Table of contents
[en]I ns t r u ct i on manual Bui l t - i n ov en
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
( Important safety information . . . . . . . . . . . . . . . 4
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Halogen lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
] Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 6
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Installation and connection. . . . . . . . . . . . . . . . . 6
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Measures to be noted during transport . . . . . . . . . . . . 7
7 Environmental protection . . . . . . . . . . . . . . . . . . 7
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 8
* Getting to know your appliance . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Buttons and display . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Types of heating and functions . . . . . . . . . . . . . . . . . . 9
Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cooking compartment . . . . . . . . . . . . . . . . . . . . . . . . 10
_ Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 11
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 11
K Before using for the first time. . . . . . . . . . . . . . 12
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cleaning the cooking compartment and accessories 12
1 Operating the appliance . . . . . . . . . . . . . . . . . . 13
Switching the appliance on and off . . . . . . . . . . . . . . 13
Setting the heating function and temperature . . . . . . 13
Rapid heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
O Time-setting options . . . . . . . . . . . . . . . . . . . . . 14
Setting a cooking time . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the end time . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
A Childproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 16
Activating and deactivating . . . . . . . . . . . . . . . . . . . . 16
Q Basic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
List of basic settings . . . . . . . . . . . . . . . . . . . . . . . . . 16
Changing the basic settings. . . . . . . . . . . . . . . . . . . . 16
D Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .17
Surfaces in the cooking compartment . . . . . . . . . . . .19
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .19
p Rails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Detaching and refitting the rails . . . . . . . . . . . . . . . . .20
q Appliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Detaching and attaching the oven door . . . . . . . . . . .20
Removing and refitting the door panels . . . . . . . . . . .21
Additional door safety. . . . . . . . . . . . . . . . . . . . . . . . .21
3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 22
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .22
Replacing the bulb in the top of the cooking
compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
4 Customer service . . . . . . . . . . . . . . . . . . . . . . . . 23
E number and FD number . . . . . . . . . . . . . . . . . . . . .23
J Tested for you in our cooking studio. . . . . . . . 23
General information . . . . . . . . . . . . . . . . . . . . . . . . . .23
Cakes and pastries. . . . . . . . . . . . . . . . . . . . . . . . . . .24
Bakes and gratins . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Poultry, meat and fish . . . . . . . . . . . . . . . . . . . . . . . . .28
Vegetables and side dishes . . . . . . . . . . . . . . . . . . . .31
Yoghurt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . .31
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Prove dough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Cooking more than one dish/course at a time . . . . . 35
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com
en Intended use
4
8Intended use
Intended use
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
The images shown in these instructions are for
guidance only.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~ "Accessories" on page 11
(Important safety
information
Impor t ant saf et y informat i on
General information
:Warning – Risk of fire!
■ Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■ Loose food remnants, fat and meat juices
may catch fire. Before using the appliance,
remove the worst of the food remnants from
the cooking compartment, heating elements
and accessories.
Risk of fire!
■ A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■ The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■ Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■ Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
:Warning – Risk of scalding!
■ The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■ When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Important safety information en
5
Risk of scalding! ■ Water in a hot cooking compartment may
create hot steam. Never pour water into the
cooking compartment when the cooking
compartment is hot.
:Warning – Risk of injury!
■ Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■ The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
Risk of injury!
■ If you leave the appliance door open,
people may bump into it, resulting in injury.
The appliance door must be kept closed
both while the appliance is in operation and
when it has finished.
:Warning – Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the after-
sales service.
Risk of electric shock and serious injury!
■ The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■ Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■ A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
Halogen lamp
:Warning – Risk of burns!
The bulbs in the cooking compartment
become very hot. There is still a risk of burning
your skin for some time after they have been
switched off. Do not touch the glass cover.
Avoid contact with your skin when cleaning.
:Warning – Risk of electric shock!
When replacing the cooking compartment
bulb, the bulb socket contacts are live. Before
replacing the bulb, unplug the appliance from
the mains or switch off the circuit breaker in
the fuse box.
en Causes of damage
6
]Causes of damage
Ca u s e s of damage
General information
Caution!
■ Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■ Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■ Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■ Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■ Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■ Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■ Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean. Never
operate the appliance if the seal is damaged or
missing. ~ "Cleaning" on page 17
■ Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■ Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■ Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
5Installation and connection
Installation and connect i on
This appliance is only intended to be fully fitted in a
kitchen. Observe the special installation instructions.
Do not install the appliance behind a decorative door or
the door of a kitchen unit, as this may cause the
appliance to overheat.
Electrical connection
Only licensed specialists may connect the appliance.It
is important that you comply with the requirements of
your electricity supplier.
Any damage arising from the appliance being
connected incorrectly will invalidate the warranty.
Caution!
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
■ The appliance must be disconnected from the power
supply whenever installation work is being carried
out.
■ The appliance fulfils the requirements of protection
class I and may only be connected to an earthed
socket.
■ The mains power cable must be at least type
H05 V V-F 3G, 1.5 mm².
:Warning – Danger of death!
There is a risk of electric shock if you touch live
components.
■ Always make sure your hands are dry when you
touch or hold the mains plug.
■ Only pull out the mains cable by taking hold of the
plug and removing the plug; never pull it out by the
mains cable itself, as this could damage it.
■ Never unplug the mains plug when the appliance is
in operation.
Please note the following information and ensure that:
Notes
■ The mains plug fits the socket.
■ The cable cross section is adequate.
■ The earthing system is properly installed.
■ The mains cable is only replaced by a qualified
electrician (if this is necessary).Spare mains cables
can be ordered from our after-sales service.
■ No power strips/multi-way connectors or extension
cables are used.
■ If using a residual current device, only use one that
bears the mark z.
The presence of this mark is the only way to be sure
that it fulfils all the applicable regulations.
■ The mains plug can be accessed at all times.
■ The mains cable is not kinked, crushed, modified or
severed.
■ The mains cable does not come into contact with
heat sources.
Environmental protection en
7
Measures to be noted during transport
Secure all mobile parts in and on the appliance using
an adhesive tape that can be removed without leaving
any traces. Push all accessories (e.g. baking tray) into
the corresponding slots with cardboard at the edges, in
order to avoid damaging the appliance. Place
cardboard or similar between the front and rear side to
prevent knocks against the inside of the glass door.
Secure the door and, if available, the top cover to the
appliance sides using adhesive tape.
Keep the original appliance packaging. Only transport
the appliance in the original packaging. Observe the
transport arrows on the packaging.
If the original packaging is no longer available
pack the appliance in protective packaging to
guarantee sufficient protection against any transport
damage.
Transport the appliance in an upright position. Do not
hold the appliance by the door handle or the
connections on the rear, as these could be damaged.
Do not place any heavy objects on the appliance.
7Environmental protection
En v i r o nment al pr ot ec t i on
Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■ Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■ Leave frozen food to defrost before placing it in the
cooking compartment.
■ Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■ Remove any unnecessary accessories from the
cooking compartment.
en Getting to know your appliance
8
■ Open the appliance door as infrequently as possible
when the appliance is in use.
■ It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
■ For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
*Getting to know your
appliance
Get t i ng to know your appl i ance
In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
Control panel
You can set your appliance's various functions on the
control panel. Below, you will see an overview of the
control panel and the layout of the controls.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment -
WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
(
Buttons and display
The buttons are touch keys with sensors
underneath. Simply touch a symbol to select the
function.
The display shows symbols for active functions
and the time-setting options.
0
Function selector
Use the function selector to set the heating
function or other functions.
You can turn the function selector clockwise or
anti-clockwise from the "Off" position.
Getting to know your appliance en
9
Note: On some appliances, the control knobs can be
pushed in. To push the control knob in and engage it or
to release it again, turn it to the "Off" position.
Buttons and display
You can use the buttons to set various additional
functions on your appliance. You will be able to see the
values for these on the display.
--------
Display
The value that can be set at the present time or that is
elapsing will be shown in large digits on the display.
To use the individual time-setting options, tap the
v button several times.If there is a red bar above or
below a symbol, this means that the value being shown
in large digits on the display refers to the function that
this symbol represents.
Types of heating and functions
Use the function selector to set the types of heating and
other functions.
To make sure you always use the right type of heating
to cook your food, we have explained the differences
and applications below.
8
Temperature selector
Use the temperature selector to set the
temperature for the heating function or select the
setting for other functions.
You can only turn the temperature selector
clockwise from the "Off" position, until it offers
resistance. Do not turn the selector beyond this
point.
Symbol Meaning
v
Time-setting options Tap the symbol repeatedly to select
the time v, timer t, duration y
and end time {.
A
@
Minus
Plus
Reduce setting values.
Increase setting values.
D
Childproof lock Lock and unlock the oven functions
on the control panel.
Type of heating Use
<
3D hot air For baking and roasting on one or more levels.
The fan distributes the heat from the ring heating element in the back panel evenly around
the cooking compartment.
6
Gentle hot air For gently cooking selected types of food on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back panel
around the cooking compartment.
This heating function is used to measure both the energy consumption in air recirculation
mode and the energy efficiency class.
$
Pizza setting For cooking pizza and dishes that require a lot of heat from underneath.
The bottom heating element and the ring heating element in the back panel heat up.
$
Bottom heating For cooking in a bain marie and for baking food for extra time.
Heat is emitted from below.
(
Grill, large area For grilling flat items, such as steaks or sausages, for making toast, and for browning
food.
The whole area below the grill element becomes hot.
7
Circulated air grilling For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the hot air
around the food.
%
Top/bottom heating For traditional baking and roasting on one level. Especially suitable for cakes with moist
toppings.
Heat is emitted evenly from above and below.
This heating function is used to measure the energy consumption in the conventional
mode.
en Getting to know your appliance
10
--------
Other functions
Your new oven has yet more functions; see below for a
brief description of these.
--------
Temperature
Use the temperature selector to set the temperature in
the cooking compartment. You can also use it to select
the settings for other functions.
For temperature settings above 250 °C, the appliance
reduces the temperature to approx. 240 °C after
approx. 10 minutes. If your appliance has the top/
bottom heating or bottom heating types, this reduction
does not take place.
--------
Temperature indicator
The line at the bottom of the display turns red in three
increments, from left to right, as the cooking
compartment heats up.
