Hitachi Q142383 50 Inches Smart Tv 4k Uhd With Hdr User Manual

English - 1 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Contents

Support

............................................................7

Environmental Information...............................8

Features

..........................................................8

Ultra HD (UHD)

................................................8

Dolby Vision

.....................................................8

Accessories Included.......................................9

Standby Notications

.......................................9

TV Control Switch & Operation........................9

Using Main TV Menu

.....................................10

Inserting the Batteries into the Remote

.........11

Power Connection

.........................................11

Antenna Connection

...................................... 11

License Notication

.......................................11

Disposal Information

......................................11

Specication

..................................................12

Remote Control

.............................................14

Connections...................................................15

Switching On/Off

............................................16

First Time Installation.....................................16

Media Playback via USB Input

......................17

Media Browser...............................................17

FollowMe TV

..................................................18

CEC

...............................................................18

Settings Menu Contents

................................19

General TV Operation

...................................23

Using the Channel List

..................................23

Conguring Parental Settings

........................ 23

Electronic Programme Guide

........................23

Teletext Services (where available)

...............24

MHEG Teletext

..............................................24

BBC Red Button+ (RB+)................................24

Software Upgrade..........................................25

Troubleshooting & Tips

..................................25

To Program Your SKY Remote For Your TV

..25

PC Input Typical Display Modes

....................26

AV and HDMI Signal Compatibility

................26

Supported File Formats for USB Mode

.........27

Video File Formats

........................................27

Picture File Formats

......................................27

Audio File Formats

........................................27

Subtitle File Formats......................................28

Supported DVI Resolutions

...........................29

Connectivity

...................................................30

Wired Connectivity.........................................30

Wireless Connectivity

....................................30

Wake ON

.......................................................31

Wireless Display

............................................32

Connectivity Troubleshooting

........................32

Using Audio Video Sharing Network Service

. 33

Apps

..............................................................33

Freeview Play Platform..................................33

Internet Browser

............................................34

HBBTV System..............................................34

Smart Center

.................................................35

DVB functionality information

........................36

Quick UI Launcher functionality information

..37

Guarantee......................................................38

Energy Label

.................................................40

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 2 -

Important safety precautions

Don’t operate your TV in extreme ambient

conditions as this may cause damage to your TV.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO

NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER

SER

VICING TO QUALIFIED SERVICE PERSONNEL.

Note: Follow the on screen instructions for operating the related

features.

The lightning ash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufcient magnitude

to constitute a risk of electric shock of persons.

The exclamation point within an equilateral

triangle is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

IMPORTANT - Please read these

instructions fully before installing or

operating

Preparation

Place the device on a solid even surface. For

ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, do not place any objects on top of the

set. Use this device in moderate climates.

Operation temperature and operation humidity:

0ºC up to 40ºC, 85% rel. humidity max. (not

blocking ventilation openings).

Intended Use

This device is used to receive and display TV

programmmes. The different connection options

make an additional expansion of the reception

and display sources possible (various external

devices). This device is only suitable for dry

interior use. This appliance is intended solely

for private domestic use and may not be used

for industrial and commercial purposes. We

exclude liability in principle, if the device is not

used as intended, or unauthorized modications

have been made. To operate your TV in extreme

ambient conditions may cause the damage of

the device.

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been given supervision or

instructions concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that

they do not play with the appliance.

Children may not recognize dangers. The

swallowing of batteries can be fatal. Keep

batteries always out of reach of small

children. If a battery is swallowed, seek

immediate medical attention. Keep the

packaging lms out of reach of children, there

is a risk of suffocation.

For optimal performance use this TV set at an

altitude of less than 2000 meters above the

sea level, in dry locations and in regions with

moderate or tropical climates.

To avoid danger of suffocation, keep plastic

bags out of the reach of the babies, children and

domestic animals.

Carefully attach the stand to the TV. If the stand

is provided with screws, tighten the screws rmly

to prevent the TV from tilting. Do not over-tighten

the screws and mount the stand rubbers properly.

**************

Please read the following recommended

safety precautions carefully for your safety.

SOME DO’S AND DON’TS ON THE SAFE USE

OF EQUIPMENT

This equipment has been designed and

manufactured to meet international safety

standards but, like any electrical equipment, care

must be taken if you are to obtain the best results

and safety is to be assured.

**************

English - 3 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

DO read the operating instructions before you

attempt to use the equipment.

DO ensure that all electrical connections

(including the mains plug, extension leads

and inter-connections between the pieces of

equipment) are properly made and in accordance

with the manufacturer’s instructions. Switch off

and withdraw the mains plug before making or

changing connections.

DO consult your dealer if you are ever in doubt

about the installation, operation or safety of your

equipment.

DO be careful with glass panels or doors on

equipment.

DO route the mains lead so that it is not likely to

be walked on, crushed, chafed, or subjected to

excessive wear and tear or heat.

**************

DON’T remove any fixed cover as this may

expose dangerous voltages.

DON’T obstruct the ventilation openings of the

equipment with items such as newspapers,

tablecloths, curtains, etc. Overheating will cause

damage and shorten the life of the equipment.

DON’T allow electrical equipment to be exposed

to dripping or splashing, or objects lled with

liquids, such as vases, to be placed around the

equipment.

DON’T place hot objects or naked ame sources

such as lighted candles or nightlights on, or close

to equipment. High temperatures can melt plastic

and lead to res.

DON’T use makeshift stands and NEVER x legs

with wood screws - to ensure complete safety

always t the manufacturer’s approved stand or

legs with the xings provided according to the

instructions.

DON’T listen to headphones at high volume, as

such use can permanently damage your hearing.

DON’T leave equipment switched on when it is

unattended unless it is specically stated that it

is designed for unattended operation or has a

stand-by mode. Switch off using the switch, on the

equipment and make sure that your family know

how to do this. Special arrangements may need

to be made for inrm or handicapped people.

DON’T continue to operate the equipment if you

are in any doubt about it working normally, or if it

is damaged in any way - switch off, withdraw the

mains plug and consult your dealer.

ABOVE ALL

--- NEVER let anyone especially children

push anything into holes, slots or any other

opening in the case - this could result in a

fatal electrical shock;

--- NEVER guess or take chances with

electrical equipment of any kind

--- It is better to be safe than sorry!

Power source

• The TV should be operated only from a 220-240

V AC, 50 Hz outlet.

WARNING: Do not leave your TV in standby

or operating mode when you leave your house.

Positioning the TV

• For ventilation, please leave a clear space of

at least 10cm all around the TV.

• Do not block the ventilation openings.

• Do not place the TV on sloping or unstable

surfaces, the TV may tip over.

• To prevent damage to the TV, do not place any

objects on top of the TV.

Power cord and plug

• Do not place the set, a piece of furniture, etc.

on the power cord (mains lead) or pinch the

cord. Handle the power cord by the plug. Do not

pull the plug by holding its neck, as this could

result in damage to the plug. Do not unplug the

appliance by pulling from the power cord and

never touch the power cord with wet hands

as this could cause a short circuit or electric

shock. Never make a knot in the cord or tie it

with other cords. The power cords should be

placed in such a way that they are not likely

to be stepped on. A damaged power cord can

cause re or give you an electric shock. When it

is damaged and needs to be replaced, it should

be done by qualied personnel.

English - 4 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

• This TV receiver is supplied with a moulded

mains plug. The mains plug must not be cut off,

as it may contain a special radio interference

filter, the removal of which could lead to

impaired performance. If you wish to extend

the lead, obtain an appropriate safety approved

extension lead or consult your dealer.

• Observe the manufacturers instructions when

connecting extension leads to the set. Check

the fuse rating on the new plug; this should be

tted with a 5 Amp fuse which conforms to either

ASTA or BSI (BS1362) approvals, these are

easily identifiable by either the

ASA

symbols. If you are in any doubt about the

installation of an extension lead, please consult

a competent electrician.

Moisture and Water

• Do not use this TV in a humid or damp

place (avoid bathrooms or kitchens where

condensation or moister can damage the

equipment and near the washing machine).

• Do not expose this TV to rain or water.

• Do not place objects lled with liquids, such as

ower vases, directly above the TV. Avoid from

dripping or splashing.

• If any solid object or liquid falls into the cabinet,

unplug the TV and have it checked by qualied

personnel before operating it any further.

Ventilation

• The slots and openings on the TV set are

intended for ventilation and to ensure reliable

operation.

• To prevent overheating, these openings must

not be blocked or covered in anyway.

Heat sources and Flames

• Do not expose the TV to direct sunlight or other

heat sources.

• The TV should not be placed near to open

ames and sources of intense heat such as an

electric heater.

• Ensure that no open ame sources,

such as lit candles, are placed on top

of the TV.

Headphone Volume

• Excessive sound pressure from ear-

phones and headphones can cause

hearing loss, please take care.

Wall Mounting (optional)

• To prevent injury, this TV must be securely

attached to the wall in accordance with

the installation instructions (if the option is

available).

LCD Screen

• Occasionally, a few non-active pixels may

appear on the screen as a xed blue, green or

red point. Please note that this does not affect

the performance of your product.

• Take care not to scratch the screen with

ngernails or other hard objects.

Cleaning

• Before cleaning, unplug the TV from the wall

socket.

• Do not use liquid or aerosol cleaners. Only use

a soft, dry cloth.

Batteries

WARNING: Incorrect installation of batteries

may cause battery leakage and corrosion,

resulting in damage to the remote control.

• Do not mix old and new batteries, or batteries

of different types.

• Do not dispose of batteries in

a re.

• Do not dispose of batteries with

normal household waste, take to

a local recycling centre.

CAUTION: Insert the batteries / rechargeable

batteries in the correct polarity. Don´t try to

recharge non rechargeable batteries and under

no circumstances throw them into re. Danger of

explosion. Do not use unequal batteries (old and

new, Alkaline and carbon, etc.) simultaneously. If

you will not use the device for a long time, remove

the batteries and store the device in a dry and

dust free place. Improper use of batteries may

cause an explosion or leakage. If the batteries

have leaked, use gloves and clean the appliance

thoroughly with a dry cloth! Batteries should not

be exposed to heat, such as sunshine, re or

the like.

Replacement Parts

When replacement parts are required, make sure

that the service technician has used replacement

parts, which are specied by the manufacturer

or have the same specications as the original

English - 5 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

one. Unauthorised substitutions may result in re,

electrical shock or other hazards.

Taking out of service and storing

Unplug the TV from the mains and pack the TV

in an appropriate cardboard box. Remove the

batteries from the remote control and pack the

remote control with the TV set.

NOTE: The TV set should be stored in a dry and

dust-free room.

Connection to a Television Distribution

System (Cable TV etc.) from Tuner

Device connected to the protective earthing of the

building installation through the mains connection

or through other apparatus with a connection to

protective earthing-and to a television distribution

system using coaxial cable, may in some

circumstances create a re hazard.

Connection to a cable distribution system has

therefore to be provided through a device

providing electrical isolation below a certain

frequency range (galvanic isolator, see EN

60728-11).

CAUTION

Do not put your ngers in the middle between the

TV and stand, especially when you carry the TV,

as they may be injured.

WARNING

Do not ingest the battery, Chemical Burn Hazard

This product or the accessories supplied with the

product may contain a coin/button cell battery. If

the coin/button cell battery is swallowed, it can ca-

use severe internal burns in just 2 hours and can

lead to death.

Keep new and used batteries away from children.

If the battery compartment does not close secu-

rely, stop using the product and keep it away from

children.

If you think batteries might have been swallowed or

placed inside any part of the body, seek immediate

medical attention.

WARNING

Never place a television set in unstable or inclined

locations. A television set may fall, causing serious

personal injury or death. Many injuries, particularly

to children, can be avoided by taking simple preca-

utions such as;

• Using cabinets or stands recommended by

the manufacturer of the television set.

• Only using furniture that can safely support

the television set.

•

Ensuring the

television set is not overhanging

the edge of the supporting furniture.

• Not placing the television set on tall furniture

(for example, cupboards or bookcases)

without anchoring both the furniture and the

television set to a suitable support.

•

Not

standing the television set on cloth or

other materials placed between the television

and supporting furniture.

•

Edu

cating children about the dangers of

climbing on furniture to reach the television

set or its controls. If your existing television

set is being retained and relocated, the same

considerations as above should be applied.

English - 6 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

WALL MOUNTING WARNINGS

• Read the instructions before mounting your

TV on the wall.

