All about the
Use & Care
of your
TABLE OF CONTENTS
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
Gas Range
316901312 Rev C (March 2016)
Important Safety Instructions ...........................3-6
Before Setting Oven Controls ...........................7-9
Before Setting Surface Controls .................... 10-11
Setting Surface Controls ..................................12
Oven Control Functions (540 probe) ..................13
Setting Oven Controls .................................. 14-28
Self-Cleaning ............................................... 29-31
Care & Cleaning ......................................... 32-35
Before You Call ........................................... 36-39
Major Appliance Warranty .....................back cover
2
Thank you for choosing Frigidaire.
This Use & Care Guide is part of our commitment to
customer satisfaction and product quality throughout the
service life of your new appliance.We view your purchase
as the beginning of a relationship. To ensure our ability
to continue serving you, please use this page to record
important product information.
Need help??
Visit the Frigidaire web site at www.frigidaire.com
Before you call for service, there are a few things you can
do to help us serve your better.
Read this Use & Care manual.
It contains instructions to help you use and maintain your
range properly.
If you received a damaged range ...
Immediately contact the dealer (or builder) that sold you
the range.
Save time and money.
Check the section “Before You Call”. This section helps step
you through some common problems that might occur. If
you do need service, help is only a phone call away. Call
Frigidaire Customer Services at 1-800-944-9044.
©2015 Electrolux Home Products, Inc.
All rights reserved. Printed in the USA
Product Registration
Registering your product with Frigidaire enhances our
ability to serve you. You can register online at www.
frigidaire.com or by dropping your Product Registration
Card in the mail.
PRODUCT RECORD AND REGISTRATION
Contents
Serial plate location:
open storage drawer (some models) or
remove lower front panel (some models).
Serial plate
location
Purchase date
Model number
Serial number
Record model & serial numbers here
Be sure to visit us online at
www.frigidaire.com
for a complete line of accessories.
Product Registration ...................................................... 2
Important Safety Instructions ............................ 3-6
Before Setting Oven Controls ...............................7-9
Oven racks .............................................................7-8
Effortless™ Oven Rack system and assembly ............... 9
Before Setting Surface Controls .......................10-11
Cookware material types ........................................... 10
Checking for proper burner cap placement ................. 11
Using the griddle (some models) ............................... 11
Setting Surface Controls .......................................12
Setting a surface burner ........................................... 12
Home canning ......................................................... 12
Oven Controls Functions .......................................13
Setting Oven Controls ......................................14-28
Setting the clock ...................................................... 14
Changing between 6-Hour Engery Saving feature
or continuous bake setting ........................................ 14
Setting 12 or 24 hour display modes .......................... 14
Changing oven temperature display mode .................. 15
Setting for audible or silent keypad operation ............. 15
Setting oven lock ..................................................... 15
Setting the timer ...................................................... 16
Add a minute feature ................................................ 16
Quick preheat .......................................................... 16
Bake ....................................................................... 17
Bake time ................................................................ 17
Delay start ............................................................... 18
Convect bake ........................................................... 19
Convect roast ........................................................... 19
Convect convert ....................................................... 20
Probe ................................................................. 20-23
Broil ........................................................................ 24
Setting pizza feature ................................................. 25
Setting keep warm ................................................... 25
Adjusting oven temperature ...................................... 26
Restoring to factory default settings .......................... 26
Operating oven light ................................................. 26
Setting the Sabbath mode feature ........................ 27-28
Self-Cleaning ....................................................29-31
Care & Cleaning ................................................32-35
Cleaning recommendation table ................................ 32
Cleaning the cooktop and surface burners ............. 33-34
Replacing the oven light ........................................... 34
Removing & replacing oven door ............................... 35
Before You Call - Solutions to common problems .. 36-39
Appliance Warranty ..................................back cover
3
Read all instructions before using this appliance.
Do not attempt to install or operate your appliance until
you have read the safety precautions in this manual.
Safety items throughout this manual are labeled with a
WARNING or CAUTION statement based on the risk type.
Denitions
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury
or death.
WARNING indicates a potentially hazardous
situation which, if not avoided, may result in
death or serious injury.
Save these instructions for future reference.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
IMPORTANT indicates installation, operation,
maintenance or valuable information that is not hazard
related.
Important Safety Instructions
•Remove all tape and packaging before using
the range. Destroy the carton and plastic bags after
unpacking the range. Never allow children to play with
packaging material.
•Proper Installation—Be sure your appliance is
properly installed and grounded by a qualied
technician in accordance with the National Fuel
Gas Code ANSI Z223.- latest edition, or in Canada
CAN/CGA B149.1, and CAN/CGA B149.2, and
the National Electrical Code ANSI/NFPA No.70-
latest edition, or in Canada CSA Standard C22.1,
Canadian Electrical Code, Part 1, and local code
requirements. Install only per installation instructions
provided in the literature package for this range. Ask
your dealer to recommend a qualied technician and an
authorized repair service. Know how to disconnect the
power to the range at the circuit breaker or fuse box in
case of an emergency.
If the information in this manual is not followed
exactly, a re or explosion may result causing
property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other
ammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call
the re department.
— Installation and service must be performed
by a qualied installer, servicer or the gas
supplier.
Tip Over Hazard
• A child or adult can tip the
range and be killed.
• Verify the anti-tip device has
been installed to oor or wall.
To check if the anti-tip bracket is installed properly,
use both arms and grasp the rear edge of range back.
Carefully attempt to tilt range forward. When properly
installed, the range should not tilt forward.
Refer to the anti-tip bracket installation instructions
supplied with your range for proper installation.
• Ensure the anti-tip device is re-engaged when
the range is moved to oor or wall.
• Do not operate the range without the anti-tip
device in place and engaged.
• Failure to follow these instructions can result in
death or serious burns to children and adults.
Range
leveling leg
Anti-Tip
bracket
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT
4
• Wear proper apparel—loose-tting or hanging
garments should never be worn while using the
appliance. Do not let clothing or other ammable
materials contact hot surfaces.
• Do not use water or our on grease res — our
may be explosive. Smother the re with a pan
lid, or use baking soda, a dry chemical or foam-
type extinguisher.
• When heating fat or grease, watch it closely. Fat
or grease may catch re if allowed to become too hot.
• Use dry potholders - moist or damp potholders
on hot surfaces may result in burns from steam.
Do not let potholders touch hot heating elements.
Do not use a towel or other bulky cloth instead of a
potholder.
• Do not heat unopened food containers - buildup
of pressure may cause container to burst and
result in injury.
For electric ignition models only: Do not attempt
to operate the range during a power failure. If
the power fails, always turn off the range. If the range
is not turned off and the power resumes, the range will
begin to operate again. Once the power resumes, reset
the clock and oven function.
• Do not store items of interest to children in the
cabinets above a range or on the backguard of
the range. Children climbing on the range to reach
items could be seriously injured.
• Do not touch surface burners, areas near these
burners, oven burners or interior surfaces of
the oven. Both surface and oven burners may be hot
even though ames are not visible. Areas near surface
burners may become hot enough to cause burns.
During and after use, do not touch, or let clothing or
other ammable materials touch these areas until they
have had sufcient time to cool. Among these areas
are the cooktop, surfaces facing the cooktop, the oven
vent openings and surfaces near these openings, oven
door and window.
• Stepping, leaning or sitting on the door or
drawers of a range can result in serious injuries
and also cause damage to the appliance. DO NOT
allow children to climb or play around the range. The
weight of a child on an open oven door may cause the
range to tip, resulting in serious burns or other injury.
• NEVER use this appliance as a space heater to
heat or warm the room. Doing so may result in
carbon monoxide poisoning.
• NEVER cover any slots, holes or passages in
the oven bottom or cover an entire rack with
materials such as aluminum foil. Doing so blocks
air ow through the oven and may cause carbon
monoxide poisoning. Aluminum foil linings may
trap heat, causing a re hazard.
• Storage in or on appliance — to avoid a re
hazard, ammable materials should not be
stored in an oven, near surface units or in the
storage drawer, warmer drawer or lower oven.
This includes paper, plastic and cloth items, such
as cookbooks, plasticware and towels, as well as
ammable liquids. Do not store explosives, such as
aerosol cans, on or near the range.
• DO NOT LEAVE CHILDREN ALONE — to avoid
injuries or burns children should not be left
alone or unattended in the area where the
range is in use. They should never be allowed to
sit or stand on any part of the range including the
storage drawer, lower broiler drawer, lower oven or
warmer drawer.
• Be sure to always have an appropriate foam-type re
extinguisher available, visible and easily accessible
located near the appliance.
• Never modify or alter the construction of a range
by removing the leveling legs, panels, wire
covers, anti-tip bracket/screws, or any other part
of the range.
• Remove the oven door from any unused range if
it is to be stored or discarded.
• User servicing — Do not repair or replace any part
of the appliance unless specically recommended
in the manuals. All other servicing should be done
only by a qualied technician. This may reduce the risk
of personal injury and damage to the range.
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT
5
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
• Use care when opening oven door , warmer
drawer or lower oven door—Stand to the side of the
range when opening the door of a hot oven. Let hot air
or steam escape before you remove or replace food in
the oven.
• Keep Oven Vent Ducts Unobstructed. The oven
vent is located below the backguard. Touching the
surfaces in this area when the oven is operating may
cause severe burns. Also, do not place plastic or heat-
sensitive items on or near the oven vent. These items
could melt or ignite.
• Placement of Oven Racks. Always place oven racks
in desired location while oven is cool. If rack must be
moved while oven is hot use extreme caution. Use
potholders and grasp the rack with both hands to
reposition. Do not let potholders contact the hot heating
elements in the oven. Remove all utensils from the rack
before moving.
• Do not use the broiler pan without its insert. The
broiler pan and its insert allow dripping fat to drain and
be kept away from the high heat of the broiler.
• Do not cover the broiler insert with aluminum
foil. Exposed fat and grease could ignite.
• Protective liners—Do not use aluminum foil to line the
oven bottom. Only use aluminum foil as recommended
in this manual. Improper installation of these liners may
result in risk of electric shock, or re.
Important Safety Notice
The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a
list of substances known to the state to cause cancer,
birth defects or other reproductive harm, and requires
businesses to warn customers of potential exposure to
such substances.
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
• Know which knob controls each surface burner.
Place a pan of food on the burner before turning it on,
and turn the burner off before removing the pan.
• Always turn knob to the full LITE position when
igniting top burners. Visually check that burner has
lit. Then adjust the ame so it does not extend beyond
the edge of the utensil.
• Utensil handles should be turned inward and not
extend over adjacent surface burners—To reduce
the risk of burns, ignition of ammable materials, and
spillage due to unintentional contact with the utensil,
the handle of the utensil should be positioned so that
it is turned inward, and does not extend over adjacent
surface burners.
• Never leave surface burners unattended at high
heat settings—Boilovers cause smoking and greasy
spillovers that may ignite, or a pan that has boiled dry
may melt.
• Glazed cooking utensils—Only certain types of
glass, glass/ceramic, ceramic, earthenware, or other
glazed utensils are suitable for cook top service without
breaking due to the sudden change in temperature.
Check the manufacturer’s recommendations for cook top
use.
• When aming foods under a ventilating hood,
turn the fan on.
• Air curtain or other overhead range hoods, which
operate by blowing a downward air ow on to a range,
shall not be used in conjunction with gas ranges other
than when the hood and range have been designed,
tested and listed by an independent test laboratory for
use in combination with each other.
Use Proper Flame Size—Adjust ame size so it does
not extend beyond the edge of the utensil. The use of
undersized utensils will expose a portion of the burner
ame to direct contact and may result in ignition of
clothing. Proper relationship of utensil to ame will also
improve efciency.
IMPORTANT SAFETY INSTRUCTIONS
6
See the Installation Instructions packaged with this range
for complete installation and grounding instructions.
Grounding Instructions
Do not under any
circumstance, cut,
remove, or bypass
the grounding
prong.
Power supply cord
with 3-prong
grounding plug.