When you are preheating the appliance, the optimal
time to place your food in the cooking compartment is
as soon as all three sections of the line have turned red.
When the appliance is in operation, one of the red
sections of the line will go out during the heating
phases.
Note: Due to thermal inertia, the temperature displayed
may be slightly different to the actual temperature inside
the oven.
Cooking compartment
Various functions in the cooking compartment make
your appliance easier to use. For example, the cooking
compartment is well lit and a cooling fan prevents the
appliance from overheating.
Opening the appliance door
If you open the appliance door when the appliance is in
operation, the appliance will continue to operate as
before.
Interior lighting
With most heating functions and other functions, the
interior lighting in the cooking compartment will remain
lit while the oven is in operation. When the function
selector is turned to bring operation to an end, the
lighting will go out.
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
quickly after operation, the cooling fan continues to run
for a certain period afterwards.
Function Use
F
Rapid heating Preheats the cooking compartment rapidly without accessories.
Position Meaning
Ú
"Off" position The appliance is not heating.
50-275 Temperature range The temperature that can be set
in the cooking compartment in °C.
1, 2, 3
or
I, II, III
Grill settings The configurable settings for the
grill, large area ( and small
area * (depending on the appli-
ance model).
Setting 1 = low
Setting 2 = medium
Setting 3 = high
Wet cleaning assistance The wet cleanin assistance takes the hard work out of cleaning your cooking
compartment.
Accessories en
11
_Accessories
Accessor i es
Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
--------
Only use genuine accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
Note: The accessories may become deformed when
they become hot. This does not affect their function.
Once they cool down again, they regain their original
shape.
Inserting accessories
The cooking compartment has five shelf positions. The
shelf positions are counted from the bottom up.
In some appliances, the highest shelf position is
marked on the cooking compartment by the grill
symbol.
Always insert accessories between the two guide rods
for the shelf position.
Accessories can be pulled out approximately halfway
without tipping. You can use the pull-out rails to pull the
accessories out further.
Depending on the appliance features, the pull-out rails
should lock in place when they are fully pulled out. This
makes it easy to place the accessories in position. To
unlock the pull-out rails, use a little force to push them
back into the cooking compartment.
When sliding accessories into the cooking
compartment, ensure that the kink in the side rail is at
the back. Only then will they lock in place.
Notes
■ Hold the baking tray securely at the sides with both
hands and slide it into the shelf supports, keeping it
parallel. Do not move the baking tray from side to
side as you slide it in, otherwise it will not go in easily
and the enamelled surfaces may be damaged.
■ Make sure that you always insert the accessories
into the cooking compartment the right way round.
■ Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
■ Take any accessories that you will not be using out
of the cooking compartment.
Optional accessories
You can buy optional accessories from our after-sales
service, from specialist retailers or online. You will find a
comprehensive range of products for your appliance in
our brochures and online.
Their availability and whether it is possible to order
them online varies from country to country. See your
sales brochures for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, always quote the exact
product number (E no.) of your appliance.
~ "Customer service" on page 23
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
you are grilling directly on the wire rack.
Baking tray
For tray bakes and small baked prod-
ucts.
Optional accessories
Wire rack
For cookware, cake tins and ovenproof dishes, and for roasts and
grilled food.
Baking tray
For tray bakes and small baked items.
Universal pan
For moist cakes, baked items, frozen food and large roasts.
It can be used to catch dripping fat when you are grilling directly on
the wire rack.
Wire insert
For meat, poultry and fish.
For inserting into the universal pan to catch dripping fat and meat
juices.
en Before using for the first time
12
--------
KBefore using for the first
time
Be f o r e us i ng for the first time
Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
The time will appear on the display once the appliance
is connected to the power supply. Set the current time.
Setting the time
Make sure that the function selector is set to the "Off"
position.
The time starts at "12:00".
1. Use the A or @ button to set the time.
2. Touch the v button to confirm.
The current time will be shown on the display.
Cleaning the cooking compartment and
accessories
Before using the appliance to prepare food for the first
time, you must clean the cooking compartment and
accessories.
Cleaning the cooking compartment
To remove the new-appliance smell, heat up the
cooking compartment when empty and with the oven
door closed.
Ensure that there is no leftover packaging, such as
polystyrene pellets, in the cooking compartment and
remove the adhesive tape that is in or on the appliance.
Before heating the appliance, wipe the smooth surfaces
in the cooking compartment with a soft, damp cloth.
Keep the kitchen ventilated while the appliance is
heating.
Make the settings indicated. You can find out how to set
the heating function and the temperature in the next
section. ~ "Operating the appliance" on page 13
Professional pan
For preparing large quantities of food. Also ideal for moussaka, for
example.
Lid for the professional pan
The lid turns the professional pan into a professional roasting dish.
Pizza tray
For pizzas and large round cakes.
Grill tray
Use for grilling in place of the wire rack or as a splatter guard. Use in
the universal pan only.
Baking stone
For home-made bread, bread rolls and pizzas that you wish to have a
crispy base.
The baking stone must be preheated to the recommended tempera-
ture.
Glass roasting dish
For stews and bakes.
Glass pan
For bakes, vegetable dishes and baked items.
Pull-out system, one level
Fitting pull-out rails at position 2 will allow you to pull accessories out
further without them tipping.
Pull-out system, two levels
Fitting pull-out rails at positions 2 and 3 will allow you to pull accesso-
ries out further without them tipping.
Pull-out system, three levels
Fitting pull-out rails at positions 1, 2 and 3 will allow you to pull acces-
sories out further without them tipping.
Operating the appliance en
13
Switch off the appliance after the specified duration.
After the cooking compartment has cooled down, clean
the smooth surfaces with soapy water and a dish cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
1Operating the appliance
Oper at i ng the appl i anc e
You have already learnt about the controls and how
they work. Now we will explain how to apply settings on
your appliance.
Switching the appliance on and off
Use the function selector to switch the appliance on or
off. Turning the function selector to any position other
than the "Off" position switches on the appliance. To
switch off the appliance, always turn the function
selector to the "Off" position.
Setting the heating function and temperature
The function selector and temperature selector make it
very easy to apply the settings you require to your
appliance. To find out which heating function is best for
which type of food, please refer to the beginning of the
instruction manual. ~ "Getting to know your
appliance" on page 8
Example in the picture: Top/bottom heating % at
190 °C.
1. Use the function selector to set the heating function.
2. Use the temperature selector to set the temperature
or grill setting.
The appliance will start heating after a few seconds.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Note: You can set both a cooking time and an end time
on the appliance. ~ "Time-setting options" on page 14
Changing
The heating function and temperature can be changed
at any time using the relevant selector.
Rapid heating
With Rapid heating, you can shorten the heat-up time.
Then, for best results, use:
■ < 3D hot air
■ % Top/bottom heating
Only use Rapid heating when a temperature of over
100 °C has been selected.
To achieve an even cooking result, do not place your
food into the cooking compartment until Rapid heating
is complete.
1. Set the function selector to F.
2. Use the temperature selector to set the temperature.
The oven will start heating after a few seconds.
Once Rapid heating is complete, an audible signal will
sound. Place your food in the cooking compartment.
Settings
Heating function
3D hot air <
Temperature maximum
Cooking time 1 hour
&
en Time-setting options
14
OTime-setting options
Ti me- set t i ng opt i ons
Your appliance has different time-setting options.
Before you can call up the cooking time using the
v button, you will need to set a heating function.Once
you have set a cooking time, the end time can be called
up. The timer can be set at any time.
An audible signal will sound once the cooking time or
timer duration has elapsed. You can cancel the audible
signal early by touching the v button.
Note: You can change how long the audible signal
sounds for in the basic settings. ~ "Basic settings"
on page 16
Setting a cooking time
You can set the cooking time for your food on the
appliance. This prevents the food from accidentally
being cooked for too long, and means that you do not
have to stop what you are doing to switch off the oven.
The maximum time that can be set is 23 hours and 59
minutes. The cooking time can be set in 1-minute
increments up to 1 hour, and in 5-minute increments
thereafter.
The cooking time starts at a different default value
depending on which button you touch first:
10 minutes if you touch the A button and 30 minutes if
you touch the @ button.
Example in the picture: Cooking time of 45 minutes.
1. Setting the heating function and temperature or
setting
2. Touch the v button twice.
The cooking time y is highlighted in the display.
3. Use the A or @ button to set the cooking time.
The appliance starts to heat up after a few seconds. The
cooking time counts down in the display.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @ button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the A or @ button to change the cooking
time at any time.After a few seconds, the change will be
applied.
To cancel, use the A button to reset the cooking time all
the way to zero. The appliance will continue heating
without a cooking time.
Checking time-setting options
If time-setting options have been set, the corresponding
symbols are lit up on the display. The symbol for which
the time is currently being displayed will be indicated.
To check the values for the different time-setting
options, touch the v button repeatedly until the
required symbol is indicated.
Setting the end time
You can delay the time at which cooking is due to
finish. You can, for example, put your food in the
cooking compartment in the morning and set the
cooking time so that it is ready at lunch time.
Notes
■ Make sure that food is not left in the cooking
compartment for too long as it may spoil.
■ Do not adjust the end time once the appliance is
already in operation. Otherwise the cooking result
may no longer be satisfactory.
The end of the cooking time can be delayed by up to
23 hours 59 minutes.
Example in the picture: The time is 10.30 a.m., a
cooking time of 45 minutes has been set and you want
the food to be ready at 12.30 p.m.
1. Setting the heating function and temperature or
setting
Time-setting option Use
y
Cooking time Once the set cooking time has elapsed, the
appliance will automatically stop heating.
{
End time Enter a cooking time and the required end
time. The appliance will start up automatically
so that it finishes cooking at the required time.
t
Timer The timer functions like an egg timer. It runs
independently of the appliance when it is
heating and of other time-setting options and
does not affect the appliance.
v
Time When no other function is running in the fore-
ground, the appliance will show you the time
of day on the display.
[
Time-setting options en
15
2. Touch the v button twice and use the A or @ button
to set the cooking time.
