Register your product and get support at
www.philips.com/welcome
EN User manual
47PFL4606H
46PFL5606H
42PFL4x06H
42PFL3x06H
40PFL56x6H
37PFL4606H
32PFL5x06H
32PFL4606H
32PFL3x06H
26PDL49x6H
22PDL49x6H
België/ Belgique
0800 80 190 Gratis/Gratuit
ß chat www.philips.com/support
България
00800 11 544 24
Česká republika
800 142 840 Bezplatný hovor
Danmark
3525 8759 Lokalt opkald
ß chat www.philips.com/support
Deutschland
0800 000 7520 (kostenfrei)
ß chat www.philips.com/support
Ελλάδα
0 0800 3122 1280
Κλήση χωρίς χρέωση
España
900 800 655 Teléfono local gratuito
solamente para clientes en España
ß chat www.philips.com/support
Estonia
8000100288 kohalik kõne tariifi
France
0805 025 510 numéro sans frais
ß chat www.philips.com/support
Hrvatska
0800 222778 free
Ireland
South: 1 800 7445477
North: 0 800 331 6015
Italia
800 088774 Numero Verde
Қазақстан
+7 727 250 66 17 local
Contact information
Latvia
80002794 local
Lithuania
880030483 local
Luxemburg/Luxembourg
080026550
Ortsgespräch/Appel local
Magyarország
06 80 018 189 Ingyenes hívás
Nederland
0800 023 0076 Gratis nummer
Norge
22 70 81 11 Lokalsamtale
Österreich
0800 180 016
Polska
00800 3111 318
Portugal
0800 780 902 Chamada Grátis
Россия
(495) 961 1111
8800 200 0880
(бесплатный звонок по России)
România
0800-894910 Apel gratuit
0318107125 Apel local
Србија
+381 114 440 841 Lokalni poziv
Slovensko
0800 004537 Bezplatný hovor
Slovenija
600 744 5477 lokalni klic
Sverige
08 5792 9100 Lokalsamtal
Suisse/Schweiz/Svizzera
0800 002 050
Schweizer Festnetztarif/ Tarif réseau
fixe France
Suomi
09 2311 3415 paikallispuhelu
Türkiye
444 7 445
United Kingdom
0800 331 6015 Toll Free
Українська
0-800-500-697
This information is correct at the time of print. For updated information, see www.philips.com/support.
updated:20110912
1
English
6 Install channels 29
Automatically install channels 29
Manually install analogue channels 30
Manually install digital channels 30
Rename channels 31
Rearrange channels 31
Hide channels 31
Unhide channels 31
Access CAM services 31
7 Connect devices 32
Back connections 32
Side connections 34
Connect a computer 35
Use a Conditional Access Module 36
Use Philips EasyLink 36
Use a Kensington lock 39
8 Product information 40
Supported display resolutions 40
Multimedia 40
Tuner/Reception/Transmission 40
Remote control 40
Power 40
Supported TV mounts 41
Product specication 41
9 Troubleshooting 43
General TV issues 43
TV channel issues 43
Picture issues 43
Sound issues 44
HDMI connection issues 44
Computer connection issues 44
Contact us 44
10 Index 45
Contents
1 Notice 2
2 Important 4
3 Your TV 7
TV controls 7
Remote control 8
Remote control usage 9
4 Use your TV 10
Switch your TV on 10
Switch your TV to standby 10
Switch your TV off 11
Switch channels 11
Watch connected devices 12
Adjust TV volume 12
Use teletext 13
5 Use more of your TV 14
Access TV menus 14
Add device to the home menu 14
Rename devices from the home menu 14
Remove devices from the home menu 15
Change picture and sound settings 15
Use the universal access menu 18
Use advanced teletext features 18
Create and use lists of favourite channels 19
Use the Electronic Programme Guide 20
Display the TV clock 20
Use timers 21
Lock unsuitable content 22
View Scenea 22
Change language 23
Play photos, music and videos on USB
storage devices 24
Listen to digital radio channels 25
Update the TV software 26
Change TV preferences 27
Start a TV demo 28
Reset the TV to factory settings 28
EN
2
Pixel characteristics
This LCD product has a high number of
colour pixels. Although it has effective pixels of
99.999% or more, black dots or bright points of
light (red, green or blue) may appear constantly
on the screen. This is a structural property of
the display (within common industry standards)
and is not a malfunction.
Compliance with EMF
Koninklijke Philips Electronics N.V. manufactures
and sells many products targeted at consumers
which, like any electronic apparatus, in
general have the ability to emit and receive
electromagnetic signals.
One of Philips’ leading Business Principles is to
take all necessary health and safety measures
for our products, to comply with all applicable
legal requirements and to stay well within
the Electro Magnetic Field (EMF) standards
applicable at the time of producing the
products.
Philips is committed to develop, produce and
market products that cause no adverse health
effects. Philips conrms that if its products are
handled properly for their intended use, they
are safe to use according to scientic evidence
available today.
Philips plays an active role in the development
of international EMF and safety standards,
enabling Philips to anticipate further
developments in standardisation for early
integration in its products.
Mains fuse (UK only)
This TV is tted with an approved moulded
plug. Should it become necessary to replace
the mains fuse, this must be replaced with a
fuse of the same value as indicated on the plug
(example 10A).
1 Remove fuse cover and fuse.
2 The replacement fuse must comply with
BS 1362 and have the ASTA approval
mark. If the fuse is lost, contact your dealer
in order to verify the correct type.
3 Ret the fuse cover.
1 Notice
2011 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specications are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
The material in this manual is believed
adequate for the intended use of the system.
If the product, or its individual modules or
procedures, are used for purposes other than
those specied herein, conrmation of their
validity and suitability must be obtained. Philips
warrants that the material itself does not
infringe any United States patents. No further
warranty is expressed or implied.
Terms of warranty
• Risk of injury, damage to TV or void of
warranty! Never attempt to repair the TV
yourself.
• Use the TV and accessories only as
intended by the manufacturer.
• The caution sign printed on the back of
the TV indicates risk of electric shock.
Never remove the TV cover. Always
contact Philips Customer Support for
service or repairs.
• Any operation expressly prohibited in
this manual, or any adjustments and
assembly procedures not recommended
or authorised in this manual shall void the
warranty.
EN
3
English
Copyright
Kensington and Micro Saver are registered US
trademarks of ACCO World corporation with
issued registrations and pending applications in
other countries throughout the world.
Manufactured under licence from Dolby
Laboratories. Dolby and the double D symbol
are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC in
the United States and other countries.
All other registered and unregistered
trademarks are the property of their respective
owners.
EN
4
Risk of injury or damage to the TV!
• Two people are required to lift and carry a
TV that weighs more than 25 kg or 55 lbs.
• When stand mounting the TV, use only the
supplied stand. Secure the stand to the TV
tightly. Place the TV on a at, level surface
that can support the combined weight of
the TV and the stand.
• When wall mounting the TV, use only a
wall mount that can support the weight
of the TV. Secure the wall mount to a wall
that can support the combined weight of
the TV and wall mount. Koninklijke Philips
Electronics N.V. bears no responsibility
for improper wall mounting that result in
accident, injury or damage.
• If you need to store the TV, disassemble
the stand from the TV. Never lay the TV on
its back with the stand installed.
• Before you connect the TV to the power
outlet, ensure that the power voltage
matches the value printed on the back
of the TV. Never connect the TV to the
power outlet if the voltage is different.
• Parts of this product may be made of
glass. Handle with care to avoid injury and
damage.
Risk of injury to children!
Follow these precautions to prevent the
TV from toppling over and causing injury to
children:
• Never place the TV on a surface covered
by a cloth or other material that can be
pulled away.
• Ensure that no part of the TV hangs over
the edge of the surface.
• Never place the TV on tall furniture (such
as a bookcase) without anchoring both the
furniture and TV to the wall or a suitable
support.
• Educate children about the dangers of
climbing on furniture to reach the TV.
Risk of swallowing batteries!
• The product/remote control may contain a
coin-type battery, which can be swallowed.
Keep the battery out of reach of children
at all times!
2 Important
Read and understand all instructions before you
use your TV. If damage is caused by failure to
follow instructions, the warranty does not apply.
Safety
Risk of electric shock or re!
• Never expose the TV to rain or water.
Never place liquid containers, such as
vases, near the TV. If liquids are spilt on or
into the TV, disconnect the TV from the
power outlet immediately. Contact Philips
Consumer Care to have the TV checked
before use.
• Never place the TV, remote control or
batteries near naked ames or other heat
sources, including direct sunlight.
To prevent the spread of re, keep candles
or other ames away from the TV, remote
control and batteries at all times.
• Never insert objects into the ventilation
slots or other openings on the TV.
• When the TV is swivelled ensure that no
strain is exerted on the power cord. Strain
on the power cord can loosen connections
and cause arcing.
• To disconnect the TV from the mains
power, the power plug of the TV must be
disconnected. When disconnecting the
power, always pull the power plug, never
the cord. Ensure that you have full access
to the power plug, power cord and outlet
socket at all times.
Risk of short circuit or re!
• Never expose the remote control or
batteries to rain, water or excessive heat.
• Avoid force coming onto power plugs.
Loose power plugs can cause arcing or re.
EN
5
English
Temperature and humidity
On rare occasions, depending on temperature
and humidity, minor condensation can occur on
the inside of the glass front. To prevent this, do
not expose the TV to direct sunlight, heat or
extreme humidity. If condensation occurs, it will
disappear spontaneously after the TV has played
for a few hours. The condensation moisture will
not harm the TV or cause malfunction.