Grounding type
wall receptacle
• Clean in the self-cleaning cycle only the parts
listed in this Use & Care Manual. Before self-
cleaning the oven, remove the broiler pan and any
utensils or foods from the oven.
• Do not use oven cleaners—No commercial oven
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven.
• Do not clean door gasket—The door gasket is
essential for a good seal. Care should be taken not to
rub, damage or move the gasket.
• The health of some birds is extremely sensitive to the
fumes given off during the self-cleaning cycle of any
range. Move birds to another well-ventilated room.
IMPORTANT INSTRUCTIONS FOR CLEANING
YOUR RANGE
• Clean the range regularly to keep all parts free of
grease that could catch re. Pay particular attention
to the area around each surface element. Do not allow
grease to accumulate.
• Kitchen cleaners and aerosols—Always follow the
manufacturer’s recommended directions for use.
Be aware that excess residue from cleaners and aerosols
may ignite causing damage and injury.
• Clean ventilating hoods frequently—Grease
should not be allowed to accumulate on the hood
or lter. Follow the manufacturer’s instructions for
cleaning hoods.
SELF-CLEANING OVENS
• Do not touch the oven during the self-clean cycle.
• Keep children away from oven during self-clean cycle.
• Failure to follow these instructions can result in burns.
If your gas range model design allows for L.P. conversion,
the L.P. conversion kit may be obtained from your local
appliance dealer and should be installed by a qualied
service technician. Before installing the kit be sure to
follow the L.P. Installation Instructions carefully.
Personal injury or death from electrical shock may
occur if the range is not installed by a qualied installer
or electrician. Any additions, changes or conversions
required in order for this appliance to satisfactorily meet
the application needs must be made by a qualied
technician.
Conversion to Liqueed Petroleum Gas
Avoid re hazard or electrical shock. Do not use
an adapter plug, an extension cord, or remove
grounding prong from electrical power cord.
Failure to follow this warning can cause serious
injury, re or death.
This appliance is equipped with a 3-prong grounding plug
for your protection against shock hazard and should be
plugged directly into a properly grounded receptacle. DO
NOT cut or remove the grounding prong from this plug.
For personal safety, the range must be properly grounded.
For maximum safety, the power cord must be plugged into
an electrical outlet that is correctly polarized and properly
grounded.
If a 2-prong wall receptacle is the only available outlet, it
is the personal responsibility of the consumer to have it
replaced with a properly grounded 3-prong wall receptacle
installed by a qualied electrician.
IMPORTANT SAFETY INSTRUCTIONS
7
oven vent location
Fig. 1
Removing, replacing & arranging most
oven racks types
Arranging- Always
arrange oven racks when
the oven is cool (prior to
operating the oven).
To remove- Pull the
oven rack straight out
until it reaches the stop
position. Tilt up front of
oven rack to slide past
the stop position and pull
the rack out of the oven
cavity (Fig. 4).
To replace- Rest the
oven rack at the front of
a left and right rack guide
along the oven walls so
that the oven rack rests
level. Tilt front of rack
upward and slide rack in
past the stop position.
Then bring the rack to a
level position and slide
the rack completely inside
oven (Fig. 5).
Fig. 4
Fig. 5
Oven rack stop
Most oven racks slide on rack guides provided along the
oven cavity sides. The rack guides are curved near the
front of each guide. The curve will catch and hold the
oven rack stable into a stop position when an oven rack is
extended straight out from the oven.
For better access to food items in the oven, slowly pull
the oven rack straight out to the oven rack stop position
(Fig. 3) before checking on food items or removing food
dishes from the oven.
Oven rack positions - Fig. 2
Oven vent location
The oven vent is located below the control panel (Fig. 1).
When the oven is heating, warm air passes through this
vent. This venting is necessary for proper air circulation in
the oven which helps to provide good baking results. Do
not block the oven vent.
2
3
4
5
6
1
Always use oven mitts to protect hands from possible
burns when using the oven or cooktop. The oven, oven
racks and cooktop will become very hot.
Oven racks
Do not remove or attempt to arrange oven racks with
cookware still on the racks. To avoid damaging cookware
or spilling food items, always remove any cookware rst.
rack
guides
Fig. 3
BEFORE SETTING OVEN CONTROLS
IMPORTANT
Recommended oven rack positions by food type
Food type Position
Broiling meats See broil
Cookies, cakes, pies, biscuits & mufns 3 or 4
Frozen pies, angel food cake, yeast, bread
and casseroles
1 or 2
Small cuts of meat or poultry 1 or 2
Turkey, roast or ham 1
8
BEFORE SETTING OVEN CONTROLS
Types of oven racks
Your range may be equipped with one or more of the
following oven rack types listed below:
The at oven rack may be used for most cooking needs
and may be placed in most rack positions.
The at handle oven rack (some models) may be used
for most cooking needs and may be placed in most rack
positions. Similar to the at rack but comes with a handle.
The offset oven rack (some models) provides additional
stepdown positions from the standard at rack design.
The offset design positions the base of the rack about 1/2
of a rack position lower than the at rack.
The half rack (some models) has a removable section
to allow for taller cooking utensils in the oven. When the
removable section is in place, the rack may be used like a
at rack.
The Effortless™ Oven Rack (some models) instructions
are provided later in this section. Be sure to read the
important notes.
The bottom oven rack (some models) should only be
used in the lowest oven rack position. This rack may be
used when placing large cuts of meat in the oven.
Fig. 1
at
oven
rack
at handle
oven rack
(some
models)
offset
oven rack
(some
models)
Effortless™
Oven Rack
(some
models)
half
oven rack
with
removable
shelf (some models)
bottom
oven rack
(some
models)
Baking layer cakes with 1 or 2 oven racks
For best results when baking cakes using 2 oven racks,
place cookware on rack in positions 3 & 5. For best results
when using a single or an offset oven rack, place cookware
on rack in position 2, 3 or 4.
For best baking results allow 2 to 4 inches (5-10 cm)
around the cookware for proper air circulation and be
sure pans and cookware do not touch each other, the oven
door, sides or back of the oven cavity. For even heating,
hot air must be able to circulate freely around the pans
and cookware (See Fig. 1).
Air circulation in the oven
9
Effortless™ Oven Rack system (some models)
Some models are equipped with a special oven rack
system that automatically partially extends the oven rack
from the interior oven glides to assist in easier access to
your food items. This feature works whenever the oven
door is opened or closed.
To assemble the Effortless™ Oven Rack system:
1. Locate all required parts. You will need the supplied
oven rack (Effortless™ Oven Rack is a at rack with
a special dark coating on the left and right rack
sides) and the 2 supplied chrome connector arms.
2. Open the oven door. Be sure the oven is completely
cool before proceeding.
3. Place the oven rack in positions 2, 3 or 4 only. Be
sure the rack connector brackets are at the rear of the
range and pointing towards oven bottom (See Fig. 2).
4. Assemble one connector arm at a time. With the
oven door open and the oven rack in place, install
one end of the connector arm to the hole in the door
connector bracket (Fig. 1) and the other end in the
hole in the rack connector bracket (Fig. 2 and as
in Fig. 3). The oven rack may need to be adjusted in
or out in the rack position to match the length of the
connector arm.
5. While holding the connector arm in place, twist the
connector arm so the ends of the connector arm point
upwards (See Figs. 4 & 5). The connector arm should
now be locked into position.
6. Repeat steps 4 and 5 for the other connector arm.
7. Once both connector arms are properly in place, be
sure to test the oven rack operation by gently closing
the oven door. The oven rack should move in and out
of the oven freely when the door is opened or closed.
Fig. 6 - Effortless™ Oven Rack after assembly
BEFORE SETTING OVEN CONTROLS
left and right
door connector
brackets
with connector arm ends
shown in locked position
(pointing upwards)
connector
arm
connector
arm
Fig. 5
door con-
nector
bracket
rack connector
bracket
connector
arm
connector
arm
open oven
door
Fig. 2
Fig. 1
Fig. 3 - assembly
of the Effortless™
Oven Rack
Fig. 4
IMPORTANT
• Only the Effortless™ Oven Rack system should
be used in oven rack position 2. Placing ANY other
rack in oven rack position 2 will prevent the oven
door from fully closing and may damage the oven
door, oven cavity or the door connector brackets.
• If the rack system is not assembled with the connector
arms the Effortless™ Oven rack may be used in oven
rack positions 2 thru 6. Do not attempt to use the
Effortless™ Oven rack in rack position 1.
CAUTION
Never pick up hot oven rack parts. Make sure the
oven and oven racks are COMPLETELY cool and safe to
touch before attempting to assemble or disassemble the
Effortless™ Oven Rack.
IMPORTANT
Remove ALL oven racks and accessories before
starting a self-clean cycle. If the oven racks are left
in the oven during self-clean, the glide ability of the
Effortless™ Oven Rack system will be damaged and will
cause oven racks to loose their shiny nish. Remove ALL
oven racks and clean according to instructions provided
in the Care & Cleaning section of this manual.
oven
rack
10
BEFORE SETTING SURFACE CONTROLS
To prevent are-ups and avoid creation of harmful
by-products, do not use the cooktop without all burner
caps properly installed to insure proper ignition and gas
ame size.
To avoid possible burns DO NOT touch burner caps
or surface burner grates after using any of the surface
burners. The surface burner grates, caps, and areas
around them may still be very hot. Provide sufcient
time for these areas and the parts to completely cool
before handling.
Fig. 1 - correct burner cap
placement
Be sure to review the Care & Cleaning section for com-
plete detailed information about cleaning the burner caps
and proper burner cap placement.
Using the griddle (some models)
Before rst use:
• Wash griddle in hot soapy water.
• Rinse and dry completely.
Using the griddle:
Remove the center burner grate (some models) and
carefully replace with the griddle.
For best results, preheat the griddle for 5 minutes on
medium or a medium low setting. Slow preheating
provides more even heat distribution during the cooking
process. Do not preheat the griddle on Hi setting.
Preheating using a Hi burner setting may warp the griddle
and prevent even heat distribution.
After each use:
• To prevent possible rusting, store in a dry place and
keep uncovered.
• After each use, clean with a stiff brush and hot water
only, then rinse.
• Dry immediately.
• Do not clean griddle in the dishwasher.
Fig. 2 - incorrect burner cap
placement
Visually check for proper burner cap placement before
operating any of the surface burners (See Fig.1).
Before operating the cooktop, check for
proper burner cap placement
If any of the surface burner caps appears to be resting
unevenly, not centered or appears unlevel on the burner
head (Fig. 2), be sure to correct the burner cap position on
the burner head before starting the surface burner.
11
The size and type of utensil used, the amount and type
of food being cooked will inuence the settings needed
to obtain the best cooking results.
Use quality cookware in good condition
Fig. 2
Set proper burner ame size
For most cooking; start on the highest setting and then
turn to a lower setting to complete the process. Use the
recommendations below as a guide for determining proper
ame size for various types of cooking (Fig. 2)
For deep fat frying; use a thermometer and adjust
the surface knob accordingly. If the fat is too cool, the
food will absorb the fat and be greasy. If the fat is too
hot, the food will brown so quickly that the center will
be undercooked. Do not attempt to deep fat fry too
much food at once as the food will neither brown or cook
properly.
*These settings are based for medium-weight metal or
aluminum pans with lids. Settings may vary when using
other types of pans.
The color of the ame is the key to proper burner adjustment.
A good ame is clear, blue and hardly visible in a well-lighted
room. Each cone of ame should be steady and sharp. Adjust
or clean burner if ame is yellow-orange.
Do not place aluminum foil, or ANY material that
can melt on the range cooktop. If these items melt
they may damage the cooktop.
Fig. 1
NOTE
Cookware material types
The most popular materials available are:
Aluminum - Excellent heat conductor. Some types of
food will cause it to darken (Anodized aluminum cookware
resists staining & pitting).
Copper - Excellent heat conductor but discolors easily.
Stainless - Slow heat conductor with uneven cooking
results. Is durable, easy to clean and resists staining.
Cast Iron - A slow heat conductor however will retain
heat very well. Cooks evenly once cooking temperature is
reached.
Porcelain-enamel on metal - Heating characteristics
will vary depending on base material.
