storage container
*optional
Using the Icematic
Fill the Icematic with water and
place it into its seat. Your ice will be
ready approximately in two hours.
Do not remove the Icematic from its
seating to take ice.
Turn the knobs on the ice reservoirs
clockwise by 90 degrees.
Ice cubes in the reservoirs will fall
down into the ice storage container
below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only
intended for accumulating the
ice cubes. Do not put water in it.
Otherwise, it will break.
5.13 Using the water dispenser
*optional
C
It is normal for the first
few glasses of water taken
from the dispenser to be
warm.
C
If the water dispenser is
not used for a long period
of time, dispose of first few
glasses of water to obtain
fresh water.
1. Push in the lever of the water dis-
penser with your glass. If you are
using a soft plastic cup, pushing
the lever with your hand will be ea-
sier.
2. After filling the cup up to the level
you want, release the lever.
C
Please note, how much
water flows from the
dispenser depends on
how far you depress the
lever. As the level of water
in your cup / glass rises,
gently reduce the amount
of pressure on the lever
to avoid overflow. If you
slightly press the arm, the
water will drip; this is quite
normal and not a failure.
22
5.14 Filling the water
dispenser's tank
Water tank filling reservoir is
located inside the door rack.
1. Open the cover of the tank.
2. Fill the tank with fresh drinking
water.
3. Close the cover.
C
Do not fill the water
tank with any other liquid
except for water such as
fruit juices, carbonated
beverages or alcoholic
drinks which are not
suitable to use in the water
dispenser. Water dispenser
will be irreparably damaged
if these kinds of liquids are
used. Warranty does not
cover such usages. Some
chemical substances and
additives contained in these
kinds of drinks/liquids may
damage the water tank.
C
Use clean drinking water
only.
C
Capacity of the water tank
is 3 litres; do not overfill.
5.15 Cleaning the water tank
1. Remove the water filling reservoir
inside the door rack.
2. Remove the door rack by holding
from both sides.
3. Grab the water tank from both si-
des and remove it with an angle of
45°C.
23
4. Remove the cover of the water tank
and clean the tank.
C
Components of the water
tank and water dispenser
should not be washed in
dishwasher.
5.16 Drip tray
Water that dripped while using the
water dispenser accumulates in the
spillage tray.
Remove the plastic filter as shown
in the figure.
With a clean and dry cloth, remove
the water that has accumulated.
24
5.17 HerbBox/HerbFresh
(This feature is optional)
Remove the film container from
HerbBox/HerbFresh+
Take the film out of the bag and put
it into the film container as shown in
the image.
Seal the container again and replace
it into HerbBox/HerbFresh+ unit.
HerbBox-HerbFresh+ sections are
especially ideal for storage of various
herbs that are supposed to be kept
in delicate conditions. You can store
your unbagged herbs (parsley, dill,
etc.) in this section horizontally and
keep them fresh for a much longer
period.
The film shall be replaced in every
six months.
which is placed on the ceiling of
the fresh food compartment, the
bad odours dissolve while the air is
actively being passed on the odour
filter, then the air that has been
cleaned by the filter is re-emitted to
the fresh food compartment. This
way, the unwanted odours that may
emerge during the storage of foods in
the refrigerator are eliminated before
they permeate the surfaces.
This is achieved thanks to the fan,
LED and the odour filter integrated
into the module. In daily use, the
deodorising module will turn on
automatically on a periodic basis. To
maintain efficient performance, it is
recommended to have the filter in the
deodorising module by the authorised
service provider every 5 years. Due
to the fan integrated into the module,
the noise you will hear during
operation is normal. If you open the
door of the fresh food compartment
while the module is active, the fan
will pause temporarily and resume
where it has left off after some time
the door is closed again. In case of
power failure, the deodoriser module
will resume where it has left off in
the total operation duration once the
power is back.
Info: It is recommended to store
aromatic foods (such as cheese,
olives and delicatessen foods) in their
packaging and sealed to avoid bad
odours that may result when smells
of various foods get mixed. Besides,
it is recommended to take spoiled
foods out of the refrigerator quickly to
prevent the other foods from getting
spoiled and avoid bad odours.