•

The wall mount kit is optional.

You can obtain

from your local dealer, if not supplied with

your TV.

•

Do not install the

TV on a ceiling or on an

inclined wall.

•

Use

the specied wall mounting screws and

other accessories.

• Tighten the wall mounting screws rmly to

prevent the TV from fall. Do not over-tighten

the screws.

WARNING

Apparatus connected to the protective earthing of

the building installation through the MAINS conne-

ction or through other apparatus with a connection

to protective earthing – and to a television distri-

bution system using coaxial cable, may in some

circumstances create a re hazard. Connection

to a television distribution system has therefore to

be provided through a device providing electrical

isolation below a certain frequency range (galvanic

isolator, see EN 60728-11)

Symbols in this Instruction Book

The following symbols are used in the Instruction

Book as a marker for restrictions and precautions

and safety instructions. Note such information for

security reasons.

WARNING

If you do not pay attention to such a marked

warning, it can cause serious injury or death.

Note these warnings strictly, in order to ensure

a safe operation.

CAUTION

Such a precaution is marked, you should take

up or note, to avoid injury or property damage.

Note these instructions strictly, in order to ensure

a safe operation.

IMPORTANT

Warnings on the appliance and restrictions are

displayed like this. Read this information strictly

in order to operate the system correctly and

avoid damage.

NOTE

Information about the operation and additional

explanations are marked like this. To be aware

of such information is recommended to ensure

that the functions can be used optimally.

Markings on the Product

The following symbols are used on the product

as a marker for restrictions and precautions and

safety instructions. Each explanation shall be

considered where the product bears related

marking only. Note such information for security

reasons.

Class II Equipment: This appliance is

designed in such a way that it does not

require a safety connection to electrical

earth.

Class II Equipment With Functional

Earthing: This appliance is designed in

such a way that it does not require a

safety connection to electrical earth, the earth

connection is used for functional purposes.

Protective Earth Connection: The

marked terminal is intended for connection

of the protective earthing conductor

associated with the supply wiring.

Hazardous Live Terminal: The marked

terminal(s) is/are hazardous live under

normal operating conditions.

Caution, See Operating Instructions:

The marked area(s) contain(s) user

replaceable coin or button cell batteries.

Class 1 Laser Product:

This product contains

Class 1 laser source

that is safe under

reasonably foreseeable

conditions of operation.

The illustrations and the OSD in this operation

manual are for explanation purposes and may

vary slightly from the actual operations.

CLASS 1

LASER PRODUCT

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 7 -

Support

Technical experts are available 7 days a week

• Simple help and advice on setting up your

digital equipment (image).

•

uidance on connecting other devices to your

television such as a DVD player, Sky, home

cinema system or a games console.

•

Order

spare parts, including that lost remote

control.

•

Any other technical issues you may need

assistance with.

Call us today: 0 345 604 0105

Local call rates applies*

Lines open 8am - 7pm Monday to Saturday and 10am - 4pm Sunday

*Calls to Argos enquiry lines may attract a charge and set up fee from residential

lines depending on your call plan/tariff. Mobile and other providers costs may vary,

see www.bt.com/pricing for details.

For Security and training purposes, telephone calls to and from

customer service

centres maybe recorded and monitored. Calls from Republic of Ireland will attract

international call charges.

For online detailed guides and further assistance please use the link below

https://www.argos-support.co.uk/8038335)

English - 8 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Environmental Information

This television is designed to be environment

friendly. To reduce energy consumption, you can

follow these steps:

If you set the Energy Saving to Minimum,

Medium, Maximum or Auto the TV will reduce

the energy consumption accordingly. If you like to

set the Backlight to a xed value set as Custom

and adjust the Backlight (located under the

Energy Saving setting) manually using Left or

Right buttons on the remote. Set as Off to turn

this setting off.

Note: Available Energy Saving options may differ

depending on the selected Mode in the Settings>Picture

menu.

The Energy Saving settings can be found in the

Settings>Picture menu. Note that some picture

settings will be unavailable to be changed.

If pressed Right button or Left button consecutively,

“Screen will be off in 15 seconds.” message will

be displayed on the screen. Select Proceed and

press OK to turn the screen off immediately. If

you don’t press any button, the screen will be off

in 15 seconds. Press any button on the remote

or on the TV to turn the screen on again.

Note: Screen Off option is not available if the Mode

is set to Game.

When the TV is not in use, please switch off or

disconnect the TV from the mains plug. This will

also reduce energy consumption.

Features

• Remote controlled colour TV

• Fully integrated digital terrestrial/cable TV

(DVB-T-T2/C)

• HDMI inputs to connect other devices with

HDMI sockets

• USB input

• OSD menu system

• Stereo sound system

• Teletext

• Headphone connection

• Automatic programming system

• Manual tuning

• Automatic power down after up to eight hours.

• Sleep timer

• Child lock

• Automatic sound mute when no transmission.

• NTSC playback

• AVL (Automatic Volume Limiting)

• PLL (Frequency Search)

• PC input

• Game Mode (Optional)

• Picture off function

• Ethernet (LAN) for Internet connectivity and

service

• 802.11 a/b/g/n built in WLAN Support

• Audio Video Sharing

Ultra HD (UHD)

TV supports Ultra HD (Ultra High Denition - also

known as 4K) which provides resolution of 3840

x 2160 (4K:2K). It equals 4 times the resolution

of Full HD TV by doubling the pixel count of the

Full HD TV both horizontally and vertically. Ultra

HD contents are supported from HDMI, USB

inputs and over DVB-T2 and DVB-S2 broadcasts.

High Dynamic Range (HDR) / Hybrid Log-

Gamma (HLG)

Using this feature the TV can reproduce greater

dynamic range of luminosity by capturing and

then combining several different exposures.

HDR/HLG promises better picture quality thanks

to brighter, more realistic highlights, more realistic

colour and other improvements. It delivers the

look that lmmakers intended to achieve, showing

the hidden areas of dark shadows and sunlight

with full clarity, colour and detail. HDR/HLG

contents are supported via native and market

applications, HDMI, USB inputs and over DVB-S

broadcasts. Set the related HDMI source input

as Enhanced from the Sources option in the

Settings>System menu in order to watch HDR/

HLG content, if the HDR/HLG content is received

through an HDMI input. The source device

should also be at least HDMI 2.0a compatible

in this case.

Dolby Vision

Dolby Vision™ delivers a dramatic visual expe-

rience, astonishing brightness, exceptional con-

trast, and vivid colour, that brings entertainment

to life. It achieves this stunning image quality by

combining HDR and wide colour gamut imaging

technologies. By increasing the brightness of

the original signal and using a higher dynamic

colour and contrast range, Dolby Vision presents

amazing true-to-life images with stunning detail

that other post-processing technologies in the TV

English - 9 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

aren’t able to produce. Dolby Vision is supported

via native and market applications, HDMI and

USB inputs. In the Settings>Picture>Mode

menu two predened picture modes will be avail-

able if Dolby Vision content is detected: Dolby

Vision Bright and Dolby Vision Dark. Both allow

the user to experience the content in the way the

creator originally intended with different ambient

lighting conditions.

Accessories Included

• Remote Control

• Batteries: 2 x AAA

• Instruction Book

• Quick Start Guide

Standby Notications

If the TV does not receive any input signal (e.g.

from an aerial or HDMI source) for 3 minutes, it

will go into standby. When you next switch-on,

the following message will be displayed: “TV

switched to stand-by mode automatically

because there was no signal for a long time.”

Press OK to continue.

The Auto TV OFF option(in the Settings>System

>More menu) could have been set to a value

between 1 and 8 hours by default. If this setting

is not set as Off and the TV has been left on

and not been operated during the set time, it

will switch into standby mode after the set time

has expired. When you next switch-on the TV,

the following message will be displayed. “TV

switched to stand-by mode automatically

because no operation was made for a long

time.” Press OK to continue. Before the TV

switches into standby mode a dialogue window

will be displayed. If you do not press any button

the TV will switch into the standby mode after

a waiting period of about 5 minutes. You can

highlight Yes and press OK to switch the TV into

standby mode immediately. If you highlight No

and press OK, the TV will remain on. You can

also choose to cancel the Auto TV OFF function

from this dialogue. Highlight Disable and press

OK, the TV will remain on and the function will be

cancelled. You can enable this function again by

changing the setting of the Auto TV OFF option

from the Settings>System>More menu.

TV Control Switch & Operation

1. Up direction

2. Down direction

3. Volume / Info / Sources List selection and

Standby-On switch

The Control button allows you to control the

Volume / Programme / Source and Standby-On

functions of the TV.

To change volume: Increase the volume by

pushing the button up. Decrease the volume by

pushing the button down.

To change channel: Press the middle of the

button in, the information banner will appear on

the screen. Scroll through the stored channels

by pushing the button up or down.

To change source: Press the middle of the

button in twice(for the second time in total),

the source list will appear on the screen. Scroll

through the available sources by pushing the

button up or down.

To turn the TV off: Press the middle of the button

in and hold it down for a few seconds, the TV will

turn into standby mode.

To turn on the TV: Press the middle of the button

in, the TV will turn on.

Notes:

If you turn the TV off, this cycle starts again beginning

with the volume setting.

Main menu OSD cannot be displayed via control button.

Operation with the Remote Control

Press the Menu button on your remote control to

display main menu. Use the directional buttons

and OK button to navigate and set. Press Return/

Back or Menu button to quit a menu screen.

Input Selection

Once you have connected external systems to

your TV, you can switch to different input sources.

English - 10 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Press the Source button on your remote control

consecutively to select the different sources.

Changing Channels and Volume

You can change the channel and adjust the

volume by using the Programme +/- and Volume

+/- buttons on the remote.

Using Main TV Menu

When the Menu button is pressed, the main TV

menu will appear at the bottom of the screen.

You can navigate through the menu items using

the directional buttons on the remote. To select

an item or see the sub-menu options of the

highlighted menu press OK button. When you

highlight a menu option some of the sub-menu

items of this menu may appear on the upper

side of the menu bar for quick access. To use

a quick access item highlight it, press OK and

set as desired using the Left/Right directional

buttons. When nished press OK or Back/Return

button to exit.

Press Exit button to close the main menu.

1. Home

When main menu is opened Home menu bar will

be highlighted. The content of the Home menu

can be customised by adding options from other

menus. Just highlight an option and press the

Down direction button on the remote. If you see

Add to Home option you can add it to the Home

menu. Same way you can delete or change the

position of any item in the Home menu. Press the

Down direction button and select Delete or Move

option and press OK. In order to move a menu

item use the Right and Left direction buttons to

select the position that you want the item to move

to and press OK.

2. TV

2.1. Guide

You can access the electronic programme guide

menu using this option. Refer to Electronic

Programme Guide section for more information.

2.2. Channels

You can access the Channels menu using this

option. Refer to Using the Channel List section

for more information.

2.3. Timers

You can set timers for future events using the

options of this menu. You can also review the

previously created timers under this menu.

To add a new timer select the Add Timer tab

using the Left/Right buttons and press OK. Set

the sub-menu options as desired and when

nished press OK. A new timer will be created.

To edit a previously created timer, highlight that

timer, select the Edit Selected Timer tab and

press OK. Change the sub-menu options as

desired and press OK to save your settings.

To cancel an already set timer, highlight that timer,

select Delete Selected Timer tab and press

OK. A conrmation message will be displayed.

Highlight Yes and press OK to proceed. The timer

will be cancelled.

It is not possible to set timers for two or more

events that will broadcasted in different channels

at the same time interval. In this case you will be

asked to choose one of these timers and cancel

others. Highlight the timer you want to cancel and

press OK, Options menu will be displayed. Then

highlight Set/Cancel and press OK to cancel

that timer. You will have to save changes after

that. In order to do that press OK, highlight Save

Changes and press OK again.

3. Settings

You can manage the settings of your TV using

the options of this menu. Refer to Settings Menu

Contents section for more information.

4. Apps

When your TV is connected to the Internet related

contents will also be available, including Apps

related contents. Using the Apps menu you

can access and manage your applications. You

can add new apps from the market or delete the

existing ones. Refer to Apps section for more

information.

5. Sources

You can manage your input source references

using the options of this menu. To change the

current source highlight one of the options and

press OK.

5.1. Source Settings

Edit the names, enable or disable selected source

options. There are also Regular, Enhanced and

Disabled options available for HDMI sources.