Disposal of your old product and
batteries
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules
on separate collection of batteries because
correct disposal helps to prevent negative
consequences for the environment and human
health.
Risk of overheating!
• Never install the TV in a conned space.
Always leave a space of at least 4 inches
or 10 cm around the TV for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the TV.
Risk of injury, re or power cord damage!
• Never place the TV or any objects on the
power cord.
• Disconnect the TV from the power outlet
and antenna before lightning storms.
During lightning storms, never touch any
part of the TV, power cord or antenna
cable.
Risk of hearing damage!
• Avoid using earphones or headphones at
high volumes or for prolonged periods of
time.
Low temperatures
• If the TV is transported in temperatures
below 5°C or 41°F, unpack the TV and
wait until the TV temperature matches
room temperature before connecting the
TV to the power outlet.
Screen care
• Avoid stationary images as much as
possible. Stationary images are images that
remain on-screen for extended periods of
time. Examples include: on-screen menus,
black bars and time displays. If you must
use stationary images, reduce screen
contrast and brightness to avoid screen
damage.
• Unplug the TV before cleaning.
• Clean the TV and frame with a soft, damp
cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the TV.
• Risk of damage to the TV screen! Never
touch, push, rub or strike the screen with
any object.
• To avoid deformations and colour fading,
wipe off water drops as soon as possible.
EN
6
Environmental efforts
Philips continuously focuses on lowering
the environmental impact of its innovative
consumer products. We aim our efforts
towards environmental improvements during
manufacturing, reduction of harmful substances,
energy-efcient use, end-of-life instructions and
product recycling.
To access energy-efcient settings:
1 While you watch TV, press the green
button on the remote control.
2 Select one of the following settings:
• [Energy saving]: Picture settings that
conserve the most energy.
• [Mute screen]: If you only want to
listen to audio from the TV, you can
turn off the TV display. Other functions
continue to operate normally.
• [Light sensor]: The built-in ambient
light sensor lowers the brightness of
the TV screen when the surrounding
light darkens.
• [Switch off unused sources]: If you
connect EasyLink-compliant devices,
you can switch them off.
EN
7
English
xxPFL3xx6
1
4
2
3
DesignLine Tilt
1
4
2
3
3 Your TV
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your TV at
www.philips.com/welcome.
TV controls
a +/-: Adjust volume.
b (Home): Access the home menu.
c CH +/-: Switch channels.
d Power: Switch the TV on or off.
1
2
3
4
xxPFL5xx6
1 2 34
xxPFL4xx6
EN
8
g (Mute)
• Mute or restore audio.
h +/- (Volume)
• Adjust volume.
i 0-9 (Numeric buttons)
• Select channels.
j SUBTITLE
• Enable or disable subtitles.
k TEXT
• Enable or disable teletext.
l OPTIONS
• Access options for the current activity
or selection.
m (Back)
• Return to the previous menu or exit
a function.
n OK
• Conrm an entry or selection.
o (Navigation buttons)
• Navigate through menus and select
items.
p ADJUST
• Access the menu to adjust settings.
q Colour buttons
• Select tasks or options.
Remote control
a (Standby-On)
• Switch the TV on or to standby.
b Play buttons
• Control video or music.
c FIND
• Access the menu to select a TV
channel list.
d (Home)
• Access the home menu.
e CH - / CH + (Previous/Next)
• Switch channels or navigate through
menu pages, tracks, albums or folders.
f SOURCE
• Select connected devices.
11
10
1
2
17
16
12
15
14
13
7
4
5
3
6
9
8
EN
9
English
Remote control usage
When you use the remote control, hold it close
to the TV and point it at the remote control
sensor. Make sure that the line-of-sight between
the remote control and TV is not blocked by
furniture, walls or other objects.
~5m
~30˚
xxPFL5xx6/xxPFL4xx6
~5m
~30˚
xxPFL3xx6
~5m
~30˚
DesignLine Tilt
EN
10
If the TV is in standby
• Press (Standby-On) on the remote
control.
Switch your TV to standby
• Press (Standby-On) on the remote
control again.
» The remote control sensor on the TV
switches to red.
DesignLine Tilt
4 Use your TV
This section helps you perform basic TV
operations.
Switch your TV on
• Press the power switch on the TV.
» There is a short delay before the TV
responds.
xxPFL5xx6
xxPFL5xx6/xxPFL4xx6
xxPFL3xx6
EN
11
English
Other ways to switch channels
• Enter a channel number using the Numeric
buttons.
• Press (BACK) on the remote control
to return to the previous channel.
Note
• When you use a favourite list, you can only select those
channels in the list (see ‘Create and use lists of favourite
channels’ on page 19).
View channel preview
You can view a preview of all available channels
with the channel grid.
• Press FIND.
» The channel grid appears.
» To preview a channel, select it.
» To watch a channel, select it, then press
OK.
xxPFL3xx6
DesignLine Tilt
Switch your TV off
• Press the power switch on the TV again.
» The remote control sensor on the TV
switches off.
» For xxPFL5xx6, the TV no longer
consumes energy.
» For xxPFL4xx6, xxPFL3xx6, and
DesignLine Tilt, though the TV
consumes very little power when
in standby, energy continues to be
consumed. When not in use for an
extended period of time, disconnect
the TV power cable from the power
outlet or turn off the power switch.
Note
• If you cannot locate your remote control and want to
switch on the TV from standby, press CH+/- on the TV.
Switch channels
• Press CH+ or CH- on the remote control.
• Press CH +/- on the TV.
xxPFL5xx6/xxPFL4xx6
EN
12
Adjust TV volume
• Press +/- on the remote control.
• Press +/- on the TV.
To mute or unmute sound
• Press to mute the sound.
• Press again to restore the sound.
xxPFL5xx6/xxPFL4xx6
xxPFL3xx6
DesignLine Tilt
Watch connected devices
Note
• Before you select a device as a source, switch the
device on.
Select a device from the source list
1 Press SOURCE.
» The source list appears.
2 Press to select a device.
3 Press OK to conrm your choice.
» The TV switches to the selected
device.
EN
13
English
Use teletext
1 Press TEXT.
» The main index page appears.
2 Select a page with one of the following:
• Press the Numeric buttons to enter a
page number.
• Press or to view the next or
previous page.
• Press the Colour buttons to select a
colour coded item.
• Press (BACK) to return to a
previously viewed page.
3 Press TEXT to exit teletext.
Note
• For UK users only: Some digital TV channels offer
dedicated digital text services (for example, BBC1).
EN
14
Add device to the home
menu
After you connect a device, add it to the home
menu.
1 Press .
2 Select [Add new device].
3 Follow the onscreen instructions to add
the device to the home menu.
» The device is displayed in the home
menu.
4 To watch the device, switch it on, then
select it in the home menu.
5 You can also select the device with the
source button (see ‘Select a device from
the source list’ on page 12).
Rename devices from the
home menu
After you add a new device to the home menu,
you can rename it to your preference.
Note
• The device name can be up to 16 characters long.
1 Press .
2 Select a device to rename.
3 Press OPTIONS.
» The options menu appears.
4 Select [Rename device], then press OK.
5 To display the text input box, press OK.
6 For each character, select a character, then
press OK.
• To select uppercase letters, lowercase
letters or symbols: In the row below
the space key, select the respective
key, then press OK.
5 Use more of
your TV
Access TV menus
Menus help you to install channels, change
picture and sound settings and access other
features.
1 Press .
The menu screen appears.
2 Select one of the following, then press OK.
• [Watch TV]: If a source other than
antenna is selected, switch back to the
antenna source
• [Programme guide]: Access the
electronic programme guide.
• [Browse USB]: If a USB device
is connected, access the content
browser.
• [Scenea]: Switch on Scenea wallpaper.
• [Add new device]: Add new devices
to the home menu.
• [Setup]: Access menus to change
picture, sound and other settings.
• [Help]: Access the TV tour.
3 Press to exit.
EN
15
English
Use settings assistant
Use the settings assistant to guide you through
the picture and sound settings.
1 Press .
2 Select [Setup] > [Quick picture and
sound settings], then press OK.
3 Select [Continue], then press OK.
» The [Settings assistant] menu appears.
4 Follow the onscreen instructions to choose
your preferred picture settings.
Use smart picture
Use smart picture to apply pre-dened picture
settings.
1 Press ADJUST.
2 Select [Smart picture], then press OK.
3 Select one of the following settings, then
press OK.
• [Personal]: Apply your customised
picture settings
• [Vivid]: Rich and dynamic settings,
ideal for daytime.
• [Natural]: Natural picture settings.
• [Cinema]: Ideal settings for movies.
• [Game]: Ideal settings for games.
• [Energy saving]: Settings that conserve
the most energy.
• [Standard]: Default settings that suit
most environments and types of
video.
• [Photo]: Ideal settings for photos.
• [Custom]: Customise and store
your personal picture settings. Select
[Personal] to apply these settings.
7 When complete, select [Done], then press
OK.
» The text input box closes.
8 In the rename device menu, select [Done],
then press OK.
Remove devices from the
home menu
If a device is no longer connected to the TV,
remove it from the home menu.
1 Press .
2 Select a device to remove.
3 Press OPTIONS.
4 Select [Remove device], then press OK.
5 Select [Remove], then press OK.
» The selected device is removed from
the home menu.
Change picture and sound
settings
Change picture and sound settings to suit your
preferences. You can apply pre-dened settings
or change settings manually.
Note
• While you watch TV or external devices, press
ADJUST, then select [Smart picture] or [Smart
sound] for quick access to picture and sound settings.
EN
16
• [Colour enhancement]: Make colours
more vivid and improve the details
in bright colours. You can switch this
feature on or off.