Glass - Slow heat conductor.
For the best possible
cooking results when using
the cooktop, always use
quality cookware in good
condition. Pans should
have at bottoms that sit
level on the burner grate.
Before using cookware,
check for atness by
rotating a ruler across the
bottom of the cookware
(Fig. 1).
BEFORE SETTING SURFACE CONTROLS
Do not place ammable items such as plastic
wrappings, spoon holders or plastic salt and pepper
shakers on the cooktop when it is in use. These items
could melt or ignite. Potholders, towels or wooden
spoons could catch re if placed too close to the range
cooktop.
IMPORTANT
Flame size* Type of cooking
High ame Start most foods; bring water to a
boil; pan broiling.
Medium ame Maintain a slow boil; thicken sauces,
gravies; steaming.
Low ame Keep foods cooking; poach; stewing.
12
SETTING SURFACE CONTROLS
Fig. 1
Home Canning
Be sure to read and observe all the following points when
home canning with your appliance. Check with the USDA
(United States Department of Agriculture) website and be
sure to read all the information they have available as well
as follow their recommendations for canning procedures.
• Use only quality at bottom canners when home
canning. Use a straight-edge to check canner bottom.
• Start with hot tap water to bring water to boil more
quickly.
• Use the highest heat seating when rst bringing the
water to a boil. Once boiling is achieved, reduce heat to
lowest possible setting to maintain that boil.
• When using two canners at the same time, stagger the
canners on the burners. This will allow for better air ow
to the burners. Do not block air to the burners.
• NEVER place or straddle a cooking utensil over two
different surface cooking areas at the same time. This
may cause uneven heating results.
Setting surface controls
The ability to heat food quicker and in larger volumes
increases as the burner size increases. Your gas appliance
may be equipped with many different sized surface
burners.
It is important to select cookware that is suitable for the
amount and type of food being prepared. Select a burner
and ame size appropriate for the cookware size.
The standard size burner or burners may be used for most
surface cooking needs. Use the smaller simmer burner
(some models) when simmering delicate sauces, etc.
The larger quick boil (some models) burner or burners
are best when used to bring large quantities of liquid to
temperature or when heating larger quantities of food.
Setting a surface burner:
1. Place cooking utensil on center of surface burner
grate. Be sure the cooking utensil rests stable on the
burner grate.
2. Push the desired surface control knob in and turn
counterclockwise out of the OFF position (Fig. 1).
3. Release the surface control knob and rotate to the lite
position. Visually check that the burner has a steady
gas ame.
4. Once the surface burner has a ame, push the surface
control knob in and turn counterclockwise to the
desired ame size setting. Use the knob markings and
adjust the ame as needed.
Do not place ammable items such as plastic
wrappings, spoon holders or plastic salt and pepper
shakers on the cooktop when it is in use. These items
could melt or ignite. Potholders, towels or wooden
spoons could catch re if placed too close to the range
cooktop.
• DO NOT cook with a surface control knob left in the
lite position. The electronic ignitor will continue to
spark. Turn control knob out of lite position and adjust
the ame size.
• Do not place aluminum foil, or ANY material that
can melt on the range cooktop. If items melt the
they may permanently damage the appearance of the
cooktop.
NOTES
• When setting a surface control knob to the lite position,
all the electronic surface ignitors will spark at the same
time. However, only the surface burner you are setting
will ignite.
• In the event of an electrical power outage, the surface
burners may be lit manually. To light a surface burner,
hold a lit match to the burner head, then slowly turn
the surface control knob to lite. Once the burner
ignites, push in and turn knob out of lite then to
the desired ame setting. Use caution when lighting
surface burners manually.
IMPORTANT
13
OVEN CONTROL FUNCTIONS
0 thru 9
keypads —
Use to enter
temperature
and times.
timer on•off
— Use to set
or cancel the
minute timer.
broil — Use
to set broil
feature.
convect — Use
to set the convect
bake or convect
roast features.
bake —Use to
set the bake
feature.
delay start — Add to
quick preheat, bake,
convect, convect
convert and self-clean
features to program a delay
start time or delay start
self-cleaning cycle.
cancel — Use to
cancel any oven
mode previously
set except the oven
lock, set clock &
timer. Press cancel
to stop cooking.
start — Use
to activate
most oven
features
(except oven
light).
oven light
—Use to turn
the oven light
ON or OFF.
quick
preheat
— Use to
preheat
the oven.
keep
warm —
Use to set
the keep
warm
feature.
convect convert
— Use to convert a
standard bake recipe
to a convection bake
recipe.
self-clean — Use to
set a 2, 3 or 4 (some
models) hour self-clean
cycle.
oven
lock
— Use to
activate
oven lock
setting.
set clock — Use to set
the time of day.
Minimum &
maximum
control settings
bake time — Use to
enter the length of
baking time needed.
pizza —
Use to set
the pizza
feature.
probe —
Use to set
and adjust
settings for
the probe.
add a
minute —
Use to add
additional
minutes to
the timer.
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
For satisfactory use of your oven, become familiar with the various keypad functions as described below.
An entry acceptance tone (1 beep) will sound each time
a keypad is touched (the oven lock keypad tone is delayed
3 seconds).
The features listed
have minimum and
maximum time or
temperature settings
that may be entered
or adjusted using the
oven control numeric
keypads.
An entry error tone (3 short beeps) will sound if the entry
of the temperature or time is below the minimum or above
the maximum settings for the feature.
Feature Min. temp. /time Max. temp. /time
quick preheat temperature setting 170°F / 77°C 550°F / 288°C
bake temperature setting 170°F / 77°C 550°F / 288°C
broil temperature setting 400°F / 205°C 550°F / 288°C
timer 1 min. 11 hrs., 59 mins.
bake time 1 min. 6 hours
delay start 1 min. 11 hrs., 59 mins.
self-clean duration 2 hours 4 hours
convect bake temperature setting (gas) 300°F / 149°C 550°F / 288°C
convect roast temperature setting (gas) 300°F / 149°C 550°F / 288°C
pizza temperature settings (gas) 300°F / 149°C 550°F / 288°C
probe sensor reading 32°F / 0°C 240°F / 116°C
probe target temperature setting 140°F / 60°C 210°F / 98°C
14
SETTING OVEN CONTROLS
Setting the clock
When the appliance is powered up for the rst time
or when the electric supply to the appliance has been
interrupted, the display will ash “12:00” (Fig. 1).
Changing between 6-Hour Energy Saving
or continuous bake mode settings
The oven control is factory preset with to the 6 Hour
Energy Saving mode that will automatically turn the oven
off after 6 hours. The control may also be programmed to
override this feature to continuously bake.
To switch between 6-Hour Energy Saving or
continous bake modes:
Step Press
1. Press and hold timer on • off
for 6 seconds.
2. Press self-clean
to toggle between “6 Hr OFF”
(Fig. 2) or “StAY On” (Fig. 3)
and release keypad.
3. Press start to accept.
Fig. 2 Fig. 3
Setting 12 or 24 hour display mode
The oven control is factory preset to show the time of
day with a 12 hour clock. This setting may be changed to
provide the time of day with a 24 hour clock.
To set 12 or 24 hour display mode:
Step Press
1. Press and hold set clock
for 6 seconds.
2. Press self-clean
to toggle between “12 Hr dAY” or
“24 Hr dAY” display modes
(See Figs. 4 & 5) and release
keypad when the mode you prefer
is displayed.
3. Press start to accept.
Fig. 4
Fig. 5
NOTES
• Be sure to set the clock with the correct time of day
before using the oven.
• The clock cannot be adjusted when the oven is active
with any cooking function or during self-clean.
Changing between the 6-Hour Energy Saving or
continuous bake mode will not change how the cooktop
controls operate.
NOTE
To set the clock for 1:30:
Step Press
1. Press set clock.
2. Enter 1 3 0.
3. Press start to accept.
Fig. 1
15
Fig. 1
Fig. 2
To switch between audible or silent keypad
operation modes:
Step Press
1. Press and hold
delay start for 6 seconds.
2. Press self-clean
to toggle between “bEEP On” (Fig. 1)
or “bEEP OFF” (Fig. 2).
Release keypad when the mode you
prefer is displayed.
3. Press start to accept.
Fig. 3
Setting for audible or silent keypad
operation
Normally a beep will sound each time a keypad is pressed.
If desired, the control may be set for silent keypad
operation.
SETTING OVEN CONTROLS
NOTE
The temperature display mode option cannot be
changed when the oven is active with any cooking
function or during self-clean.
When the control is set for silent keypad operation the
timer, preheat and any end of cycle or error tone
alerts will remain audible.
Setting oven lock
The control may be programmed to lock the oven door
and lock the oven control keypad operations.
To activate the oven lock feature:
Step Press
Press and hold lock keypad for 3 seconds.
“door Loc” will appear in the display until
the oven door is completely locked.
Press and hold lock keypad for 3 seconds.
Once the oven door has unlocked the
“door Loc” message will no longer display
(See Fig. 3).
To cancel the oven lock feature:
Step Press
NOTE
NOTES
• To avoid possible damage to the oven door latching
mechanism, do not attempt to force open the oven
door whenever the door Loc message is displayed.
• If a control keypad is pressed when oven lock is active,
the oven control may produce an error tone (triple
beep) indicating the keypad action requested is not
available when the oven lock feature is active.
Changing oven temperature display mode
The oven control is preset to display the oven temperature
with Fahrenheit values. The control may be changed to
display either Fahrenheit or Celsius temperatures.
To change the temperature display mode:
Step Press
1. Press and hold broil for
6 seconds.
2. Press self-clean to toggle
between Fahrenheit or Celsius
temperature display modes and
release keypad when the mode
you prefer is displayed.
3. Press start to accept.
16
Quick preheat
Use this feature to quickly preheat the oven. For best
results use when baking with a single rack only. A
reminder tone will sound indicating when to place the
food in the oven. Quick preheat may be set for 170°F
(77°C) to 550°F (288°C). The quick preheat default oven
temperature is 350°F (177°C).
1. Press quick preheat.
2. Press start.
To set quick preheat using the default temperature
of 350°F:
Step Press
Once the oven has fully preheated, the quick preheat
feature will perform like bake and continue to bake
until cancelled.
SETTING OVEN CONTROLS
To set quick preheat with oven temperature of
325°F:
Step Press
1. Press quick preheat.
2. Enter 3 2 5.
3. Press start.
Add a minute
Use the add a minute feature to set additional minutes
to the timer. When the timer is active, each press of the
keypad will add one additional minute to the timer.
To add two additional minutes to the timer:
Step Press
Press add a minute keypad twice.
Step Press
1. Press timer on•off.
2. Enter 5 minutes.
3. Press start to activate.
NOTES
• The timer does not start or stop the cooking
process. The timer may be started alone or with any
other active oven feature.
• The timer will display hours and minutes until 1 hour
remains. When less than 1 hour remains, the display
will count down in minutes and seconds. Once the
timer has less than 1 minute remaining only seconds
will display.
• If both the oven and timer are active, the timer
information will display by default. To momentarily
display information for any other active oven feature,
press the keypad once for the active feature.
To set the timer for 5 minutes:
NOTE
If the add a minute keypad is pressed once when
the timer is inactive, the timer will activate and start
counting down from one minute.
The timer helps keep track of cooking times without
interfering with the cooking process. The timer may be set
for 1 minute up to 11 hours and 59 minutes.
Timer
When the timer countdown expires, “End” will appear in
the display and alert the user with 3 beeps 1 second apart.
The alert will continue until the timer on•off keypad is
pressed.
NOTE
bake time and delay start settings may be added to
quick preheat.
Always use pot holders or oven mitts when working with
a hot oven. When cooking, the oven, oven racks and
cooktop will become hot enough to cause burns.
To cancel the timer at any time press timer on•off.
To stop quick preheat at any time press cancel.
To stop quick preheat at any time press cancel.
IMPORTANT
17
SETTING OVEN CONTROLS
Bake time
A bake time setting may be added to most oven baking
features. Use the bake time setting to start the oven
immediately and to turn off automatically after the set
bake time runs out.
