DT150-TUN
OWNER’S MANUAL
Thank you for purchasing
the DynaTrap
®
Insect Trap!
This product may be covered by one or more U.S. patents
or pending patent applications. See www.DynaTrap.com/patents
A000-399.2019.11
UV BULB
TiO
2
COATED
SURFACE
RETAINING
CAGE
FAN
This device complies with Performance Standards
for Light-Emitting Products, 21 DFR, Part 1040,
Chapter 1, Subchapter J, Radiological health.
Dynamic Solutions Worldwide, LLC
U.S.A. & Canada
12247 W. Fairview Ave. Milwaukee, WI 53226
1-877-403-TRAP (8727)
[email protected] | www.DynaTrap.com
Mexico
Dynatrap Servicios de Mexico S. de R. L. de C.V.
01-800-880-8727 | [email protected]
©2019 Dynamic Solutions Worldwide, LLC
4002907
6. SERVICING OF DOUBLE-INSULATED APPLIANCES - In a double-insulated appliance, two systems of
insulation are provided instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added to the appliance. Servicing of a double-
insulated appliance requires extreme care and knowledge of the system and should be done only by
qualified service personnel. Replacement parts for a double-insulated appliance must be identical
to those parts in the appliance. The symbol must be identical to those parts in the appliance.
A double-insulated appliance is marked with the words “DOUBLE INSULATION”, “DOUBLE-INSULATED”
or the symbol:
7. The electrical adapter provided with this product is equipped with a 2-conductor cord and a 2-prong plug
as a safety feature. If the plug does not fully fit in the outlet, contact a qualified electrician. To reduce the
risk of electrical shock, only plug into a properly installed outlet. Do not attempt to defeat this safety
feature.
CLEANING
Frequent cleaning will prolong the life of the unit, ensure fire prevention and provide for more efficient
operation.
1. Be sure to clean the unit at least once per week.
2. Unplug the unit. CAUTION: There may be insects still alive when opening the trap.
3. For weekly cleaning, remove the cage by turning it clockwise.
Remove any buildup from the inside of the retaining cage and fan with a brush.
4. When replacing the retaining cage – DO NOT press/push against the screen windows.
5. Clean prior to storage.
HOW THE DYNATRAP
®
INSECT TRAP WORKS
Flying insects are attracted to the unit by UV light and CO2 that is generated by the photo-catalysis between
the UV lamps and special TiO2 coating. The fan then pulls the insects into the screened base, trapping them
until they dehydrate and die. The base can be removed, allowing the contents to be periodically emptied into
the trash. Monitor the insects trapped in the retaining cage through the see-through screen, and empty when
compartment becomes full.
Problem: Possible cause: Correction:
Bulb does not illuminate
and fan does not spin.
No electrical power. 1. Check plug, receptacle, fuse or circuit breaker.
Bulb illuminates, but fan
does not spin.
Shorted fan. UNPLUG UNIT: Examine fan to see that it is free from
foreign material, dirt or buildup of dead insects.
Clean unit as in “CLEANING” section.
Fan spins, but bulb does
not illuminate.
Burnt out bulb.* The UV-Lamp has an expected lifespan of 20,000 hours and
is not replaceable.
If lamp fails to illuminate before 20,000 hours of operation,
call customer service at 877-403-8727.
TROUBLESHOOTING
IMPORTANT: READ CAREFULLY
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
WARNING: when using electric appliances, basic precautions should
always be followed, including the following:
1. Please read all instructions before using the DynaTrap
®
Insect Trap and keep for future reference.
2. To disconnect remove plug from outlet.
3. To reduce the risk of injury from moving parts or electric shock, always disconnect plug before
servicing or cleaning.
4. Do not position the unit near heat, gas, oil or other flammable materials.
5. Place out of reach from children.
6. To reduce the risk of electrical shock, do not put appliance in water or other liquid.
7. Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or if it has been dropped into water or other liquid.
8. Do not insert fingers or any foreign objects into the unit while it is connected to an electrical outlet.
9. Collected insects within the unit may contribute to fire, so clean insects from the unit frequently.
10. Do not clean this product with water spray. Do not place where it can fall into water, or near
flammable materials.
11. Do not touch fan while in motion.
12. Do not abuse cord—never carry or hang unit by cord or yank it to disconnect from receptacle.
Keep cord away from sharp edges.
13. Use only extension cords that have plug and receptacles that match the product plug.
Replace or repair damaged cords.
14. Only use attachments recommended or sold by the manufacturer.
15. This appliance is provided with double insulation. Use only identical replacement parts.
See instructions or Servicing of Double-Insulated Appliances.
INSTALLATION & OPERATING INSTRUCTIONS
1. Unpack unit. Save carton for off-season storage (if needed).
2. The unit will turn on automatically when plugged in. For best catch results, leave the trap on and
running, 24/7.
3. Catch rate activity will be higher at night. For best catch results it is recommended to keep the unit
away from competing light sources.
4. It is recommended to place the unit at least 20 to 40 feet away from where people will be sitting.
5. This unit is for indoor, household use only.
LIMITED WARRANTY
DYNAMIC guarantees to the original purchaser that this product is free from defective materials and
workmanship. This warranty is limited to remedy any defective part for a period of one year from date of
original date of purchase. Retain your original receipt as proof of purchase. This warranty does not apply
to the light bulb, nor to, in our judgment, misuse or abuse. If this unit has been altered, no warranty is in
force. This warranty does not apply if this unit is purchased outside the United States, Canada and Mexico.
In no case shall DYNAMIC be liable for any accidental, punitive, consequential, or any other damages of
any kind for breach of this or any other warranty, expressed or implied, whatsoever. Some states do not
allow limitation on how long an implied warranty lasts, so the above limitation or exclusion may not apply
to you. This warranty gives you specific legal rights, and you may also have other rights that vary from
state to state.
REPLACEMENT PARTS
41048 Power Supply
41074 Replacement Retaining Cage
To see all replacement and accessory parts available for your DynaTrap, visit www.DynaTrap.com.
FOR HOUSEHOLD, INDOOR USE ONLY
Input: 100-240VAC 50/60 Hz, Output: 12Vdc 1.0A 12VA