Regular and Enhanced options are affecting the

colour settings of the selected HDMI source. To

be able to watch 4K or HDR/HLG images from

an HDMI source related source setting should

be set as Enhanced if the connected device

is compatible with HDMI 2.0 and subsequent

English - 11 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

versions. Set as Regular if the connected

device is HDMI 1.4 compatible. Set accordingly

or disable the related HDMI source by setting

as Disabled.

Inserting the Batteries into the Remote

Remove the back cover to reveal the battery

compartment. Insert two size AAA batteries.

Make sure the (+) and (-) signs match (observe

correct polarity). Do not mix old and new batter-

ies. Replace only with same or equivalent type.

Place the cover back on.

A message will be displayed on the screen when

the batteries are low and must be replaced. Note

that when the batteries are low, the performance

of the remote control may be impaired.

Batteries should not be exposed to excessive

heat such as sunshine, re or the like.

Power Connection

IMPORTANT: The TV set is designed to

operate on a 220-240V AC, 50 Hz supply. After

unpacking, allow the TV set to reach the ambient

room temperature before you connect the set to

the mains. Plug the power cable to the mains

socket outlet.

Antenna Connection

Connect the aerial or cable TV plug to the AERIAL

INPUT (ANT-TV) socket located on the rear side

of the TV.

Rear side of the TV

ANT-TV

If you want to connect a device to the TV, make

sure that both the TV and the device are turned off

before making any connection. After the connection

is done, you can turn on the units and use them.

License Notication

The terms HDMI and HDMI High-Definition

Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI

Licensing Administrator, Inc. in the United States

and other countries.

Manufactured under license from Dolby

Laboratories. Dolby, Dolby Audio, and the

double-D symbol are trademarks of Dolby

Laboratories.

Dolby, Dolby Vision, and the double-D symbol are

trademarks of Dolby Laboratories. Manufactured

under license from Dolby Laboratories.

Confidential unpublished works. Copyright

reserved.

YouTube and the YouTube logo are trademarks

of Google Inc.

For DTS patents, see http://

patents.dts.com.

Manufactured under license

from DTS Licensing Limited. DTS, the Symbol,

& DTS and the Symbol together are registered

trademarks, and DTS TruSurround is a trademark

of DTS, Inc.

For DTS patents, see

http://patents.dts.com.

Manufactured under

license from DTS Licensing Limited. DTS, DTS-

HD, the Symbol, & DTS or DTS-HD and the

Symbol together are registered trademarks of

DTS, Inc.

This product contains technology subject to

certain intellectual property rights of Microsoft.

Use or distribution of this technology outside of

this product is prohibited without the appropriate

license(s) from Microsoft.

Content owners use Microsoft PlayReady™

content access technology to protect their

intellectual property, including copyrighted

content. This device uses PlayReady technology

to access PlayReady-protected content and/or

WMDRM-protected content. If the device fails to

properly enforce restrictions on content usage,

content owners may require Microsoft to revoke

the device’s ability to consume PlayReady-

protected content. Revocation should not affect

unprotected content or content protected by other

content access technologies. Content owners

may require you to upgrade PlayReady to access

their content. If you decline an upgrade, you will

not be able to access content that requires the

upgrade.

Disposal Information

[European Union]

These symbols indicate that the electrical and

electronic equipment and the battery with this

English - 12 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

symbol should not be disposed of as general

household waste at its end-of-life. Instead, the

products should be handed over to the applicable

collection points for the recycling of electrical

and electronic equipment as well as batteries

for proper treatment, recovery and recycling in

accordance with your national legislation and the

Directive 2012/19/EU and 2013/56/EU.

By disposing of these products correctly, you

will help to conserve natural resources and will

help to prevent potential negative effects on the

environment and human health which could

otherwise be caused by inappropriate waste

handling of these products.

For more information about collection points

and recycling of these products, please contact

your local municipal office, your household

waste disposal service or the shop where you

purchased the product.

Penalties may be applicable for incorrect disposal

of this waste, in accordance with national

legislation.

[Business users]

If you wish to dispose of this product, please

contact your supplier and check the terms and

conditions of the purchase contract.

[Other Countries outside the European

Union]

These symbols are only valid in the European

Union.

Contact your local authority to learn about

disposal and recycling.

The product and packaging should be taken to

your local collection point for recycling.

Some collection points accept products free of

charge.

Note: The sign Pb below the symbol for batteries

indicates that this battery contains lead.

1 2

1-Products

2- Battery

Specication

TV Broadcasting

PAL BG/I/DK

SECAM BG/DK

Receiving Channels

VHF (BAND I/III) - UHF

(BAND U) - HYPERBAND

Digital Reception

Fully integrated digital

terrestrial-cable TV

(DVB-T-C)

(DVB-T2 compliant)

Number of Preset

Channels

1 000

Channel Indicator On Screen Display

RF Aerial Input 75 Ohm (unbalanced)

Operating Voltage 220-240V AC, 50Hz.

Audio

DTS TruSurround

DTS-HD

Audio Output Power

(WRMS.) (10% THD)

2 x 10

Power Consumption

(W)

135

Networked Standby

(W)

< 3

TV Dimensions

DxLxH (with stand)

(mm)

219 x 1127 x 698

TV Dimensions

DxLxH (without

stand) (mm)

44/74 x 1127 x 657

Display 50”

Operation

temperature and

operation humidity

0ºC up to 40ºC, 85%

humidity max

English - 13 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Wireless LAN Transmitter

Specications

Frequency Ranges Max Output Power

2400 - 2483,5 MHz (CH1-CH13) < 100 mW

5150 - 5250 MHz (CH36 - CH48) < 200 mW

5250 - 5350 MHz (CH52 - CH64) < 200 mW

5470 - 5725 MHz (CH100 -

CH140)

< 200 mW

Country Restrictions

This device is intended for home and ofce use

in all EU countries (and other countries following

the relevant EU directive) without any limitation

except for the countries mentioned below.

Country Restriction

Bulgaria

General authorization required for outdoor

use and public service

France In-door use only for 2454-2483.5 MHz

Italy

If used outside of own premises, general

authorization is required

Greece

In-door use only for 5470 MHz to 5725

MHz band

Luxembourg

General authorization required for network

and service supply(not for spectrum)

Norway

Radio transmission is prohibited for the

geographical area within a radius of 20 km

from the centre of Ny-Ålesund

Russian Fed-

eration

In-door use only

The requirements for any country may change

at any time. It’s recommended that user checks

with local authorities for the current status of their

national regulations for both 2.4 GHz and 5 GHz

wireless LAN’s.

English - 14 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Remote Control

(*) MY BUTTON 1:

This button may have a default function depending on

the model. However you can set a special function to

this button by pressing on it for ve seconds when on

a desired source or channel. A conrmation message

will be displayed on the screen. Now the My Button 1 is

associated with the selected function.

Note that if you perform First Time Installation, My

Button 1 will return to its default function.

1. Standby: Switches On / Off the TV

2. Numeric buttons: Switches the channel, enters

a number or a letter in the text box on the screen.

3. Language: Displays and changes audio/subtitle

language and turns subtitles on or off (digital TV,

where available)

4. Mute: Completely turns off the volume of the TV

5. Volume +/-

6. Menu: Displays TV menu

7. Guide: Displays the electronic programme guide

8. Directional buttons: Helps navigate menus,

content etc. and displays the subpages in TXT

mode when pressed Right or Left

9. OK: Conrms user selections, holds the page (in

TXT mode), views Channels menu (DTV mode)

10. Back/Return: Returns to previous screen,

previous menu, opens index page (in TXT mode)

11. Netix: Launches the Netix application

12. Freeview Play: Connects to the Freeview Play

platform where you can access available catch-

up TV services

13. Coloured Buttons: Follow the on-screen instruc-

tions for coloured button functions

14. Rewind: Moves frames backwards in media such

as movies

15. No function

16. Play: Starts to play selected media

17. Pause: Pauses the media being played

18. Stop: Stops the media being played

19. Fast Forward: Moves frames forward in media

such as movies

20. My Button 1 (*)

21. YouTube: Launches the YouTube application

22. Exit: Closes and exits from displayed menus or

returns to previous screen

23. Info: Displays information about on-screen

content, shows hidden information (reveal - in

TXT mode)

24. Source: Shows available broadcast and content

sources

25. Programme +/-

26. Text: Displays teletext (where available), press

again to superimpose the teletext over a normal

broadcast picture (mix), turns MHEG services on

and off (where available)

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 15 -

Connections

Connector Type Cables Device

VGA

Connection

(back)

AUDIO IN

PC/YPbPr

Audio

Connection

(back)

YPbPr/PC Audio Cable

HDMI

Connection

(side&back)

SPDIF

(Optical Out)

Connection

(back)

BACK AV

Back AV

(Audio/Video)

Connection

(back)

Audio Video Cable

HEADPHONE

Headphone

Connection

(side)

YPBPR

YPbPr Video

Connection

(back)

PC to YPbPr Connection Cable

USB

Connection

(side)

Connection

(side)

CAM

module

LAN

Ethernet

Connection

(back)

LAN / Ethernet Cable

See the illustrations on the left

side. You can use YPbPr to VGA

cable to enable YPbPr signal via

VGA input. You cannot use VGA

and YPbPr at the same time. To

enable PC/YPbPr audio, you

will need to use the back audio

inputs with a YPbPr/PC audio

cable for audio connection.

When using the wall mounting

kit (available from a third party

in the market, if not supplied),

we recommend that you plug all

your cables into the back of the

TV before mounting on the wall.

Insert or remove the CI module

only when the TV is SWITCHED

OFF. You should refer to the

module instruction manual for

details of the settings. The/

Each USB input of your TV

supports devices up to 500mA.

Connecting devices that have

current value above 500mA

may damage your TV. When

connecting equipment using

a HDMI cable to your TV, to

guarantee sufficient immunity

against parasitic frequency

radiation and trouble-free

transmission of high denition

signals, such as 4K content,

you have to use a high speed

shielded (high grade) HDMI

cable with ferrites.

If you want to connect a device to the TV, make sure that both the TV and the device are turned off before making

any connection. After the connection is done, you can turn on the units and use them.

English - 16 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Switching On/Off

To Switch the TV On

Connect the power cord to a power source such

as a wall socket (220-240V AC, 50 Hz).

To switch on the TV from standby mode either:

• Press the Standby button, Programme +/- or

a numeric button on the remote control.

• Press the middle of the side function switch

on the TV in.

To Switch the TV Off

Press the Standby button on the remote control

or press the middle of the side function switch on

the TV in and hold it down for a few seconds, the

TV will switch into standby mode.

To power down the TV completely, unplug the

power cord from the mains socket.

Note: When the TV is switched into standby mode, the

standby LED can blink to indicate that features such as

Standby Search, Over Air Download or Timer is active.

The LED can also blink when you switch on the TV from

standby mode.

First Time Installation

When turned on for the rst time, the language

selection screen is displayed. Select the desired

language and press OK. In the following steps of

the installation guide, set your preferences using

the directional buttons and OK button.

On the second screen set your country

preference.

Depending on the Country selection

you may be asked to set and conrm a PIN at this

point. The selected PIN cannot be 0000. You have

to enter it if you are asked to enter a PIN for any

menu operation later.

You can activate Store Mode option in the next

step. This option will congure your TV’s settings

for store environment and depending on the TV

model being used, the supported features of it

may be displayed on the side of the screen as

an info banner. This option is intended only for

store use. It is recommended to select Home

Mode for home use. This option will be available

in Settings>System>More menu and can be

turned off/on later. Make your selection and press

OK to continue.

Depending on the model of your TV and the

country selection Privacy Settings menu may

appear at this point. Using this menu you can

set your privacy privileges. Highlight a feature

and use Left and Right directional buttons to

enable or disable. Read the related explanations

displayed on the screen for each highlighted

feature before making any changes. You can

use Programme +/- buttons to scroll up and

down to read the entire text. You will be able

to change your preferences at any time later

from the Settings>System>Privacy Settings

menu. If the Internet Connection option is

disabled Network/Internet Settings screen will

be skipped and not displayed. If you have any

questions, complaints or comments regarding

this privacy policy or its enforcement, please

contact by email at smarttvsecurity@vosshub.

com.

Highlight Next and press OK button on the

remote control to continue and the Network/

Internet Settings menu will be displayed. Please

refer to Connectivity section to congure a wired

or a wireless connection. If you want your TV to

consume less power in standby mode, you can

disable the Wake On option by setting it as Off.