5.18 Deodoriser Module
(OdourFresh +)
(This feature is optional)
The deodoriser module quickly
eliminates the bad smells in your
refrigerator before they permeate
the surfaces. Thanks to this module,
25
5.19 Freezing fresh food
• In order to preserve the quality
of the food, it shall be frozen
as quickly as possible when
it is placed in the freezer
compartment, use the fast
freezing feature for this
purpose.
• You may store the food longer
in freezer compartment when
you freeze them while they are
fresh.
• Pack the food to be frozen and
close the packing so that it
would not allow entrance of air.
• Ensure that you pack your food
before putting them in the
freezer. Use freezer containers,
foils and moisture-proof papers,
plastic bags and other packing
materials instead of traditional
packing papers.
• Label each pack of food by
adding the date before freezing.
You may distinguish the
freshness of each food pack in
this way when you open your
freezer each time. Store the
food frozen before in the front
side of compartment to ensure
that they are used first.
C
The freezer compartment
defrosts automatically.
• Frozen food must be used
immediately after they are
thawed and they should not be
re-frozen.
• Do not freeze too large
quantities of food at one time.
26
Freezer
Compartment
Setting
Fridge
compartment
Setting
Remarks
-18°C 4°C This is the normal recommended setting.
-20,-22 or -24°C 4°C
These settings are recommended when the
ambient temperature exceeds 30°C.
Quick Freeze 4°C
Use when you wish to freeze your food in a short
time. Your product will return to its previous
mode when the process is over.
-18°C or colder 2°C
Use these settings if you think that your fridge
compartment is not cold enough because of the
hot ambient conditions or frequent opening and
closing of the door.
5.20 Recommendations for
preserving the frozen food
Compartment shall be set to -18°C at
least.
1. Put packages in the freezer
as quickly as possible after
purchase without allowing
the to thaw.
2. Check whether the “Use
By” and “Best Before” da-
tes on the packaging are
expired or not before free-
zing it.
3. Ensure that the package of
the food is not damaged.
5.21 Deep-freeze information
According to IEC 62552 standards,
the product shall freeze at least
4.5 kg of food at 25°C ambient
temperature to -18°C or lower
within 24 hours for every 100-litres
of freezer volume.
It is possible to preserve the food
for a long time only at -18°C or
lower temperatures.
You can keep the freshness of
food for many months (at -18°C or
lower temperatures in the deep
freeze).
Foods to be frozen should not be
allowed to come in contact with the
previously frozen items to prevent
them from getting thawed partially.
Boil the vegetables and drain their
water in order to store vegetables
for a longer time as frozen. After
draining their water, put them
in air-proof packages and place
them inside the freezer. Food such
as bananas, tomatoes, lettuce,
celery, boiled eggs, potatoes are
not suitable for freezing. When
these foods are frozen, only their
nutritional value and taste shall
be affected negatively. They shall
not be spoiled so that they would
create a risk for human health.
27
5.22 Placing the food
Freezer
compartment
shelves
Various frozen
food such as
meat, fish,
ice cream,
vegetables and
etc.
Refrigerator
compartment
shelves
Food in pans,
covered plates
and closed
containers,
eggs (in closed
container)
Door shelves
of fridge
compartment
Small and
packaged food
or beverage
Crisper
Vegetables and
fruits
Fresh zone
compartment
Delicatessen
(breakfast food,
meat products
that shall be
consumed in a
short time)
5.23 Door open warning
(This feature is optional)
Door open warning is given to user
both visually and acoustically. If the
warning continues for 10 minutes,
interior lights will be turned off.
5.24 Illumination lamp
LED lamps are used as
illumination lamps. Contact
authorized service in case of any
problem with this type of light.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose
of this lamp is to assist the user to
place foodstuffs in the refrigerator/
freezer in a safe and comfortable
way.