3. Touch the v button again.
The end time { is highlighted in the display.
4. Use the @ or A button to delay the end time.
The appliance applies the settings after a few seconds.
The end time is shown in the display. Once the
appliance starts, the cooking time begins to count
down.
The cooking time has elapsed
An audible signal will sound. The appliance will stop
heating. The cooking time will be zero on the display.
Once the signal stops, you can touch the @ button to
set a new cooking time.
Once your food is cooked, turn the function selector to
the "Off" position to switch the appliance off.
Changing and cancelling
You can use the A or @ button to change the end time.
After a few seconds, the change will be applied. The
end time cannot be changed once the cooking time has
already started to count down. Otherwise the cooking
result would no longer be satisfactory.
To cancel, use the A button to set the end time all the
way back to the current time plus the cooking time. The
appliance will start to heat and the cooking time will
start to count down.
Checking time-setting options
If time-setting options have been set, the corresponding
symbols are lit up on the display. The symbol for which
the time is currently being displayed will be indicated.
To check the values for the different time-setting
options, touch the v button repeatedly until the
required symbol is indicated.
Setting the timer
The timer runs alongside other settings. You can set it
at any time, even if the appliance has been switched off.
It has its own audible signal so that you can tell whether
it is the timer or a cooking time that has elapsed.
The maximum time that can be set is 23 hours and 59
minutes. Up to 10 minutes, the timer duration can be
set in 30-second increments.Above 10 minutes, the
time increments become longer the higher the value.
The timer duration will start at a different default value,
depending on which button you touch first:
5 minutes if you touch the A button and 10 minutes if
you touch the @ button.
1. Touch the v button until the timer symbol t is
underlined.
2. Use the A or @ button to set the timer duration.
After a few seconds, the timer duration will start to
count down.
Tip: If the set timer duration is the duration for which
you wish to cook your food, use the cooking time. The
appliance will then switch off automatically when it has
finished cooking.
The timer duration has elapsed
An audible signal will sound. The timer duration will be
zero on the display.
Touch any button to switch off the timer.
Changing and cancelling
You can use the A or @ button to change the timer
duration at any time. After a few seconds, the change
will be applied.
To cancel, use the A button to reset the timer duration
all the way to zero. The timer is now switched off.
Checking time-setting options
If time-setting options have been set, the corresponding
symbols are lit up on the display. The symbol for which
the time is currently being displayed will be indicated.
To check the values for the different time-setting
options, touch the v button repeatedly until the
required symbol is indicated.
Setting the time
Once the appliance has been connected to the mains
or following a power failure, the clock will flash on the
display. Set the time.
The function selector must be set to the "Off" position.
1. Use the A or @ button to set the time.
The time will stop flashing.
2. Confirm by pressing the v button.
The appliance will apply the time you have set.
Note: You can go to the basic settings to specify
whether or not the time should be shown on the display.
~ "Basic settings" on page 16
en Childproof lock
16
Changing the time
You can change the time again when you need to, e.g.
from summer to winter time.
To do this, when the appliance is switched off, touch the
v button until the symbol for the time is underlined,
and use the A or @ button to change the time.
AChildproof lock
Childproof lock
Your appliance is equipped with a childproof lock so
that children cannot switch it on accidentally or change
any settings.
Notes
■ You can go to the basic settings to specify whether
you want the option to set the childproof lock.
~ "Basic settings" on page 16
■ If a hob is connected, it will not be affected by the
childproof lock on the oven.
■ After a power cut, the childproof lock will no longer
be active.
Activating and deactivating
To activate the childproof lock, the function selector
must be set to the "Off" position.
Press and hold the D button for approx. 4 seconds.
The symbol for this function will appear on the display.
The childproof lock is now activated.
Note: If a timer duration t has been set, this will
continue to count down. While the childproof lock is
active, the timer duration cannot be changed.
To deactivate the childproof lock, press and hold the
D button again for approx. 4 seconds until the symbol
goes out on the display.
QBasic settings
Ba s i c set t i ngs
There are various settings available to you in order to
help use your appliance effectively and simply. You can
change these settings as required.
List of basic settings
Depending on the features of your appliance, not all
basic settings will be available.
--------
Changing the basic settings
The function selector must be set to the "Off" position.
1. Press and hold the v button for approx. 4 seconds.
The first basic setting will appear on the display,
e.g. ™‚ ‚.
2. Use the A or @ button to change the setting if
necessary.
3. Press the v button to confirm.
The next basic setting will appear on the display.
4. Using the v button, continue going through all the
basic settings as described above, changing the
settings if necessary using the A or @ button.
5. When you have finished, press and hold the
v button again for approx. 4 seconds to confirm the
settings.
All basic settings have now been applied.
Basic setting Options
™‚
Display the time
‹ = Hide the time
‚ = Display the time*
™ƒ
Audible signal duration
upon completion of a cook-
ing time or timer duration
‚ = Approx. 10 seconds
ƒ = Approx. 30 seconds*
„ = Approx. 2 minutes
™„
Button tone that sounds
when a button is touched
‹ = off
‚ = on*
™…
Cooling fan run-on time
‚ = Short
ƒ = Medium
„ = Long*
… = Extra long
™†
Amount of time until a set-
ting is applied
‚ = Approx. 3 seconds*
ƒ = Approx. 6 seconds
„ = Approx. 10 seconds
™‡
Enable childproof lock acti-
vation
‹ = No
‚ = Yes*
™ˆ
Water hardness**
‹ = softened
‚ = soft (up to 1.3 mmol/l)
ƒ = medium (1.3 - 2.5 mmol/l)
„ = hard (2.5 - 3.8 mmol/l)
… = very hard* (above 3.8 mmol/
l)
* Factory setting (factory settings may vary depending on the appli-
ance model)
** Not available for all appliance types.
Cleaning en
17
You can change the basic settings again at any time.
Note: Following a power failure, the basic factory
settings will be restored.
DCleaning
Cl eani ng
With good care and cleaning, your appliance will retain
its appearance and remain fully functioning for a long
time to come. We will explain here how you should
correctly care for and clean your appliance.
Suitable cleaning agents
To ensure that the different surfaces are not damaged
by using the wrong cleaning agent, observe the
information in the table. Depending on the appliance
model, not all of the areas listed may be on/in your
appliance.
Caution!
Risk of surface damage
Do not use:
■ Harsh or abrasive cleaning agents,
■ Cleaning agents with a high alcohol content,
■ Hard scouring pads or cleaning sponges,
■ High-pressure cleaners or steam cleaners,
■ Special cleaners for cleaning the appliance while it is
hot.
Wash new sponge cloths thoroughly before use.
Tip: Highly recommended cleaning and care products
can be purchased through the after-sales service.
Observe the respective manufacturer's instructions.
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
--------
Notes
■ Slight differences in colour on the front of the
appliance are caused by the use of different
materials, such as glass, plastic and metal.
■ Shadows on the door panels, which look like
streaks, are caused by reflections made by the
interior lighting.
Area Cleaning
Appliance exterior
Stainless steel
front
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Remove flecks of limescale, grease, starch and
albumin (e.g. egg white) immediately. Corrosion
can form under such flecks.
Special stainless steel cleaning products suitable
for hot surfaces are available from our after-sales
service or from specialist retailers. Apply a very
thin layer of the cleaning product with a soft cloth.
Plastic Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Painted surfaces Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Control panel Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use glass cleaner or a glass scraper.
Door panels Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
Do not use a glass scraper or a stainless steel
scouring pad.
Door handle Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If descaler comes into contact with the door han-
dle, wipe it off immediately. Otherwise, any stains
will not be able to be removed.
Appliance interior
Enamel surfaces
and self-cleaning
surfaces
Observe the instructions for the surfaces of the
cooking compartment that follow the table.
Glass cover for
the interior light-
ing
Hot soapy water:
Clean with a dish cloth and then dry with a soft
cloth.
If the cooking compartment is heavily soiled, use
oven cleaner.
Door seal
Do not remove.
Hot soapy water:
Clean with a dish cloth.
Do not scour.
Door cover made from stainless steel:
Use stainless steel cleaner. Follow the manufac-
turers' instructions. Do not use stainless steel
care products.
made from plastic:
Clean using hot soapy water and a dish cloth. Dry
with a soft cloth. Do not use glass cleaner or a
glass scraper.
Remove the door cover for cleaning.
Rails Hot soapy water:
Soak and clean with a dish cloth or brush.
Pull-out system Hot soapy water:
Clean with a dish cloth or a brush.
Do not remove the lubricant while the pull-out rails
are pulled out – it is best to clean them when they
are pushed in. Do not clean in the dishwasher.
Accessories Hot soapy water:
Soak and clean using a dishcloth or brush.
If there are heavy deposits of dirt, use a stainless
steel scouring pad.
Enamelled accessories are dishwasher-safe.
en Cleaning
18
■ Enamel is baked on at very high temperatures.This
can cause some slight colour variation. This is
normal and does not affect operation.
The edges of thin trays cannot be completely
enamelled. As a result, these edges can be rough.
This does not impair the anti-corrosion protection.
Wet-cleaning assistant
The wet-cleaning assistant takes the hard work out of
cleaning your cooking compartment. Dirt is presoaked
by vaporising the soapy water, making it easier to
remove this dirt afterwards.
:Risk of scalding!
Water in a hot cooking compartment may create hot
steam. Never pour water into the cooking compartment
when the cooking compartment is hot.
Setting the cleaning assistant
The wet-cleaning assistant can only be used in the
cooking compartment when the cooking compartment
is cold. Allow the cooking compartment to completely
cool down.
1.
2.
Remove any accessories from the cooking
compartment.
Mix 0.4 litres of water (not distilled water) with a drop
of washing-up liquid and pour into the middle of the
cooking compartment floor (fig. !).
3. Close the appliance door.
4. Use the function and temperature selector to select
the function.
5.. The appliance will start heating after a few second
Wait for 4 mins.
6.. After 4 minutes, turn the selection switch a
temperature switch to off position.
7.Wait 20-30 min. to open the applicance door
Subsequent cleaning
The remaining water in the cooking compartment must
be removed promptly. Do not leave the remaining water
in the cooking compartment for a long time (e.g.
overnight). The oven must not be operated while the
cooking compartment is still wet or damp.