After the settings are completed highlight Next

and press OK button to continue.

On the next screen you need to agree to the

terms and conditions of Freeview Play to make

use of the related services. Scroll the page to

read the entire text using the up/down directional

buttons or Programme +/- buttons. Highlight

Yes and press OK on the remote to conrm and

proceed. Highlight No and press OK to proceed

without conrmation. For further requirements

for Freeview Play services refer to the Freeview

Play Platform section.

On next screen you can set broadcast types to be

searched, set your encrypted channel searching

and time zone (depending on the country

selection)preferences. Additionally you can set a

broadcast type as your favourite one. Priority will

be given to the selected broadcast type during

the search process and the channels of it will be

listed on the top of the channel list. When nished,

highlight Next and press OK to continue.

About Selecting Broadcast Type

(For use in the UK the default will be

D.Aerial)

To turn a search option for a broadcast type

highlight it and press OK. The checkbox next to

the selected option will be checked. To turn the

search option off clear the checkbox by pressing

English - 17 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

OK after moving the focus on the desired

broadcast type option.

Digital Aerial: If D. Aerial broadcast search

option is turned on, the TV will search for digital

terrestrial broadcasts after other initial settings

are completed.

Digital Cable: If D. Cable broadcast search

option is turned on, the TV will search for digital

cable broadcasts after other initial settings are

completed. A message will be displayed before

starting to search asking if you want to perform

cable network search. If you select Yes and press

OK you can select Network or set values such as

Frequency, Network ID and Search Step on the

next screen. If you select No and press OK you

can set Start Frequency, Stop Frequency and

Search Step on the next screen. When nished,

highlight Next and press OK button to continue.

Note: Searching duration will change depending on the

selected Search Step.

After the initial settings are completed TV will start

to search for available broadcasts of the selected

broadcast types.

While the search continues current scan results

will be displayed at the bottom of the screen. After

all the available stations are stored, Channels

menu will be displayed. You can edit the channel

list according to your preferences using the Edit

tab options or press the Menu button to quit and

watch TV.

While the search continues a message may

appear, asking whether you want to sort channels

according to the LCN(*). Select Yes and press

OK to conrm.

(*) LCN is the Logical Channel Number system that

organizes available broadcasts in accordance with a

recognizable channel number sequence (if available).

Note: Do not turn off the TV while initializing rst time

installation. Note that, some options may not be available

depending on the country selection.

Media Playback via USB Input

You can connect 2.5” and 3.5” inch (HDD with external

power supply) external hard disk drives or USB memory

stick to your TV by using the USB inputs of the TV.

IMPORTANT! Back up the les on your storage

devices before connecting them to the TV.

Manufacturer will not be responsible for any

le damage or data loss. Certain types of USB

devices (e.g. MP3 Players) or USB hard disk

drives/memory sticks may not be compatible

with this TV. The TV supports FAT32 and NTFS

disk formatting.

Wait a little while before each plugging and

unplugging as the player may still be reading les.

Failure to do so may cause physical damage to

the USB player and the USB device itself. Do not

pull out your drive while playing a le.

You can use USB hubs with your TV’s USB

inputs. External power supplied USB hubs are

recommended in such a case.

It is recommended to use the TV’s USB input(s)

directly, if you are going to connect a USB hard

disk.

Note: When viewing image les the Media Browser

menu can only display 1000 image les stored on the

connected USB device.

Media Browser

You can play back music and movie les and

display photo les stored on a USB storage

device by connecting it to your TV. Connect a

USB storage device to one of the USB inputs

located on the side of the TV.

After connecting a USB storage device to your

TV Media Browser menu will be displayed on

the screen. You can access the content of the

connected USB device any time later from the

Sources menu. Select the related USB input

option from this menu and press OK. Then select

the le of your choice and press OK to display

or play it back.

You can set your Media Browser preferences

by using the Settings menu. Settings menu

can be accessed via the information bar which

is displayed on the bottom of the screen when

pressed the Info button while playing back a

video le or displaying a picture le. Press the

Info button, highlight the gear wheel symbol

positioned on the right side of the information

bar and press OK. Picture Settings, Sound

Settings, Media Browser Settings and Options

menus will be available. The contents of these

menus may change according to the type of the

currently open media le. Only Sound Settings

menu will be available while playing back audio

les.

English - 18 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Loop/Shufe Mode Operation

Start playback and activate

All les in the list will be

continuously played in

original order

Start playback and activate

The same le will be

played continuously

(repeat)

Start playback and activate

All les in the list will be

played once in random

order

Start playback and activate

All les in the list will be

continuously played in

the same random order

To use the functions on the information bar

highlight the symbol of the function and press OK.

To change the status of a function highlight the

symbol of the function and press OK as much as

needed. If the symbol is marked with a red cross,

that means it is deactivated.

FollowMe TV

With your mobile device you can stream the

current broadcast from your smart TV using the

FollowMe TV feature. Install the appropriate

Smart Center application to your mobile device.

Start the application.

For further information on using this feature refer

to the instructions of the application you use.

Note: Depending on model, your TV may not support

this function. The application may not be compatible

with all mobile devices. Both of the devices must be

connected to the same network.

CEC

This function allows to control the CEC-enabled

devices, that are connected through HDMI ports

by using the remote control of the TV.

The CEC option in the Settings>System>More

menu should be set as Enabled at rst. Press

the Source button and select the HDMI input of

the connected CEC device from the Sources

List menu. When new CEC source device is

connected, it will be listed in source menu with its

own name instead of the connected HDMI ports

name(such as DVD Player, Recorder 1 etc.).

The TV remote is automatically able to perform the

main functions after the connected HDMI source has

been selected. To terminate this operation and control

the TV via the remote again, press and hold the “0-

Zero” button on the remote control for 3 seconds.

You can disable the CEC functionality by setting the

related option under the Settings>System>More

menu accordingly.

The TV supports ARC (Audio Return Channel).

This feature is an audio link meant to replace

other cables between the TV and an audio system

(A/V receiver or speaker system).

When ARC is active, the TV does not mute its

other audio outputs automatically. You will need

to decrease TV volume to zero manually if you

wish to hear the ARC audio only (same as optical

or co-axial digital audio outputs). If you want to

change connected device’s volume level, you

should select that device from the source list.

In that case volume control keys are directed to

connected audio device.

Note: ARC is supported only via the HDMI2 input.

System Audio Control

Allows an Audio Amplier/Receiver to be used

with the TV. The volume can be controlled

using the remote control of the TV. To activate

this feature set the Speakers option in the

Settings>System>More menu as Amplier.

The TV speakers will be muted and the sound

of the watched source will be provided from the

connected sound system.

Note: The audio device should support System Audio

Control feature and CEC option should be set as

Enabled.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 19 -

Settings Menu Contents

Picture Menu Contents

Mode

You can change the picture mode to suit your preference or requirements. Picture mode can

be set to one of these options: Cinema, Game(optional), Sports, Dynamic and Natural.

Contrast

Adjusts the light and dark values on the screen.

Brightness

Adjusts the brightness values on the screen.

Sharpness

Sets the sharpness value for the objects displayed on the screen.

Colour

Sets the colour value, adjusting the colours.

Energy Saving

For setting the Energy Saving to Custom, Minimum, Medium, Maximum, Auto,

Screen Off or Off.

Note: Available options may differ depending on the selected Mode.

Backlight

This setting controls the backlight level. The backlight function will be inactive if the

Energy Saving is set to an option other than Custom.

Advanced Settings

Dynamic

Contrast

You can change the dynamic contrast ratio to desired value.

Noise Reduction

If the signal is weak and the picture is noisy, use the Noise Reduction setting to reduce

the amount of noise.

Colour Temp

Sets the desired colour temperature value. Cool, Normal, Warm and Custom options

are available.

White Point

If the Colour Temp option is set as Custom, this setting will be available. Increase the

‘warmth’ or ‘coolness’ of the picture by pressing Left or Right buttons.

Picture Zoom

Sets the desired image size format.

Picture Shift

This option may be available depending on the Picture Zoom setting. Highlight and

press OK, then use directional buttons to shift the picture upwards or downwards.

Film Mode

Films are recorded at a different number of frames per second to normal television programmes.

Turn this feature on when you are watching lms to see the fast motion scenes clearly.

Skin Tone

Skin tone can be changed between -5 and 5.

Colour Shift

Adjust the desired colour tone.

HDMI Full Range

While watching from a HDMI source, this feature will be visible. You can use this feature

to enhance blackness in the picture.

Dolby Vision

Notication

Sets the notication appearance preference for Dolby Vision contents. When set as On,

Dolby Vision logo will be displayed on the lower right side of the screen when Dolby

Vision content is detected.

PC Position

Appears only when the input source is set to VGA/PC.

Autoposition

Automatically optimizes the display. Press OK to optimize.

H Position

This item shifts the image horizontally to the right hand side or left hand side of the screen.

V Position

This item shifts the image vertically towards the top or bottom of the screen.

Dot Clock

Dot Clock adjustments correct the interference that appear as vertical banding in dot

intensive presentations like spreadsheets or paragraphs or text in smaller fonts.

Phase

Depending on the input source(computer etc.) you may see a hazy or noisy picture on

the screen. You can use phase to get a clearer picture by trial and error.

Reset

Resets the picture settings to factory default settings (except Game mode).

While in VGA (PC) mode, some items in Picture menu will be unavailable. Instead, VGA mode settings will be added to the Picture menu

while in PC mode.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 20 -

Sound Menu Contents

Volume

Adjusts the volume level.

Equalizer

Selects the equalizer mode. Custom settings can be made only when in User mode.

Balance

Adjusts whether the sound comes from the left or right speaker.

Headphone

Sets headphone volume.

Please ensure before using headphones that the headphone volume is set to a low

level, to prevent damage to your hearing.

Sound Mode

You can select a sound mode (If the viewed channel supports).

AVL (Automatic

Volume Limiting)

Sets the sound to obtain xed output level between programmes.

Headphone/Lineout

When you connect an external amplier to your TV using the headphone jack, you can

select this option as Lineout. If you have connected headphones to the TV, set this

option as Headphone.

Please ensure before using headphones that this menu item is set to Headphone. If it

is set to Lineout, the output from the headphone socket will be set to maximum which

could damage your hearing.

Dynamic Bass

Enables or disables the Dynamic Bass.

DTS TruSurround HD

Enables or disables the DTS TruSurround HD.

Digital Out

Sets digital out audio type.

Network Menu Contents

Network Type

Disable the network connection or change the connection type.

Scan Wireless

Networks

Start a search for wireless networks. This option will be available if the Network Type

is set as Wireless Device.

Press WPS on your

wi router

If your modem/router device has WPS, you can directly connect to it using this option.

Highlight this option and press OK. Go to your modem/router device and press the

WPS button on it to make the connection. This option will be available if the Network

Type is set as Wireless Device.

Internet Speed Test

Start a speed test to check your connection bandwidth. The result will be displayed on

the screen when nished.

Advanced Settings

Change the IP and DNS congurations of your TV.

Wake On

Enable or disable this feature by setting it as On or Off.

Note: For detailed information on the options of this menu refer to the Connectivity section.

Installation Menu Contents

Automatic channel

scan (Retune)

Displays automatic tuning options. D. Aerial: Searches and stores aerial DVB stations.

D. Cable: Searches and stores cable DVB stations.

Manual channel

scan

This feature can be used for direct broadcast entry.

Network channel

scan

Searches for the linked channels in the broadcast system. D. Aerial: Searches for aerial

network channels. D. Cable: Searches for cable network channels.

Installation Settings

(*)

Displays installation settings menu. Standby Search (**): Your TV will search for new or

missing channels while in standby. Any new found broadcasts will be shown. Dynamic

Channel Update(**): If this option is set as Enabled, the changes on the broadcasts

such as frequency, channel name, subtitle language etc., will be applied automatically

while watching.

(**) Availability depends on model.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 21 -

Clear Service List (*)

Use this setting to clear channels stored. This setting is visible only when the Country

option is set to Denmark, Sweden, Norway or Finland.

Select Active

Network (*)

This setting allows you to select only the broadcasts within the selected network to be

listed in the channel list. This feature is available only for the country option of Norway.

Signal Information

You can use this menu item to monitor signal related information such as signal level/

quality, network name etc for available frequencies.

First time installation

Deletes all stored channels and settings, resets TV to factory settings.

(*) These features may not be available depending on the model of your TV and the selected country in the First Time Installation.