5.25 Vitamin Care
Technology
*May not be available in all
models
For the blue light,
Fruits and vegetables stored
in the crispers that are
illuminated with a blue light
continue their photosynthesis
by means of the wavelength
effect of blue light and thus
preserve their vitamin C
content longer.
For VitaminCare+,
Fruits and vegetables stored
in crispers illuminated with
the VitaminCare+ technology
preserve their vitamin A and
C content for a longer time
thanks to the blue, green, red
lights and dark cycles, which
simulate a day cycle.
With this technology, you can
keep your fruits & vegetables
tasty & healthy longer which
helps you to minimize food
waste at home.
If you open the door of the
refrigerator during the dark
period of the VitaminCare+
technology, the refrigerator will
automatically detect this and
enable the blue, green or red
light to illuminate the crisper
for your convenience. After you
have closed the door of the
refrigerator, the dark period
will continue, representing the
night time in a day cycle.
28
6. Maintenance and cleaning
Service life of the product extends
and frequently faced problems
decrease if cleaned at regular
intervals.
B
WARNING: Unplug the
product before cleaning it.
• Never use gasoline, benzene or
similar substances for cleaning
purposes.
• Never use any sharp and
abrasive tools, soap, household
cleaners, detergent and wax
polish for cleaning.
• Dissolve one teaspoon of
carbonate in half litre of water.
Soak a cloth with the solution
and wrung it thoroughly. Wipe
the interior of the refrigerator
with this cloth and the dry
thoroughly.
• Make sure that no water enters
the lamp housing and other
electrical items.
• If you will not use the
refrigerator for a long period of
time, unplug it, remove all food
inside, clean it and leave the
door ajar.
• Check regularly that the door
gaskets are clean. If not, clean
them.
• To remove door and body
shelves, remove all of its
contents.
• Remove the door shelves by
pulling them up. After cleaning,
slide them from top to bottom to
install.
• Never use cleaning agents or
water that contain chlorine to
clean the outer surfaces and
chromium coated parts of
the product. Chlorine causes
corrosion on such metal
surfaces
• Do not use sharp, abrasive
tools, soap, household cleaning
agents, detergents, kerosene,
fuel oil, varnish etc. to prevent
removal and deformation of the
prints on the plastic part. Use
lukewarm water and a soft cloth
for cleaning and then wipe it dry.
6.1 Avoiding bad odours
Materials that may cause odour
are not used in the production of
our refrigerators. However, due
to inappropriate food preserving
conditions and not cleaning the
inner surface of the refrigerator
as required can bring forth the
problem of odour. Pay attention to
following to avoid this problem:
• Keeping the refrigerator clean
is important. Food residuals,
stains, etc. can cause odour.
Therefore, clean the refrigerator
with carbonate dissolved in
water every 15 days.Never use
detergents or soap.
• Keep the food in closed
containers.Microorganisms
spreading out from uncovered
containers can cause
unpleasant odours.
• Never keep the food that have
expired best before dates and
spoiled in the refrigerator.
6.2 Protecting the
plastic surfaces
Do not put liquid oils or oil-
cooked meals in your refrigerator
29
in unsealed containers as they
damage the plastic surfaces of
the refrigerator. If oil is spilled or
smeared onto the plastic surfaces,
clean and rinse the relevant part
of the surface at once with warm
water.
30
7. Troubleshooting
Check this list before contacting
the service. Doing so will save you
time and money. This list includes
frequent complaints that are not
related to faulty workmanship
or materials. Certain features
mentioned herein may not apply to
your product.
The refrigerator is not working.
• The power plug is not fully
settled. >>> Plug it in to settle
completely into the socket.
• The fuse connected to the
socket powering the product
or the main fuse is blown. >>>
Check the fuses.
Condensation on the side wall of
the cooler compartment (MULTI
ZONE, COOL, CONTROL and FLEXI
ZONE).
• The door is opened too
frequently >>> Take care not
to open the product’s door too
frequently.
• The environment is too humid.
>>> Do not install the product in
humid environments.
• Foods containing liquids are
kept in unsealed holders. >>>
Keep the foods containing
liquids in sealed holders.