1.
2.
Open the appliance door and remove the remaining
water with an absorbent sponge cloth (fig. ").
Clean the smooth surfaces in the cooking
compartment with a dish cloth or a soft brush.
Remove stubborn food remnants using a stainless
steel scouring pad.
3. Remove limescale deposits with a cloth soaked in
vinegar. Then wipe with clean water and rub dry with
a soft cloth (including under the door seal).
4. Leave the appliance door ajar in the stop position
(approx. 30°) for approx. 1 hour to allow the enamel
surfaces in the cooking compartment to dry
thoroughly. Alternatively, you can also run the rapid
drying function for the cooking compartment.
Running the rapid drying function for the cooking
compartment
1. Once the cleaning assistant has finished, open the
appliance door as far as the stop position (approx.
30°).
2. Set 3D hot air to 50 °C.
3. After 5 minutes, switch off the oven and close the
appliance door.
Removing heavy deposits of dirt
You have several options for removing particularly
stubborn deposits of dirt.
■ Leave the soapy water in place for a while before
starting the cleaning assistant.
■
■
Rub soapy water onto the dirty areas of the smooth
surfaces before starting the cleaning assistant.
Run the cleaning assistant function again once the
cooking compartment has cooled down.
Cleaning en
19
Surfaces in the cooking compartment
The back wall in the cooking compartment is self-
cleaning.You can tell this from the rough surface.
The base, ceiling and side panel are enamelled and
have smooth surfaces.
Cleaning enamel surfaces
Clean the smooth enamel surfaces with a dish cloth
and hot soapy water or a vinegar solution. Then dry
them with a soft cloth.
Soften baked-on food remnants with a damp cloth and
soapy water. Use stainless steel wire wool or oven
cleaner to remove stubborn dirt.
Caution!
Never use oven cleaner in the cooking compartment
when it is still warm. This may damage the enamel.
Remove all food remnants from the cooking
compartment and the appliance door before you next
heat up the appliance.
Leave the cooking compartment open to dry after
cleaning it.
Note: Food residues can cause white deposits to form.
These are harmless and do not affect how the
appliance works. You can remove these residues using
lemon juice if required.
Cleaning self-cleaning surfaces
The self-cleaning surfaces are coated with a porous,
matte ceramic layer. This coating absorbs and dispels
splashes from baking and roasting while the appliance
is in operation.
If the self-cleaning surfaces no longer clean themselves
sufficiently and dark stains appear, they can be cleaned
using targeted heating.
Making settings
Remove the rails, pull-out shelves, accessories and
ovenware from the cooking compartment beforehand.
Thoroughly clean the smooth enamel surfaces in the
cooking compartment, the inside of the appliance door
and the glass cover on the interior lighting.
1. Set the 3D hot air type of heating.
2. Set the maximum temperature.
3. Start the mode and leave it to run for at least one
hour.
The ceramic coating is regenerated.
When the cooking compartment has cooled down,
remove the brown or white residue with water and a soft
sponge.
Note: During operation, reddish spots form on the
surfaces. This is not rust, but residues from food. These
spots are not harmful and do not restrict the cleaning
ability of the self-cleaning surfaces.
Caution!
Do not use oven cleaner on the self-cleaning surfaces.
This will damage the surfaces.If oven cleaner does get
onto these surfaces, dab it off immediately using water
and a sponge cloth. Do not rub the surface and do not
use abrasive cleaning aids.
Keeping the appliance clean
Always keep the appliance clean and remove dirt
immediately so that stubborn deposits of dirt do not
build up.
:Warning – Risk of fire!
Loose food remnants, fat and meat juices may catch
fire. Before using the appliance, remove the worst of the
food remnants from the cooking compartment, heating
elements and accessories.
Tips
■ Clean the cooking compartment after each use. This
will ensure that dirt cannot be baked on.
■ Always remove flecks of limescale, grease, starch
and albumin (e.g. egg white) immediately.
■ Use the universal pan for baking very moist cakes.
■ Use suitable ovenware for roasting, e.g. a roasting
dish.
en Rails
20
pRails
Rails
With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
shelves and clean them.
Detaching and refitting the rails
The rails can be removed for cleaning. The oven must
have cooled down.
Detaching the rails
1. Lift up the front of the rail
2. and unhook it (figure A).
3. Then pull the whole rail forward
4. and remove it (Fig. B).
Clean the rails with cleaning agent and a sponge. For
stubborn deposits of dirt, use a brush.
Refitting the rails
1. First insert the rail into the rear socket, press it to the
back slightly (figure A),
2. and then hook it into the front socket (figure B).
The rails only fit on the right or the left side. Ensure that,
as shown in figure B, levels 1 and 2 are below and
levels 3, 4 and 5 are above. The pull-out rail must be
pulled out forwards.
qAppliance door
Ap p l i a n c e door
With good care and cleaning, your appliance will retain
its appearance and remain fully functional for a long
time to come. This will tell you how to remove the
appliance door and clean it.
Detaching and attaching the oven door
For cleaning purposes and to remove the door panels,
you can detach the oven door.
The oven door hinges each have a locking lever. When
the locking levers are closed (figure A), the oven door
is secured in place. It cannot be detached. When the
locking levers are open in order to detach the oven
door (Fig. B), the hinges are locked. They cannot snap
shut.
:Warning – Risk of injury!
Whenever the hinges are not locked, they snap shut
with great force. Ensure that the locking levers are
always fully closed or, when detaching the oven door,
fully open.
Detaching the door
1. Open the oven door fully.
2. Fold up the two locking levers on the left and right
(figure A).
3. Close the oven door as far as the limit stop. With
both hands, grip the door on the left and right-hand
sides. Close the door a little further and pull it out
(figure B).
%
$
%
$
%$
%$
Appliance door en
21
Attaching the door
Reattach the oven door in the reverse sequence to
removal.
1. When attaching the oven door, ensure that both
hinges are inserted straight into the opening
(figure A).
2. The notch on the hinge must engage on both sides
(figure B).
3. Fold back both locking
levers (figure C). Close the oven door.
:Warning – Risk of injury!
If the oven door falls out accidentally or a hinge snaps
shut, do not reach into the hinge. Call the aftersales
service.
Removing and refitting the door panels
The glass panels can be removed from the oven door
to allow more thorough cleaning.
Removal
1. Removing the oven door See the section Removing
the oven door
. Lay the oven door on a cloth with the
handle facing downwards.
2. Remove the cover from the top of the oven door. To
do this, press with your fingers on the left and right-
hand side. Pull out the cover (Fig. A).
3. Raise the top panel and pull it out (Fig. B).
Clean the panels with glass cleaner and a soft cloth.
:Warning – Risk of injury!
Scratched glass in the appliance door may develop into
a crack. Do not use a glass scraper, sharp or abrasive
cleaning aids or detergents.
Fitting
1. Hold the top glass panel firmly by the sides and slide
it in towards the back at an angle. The panel must
be inserted into the openings on the lower side. The
smooth surface must face outwards, while the
roughened side must be on the inside. (Fig. A).
2. Place the cover on the top of the oven door and
press in place. Make sure that the grooves along the
sides lock into position.
3. Refitting the oven door See the section Refitting the
oven door
.
Do not use the oven again until the panels have been
correctly fitted.
Additional door safety
When preparing meals with long cooking times, the
oven door can reach very high temperatures.
Supervise small children and keep them away from the
oven when the oven is in operation.
Additional safety devices have been fitted to prevent
contact with the oven door. Always attach these safety
devices when children could come near the oven.
You can purchase this optional accessory (11023590)
from the after-sales service.
%
$
&
%$
$
en Trouble shooting
22
3Trouble shooting
Tr oubl e s hoot i ng
If a fault occurs, there is often a simple explanation.
Before calling the after-sales service, please refer to the
fault table and attempt to correct the fault yourself.
Rectifying faults yourself
You can often easily rectify technical faults with the
appliance yourself.
If a dish does not turn out exactly as you wanted, you
can find useful cooking tips and instructions at the end
of this instruction manual. ~ "Tested for you in our
cooking studio" on page 23
--------
:Warning – Risk of injury!
Incorrect repairs are dangerous. Do not attempt to
repair the appliance yourself. Repairs must only be
carried out by one of our trained after-sales engineers. If
the appliance is defective, call the after-sales service.
:Warning – Risk of electric shock!
Incorrect repairs are dangerous. Repairs may only be
carried out and damaged power cables replaced by
one of our trained after-sales technicians. If the
appliance is defective, unplug the appliance from the
mains or switch off the circuit breaker in the fuse box.
Contact the after-sales service.
Error messages on the display
If an error message with "“" appears on the display,
e.g. “‹†-„ƒ, touch the v button. This will reset the
error message. Reset the time, if necessary.
If the fault was a one-off, you can continue to use your
appliance as normal. If the error message appears
again, call our after-sales service and quote the exact
error message and the E no. of your appliance.
~ "Customer service" on page 23
Replacing the bulb in the top of the cooking
compartment
If the cooking compartment light bulb fails, it must be
replaced. Heat-resistant, 25 watt, 230 V halogen bulbs
are available from the after-sales service or specialist
retailers.
When handling the halogen bulb, use a dry cloth. This
will increase the service life of the bulb. Only use these
bulbs.
:Warning – Risk of electric shock!
When replacing the cooking compartment bulb, the
bulb socket contacts are live. Before replacing the bulb,
unplug the appliance from the mains or switch off the
circuit breaker in the fuse box.
:Warning – Risk of burns!
The appliance becomes very hot. Never touch the
interior surfaces of the cooking compartment or the
heating elements. Always allow the appliance to cool
down. Keep children at a safe distance.
1. Place a tea towel in the cold cooking compartment
to prevent damage.
2. Turn the glass cover anti-clockwise to remove it
(figure !).
3. Pull out the bulb – do not turn it (figure ").
Insert the new bulb, making sure that the pins are in
the correct position. Push the bulb in firmly.