System Menu Contents

Conditional Access

Controls conditional access modules when available.

Language

You may set a different language depending on the broadcaster and the country.

Privacy Settings (*)

Manage your privacy privileges for smart TV related applications. Press OK to enter

the menu and set according to your preferences.

Parental

Enter correct password to change parental settings. You can easily adjust Menu Lock,

Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN

or change the Default CICAM PIN using the related options.

Note: Some menu options may not be available depending on the country selection in the First Time

Installation. Default PIN could have been set to 0000 or 1234. If you have dened the PIN(is requested

depending on the country selection) during the First Time Installation use the PIN that you have dened.

Date/Time

Sets date and time.

Sources

Edit the names, enable or disable selected source options. There are also Regular,

Enhanced and Disabled options available for HDMI sources. Regular and Enhanced

options are affecting the colour settings of the selected HDMI source. To be able to

watch 4K or HDR/HLG images from an HDMI source related source setting should be

set as Enhanced if the connected device is compatible with HDMI 2.0 and subsequent

versions. Set as Regular if the connected device is HDMI 1.4 compatible. Set accordingly

or disable the related HDMI source by setting as Disabled.

Accessibility

Displays accessibility options of the TV.

Hard of Hearing

Enables any special feature sent from the broadcaster.

Audio

Description

A narration track will be played for the blind or visually impaired audience. Press OK

to see all available Audio Description menu options. This feature is available only if

the broadcaster supports it.

Netix

If this feature is supported by your TV, you can view your ESN(*) number and deactivate

Netix.

(*) ESN number is an unique ID number for Netix, created especially to identify your TV.

Note: For 4K video streaming, a minimum 25Mb/s internet connection speed is required – For an

example of the requirements for streaming 4K content you may find more information on the Netflix

website (https://help.netflix.com/en/node/13444). When you start to stream video content via the

internet the quality of your connection will be analysed and the full HD or 4K quality may take a

short time to be realised, or in the event of a slow connection not be possible. You should check

your internet capabilities with your internet provider if you are at all unsure.

Displays other setting options of the TV.

Menu Timeout

Changes timeout duration for menu screens.

Standby LED

If set as Off the standby LED will not light up when the TV is in standby mode.

HBBTV (*)

You can enable or disable this feature by setting it as On or Off.

Software

Upgrade

Ensures that your TV has the latest rmware. Press OK to see the menu options.

Application

Version

Displays current software version.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 22 -

Subtitle Mode (*)

This option is used to select which subtitle mode will be on the screen (DVB subtitle /

Teletext subtitle) if both is available. Default value is DVB subtitle. This feature is available

only for the country option of Norway.

Auto TV OFF

Sets the desired time for the TV to automatically go into standby mode when not being

operated. This option can be set from 1 to 8 hours in steps of 1 hour. You can also

disable this option by setting as Off.

Store Mode

Select this mode for store display purposes. Whilst Store Mode is enabled, some items

in the TV menu may not be available.

AVS (Audio

Video Sharing)

AVS feature allows you to share les stored on your smartphone or tablet pc. If you have

a compatible smartphone or tablet pc and the appropriate software is installed, you can

share/play photos on your TV. See instructions of your sharing software for more information.

Power Up Mode

This setting congures the power up mode preference. Last State and Standby options

are available.

Virtual Remote

Enable or disable the virtual remote feature.

CEC

With this setting you can enable and disable CEC functionality completely. Press Left

or Right button to enable or disable the feature.

CEC Auto Power

This function allows the connected HDMI-CEC compatible device to turn on the TV

and switch to its input source automatically. Press Left or Right button to enable or

disable the feature.

Speakers

To hear the TV audio from the connected compatible audio device set as Amplier.

You can use the remote control of the TV to control the volume of the audio device.

Show All Cookies

(*)

Displays all saved cookies.

Delete All Coo-

kies (*)

Deletes all saved cookies.

OSS

Displays Open Source Software license information.

(*) These features may not be available depending on the model of your TV and the selected country in the First Time Installation.

English - 23 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

General TV Operation

Using the Channel List

The TV sorts all stored stations in the channel list.

You can edit this channel list, set favourites or set

active stations to be listed by using the Channels

menu options. Press the OK button to open the

channel list. You can lter the listed channels or

make advanced changes in the current list using

the Filter and Edit tab options. Highlight the tab

you want and press OK to see available options.

Managing the Favourite Lists

You can create four different lists of your favourite

channels. Enter the TV>Channels menu or press

the OK button in order to open the Channels

menu. Highlight the Edit tab and press OK to

see the editing options and select the Tag/Untag

channel option. Select the desired channel on the

list by pressing the OK button while the channel is

highlighted. You can make multiple choices. You

can also use the Tag/Untag all option to select

all channels on the list. Then press Back/Return

button to return to the Edit menu options. Select

Add/Remove Favourites option and press the

OK button again. Favourite channel list options

will be displayed. Set the desired list option to On.

The selected channel/s will be added to the list.

In order to remove a channel or channels from a

favourite list follow the same steps and set the

desired list option to Off.

You can use the ltering function in the Channels

menu to lter the channels in the channel list

permanently according to your preferences.

For instance, using the options of the Filter tab,

you can set one of your four favourite lists to be

displayed every time the channel list is opened.

Conguring Parental Settings

The Parental menu options can be used

to prohibit users from viewing of certain

programmes, channels and using of menus.

These settings are located in the Settings>

System>Parental menu.

To display parental lock menu options, a PIN

should be entered. After coding the correct PIN,

Parental menu will be displayed.

Menu Lock: This setting enables or disables

access to all menus or installation menus of

the TV.

Guidance: This setting enables or disables

access some of the MHEG applications. Disabled

applications can be released by entering the

right PIN.

Internet Lock (*): If this option is set to ON, the

internet using applications will be disabled. Set to

OFF to release these applications again.

(*) This feature may not be available depending on the

model of your TV and the selected country in the First

Time Installation.

Set PIN: Denes a new PIN number.

Default CICAM PIN: This option will appear as

greyed out if no CI module is inserted into the CI

slot of the TV. You can change the default PIN of

the CI CAM using this option.

Note: Default PIN could have been set to 0000 or 1234.

If you have dened the PIN(is requested depending on

the country selection) during the First Time Installation

use the PIN that you have dened.

Some options may not be available depending on the

model and/or on the country selection in the First Time

Installation.

Electronic Programme Guide

By means of electronic programme guide function

of your TV you can browse the event schedule of

the currently installed channels on your channel

list. It depends on the related broadcast whether

this feature is supported or not.

To access the programme guide, press the Guide

button on your remote. You can also use the Guide

option under TV menu.

There are 2 different types of schedule layouts

available, Timeline Schedule and Now/Next. To

switch between these layouts highlight the tab with

the name of the alternative layout on the upper

side of the screen and press OK.

Use the directional buttons to navigate through the

programme guide. Use the Back/Return button to

use the tab options on the upper side of the screen.

Timeline Schedule

In this layout option, all events of the listed

channels will be displayed by timeline. You can

use the directional buttons to scroll through the list

of the events. Highlight an event and press OK to

display event options menu.

Press Back/Return button to use available tab

options. Highlight Filter tab and press OK to

see the ltering options. To change the layout

highlight Now/Next and press OK. You can use

English - 24 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

the Previous Day and Next Day options to display

the events of the previous and next day.

Highlight Extras tab and press OK to access

below options.

Highlight Genre: Displays Highlight Genre

menu. Select a genre and press OK. The events

in the programme guide matching the selected

genre will be highlighted.

Guide Search: Displays searching options.

Using these options, you can search the

programme guide database in accordance

with the selected criteria. Matching results will

be listed.

Now: Displays current event of the highlighted

channel.

Zoom: Highlight and press OK to see events in

a wider time interval.

Now/Next Schedule

In this layout option, only the current and next

events of the listed channels will be displayed. You

can use the directional buttons to scroll through

the list of the events.

Press Back/Return button to use available tab

options. Highlight Filter tab and press OK to see

the ltering options. To change the layout highlight

Timeline Schedule and press OK.

Event Options

Use the directional buttons to highlight an event

and press OK button to display Options menu.

The following options are available.

Select Channel: Using this option, you can switch

to the selected channel in order to watch it. The

programme guide will be closed.

More Info: Display detailed information on the

selected event. Use up and down directional

buttons to scroll through the text.

Set Timer on Event / Delete Timer on Event:

Select Set Timer on Event option and press OK.

You can set timers for future events. To cancel an

already set timer, highlight that event and press the

OK button. Then select Delete Timer on Event

option. The timer will be cancelled.

Notes: You cannot switch to any other channel while there

is an active timer on the current channel.

It is not possible to set timer for two or more individual

events at the same time interval.

Integrated Catch-Up Services

You can enjoy Freeview Play catch-up TV

services that work directly through the electronic

programme guide. Whilst you are on a channel

use the directional buttons to scroll back in time

through the timeline-based guide. You will see

contents from last few days. Available catch-up

contents may change according to broadcasters

and will be marked with a play icon. Highlight the

content you want to play back and press the OK

button.

Make sure that your TV is connected to your home

network in order to use the catch-up services. For

further information regarding this matter and other

requirements for Freeview Play services refer to

the Connectivity and Freeview Play Platform

sections.

Teletext Services (where available)

Press the Text button to enter. Press again to

activate mix mode, which allows you to see the

teletext page and the TV broadcast at the same

time. Press once more to exit. If available, sections

in the teletext pages will become colour-coded and

can be selected by pressing the coloured buttons.

Follow the instructions displayed on the screen.

Digital Teletext

Press the Text button to view digital teletext

information. Operate it with the coloured buttons,

cursor buttons and the OK button. The operation

method may differ depending on the contents

of the digital teletext. Follow the instructions

displayed on the digital teletext screen. When

the Text button is pressed again, the TV returns

to television broadcast.

MHEG Teletext

With digital terrestrial broadcasting (DVB-T),

in addition to pictures and sound, you can also

view digital teletext. Digital teletext is sometimes

broadcast at the same time with the normal

broadcasting.

• Press the Text or Red button

• The digital teletext information appears

• Operate it with the coloured buttons, directional

buttons and OK button

The operation method may differ depending on

the contents of the digital teletext. Follow the

instructions displayed on digital teletext screen.

Press the Text button to returs to television

broadcast.

BBC Red Button+ (RB+)

While watching BBC channels, press the Red

button or Text button to access Red Button+

English - 25 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

services provided by the BBC. On the opening

page you can access to BBC’s main services

such as BBC iPlayer, BBC News, BBC Sport and

many others. There are also links to the home

pages of the related applications available. Use

the navigation buttons on the TV’s remote control

to move through the application. Press Exit button

to close and exit.

Software Upgrade

Your TV is capable of nding and updating the

rmware automatically via the broadcast signal

or via Internet.

Software upgrade search via user

interface

On the main menu select Settings>System

and then More. Navigate to Software upgrade

and press the OK button. Then select Scan for

upgrade and press OK button to check for a new

software upgrade.

If a new upgrade is found, it starts to download

the upgrade. After the download is completed,

a warning will be displayed, press OK button to

complete software upgrade process and restart

TV.

3 AM search and upgrade mode

Your TV will search for new upgrades at 3:00

o’clock if Automatic scanning option is set to

Enabled and if the TV is connected to an aerial

signal or to Internet. If a new software is found and

downloaded successfully, it will be installed at the

next power on.

Note: Do not unplug the power cord while led is blinking

during the reboot process. If the TV fails to come on

after the upgrade, unplug, wait for two minutes then

plug it back in.

All updates are automatically controlled. If a manual

search is carried out and no software is found then this

is the current version.

Troubleshooting & Tips

TV will not turn on

Make sure the power cord is plugged in securely

to a wall outlet. Press the Power button on the TV.

Poor picture

• Check if you have correctly tuned the TV.

• Low signal level can cause picture distortion.

Please check antenna connections.

• Check if you have entered the correct channel

frequency if you have performed manual tuning.

No picture

• TV is not receiving any signal. Make sure the

correct source has been selected.

• Is the antenna connected properly?

• Is the antenna cable damaged?

• Are suitable plugs used to connect the antenna?

• If you are in doubt, consult your dealer.

No sound

• Check if the TV sound is muted. Press the Mute

button or increase the volume to check.

• Sound may be coming from only one speaker.

Check the balance settings from Sound menu.

Remote control - no operation

• The batteries may be exhausted. Replace the

batteries.

