WEEE Number
: 80133970
INSTALLATION INSTRUCTION
T8 LED Tubes
EL
LED replacement starter
(Included in the packaging)
LED Tubes not suitable for
emergency operations
LED Tubes are NOT suitable for
dimming
LED Lamps suitable for 50Hz
operation
LED Lamps to be used in dry conditions
or in a luminaire that provides protection
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
DUMMY STARTER
INCLUDED
STARTER
FOR LED TUBES
W
H
MODEL VT-6072 VT-9077 VT-1277 VT-1577
WATTS 10W 14W 18W 22W
LUMENS 850LM 1200LM 1700LM 2000LM
PF >0.5 >0.5 >0.5 >0.5
CRI >80 >80 >80 >80
BEAM ANGLE 160° 160° 160° 160°
BODY TYPE Plastic Plastic Plastic Plastic
HOLDER G13 G13 G13 G13
ON/OFF CYCLE >15,000 >15,000 >15,000 >15,000
LONG LIFE 30,000 HOURS 30,000 HOURS 30,000 Hours 30,000 Hours
DIMENSION 27.9x600mm 27.9x900mm 27.9x1200mm 27.9x1500mm
INPUT POWER AC:220-240V,50Hz AC:220-240V,50Hz AC:2
20-240V,50Hz AC:220
-240V,50Hz
TECHNICAL DATA:
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
WARRANTYWARRANTY
YEARSYEARS
33
PREMIUMPREMIUM
QUALITYQUALITY