4. Screw the glass cover back on.
Depending on the appliance model, the glass cover
may have a sealing ring. If the glass cover has a
sealing ring, put it back in place before screwing the
cover back on.
5. Remove the tea towel and switch on the circuit
breaker.
Fault Possible
cause
Notes/remedy
The appliance is
not working.
Defective cir-
cuit breaker.
Check the circuit breaker in the
fuse box.
Power failure Check whether the kitchen light
or other kitchen appliances are
working.
The time is flash-
ing on the display.
Power failure. Reset the time.
The settings on
the appliance
cannot be config-
ured. A key sym-
bol has lit up on
the display or
†‘”“.
The child-
proof lock is
activated.
Deactivate the childproof lock by
pressing and holding the button
with the key symbol for approx. 4
seconds.
2
1
Customer service en
23
4Customer service
Cu s t o mer ser vi ce
Our after-sales service is there for you if your appliance
needs to be repaired. We will always find an
appropriate solution, also in order to avoid after-sales
personnel having to make unnecessary visits.
E number and FD number
When calling us, please give the product number (E
no.) and the production number (FD no.) so that we can
provide you with the correct advice. The rating plate
containing these numbers can be found on the right-
hand side of the oven door. You can make a note of the
numbers of your appliance and the telephone number
of the after-sales service in the space below to save
time should it be required.
Please note that there will be a fee for a visit by a
service technician in the event of a malfunction, even
during the warranty period.
After-sales contact details for all countries can be found
in the attached after-sales service directory.
JTested for you in our
cooking studio
Tes t e d for you in our cooki ng st udi o
Here, you can find a selection of dishes and the ideal
settings for them. We will show you which type of
heating and temperature are best suited to your dish.
You will get information on suitable cooking
accessories and the height at which they should be
placed in the oven. You will also get tips about
cookware and preparation methods.
Note: A lot of steam can build up in the cooking
compartment when cooking food.
Your appliance is very energy-efficient and radiates very
little heat to its surroundings during operation. Due to
the significant differences in temperature between the
appliance interior and the external parts of the
appliance, condensation may build up on the door, the
control panel or the front panels of adjacent kitchen
cabinets. This is a normal physical phenomenon.
Condensation can be reduced by preheating the oven
or opening the door carefully.
General information
Recommended setting values
The table lists the optimal heating function for various
types of food. The temperature and cooking time
depend on the amount of food and the recipe.For this
reason, the table specifies setting ranges. Try using the
lower value to start with. A lower temperature will result
in more even browning. You can increase the
temperature next time if necessary.
Note: Cooking times cannot be reduced by using
higher temperatures. The food would only be cooked
on the outside, but would not be fully cooked in the
middle.
The setting values apply to food placed in the cooking
compartment while the cooking compartment is still
cold. This will save energy.If you preheat the oven, you
can reduce the indicated baking times by several
minutes.
Preheating is necessary for selected types of food –
this is indicated in the table. Do not place your food and
accessory into the cooking compartment until it has
finished preheating.
If you wish to follow one of your own recipes, you
should use the settings listed in the table for similar
food as reference. Additional information can be found
in the baking tips listed after the settings tables.
Remove any accessories that are not being used from
the cooking compartment. This will allow you to achieve
optimal cooking results while saving energy.
Gentle hot air heating function
Gentle hot air is an intelligent heating function that
allows you to gently cook meat, fish and baked items.
The appliance optimally controls the supply of energy to
the cooking compartment. The food is cooked in
phases using residual heat. This means that it remains
more succulent and browns less. Depending on the
E no.
FD no.
After-sales service O
en Tested for you in our cooking studio
24
method of preparation and the type of food, it is
possible to save energy. If you open the appliance door
before the food has finished cooking or if you preheat
the appliance, you may not be able to achieve this
result.
Only use genuine accessories for your appliance.
These have been tailored to the cooking compartment
and the heating functions of your appliance. Remove
any accessories that are not being used from the
cooking compartment.
Place the food into the empty cooking compartment
before the oven is heated up. Select a temperature of
between 120 °C and 230 °C.Always keep the
appliance door closed when cooking. Only cook on one
level when using this function.
The Gentle hot air heating function is used to measure
both the energy consumption in air recirculation mode
and the energy efficiency class.
Baking on one level
When baking on one level, use the following shelf
positions:
■ Position 2 – tall baked items and tins/dishes on the
wire rack
■ Position 3 – shallow baked items and baking trays
Baking on two or more levels
Use the hot air heating function. Items that are placed in
the oven on baking trays or in baking tins/dishes at the
same time will not necessarily be ready at the same
time.
Baking on two levels:
■ Universal pan, position 3
Baking tray, position 1
■ Baking tins/dishes on the wire rack
First wire rack, position 3
Second wire rack, position 1
Baking on three levels:
■ Baking tray, position 5
Universal pan, position 3
Baking tray, position 1
You can cut energy use by cooking different items at
the same time. Position baking tins/dishes either next to
one another or offset on different shelves so that they
are not directly one above the other in the cooking
compartment.
Accessories
Only use original accessories supplied with your
appliance. These have been tailored to the cooking
compartment and the operating modes of your
appliance.
Ensure that you always use suitable accessories and
that they are placed in the oven the right way around.
~ "Accessories" on page 11
Greaseproof paper
Only use greaseproof paper that is suitable for the
selected temperature. Always cut greaseproof paper to
size.
Cakes and pastries
Your appliance offers you a range of heating types for
the preparation of cakes and small baked items. You
can find the ideal settings for many dishes in the
settings tables.
Also refer to the notes in the section on allowing dough
to rise.
Baking tins
For optimal cooking results, we recommend using dark-
coloured metal baking tins.
Tinplate baking tins, ceramic dishes and glass dishes
extend baking time and mean that the baked item will
not brown evenly.
If you are using silicone moulds, follow the
manufacturer's instructions and recipes. Silicone
moulds are often smaller than normal baking tins.
Quantity and recipe specifications may vary.
Frozen products
Do not use frozen products that are heavily frosted.
Remove any ice on the food.
Some frozen products may be unevenly pre-baked.
Uneven browning may remain even after baking.
Bread and rolls
Caution!
Never pour water into the hot cooking compartment or
place cookware containing water onto the bottom of the
cooking compartment. The change in temperature can
cause damage to the enamel.
Some food turns out better if it is baked in several
stages. These dishes are indicated in the table.
The setting values for bread dough apply to both dough
placed on a baking tray and dough placed in a loaf tin.
Tested for you in our cooking studio en
25
Cakes in tins
Cakes on trays
Small baked items
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Tempera-
ture in °C
Cooking
time in
mins
Sponge cake, simple Vienna ring tin/loaf tin 2
6
160-180 50-60
Sponge cake, simple, 2 levels Vienna ring tin/loaf tin 3+1
<
140-160 60-80
Sponge cake, delicate Vienna ring tin/loaf tin 2
%
150-170 60-80
Sponge flan base Flan tin 3
%
160-180 30-40
Fruit tart or cheesecake with shortcrust pastry
base
26 cm springform cake tin 2
%
160-180 70-90
Tart Tart dish or tin 1
%
200-240 25-50
Yeast cake 28 cm springform cake tin 2
<
150-160 25-35
Bundt cake Bundt cake tin 2
%
150-170 60-80
3-egg fatless sponge cake 26 cm springform cake tin 2
6
160-170 30-40
6-egg fatless sponge cake 28 cm springform cake tin 2
6
160-170 35-45
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Temperature
in °C
Cooking
time in
mins
Sponge cake with topping Universal pan 3
%
160-180 20-45
Small yeast cakes, 2 levels Universal pan + baking tray 3+1
<
140-160 30-55
Shortcrust tart with dry topping Universal pan 2
%
170-190 25-35
Shortcrust tart with dry topping, 2 levels Universal pan + baking tray 3+1
<
160-170 35-45
Shortcrust tart with moist topping Universal pan 2
%
160-180 60-90
Yeast cake with dry topping Universal pan 3
%
170-180 25-35
Yeast cake with dry topping, 2 levels Universal pan + baking tray 3+1
<
150-170 20-30
Yeast cake with moist topping Universal pan 3
%
160-180 30-50
Yeast cake with moist topping, 2 levels Universal pan + baking tray 3+1
<
150-170 40-65
Plaited loaf, savarin Universal pan 2
%
160-170 35-40
Swiss roll Universal pan 2
%
170-190* 15-20
Strudel, sweet Universal pan 2
%
190-210 55-65
Strudel, frozen Universal pan 3
$
180-200 35-45
* Preheat for 10 minutes
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Temperature
in °C
Cooking
time in
mins
Muffins Muffin tray 2
%
170-190 20-40
Muffins, 2 levels Muffin trays 3+1
<
160-170 30-40
Small yeast cakes Universal pan 3
6
150-170 25-35
Small yeast cakes, 2 levels Universal pan + baking tray 3+1
<
150-170 25-40
Puff pastry Universal pan 3
<
180-200 20-30
Puff pastry, 2 levels Universal pan + baking tray 3+1
<
180-200 25-35
Puff pastry, 3 levels Baking trays + universal pan 5+3+1
<
170-190 30-45
en Tested for you in our cooking studio
26
Biscuits
Bread and rolls
Pizza, quiche and savoury cakes
Choux pastry Universal pan 3
%
190-210 35-50
Choux pastry, 2 levels Universal pan + baking tray 3+1
<
190-210 35-45
Dish Accessories/cookware Shelf position Heating
function
Temperature in
°C
Cooking
time in
mins
Viennese whirls Universal pan 3
%
140-150* 30-40
Viennese whirls, 2 levels Universal pan + baking tray 3+1
<
140-150* 30-45
Viennese whirls, 3 levels Baking trays + universal pan 5+3+1
<
130-140* 40-55
Biscuits Universal pan 3
%
140-160 20-30
Biscuits, 2 levels Universal pan + baking tray 3+1
<
130-150 25-35
Biscuits, 3 levels Baking trays + universal pan 5+3+1
<
130-150 30-40
Meringue Universal pan 3
<
80-100 100-150
Meringue, 2 levels Universal pan + baking tray 3+1
<
90-100* 100-150
Macaroons Universal pan 2
%
100-120 30-40
Macaroons, 2 levels Universal pan + baking tray 3+1
<
100-120 35-45
Macaroons, 3 levels Baking trays + universal pan 5+3+1
<
100-120 40-50
* Preheat
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Step Temperature in
°C
Cooking
time in
mins
Bread, 750 g (in a loaf tin or free-form) Universal pan or loaf tin 2
6
- 180-200 50-60
Bread, 1000 g (in a loaf tin or free-form) Universal pan or loaf tin 2
6
- 200-220 35-50
Bread, 1500 g (in a loaf tin or free-form) Universal pan or loaf tin 2
6
- 180-200 60-70
Flatbread Universal pan 3
<
- 240-250 25-30
Bread rolls, sweet, fresh Universal pan 3
%
- 170-180* 20-30
Bread rolls, sweet, fresh, 2 levels Universal pan + baking tray 3+1
<
- 160-180* 15-25
Bread rolls, fresh Universal pan 3
%
- 200-220 20-30
Toast with topping, 4 slices Wire rack 3
%
- 200-220 15-20
Toast with topping, 12 slices Wire rack 3
%
- 220-240 15-25
* Preheat
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Temperature
in °C
Cooking
time in
mins
Pizza, fresh Universal pan 3
$
170-190 20-30
Pizza, fresh, 2 levels Universal pan + baking tray 3+1
<
160-180 35-45
Pizza, fresh, thin-crust Universal pan 2
%
250-270* 20-30
Pizza, chilled Universal pan 1
$
180-200* 10-15
Pizza, frozen, thin-crust, x 1 Wire rack 2
$
190-210 15-20
Pizza, frozen, thin-crust, x 2 Universal pan + wire rack 3+1
<
190-210 20-25
* Preheat
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Temperature
in °C
Cooking
time in
mins
Tested for you in our cooking studio en
27
Baking tips
Pizza, frozen, deep-pan, x 1 Wire rack 3
$
180-200 20-25
Pizza, frozen, deep-pan, x 2 Universal pan + wire rack 3+1
<
170-190 20-30
Mini pizzas Universal pan 3
$
190-210 10-20
Savoury cakes in a tin 28 cm springform cake tin 2
$
170-190 40-50
Quiche Tart dish or tin 2
$
190-210 35-45
Tart Ovenproof dish 2
<
170-190 55-65
Empanadas Universal pan 3
<
180-190 35-45
Börek Universal pan 2
%
220-240 30-40
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Temperature
in °C
Cooking
time in
mins
* Preheat
You want to find out whether the
baked item is completely cooked in
the middle.
