Basic Owner’s Manual
Digital Camera
Model No. DC-TS7
Please read these instructions carefully before using this
product, and save this manual for future use.
More detailed owner's manual is available in “Owner’s Manual for
advanced features (PDF format)”. To read it, download it from the
website. (P64)
PPP
DVQX1500ZA
F0518HN0
Register online at http://shop.panasonic.com/support
(U.S. customers only)
If you have any questions, visit:
USA : http://shop.panasonic.com/support
Canada : www.panasonic.ca/english/support
until
2018/06/30
DC-FT7-TS7PPP-DVQX1500_eng.book 1 ページ ２０１８年５月１０日 木曜日 午後２時４０分
2
DVQX1500 (ENG)
Dear Customer,
Thank you for choosing Panasonic!
You have purchased one of the most sophisticated and reliable products on the
market today. Used properly, we’re sure it will bring you and your family years of
enjoyment. Please take time to fill in the information below. The serial number is on
the tag located on the underside of your camera. Be sure to retain this manual as
your convenient camera information source.
Please note that the actual controls and components, menu items, etc. of your
Digital Camera may look somewhat different from those shown in the illustrations in
this Owner’s Manual.
Carefully observe copyright laws.
• Recording of pre-recorded tapes or discs or other published or broadcast material for
purposes other than your own private use may infringe copyright laws. Even for the
purpose of private use, recording of certain material may be restricted.
For the U.S.A. and Canada only
A lithium ion battery that is recyclable powers the product
you have purchased. Please call 1-800-8-BATTERY for
information on how to recycle this battery.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
DC-FT7-TS7PPP-DVQX1500_eng.book 2 ページ ２０１８年５月１０日 木曜日 午後２時４０分
3
(ENG) DVQX1500
Information for Your Safety
∫ Product identification marking
WARNING:
To reduce the risk of fire, electric shock or product damage,
• Do not let water or other liquids drip or splash inside the unit.
• Do not expose accessories (battery pack, battery charger, AC adaptor, SD
memory card and etc.) to rain, moisture, dripping or splashing.
• Use the recommended accessories.
• Do not remove covers.
• Do not repair this unit by yourself. Refer servicing to qualified service
personnel.
The socket outlet shall be installed near the equipment and shall be easily
accessible.
Product Location
Digital camera Bottom
DC-FT7-TS7PPP-DVQX1500_eng.book 3 ページ ２０１８年５月１０日 木曜日 午後２時４０分
4
DVQX1500 (ENG)
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached installation
instructions and use only shielded interface cables with ferrite
core when connecting to computer or peripheral devices.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Declaration of Conformity
Trade Name: Panasonic
Model No.: DC-TS7
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Support Contact: http://shop.panasonic.com/support
DC-FT7-TS7PPP-DVQX1500_eng.book 4 ページ ２０１８年５月１０日 木曜日 午後２時４０分
5
(ENG) DVQX1500
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
Certification and Compliance
See Camera for the certification and compliance mark specific to that device.
1 Select
[Wi-Fi]
in the [Setup] menu
2 Select
[Wi-Fi Setup]
in the [Wi-Fi]
3
Press
3
/
4
to select [Approved Regulations], and press [MENU/SET]
Contains FCC ID: 2AAD3AA2G1J1
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
The available scientific evidence does not show that any health problems are
associated with using low power wireless devices. There is no proof, however,
that these low power wireless devices are absolutely safe. Low power Wireless
devices emit low levels of radio frequency energy (RF) in the microwave range
while being used. Whereas high levels of RF can produce health effects (by
heating tissue), exposure of low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF
exposures have not found any biological effects. Some studies have suggested
that some biological effects might occur, but such findings have not been
confirmed by additional research. DC-TS7 has been tested and found to
comply with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines.
DC-TS7
DC-FT7-TS7PPP-DVQX1500_eng.book 5 ページ ２０１８年５月１０日 木曜日 午後２時４０分
6
DVQX1500 (ENG)
THE FOLLOWING APPLIES ONLY IN CANADA.
Certification and Compliance
See Camera for the certification and compliance mark specific to that device.
1 Select
[Wi-Fi]
in the [Setup] menu
2 Select
[Wi-Fi Setup]
in the [Wi-Fi]
3
Press
3
/
4
to select [Approved Regulations], and press [MENU/SET]
CAN ICES-3(B)/NMB-3(B)
Contains IC : 10290A-AA2G1J1
This device complies with Industry Canada’s licence-exempt RSSs. Operation
is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the device.
The available scientific evidence does not show that any health problems are
associated with using low power wireless devices. There is no proof, however, that
these low power wireless devices are absolutely safe. Low power Wireless devices
emit low levels of radio frequency energy (RF) in the microwave range while being
used. Whereas high levels of RF can produce health effects (by heating tissue),
exposure of low-level RF that does not produce heating effects causes no known
adverse health effects. Many studies of low-level RF exposures have not found any
biological effects. Some studies have suggested that some biological effects might
occur, but such findings have not been confirmed by additional research. DC-TS7
has been tested and found to comply with IC radiation exposure limits set forth for
an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF)
Exposure rules.