• The product’s door is left open.
>>> Do not keep the product’s
door open for long periods.
• The thermostat is set to too
low temperature. >>> Set the
thermostat to appropriate
temperature.
Compressor is not working.
• In case of sudden power failure
or pulling the power plug
off and putting back on, the
gas pressure in the product’s
cooling system is not balanced,
which triggers the compressor
thermic safeguard. The product
will restart after approximately 6
minutes. If the product does not
restart after this period, contact
the service.
• Defrosting is active. >>>
This is normal for a fully-
automatic defrosting product.
The defrosting is carried out
periodically.
• The product is not plugged in.
>>> Make sure the power cord is
plugged in.
• The temperature setting
is incorrect. >>> Select the
appropriate temperature
setting.
• The power is out. >>> The
product will continue to operate
normally once the power is
restored.
The refrigerator’s operating noise
is increasing while in use.
• The product’s operating
performance may vary
depending on the ambient
temperature variations. This is
normal and not a malfunction.
The refrigerator runs too often or
for too long.
• The new product may be larger
than the previous one. Larger
products will run for longer
periods.
• The room temperature may
be high. >>> The product will
normally run for long periods in
higher room temperature.
• The product may have been
recently plugged in or a new
food item is placed inside. >>>
The product will take longer to
reach the set temperature when
31
recently plugged in or a new
food item is placed inside. This
is normal.
• Large quantities of hot food may
have been recently placed into
the product. >>> Do not place
hot food into the product.
• The doors were opened
frequently or kept open for
long periods. >>> The warm air
moving inside will cause the
product to run longer. Do not
open the doors too frequently.
• The freezer or cooler door may
be ajar. >>> Check that the
doors are fully closed.
• The product may be set to
temperature too low. >>> Set the
temperature to a higher degree
and wait for the product to reach
the adjusted temperature.
• The cooler or freezer door
washer may be dirty, worn out,
broken or not properly settled.
>>> Clean or replace the washer.
Damaged / torn door washer
will cause the product to run for
longer periods to preserve the
current temperature.
The freezer temperature is very
low, but the cooler temperature is
adequate.
• The freezer compartment
temperature is set to a very
low degree. >>> Set the freezer
compartment temperature to a
higher degree and check again.
The cooler temperature is very
low, but the freezer temperature
is adequate.
• The cooler compartment
temperature is set to a very
low degree. >>> Set the freezer
compartment temperature to a
higher degree and check again.
The food items kept in cooler
compartment drawers are frozen.
• The cooler compartment
temperature is set to a very
low degree. >>> Set the freezer
compartment temperature to a
higher degree and check again.
The temperature in the cooler or
the freezer is too high.
• The cooler compartment
temperature is set to a very high
degree. >>> Temperature setting
of the cooler compartment has
an effect on the temperature in
the freezer compartment. Wait
until the temperature of relevant
parts reach the sufficient level
by changing the temperature of
cooler or freezer compartments.
• The doors were opened
frequently or kept open for long
periods. >>> Do not open the
doors too frequently.
• The door may be ajar. >>> Fully
close the door.
• The product may have been
recently plugged in or a new
food item is placed inside. >>>
This is normal. The product
will take longer to reach the
set temperature when recently
plugged in or a new food item is
placed inside.
• Large quantities of hot food may
have been recently placed into
the product. >>> Do not place
hot food into the product.
Shaking or noise.
• The ground is not level or
durable. >>> If the product is
shaking when moved slowly,
adjust the stands to balance the
product. Also make sure the
ground is sufficiently durable to
bear the product.
32
• Any items placed on the product
may cause noise. >>> Remove
any items placed on the product.
The product is making noise of
liquid flowing, spraying etc.
• The product’s operating
principles involve liquid and gas
flows. >>> This is normal and
not a malfunction.
There is sound of wind blowing
coming from the product.
• The product uses a fan for the
cooling process. This is normal
and not a malfunction.
There is condensation on the
product’s internal walls.
• Hot or humid weather will
increase icing and condensation.