NOTES
1. Press bake time.
2. Enter 3 0 minutes.
3. Press start.
4. Press bake.
5. Press start to activate.
To set bake using a default temperature of 350°F and
to stop baking after 30 minutes:
Step Press
Bake
Use the bake feature to prepare most food items when the
recipe calls for normal baking. A reminder tone will sound
once the oven nishes preheating. Bake may be set for
any temperature from 170°F (77°C) to 550°F (288°C). If
bake is programmed with no temperature, the control will
default to 350°F (177°C).
When the set bake time runs out:
1. “End” will appear in the display window and the oven
will shut-off automatically.
2. The control will beep 3 times every 30 seconds as a
reminder until the cancel keypad is pressed.
FOOD POISONING HAZARD. Do not let food sit for
more than one hour before or after cooking. Doing so
can result in food poisoning or sickness.
NOTES
Dark or dull pans absorb more heat than shiny bake-
ware resulting in dark or overbrowning of foods. It may
be necessary to reduce the oven temperature or cook
time to prevent overbrowning of some foods. Dark
pans are recommended for pies. Shiny pans are recom-
mended for cakes, cookies and mufns.
Always use pot holders or oven mitts when working with
a hot oven. When cooking, the oven interior, oven racks
and cooktop will become hot enough to cause burns.
CAUTION
• The maximum bake time setting is 6 hours.
• Whenever cooking with bake time settings, press
keypad once to momentarily display the
remaining bake time.
• When bake is active with bake time settings you may
remove the bake time instructions at anytime by
setting a new bake time of 0:00.
• bake time settings cannot be added when broiling or
to the self-clean cycle.
• bake time settings may be added to quick preheat
and the convect features.
• If bake is active without bake time instructions and
bake is not cancelled, the oven will continue to bake for
6 hours before automatically turning off.
• A bake time instruction may be be added even when
the bake feature is already active.
To set bake with oven temperature of 425°F:
Step Press
1. Press bake.
2. Enter 4 2 5.
3. Press start.
To stop bake at any time press cancel.
To stop baking at any time press cancel.
IMPORTANT
18
When the set bake time runs out:
1. “End” will appear in the display window and the oven
will shut-off automatically (See Fig. 2).
2. The control will beep 3 times every 30 seconds as a
reminder until the cancel keypad is pressed.
SETTING OVEN CONTROLS
For optimum cooking results it is recommended to preheat
the oven when baking foods such as cookies, biscuits and
breads.
To program the oven for delay start and to shut-off
automatically (example for baking at 375°F for 50
minutes and to start at 5:30):
Step Press
NOTES
FOOD POISONING HAZARD. Do not let food sit for
more than one hour before or after cooking. Doing so
can result in food poisoning or sickness.
Fig. 1
Fig. 2
1. Press bake time.
2. Enter 50 mintues.
3. Press start.
4. Press delay start (See Fig. 1).
5. Enter 530.
6. Press start.
7. Press bake.
8. Enter 375.
9. Press start to activate.
• A delay start setting may be set with self-clean.
The self-clean feature will not accept bake time
instructions. Refer to the self-clean section for details
on how to select different self-clean cycle times.
• The delay start setting may be added to the quick
preheat, convect or convect convert features. A
delay start setting cannot be added to broil.
• Once the delay start feature has started the cooking
process, press the bake time keypad once to display
any bake time remaining.
Delay start
Use this keypad to add delay start time instructions for
most timed cooking features or with the self-clean feature.
To stop baking with a delay start setting at any time press
cancel.
Use caution when setting bake time or delay start
instructions. Foods that can easily spoil such as milk,
eggs, sh, meat or poultry, should be chilled in the
refrigerator rst. Even when chilled, they should not
stand in the oven for more than 1 hour before cooking
begins, and should be removed promptly when nished
cooking.
19
The convect feature uses a fan to circulate the oven’s
heat uniformly around the oven. This improved heat
distribution allows for fast, even cooking and browning
results. Heated air ows around the food from all sides,
sealing in juices and avors. Convect provides better
results when baking using multiple oven racks. Most foods
cooked with a bake setting will cook faster and more
evenly when using the convect features.
Fig. 1
SETTING OVEN CONTROLS
1. Press convect.
2. Press start.
To set convect bake with a default oven set
temperature of 350°F:
Step Press
Convect roast
1. Press convect.
2. Press convect again.
3. Press start.
To set convect roast with a default oven set
temperature of 350°F:
Step Press
Convect
Convect bake
NOTE
2
3
4
5
6
• When using the convect features, any cook time
reductions used may need to vary depending on the
oven set temperature.
• When baking layer cakes, use the bake feature to
obtain the best possible results.
• The convect fan will not start until 6 minutes after
setting the convect bake or convect roast features.
• If the oven door is opened when a convect feature is
active, the convect fan will stop rotating until the oven
door is closed.
Benets of the convection features
— Foods cook more evenly
— Multiple rack baking
— No special pans or bakeware needed
NOTES
Suggestions for convect baking
• For optimum results it is recommended to preheat the
oven before baking foods such as cookies, biscuits and
breads.
• Reduce the oven temperature 25°F from the recipe’s
recommended oven temperature. Follow the remainder
of the recipe’s instructions using the minimum
recommended cook time.
• When using 2 oven racks at the same time, place in
positions 3 & 5 for best results (Fig. 1).
Suggestions for convect roasting
• Preheating is not necessary when roasting foods using
convect roast.
• Since convect roast cooks faster, reduce cook times by
25% from the recommended time of your recipe (check
the food at this time). Then if needed, increase cook
time until the desired doneness is obtained.
• Do not cover foods when dry roasting - this will prevent
the meat from browning properly.
When choosing the different convect features, use the
convect keypad to toggle between the choices.
To stop convect bake at any time press cancel.
To stop convect roast at any time press cancel.
1
20
Convect convert
The convect convert feature allows you to convert any
baking recipe for the convect feature. The control uses the
normal recipe settings and adjusts to a lower temperature
for convection baking. The convect convert feature may
only be used when convect baking.
To set convect using default oven set temperature
of 350°F and adding the convect convert:
Step Press
1. Press convect keypad.
2. Press convect convert.
NOTES
SETTING OVEN CONTROLS
• When using convect convert, any cook time
reductions needed may vary depending on the oven
set temperature.
• When baking layer cakes, use the bake feature to
obtain the best results.
• The convection fan will not start until 6 minutes after
setting the convect convert feature.
• The minimum bake time setting allowed using the
convect convert feature is 20 minutes.
Probe
The probe feature, when set
correctly, will alert when the
internal food temperature
reaches the desired
“target”
temperature.
When active, the probe will
display the internal food
temperature, eliminating the
need for any guesswork.
• To avoid damaging the probe, do not use kitchen
utensils such as tongs to pull on the probe cable or
handles. Always insert and remove the probe using
the provided handles (See Fig. 2) and always use a
pot holder to protect hands from possible burns.
• Do not store the probe inside the oven. Always
remove the probe from the oven when nished.
• Use only the original probe provided with this
appliance. Connecting any other probe or device into
the probe receptacle could result in damage to the
oven control, electronics and the receptacle.
• Before starting self-clean, double check that the
probe is removed from the oven interior. The high
temperatures generated by self-clean may damage or
destroy the probe.
• To avoid damaging the probe, defrost frozen foods
completely before inserting the probe.
handle
handle
probe
cable
probe
sensor
Fig. 2
To stop convect convert at any time press cancel.
Fig. 1
For some food types, especially
poultry and roasts, using a
probe to check the internal
temperature is the safest
possible method to insure
properly cooked food.
To avoid the possibility of burns after cooking with the
probe, use care when disconnecting the probe from the
receptacle or food. The probe may be hot. Be sure to
always use a pot holder to protect hands.
Be sure to use the probe feature for best results when
cooking foods such as roasts, hams or poultry. This feature
also works well with other foods such as meat loaf and
casseroles.
When convect convert is active with a bake time or a delay
start setting, the convect convert feature will display the
message “CF” for check food when the bake time is 75%
complete (See Fig. 1). At this time the oven control will
sound 1 long beep at regular intervals until the set bake
time has nished.
IMPORTANT
21
SETTING OVEN CONTROLS
Probe (cont’d)
• Always insert the probe so that the probe tip rests
inside at the center of the thickest part of meat or food
(See Fig. 1). For best results, do not allow the probe
temperature sensor to contact bone, fat, gristle or the
cookware.
• For bone-in ham or lamb, insert the probe into the
center of lowest large muscle or joint. For dishes such as
meat loaf or casseroles, insert the probe into center of
food. When cooking sh, insert meat probe just above
the gill.
• For whole poultry or turkey, fully insert the probe sensor
into the thickest part of breast area (See Fig. 2).
Proper probe placement in food:
Fig. 2
Fig. 1
To set the oven to continue cooking after reaching
the target temperature:
1. Press keypad and hold for 6 seconds.
2. Press keypad and toggle until the “Continu”
message appears (Fig. 3) then press to accept.
To set the oven to automatically stop cooking and
start keep warm once reaching target temperature:
1. Press
keypad and hold for 6 seconds.
2. Press keypad and toggle until “CAnCEL”
message appears (Fig. 4) then press to accept.
Fig. 3
Fig. 4
Choosing a setting for how the oven will operate
once the probe reaches the target temperature
Your oven is factory preset to automatically stop cooking
and start the keep warm feature once the probe sensor
reaches the set target temperature. This setting may be
changed to continue cooking if desired.
Setting the option for how the oven will heat once the
probe reaches the target temperature must be done
when the oven is inactive. The probe is not required to
be connected to the probe receptacle when setting this
option.
Insert
probe tip
to center of
food
IMPORTANT
22
Probe (cont’d)
Fig. 2 -
SETTING OVEN CONTROLS
To set probe:
1. Insert the probe into the food.
2. Place prepared food on the desired oven rack position
and slide into the oven.
3. Plug the connector end of the probe all the way into
the probe receptacle while the oven is still cool. The
receptacle is located on the upper left front oven
cavity wall (Fig. 2).
4. When the probe is detected, an acceptance tone will
sound, the icon will illuminate and the current
actual probe temperature will appear in the display
(Fig. 3). Close the oven door.
receptacle probe
connector
Fig. 3
5. Press keypad.
6. Enter the desired target food temperature using
the numeric keypads and set temperature for food
type (Refer to Fig. 1). The minimum target setting
is 140ºF/60ºC; the maximum target setting is
210ºF/99ºC. The default target is 170ºF/77ºC.
7. Press to accept the target temperature.
8. Set for quick preheat, bake, convect bake,
convect roast or convect convert and if necessary
adjust the oven temperature accordingly.
9. The control will provide 3 beeps when the internal
target temperature is reached. By default the oven
will automatically change to a keep warm setting
(“HLd” and the actual probe temperature will alternate
in the display). keep warm will maintain the oven
temperature at 170° F (77°C) for 3 hours unless
otherwise cancelled.
To stop cooking at any time press cancel.
handle
† The U.S. Department of Agriculture states, “Rare
fresh beef is popular, but you should know that
cooking it to only 140°F/60°C means some food
poisoning organisms may survive.” (Source: Safe
Food Book, Your Kitchen Guide, USDA Rev. June 1985.)
Information courtesy the U.S. Department of Agriculture
Food Safety and Inspection Service.
Visit the U.S. Department of Agriculture Food Safety and
Inspection Service website at www. fsis.usda.gov
Fig. 1
USDA recommended minimum internal cooking
temperatures:
Food type Internal temp.
Ground meat & meat mixtures
Beef, Pork, Veal, Lamb 160°F (71°C)
Turkey, Chicken 165°F (74°C)
Fresh beef, veal, lamb
Medium rare† 145°F (63°C)
Medium 160°F (71°C)
Well done 170°F (77°C)
Poultry
Chicken & Turkey, whole 165°F (74°C)
Poultry Breasts, Roasts 165°F (74°C)
Poultry Thighs, Wings 165°F (74°C)
Duck & Goose 165°F (74°C)
Stufng (cooked alone or in bird) 165°F (74°C)
Fresh pork 160°F (71°C)
Ham
Fresh (raw) 160°F (71°C)
Pre-cooked (to reheat) 140°F (60°C)
Eggs & egg dishes
Eggs Cook until yolk & white are rm.