Push a cocktail stick into the highest point on the baked item. If the cocktail stick comes out clean with no
dough residue, the baked item is ready.
The baked item collapses. Next time, use less liquid. Alternatively, set the temperature 10 °C lower and extend the baking time. Adhere
to the specified ingredients and preparation instructions in the recipe.
The baked item has risen in the mid-
dle but is lower around the edge.
Only grease the base of the springform cake tin. After baking, loosen the baked item carefully with a knife.
The fruit juice overflows. Next time, use the universal pan.
Small baked items stick to one
another during baking.
There should be a gap of approx. 2 cm around each item. This gives enough space for the baked items to
expand well and brown on all sides.
The baked item is too dry. Set the temperature 10 °C higher and shorten the baking time.
The baked item is too light in colour
overall.
If the shelf position and the accessories are correct, then you should increase the temperature if necessary or
extend the baking time.
The baked item is too light on top, and
too dark underneath.
Bake the cake one level higher in the oven the next time.
The baked item is too dark on top,
and too light underneath.
Bake the cake one level lower in the oven the next time. Select a lower temperature and extend the baking
time.
The baked item is too dark in a tin or
loaf tin.
Place the baking tray in the middle of the accessory, not directly against the back wall.
The baked item is too dark in colour
overall.
Select a lower temperature next time and extend the baking time if necessary.
The baked item is unevenly browned. Select a slightly lower temperature.
Protruding greaseproof paper can affect the air circulation. Always cut greaseproof paper to size.
Ensure that the baking tin does not stand directly in front of the openings in the cooking compartment back
wall.
When baking small items, you should use similar sizes and thicknesses wherever possible.
You were baking on several levels.
The items on the top baking tray are
darker than those on the lower baking
tray.
Always select hot air when baking on several levels. Baked items that are placed into the oven on trays or in
baking tins at the same time will not necessarily be ready at the same time.
The baked item looks good, but is not
cooked properly in the middle.
Use a lower temperature and bake slightly longer; if necessary, add slightly less liquid. For baked items with a
moist topping, bake the base first. Sprinkle it with almonds or breadcrumbs and then place the topping on top.
The baked item cannot be turned out
of the dish when it is turned upside
down.
Allow the baked item to cool down for 5 to 10 minutes after baking. If it still sticks, carefully loosen it around
the edges again using a knife. Turn the baked item upside down again and cover it several times with a cold,
wet cloth. Next time, grease the baking tin and sprinkle with breadcrumbs.
en Tested for you in our cooking studio
28
Bakes and gratins
Your appliance offers a range of heating functions for
cooking bakes. The settings tables list the optimal
settings for a wide range of dishes.
How well cooked a bake is will depend on the size of
the cookware and the shelf position of the bake.
Use wide, shallow cookware for bakes and gratins.
Food takes longer to cook in deep, narrow cookware
and it browns more on top.
Always use the shelf positions indicated.
You can cook food on one level in baking tins/dishes or
in the universal pan.
■ Baking tins/dishes on the wire rack: Position 2
■ Universal pan, position 3
You can cut energy use by cooking different items at
the same time. Position baking tins/dishes next to one
another in the cooking compartment.
Poultry, meat and fish
Your appliance offers you a range of heating types for
preparing poultry, meat and fish. You can find the ideal
settings for certain dishes in the settings tables.
Roasting on the wire rack
Roasting on the wire rack works particularly well for
large poultry or for multiple pieces at the same time.
Place the food to be grilled directly onto the wire rack. If
you are grilling a single piece, place it in the centre of
the wire rack for best results.
The universal pan should also be inserted at position 1.
This will catch the meat juices that drip down and keeps
the cooking compartment clean.
Add up to ^ litre of water to the universal pan,
depending on the size and type of joint. This will catch
the liquid that drips down. You can make a sauce from
these juices. This will also result in less smoke being
produced and keep the cooking compartment clean.
Roasting in cookware
:Warning – Risk of injury caused by shattering
glass!
Place hot glass cookware on a dry mat after cooking. If
the surface is damp or cold, the glass may crack.
:Warning – Risk of scalding!
Very hot steam may escape when opening the lid after
cooking. Lift the lid at the rear, so that the hot steam
can escape away from you.
Only use cookware which is suitable for use in an oven.
Glass cookware is best. Check whether the cookware
fits in the cooking compartment.
Shiny roasting dishes made from stainless steel or
aluminium reflect heat like a mirror and are therefore
not particularly suitable. The poultry, meat and fish
cooks slower and does not brown so well. Use a higher
temperature and/or a longer cooking time.
Observe the manufacturer's instructions for your
roasting cookware.
Uncovered cookware
To cook poultry, meat and fish, it is best to use a deep
roasting tin. Place the tin onto the wire rack. If you do
not have any suitable cookware, use the universal pan.
Covered cookware
When cooking with covered cookware, the cooking
compartment remains considerably cleaner. Ensure that
the lid fits well and closes properly. Place the cookware
onto the wire rack.
Poultry, meat and fish can also become crispy in a
covered roasting dish. Simply use a roasting dish with a
glass lid and set a higher temperature.
Grilling
Keep the appliance door closed when using the grill.
Never grill with the appliance door open.
Place the food to be grilled on the wire rack. In addition,
slide the universal pan in at least one shelf position
lower, with the slanted edge facing the appliance door.
Any dripping fat will be caught.
When grilling, try wherever possible to use pieces of
food which are of a similar thickness and weight. This
will allow them to brown evenly and remain succulent
and juicy. Place the food to be grilled directly onto the
wire rack.
Use tongs to turn the pieces of food you are grilling. If
you pierce the meat with a fork, the juices will run out
and it will become dry.
Do not add salt to the meat until it has been grilled. Salt
draws water from the meat.
Notes
■ The grill element switches itself on and off
repeatedly; this is normal. The grill setting
determines how frequently this occurs.
■ Smoke may be produced when grilling.
■ When you are using the grill, do not insert the baking
tray or universal pan into the cooking compartment
any higher than shelf position 3. The high
temperatures at the top of the cooking compartment
can warp accessories, which may damage the
cooking compartment when removed.
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Temperature in
°C
Cooking time
in mins
Bake, savoury, cooked ingredients Ovenproof dish 2
%
200-220 30-60
Bake, sweet Ovenproof dish 2
%
180-200 50-60
Potato gratin, raw ingredients, 4 cm deep Ovenproof dish 2
<
150-170 60-80
Potato gratin, raw ingredients, 4 cm deep, 2 levels Ovenproof dish 3+1
<
150-160 70-80
Tested for you in our cooking studio en
29
Meat thermometer
Depending on your appliance's features, you may have
a meat thermometer. You can cook accurately using a
meat thermometer. Read important notes on using the
meat thermometer in the corresponding chapter. There,
you can find notes on inserting the meat thermometer,
the possible heating types and additional information.
Recommended setting values
The setting values are based on the assumption that
unstuffed, chilled, ready-to-roast poultry, meat or fish is
placed into a cold cooking compartment.
In the table, you can find specifications for poultry, meat
and fish with default values for the weight. If you wish to
prepare heavier poultry, meat or fish, always use the
lower temperature. If roasting several joints, use the
weight of the heaviest piece as a basis for determining
the cooking time. The individual pieces should be
approximately equal in size.
The larger the poultry, meat or fish is, the lower the
cooking temperature and the longer the cooking time.
Turn the poultry, meat and fish after approx.
^ to Z of
the indicated time.
Poultry
When cooking duck or goose, pierce the skin on the
underside of the wings. This allows the fat to run out.
If using duck breast, score the skin. Do not turn duck
breasts.