This is normal and not a
malfunction.
• The doors were opened
frequently or kept open for long
periods. >>> Do not open the
doors too frequently; if open,
close the door.
• The door may be ajar. >>> Fully
close the door.
There is condensation on the
product’s exterior or between the
doors.
• The ambient weather may be
humid, this is quite normal
in humid weather. >>> The
condensation will dissipate
when the humidity is reduced.
The interior smells bad.
• The product is not cleaned
regularly. >>> Clean the interior
regularly using sponge, warm
water and carbonated water.
• Certain holders and packaging
materials may cause odour.
>>> Use holders and packaging
materials without free of odour.
• The foods were placed in
unsealed holders. >>> Keep the
foods in sealed holders. Micro-
organisms may spread out of
unsealed food items and cause
malodour. Remove any expired
or spoilt foods from the product.
The door is not closing.
• Food packages may be blocking
the door. >>> Relocate any items
blocking the doors.
• The product is not standing
in full upright position on the
ground. >>> Adjust the stands to
balance the product.
• The ground is not level or
durable. >>> Make sure the
ground is level and sufficiently
durable to bear the product.
The vegetable bin is jammed.
• The food items may be in
contact with the upper section of
the drawer. >>> Reorganize the
food items in the drawer.
If The Surface Of The Product Is
Hot.
• High temperatures may be
observed between the two
doors, on the side panels and at
the rear grill while the product
is operating. This is normal
and does not require service
maintenance!Be careful when
touching these areas.
A WARNING:
If the problem persists after
following the instructions in this
section, contact your vendor or an
Authorised Service. Do not try to
repair the product.
33
GRUNDIG UK AND IRELAND STANDARD MANUFACTURER GUARANTEE
TERMS AND CONDITIONS
Your new Grundig product is guaranteed against faulty materials,
defective components or manufacturing defects.
The standard guarantee starts from the date of original purchase of the
product, and lasts for a period of thirty six (36) months unless Beko plc
(the “Manufacturer”) agrees to extend the guarantee for the product in
writing.
If you have registered the product within 90 days of purchase by
completing the online registration form, then the standard 36 month
guarantee will be extended to 60 months, under the same terms and
conditions as detailed below
If you have any questions about the guarantee on your product (including
how long it is valid), please contact your retailer or our contact centre on
0333 207 9920 (UK and Northern Ireland) or 01 691 0203 (Republic of
Ireland)
This guarantee does not in any way diminish or affect your statutory
rights in connection with the product. This guarantee is in addition to
your statutory rights as a consumer. If you have any questions about
these rights, please contact the retailer from which you purchased the
product. In certain circumstances, it is possible that your statutory rights
may offer additional or higher levels of protection than those offered
under the terms of this guarantee.
What is covered by this guarantee?
• Repairs to the product required as a result of faulty materials,
defective components or manufacturing defects.
• Functional replacement parts to repair a product.
• The costs of a Grundig Approved Engineer to carry out the repair.
What is not covered?
• Transit and delivery damage.
• Cabinet or appearance parts, including but not limited to control
knobs, flaps and handles.
• Accessories and/or consumable items including but not limited to ice
trays, scrapers, cutlery baskets, filters and light bulbs.
• Repairs necessary as a direct or indirect result of:
-Accidental damage, misuse or abuse of a product.
-An attempted repair of a product by anyone other than a Grundig
Approved Engineer (the “Engineer”).
34
-Installation or use of a product where such installation or use fails to
meet the requirements contained in this guarantee or the User Instructions
Booklet.
• Repairs to a product operated at any time on commercial or non-
residential household premises (unless we have previously agreed to the
installation environment).
This guarantee is limited to the cost of repairing the product. To the extent
permitted by law, the Manufacturer does not accept and will not be held liable
for any financial loss incurred in connection with the failure of any product
to operate in accordance with the expected standards. Such financial loss
includes but is not limited to loss arising from:
• Time taken off work.
• Damaged food, clothing or other items.
• Meals taken at restaurants or from takeaways.