Egg dishes 160°F (71°C
Leftovers & Casseroles 165°F (74°C)
23
If the error message “Prob ERR” displays (Fig. 1), check
to be sure that the probe connector is fully inserted
into the receptacle. If the probe is fully inserted in the
receptacle and the error message continues, the probe
may be defective and need replaced.
When “Prob ERR” displays, the oven control will not
permit any oven feature to activate until corrected or the
probe is removed. If the error message continues, remove
the probe from the receptacle and oven.
Probe error message:
Fig. 1
“Probe Too Hot” message:
When the message “Prob” ... “Too”... “Hot” ... ashes in
the display, the probe sensor temperature has exceeded
250°F (121°C). If the probe is not removed this message
may continue until the sensor reaches 300°F (149°C) or
higher, at which time the oven will automatically turn OFF
and display “Prob ERR” message.
This message may have been generated if the probe
sensor is exposed to direct oven heat or the food
internal temperature is over 250°F (121°C). Be sure the
probe sensor is fully covered by the food or if the food is
done, press cancel and remove food and probe from the
oven.
Probe (cont’d)
NOTES
• During the cooking process the internal food
temperature will display by default. To review the
target temperature press the keypad once. After
6 seconds the display will revert back to the internal
food temperature.
• To assure temperature accuracy, do not remove the
probe from the food or receptacle until the desired
internal temperature is met.
• If the probe is active and the probe is removed from
the receptacle only, the probe feature will cancel but
the oven will continue to cook.
• If the probe is active and the probe is removed from
the food only, the probe feature will remain active, but
the displayed internal food temperature may no longer
be reliable. This may eventually generate a “Probe
Too Hot” message.
• The oven will automatically turn OFF if the probe
sensor reaches 300°F (149°C) or more.
• The probe feature cannot be set with broil or self-
clean.
• To change the target temperature while cooking,
press the keypad once. Use the numeric
keypads to change the target temperature. Press the
start keypad to accept any change.
handle
probe
cable
probe
sensor
Fig. 2
SETTING OVEN CONTROLS
handle
24
SETTING OVEN CONTROLS
Use the broil feature to cook meats that require direct
exposure to ame heat for optimum browing results.
When broiling, always remember to arrange the oven
racks while the oven is still cool.
Broil
1. Arrange the oven racks when cool (See Figs. 2 & 4).
For optimum browning results, preheat the oven for
about 5 minutes before adding food.
2. Be sure to place prepared food directly under upper
oven burner. Close the oven door.
3. Press broil (See Fig. 1).
4. Press start to activate.
5. Broil food on one side until browned.
Turn and broil food on other side.
To set broil:
Step Press
Insert
Broil
pan
Fig. 2
Fig. 4
Fig. 3
NOTES
Fig. 1
4
5
6
To stop broil at any time press cancel.
Should an oven re occur, close the oven door and
turn the oven OFF. If the re continues, use a re
extinguisher. DO NOT put water or our on the re.
Flour may be explosive.
• For better access to food while broiling, use oven mitts
and pull the oven rack out to the rack stop position
before turning or removing the food.
• If needed, lower the oven temperature to avoid over
browning or drying of food items that should be cooked
to the well-done stage.
• bake time or start time instructions cannot be added
to the broil feature.
• When broiling the oven control does not provide a
preheat indicator or reminder tone when the oven
reaches set temperature.
• When broiling with a pan, be sure to use only
Electrolux Home Products, Inc. approved broil pan &
insert (Fig. 3).
Suggested broil settings table (gas oven)
Food Rack position Setting
Cook time in minutes
Internal
temperature Doneness1st side 2nd side
Steak 1
” thick
5th 550°F
5
5 125°F/52°C Rare
Steak 1
” thick
5th or 6th* 550°F 8 6 145°F/63°C Medium
Steak 1
” thick
5th or 6th* 550°F 10 8 160°F/71°C Medium-Well
Steak 1
” thick
5th or 6th* 550°F 11 10 170°F/77°C Well
Pork chops 3/4
” thick
5th 550°F 12 8 170°F/77°C Well
Chicken-bone in 4th 450°F 25 15 170°F/77°C Well
Chicken-boneless 5th 450°F 10 8 170°F/77°C Well
Fish 5th 550°F - as directed - 170°F/77°C Well
Shrimp 4th 550°F - as directed - 170°F/77°C Well
Hamburger 1
” thick
5th 550°F 5 5 125°F/52°C** Rare
Hamburger 1
” thick
6th* 550°F 12 10 145°F/63°C** Medium
Hamburger 1
” thick
5th 550°F 14 12 170°F/77°C Well
* Use the off-set rack if you choose to use rack position 6.
**We recommend following the USDA guidelines of 160°F/71°C as a safe minimum internal temperature for Ground beef. Consuming raw or
undercooked meats, poultry, seafood or shellsh may increase your risk of food borne illness.
***Broiling is direct heat cooking and will produce some smoke. If smoke is excessive, place food further away from the element. Always watch
food carefully to prevent burning.
25
1. Press pizza once to cook frozen
pizza (Fig.1) or twice when setting
for fresh pizza (Fig. 2). You may
adjust the oven temperature
to t your needs.
2. Press start.
Setting pizza feature
For your convenience the pizza feature provides 2 different
settings. You may use the pizza feature whether starting
with fresh or frozen pizza.
To set the pizza feature:
Step Press
Setting keep warm
The keep warm feature will keep oven cooked foods warm
for serving up to 3 hours. After 3 hours the keep warm
feature will automatically turn OFF.
The keep warm feature may be used independently. This
feature may also be set as a “trailing keep warm”.
1. Press keep warm.
2. Press start.
“HLd” for hold will appear
in the display.
Step Press
FOOD POISONING HAZARD. Do not let food sit for
more than one hour before or after cooking. Doing so
can result in food poisoning or sickness.
NOTES
Fig. 1 Fig. 2
To set oven for keep warm:
1. Press bake time.
2. Enter 3 0 minutes.
3. Press start.
4. Press bake.
5. Press start to activate.
6. Press keep warm. “HLd” for hold
will appear in the display.
7. To accept, press start.
To set to bake for 30 minutes with the default
temperature of 350°F; after baking the keep warm
feature will automatically activate:
Step Press
To stop pizza feature at any time press cancel.
To stop keep warm at any time press cancel.
• Use only one oven rack for best results with the pizza
feature.
• The pizza feature is not timed. Be sure to monitor
the time needed to nish cooking the pizza. Follow
package directions for baking time. Check pizza at the
minimum recommended time.
• The preset oven temperature for the frozen pizza
setting is 425°F and the fresh pizza is 400°F.
SETTING OVEN CONTROLS
NOTES
• Once activated, the keep warm feature will
automatically turn the oven OFF after 3 hours.
• If a keep warm setting is added to bake as a
“trailing keep warm” for example, the setting must
include bake time instructions.
26
The purpose of the Keep Warm Drawer is to keep hot
cooked foods at serving temperatures. Examples are
vegetables, gravies, meats, casseroles, biscuits, rolls and
pastries. It is not recommended to heat cold food in the
warmer drawer; always start with hot food.
The Keep Warm Drawer may also be used to warm dinner
plates. All food placed in the Keep Warm Drawer should be
covered with a lid or aluminum foil to maintain quality.
Setting Keep Warm Drawer (some models)
• DO NOT LEAVE CHILDREN ALONE —children
should not be left alone or unattended in the area
where appliance is in use. They should never be
allowed to sit or stand on any part of the appliance,
including the warmer drawer.
• FOOD POISONING HAZARD. Do not let food sit
for more than one hour before or after cooking. Do-
ing so can result in food poisoning or sickness.
• Storage in or on appliance—ammable materi-
als should not be stored in an oven, warmer drawer,
near surface units. This includes paper, plastic and
cloth items, such as cookbooks, plasticware and
towels, as well as ammable liquids. Do not store
explosives, such as aerosol cans, on or near the
range.
KEEP WARM DRAWER
Always use potholders or oven mitts when removing food
or plates from the warmer drawer as cookware andplates
will be hot and you can be burned.
IMPORTANT
Do not use plastic wrap to cover food. Plastic
wrap can melt onto the drawer surfaces and be
very difcult to clean up afterwards.
Use only cooking utensils and cookware recommended
by the manufacturer for use in a warmer drawer
NOTES
• Always start with hot food when using the Keep
Warm Drawer. Do not heat cold food in the
KeepWarm Drawer.
• The Keep Warm Drawer is equipped with a catch-
that may require extra force when opening or clos-
ing the drawer.
• Self clean can not be set when the Keep Warm-
Drawer is turned on.
Keep Warm Drawer rack positions
The Keep Warm Drawer rack may be positioned in the
drawer two ways:
• In the upright position to allow low prole food
items to be placed both under and on top of the rack
(for example, rolls or biscuits on top of rack and a
casserole dish underneath).
• In the downward position to allow for light weight
food items and empty cookware on rack (for example,
rolls or pastries and dinner plates).
Downward Position
Upright Position
27
KEEP WARM DRAWER
Keep Warm Drawer recommended food settings
The recommended food settings for the Keep Warm
Drawer are provided below. The heat settings provided
should be used for recommendations only. If a particular
food item is not listed, start with a medium setting. If
more crispness is desired, remove the lid or aluminum foil
from the food item.
Most food items may be maintained at serving tempera-
tures using the medium setting (midway between hi and
lo - See Fig. 2). When a combination of foods are
to be kept warm (for example, a meat with 2 vegetables
and rolls) use the hi (high) setting.
Keep Warmer Drawer recommended food
heat settings table
Food item
Bacon
Hamburger patties
Poultry
Pork chops
Fried foods
Pizza
Gravies
Casseroles
Eggs
Roasts (beef, porkor lamb)
Vegetables
Biscuits
Rolls (hard)
Pastries
Rolls (soft)
Empty dinner plates
Setting
hi (high)
hi (high)
hi (high)
hi (high)
hi (high)
hi (high)
medium
medium
medium
medium
medium
medium
medium
medium
lo (low)
lo (low)
IMPORTANT
For better results, limit the number of times the Keep
Warm Drawer is opened when active. This will help mini-
mize heat and moisture loss.
Keep Warm Drawer indicator light
The indicator light is located above the Warmer Drawer
thermostat control knob (See Fig. 2). The indicator turns
on when the control is set, and stays on until the heat
setting is turned OFF.
Keep Warm Drawer control knob
Use the thermostat control knob to select the desired
temperature setting for the Keep Warm Drawer. It is
located on the control panel. The heat settings are
marked OFF, lo and hi. Please note that the approximate
medium setting is shown on illustration (See Fig. 2).
med
Fig. 2
To set Keep Warm Drawer:
1. Open Keep Warm Drawer when cool and arrange
Keep Warm Drawer rack as needed.
2. For best results, close the Keep Warm Drawer and
preheat the drawer before adding food items. An
empty Keep Warm Drawer will fully preheat in ap-
proximately 15 minutes.
3. Push in and turn the Keep Warm Drawer control
knob in either direction to the desired heat setting
and release (See Fig. 2).
4. Only hot food that has already reached serving
temperature should be placed in the Keep Warm
Drawer. Position on rack and close Keep Warm
Drawer. Dinner plates may be warmed also.
5. When nished, turn the Keep Warm Drawer heat
setting knob to OFF position. Carefully remove
itemsand close Keep Warm Drawer.
Always use potholders or oven mitts when removing
food or plates from the warmer drawer as cookware
and plates will be hot and you can be burned.
28
SETTING OVEN CONTROLS
Operating the oven light
The oven light will automatically turn ON when the oven
door is opened.
Press to turn the oven light ON and OFF whenever
the oven door is closed.
The oven light is located at the upper left rear wall of the
oven interior and is covered with a glass shield held by a
wire holder. The glass shield must be in place whenever
the oven is in use.