• [Gamma]: For selected models. Adjust
the midtone intensity in the picture.
Black and white are not affected.
• [PC mode]: Adjust the picture when a PC
is connected to the TV via HDMI or DVI.
• [Light sensor]: Adjust settings dynamically
based on the current lighting conditions.
• [Picture format]: Change the picture
format.
• [Screen edges]: Adjust the viewing area.
(when set to maximum, you may see noise
or the rough edge of an image).
• [Picture shift]: If available, adjust the picture
position for all picture formats except for
[Auto zoom] and [Wide screen].
Change picture format
1 Press ADJUST.
2 Select [Picture format], then press OK.
3 Select a picture format, then press OK.
Summary of picture formats
The following picture settings can be congured.
Note
• Depending on the format of the picture source, some
picture settings are not available.
Manually adjust picture settings
1 Press .
2 Select [Setup] > [TV settings] > [Picture],
then press OK.
3 Select one of the following settings, then
press OK.
• [Smart picture]: Access predened smart
picture settings.
• [Reset]: Reset to factory default settings.
• [Contrast]: Adjust the intensity of backlight
areas, while the video contents are kept
unchanged.
• [Brightness]: Adjust the intensity and
details of dark areas.
• [Colour]: Adjust colour saturation.
• [Hue]: Compensate for colour variations.
• [Sharpness]: Adjust sharpness in the image.
• [Noise reduction]: Filter and reduce noise
in an image.
• [Tint]: Adjust the colour balance in an
image.
• [Custom tint]: Customise tint setting.
(Only available if [Tint] > [Custom] is
selected)
• [Digital Crystal Clear] / [Pixel Plus] /
[Pixel Plus HD]: Fine-tune each pixel to
match surrounding pixels. This setting
produces a brilliant, high-denition image.
• [HD Natural Motion]: For selected
models. Minimise juddering effects and
enhance picture smoothness.
• [100Hz Clear LCD] / [120Hz Clear
LCD]: For selected models. Reduce
motion blurring and make picture
clearer.
• [Advance sharpness]: Enable superior
picture sharpness.
• [Dynamic contrast]: Enhance contrast.
[Medium] setting is recommended.
• [Dynamic backlight]: Adjust brightness
of the TV backlight to match lighting
conditions.
• [MPEG artifact reduction]: Smooth
out transitions on digital pictures. You
can switch this feature on or off.
EN
[Auto format]: For
selected models. (Not for
PC mode.) Automatically
display the suitable picture
format. If not, widescreen is
applied.
[Auto ll]: For selected
models. Adjust the
picture to ll the screen
(subtitles remain visible).
Recommended for minimal
screen distortion but not
for HD or PC.
17
English
• [News]: Ideal settings for spoken
audio, such as news.
• [Cinema]: Ideal settings for movies.
• [Game]: Ideal settings for games.
• [DRAMA]: Ideal settings for drama
programmes.
• [Sports]: Ideal settings for sports
programmes.
Manually adjust sound settings
1 Press .
2 Select [Setup] > [TV settings] > [Sound],
then press OK.
» The [Sound] menu appears.
3 Select one of the following settings, then
press OK.
• [Smart sound]: Access predened smart
sound settings.
• [Reset]: Reset to factory default settings.
• [Clear sound]: Enhance the sound clarity.
• [Bass]: Adjust the bass level.
• [Treble]: Adjust the treble level.
• [Surround]: Switch on spatial sound.
• [Incredible Surround]: (For selected
models) Enhanced spatial sound for
increased surround effect.
• [Headphone volume]: (For models with
headphones) Adjust headphone volume.
• [Auto volume levelling]: Automatically
reduce sudden volume changes, for
example when switching channels.
• [Balance]: Adjust the balance of the right
and left speakers.
• [Digital output format]: Select the type of
digital audio output through digital audio
output connector.
• [PCM]: Convert non-PCM audio type
to PCM format.
• [Multichannel]: Output audio to the
home theatre.
[Auto zoom]: For selected
models. Enlarge the
picture to ll the screen.
Recommended for minimal
screen distortion but not
for HD or PC.
[Super zoom]: (Not
for HD and PC mode.)
Remove the black bars on
the side of 4:3 broadcasts.
There is minimal distortion.
[4:3]: Show the classic 4:3
format.
[Movie expand 16:9]: (Not
for HD and PC mode.)
Scale 4:3 format to 16:9.
[Wide screen]: Scale 4:3
format to 16:9.
[Unscaled]: For HD and
PC mode only, and in
selected models only. Allow
maximum sharpness. Some
distortion may be present
due to the broadcaster’s
systems. Set your PC
resolution to wide screen
mode for best results.
Use smart sound
Use smart sound to apply pre-dened sound
settings.
1 Press ADJUST.
2 Select [Smart sound], then press OK.
3 Select one of the following settings, then
press OK.
• [Personal]: Apply the settings that
were customised in the sound menu.
• [Standard]: Settings that suit most
environments and types of audio.
EN
18
Use advanced teletext
features
Access the teletext options menu
Access the teletext features through the
teletext options menu.
1 Press TEXT.
» The teletext screen appears.
2 Press OPTIONS.
» The teletext options menu appears.
3 Select one of the following options, then
press OK.
• [Freeze page] / [Unfreeze page]:
Freeze/unfreeze the current page.
• [Dual screen] / [Full screen]: Switch
between full screen and dual screen
teletext.
• [T.O.P. overview]: Switch on Table of
Pages teletext broadcasts
• [Enlarge] / [Normal view]: Switch
between enlarged and normal view of
teletext pages.
• [Reveal]: Hide or reveal hidden
information on a page, such as
solutions to riddles or puzzles.
• [Cycle subpage]: If subpages are
available, automatically display each
subpage in sequence.
• [Languages]: Select a language for
teletext.
Select teletext subpages
A teletext page can contain several subpages.
Subpages are displayed next to the main page
number.
1 Press TEXT.
» The teletext screen appears.
2 Press or to select a teletext page.
3 Press or to enter a subpage.
Use the universal access
menu
You can activate the universal access menu
during the rst installation. Once enabled, you
can quickly access the visually impaired and
hearing impaired menus when watching TV or
external devices.
1 While you watch TV, press OPTIONS.
» The TV options menu appears.
2 Select [Universal access], then press OK.
3 Select one of the following options, then
press OK.
• [Hearing impaired]: Enable or disable
hearing impaired subtitles.
• [Visually impaired]: Some digital TV
channels broadcast special audio adapted
for people who are visually impaired.
The normal audio is mixed with extra
commentary. Use the colour buttons to
select the options:
• Red ([Off]): Turn off visually impaired
audio.
• Green ([Speakers]): Hear visually
impaired audio from speakers only
• Yellow ([Headphone]): Hear visually
impaired audio from headphones only.
• Blue ([Speaker + headphone]): Hear
visually impaired audio from both
speakers and headphone.
• [Mixed volume]: Adjust the volume of
visually impaired audio.
• [Key beep]: Switch on audio feedback
when buttons are pressed on the remote
control or TV.
Tip
• Press the colour buttons on the remote control to
enter the options.
EN
19
English
3 Select [Select list] > [Favourites], then
press OK.
» Only channels in the favourites list
appear in the channel grid.
Note
• The favourites channel grid is empty until you add
channels into the favourites list.
View all channels
You can exit the favourites list, and view all
installed channels.
1 While you watch TV, press FIND.
» The channel matrix menu is displayed.
2 Press OPTIONS.
3 Select [Select list] > [All], then press OK.
» All channels are displayed in the
channel grid.
Note
• All favourite channels are marked by an asterisk when
you view the channel grid.
Manage the favourites list
1 While you watch TV, press FIND.
» The channel matrix menu appears.
2 Press OPTIONS.
3 Select [Select list] > [All], then press OK.
4 Press OPTIONS.
5 Select [Mark as favourite] or [Unmark as
favourite], then press OK.
» The channel is added or removed from
the favourite list.
Note
• All favourite channels are marked by an asterisk in the
channel grid.
Select T.O.P. teletext broadcasts
Jump from one subject to another without
entering page numbers with Table Of Pages
(T.O.P.) teletext broadcasts. T.O.P. teletext
broadcasts are available on selected TV
channels.
1 Press TEXT.
» The teletext screen appears.
2 Press OPTIONS.
3 Select [T.O.P. overview], then press OK.
» The T.O.P. overview appears.
4 Select a subject.
5 Press OK to view the page.
Use Teletext 2.5
Teletext 2.5 offers more colours and better
graphics than normal teletext. If Teletext 2.5
is broadcast by a channel, it is switched on by
default.
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Teletext 2.5].
3 Select [On] or [Off], then press OK to
conrm.
Create and use lists of
favourite channels
You can create a list of your preferred TV
channels so that you can nd those channels
easily.
View only the list of favourite
channels
1 While you watch TV, press FIND.
» The channel matrix menu is displayed.
2 Press OPTIONS.
EN
20
• [Scheduled reminders]: List
programme reminders. Only available
for upcoming programmes.
• [Acquire EPG data]: Update the latest
programme guide information.
Display the TV clock
You can display a clock on the TV screen. The
clock displays the current time using time data
received from your TV service operator.
Set the TV clock manually
In some countries, you need to set TV clock
manually.
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Clock].
3 Select [Auto clock], then press OK.
4 Select [Manual], then press OK.
5 Select [Time] or [Date], then press OK.
6 Press the Navigation buttons to set the
time or date.
7 Select [Done], then press OK.
8 Press to exit.
Note
• If your selected country supports digital broadcast,
the clock displays the time data from your TV service
operator as priority.