• General compensation for inconvenience.
Important Notes
1. Your product is designed and built for domestic household use only.
2. The guarantee will automatically be void if the product is installed or
is used in commercial or non-residential domestic household premi-
ses, unless we have previously agreed to the installation environment.
3. The product must be correctly installed, located and operated in
accordance with the instructions contained in the User Instructions
Booklet provided with your product.
4. Professional installation by a qualified Electrical Domestic Appliance
Installer is recommended for all Washing Machines, Dishwashers and
Electric Cookers (as incorrect installation may result in you having to
pay for the cost of repairing the product).
5. Gas Cookers must be professionally installed by a Gas Safe (or Gas
Networks Ireland for Republic of Ireland) registered gas installer.
6. This guarantee is given in respect of products purchased and used
within the United Kingdom and the Republic of Ireland.
7. This guarantee is effective from the initial date of purchase of a new
product from an authorised retailer and will be void if the product is
resold.
8. This guarantee does not apply to graded sales (where the product is
purchased as a “second”).
9. Possession of a copy of these terms and conditions does not neces-
sarily mean that a product has the benefit of this guarantee. If you
have any questions, please call our Call Centre on the number set out
above.
10. The Manufacturer reserves the right to terminate the guarantee if its
staff or representatives are subjected to physical or verbal abuse in
the course of carrying out their duties.
11. Optional extras, where available (i.e. extendable feet) are supplied on
a chargeable basis only.
35
Does Grundig offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may
at its sole discretion, replace your product with a new product instead
of carrying out a repair. Where a replacement is offered, this would
normally be an identical model but when this is not possible, a model
of similar specification will be provided. The Manufacturer will cover
the costs and arrange for the delivery of the new product and for the
return of the old product. Any costs related to disconnecting the faulty
product and installing the replacement product will not be borne by
the Manufacturer unless previously agreed to in writing. The original
guarantee will continue to apply to the replacement product; the new
product will not come with a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments
outside these hours may be possible at the sole discretion of the
Manufacturer but cannot be guaranteed. Whilst our Engineers will
endeavour to minimize inconvenience and to meet requests for specific
timed appointments, this cannot be guaranteed. We will not be liable
for delays or if it is unable to carry out a repair because a convenient
appointment cannot be arranged.
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your
product is covered by this guarantee with a proof of purchase. The
Manufacturer reserves the right to charge for the reasonable cost of any
service call if:
• You cannot provide evidence that your product is covered by this
guarantee.
• Where a service call has been made and the engineer finds that there
is no fault with your product.
• That your product has not been installed or operated in accordance
with the User Instructions Booklet.
• That the fault was caused by something other than faulty materials,
defective components or manufacturing defects.
• For missed appointments.
Payment of these costs are due immediately upon the Engineer providing
you with an invoice. The Manufacturer reserves the right to terminate
the guarantee if you fail to pay the costs for the service call in a timely
manner.
36
If you are a resident of the United Kingdom, this guarantee will be
governed by English law and subject to the English Courts, save where
you live in another part of the United Kingdom, in which case the law and
courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be
governed by Irish law and the Irish courts will have jurisdiction.
This guarantee is provided by Beko plc. Beko House, 1 Greenhill
Crescent, Watford, Hertfordshire. WD18 8QU.
Beko plc is registered in England and Wales with company registration
number 02415578.
HOW TO OBTAIN SERVICE FOR YOUR APPLIANCE
Please keep your purchase receipt or other proof of purchase details in a
safe place; you will need to have this documentation available should the
product require attention under guarantee.
Please take a few moments to complete the details below, as you will
need this information when you call us, or to use our online services.
When you call us you may be required to input your serial number into
your telephone keypad. For help please visit grundig.co.uk/support/
model-finder
• The product model number is printed on the Operating Instruction
Booklet / User guide
• The product model and serial number is printed on the Rating Label
affixed to the appliance.
• The Retailer (Purchased from) and Date of purchase will be printed on
your purchase receipt or other proof of purchase paperwork
Recording of these details alone will not count as proof of purchase.