Your appliance has been factory calibrated and tested
to ensure an accurate baking temperature. For the rst
few uses, follow your recipe times and temperature
recommendations carefully. If you think the oven is
cooking too hot or too cool for your recipe times, you can
adjust the control so the oven cooks hotter or cooler than
the temperature displayed.
The oven temperature may be increased +35°F (+19°C)
or decreased -35°F (-19°C) from the factory settings.
Example: increase the oven temperature by 30°F:
Adjusting the oven temperature
Step Press
1. Press and hold bake
for 6 seconds.
2. Enter 30.
3. To accept, press start.
Example: decrease the oven temperature by 30°F:
Step Press
1. Press and hold bake
for 6 seconds.
2. Enter 30.
3. Press self clean.
4. To accept, press start.
NOTES
Restoring to factory default settings
When new, your appliance was set with preset oven
control settings. Over time, the user may make changes to
these default settings.
The following features have user program options or
adjustments that may have been modied from the factory
default settings:
• 12 or 24 hour clock display mode.
• 6-Hour Engergy Savings or continuous bake mode.
• Silent or audible keypad operation.
• Oven temperature display mode (F° or C°).
• Any oven temperature offset adjustment made.
• Temp probe options (some models).
• Any stored favorite recipes (some models).
Before restoring the settings, be aware that all
changes made to the oven control settings will be
erased once the start keypad is pressed. This includes
any temperature offset made for the oven.
1. Press and hold 7 keypad until
acceptance tone sounds
(about 6 seconds).
2. To accept, press start.
Step Press
To restore oven control to factory settings:
• Oven temperature adjustments made will not affect
the broil or self-clean operating temperatures.
• If the temperature shows an adjustment of -30°F,
and a +30°F adjustment is needed, you can toggle
between the (-) or (+) in the display by pressing self
clean.
• Do not use oven thermometers such as those found
in grocery stores to check the temperature settings
inside your oven. These oven thermometers may
vary as much as 20 to 40 degrees from actual
temperatures.
NOTE
The oven light will not operate when self-clean is active.
If the oven light is ON when setting self-clean, the oven
light will turn off.
IMPORTANT
29
The bake time and delay start keypads are used to
set the Sabbath feature. The Sabbath feature may only
be used with the bake feature. The oven temperature
may be set higher or lower after setting the Sabbath
feature (oven temperature adjustments should be used
only during Jewish Holidays), however the display will not
be visible and no audible tones will be provided when a
change occurs.
Once the oven is properly set using the bake feature
with the Sabbath mode active, the oven will remain
continuously ON until cancelled. The Sabbath mode will
override the factory preset 6-Hour Energy Saving feature.
If the oven light is needed during the Sabbath, turn on
the oven light before activating the Sabbath feature.
Once the oven light is turned on and the Sabbath feature
is active, the oven light will remain on until the Sabbath
feature is turned OFF. If the oven light needs to be off,
be sure to turn the oven light off before activating the
Sabbath feature.
1. Be sure that the clock is set with
the correct time of day.
2. Arrange the oven racks.
3. Press bake.
4. Press start.
5. If a bake time or delay start
is needed then enter the time
in this step.
If not, skip this step and continue
to step 6. Refer to the bake time
or delay start instructions.
Remember the oven will shut-off
after completing a
bake time or delay start and
therefore may only be used once
during the Sabbath/Jewish Holidays.
The maximum delay start time
is 11 hours & 59 minutes.
6. Press and hold both the +
bake time and delay start
keypads for at least 3 seconds
simultaneously. The control will
beep and SAb will appear in
the display (See Fig. 1). The oven
is properly set for the Sabbath
once SAb appears in the display.
To program the oven for 350°F bake and activate
the Sabbath feature:
Step Press
FOOD POISONING HAZARD. Do not let food sit for
more than one hour before or after cooking. Doing so
can result in food poisoning or sickness.
It is recommended that any oven temperature change
with the Sabbath feature active be followed with 2 presses
of the start keypad. This will insure the oven remains
ON even if the attempt to set the oven temperature was
lower or higher than the oven control can accept. If the
oven temperature is set incorrectly, the oven temperature
will default to 170°F or 550°F. Try to set the desired oven
temperature again.
To Set the Sabbath Feature (for use on the
Jewish Sabbath & Holidays)
For further assistance, guidelines for proper
usage and a complete list of models with
the Sabbath feature, please vist the web at
http:\\www.star-k.org.
Fig. 1
SETTING OVEN CONTROLS
30
To Set the Sabbath Feature (cont’d)
NOTES
What to do during a power failure or power
interruption after the Sabbath feature was
activated:
Should you experience a power failure or interruption, the
oven will shut-off. When power is restored the oven will
not turn back on automatically. The oven will remember
that it is set for the Sabbath and the oven display will
show the message “SF” for Sabbath failure (Fig. 1).
To turn off the oven but keep the Sabbath feature
active:
Press cancel.
To turn off the Sabbath feature:
Press and hold both the
+
bake time and delay start pads
for at least 3 seconds. The control
will beep and SAb will disappear
from the display. The oven is no
longer programmed for the
Sabbath feature.
The food may be safely removed from the oven while
still in the Sabbath feature, however the oven cannot be
turned back on until after the Sabbath/Holidays.
After the Sabbath observance turn OFF the Sabbath
feature. At the same time press and hold both the
+ keypads for at least 3 seconds.
SF will disappear from the display and the oven may be
used with all normal functions.
Fig. 1
SETTING OVEN CONTROLS
• If a delay start time longer than 12 hours (maximum
of 24 hours) is desired, set the display mode for the
24 hour setting. For detailed instructions see the
section “Setting 12 or 24 hour display modes”.
• It is not advised to attempt to activate any other
program feature except bake while the Sabbath
feature is active. ONLY the following keypads will
function correctly with the Sabbath feature: 0-9
number keypads, bake, start & cancel. All
other keypads should not be used once the
Sabbath feature is active.
• You may change the oven temperature once baking
has started. Press bake , enter the oven temperature
change (170 to 550F°) and press start (for Jewish
Holidays only). Remember that the oven control will
no longer beep or display any further changes
once the oven is set for the Sabbath feature.
• If the keep warm feature was activated and the
Sabbath feature was set the keep warm feature will
automatically shut-off the oven off after 3 hours.
31
SELF-CLEANING
A self-cleaning oven cleans itself using high temperatures
that are well above normal cooking temperatures. The
self-clean feature, if used properly, will eliminate soils from
the oven completely or reduce them to a ne powdered
ash. Once the oven has cooled, simply wipe away the ash
using a damp cloth.
Fig. 1
• Do not touch the oven during the self-clean cycle.
• Keep children away from oven during self-clean cycle.
• Failure to follow these instructions can result in burns.
Preparing for self-clean
The health of some birds is extremely sensitive to the
fumes given off during the self-cleaning cycle of any
range. Move birds to another well-ventilated room.
Read before starting self-clean
• Remove all items from the oven and cooktop,
including food, cookware, utensils, plastic and
any aluminum foil and probe (if equipped).
Aluminum foil will not withstand high temperatures
generated during a self-clean cycle.
• Remove all oven racks and any accessories
from the oven to avoid possible heat damage. If
the oven racks are not removed they may discolor.
The Effortless™ Oven Rack (some models) must be
removed before starting self-clean to avoid damaging
the glide ability of the rack.
• Be sure the oven vent area is clear.
• Remove all items from the storage drawer (some
models) or warming drawer (some models).
• Be sure the oven light shield is in place.
• Remove any excessive spillovers. Spills on
the oven bottom should be wiped-up and removed
before starting self-clean. To clean, use hot, soapy
water and a cloth. Large food spillovers can cause
heavy smoke or a re during self-clean.
• Remove any food spills from oven that have a high
sugar or acid content (such as milk, tomatoes,
sauerkraut, fruit juices or pie lling) before starting
a self-clean cycle. If they are not removed they may
leave a dull spot even after self-cleaning.
• Clean any soil from the outer oven frame, the door
liner outside the oven door gasket and the small area
at the front center of the oven bottom. Clean using
soap and water before starting self-clean. These areas
(See Fig. 1) heat sufciently to burn soil on.
• Do not clean the oven door gasket (See Fig. 1).
Do not use any cleaning materials on the oven door
gasket. Doing so could cause damage to the door
gasket. The woven material of the oven door gasket is
essential for a good seal. Care should be taken not to
rub, damage or remove the gasket.
• Do not use commercial oven cleaners or protective
coatings of any kind inside oven. Residue from oven
cleaners may damage the porcelain during the next
self-clean cycle.
Your oven provides three self-cleaning duration choices. A
3-hour cleaning time for normal cleaning; a 2-hour clean
for lighter soils and a 4-hour option for heavier burnt-on
soils (some models).
clean
do not
clean
IMPORTANT
32
SELF-CLEANING
After pressing start, the door lock motor will activate.
“door Loc” will appear in the display (Fig. 1). DO
NOT attempt to open the oven door when the “door
Loc” message is displayed (allow about 15 seconds for
the oven door to completely lock). DO NOT force the
oven door open. This may damage the automatic door
locking system.
Setting a self-clean cycle
When the self-clean cycle is done:
1. The time of day and “Hot” will show in the display
(See Fig.3).
2. Once the oven has cooled (about 1 hour) and “Hot”
is no longer displayed the “door OPn” message will
appear (Fig. 4). When this message turns off the door
is nished unlocking. Use caution and avoid possible
burns when opening the door after the self-cleaning
cycle. The oven may still be VERY HOT.
Step Press
1. The oven should be empty and all
oven racks removed. Remove
all items from the cooktop. Be sure
the oven door is completely closed.
2. Press self clean once for a 3-hour
clean time, press self clean twice for
4-hour clean and press 3 times
for a 2-hour self-clean cycle time.
3. Press start to activate.
Example: To start an immediate self-clean cycle:
NOTES
Fig. 1
Fig. 2
Fig. 3
Fig. 4
• Whenever the self-clean feature is active you may
check the amount of clean time remaining by pressing
the
keypad once. The oven door will remain
locked until the range has cooled sufciently. You will
need to allow about 1 additional hour to the time
displayed before you can open the oven door.
• When the oven is cool, wipe away any residue or
powdered ash from the oven interior using a damp
cloth or paper towel.
• It is normal for odors to occur during self-clean,
especially during the rst self-clean cycle. It is
recommend to ventilate the kitchen. Open any
windows and if available turn on an exhaust fan or
overhead range hood during the self-clean cycle.
• Be aware that during self-clean temperatures inside
the oven will become hot enough to melt or destroy
some types of materials, including cookware made
with materials having a low melting point and
aluminum foil.
Read before starting self-clean (cont’d)
Once the door has locked, “CLn”
will appear in the display indicating
the oven has started heating for the
self-clean cycle (Fig. 2).
To avoid possible burns use caution when opening the
oven door when the self-clean cycle is nished. The
oven may still be VERY HOT. Stand to the side of
the oven when opening the door to allow hot air or
steam to escape.
Press cancel at any time to stop self-clean.
IMPORTANT
IMPORTANT
33
Step Press
1. The oven should be empty and all
oven racks removed. Remove
all items from the cooktop. Be sure
the oven door is completely closed.
2. Press delay start.
3. Enter 9 0 0.
4. Press start.
5. Press self clean once for a 3-hour
clean time, press self clean twice for
4-hour clean and press 3 times
for a 2-hour self-clean cycle time.
6. Press start to accept.
Example: To program a self-cleaning cycle with a
delay start time of 9:00 o’clock:
Setting a delay start self-clean cycle
1. Press keypad.
2. If the self-clean cycle has heated the oven to a high
temperature, the “Hot” (Fig. 1) message will show in
the display. Allow enough time for the oven to cool
and for the “door OPn” message to display (Fig. 2).
When this message turns off the oven door may be
opened.
If it becomes necessary to cancel self-clean:
Restarting a self-clean cycle after a power outage:
If a self-clean cycle was cancelled using the cancel
keypad before the oven was nished cleaning, you may
wish to set for another self-clean cycle.
If self-clean was cancelled shortly after being started,
and the oven interior did not reach high self-clean
temperatures, the next clean cycle may be set as soon as
the oven door unlocks from the cancelled clean cycle.