Display the TV clock
1 While you watch TV, press OPTIONS.
» The options menu is displayed.
2 Select [Clock].
» The clock is displayed.
3 Press OK.
Note
• To disable the clock, repeat the procedure.
Use the Electronic
Programme Guide
The programme guide is an on-screen guide
available for digital channels. It allows you to:
• View a list of digital programmes being
broadcast
• View upcoming programmes
• Group programmes by genre
• Set reminders when programmes start
• Setup preferred programme guide
channels
Switch on EPG
1 Press .
2 Select [Programme guide], then pressOK.
» The programme guide appears
displaying information about the
scheduled programmes.
Note
• Programme guide data is available only in selected
countries and can take some time to load.
Change programme guide options
You can set or clear reminders, change the
day, and access other useful options in the
programme guide options menu.
1 Press .
2 Select [Programme guide], then press OK.
3 Press OPTIONS.
» The programme guide menu appears.
4 Select one of the following options, then
press OK.
• [Set reminder] / [Clear reminders]:
Set or clear programme reminders.
• [Change day]: Set the programme
guide day.
• [More info]: Display programme
information.
• [Search by genre]: Search TV
programmes by genre.
EN
21
English
Use timers
You can set timers to switch the TV to standby
at a specied time.
Tip
• Set the TV clock before you use timers.
Automatically switch the TV to
standby (sleep timer)
Sleep timer switches the TV to standby after a
pre-dened duration.
Tip
• You can switch off your TV earlier or reset the sleep
timer during the countdown.
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Sleep timer].
» The [Sleep timer] menu appears.
3 Select a value between zero and 180
minutes.
» If you select zero, the sleep timer
switches off.
4 Press OK to switch on the sleep timer.
» The TV switches to standby after the
specied time.
Change the clock mode
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Clock] > [Auto clock].
3 Select [Automatic] or [Manual], then press
OK.
Change the time zone
Note
• This option is only available if you select [Auto clock] >
[Automatic] (in countries with clock transmission data).
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Clock] > [Time zone].
3 Select your time zone.
4 Press OK to conrm.
Use daylight saving
Note
• This option is only available if you select [Auto clock
mode] > [Manual].
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Clock] > [Daylight
saving], then press OK.
3 Select [Standard time] or [Daylight saving
time], then press OK.
EN
22
6 To activate the locks, switch the TV on and
off.
» When you switch channels with
CH - or CH +, the locked channels are
skipped.
» When you access the locked channels
from the channel grid, you are
prompted to enter your PIN code.
Set parental ratings
Some digital broadcasters rate their
programmes according to age. You can set your
TV to display only programmes with age ratings
lower than your child’s age.
1 Press .
2 Select [Setup] > [Channel settings] >
[Child lock] > [Parental rating].
» A code setup screen appears.
3 Enter your code using Numeric buttons.
» The rating menu appears.
4 Select an age rating, then press OK.
5 Press to exit.
View Scenea
You can display a default picture as the
wallpaper on your TV. You can also load another
picture as the wallpaper.
If the sleeptimer is off, the wallpaper is displayed
for 240 minutes. Otherwise, it is displayed for
the duration of the sleeptimer.
Switch on Scenea
1 Press .
2 Select [Scenea], then press OK.
» If no picture has been set, the default
picture is displayed.
» If a customised Scenea picture is
loaded, that picture is displayed (see
‘Customise the Scenea picture’ on
page 23).
Lock unsuitable content
You can prevent your children from watching
certain programmes or channels by locking the
TV controls.
Set or change code
1 Press .
2 Select [Setup] > [Channel settings] >
[Child lock].
3 Select [Set code] or [Change code].
» The [Set code] / [Change code] menu
appears.
4 Enter your code using the Numeric
buttons.
» Follow the on-screen instructions to
create or change your PIN code.
Tip
• If you forget your code, enter ‘8888’ to override any
existing codes.
Lock or unlock one or more channels
1 Press .
2 Select [Setup] > [Channel settings] >
[Child lock] > [Channel lock].
» A list of channels is displayed.
3 Select the channel that you want to lock or
unlock, then press OK.
» The rst time you lock or unlock a
channel, you are prompted to enter
your PIN code.
4 Enter your code and press OK.
» If the channel is locked, a lock icon is
displayed.
5 Repeat the process to lock or unlock more
channels.
EN
23
English
Change audio language
You can choose an audio language if it is
available from your broadcaster. For digital
channels, multiple languages may be available.
For analogue channels, two languages may be
available.
1 While you watch TV, press OPTIONS.
2 For digital channels, select [Audio
language], select the language, then press
OK.
3 For analogue channels, select [Dual I-II],
select either language, then press OK.
Show or hide subtitles
1 While you watch TV, press SUBTITLE.
2 Select one of the following, then press OK.
• [Subtitles on]: Always display subtitles.
• [Subtitles off]: Never display subtitles.
• [On during mute]: When audio is
muted, display subtitles.
Note
• Repeat this procedure to enable subtitles on each
analogue channel.
• Select [Subtitles] > [Subtitles off] to disable subtitles.
Select a subtitle language in digital
channels
Note
• When you select a subtitle language in a digital TV
channel as described below, the preferred subtitle
language set in the installation menu is temporarily
overruled.
1 While you watch TV, press OPTIONS.
2 Select [Subtitle language], then press OK.
3 Select a subtitle language.
4 Press OK to conrm.
Customise the Scenea picture
You can load another picture as the wallpaper.
Note
• When you load a new Scenea picture, it overrides the
current Scenea picture.
• To use another picture as the wallpaper, you need a
USB storage device that contains a picture that is less
than 1 MB in size.
1 Load a picture smaller than 1MB in size
into a USB storage device.
2 Connect the USB storage device to the TV.
3 Press .
4 Select [Browse USB], then press OK.
5 Select a picture, then press OPTIONS.
6 Select [Set as Scenea], then press OK.
7 Press any button to exit Scenea.
Change language
Depending on your broadcaster, you can change
the audio language, subtitle language, or both,
for a TV channel.
Multiple audio languages, subtitles, or both, are
broadcast through teletext or DVB-T digital
broadcasts. Dual sound broadcasts: With digital
broadcasts, you can select a subtitle language.
Change menu language
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Menu language], then
press OK.
3 Select a language, then press OK.
EN
24
Change slide show settings
1 While you view a slide show, press
OPTIONS.
» The slide show options menu is
displayed.
2 Select one of the following, then press OK.
• [Start/Stop slideshow]: Start or stop
slideshow.
• [Slideshow transitions]: Set the
transition from one picture to the
next.
• [Slideshow frequency]: Select the
display time for each photo.
• [Repeat] / [Play once]: View the
pictures in the folder once only, or
repeatedly.
• [Shufe off] / [Shufe on]: View the
pictures in sequential order, or at
random.
• [Rotate image]: Rotate photo.
• [Show info]: Display the picture name,
date, size and next picture in the slide
show.
• [Set as Scenea]: Set the selected
picture as the TV wallpaper (see ‘View
Scenea’ on page 22).
3 To return, press .
Note
• [Rotate image] and [Show info] appear only when the
slideshow is paused.
Listen to music
1 In the USB browser, select [Music], then
press OK.
2 Select a music track or album, then press
OK to play.
3 To control play, press the play buttons:
• to play.
• to pause.
• or to play the previous or next
track.
• or to search forward or
backward.
• to stop.
Play photos, music and videos
on USB storage devices
Caution
• Philips is not responsible if the USB storage device is
not supported, nor is it responsible for damage or loss
of data from the device.
Connect a USB storage device to play photos,
music or videos stored on it.
1 Switch on the TV.
2 Connect the USB device to the USB port
on the side of your TV.
3 Press .
4 Select [Browse USB], then press OK.
» The USB browser appears.
View photos
1 In the USB browser, select [Picture], then
press OK.
2 Select a photo or a photo album, then
press OK to view the photo enlarged to
ll the TV screen.
• To view the next or previous photo,
press .
3 To return, press .
View a slide show of your photos
1 When a full screen image of a photo is
displayed, press OK.
» A slide show begins from the selected
photo.
• Press the following buttons to control play:
• to play.
• to pause.
• or to play the previous or next
photo.
• to stop.
• To return, press .
EN
25
English
View a slideshow with music
You can view a picture slide show with
background music.
1 Select an album of songs.
2 Press OK.
3 Press to return to the USB content
browser.
4 Select an album of pictures.
5 Press OK.
» The slideshow begins.
6 To exit, press .
Disconnect a USB storage device
Caution
• Follow this procedure to avoid damage to your USB
storage device.
1 Press to exit the USB browser.
2 Wait for ve seconds, then disconnect the
USB storage device.
Listen to digital radio
channels
1 Press FIND.
» The channel matrix menu is displayed.
2 Press OPTIONS, then select [Select
list] > [Radio].
» The radio channel grid appears.
3 Select a radio channel and press OK to
listen.
Change music settings
• While you play music, press OPTIONS
to access one of the following settings,
then press OK.
• [Stop playback]: Stop music play.
• [Repeat]: Play a song once or
repeatedly.
• [Shufe on] / [Shufe off]: Play songs
in sequence or at random.
• [Show info]: Display the le name.
Watch video
1 In the USB browser, select [Video], then
press OK.
2 Press OK to play.
3 To control play, press the play buttons:
• to play.
• to pause.
• or to play the previous or next
video.
• or to search forward or
backward.
• to stop.
Change video settings
• While you play video, press OPTIONS
to access one of the following settings,
then press OK.
• [Stop playback]: Stop video play.
• [Repeat]: Play once or repeatedly.
• [Full screen] / [Small Screen]: View
the video stretched to ll the screen,
or view it in its native picture format.