DC-FT7-TS7PPP-DVQX1500_eng.book 6 ページ ２０１８年５月１０日 木曜日 午後２時４０分
7
(ENG) DVQX1500
∫ About the battery pack
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time
with doors and windows closed.
CAUTION
Battery pack (Lithium ion battery pack)
• Use the specified unit to recharge the battery pack.
• Do not use the battery pack with equipment other than the specified unit.
• Do not get dirt, sand, liquids, or other foreign matter on the terminals.
• Do not touch the plug terminals (i and j) with metal objects.
• Do not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes, wash it
off thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub the eyes.
Rinse eyes thoroughly with water, and then consult a doctor.
CAUTION
• Danger of explosion if battery is incorrectly replaced. Replace only with the type
recommended by the manufacturer.
• When disposing of the batteries, please contact your local authorities or dealer and
ask for the correct method of disposal.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC
(140 oF) or incinerate.
DC-FT7-TS7PPP-DVQX1500_eng.book 7 ページ ２０１８年５月１０日 木曜日 午後２時４０分
8
DVQX1500 (ENG)
∫ About the AC adaptor (supplied)
• Do not use any other USB connection cables except the supplied one.
• Use a “High Speed HDMI micro cable” with the HDMI logo.
Cables that do not comply with the HDMI standards will not work.
“High Speed HDMI micro cable” (Type D–Type A plug, up to 2 m (6.6 feet) long)
Keep this unit as far away as possible from electromagnetic equipment (such
as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise adversely
affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong magnetic
fields created by speakers or large motors.
• Electromagnetic wave radiation may adversely affect this unit, disturbing the pictures
and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops functioning
properly, turn this unit off and remove the battery or disconnect AC adaptor. Then
reinsert the battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures and/or
sound may be adversely affected.
CAUTION!
To reduce the risk of fire, electric shock or product damage,
• Do not install or place this unit in a bookcase, built-in cabinet or in another
confined space. Ensure this unit is well ventilated.
AC adaptor
This AC adaptor operates on AC between 110 V and 240 V.
But
• In the U.S.A. and Canada, the AC adaptor must be connected to a 120 V AC power
supply only.
• When connecting to an AC supply outside of the U.S.A. or Canada, use a plug
adaptor to suit the AC outlet configuration.
Cautions for Use
DC-FT7-TS7PPP-DVQX1500_eng.book 8 ページ ２０１８年５月１０日 木曜日 午後２時４０分
9
(ENG) DVQX1500
• Before cleaning the camera, remove the battery or disconnect the power plug
from the outlet.
• Do not press the monitor with excessive force.
• Do not press the lens with excessive force.
• Do not spray the camera with insecticides or volatile chemicals.
• Do not keep rubber or plastic products in contact with the camera for a long
period of time.
• Do not use solvents such as benzine, thinner, alcohol, kitchen detergents, etc., to
clean the camera, since it may deteriorate the external case or the coating may
peel off.
• Do not leave the camera with the lens facing the sun, as rays of light from the sun
may cause it to malfunction.
• Always use the supplied cords and cables.
• Do not extend the cords or the cables.
• During access (image writing, reading and deleting, formatting etc.), do not turn
this unit off, remove the battery, card or disconnect the AC adaptor. Furthermore,
do not subject the camera to vibration, impact or static electricity.
• The data on the card may be damaged or lost due to electromagnetic waves, static
electricity or breakdown of the camera or the card. We recommend storing important
data on a PC etc.
• Do not format the card on your PC or other equipment. Format it on the camera only to
ensure proper operation.
• The battery is not charged when the camera is shipped. Charge the battery before
use.
• The battery is a rechargeable lithium ion battery. If the temperature is too high or
too low, the operating time of the battery will become shorter.
• The battery becomes warm after using and during and after charging. The camera also
becomes warm during use. This is not a malfunction.
• Do not leave any metal items (such as clips) near the contact areas of the power
plug or near the batteries.
• Store the battery in a cool and dry place with a relatively stable temperature:
(Recommended temperature: 15 oC to 25 oC (59 oF to 77 oF), Recommended
humidity: 40%RH to 60%RH)
• Do not store the battery for a long time while fully charged. When storing the
battery for a long period of time, we recommend charging it once a year. Remove the
battery from the camera and store it again after it has completely discharged.