A valid proof of purchase is required for requesting service under
guarantee.
Model number Serial number Purchased from Date of purchase
For service under guarantee or for product advice please call our
Contact centre
Before requesting service please check the troubleshooting guide in the
Operating Instructions booklet, as a charge may be levied where no fault
is found, and even though your product may still be under guarantee.
37
After arranging service the area around the product must be easily
accessible to the Engineer, without the need for cabinets or furniture to
be removed or moved.
It is your responsibility to ensure our Engineers have a clean and safe
environment to carry out any repairs.
Please have your Model number and Serial number available when you
call us, as you may be required to input your serial number into your
telephone keypad during your call.
UK Mainland & Northern Ireland:
0333 207 9920
Landline or mobile calls to 0333 numbers cost no more than calls to
geographic numbers 01 or 02, and are charged at the basic rate. Calls
from landlines and mobiles are included in free call packages but please
check with your telephone service provider for exact call charges.
Republic of Ireland:
01 691 0203
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the
instructions contained within the extended guarantee agreement
document, otherwise please call us using the appropriate number above,
where service can be obtained at a charge.
Should you experience any difficulty in obtaining service please call us on
0333 207 9920 or 01 691 0203
Contact us though our website
Send us a secure message through our online contact us form. Please
visit our website, click Contact Us and choose a product support topic
from the list of options. Complete the required details and click send
message.
Product registrations
For UK and Republic of Ireland product registrations please visit grundig.
co.uk/register.
38
DISCLAIMER / WARNING
Some (simple) failures can be adequately
handled by the end-user without any
safety issue or unsafe use arising,
provided that they are carried out within
the limits and in accordance with the
following instructions (see the “Self-
Repair” section).
Therefore, unless otherwise authorized
in the “Self-Repair” section below,
repairs shall be addressed to registered
professional repairers in order to avoid
safety issues. A registered professional
repairer is a professional repairer that has
been granted access to the instructions
and spare parts list of this product by the
manufacturer according to the methods
described in legislative acts pursuant to
Directive 2009/125/EC.
However, only the service agent (i.e.
authorized professional repairers)
that you can reach through the phone
number given in the user manual/
warranty card or through your
authorized dealer may provide service
under the guarantee terms. Therefore,
please be advised that repairs by
professional repairers (who are not
authorized by Grundig) shall void the
guarantee.
Self-Repair
Self-repair can be done by the end-user
with regard to the following spare parts:
door handles,door hinges, trays, baskets
and door gaskets (an updated list is also
available in support.grundig.com as of 1st
March 2021).
Moreover, to ensure product safety and to
prevent risk of serious injury, the mentioned
self-repair shall be done following the
instructions in the user manual for self-
repair or which are available in support.
grundig.com. For your safety, unplug the
product before attempting any self-repair.
Repair and repair attempts by end-users
for parts not included in such list and/
or not following the instructions in the
user manuals for self-repair or which are
available in support.grundig.com, might
give raise to safety issues not attributable
to Grundig, and will void the warranty of
the product.
Therefore, it is highly recommended that
end-users refrain from the attempt to carry
out repairs falling outside the mentioned
list of spare parts, contacting in such
cases authorized professional repairers
or registered professional repairers. On
the contrary, such attempts by end-users
may cause safety issues and damage
the product and subsequently cause fire,
flood, electrocution and serious personal
injury to occur.
By way of example, but not limited to,
the following repairs must be addressed
to authorized professional repairers
or registered professional repairers:
compressor, cooling circuit, main
board,inverter board, display board, etc.
The manufacturer/seller cannot be held
liable in any case where end-users do not
comply with the above.
The spare part availability of the refrigerator
that you purchased is 10 years.
During this period, original spare parts will
be available to operate the refrigerator
properly
The minimum duration of guarantee of
the refrigerator that you purchased is 36
months.
39
Notes
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
................................................................................................................................................................................................................
40
Notes
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
...............................................................................................................................
..................................................................................
................................................................................................................................................................................................................