• [Shufe on] / [Shufe off]: Play in
sequence or at random.
• [Show info]: Display the le name.
EN
26
Step 2: Download and update the
latest software version
1 Connect a USB storage device.
2 Press .
3 Select [Setup] > [Update software].
4 Follow the instructions to load a le onto
your USB storage device.
5 Connect the USB storage device to your
computer, then double-click the le.
» A Web page is launched.
6 Follow the instructions in the Web page.
• If the current software version
matches the latest software update
le, you do not need to update your
TV software.
• If the current software version is
smaller than the latest software
update le, download the latest
software update le to the root
directory of your USB device.
7 Disconnect the USB storage device from
the computer.
Step 3: Update the TV software
1 Connect your USB storage device to the
TV.
» The TV detects the USB ash drive and
starts to scan for software version.
2 If a message prompts you to update the
software, follow the on-screen instructions
to update the TV software.
3 If the message is not displayed, continue
with the following steps:
4 Press .
5 Select [Setup] > [Software settings] >
[Local updates].
6 Select the le that you downloaded, then
press OK to update the TV software
manually.
7 Follow the on-screen instructions to
complete the update.
8 To exit, press .
Update the TV software
Philips continuously tries to improve its
products and we recommend that you update
the TV software when updates are available.
Ways to update the TV software
You can update the TV software in one of the
following ways:
A: with a USB storage device,
B: when prompted through digital broadcasts, or
C: after being prompted through digital
broadcasts.
A: Update with a USB device
To update with a USB storage device, you need:
• An empty USB ash drive. The USB ash
drive must be FAT or DOS-formatted. Do
not use a USB hard drive.
• A computer with Internet access
• An archive utility that supports the ZIP
le format (for example, WinZip® for
Microsoft® Windows® or Stuft® for
Macintosh®).
Step 1: Check the current software
version
1 Press .
2 Select [Setup] > [Software settings] >
[Current software inf].
» The current software information is
displayed.
3 Write down the software version number.
4 To return, press OK.
5 To exit, press .
EN
27
English
Change TV preferences
Use the preferences menu to customise your
TV settings.
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences].
3 Select one of the following, then press OK.
• [Menu language]: Select a menu
language.
• [Sleep timer]: Switch the TV to
standby after a pre-dened duration.
• [Location]: Optimise TV settings for
your location - home or shop.
• [E-sticker]: (For shop mode only)
Switch the e-sticker on or off.
• [Volume bar]: Display the volume bar
when you change the volume.
• [Auto switch off]: To conserve energy,
set the TV to switch to standby
automatically after a period of
inactivity.
This TV is also designed with other
energy efciency settings. If there is
no user interaction (such as pressing
a remote control button or a control
on the front panel) for four hours,
the TV will automatically switch to
standby.
• [Channel information size]: Change
the type of information that is
displayed when you switch channels.
• [Universal access]: Enable or disable
the universal access menu.
• [Key beep]: Enable audio feedback
when you press buttons on the
remote control or TV.
• [Audio out delay]: Automatically sync
the image on your TV to the audio
from a connected home theatre.
• [TV position]: Apply the best settings
for your TV based on how it is
mounted.
• [Teletext 2.5]: Enable or disable
Teletext 2.5. (For digital TV)
• [Clock]: Display or remove the time
from the TV, and set clock options.
B: Update when prompted through
digital broadcasts
If you receive digital broadcasts (DVB-T), your
TV can automatically receive software updates.
When your TV receives a software update, it
will prompt you to update the TV software.
1 Press .
2 Select [Setup] > [Software settings] >
[Announcement] .
3 If a message appears to prompt you
to update your software, follow the
instructions to start the update.
» The TV restarts after the software
update is complete.
4 If you do not want to update the software,
select [Setup] > [Software settings] >
[Clear announcement], then press OK.
Note
• If you skip the update, you can update it manually later
(see ‘C: Check for updates through digital broadcasts’
on page 27).
C: Check for updates through digital
broadcasts
You can check if there are updates available
through digital broadcasts.
1 Press .
2 Select [Setup] > [Software settings] >
[Check on major updates].
3 If an update is available, follow the on-
screen instructions to start the update.
» The TV restarts after the software
update is complete.
EN
28
Start a TV demo
You can use demonstrations to better
understand the features of your TV. Some
demos are not available on certain models.
Available demos are displayed in the menu list.
1 While you watch TV, press .
2 Select [Setup] > [Watch demo], OK.
3 Select a demo and press OK to view it.
4 To exit, press .
Reset the TV to factory
settings
You can restore the default picture and sound
settings of your TV. The channel installation
settings remain the same.
1 Press .
2 Select [Setup] > [TV settings] > [Factory
settings], then press OK.
3 If you are prompted to enter a code, enter
the child-lock code (see ‘Set or change
code’ on page 22).
» A conrmation message is displayed.
4 Press OK to conrm.
EN
29
English
1 Press .
2 Select [Setup] > [Search for channels],
then press OK.
3 Select [Reinstall channels], then press OK.
» The country menu is displayed.
4 Select your country, then press OK.
» The network menu is displayed.
5 Select the network, then press OK.
• [Antenna]: For free-to-air antenna or
digital DVB-T channels.
• [Cable]: For cable or digital DVB-C
channels.
6 Follow the onscreen instructions to select
other options, if any.
» The start menu for channel search is
displayed.
7 Select [Start], then press OK.
» All available channels are stored.
8 To exit, press OK.
Update the channel list
You can enable automatic update of channels
when your TV is in standby mode. The channels
stored in your TV are updated every morning
according to the channel information in the
broadcast.
1 Press .
2 Select [Setup] > [Channel settings] >
[Channel installation] > [Automatic
channel update].
3 Select [On] to enable the automatic
update or select [Off] to disable it.
4 To return, press .
6 Install channels
The rst time you set up your TV, you are
prompted to select a menu language and to
install TV and digital radio channels (if available).
Afterwards, you can re-install and ne tune
channels.
Automatically install channels
You can search and store channels automatically.
Note
• If you have not set the child lock code, you may be
prompted to set the code (see ‘Set or change code’ on
page 22).
Step 1: Select your menu language
1 Press .
2 Select [Setup] > [TV settings] >
[Preferences] > [Menu language], then
press OK.
3 Select a language, then press OK.
Step 2: Search for channels
When the TV was switched on for the
rst time, a full installation of channels was
performed. You can run this full installation again
to set your language, country, and install all
available TV channels.
Note
• For selected models, some options are different.
EN
30
Step 3: Fine-tune channels
1 Press .
2 Select [Setup] > [Channel settings]
> [Channel installation] > [Analogue:
Manual antenna installation] > [Fine-tune],
then press OK.
3 Press to ne-tune the channel.
Manually install digital
channels
You can search and store digital TV channels
one at a time.
Note
• If you have not set the child lock code, you may be
prompted to set the code (see ‘Set or change code’ on
page 22).
1 Press .
2 Select [Setup] > [Channel settings]
> [Channel installation] > [Digital:
Reception test] > [Find channel], then
press OK.
3 Press the Numeric buttons to enter the
channel frequency.
4 Select [Search], then press OK.
5 When the correct channel is located, select
[Store], then press OK.
6 To exit, press .
Note
• If the reception is poor, reposition your antenna and
repeat the procedure.
• If you receive the channel with DVB-C, select [Symbol
rate mode] > [Automatic], unless your cable provider
supplies you with a specic symbol rate value.
Manually install analogue
channels
You can search and store analogue TV channels
one at a time.
Note
• If you have not set the child lock code, you may be
prompted to set the code (see ‘Set or change code’ on
page 22).
Step 1: Select your system
Note
• If your system settings are correct, skip this step.
1 Press .
2 Select [Setup] > [Channel settings]
> [Channel installation] > [Analogue:
Manual antenna installation] > [System],
then press OK.
3 Select the correct system for your country
or region, then press OK.
Step 2: Search and store channels
1 Press .
2 Select [Setup] > [Channel settings]
> [Channel installation] > [Analogue:
Manual antenna installation] > [Find
channel], then press OK.
• If you know the three-digit frequency
of the channel, enter it.
• To search, select [Search], then press
OK.
3 When the channel is found, select [Done],
then press OK.
• To store the channel as a new number,
select [Store as new channel], then
press OK.
• To store the channel as the previously
selected channel, select [Store
current channel], then press OK.
EN
31
English
Hide channels
To prevent unauthorised access to channels,
hide them from the channel list.
1 While you watch TV, press FIND.
» The channel matrix menu is displayed.
2 Select the channel to hide.
3 Press OPTIONS.
» The channel options menu is displayed.
4 Select [Hide channel], then press OK.
» The channel is marked as hidden.
Unhide channels
To prevent unauthorised access to channels,
hide them from the channel list.
1 While you watch TV, press FIND.
» The channel matrix menu is displayed.
2 Press OPTIONS.
» The channel options menu is displayed.
3 Select [Show hidden channels], then press
OK.
» The hidden channels are displayed.
4 Select the channel to unhide, then press
OPTIONS.
5 Select [Unhide channel], then press OK.
» The channel is no longer marked as
hidden.
» You can access the hidden channel.
6 To exit, press .
Access CAM services
1 Insert and activate the CAM (see ‘Insert
and activate a CAM’ on page 36).
2 Press OPTIONS.
3 Select [Common interface].
» Applications provided by the digital TV
service operator are displayed.
Note
• This menu option is available only if the CAM is
inserted and activated correctly.
Rename channels
You can rename channels. The name appears
when you select the channel.
1 While you watch TV, press FIND.
» The channel matrix menu is displayed.
