marvelrefrigeration.com | 616.754.5601
The upper zone features a glide-out 3-in-1 Convertible Shelf that
can store food and beverages or convert to additional wine rack.
The lower zone creates the ideal preservation environment for
wine and glide-out shelving brings your collection to you without
jarring bottles.
24” Marvel Dual Zone
Wine and Beverage
Center
MLBD224
Storage Adaptability
• 5.2 total cu. ft.
• 1.85 cu. ft. upper zone ca
n hold (112) 12-oz cans, (64) longneck bottles
or an additional 6 wine bottles
• 3-in-1 Split Convertible Shelf converts to 3 or 6-bottle wine rack
• 3.27 cu. ft. lower zone stores 16 bottles of wine on (2) 8-bottle
smooth-glide wine racks
• 3/4 extension smooth-glide ball-bearing wine rack system
• Heavy-gauge wire wine racks safely cradle each wine bottle
and prevent jarring
• Vibration Neutralization System protects wine from agitation,
allowing it to come to full maturation
Cooling Performance
• Two independently controlled temperature zones offer dual options
for wine and beverage storage
• Dynamic cooling technology delivers rapid cool down, frost-free operation
and precise temperature stability
• Proprietary shelving design allows for cool air to circulate throughout
each compartment for temperature consistency from top to bottom
• Thermal-efcient cabinet insulates cooling environment and conserves
energy while maximizing capacity
• Argon-lled, UV-resistant tinted dual pane glass door protects contents
from damaging ultraviolet light and helps conserve energy
• Sound-buffering design
Convenient Controls
• Multifunction controls allow you to select a precise temperature
for each zone
• Features easy-to-use settings and options
Warranty
• 1-year parts and labor warranty and 5-year sealed system parts warranty
DOOR STYLE MODEL NUMBER
Stainless Steel Frame Glass
M
LBD224-SG01A
Panel Ready Frame Glass
M
LBD224-IG01A
Solid Panel Ready
M
LBD224-IS01A
Solid Stainless Steel
M
LBD224-SS01A
Fresh Living Tip
If you enjoy having a wide variety of beverages
at hand, this model is perfect for you. The upper
zone stores as many as 112 12-oz cans or 64
longneck bottles. And the lower zone holds 16
wine bottles on two smooth-glide wine racks.
FINISH OPTIONS
Fit & Finish
• Elegant midnight black interior and arctic white LED interior lighting
• Solid black shelf fronts
• Reversible door allows for right or left swing for adaptable installation
• Black toe kick adjustable to 4” with leveling legs
marvelrefrigeration.com | 616.754.5601
For comprehensive installation instructions, including panel overlay
details, please visit marvelrefrigeration.com to access the owner’s guide.
Lock
Electrical Requirements
Cord Length
Shipping Dimensions
Shipping Weight
Agency Approval
Refrigerant Type
No
115V / 60 Hz / 15A
6 FT.
28” W x 31” D x 37” H
160 LBS
UL
R600a
Rough In Dimensions*
“A” “B” “C”
24” 34-1/4” to 35-1/4” 24”
(61 CM) (87 CM to 89.5 CM) (61 CM)
Cabinet Dimensions*
"D" "E" "F" "G" "H" "J"
23-7/8" 33-5/8" TO 34-5/8" 23-5/8"*
25-2
1/32"* 47-3/4"* 26-1/2"*
(60.7 CM) (85.4 CM TO 87.9 CM) (60 CM)
(
65.2 CM) (146.6 CM) (67.3 CM)
*Stainless steel model dimensions only. For panel-ready models, see the owner’s guide online at marvelrefrigeration.com.
Tall item storage
Precise temp
control with alerts
Glide-out 3-in-1
Convertible Shelf
Thermal-efcient
nished cabinet design
Glide-out
wine racks
Reversible door
Arctic white
lighting
H:
33 3/4" W: 23 7/8” D: 25 21/32” (with handle)
Capacity
Control Type
Sabbath Mode
Temperature Range
Handle Style
Hinge Type
Interior Lighting
Shelving System
Toe Grille Finish
5.2 CU. FT.
Electronic
Yes
Upper Zone: 38°F to 65°F, Lower Zone: 33°F to 45°F
Slim (handle not included on panel-ready models)
Reversible
White LED
Smooth Ball-Bearing Glides, Cantilevered (Upper Shelf Only)
Black