If the oven became hot enough from the cancelled self-
clean cycle, you may be required to wait up to 4 hours
before the control will allow another self-clean cycle to
start.
NOTES
• Check to be sure the oven is empty before setting
a self-clean cycle using a delay start setting.
Immediately after setting self-clean with delay start
the oven door will lock. The self-clean feature will not
start heating the oven for cleaning until reaching the
delay start time
• The maximum delay start setting is 11 hours & 59
minutes.
If a self-clean cycle was interrupted by a power failure,
your oven may not have thoroughly cleaned. If so, once
power is restored, the oven has cooled and the oven door
has unlocked, if needed, set again for self-clean.
Fig. 1
Fig. 2
Press cancel at any time to stop self-clean.
SELF-CLEANING
Starting another self-clean after cancellation:
NOTE
If attempting to set “back to back” self-clean cycles,
the control may display the messages “CLEAn” , then
“dELAy” followed by the length of time to wait before
the next self-clean may be set. For example, if the
message displayed shows “4:00”, the control will not
allow for another self-clean cycle to start for the next 4
hours.
34
CARE & CLEANING
Cleaning recommendation table
Surface type Recommendation
• Control knobs (some models)
• Painted body parts
• Painted decorative trim
• Aluminum, plastic or vinyl trim
For general cleaning, use hot, soapy water and a cloth. For more difcult soils
and built-up grease, apply a liquid detergent directly onto the soil. Leave on
soil for 30-60 minutes. Rinse with a damp cloth and dry. Do not use abrasive
cleaners on any of these materials; they can scratch. To remove control knobs,
turn to OFF position; grasp rmly and pull straight off the shaft. To replace
knobs after cleaning, line up the at sides of both knob and shaft; then push
knob into place.
• Control panel
• Control key pad membrane
• Decorative trim (some models)
Before cleaning the control panel, turn all controls OFF, activate oven lockout
(on some models) and if needed remove any knobs from panel. Do not use
abrasive cleaners on any of these materials; they can scratch. Clean using hot,
soapy water and a dishcloth. Be sure to squeeze excess water from dishcloth
before wiping control panel; especially when wiping around the controls area.
Excess water in or around the controls may cause damage to the appliance.
When rinsing, use clean water and a dishcloth and be sure to squeeze excess
water from dishcloth before wiping the control panel.
• Easy Care™ Stainless
Steel (some models)
If your range nish is Easy Care™ Stainless Steel (some models), clean
the stainless with warm soapy water using a clean sponge or cloth. Rinse with
clean water and dry with a soft clean cloth. DO NOT use ANY store bought
cleaners like Stainless Steel cleaners or any other types of cleaners containing
any abrasive, chlorides, chlorines or ammonia. It is recommended to use mild
dish soap and water or a 50/50 solution of water and vinegar.
• Porcelain enamel parts
• Porcelain enamel broiler pan and
broiler pan insert (if equipped)
Gentle scrubbing with a soapy no-scratch cleaning pad will remove most spots.
Rinse with a 1:1 solution of clear water and ammonia. If necessary, cover
difcult spots with an ammonia-soaked paper towel for 30 to 40 minutes.
Rinse with clean water and a damp cloth, and then scrub with a soap-lled no-
scratch cleaning pad. Rinse and wipe dry with a clean cloth. Do not allow food
spills with high sugar or acid content (milk, tomatoes, sauerkraut, fruit juices
or pie lling) to remain on the surface; they may cause a dull spot even after
cleaning.
• Oven interior Remove excessive spillovers from oven cavity bottom before starting self-
clean. Clean any soils from oven frame and door liner outside the oven door
gasket. For very important preparation information be sure to read all the
instructions in the self-cleaning section
.
• Oven racks Oven racks must be removed from oven. Do not clean oven racks in
oven during the self-clean cycle. Remove and clean using a mild, abrasive
cleaner following manufacturer’s instructions. Thoroughly rinse and dry.
• Oven door Use soap & water to thoroughly clean the top, sides and front of the oven door.
Rinse well. You may use a glass cleaner on the outside glass of theoven door.
Do not immerse the door in water. Do not spray or allow water or the
glass cleaner to enter the door vents. Do not use oven cleaners, cleaning
powders or any harsh abrasive cleaning materials on the outside of the oven
door. Do not clean the oven door gasket. On self-cleaning models the oven
door gasket is made of a woven material which is essential for a good seal.
Care should be taken not to rub, damage or remove this gasket.
• Cooktop surface , contoured well
area, burner heads & burner caps
See “Cleaning the cooktop and surface burners” instructions provided in the
Care & Cleaning section.
35
To clean recessed and contoured areas of cooktop
Routinely clean the cooktop. Wipe with a clean, damp cloth
and wipe dry to avoid scratches. If a spill occurs on or in the
recessed or contoured areas, blot up spill with an absorbent
cloth. Rinse with a clean, damp cloth and wipe dry.
To clean burner grates
• Clean when the grates are cool.
• Use nonabrasive plastic scrubbing pad and mild abrasive
cleanser.
• Food soils containing acids may affect the nish. Clean
immediately after the grates are cool.
• Thoroughly dry grates immediately following cleaning.
To clean burner caps
• Remove caps from burner heads after they have cooled.
• Clean heavy soils with a plastic scrubbing pad and
absorbent cloth.
• Thoroughly dry burner caps immediately following
cleaning including the bottom and inside of cap.
• Do not use abrasive cleaners. They can scratch porcelain.
• Do not clean burner caps in the dishwasher.
• Check for correct burner cap placement after having
removed and replaced the burner caps for cleaning.
Cleaning the cooktop and surface burners
To avoid possible burns DO NOT attempt the cleaning
instructions provided below before turning OFF the
surface burners and provide sufcient time for the
cooktop and all cooktop parts to cool.
To prevent are-ups and avoid creation of harmful
by-products, do not use the cooktop without all burner
caps properly installed to insure proper ignition and gas
ame size.
Always check for proper burner cap placement before
operating any surface burner.
Checking for proper burner cap placement
When placing burner caps, be sure that all burner caps
are seated rmly and rest level on top of burner heads.
On round style burners, the burner cap lip should t snug
into the center of burner head and rest level (Fig. 1).
Fig. 1
Burner cap lip
Burner cap
Fig. 2
Correct
Burner head
Refer to Figs. 2 & 3 for correct and incorrect burner cap
placement. Once in place, you may check the t by gently
sliding the burner cap from side to side (Fig. 4) to be sure
it is centered and rmly seated. When the burner cap lip
makes contact inside the center of the burner head you
will be able to hear the burner cap click. Please note that
the burner cap should NOT move off the center of the
burner head when sliding from side to side. Check and be
sure that all oval style (some models) burner caps are
correctly in place on oval burner heads.
Fig. 3
Incorrect
Fig.4
Checking for proper burner cap placement (cont’d)
Any additions, changes or conversions required in order
for this appliance to satisfactorily meet the application
needs must be made by an authorized qualied Agency.
CARE & CLEANING
IMPORTANT
IMPORTANT
36
CARE & CLEANING
Cleaning the cooktop and surface burners
To clean the burner head ignition ports
Each burner head has a small ignition port (Fig. 1). Should
you experience ignition problems it may be that this port
hole is partially blocked with soil. With the burner head in
place, use a small wire gauge needle or the end of a paper
clip to clear the ignition port (center burner not shown).
To avoid possible burns DO NOT attempt any of the
cleaning instructions provided below before turning OFF
all of the surface burners and allow them to cool.
Replacing interior oven light
To replace the interior oven light:
1. Turn electrical power off at the main source or unplug
the range.
2. While holding the glass shield in place, press wire
holder to one side to release the glass shield.
3. Remove glass shield. Replace bulb with a new 40 watt
appliance bulb.
4. Replace glass shield over bulb and snap wire holder
into place.
5. Turn power back on again at the main source (or plug
the range back in).
6. The clock will need to be reset. To reset review
“Setting the clock” section in this manual.
wire
holder
glass
shield
The interior oven light is
located at the rear of the
oven interior back wall
and is protected with a
glass shield held by a wire
holder.
The glass shield should
always be in place
to protect and shield
the oven interior light
whenever using the oven.
Be sure the range is unplugged and all parts are COOL
before replacing the oven light. Wear a leather-faced
glove for protection against possible broken glass.
Aluminum foil and oven liners
Using a liner in the
oven restricts the heat
and air ow needed to
obtain the best possible
cooking results for any
oven, including the
warmer drawer (on
some models).
Do not use oven bottom liners or use aluminum foil to
cover the oven bottom or any oven racks.
Fig. 1 - Cooktop burner head
NEVER cover any slots, holes or passages in
the oven bottom or cover an entire rack with
materials such as aluminum foil. Doing so blocks
air ow through the oven and may cause carbon
monoxide poisoning. Aluminum foil linings may
trap heat, causing a re hazard.
Aluminum foil and oven liners (cont’d)
During self-clean the oven temperature can become hot
enough to melt aluminum cooking utensils or aluminum
foil if left in the oven. This could result in damage to the
oven interior porcelain nish.
For proper gas ow it
may be necessary to
clean the burner head
and slots. To clean,
remove burner cap
and use a clean DAMP
cloth to soak up any
excessive spills.
Remove any food from
To clean the surface burner heads
• The burner heads are secured to the cooktop and
must be cleaned in place. DO NOT remove from
cooktop.
• For proper ow of gas and ignition of burners DO
NOT allow spills, food, cleaning agents or any
other material to enter the orice port opening.
between the burner slots using a small nonabrasive brush
like a toothbrush. Afterwards wipe up using a damp cloth.
For stubborn soils, use a small-gauge wire or needle to
clean.
After cleaning the burner heads or ignition ports, be sure
to replace the burner caps properly on the burner
heads. See section “Checking for proper burner cap
placement”.
IMPORTANT
slots
ignition port
orice port
37
Fig. 3
To remove oven door:
1. Open oven door (horizontal with oor - See Fig. 1).
2. Pull the door hinge locks on both left and right door
hinges down from the oven frame completely towards
the oven door to unlock (See Fig. 2). A tool such as a
small at-blade screwdriver may be required.
3. Close the door to the broil stop position. The oven door
will stop into this position just before fully closing.
4. Firmly grasp both sides of oven door along the door
sides (Do not use the oven door handle).
5. With the oven door in the broil stop position (Fig. 3), lift
the oven door hinge arms over the roller pins located
on each side of the oven frame (See Fig. 4). To avoid
damage to oven nish, be careful not to allow the oven
door hinges to contact the oven front frame.
Removing and replacing the lift-off oven door
Oven door hinge
locations
with oven door
fully open.
Fig. 1
Fig. 2
Fig. 4
roller
pin
hinge
arm
about
10°
hinge
oven
door
Read the following recommendations:
• DO NOT close the oven door until all the oven racks
are fully positioned inside the oven.
• Do not hit door glass with cookware or other objects.
• Scratching, hitting, jarring or stressing the glass may
weaken its structure causing an increased risk of
breakage at a later time.
Special door care instructions - Most oven doors
contain glass that can break.
To replace oven door:
1. Firmly grasp both sides of oven door along the door
sides (Do not use the oven door handle).
2. Holding the oven door at the same angle as the
removal position (See Fig. 3), seat the hook of the
hinge arm over the roller pins located on each side
of the oven door frame (See Fig. 4). The hook of the
hinge arms must be fully seated onto the roller pins.
3. Fully open the oven door (horizontal with oor - See
Fig. 1).
4. Push the door hinge locks up towards and into the
oven frame for both left and right oven door hinges to
the lock position (See Fig. 2).
5. Close the oven door.
To avoid possible injury when removing or replacing
the oven door, follow the instructions below carefully and
always handle the oven door with both hands positioned
away from the door hinge areas.
The door is heavy. For safe, temporary storage, lay the
door at with the inside of the door facing down.
CARE & CLEANING
IMPORTANT
38
BEFORE YOU CALL • Solutions to common problems
Problem Possible Causes Solutions
Display ashes time. Power interruption. Press cancel then set the correct time of day.