2 Select the channel to rename.
3 Press OPTIONS.
» The channel options menu is displayed.
4 Select [Rename channel], then press OK.
5 To display the text input box, press OK.
6 For each character, select a character, then
press OK.
• To select uppercase letters, lowercase
letters or symbols: In the row below
the space key, select the respective
key, then press OK.
7 When complete, select [Done], then press
OK.
» The text input box closes.
8 In the rename channel menu, select
[Done], then press OK.
Rearrange channels
After you install channels, you can rearrange the
order in which they appear.
1 While you watch TV, press FIND.
» The channel matrix menu is displayed.
2 Press OPTIONS.
» The channel options menu appears.
3 Select [Reorder], then press OK.
4 Select the channel to rearrange, then press
OK.
» The selected channel is highlighted.
5 Move the highlighted channel to its new
location, then press OK.
6 Press OPTIONS.
7 Select [Done reordering], then press OK.
EN
32
b EXT 1 (RGB and CVBS)
Analogue audio and video input from
analogue or digital devices such as DVD
players or game consoles.
c DIGITAL AUDIO OUT
Digital audio output to home theatres and
other digital audio systems.
d SERV. U
For use by service personnel only.
SPDIF OUT
7 Connect devices
This section describes how to connect devices
with different connectors. For the location of
these connectors on your TV, see the quick
start guide. More examples of connections with
other devices are provided in the Quick Start
Guide.
Note
• You can use different types of connectors to connect a
device to your TV.
Tip
• After connection, for easy access to your device, add
it to the home menu: press , then select [Add new
device].
Back connections
a TV ANTENNA
Signal input from an antenna, cable or
satellite.
TV ANTENNA
EN
33
English
g HDMI 2 (For selected models)
Digital audio and video input from high-
denition digital devices such as Blu-ray
players.
Connections via DVI or VGA require an
additional audio cable (see ‘Connect a
computer’ on page 35).
h EXT 2 (Y Pb Pr and AUDIO L/R)
Analogue audio and video input from
analogue or digital devices such as DVD
players or game consoles.
e PC IN (VGA and AUDIO IN)
Audio and video input from a computer.
f HDMI 1 ARC
Digital audio and video input from high-
denition digital devices such as Blu-ray
players. Also outputs TV audio to other
EasyLink-compliant devices, such as home
theatre systems.
Connections via DVI or VGA require an
additional audio cable (see ‘Connect a
computer’ on page 35).
VG A
VG A
AUDIO IN
LEFT/RIGHT
VGA/DVI
EN
34
d HDMI
Digital audio and video input from high-
denition digital devices such as Blu-ray
players.
e (Headphone)
Stereo audio output to headphones or
earphones.
f COMMON INTERFACE
Slot for a Conditional Access Module
(CAM).
Side connections
a AUDIO L/R
Audio input from analogue devices
connected to VIDEO.
b VIDEO
Composite video input from analogue
devices such as VCRs.
c USB
Data input from USB storage devices.
EN
35
English
• HDMI cable and HDMI-DVI adaptor
• VGA cable
DVI
AUDIO IN
LEFT/RIGHT
VGA/DVI
VGA
VGA
AUDIO IN
LEFT/RIGHT
VGA/DVI
Connect a computer
Before you connect a computer to the TV
• Set the screen refresh rate on your
computer to 60Hz.
• Select a supported screen resolution on
your computer.
Connect a computer with one of the following
connectors:
Note
• Connections via DVI or VGA require an additional
audio cable.
• HDMI cable
• DVI-HDMI cable
DVI
AUDIO IN
LEFT/RIGHT
VGA/DVI
EN
36
Access CAM services
1 Insert and activate the CAM (see ‘Insert
and activate a CAM’ on page 36).
2 Press OPTIONS.
3 Select [Common interface].
» Applications provided by the digital TV
service operator are displayed.
Note
• This menu option is available only if the CAM is
inserted and activated correctly.
Use Philips EasyLink
Get the most out of your HDMI-Consumer
Electronic Control (CEC) compliant devices
with Philips EasyLink enhanced control features.
If your HDMI-CEC compliant devices are
connected through HDMI, you can control
them at the same time with your TV remote
control.
To enable Philips EasyLink, you need to:
• Connect at least two HDMI-CEC
compliant devices through HDMI
• Congure each HDMI-CEC compliant
device properly
• Switch on EasyLink
Note
• The EasyLink-compliant device must be switched on
and selected as the source.
• Philips does not guarantee 100% interoperability with
all HDMI CEC devices.
Use a Conditional Access
Module
A Conditional Access Module (CAM) is
provided by digital TV service operators to
decode digital TV channels.
Note
• Refer to the documentation from your service
operator on how to insert a smart card into the
Conditional Access Module.
Insert and activate a CAM
Caution
• Be sure to follow the instructions described below.
Wrong insertion of a CAM may damage both the
CAM and your TV.
1 Switch off the TV and disconnect it from
the power outlet.
2 Following the directions printed on the
CAM, gently insert the CAM into the
COMMON INTERFACE at the side of the
TV.
3 Push the CAM in as far as it will go.
4 Reconnect the TV to the power outlet.
5 Turn on the TV and wait for the CAM to
be activated. This may take several minutes.
Do not remove the CAM from the slot
when in use — this action deactivates
digital services.
EN
37
English
Use one-touch standby
When you press on the TV remote control,
the TV and all HDMI-CEC compliant devices
switch to standby mode.
1 Press (Standby-On) on the TV’s or
device’s remote control.
» The TV and all connected HDMI
devices switch to standby.
Set TV speakers to EasyLink mode
If you connect an HDMI-CEC compliant device
that includes speakers, you can choose to hear
the TV from those speakers instead of the TV
speakers.
When you play content from an EasyLink
compliant home theatre, if you want to mute
the TV speakers automatically, turn on EasyLink
mode.
If the connected device is HDMI Audio Return
Channel (ARC) compliant, and you connect the
device through an HDMI ARC connector, you
can output TV audio through the HDMI cable.
You do not need an additional audio cable.
1 Make sure that the EasyLink-compliant
device is connected through an HDMI
ARC connector (see ‘Back connections’ on
page 32).
2 Select [Setup] > [TV settings] >
[EasyLink] > [TV speakers].
3 Select one of the following, then press OK.
• [Off]: Switch off TV speakers.
• [On]: Switch on TV speakers.
• [EasyLink]: Stream TV audio through
the connected HDMI-CEC device.
Switch the TV audio to the connected
HDMI-CEC audio device through the
adjust menu.
• [EasyLink autostart]: Turn off TV
speakers automatically and streams TV
audio to the connected HDMI-CEC
audio device.
Note
• To mute the TV speakers, select [TV speakers] > [Off].
Switch on or off EasyLink
When you play an HDMI-CEC compliant
device, the TV switches on from standby, and
switches to the correct source.
Note
• If you do not intend to use Philips EasyLink, switch it off.
1 Press .
2 Select [Setup] > [TV settings] >
[EasyLink] > [EasyLink].
3 Select [On] or [Off], then press OK.
Use one-touch play
1 After you switch on EasyLink, press play on
your device.
» The TV automatically switches to the
correct source.
Use one-touch play control
If you connect multiple HDMI-CEC devices that
support this setting, all such devices respond
to the play control buttons on this TV remote
control.
Caution
• This is an advanced setting. Devices that do not
support this setting will not respond to the TV remote
control.
1 Press .
2 Select [Setup] > [TV settings] >
[EasyLink] > [EasyLink remote control].
3 Select [On] or [Off], then press OK.
EN
38
Hear TV audio through another
device
If you connect an EasyLink- compliant device
that has speakers, you can get the most out of
those speakers if you listen to TV audio through
them.
If the connected device is HDMI-ARC
compliant, and you connect the device through
an HDMI ARC connector, you can output TV
audio through the HDMI cable. You will not
need an additional audio cable.
1 Make sure that the EasyLink-compliant
device is connected through an HDMI
ARC connector (see ‘Back connections’ on
page 32).
2 Press .
3 Select [Setup] > [TV settings] >
[EasyLink] > [HDMI1 - audio out], then
press OK.
4 Select one of the following, then press OK.
• [On]: Hear the TV audio through
the connected EasyLink device. You
cannot hear the TV audio through
the TV speakers or through devices
connected through the digital audio
out connector.
• [Off]: Hear the TV audio through the
TV speakers, or through a device
connected through the digital audio
out connector.
5 Control playback with the TV remote
control play buttons.
Switch all EasyLink devices to standby
To save electricity, you can switch all unused
EasyLink-compliant devices to standby.
1 Press the green button.
2 Select [Switch off unused sources], then
press OK.
» All connected EasyLink devices are
switched to standby.
Select speaker output with Adjust menu
If [EasyLink] or [EasyLink autostart] are
selected, access the adjust menu to switch the
TV audio.
1 While you watch TV, press ADJUST.
2 Select [Speaker], then press OK.
3 Select one of the following, then press OK:
• [TV]: On by default. Stream TV audio
through TV and the connected HDMI-
CEC audio device until the connected
device switches to system audio
control. TV audio is then streamed
through the connected device.
• [Amplier]: Stream audio through
the connected HDMI-CEC device. If
system audio mode is not enabled on
the device, audio continue to stream
from the TV speakers. If [EasyLink
autostart] was enabled, the TV
prompts the connected device to
switch to system audio mode.
Maximise display for subtitled video
Some subtitles can create a separate subtitle
bar under the video, which limits the video
display area. After you switch on auto subtitle
shift, the subtitles display over the video image,
which maximises the video display area.