• The batteries maybe inserted incorrectly. Refer

to the section “Inserting the Batteries into the

Remote”.

No signal on an input source

• It is possible that no device is connected.

• Check the AV cables and connections from

your device.

• Check the device is switched on.

To Program Your SKY Remote For Your TV

1. Make sure your SKY box is connected to

your TV

2. Turn your TV and SKY box on

3. Press TV on your SKY remote control handset

4. Hold down SELECT and the RED button

together for about two seconds, until the red

light on the SKY remote blinks twice.

5. Key in 1177 on your SKY remote. The light on

the SKY remote should blink twice

6. Press the STANDBY button on your SKY

remote control. Your TV should now switch off.

7. Press SELECT again. The light on your SKY

remote control should now blink twice

You should now be able to control some basic

functions on your TV from your SKY remote control

(e.g. volume up/down, programme up/down).

*If this number does not work, please go to SKY website

to nd the alternative number to operate the TV.

English - 26 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

PC Input Typical Display Modes

The following table is an illustration of some of

the typical video display modes. Your TV may not

support all resolutions.

Index Resolution Frequency

1 640x350 85Hz

2 640x480 60Hz

3 640x480 72Hz

4 640x480 75Hz

5 800x600 56Hz

6 800x600 60Hz

7 800x600 72Hz

8 800x600 75Hz

9 1024x768 60Hz

10 1024x768 70Hz

11 1024x768 75Hz

12 1024x768 85Hz

13 1152x864 75Hz

14 1280x768 60Hz

15 1280x768 75Hz

16 1280x960 60Hz

17 1280x960 75Hz

18 1280x1024 60Hz

19 1280x1024 75Hz

20 1360x768 60Hz

21 1366x768 60Hz

22 1400x1050 59Hz

23 1400x1050 60Hz

24 1400x1050 75Hz

25 1440x900 60Hz

26 1440x900 75Hz

27 1600x1200 60Hz

28 1680x1050 59Hz

29 1680x1050 60Hz

30 1920x1080 60Hz

AV and HDMI Signal Compatibility

Source

Supported Signals

Available

Back AV

PAL O

SECAM O

NTSC4.43 O

NTSC3.58 O

YPbPr

480i, 480p 60Hz O

576i, 576p 50Hz O

720p 50Hz,60Hz O

1080i 50Hz,60Hz O

HDMI

480i 60Hz O

480p 60Hz O

576i, 576p 50Hz O

720p 50Hz,60Hz O

1080i 50Hz,60Hz O

1080p

24Hz,

25Hz,

30Hz,

50Hz,

60Hz

3840x2160p

24Hz,

25Hz,

30Hz,

50Hz,

60Hz

4096x2160p

24Hz,

25Hz,

30Hz,

50Hz,

60Hz

(X: Not Available, O: Available)

In some cases a signal on the TV may not be

displayed properly. The problem may be an

inconsistency with standards from the source

equipment (DVD, Set-top box, etc. ). If you do

experience such a problem please contact your

dealer and also the manufacturer of the source

equipment.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 27 -

Supported File Formats for USB Mode

Video File Formats

Video Codec Resolution Bit Rate Container

MPEG1/2

1080Px2@30fps,

1080P@60fps

40Mbps

MPEG program stream (.DAT, .VOB, .MPG, .MPEG), MPEG

transport stream (.ts, .trp, .tp), MP4 (.mp4, .mov), 3GPP (.3gpp,

.3gp), AVI (.avi), MKV (.mkv), ASF (.asf)

MPEG4

MPEG program stream (.MPG, .MPEG), MP4 (.mp4, .mov),

3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf)

XviD MP4 (.mp4, .mov), AVI (.avi), MKV (.mkv), ASF (.asf)

Sorenson H.263 FLV (.v), AVI (.avi), SWF(.swf)

H.263 MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv)

H.264

3840x2160@30fps,

1080P@60fps

135Mbps

FLV (.v), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), MPEG

transport stream (.ts, .trp, .tp), ASF (.asf), AVI (.avi), MKV (.mkv)

Motion JPEG 720P@30fps 10Mbps

AVI (.avi), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov), MKV (.mkv),

ASF (.asf)

VP8 1080P@30fps 20Mbps MKV (.mkv), WebM (.webm)

HEVC/H.265

4K2K@60fps 100Mbps

MP4 (.mp4, .mov), MKV (.mkv), MPEG transport stream (.ts, .trp,

.tp)

1080P@60fps 50Mbps

MP4 (.mp4, .mov), MKV (.mkv), MPEG transport stream (.ts, .trp,

.tp), 3GPP (.3gpp, .3gp)

VP9 4K2K@30fps 100Mbps MKV (.mkv), WebM (.webm)

Picture File Formats

Image Photo Resolution (width x height)

JPEG

Base-line 15360x8640

Progressive 1024x768

PNG

non-interlace 9600x6400

interlace 1200x800

BMP 9600x6400

Audio File Formats

Audio Codec Sample rate Bit Rate Container

MPEG1/2 Layer1 16KHz ~ 48KHz

32Kbps ~

448Kbps

MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka),

MPEG transport stream (.ts, .trp, .tp), MPEG program stream

(.DAT, .VOB, .MPG, .MPEG), WAV (.wav)

MPEG1/2 Layer2 16KHz ~ 48KHz

8Kbps ~

384Kbps

MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka),

MPEG transport stream (.ts, .trp, .tp), MPEG program stream

(.DAT, .VOB, .MPG, .MPEG), WAV (.wav)

MPEG1/2 Layer3 16KHz ~ 48KHz

8Kbps ~

320Kbps

MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), 3GPP

(.3gpp, .3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream

(.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG,

.MPEG), FLV (.v), WAV (.wav), SWF (.swf)

AC3

32KHz, 44.1KHz,

48KHz

32Kbps ~

640Kbps

AC3 (.ac3), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp,

.3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp,

.tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG)

EAC3

32KHz, 44.1KHz,

48KHz

32Kbps ~ 6

Mbps

EAC3 (.ec3), 3GPP (.3gpp, .3gp), MP4 (.mp4, .mov, m4a),

MPEG transport stream (.ts, .trp, .tp), MPEG program stream

(.DAT, .VOB, .MPG, .MPEG)

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 28 -

Audio Codec Sample rate Bit Rate Container

AAC, HEAAC 8KHz ~ 48KHz

AAC (.aac), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp,

.3gp), MP4 (.mp4, .mov, m4a), MPEG transport stream (.ts, .trp,

.tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG), FLV

(.v), RM (.ra)

WMA 8KHz ~ 48KHz

128bps ~

320Kbps

ASF (.wma, .asf), AVI (.avi), Matroska (.mkv, .mka)

WMA 10 Pro M0 48KHz < 192kbps

WMA 10 Pro M1 48KHz < 384kbps

WMA 10 Pro M2 96KHz < 768kbps

G711 A/mu-law 8KHz

64Kbps ~

128Kbps

WAV (.wav), AVI (.avi), Matroska (.mkv, .mka), 3GPP (.3gpp,

.3gp), MP4 (.mp4, .mov, m4a)

LBR (cook)

8KHz, 11.025KHz,

22.05KHz, 44.1KHz

6Kbps ~

128Kbps

RM (.ra)

FLAC 8KHz~96KHz < 1.6Mbps Matroska (.mkv, .mka)

Subtitle File Formats

Internal Subtitles

Extension Container Subtitle Code

dat, mpg, mpeg, vob MPG, MPEG DVD Subtitle

ts, trp, tp TS DVB Subtitle

mp4 MP4

DVD Subtitle

UTF-8 Plain Text

mkv MKV

ASS

SSA

UTF-8 Plain Text

VobSub

DVD Subtitle

avi

AVI (1.0, 2.0),

DMF0,1, 2

XSUB

XSUB+

External Subtitles

Extension Subtitle Parser Remark

.srt Subrip

.ssa/ .ass SubStation Alpha

.smi SAMI

.sub

SubViewer

MicroDVD

DVDSusbtitleSystem

SubIdx (VobSub)

SubViewer 1.0 & 2.0 Only

.txt TMPlayer

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 29 -

Supported DVI Resolutions

When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable

- not supplied), you can refer to the following resolution information.

56Hz 60Hz 66Hz 70Hz 72Hz 75Hz

640x480

x x

800x600

x x x

1024x768

x x x

1280x768

x x

1280x960

1360x768

1366x768

1280x1024

x x x

1400x1050

1600x900

1920x1080

English - 30 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Connectivity

Wired Connectivity

To Connect to a Wired Network

• You must have a modem/router connected to

an active broadband connection.

• Connect your TV to your modem/router via an

Ethernet cable. There is a LAN port at the rear

(back) of your TV.

1. Broadband ISP connection

2. LAN (Ethernet) cable

3. LAN input on the rear side of the TV

To configure wired settings refer to the

Network section in the Settings menu.

• You might be able to connect your TV to your

LAN depending on your network’s conguration.

In such a case, use an Ethernet cable to

connect your TV directly to the network wall

outlet.

1. Network wall socket

2. LAN input on the rear side of the TV

Conguring Wired Device Settings

Network Type

The Network Type can be selected as Wired

Device, Wireless Device or Disabled, in

accordance with the active connection to the

TV set. Select this as Wired Device if you are

connecting via an Ethernet cable.

Internet Speed Test

Highlight Internet Speed Test and press the

OK button. TV will check the internet connection

bandwidth and display the result when complete.

Advanced Settings

Highlight Advanced Settings and press the OK

button. On the next screen you can change the IP

and DNS settings of the TV. Highlight the desired

one and press Left or Right button to change the

setting from Automatic to Manual. Now you

can enter the Manual IP and / or Manual DNS

values. Select the related item in the drop down

menu and enter the new values using the numeric

buttons of the remote. Highlight Save and press

the OK button to save settings when complete.

Wireless Connectivity

To Connect to a Wireless Network

The TV cannot connect to the networks with

a hidden SSID. To make your modem’s SSID

visible, you should change your SSID settings

via the modem’s software.

1. Broadband ISP connection

A Wireless-N router (IEEE 802.11a/b/g/n) with

simultaneous 2.4 and 5 GHz bands is designed

to increase bandwidth. These are optimized for

smoother and faster HD video streaming, le

transfers and wireless gaming.

• The frequency and channel differ depending

on the area.

• The transmission speed differs depending

on the distance and number of obstructions

between the transmission products, the

conguration of these products, the radio wave

English - 31 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

conditions, the line trafc and the products

that you use. The transmission may also be

cut off or may get disconnected depending on

the radio wave conditions, DECT phones or

any other Wi-Fi 11b appliances. The standard

values of the transmission speed are the

theoretical maximum values for the wireless

standards. They are not the actual speeds of

data transmission.

• The location where the transmission is most

effective differs depending on the usage

environment.

• The Wireless feature of the TV supports

802.11 a,b,g & n type modems. It is highly

recommended that you should use the IEEE

802.11n communication protocol in order to

avoid any possible problems while watching

videos.

• You must change your modem’s SSID when

there are any other modems around with the

same SSID. You can encounter connection

problems otherwise. Use a wired connection

if you experience problems with a wireless

connection.

Conguring Wireless Device Settings

Open the Network menu and select Network

Type as Wireless Device to start connection

process.

Highlight Scan Wireless Networks option and

press OK to start a search for available wireless

networks. All found networks will be listed.

Highlight your desired network from the list and

press OK to connect.

Note: If the modem supports N mode, you should set

N mode settings.

If the selected network is password-protected,

enter the correct key by using the virtual

keyboard. You can use this keyboard via the

directional buttons and the OK button on the

remote control.

Wait until the IP address is shown on the screen.

This means that the connection is now

established. To disconnect from a wireless

network, highlight Network Type and press Left

or Right buttons to set as Disabled.

If your router has WPS, you can directly connect

to the modem/router without entering a password

or adding the network rst. Highlight Press WPS

on your wi router option and press OK. Go to

your modem/router device and press the WPS

button on it to make the connection. You will see

a connection conrmation on your TV once the

devices have paired. Select OK to proceed. No

further conguration is required.

Highlight Internet Speed Test and press the OK

button to check your internet connection speed.

Highlight Advanced Settings and press the OK

button to open the advanced setting menu. Use

directional and numeric buttons to set. Highlight

Save and press the OK button to save settings

when complete.

Other Information

The status of the connection will be displayed as

Connected or Not Connected and the current IP

address, if a connection is established.

