MEMBRANE SOLUTIONS MPP SERIES
POLYPROPYLENE CARTRIDGES
Description
R
4530 B St NW #A, Auburn WA 98001
@MSPureLife
www.mspurelife.com
Membrane Solutions MPP Series cartridges
are manufactured using food-grade 100%
polypropylene material. Non-toxic and
tasteless, a non-shedding material that does
not re-contaminate the filtered water. The
unique three-layer gradient pore size design,
forming a three-dimensional filtering effect,
has the characteristics of high porosity, high
retention rate, high dirt holding capacity and
low pressure drop.
The sediment water filters remove large and
fine particles, such as rusts, silts, sands,
vegetative debris and other undissolved
particles. Excellent choice to filter sediments
from potable well or tap water. Recommend-
ed also as a pre-filter to protect RO water
systems.
®
®
Multi-layer structure, high dirt holding capacity.
High-purity polypropylene material.
Uniform void distribution, high filtration efficiency.
Long service life and low replacement cost.
Available in a wide range of micron ratings and sizes.
Features & Benefits
Inner core is thermally treated to eliminate shedding and provide additional rigidity.
Graded Pore Structure
Filtration Mechanism (Graded Density Slope)
Rough
Fine
Upstream Downstream
4530 B St NW #A, Auburn WA 98001
@MSPureLife
www.mspurelife.com
Specifications
Filter Medium
Outer Diameter
Inner Diameter
Pore Size
Length
Recommended Service Temperature
Max. Operating Temperature
Max. Operating Pressure
Polypropylene
2.5″/ 4.5″(63mm / 114mm)
1.1″/ 1.2″(28mm / 30mm)
1µm、5µm、10µm、20µm、25µm、50µm
10″/ 20″
40-113°F / 5-45℃
180 °F / 82℃
75PSI @ 68°F(Depending on operating parameters)
Pressure Drop vs Flow Rate
Note：Unit conversion：1bar=100kPa
Flow rate is for a 10" * 2.5" cartridge. For liquids other than water,
multiply differential pressure by fluid viscosity (cP)
4530 B St NW #A, Auburn WA 98001
@MSPureLife
www.mspurelife.com
Cartridge Specifications and Performance Data
MPP-F10-1
MPP-F10-5
MPP-F10-10
MPP-F10-20
MPP-F10-25
MPP-F10-50
MPP-F20-1
MPP-F20-5
MPP-F20-10
MPP-F20-20
MPP-F10B-5
MPP-F20B-1
MPP-F20B-5
10" * 2.5"(254mm*63mm)
10" * 2.5"(254mm*63mm)
10" * 2.5"(254mm*63mm)
10" * 2.5"(254mm*63mm)
10" * 2.5"(254mm*63mm)
10" * 2.5"(254mm*63mm)
20" * 2.5"(507mm*63mm)
20" * 2.5"(507mm*63mm)
20" * 2.5"(507mm*63mm)
20" * 2.5"(507mm*63mm)
10" * 4.5"(254mm*113mm)
20" * 4.5"(507mm*113mm)
20" * 4.5"(507mm*113mm)
1µm
5µm
10µm
20µm
25µm
50µm
1µm
5µm
10µm
20µm
5µm
1µm
5µm
＜0.8psi@5gpm
＜0.3psi@5gpm
＜0.2psi@5gpm
＜0.2psi@5gpm
＜0.2psi@5gpm
＜0.1psi@5gpm
＜0.8psi@10gpm
＜0.3psi@10gpm
＜0.2psi@10gpm
＜0.2psi@10gpm
＜0.3psi@10gpm
＜0.8psi@20gpm
＜0.3psi@20gpm
Model Maximum Dimensions
Micron Rating
(nominal)
Initial ∆p (psi)
@ Flow Rate (gpm)
Note：Based on manufacturer's internal testing