Add some liquid to the poultry in the dish. Cover the
base of the ovenware with approx. 1-2 cm of liquid.
When you turn poultry, ensure that the breast side or
the skin side is underneath at first.
Poultry will turn out particularly crispy and brown if you
baste it towards the end of the roasting time with butter,
salted water or orange juice.
Meat
Baste lean meat with fat as required or cover it with
strips of bacon.
When roasting, add a little liquid if the meat is lean. A
covering of approx. ^ cm depth should be applied to
the base of any glass cookware.
Score the rind crosswise. If you turn the joint when
cooking, ensure that the rind is underneath at first.
When the joint is ready, turn off the oven and allow it to
rest for another 10 minutes in the cooking
compartment. This allows the meat juices to be better
distributed. Wrap the joint in aluminium foil if necessary.
The recommended resting time is not included in the
cooking time indicated.
It is more convenient to roast and braise meat in
cookware. You can take the joint out of the cooking
compartment more easily in the cookware, and prepare
the sauce in the cookware itself.
The quantity of liquid is dependent on the type of meat,
the cookware material and also on whether or not a lid
is used. If preparing meat in an enamelled or dark metal
roasting dish, it will need a little more liquid than if
cooked in glass cookware.
The steam evaporates in the cookware when roasting.
Carefully pour in more liquid if required.
The distance between the meat and the lid should be at
least 3 cm. The meat may rise.
If necessary, braise the meat first by searing it. Add
water, wine, vinegar or a similar liquid to the braising
liquid. A covering approx. 1-2 cm deep should be
applied to the base of the cookware.
Fish
Fish cooked whole does not have to be turned. Place
the whole fish into the cooking compartment in
swimming position with the dorsal fin facing upwards.
Placing half a potato or a small oven-proof container in
the stomach cavity of the fish will provide stability.
You can tell when the fish is cooked because the dorsal
fin can be removed easily.
When stewing, add two to three tablespoons of liquid
and a little lemon juice or vinegar into the cookware.
Poultry
Dish Accessories/cookware Shelf position Heating
function
Temperature in
°C
Cooking time
in mins
Chicken, 1.3 kg Wire rack 2
7
200-220 60-70
Small chicken portions, 250 g each Wire rack 3
7
220-230 30-35
Chicken goujons, nuggets, frozen Universal pan 3
%
190-210 20-25
Duck, 2 kg Wire rack 2
7
190-210 100-110
Duck breast, medium, 300 g each Wire rack 3
7
240-260 30-40
Goose, 3 kg Wire rack 2
7
170-190 120-140
Goose legs, 350 g each Wire rack 3
7
220-240 40-50
Small turkey, 2.5 kg Wire rack 2
7
180-200 80-100
Turkey breast, boned, 1 kg Cookware, covered 2
%
240-260 80-100
Turkey thigh, bone in, 1 kg Wire rack 2
7
180-200 90-100
en Tested for you in our cooking studio
30
Meat
Fish
Tips on roasting and braising
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Step Tempera-
ture in °C
Cooking
time in
mins
Joint of pork without rind, e.g. neck, 1.5 kg Cookware, uncovered 1
7
- 180-200 140-160
Joint of pork with rind, e.g. shoulder, 2 kg Cookware, uncovered 1
7
- 170-190 190-200
Pork tenderloin steak, 1.5 kg Cookware, uncovered 2
%
- 190-210 130-140
Pork steaks, 2 cm thick Wire rack 4
(
- 3 20-25**
Fillet of beef, medium, 1 kg Cookware, uncovered 3
%
- 210-220 45-55
Pot-roasted beef, 1.5 kg Cookware, uncovered 2
6
- 200-220 100-120
Sirloin, medium, 1.5 kg Cookware, uncovered 2
7
- 200-220 60-70
Burger, 3-4 cm thick Wire rack 4
(
- 3 25-30**
Joint of veal, 1.5 kg Cookware, uncovered 2
%
- 180-200 120-140
Knuckle of veal, 1.5 kg Cookware, uncovered 2
%
- 210-230 130-150
Leg of lamb, boned, medium, 1.5 kg Cookware, uncovered 2
7
- 170-190 70-80*
Saddle of lamb on the bone, medium, 1.5 kg Wire rack 2
7
- 180-190 45-55*/**
Grilling sausages Wire rack 3
(
- 3 20-25**
Meat loaf, 1 kg Cookware, uncovered 2
7
- 170-180 70-80
* Do not turn
** Slide the universal pan in at shelf position 1
Fish Weight Accessories
and cookware
Position Heating
function
Temperature in
°C, grill setting
Cooking time
in minutes
Fish, whole Approx. 300 g each Wire rack 2
(
2 20-25
1.0 kg Wire rack 2
7
180-200 45-50
1.5 kg Wire rack 2
7
170-190 50-60
Fish steak, 3 cm thick Wire rack 3
(
2 20-25
The cooking compartment becomes
very dirty.
Prepare your food in an enclosed roasting dish with higher temperature or use the grill tray. You will achieve
the best roasting results if you use the grill tray. The grill tray can be bought later as a special accessory.
The roast is too dark and the crack-
ling is burned in places, and/or the
roast is too dry.
Check the shelf position and temperature. Select a lower temperature the next time and reduce the roasting
time if necessary.
The crackling is too thin. Increase the temperature or switch on the grill briefly at the end of the roasting time.
The roast looks good but the juices
are burnt.
Next time, use a smaller roasting dish and add more liquid if necessary.
The roast looks good but the juices
are too clear and watery.
Next time, use a larger roasting dish and add less liquid if necessary.
The meat gets burned during brais-
ing.
The roasting dish and lid must fit together well and close properly.
Reduce the temperature and add more liquid when braising if necessary.
Tested for you in our cooking studio en
31
Vegetables and side dishes
Here, you can find information for preparing grilled
vegetables, potatoes and frozen potato products.
Adhere to the specifications in the table.
Yoghurt
You can use your appliance to make your own yoghurt.
Remove accessories and shelf supports from the
cooking compartment. The cooking compartment must
be empty.
1. Heat 1 litre of milk (3.5% fat) to 90 °C on the hob
and then leave it to cool down to 40 °C.
It is sufficient to heat UHT milk to 40 °C.
2. Stir in 30 g (approx. 1 tbsp) (chilled) yoghurt.
3. Pour into cups or small jars with lids and cover.
4. Place the cups or jars onto the cooking
compartment floor and use the settings indicated in
the table.
5. After making the yoghurt, leave it to cool in the
refrigerator.
Acrylamide in foodstuffs
Acrylamide is mainly produced in grain and potato
products prepared at high temperatures, such as potato
crisps, chips, sliced bread, bread rolls, bread or fine
baked goods (biscuits, gingerbread, spiced biscuit).
Drying
You can achieve outstanding drying results with hot air.
With this type of preserving, flavours are concentrated
as a result of the dehydration.
Only use unblemished, fresh fruit, vegetables and herbs
and wash them thoroughly. Line the wire rack with
greaseproof paper or parchment paper. Drain the
excess water from the fruit and then dry the fruit
thoroughly.
If necessary, cut it into pieces of equal size or slice it
thinly. Place unpeeled fruit onto the dish with the sliced
surfaces facing upwards. Ensure that neither fruit nor
mushrooms overlap on the wire rack.
Grate vegetables and then blanch them. Drain the
excess water from the blanched vegetables and spread
them evenly on the wire rack.
Dry herbs on the stem. Spread the herbs out evenly and
slightly heaped on the wire rack.
Use the following shelf positions for drying:
■ 1 wire rack: Position 3
■ 2 wire racks: Positions 3 + 1
Turn very juicy fruit and vegetables several times. After
drying, remove the dried food from the paper
immediately.
In the table, you will find settings for drying various
foodstuffs. The temperature and drying time are
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Tempera-
ture in °C
Cooking
time in mins
Grilled vegetables Universal pan 5
(
3 10-20
Baked potatoes, halved Universal pan 3
<
160-180 45-60
Potato products, frozen, e.g. chips, croquettes,
potato pockets, rösti
Universal pan 3
%
200-220 25-35
Chips, 2 levels Universal pan + baking tray 3+1
<
190-210 30-40
Dish Accessories/cookware Shelf position Heating
function
Tempera-
ture in °C
Cooking time
Yoghurt Cup/jar Cooking compart-
ment floor
^
- 4-5h
Tips for keeping acrylamide to a minimum
General ■ Keep cooking times as short as possible.
■ Cook food until it is golden brown, but not too dark.
■ Large, thick pieces of food contain less acrylamide.
Baking With top/bottom heating at max. 200 °C.
With hot air at max. 180 °C.
Biscuits With top/bottom heating at max. 190 °C.
With hot air at max. 170 °C.
Egg or egg yolk reduces the production of acrylamide.
Oven chips Spread out a single layer evenly on the baking tray. Cook approx. 400-600 g at once on a baking tray so
that the chips do not dry out and become crunchy.
en Tested for you in our cooking studio
32
dependent on the type, moisture, ripeness and
thickness of the food. The longer you leave the food to
be dried, the better it will be preserved. The more thinly
you slice the food, the more quickly it will dry and the
more flavour it will retain.For this reason, the table
specifies setting ranges.
If you wish to dry food that is not listed in the table, you
should use the settings listed in the table for similar
food as reference.
Preserving
For preserving, the jars and rubber seals must be clean
and intact. If possible, use jars of the same size. The
information in the table is for round, one-litre jars.
Caution!
Do not use jars that are larger or taller than this. The
lids could crack.
Only use fruit and vegetables in good condition. Wash
them thoroughly.
The times given in the tables are a guide only. The time
will depend on the room temperature, number of jars,
and the quantity and temperature of the contents.
Before you switch off the appliance or change the
cooking mode, check whether the contents of the jars
are bubbling as they should.
Preparation
1. Fill the jars, but not to the top.
2. Wipe the rims of the jars, as they must be clean.
3. Place a damp rubber seal and a lid on each jar.
4. Seal the jars with the clips.
Place no more than six jars in the cooking
compartment.
Settings
1. Insert the universal pan at level 2. Arrange the
preserving jars so that they do not touch each other.