Connecting to your mobile device via

Wi-Fi

• If your mobile device has Wi-Fi feature, you

can connect it to your TV via a router, in order

to access the content in your device. For this,

your mobile device must have an appropriate

sharing software.

Connect your TV to your router following the

steps mentioned in the sections above.

Afterwards, connect your mobile device to the

router and then activate the sharing software

on your mobile device. Then, select les that

you want to share with your TV.

If the connection is established correctly, you

will be able to access the shared les installed

on your mobile device via the AVS(audio video

sharing) feature of your TV.

Highlight the AVS option in the Sources menu

and press OK, available media server devices

in the network will be displayed. Select your

mobile device and press the OK button to

continue.

• If available, you can download a virtual remote

controller application from the server of your

mobile device application provider.

Note: This feature may not be supported on all mobile

devices.

Wake ON

Wake-on-LAN (WoL) and Wake-on-Wireless LAN

(WoWLAN) are standards that allow a device to

be turned on or woken up by a network message.

The message is sent to the device by a program

English - 32 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

executed on a remote device connected to the

same local area network, such as a smartphone.

Your TV is WoL and WoWLAN compatible. This

feature might be disabled during the First Time

Installation process. To enable this feature set

the Wake On option in the Network menu as

On. It is necessary that both the device, from

which the network message will be sent to the TV,

and the TV are connected to the same network.

Wake On feature is only supported for Android

OS devices and can only be used via YouTube

and Netix applications.

In order to use this feature the TV and the

remote device should be connected at least once

while the TV is on. If the TV is powered off, the

connection should be re-established, the next

time it is switched on. Otherwise this feature will

be unavailable. This does not apply, when the TV

is switched into the standby mode.

If you want your TV to consume less power in

standby mode, you can disable this feature by

setting the Wake On option as Off.

Wireless Display

Wireless Display is a standard for streaming

video and sound content by Wi-Fi Alliance. This

feature provides the ability to use your TV as

wireless display device.

Using with mobile devices

There are different standards which enable

sharing of screens including graphical, video

and audio content between your mobile device

and TV.

Plug the wireless USB dongle to TV rst, if the

TV doesn’t have internal Wi-Fi feature.

Then press the Source button on the remote and

switch to Wireless Display source.

A screen appears stating that the TV is ready

for connection.

Open the sharing application on your mobile

device. These applications are named differently

for each brand, refer to the instruction manual

of your mobile device for detailed information.

Scan for devices. After you select your TV

and connect, the screen of your device will be

displayed on your TV.

Note: This feature can be used only if the mobile device

supports this feature. If you experience problems with

the connection check if the operating system version you

use supports this feature. There may be incompatibility

problems with the operating system versions which are

released after the production of this TV. Scanning and

connecting processes differ according to the programme

you use.

Connectivity Troubleshooting

Wireless Network Not Available

• Ensure that any rewalls of your network allow

the TV wireless connection.

• Try searching for wireless networks again, using

the Network menu screen.

If the wireless network does not function properly,

try using the wired network in your home. Refer

to the Wired Connectivity section for more

information on the process.

If the TV does not function using the wired

connection, check the modem (router). If the

router does not have a problem, check the

internet connection of your modem.

Connection is Slow

See the instruction book of your wireless

modem to get information on the internal service

area, connection speed, signal quality and

other settings. You need to have a high speed

connection for your modem.

Disruption during playback or slow

reactions

You could try the following in such a case:

Keep at least three meters distance from

microwave ovens, mobile telephones, bluetooth

devices or any other Wi-Fi compatible devices.

Try changing the active channel on the WLAN

router.

Internet Connection Not Available /

Audio Video Sharing Not Working

If the MAC address (a unique identier number)

of your PC or modem has been permanently

registered, it is possible that your TV might

not connect to the internet. In such a case, the

MAC address is authenticated each time when

you connect to the internet. This is a precaution

against unauthorized access. Since your TV

has its own MAC address, your internet service

provider cannot validate the MAC address of your

TV. For this reason, your TV cannot connect

to the internet. Contact your internet service

provider and request information on how to

connect a different device, such as your TV, to

the internet.

English - 33 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

It is also possible that the connection may not be

available due to a rewall problem. If you think

this causes your problem, contact your internet

service provider. A rewall might be the reason

of a connectivity and discovery problem while

using the TV in Audio Video Sharing mode or

while browsing via Audio Video Sharing feature.

Invalid Domain

Ensure that you have already logged on to your

PC with an authorized username/password and

also ensure that your domain is active, prior to

sharing any les in your media server program

on your PC. If the domain is invalid, this might

cause problems while browsing les in Audio

Video Sharing mode.

Using Audio Video Sharing Network Service

Audio Video Sharing feature uses a standard that

eases the viewing process of digital electronics

and makes them more convenient to use on a

home network.

This standard allows you to view and play photos,

music and videos stored in the media server

connected to your home network.

1. Server Software Installation

The Audio Video Sharing feature cannot be used

if the server programme is not installed onto your

PC or if the required media server software is not

installed onto the companion device. Prepare

your PC with a proper server programme.

2. Connect to a Wired or Wireless

Network

See the Wired/Wireless Connectivity chapters

for detailed conguration information.

3. Enable Audio Video Sharing

Enter the Settings>System>More menu

and enable the AVS option.

4. Play Shared Files via Media Browser

Highlight the AVS option in the Sources menu

by using the directional buttons and press OK.

Available media server devices in the network will

be listed. Select one and press OK to continue.

The media browser will then be displayed.

Refer to the Media Browser menu section for

further information on le playback.

If a problem occurs with the network, switch your

television off at the wall socket and back on again.

Trick mode and jump are not supported with the

Audio Video Sharing feature.

PC/HDD/Media Player or any other devices

that are compatible should be used with a wired

connection for higher playback quality.

Use a LAN connection for quicker le sharing

between other devices like computers.

Note: There may be some PC’s which may not be

able to utilize the Audio Video Sharing feature due to

administrator and security settings (such as business

PC’s).

Apps

You can access the applications installed on your

TV from Apps menu. Highlight an app and press

OK to launch.

In order to manage the apps installed on your

TV, add new apps from the market or to see all

available apps in full screen mode highlight the

Add More option and press OK. Using this menu

option you can add an installed app to Home

menu, launch or remove it. Removed apps will

no longer be accessible from Apps menu. You

can also add new apps from the market. In order

to enter the market highlight the shopping basket

logo located on the upper left side of the screen

and press OK. Available apps in the market will

be displayed. Use directional buttons to highlight

an app and press OK. Highlight Add to Apps

option and press OK again to add the selected

app to Apps menu.

For quick access to Add More menu you can

press the Internet button on the remote, if this

button is available.

Notes:

Possible application dependent problems may be

caused by the content service provider.

Third party internet services may change, be

discontinued or restricted at any time.

Freeview Play Platform

Freeview Play platform provides catch-up TV and

On Demand services. Simply press the Freeview

Play button on your remote control to connect to

the Freeview Play platform.

The Freeview Play platform can also be accessed

from the Home and Apps menus. Press Menu

button and select Home or Apps. Then highlight

Freeview Play and press the OK button.

You will have to agree to the terms and conditions

for Freeview Play services rst if you did not

agree them during the First Time Installation.

Highlight Yes and press OK on the remote to

conrm and proceed.

English - 34 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

Integrated TV Player applications will be

displayed. Select one and press the OK button.

Then select a content that you want to play back

and press the OK button to watch.

Catch-up contents can also be accessed and

played back directly from the TV Guide. Refer to

the section Electronic Programme Guide for

more information.

Requirements

The Freeview Play services may only be used if

the following requirements are fullled:

• Connecting the TV to the internet. A minimum

broadband speed of 2Mbps is required for

proper operation of catch up and on demand

services.

• Agreeing to the terms and conditions of

Freeview Play

Note: Freeview Play platform usage will count towards

any monthly broadband data allowance. Only selected

channels provide 7-day catch up.

Internet Browser

To use the internet browser, enter the Apps menu

rst. Then launch the internet browser application

which has an orange coloured logo with earth

symbol on it.

In the initial screen of the browser, the thumbnails

of the predefined (if any) links to web sites

available will be displayed as Speed Dial options

along with the Edit Speed Dial and the Add to

Speed Dial options.

To navigate the web browser, use the directional

buttons on the remote or a connected mouse. To

see the browser options bar, move the cursor to

the top of the page or press the Back/Return

button. History, Tabs and Bookmarks options

and the browser bar which contains previous/next

buttons, the refresh button, the address/search

bar, the Speed Dial and the Vewd buttons are

available.

To add a desired website to the Speed Dial list

for quick access, move the cursor to the top of

the page or press the Back/Return button. The

browser bar will appear. Highlight the Speed

Dial -

button and press the OK button. Then

select Add to Speed Dial option and press

the OK button. Fill in the blanks for Name and

Address, highlight OK and press the OK button

to add. Whilst you are on the site you wish to

add to the Speed Dial list, highlight the Vewd

button and press the OK button. Then highlight

Add to Speed Dial option in the submenu and

press the OK button again. Name and Address

will be lled automatically according to the site

you are visiting. Highlight OK and press the OK

button to add.

You can also use the Vewd menu options to

manage the browser. Highlight the Vewd button

and press the OK button to see available page

specic and general options.

There are various ways to search or visit websites

using the web browser.

Enter the address of a website(URL) into the

search/address bar and highlight the Submit

button on the virtual keyboard and press the

OK button to visit the site.

Enter keyword/s into the search/address bar

and highlight the Submit button on the virtual

keyboard and press the OK button to start a

search for the related websites.

Highlight a Speed Dial thumbnail and press the

OK button to visit the related website.

Your TV is compatible with USB mice. Plug your

mouse or wireless mouse adaptor into the USB

input of your TV for easier and quicker navigation.

Some web pages include ash content. These

are not supported by the browser.

Your TV does not support any download

processes from the internet via the browser.

All sites on the internet might not be supported.

According to the site; content problems may

occur. In some circumstances video contents

might not be able to be played.

HBBTV System

HbbTV (Hybrid Broadcast Broadband TV) is a

new industry standard that seamlessly combines

TV services delivered via broadcast with services

delivered via broadband and also enables access

to Internet only services for consumers using con-

nected TVs and set-top boxes. Services delivered

through HbbTV include traditional broadcast TV

channels, catch-up services, video-on-demand,

electronic programme guide, interactive adver-

tising, personalisation, voting, games, social

networking and other multimedia applications.

HbbTV applications are available on channels

where they are signalled by the broadcaster

(currently various channels on Astra broadcast

HbbTV applications).

English - 35 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

HbbTV requires AV streaming capability for

the platform. There are numerous applications

providing VOD (video on demand) and catch-up

TV services. The user can use play, pause, stop,

forward, and rewind keys on the remote control

to interact with the AV content.

Note: You can enable or disable this feature from the

More menu in Settings>System menu. Depending on

the model of your TV and the selected country option in

the First Time Installation this feature might be available

in the Settings>System>Privacy Settings menu

instead of the Settings>System>More menu.

This feature may not be available depending on the

model of your TV and the selected country in the First

Time Installation.

Smart Center

Smart Center is a mobile application running

on iOS and Android platforms. With your tablet

or phone, you can easily stream your favourite

live shows and programmes from your smart

TV. Also; you can launch your applications, use

your tablet as a remote control for your TV and

share media les.

Note: Being able to use all functions of this application

depends on the features of your TV.

Getting Started

To be able to use internet based features, your

modem/router must be connected to the internet.

IMPORTANT: Make sure the TV and mobile

device are connected to the same network.

For media sharing feature Audio Video

Sharing option should be enabled(if available).

Press the Menu button on the remote, select

Settings>System>More menu and press OK.

Highlight AVS and change as Enabled. Your TV

is ready to connect to your mobile device now.

Install the Smart Center application onto your

mobile device.

Start the smart center application. If all

connections are congured properly, you will

see your TV’s name on your mobile device. If

your TV’s name doesn’t appear on the list, wait

a while and tap on the Refresh widget. Select

your TV from the list.

Mobile Device screen

On the main screen you can nd tabs to access

various features.

The application retrieves actual channel list from

TV rst when it starts.

MY CHANNELS: The programmes of rst four

channels from the channel list retrieved from

the TV are shown. You can change the listed

channels. Press on the channel thumbnail and

hold. A list of channels will be displayed and you

can choose your desired channel to be replaced.