1 Press .
2 Select [Setup] > [TV settings] >
[EasyLink] > [Auto subtitle shift] > [On],
then press OK.
Retain picture quality
If your TV picture quality is affected by the
picture-processing features of other devices,
switch on Pixel Plus Link.
1 Press .
2 Select [Setup] > [TV settings] >
[EasyLink] > [Pixel Plus Link] > [On],
then press OK.
EN
39
English
Use a Kensington lock
There is a Kensington security slot at the back
of the TV. Prevent theft by looping a Kensington
lock between the slot and a permanent object,
such as a heavy table.
EN
40
Tuner / Reception /
Transmission
• Antenna input: 75ohm coaxial (IEC75)
• DVB: DVB Terrestrial, DVB-C*, DVB-T,
MPEG4
• TV system: DVB COFDM 2K/8K; PAL I,
B/G, D/K; SECAM B/G, D/K, L/L’
• Video playback: NTSC, SECAM, PAL
• Tuner Bands: Hyperband, S-channel, UHF,
VHF
*For selected models
Remote control
• Type: PF01E11B
• Batteries: 2 x AAA (LR03 type)
Power
• Mains power: 220-240V, 50-60Hz
• Standby power:
• For xxPFL5xx6: < 0.15 W
• For xxPFL4xx6, xxPFL3xx6, and
DesignLine Tilt: < 0.3 W
• Ambient temperature: 5 to 40 degrees
Celsius
• For power consumption, see the product
specications at www.philips.com/support.
The power rating stated on the product
typeplate is the power consumption for this
product during normal household use (IEC
62087 Ed.2). The maximum power rating, stated
between brackets, is used for electrical safety
(IEC 60065 Ed. 7.2).
8 Product
information
Product information is subject to change
without notice. For detailed product
information, go to www.philips.com/support.
Supported display resolutions
Computer formats
• Resolution - refresh rate:
• 640 x 480 - 60 Hz
• 800 x 600 - 60 Hz
• 1024 x 768 - 60Hz
• 1280 x 720 - 60Hz
• 1280 x 768 - 60Hz
• 1280 x 1024 - 60 Hz
• 1360 x 768 - 60Hz
• 1680 x 1050 - 60Hz (For Full HD
only)
• 1920 x 1080 - 60 Hz (For Full HD
only)
Video formats
• Resolution - refresh rate:
• 480i - 60 Hz
• 480p - 60 Hz
• 576i - 50Hz
• 576p - 50 Hz
• 720p - 50 Hz, 60 Hz
• 1080i - 50 Hz, 60 Hz
• 1080p - 24Hz, 25Hz, 30Hz, 50Hz,
60Hz.
Multimedia
• Supported storage device: USB (Only
FAT or FAT 32 USB storage devices are
supported)
• Supported multimedia le formats:
• Images: JPEG
• Audio: MP3
• Video: MPEG 2/MPEG 4, H.264
EN
41
English
Product specication
Design and specications are subject to change
without notice.
47PFL4606H
• Without TV stand
• Dimension (WxHxD): 1129.8 x 697.8
x 83 (mm)
• Weight: 17.5 kg
• With TV stand
• Dimension (WxHxD): 1129.8 x 745.6
x 268 (mm)
• Weight: 20.9 kg
46PFL5606H
• Without TV stand
• Dimension (WxHxD): 1080.8 x 652.9
x 39.9 (mm)
• Weight: 16.9 kg
• With TV stand
• Dimension (WxHxD): 1080.8 x 705.2
x 294.9 (mm)
• Weight: 20.52 kg
42PFL4606H
• Without TV stand
• Dimension (WxHxD): 1018.5 x 635.1
x 83 (mm)
• Weight: 11.7 kg
• With TV stand
• Dimension (WxHxD): 1018.5 x 683 x
236.4 (mm)
• Weight: 14.2 kg
42PFL3606H/42PFL3506H
• Without TV stand
• Dimension (WxHxD): 1018.5 x 635.8
x 83 (mm)
• Weight: 11.7 kg
• With TV stand
• Dimension (WxHxD): 1018.5 x 683 x
236.4 (mm)
• Weight: 14.2 kg
Supported TV mounts
To mount the TV, purchase a Philips TV mount
or a compatible TV mount.
Warning
• Follow all instructions provided with the TV
mount. Koninklijke Philips Electronics N.V. bears no
responsibility for improper TV mounting that results in
accident, injury or damage.
Before you mount, perform these steps:
1 To prevent damage to cables and
connectors, leave a clearance of at least 2.2
inches or 5.5cm from the back of the TV.
2 For selected models, remove the wall
mount plugs from the back of the TV.
3 Make sure that your mounting bolts follow
these specications:
TV screen
size
(inches)
Required
pitch
(mm)
Required mounting
bolts
47 400 x 300 4 x M8 (10 mm)
46 400 x 400 4 x M6 (11/12 mm)
42 300 x 200 4 x M6 (10 mm)
40 400 x 400 4 x M6 (11/12 mm)
37 300 x 200 4 x M6 (10 mm)
32 200 x 200 4 x M6 (10 mm)
26 100 x 100 4 x M4 (10 mm)
22 100 x 100 4 x M4 (10 mm)
EN
42
32PFL3406H
• Without TV stand
• Dimension (WxHxD): 787.5 x 505.1
x 80.5 (mm)
• Weight: 7.8 kg
• With TV stand
• Dimension (WxHxD): 787.5 x 547.26
x 221.43 (mm)
• Weight: 9.4 kg
26PDL49x6H
• Without TV stand
• Dimension (WxHxD): 641.5 x 428.3
x 38.7(mm)
• Weight: 8.30 kg
• With TV stand
• Dimension (WxHxD): 641.5 x 428.3
x 166.4 (mm)
• Weight: 8.98 kg
22PDL49x6H
• Without TV stand
• Dimension (WxHxD): 532.5 x 357 x
36.6 (mm)
• Weight: 5.6 kg
• With TV stand
• Dimension (WxHxD): 532.5 x 357 x
127 (mm)
• Weight: 5.9 kg
40PFL5606H/40PFL5616H
• Without TV stand
• Dimension (WxHxD): 946 x 577.5 x
40 (mm)
• Weight: 12.3 kg
• With TV stand
• Dimension (WxHxD): 946 x 631 x
243.6 (mm)
• Weight: 15 kg
37PFL4606H
• Without TV stand
• Dimension (WxHxD): 912.3 x 577.1.
x 84.1 (mm)
• Weight: 10.3 kg
• With TV stand
• Dimension (WxHxD): 912.3 x 625.2
x 236.4 (mm)
• Weight: 12.8 kg
32PFL5x06H
• Without TV stand
• Dimension (WxHxD): 761 x 473 x
39.9 (mm)
• Weight: 7.2 kg
• With TV stand
• Dimension (WxHxD): 761 x 525.5 x
221 (mm)
• Weight: 8.9 kg
32PFL4606H
• Without TV stand
• Dimension (WxHxD): 795.6 x 510.6
x 93.1 (mm)
• Weight: 8.2 kg
• With TV stand
• Dimension (WxHxD): 795.6 x 557.6
x 221.4 (mm)
• Weight: 9.8 kg
32PFL3606H/32PFL3506H
• Without TV stand
• Dimension (WxHxD): 795.6 x 508.4
x 93.1 (mm)
• Weight: 8.2 kg
• With TV stand
• Dimension (WxHxD): 795.6 x 557.6
x 221.4 (mm)
• Weight: 9.8 kg
EN
43
English
Cannot remove ‘e-sticker’ banner displayed on
the TV.
• To remove the logos and images, set the
location of your TV to home.
1. Press .
2. Select [Setup] > [TV settings] >
[Preferences] > [Location].
3. Select [Home] and press OK.
TV channel issues
Previously installed channels do not appear in
the channel list:
• Check that the correct channel list is
selected.
No digital channels were found during the
installation:
• Check that the TV supports DVB-T, DVB-T
Lite or DVB-C in your country.
Some channels are not automatically installed
on my TV:
• During installation, make sure that you
select the country where you are installing
the TV.
Picture issues
The TV is on, but there is no picture:
• Check that the antenna is properly
connected to the TV.
• Check that the correct device is selected
as the TV source.
There is sound but no picture:
• Check that the picture settings are
correctly set.
There is poor TV reception from an antenna
connection:
• Check that the antenna is properly
connected to the TV.
• Loudspeakers, unearthed audio devices,
neon lights, high buildings and other large
objects can inuence reception quality.
If possible, try to improve the reception
quality by changing the antenna direction
or moving devices away from the TV.
9 Troubleshooting
This section describes commonly encountered
issues and accompanying solutions.
General TV issues
The TV does not switch on:
• Disconnect the power cable from the
power outlet. Wait for one minute then
reconnect it.
• Check that the power cable is securely
connected.
The remote control is not working properly:
• Check that the remote control batteries
are correctly inserted according to the
+/- orientation.
• Replace the remote control batteries if
they are at or weak.
• Clean the remote control and TV sensor
lens.
The standby light on the TV blinks red:
• Disconnect the power cable from the
power outlet. Wait until the TV cools down
before reconnecting the power cable. If the
blinking reoccurs, contact Philips Consumer
Care.
You forgot the code to unlock the TV lock
feature
• Enter ‘8888’.
The TV menu is in the wrong language.
• Change the TV menu to your preferred
language.
When turning the TV on/off/to standby, you
hear a creaking sound from the TV chassis:
• No action is required. The creaking sound
is normal expansion and contraction of the
TV as it cools down and warms up. This
does not impact performance.
EN
44
HDMI connection issues
There are problems with HDMI devices:
• Note that HDCP (High-bandwidth Digital
Content Protection) support can delay the
time taken for a TV to display content from
a HDMI device.