Oven control displays
F __ (followed with
a number) and oven
control beeps.
The oven control has detected
a fault or error condition.
Press cancel to clear the display & stop beeping. Try bake or
broil feature again. If the F code error repeats, remove electric
power from appliance, wait 5 minutes and then repower
appliance and set clock. Try bake or broil feature again.
Error condition recurs. Record fault code and call your authorized service agent.
The oven does not
respond or error
tone sounds when a
keypad is pressed.
Pressed outside keypad area. Be sure to press center of keypad using at portion of nger.
Oven lock may be active. Cancel the oven lock feature.
No electric service. See “Entire appliance does not operate” in this checklist.
New oven cooks
hotter or cooler than
previous experience.
Difference in oven temperature
settings between the old and
new range.
For the rst few uses, follow your recipe times and temperature
recommendation carefully. If you feel the oven is too hot or
cool from your previous cooking experience, try adjusting the
oven temperature. See “Adjusting the oven temperature” in
Setting Oven Controls section.
Odor or some
smoking coming from
the oven during rst
few uses.
New appliance. It is possible to experience some odors and/or a small amount
of smoke from a new range. The odor will diminish after rst
using the oven. Before cooking for the rst time, turn the oven
ON to 400°F for 30 minutes to one hour. This will allow for an
initial burn-in period and help eliminate odors. If necessary,
ventilate the kitchen by opening a window.
Appliance makes
popping sounds.
Oven expands and contracts
while heating and self-clean.
This is normal.
Control panel makes
clicking noises.
The oven control is cycling the
oven ON and OFF.
This is normal.
Warm air or steam
from oven vent area.
Moisture coming from food
while cooking in oven.
This is normal. To ensure the best possible results, do not
block the oven vent area when cooking.
Poor baking or
roasting results.
Incorrect oven control setting. See Setting Oven Controls section and review instructions
for the desired cooking function.
Oven vent may be blocked. Clear any cookware or items that is blocking the oven vent
area.
Incorrect cookware type or
size.
Dark or dull pans absorb more heat than shiny bakeware
resulting in overbrowning of some foods. Try reducing the oven
temperature or cook time to prevent overbrowning. Dark pans
are recommended for pies; shiny pans for cakes, cookies and
mufns.
Bake started with cold oven. Try preheating the oven before placing food on oven rack.
Incorrect oven rack position. Adjust oven rack position upward or downward as needed.
Inadequate space around food
items or air ow is blocked by
oven liner or using aluminum
foil as a liner.
Try centering food in oven for single items. When cooking
multiple food items space cookware to allow air to circulate
completely around the food items. Review “Aluminum foil and
liners” in the Care & Cleaning section.
Oven temperature or time
settings.
Try adjusting the recipe’s recommended temperature or
cooking time.
If you still feel the oven is too hot or cool, try
adjusting the oven temperature. See “Adjusting the oven
temperature” in Setting Oven Controls section.
39
Problem Possible Causes Solutions
Oven portion of
appliance does not
operate. Gas cooktop
burners operate.
Gas regulator shut-off valve
may have been moved to OFF
at installation.
Be sure gas regulator valve is set to the ON position. See
installation instructions.
Incorrect oven control setting. Be sure the oven control was set correctly for the requested
feature. See Setting Oven Controls section and review
instructions for the desired cooking function in this manual or
see “Entire appliance does not operate” in this checklist.
Entire appliance does
not operate.
Power supply to appliance
disconnected or electrical
power outage.
Be sure appliance power cord is plugged properly to electrical
outlet. Check house circuit breaker; reset if needed. If the
electric service to the house is out, call your local electric utility
for service.
Service wiring is incomplete. Contact your dealer, installing agent or authorized service
agent for assistance.
Range is not level. Floor is not level, weak or
unstable.
If oor under range is sagging or sloping, contact a carpenter
to correct the problem.
The cooktop or oven racks are
not level.
To correct, place oven rack in center of oven. Place a bubble
level centered on the oven rack. Adjust by turning leveling legs
at bottom of range until the oven rack rests level.
Cabinet alignment may make
range appear not level.
Be sure kitchen cabinets are square and have sufcient room
for appliance clearance.
Cannot move
appliance easily.
Appliance must
be accessible for
service.
Gas line is hard-plumbed. Replace gas supply line with a exible CSA International
approved metal appliance connector.
Carpet interferes with range. Provide sufcient space so appliance may be lifted over carpet.
Cabinets are built in too tightly
to appliance sides.
Contact builder or installer to make appliance accessible.
Convect fan makes
noise (some models).
The convect fan may turn ON
or OFF automatically.
This is normal. On some cooking features the convect fan may
run until the feature is done or the oven door is opened.
Convect fan does not
start immediately or
turns ON and OFF
while cooking (some
models).
The convect fan start time is
delayed.
This is normal. The convect fan will take 6 minutes to
begin rotating after starting any convect feature.
Oven door is open. The convect fan will turn OFF if the oven door is opened while
any convect feature is active. Close oven door.
Convect fan turns on
with features that
should run without a
fan (some models).
The convect fan may turn ON
while preheating.
This is normal (on some models).
Oven control displays
“Prob ERR”.
The probe is not
recognized by the
oven control.
The probe is not fully inserted
into the probe receptacle.
Double check that the temp probe is fully inserted into probe
receptacle. Use only the probe originally supplied with range.
If the error code persists, the
probe may be damaged or the
probe cable has a short.
Remove the probe from receptacle and oven. The oven may
still be used normally without the probe. Call your authorized
service agent.
Solutions to common problems
• BEFORE YOU CALL
40
BEFORE YOU CALL • Solutions to common problems
Problem Possible Causes Solutions
bake or self-clean
did not start at the
time expected.
The time of day is incorrect. Set clock with correct time of day before adding a delay start
setting. See “Setting the clock” in Setting Oven Controls
section.
Strong odor from
range or smells hot.
Self-clean was started for
the rst times or from a new
range.
It is normal for odors to occur during self-clean, especially
during the rst self-clean cycle. It is recommend to ventilate
the kitchen area. Open any windows and if available turn on
an exhaust fan or overhead range hood during the self-clean
cycle.
Unable to remove
items from oven after
starting self-clean.
Oven door locks immediately
after setting self-clean.
Press cancel to stop self-clean. Wait for the oven door to
unlock. Once unlocked, remove any items left in the oven,
close the oven door and set for self-clean again.
Oven door did not
unlock after the self-
clean cycle.
Oven is too hot. Allow about 1 hour after the self-clean cycle for the oven to
cool enough before the oven door will unlock.
Self-clean feature will
not start.
Incorrect control setting. Carefully follow the preparation and programming instructions
under Self-cleaning.
Oven door open. The oven door must lock before the self-clean cycle will start.
Be sure the oven door is closed before starting self-clean.
Self-clean will not
restart.
The control has determined
oven is still too hot to restart
self-clean (some models).
In some cases after cancelling self-clean, you may be required
to wait up to 4 hours before the self-clean feature may be used
again. Watch display for any messages.
Soil not completely
removed after self-
cleaning cycle.
Heavy soils. Clean time too
short or spillovers were left
inside oven.
Set self-clean feature for maximum cleaning time. Remove any
excessive spillovers from oven before starting self-clean.
Carefully follow preparation instructions under “Self-cleaning”.
Failure to clean soil from the
oven frame, the door liner
outside the oven door gasket
and the small area at the front
center of the oven bottom.
These areas are not within the self-cleaning area, but get hot
enough to burn on residue. Clean these areas before starting a
self-clean cycle. Burned-on residue may be cleaned with a stiff
nylon brush and water or a nylon scrubber. Be careful not to
damage the oven gasket.
Interrupted by power outage. Once power is restored restart self-clean.
Powdered ash inside
the oven cavity after
self-clean cycle.
This is normal. The
temperature of the self-clean
feature turned dirt to ash.
Wait for the oven to completely cool. Wipe away any residue
or powdered ash from the oven interior using a clean damp
cloth or paper towel.
Oven rack nish is
dull or discoloring.
Oven racks left inside oven
during self-clean.
Remove all racks from oven before starting self-clean. Clean
after removing from the oven using a mild, abrasive cleaner
following manufacturer’s instructions. Thoroughly rinse and dry.
Oven rack no longer
slides in or out of
oven easily.
Oven racks left inside oven
during self-clean.
Remove all racks from oven before starting self-clean. To ease
rack movement, remove from oven and clean if needed. Then
apply a small amount of vegetable oil to a paper towel and
wipe oil on edges of oven racks. Do not use lubricant sprays.
41
Solutions to common problems • BEFORE YOU CALL
Problem Possible Causes Solutions
Oven smokes
excessively when
broiling.
Oven door was left open. Be sure oven door is closed when broiling.
Meat too close to upper burner. Reposition oven rack lower to provide proper clearance
between the food & the upper burner.
Meat not prepared for broil. Remove excess fat from meat. Remove fatty edges.
Insert placed incorrectly on
broil pan (some models).
Always place insert on the broil pan with ribs up and slot holes
downward. This will allow grease to drip into pan.
Excessive spillovers or grease
built up inside oven.
Regular cleaning is needed when broiling frequently.
Flames inside oven
or smoking from
oven vent.
Excessive food spillovers in
oven.
Wipe up any excessive spillovers before starting the oven.
Should an oven re occur, close the oven door and turn the
oven OFF. If the re continues, use a re extinguisher. DO
NOT put water or our on the re! Flour may be explosive.
Surface burners will
not ignite.
Surface control knob not set to
the lite position.
Push in and turn the surface control knob to the lite position
until burner ignites; then turn knob out of the lite position and
adjust to desired ame size.
Burner caps are missing or not
seated properly.
Check that all surface burner caps are level and seated
correctly on surface burner heads. See “Cleaning the cooktop
and surface burners” in the Care & Cleaning section.
Burner ports are clogged. With all surface burners turned OFF, use a small-gauge wire or
needle to burner head slots and ignition ports. See “Cleaning
the cooktop and surface burners” in the Care & Cleaning
section for additional cleaning instructions.
Electric power outage. If needed, surface burners may be lit manually. See section on
Setting Surface Controls.
Power cord is disconnected. Plug power cord into the power outlet.
Surface burner ame
uneven or only part
way around burner
cap.
Burner caps are not seated
properly.
Check that all surface burner caps are level and seated
correctly on surface burner heads. See “Cleaning the cooktop
and surface burners” in the Care & Cleaning section.
Moisture may be present after
cleaning.
Lightly fan the ame & allow burner to operate until ame
is full. Dry the surface burners thoroughly following the
instructions under “Cleaning the cooktop and surface burners”
provided in the Care & Cleaning section.
Burner slots or ports are
clogged.
With all surface burners turned OFF, use a small-gauge wire or
needle to burner head slots and ignition ports. See “Cleaning
the cooktop and surface burners” in the Care & Cleaning
section for additional cleaning instructions.
Surface burner ame
is too high.
Surface knob is set too high. Adjust surface control knob to a lower ame setting.
Burner caps are not seated
properly.
Burner caps are not seated properly. Check that all surface
burner caps are level and seated correctly on surface burner
heads. See “Cleaning the cooktop and surface burners” in the
Care & Cleaning section.
Surface burner ame
is orange.
Dust particles in gas line. Allow burner to operate a few minutes until ame turns blue.
Residence near salt water. A slightly orange ame may be unavoidable from salt content in air.
This page is left blank intentionally
MAJOR APPLIANCE WARRANTY
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove
to be defective in materials or workmanship when such appliance is installed, used and maintained in
accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside the USA or
Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances
not in ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air lters, water lters, other consumables, or
knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damages to the nish of appliance or home incurred during installation, including but not limited to oors,
cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, res, or acts of God.
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR
OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT
BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED
WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period
should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Service under this warranty must be obtained by contacting Electrolux at the addresses or phone
numbers below.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances
North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp.
Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product features or specications as described
or illustrated are subject to change without notice.
If You Need
Service
USA
1.800.944.9044
Electrolux Home Products, Inc.
10200 David Taylor Drive
Charlotte, NC 28262