TV: You can watch content through the TV tab. In

this mode you can navigate through the channel

list retrieved from your TV and click on thumbnails

to view the detail pages.

RECORDINGS: You can view your active

recordings(if available) and reminders through

this tab. To delete any item, simply press on the

delete icon found on each row.

EPG(Electronic programme guide): You can view

the broadcast schedules of selected channel lists

through this tab. You can also navigate through

channels by pressing on the selected channel

on the EPG grid. Please note that updating /

refreshing the EPG information may take a while

depending on your network and web service

quality.

Note: Internet connection is required for WEB based

EPG informations.

SETTINGS: Congure the application to your

liking. You can change;

Auto-lock (Only in IOS): The screen of the

device automatically turns off after a certain

amount of time. Default is off, which means

the screen will always stay on.

Auto-enable FollowMeTV: FollowMeTV

function (if available) will start automatically

when this setting is enabled. Default is

disabled.

Auto-connection to TV: When enabled, your

mobile device will automatically connect to last

connected TV and skips the TV search screen.

Change TV (Only in IOS): Shows the currently

connected TV. You can press on this setting

to go to the “TV search” screen and change

to a different TV.

Edit custom channel list: You can edit your

custom channel list using this setting.

Choose channel list source:

You can

choose the channel list source to be used in

the application. The options are “TV List” and

“Custom List”. Additionally you can activate

“Remember my choice” option to set the

selected channel list source as a constant

English - 36 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

choice. In this case if the selected source is

available it will be used in the application.

Version No: Displays the current version of

the application.

Detail Page

To open detail page tap on a programme. On

the detail page screen you can get detailed

information of the programmes you select. There

are “Details”, “Cast&Crew” and “Videos” tabs to

nd on this page.

DETAILS: This tab provides summary and

information about the selected programme. Also

there are links to facebook and twitter pages of

the programme selected.

CAST&CREW: Shows all the people contributed

to the current programme.

VIDEOS: Provides videos on Youtube related to

the selected programme.

Note: For some functions an internet connection may

be required.

FollowMe TV Feature (if available)

Tap on the FOLLOW ME TV widget located at the

bottom left of the screen of your mobile device

to change the layout for FollowMe TV feature.

Tap the play icon to start streaming of the content

from the TV to your mobile device. Available if

your device is in your routers operation range.

Mirror Mode

This mode of FollowMe TV feature is enabled by

default and allows streaming the content from any

other selected TV sources and Media Browser.

Notes:

Note that only digital(DVB-T/C/S) SD and HD channels

are supported.

Multilanguage audio support and subtitle on/off features

are not functional.

The streaming performance may change depending on

the quality of your connection.

Media Share Page

To access the Media Share widget tap on the

Up-arrow on the bottom left side of the screen.

If the Media Share widget is pressed, a screen

is displayed where you can select the media le

type to share with your TV.

Note: Not all image le formats are supported. This

function will not work if Audio Video Sharing feature is

not supported.

Smart Remote Feature

You can use your mobile device as a remote

control for your TV once it has connected to the

TV. To use smart remote’s full features tap on the

Up-arrow on the bottom left side of the screen.

Voice Recognition

You can tap on the Microphone( ) widget and

manage your application, giving voice commands

such as “Volume Up/Down!”, “Programme Up/

Down!”.

Note: This feature is only for android based devices

available.

Keyboard Page

The keyboard page can be opened in two ways;

by pressing the Keyboard( ) widget on the

application screen or automatically by receiving

a command from the TV.

Requirements

1. Smart TV

2. Network connection

3. Mobile Device based on Android or iOS

platform (Android OS 4.0 or higher; IOS 6

or higher version)

4. Smart Center app.(to be found on online

application stores based on Android and

iOS platforms)

5. Router modem

6. USB storage device in FAT32 format

(required for USB Recording feature, if

available)

Notes:

For Android devices, Normal(mdpi), Large(hdpi) and

Extra Large(xhdpi) screen sizes are supported. Devices

with 3” or smaller screen sizes are not supported.

For iOS devices, all screen sizes are supported.

User interface of the Smart Center application is subject

to change according to version installed on your device.

DVB functionality information

This DVB receiver is only suitable for use in the

country which it was designed to be used in.

Although this DVB receiver conforms to the latest

DVB specications at the time of manufacture,

we cannot guarantee compatibility with future

DVB transmissions due to changes that may

be implemented in broadcast signals and

technologies.

Some digital television functions may not be

available in all countries.

English - 37 -

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

We continually strive to improve our products;

therefore, specications may change without

prior notice.

For advice on where to purchase accessories,

please contact the store where you purchased

your equipment.

Quick UI Launcher functionality information

The content and services available through the

Quick UI Launcher are provided by third-party

providers and may be altered, suspended or

discontinued at any time without notice.

Hitachi is not responsible for any of the content

or services and does not warrant the availability

of or access to such content or services.

For information on a particular service or on

any content, please visit the service/content

provider’s website. If you have any questions

concerning, or problems with, any content

or services then please contact the relevant

service/content provider directly. Hitachi is not

responsible for providing customer service in

relation to content or services and accepts no

liability in this regard.

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 38 -

Guarantee

This product is guaranteed for twelve months from the date of original purchase.

Any defect that arises due to faulty materials or workmanship will either be replaced,

refunded or repaired free of charge where possible during this period by the dealer

from whom you purchased the unit.

The guarantee is subject to the following provisions:

•

The guarantee does not cover accidental damage, misuse, cabinet parts, knobs

or consumable items.

•

The product must be correctly installed and operated in accordance with the

instructions contained in this manual.

• It must be used solely for domestic purpose.

• The guarantee will be rendered invalided if the product is re-sold or has been

damaged by inexpert repair.

• Specifications are subject to change without notice.

• The manufacturer disclaims any liability for the incidental or consequential damages.

• The guarantee is in addition to, and does not diminish your statutory or legal rights.

• In the event of a problem with the product with in the guarantee period call the

Customer Helpline:

0345 604 0105

Guarantor: Argos Ltd

489 - 499

Avebury Boulevard

Central Milton Keynes

MK9 2NW

For online detailed guides and further assistance please use the link below

https://www.argos-support.co.uk/8038335)

Product Guarantee

This product is guaranteed against manufacturing defects for a period of

Year

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 39 -

Product che

Commercial Brand: HITACHI

Product No.

10117317

Model No.

50HK25T74U

Energy eciency class

A+

Visible screen size

(diagonal,approx.) (inch/cm)

50 inches 127 cm

On mode average power

consumpon (Wa)

71,0

Annual energy consumpon

(kWh/annum)

103

Standby power consumpon

(Wa)

0,50

O mode power consumpon

(Wa)

N/A

Display resoluon (px)

3840x2160

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 40 -

Energy Label

2017

HITACHI

50HK25T74U

103

127 50

50445947

*50445947*

Standby Power Consumption (approx.)

0,5

Screen Resolution

3840 x 2160

Hereby, HITACHI Europe Ltd., declares that the radio equipment type TV is in compliance

with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at

the following internet address: https://estadoc.hitachi.eu/estadoc/index.htm

Hitachi Europe Ltd. Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire.

SL6 8YA. UK

For any help concerning set up and use of your TV please call the Customer Helpline: 0345 604 0105

English - 41 -

VESA WALL MOUNT MEASUREMENTS

Hole Paern

Sizes (mm)

W H

200 200

C Screw Sizes

D Length (X)

min. (mm) 10

max. (mm) 13

E Thread (Y) M6

A B C D E

English

VESA WALL MOUNT MEASUREMENTS

Hole Pattern Sizes (mm) Screw Sizes Length (X) Thread (Y)

Deutsch

MASSANGABEN FÜR VESA-WANDMONTAGE Lochmustergrößen (mm) Schraubengrößen Länge (X) Gewinde (Y)

Français

DIMENSIONS DU SUPPORT DE FIXATION MURALE VESA Dimensions des modèles de trous de montage (mm) Dimensions des vis Longueur (X) Filetage (Y)

Italiano

Misurazioni installazione a parete VESA Dimensioni schema foro (mm) Dimensioni vite Lunghezza (X) Filettatura (Y)

Português

MEDIÇÕES DE MONTAGEM MURAL VESA Dimensões do molde de furação (mm) Tamanhos do parafuso Comprimento (X) Rosca (Y)

Español

MEDIDAS DEL MONTAJE DE PARED VESA

Tamaños de patrón para agujero (mm) Tamaños de tornillo Longitud (X) Rosca (Y)

Türkçe

   Uzunluk (X) 

Eλληvικ



   

Polski

    Gwint (Y)

čeština

    

Magyar

   Hossz (X) Menet (Y)

Română



  Lungime (X) Filet (Y)

Svenska

VESA VÄGGMONTERINGSMÅTT Hålmönsterstorlear (mm) Skruvstorlekar Längd (X) Tråd (Y)

Nederlands

VESA WANDMONTAGE METINGEN

Grootte booropening (mm) Schroefgroote Lengte (X) Draad (Y)

Suomi

  Ruuvinkoot Pituus (x) Kierre (Y)

Norsk

VESA VEGGMONTERINGSMÅL Hullmønster størrelser (mm)  Lengde (x) Tråd (Y)

Dansk

VESA VÆGMONTERINGS-MÅL Hulmønster-størrelser (mm)  Længde(X) Tråd (Y)

Русский

    

беларуская

    

македонски

    

українськa

    

Srpski

  Dimenzije zavrtnjeva  Navoj (Y)

Slovenčina

  Rozmery skrutiek  

Slovenščina

MERE STENSKEGA NOSILCA VESA Velikosti vzorca lukenj (mm) Velikosti vijakov  Navoj (Y)

Hrvatski

    Navoji (Y)

Bosanski

  Dimenzije vijaka  Navoj (Y)

Български



   

Lietuvių

VESA TVIRTINIMO PRIE SIENOS MATAVIMAI   Ilgis (X) Sriegis (Y)

Latviešu

   Garums (X) 

Eesti

  Kruvi suurus  Keere (Y)

Shqip

PËRMASAT E NJËSISË SË MONTIMIT NË MUR VESA

  Gjatësia (X) Filetimi (Y)

يبرع 󰌙󰒰󰒟󰈓󰎞󰐜 VESA󰋔󰈉󰋅󰊒󰐃󰈉 󰢃󰍔 󰉚󰒰󰉄󰉆󰉅󰐊󰐃 󰈚󰑸󰎞󰉆󰐃󰈉 󰐘󰈓󰊒󰊁󰈇 )󰐤󰐜(

󰠾

󰠈

󰡹󰈉

󰠵

󰡣󰐃󰈉 󰐘󰈓󰊒󰊁󰈇 󰏼󰑸󰍄󰐃󰈉 )X( 󰑃󰌎󰐃󰈉 )Y(

תירבע 󰀄󰀈󰀘󰀔 󰀢󰀍󰀠󰀆 󰀑󰀙 󰀆󰀍󰀍󰀑󰀥󰀆 󰀖󰀠󰀥󰀔 󰀥󰀈󰀅󰀍󰀔 VESA 󰀒󰀍󰀢󰀈󰀊󰀆 󰀥󰀈󰀍󰀗󰀃󰀥 󰀑󰀅󰀈󰀄 )󰀔"󰀔( 󰀒󰀍󰀄󰀢󰀃󰀆 󰀑󰀅󰀈󰀄 󰀎󰀢󰀈󰀁 )X( 󰀄󰀍󰀢󰀃󰀥 )Y(

یسراف

󰒐󰋔󰈉󰑸󰒡󰊶 󰏼󰈓󰌰󰈰󰈉 󰒐

󰠶

󰡣󰏊 󰑌󰋕󰈉󰋅󰐱󰈉 VESA 󰉰󰈉󰋔󰑸󰌃 󰒐󰑸󰏞󰐃󰈉 󰒐󰈓󰑐 󰑌󰋕󰈉󰋅󰐱󰈉 )

󰠉

󰡣󰐜 󰢃󰒲󰐜( 󰊬󰒲󰈸 󰒐󰈓󰑐 󰑌󰋕󰈉󰋅󰐱󰈉 󰏼󰑸󰍀 )X( 󰑘󰉅󰌄󰋔 )Y(

Hitachi Q142383 50 Inches Smart Tv 4k Uhd With Hdr

Product's Documents

User Manual

Specifications

Hitachi Q142383 Questions and Answers

Related Products

Hitachi 50HK6100 50 inches 4K Dolby Vision UHD HDR Smart TV