• If the TV does not recognise the HDMI
device and no picture is displayed, try
switching the source from one device to
another and back again.
• If there are intermittent sound disruptions,
check that output settings from the HDMI
device are correct.
• If you use an HDMI-to-DVI adapter
or HDMI-to-DVI cable, check that an
additional audio cable is connected to
AUDIO IN (mini-jack only).
Computer connection issues
The computer display on the TV is not stable:
• Check that your PC uses the supported
resolution and refresh rate.
• Set the TV picture format to unscaled.
Contact us
If you cannot resolve your problem, refer to the
FAQs for this product at
www.philips.com/support.
If the problem remains unresolved, contact
Philips Consumer Care in your country as listed
in the Addendum.
Warning
• Do not attempt to repair the product yourself. This may
cause severe injury, irreparable damage to your product
or void your warranty.
Note
• Make a note of your TV model and serial number
before you contact Philips. These numbers are printed
on the back of the TV and on the packaging.
• If reception on only one channel is poor,
ne tune this channel.
There is poor picture quality from connected
devices:
• Check that the devices are connected
properly.
• Check that the picture settings are
correctly set.
The TV did not save your picture settings:
• Check that the TV location is set to the
home setting. This mode offers you the
exibility to change and save settings.
The picture does not t the screen; it is too
big or too small:
• Try using a different picture format.
The picture position is incorrect:
• Picture signals from some devices may not
t the screen correctly. Check the signal
output of the device.
Sound issues
There is a picture but sound quality is poor:
Note
• If no audio signal is detected, the TV automatically
switches the audio output off — this does not indicate
malfunction.
• Check that all cables are properly
connected.
• Check that the volume is not set to 0.
• Check that the sound is not muted.
There is a picture but the sound quality is
poor:
• Check that the sound settings are correctly
set.
There is a picture but sound comes from one
speaker only:
• Verify that sound balance is set to the
centre.
EN
45
English
dimensions 41
display, wallpaper 22
E
EasyLink
control devices, from TV remote 37
enable 37
hear from other speakers
automatically 37
manually 38
picture quality, retain 38
subtitled video, maximise view 38
switch to standby, all devices 38
Electronic Programme Guide 20
environmental care
end of use 5
recycle 5
while you watch TV 6
EPG, menu 20
F
factory settings 28
favourites list, add 19
H
HDMI 32, 34
HDMI ARC 32
hearing impaired 18
high-denition (HD), content 32, 34
home menu 14
home mode 27
I
install
install channels
install channels (automatic) 29
K
kensington lock 39
10 Index
A
age rating 222222
analogue channels
language, change 23
audio language 23
C
CAM
enable 36
Insert 36
care 5
channels
channel list 11
favourites 19
hide or unhide 19
install (automatic) 29
rearrange 31
rename 31
reorder 31
switch 11
update 29
child lock 2222
clock 20
common interface 36
computer, see PC 35
Conditional Access Module 36
connect
connect device 32
connect, PC 35
connect, USB 24
connectors 32, 34
controls 7
D
demo 28
devices
add 14
watch 12
digital channels
digital radio 25
language, change 23
subtitles 2323
EN
46
software
digital broadcast update 27
version 26
sound settings 1717
specications 40
standby 10
subtitle, language 23
subtitles 23
switch 10
switch TV on or off 1011
T
teletext
dual screen 18
enlarge 18
subpages 18
Table Of Pages 19
teletext 2.5 19
troubleshoot 43
U
universal access 18
V
visually impaired 18
volume 12
W
wall mount 41
L
language
audio 23
menu 23
subtitles 23
location, home or shop 27
M
multimedia 24
multimedia, play les 24
mute TV speakers 3738
P
PC, display resolutions 40
picture format 16
picture settings 1516
Pixel Plus link 38
position the TV 27
power 40
R
recycle 5
reinstall TV 29
remote control
onscreen 37
overview 8
rename channels 31
reorder channels 31
S
Scenea, see screen saver 22
Scenea, switch on 22
screen care 5
screen saver 22
settings
assistant 15
picture 1516
sound 1717
shop mode 27
sleeptimer 21
smart picture 15
smart sound 17
EN
47
English
12nc
3104 315 7671.1
date
April 26, - 2010
name
Bob Vranken
product
UK Switch Over
leaflet
Recto
format / dimensions
sheet 148x210mm
material
paper 70 gr. satin
(maximum)
colours
- black
UFD
Brugge
148
Verso
Information about how to
re-tune your TV during the
digital TV switchover.
Info for UK only.
Television in the UK is going digital, bringing us
all more choice and new services. Starting in
late 2007 and ending in 2012, television
services in the UK will go completely digital, TV
region by TV region.
Please see the next page to find out when your
area switches to digital.
Digital UK is the independent, non-profit
organisation leading the process of digital TV
switchover in the UK. Digital UK provides im-
partial information on what people need to do
to prepare for the move to digital, and when
they need to do it.
How the switchover affects
your TV equipment:
Your new TV has a digital tuner built in, which
means it is ready to receive the Freeview signal
by simply plugging it into your aerial socket
(check if you can get digital TV through your
aerial now, or whether you’ll have to wait until
switchover, at www.digitaluk.co.uk).
When the TV switchover happens in your area,
there are at least two occasions when you will
need to re-tune your TV in order to continue
receiving your existing TV channels, and also to
pick up new ones.
*
*
Digital UK, the body leading the digital TV
switchover, will advise you when you need to
re-tune during the switchover.
If you do not re-tune your channels when
advised to do so by Digital UK, you may lose
some or all of your channels until you do
re-tune. You should re-tune your TV every
few months to check for any new channels.
If you choose to connect your TV to satellite or
cable with a digital box then it will not be
affected by switchover, and you won’t need to
re-tune.
If you have any questions, please contact your
equipment supplier or call Digital UK on …
0845 6 50 50 50 or visit www.digitaluk.co.uk
How to re-tune:
1. Press h on the remote control.
2. Select Setup and press OK.
3. Select Search for channels and press OK.
4. Select Reinstall channels and press OK.
5. Select your country (UK) and press OK.
6. Select Antenna DVB-T and press OK.
7. Select Start and press OK.
The installation can take several minutes.
When the installation is complete, press OK.
Your TV is now retuned.
If you are missing any channels, it may be
that they are not available in your area, or
that your aerial needs upgrading.
When does switchover happen?
Calls charged at BT rate of 3p per minute daytime and
1p per minute evenings and weekends. Rates may vary
for calls from non-BT lines.
Visit us at digitaluk.co.uk
Call us on 0845 6 50 50 50
†
Copeland switches on October 17, 2007
The exact date you switch
depends on the transmitter
you are served by. To check
when you switch, go to
Digital UK’s postcode
checker on
www.digitaluk.co.uk
Check your ITV news service
or look at Teletext page 106
to see what TV region you’re
in.
20100422
EN
48 EN
12nc
3104 315 7671.1
date
April 26, - 2010
name
Bob Vranken
product
UK Switch Over
leaflet
Recto
format / dimensions
sheet 148x210mm
material
paper 70 gr. satin
(maximum)
colours
- black
UFD
Brugge
148
Verso
Information about how to
re-tune your TV during the
digital TV switchover.
Info for UK only.
Television in the UK is going digital, bringing us
all more choice and new services. Starting in
late 2007 and ending in 2012, television
services in the UK will go completely digital, TV
region by TV region.
Please see the next page to find out when your
area switches to digital.
Digital UK is the independent, non-profit
organisation leading the process of digital TV
switchover in the UK. Digital UK provides im-
partial information on what people need to do
to prepare for the move to digital, and when
they need to do it.
How the switchover affects
your TV equipment:
Your new TV has a digital tuner built in, which
means it is ready to receive the Freeview signal
by simply plugging it into your aerial socket
(check if you can get digital TV through your
aerial now, or whether you’ll have to wait until
switchover, at www.digitaluk.co.uk).
When the TV switchover happens in your area,
there are at least two occasions when you will
need to re-tune your TV in order to continue
receiving your existing TV channels, and also to
pick up new ones.
*
*
Digital UK, the body leading the digital TV
switchover, will advise you when you need to
re-tune during the switchover.
If you do not re-tune your channels when
advised to do so by Digital UK, you may lose
some or all of your channels until you do
re-tune. You should re-tune your TV every
few months to check for any new channels.
If you choose to connect your TV to satellite or
cable with a digital box then it will not be
affected by switchover, and you won’t need to
re-tune.
If you have any questions, please contact your
equipment supplier or call Digital UK on …
0845 6 50 50 50 or visit www.digitaluk.co.uk
How to re-tune:
1. Press h on the remote control.
2. Select Setup and press OK.
3. Select Search for channels and press OK.
4. Select Reinstall channels and press OK.
5. Select your country (UK) and press OK.
6. Select Antenna DVB-T and press OK.
7. Select Start and press OK.
The installation can take several minutes.
When the installation is complete, press OK.
Your TV is now retuned.
If you are missing any channels, it may be
that they are not available in your area, or
that your aerial needs upgrading.
When does switchover happen?
Calls charged at BT rate of 3p per minute daytime and
1p per minute evenings and weekends. Rates may vary
for calls from non-BT lines.
Visit us at digitaluk.co.uk
Call us on 0845 6 50 50 50
†
Copeland switches on October 17, 2007
The exact date you switch
depends on the transmitter
you are served by. To check
when you switch, go to
Digital UK’s postcode
checker on
www.digitaluk.co.uk
Check your ITV news service
or look at Teletext page 106
to see what TV region you’re
in.
20100422
© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