2. Pour ½ litre of water (approx. 80 °C) into the
universal pan.
3. Close the oven door.
4. Set Bottom heat$.
5. Set the temperature to 170 - 180 °C.
Preserving
Fruit
After approx. 40 to 50 minutes, small bubbles begin to
form at short intervals. Switch off the oven.
After 25 to 35 minutes of residual heat, remove the
preserving jars from the cooking compartment. If they
are allowed to cool for longer in the cooking
compartment, germs could multiply, promoting
acidification of the preserved fruit.
Vegetables
As soon as bubbles begin to form in the jars, set the
temperature back to between 120 and 140 °C.
Depending on the type of vegetable, heat for approx. 35
to 70 minutes. Switch off the oven after this time and
use the residual heat.
Taking out the jars
After preserving, remove the jars from the cooking
compartment.
Caution!
Do not place the hot jars on a cold or wet surface. They
could suddenly burst.
Prove dough
Your yeast dough will prove considerably more quickly
using this heating function than at room temperature
and will not dry out. Do not start the appliance if the
cooking compartment is not completely cool.
Fruit, vegetables and herbs Accessories Heating
function
Temperature in
°C
Cooking time in
hours
Pomes (apple rings, 3 mm thick, 200 g per wire rack) 1-2 wire racks
<
80 4-8
Root vegetables (carrots), grated, blanched 1-2 wire racks
<
80 4-7
Sliced mushrooms 1-2 wire racks
<
80 5-8
Herbs, washed 1-2 wire racks
<
60 2-5
Fruit in one-litre jars When it starts to bubble Residual heat
Apples, redcurrants, strawberries Switch off approx. 25 minutes
Cherries, apricots, peaches, gooseberries Switch off approx. 30 minutes
Apple purée, pears, plums Switch off approx. 35 minutes
Vegetables with cold cooking water in one-litre jars When it starts to bubble Residual heat
Gherkins - approx. 35 minutes
Beetroot approx. 35 minutes approx. 30 minutes
Brussels sprouts approx. 45 minutes approx. 30 minutes
Beans, kohlrabi, red cabbage approx. 60 minutes approx. 30 minutes
Peas approx. 70 minutes approx. 30 minutes
Tested for you in our cooking studio en
33
Always allow yeast dough to prove twice.Use the
settings indicated in the settings tables for the first and
second proving stages (dough fermentation stage and
final fermentation stage).
Dough fermentation
Place the dough into a heat-resistant bowl and place
this onto the wire rack. Use the settings indicated in the
table.
Do not open the appliance door while the dough is
proving, otherwise moisture will escape. Do not cover
the dough.
Condensation builds up during the proving process,
which steams up the door panel. Wipe out the cooking
compartment after dough proving.Remove any
limescale with a little vinegar and wipe with clean water.
Final fermentation
Place your dough into the oven at the shelf position
indicated in the table.
If you want to preheat the oven, the final fermentation
stage takes place outside the appliance in a warm
place.
The temperature and proving time are dependent on
the type and quantity of the ingredients. For this reason,
the values indicated in the settings table are intended
as a guide only.
Defrosting
For defrosting frozen fruit, vegetables and baked items.
Poultry, meat and fish should ideally be defrosted in the
refrigerator. Not suitable for cream cakes or cream
gateaux.
Use the following shelf positions when defrosting:
■ 1 wire rack: Position 2
■ 2 wire racks: Positions 3 + 1
Tip: Food that has been frozen flat or in portions
defrosts more quickly than food items frozen in a block.
Remove frozen food from its packaging and place it
onto the wire rack in suitable cookware.
Redistribute the food or turn it once or twice as it
defrosts. Large pieces of food should be turned several
times.As the food defrosts, break up any clumps and
remove items that have already defrosted from the
appliance.
To allow the temperature to equalise, leave the
defrosted food to rest for another 10 to 30 minutes in
the appliance after switching it off.
Test dishes
These tables have been produced for test institutes to
facilitate appliance testing.
As per EN 60350-1.
Baking
Items that are placed in the oven on baking trays or in
baking tins/dishes at the same time will not necessarily
be ready at the same time.
Shelf positions for baking on two levels:
■ Universal pan, position 3
Baking tray, position 1
■ Baking tins/dishes on the wire rack
First wire rack, position 3
Second wire rack, position 1
Shelf positions for baking on three levels:
■ Baking tray, position 5
■ Universal pan, position 3
■ Baking tray: Position 1
Baking with two springform tins:
■ On one level (figure !)
■ On two levels (figure ")
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Step Temperature
in °C
Cooking
time in
mins
Yeast dough, light Bowl 2
^
1. -* 25-30
Universal pan or loaf tin 2
^
2. -* 10-20
Yeast dough, heavy and rich Bowl 2
^
1. -* 60-75
Universal pan or loaf tin 2
^
2. -* 45-60
* Heat up up to 50 °C with %
Frozen food Accessories Position Heating
function
Temperature
For example cream gateaux, buttercream cakes, gateaux with chocolate
or sugar icing, fruit, chicken, sausage and meat, bread and bread rolls,
cakes and other baked items
Wire rack 2
<
The temperature selector must
remain in the "Off" position
2
1
en Tested for you in our cooking studio
34
Notes
■ The setting values apply to dishes placed into a cold
cooking compartment.
■ Please note the information in the tables about
preheating. The setting values are valid without rapid
heating-up.
■ For baking, use the lower of the indicated
temperatures first.
Grilling
Also slide in the universal pan. The liquid will be caught
and the cooking compartment stays cleaner.
Baking
Grilling
Meal Accessories/cookware Shelf posi-
tions
Type of
heating
Temperature in
°C
Cooking
time in
mins
Viennese whirls Universal pan 3
%
140-150* 20-30
Viennese whirls Universal pan 3
<
140-150* 20-30
Viennese whirls, 2 levels Universal pan + baking tray 3+1
<
140-150* 20-35
Viennese whirls, 3 levels Baking trays + universal pan 5+3+1
<
130-140* 25-40
Small cakes Universal pan 3
%
150* 25-35
Small cakes Universal pan 3
<
150* 25-35
Small cakes, 2 levels Universal pan + baking tray 3+1
<
150* 25-35
Small cakes, 3 levels Baking trays + universal pan 5+3+1
<
140* 35-45
Sponge cake 26 cm springform cake tin 2
%
160-170** 30-40
Sponge cake 26 cm springform cake tin 2
6
170 30-40
Sponge cake, 2 levels 2 x 26 cm springform cake tins 3+1
<
150-160** 30-45
Double-crusted apple pie 2 x 20 cm black cake tins 2
%
180-200 60-80
Double-crusted apple pie 2 x 20 cm black cake tins 3
<
160-180 75-85
Double-crusted apple pie, 2 levels 2 x 20 cm black cake tins 3+1
<
170-190 70-90
** Preheat for 5 mins; do not use rapid heat-up function.
** Preheat; do not use rapid heat-up function.
Dish Accessories Shelf position Heating
function
Temperature in
°C
Cooking time
in mins
Toasting bread
Preheat for 10 min
Wire rack 5
(
3 0,2-1,5
Beefburgers, x 12
* Do not preheat
Wire rack 4
(
3 25-30*
* Turn after 2/3 of the total time
Tested for you in our cooking studio en
35
Cooking more than one dish/
course at a time
You can cook more than one dish at a time in your
appliance. This way, the appliance is able to use less
energy and you are able to use the cooking positions
efficiently.
The cooking result depends on the quantity of food and
the size of the ovenware.
For macaroni bakes, use wide, shallow ovenware.
To cook the food, place it into the appliance at levels 1,
3 and 5. Set the appliance to 3D Hot Air at 160 °C. Use
the cooking times listed in the table. Once the time
specified in the table has elapsed, remove the
accessory containing the food from the oven.
If you wish to follow one of your own recipes, you
should use the settings listed in the table for similar
food as reference. Additional information can be found
in the baking tips listed after the settings tables.
Dish Accessories/cookware Shelf posi-
tion
Heating
function
Temperature in
°C
Cooking time
in mins
Fish, whole Baking tray 5
<
160 60
Muffins (x 12) Universal pan 3 30-40
Macaroni bake Wire rack + glass oven-
proof dish*
1 50-60
*Use heat-resistant glass ovenware only.Never set hot glass ovenware down on a cold or wet surface after taking it out of the oven.
Additional baking trays and wire racks can be purchased from our after-sales service, from specialist retailers or online.
5IBOLZPVGPSCVZJOHB
#PTDI)PNF"QQMJBODF
3FHJTUFSZPVSOFXEFWJDFPO.Z#PTDIOPXBOEQSPGJUEJSFDUMZGSPN
t&YQFSUUJQTUSJDLTGPSZPVSBQQMJBODF
t8BSSBOUZFYUFOTJPOPQUJPOT
t%JTDPVOUTGPSBDDFTTPSJFTTQBSFQBSUT
t%JHJUBMNBOVBMBOEBMMBQQMJBODFEBUBBUIBOE
t&BTZBDDFTTUP#PTDI)PNF"QQMJBODFT4FSWJDF
'SFFBOEFBTZSFHJTUSBUJPOoBMTPPONPCJMFQIPOFT
XXXCPTDIIPNFDPNXFMDPNF
-PPLJOHGPSIFMQ
:PV}MMGJOEJUIFSF
&YQFSUBEWJDFGPSZPVS#PTDIIPNFBQQMJBODFTOFFEIFMQXJUIQSPCMFNT
PSBSFQBJSGSPN#PTDIFYQFSUT
'JOEPVUFWFSZUIJOHBCPVUUIFNBOZXBZT#PTDIDBOTVQQPSUZPV
XXXCPTDIIPNFDPNTFSWJDF
$POUBDUEBUBPGBMMDPVOUSJFTBSFMJTUFEJOUIFBUUBDIFETFSWJDFEJSFDUPSZ
3PCFSU#PTDI)BVTHFSÉUF(NC)
$BSM8FSZ4USBF
.ßODIFO
(FSNBOZ
XXXCPTDIIPNFDPN
*9001570222*
9001570222
000916(A)