DC-FT7-TS7PPP-DVQX1500_eng.book 9 ページ ２０１８年５月１０日 木曜日 午後２時４０分
10
DVQX1500 (ENG)
Contents
Information for Your Safety ....................3
Preparation/Basic
Care of the camera..............................11
Standard Accessories ..........................13
About cards that can be used with this
unit.......................................................14
(Important) About the Waterproof/
Dustproof and Anti-shock Performance
of the Camera......................................15
Names and Functions of
Components ........................................21
Preparations before Recording............23
Basic Operations .................................27
Setting menu items..............................33
Assigning frequently used functions to
the buttons (function buttons) ..............34
Using the Compass and Altimeter .......34
Recording
Taking Pictures using the Automatic
Function (Intelligent Auto Mode)..........36
Recording 4K Photos...........................37
Controlling Focus After Recording
(Post Focus) ........................................40
Recording Motion Picture/4K Motion
Picture..................................................42
Playback
Playing Back Pictures ......................... 45
Menu
Menu list ............................................. 46
Wi-Fi
What you can do with the Wi-Fi
®
function ............................................... 48
Controlling with a
Smartphone/Tablet.............................. 49
Others
Monitor Display/Viewfinder Display..... 54
Troubleshooting .................................. 56
Specifications...................................... 59
Reading the Owner's Manual
(PDF format) ....................................... 64
Limited Warranty
(ONLY FOR U.S.A.) ............................ 65
Limited Warranty
(ONLY FOR CANADA) ....................... 69
DC-FT7-TS7PPP-DVQX1500_eng.book 10 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
11
(ENG) DVQX1500
Care of the camera
• Do not apply strong shock or vibration by dropping or knocking the camera. Also,
do not apply strong pressure to the camera.
– Waterproof performance may be impaired.
– The lens or the monitor may get damaged.
If the monitor should get damaged, take care to avoid injury caused by the fragments
of broken glass and other damaged components.
– It may cause malfunction in the performance or the function.
• After the camera is used underwater, speaker and microphone performance may
be temporarily degraded, so motion pictures may be recorded or played back with
weak audio.
– After underwater use, perform steps
1 through 4 in “Caring of the camera after using
it underwater” on P19.
∫ When inner side of the viewfinder or monitor is fogged (condensation)
It is not a malfunction or failure of the camera. It may be caused by the
environment in which the camera is used.
What to do when inner side is fogged
• Turn off the camera and open the side door in a place with constant ambient
temperature, away from high temperatures, humidity, sand and dust. The fog will
disappear naturally in approximately 2 hours with the side door open when the
temperature of the camera gets close to the ambient temperature.
• Contact Panasonic if the fogging does not disappear.
Conditions in which inner side may be fogged
Condensation may occur and cause the inner side of the lens, viewfinder, and
monitor to fog up when the camera is used under conditions with drastic
temperature changes or high humidity levels, such as the following:
• When the camera is used underwater suddenly after being on a hot beach etc.
• When the camera is moved to a warm area from a cold area, such as at a ski
resort or at high altitude
• When the side door is opened in a high-humidity environment
Please be sure to read “(Important) About the Waterproof/Dustproof and
Anti-shock Performance of the Camera” (P15) before using this unit underwater
to prevent the unit from being mishandled, which may cause water to seep in.
If you shake the camera while it is turned off, a rattling sound will be heard. This
is the sound of the lens moving and not a malfunction.
DC-FT7-TS7PPP-DVQX1500_eng.book 11 ページ ２０１８年５月１０日 木曜日 午後２時４０分
12
DVQX1500 (ENG)
Preparation/Basic
∫ When using in a cold climate or at low temperatures
• The performance of the battery (number of recordable pictures/operating time) may
decrease temporarily when using in a temperature between j10 oC and 0 oC (14 oF and
32 oF) (cold places such as ski resorts or places at high altitude). (Charge the battery
sufficiently before use)
• The battery cannot be recharged in a temperature less than 0 oC (32 oF). (The charging
lamp blinks when the battery cannot be recharged.) Charge it sufficiently in a location
where the ambient temperature is between 10 oC and 30 oC (50 oF and 86 oF).
• When using the camera in cold places such as ski resorts or places at high altitude, do
not leave the camera with snow or water droplets sticking to it. Some parts of the
camera may become hard to move or the sound may become dim with snow or water
droplets freezing in narrow spaces, such as the gaps of the buttons, dial, speaker, and
microphone. This is not a malfunction.
• When the camera is used at cold temperatures, speaker and microphone
performance may be temporarily degraded, so motion pictures may be recorded
or played back with weak audio.
– Keep the camera warm by placing it in a warm place such as inside your cold
protection gear or clothes during use.
• The screens used in this owner's manual are examples provided to describe operations.
• The product design and specifications described in this owner's manual may differ from
the actual product due to improvements.
∫ About the symbols in the text
Applicable modes:
In Recording Modes shown as black icons, you can select and use indicated menu
items and functions.
How to use this manual
: Indicates that the menu can be set by pressing [MENU/SET] button.
: Tips for skillful use and points for recording.
In this owner's manual, steps for setting a menu item are described as follows.
> [Rec] > [Quality] > [›]
MENU
MENU
DC-FT7-TS7PPP-DVQX1500_eng.book 12 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
13
(ENG) DVQX1500
Standard Accessories
Check that all the accessories are supplied before using the camera.
Product numbers correct as of May 2018. These may be subject to change.
• Supplied accessories such as battery pack etc.
are not waterproof. (excluding hand strap)
• SD Memory Card, SDHC Memory Card and SDXC Memory Card are indicated as card
in the text.
• The card is optional.
(For U.S.A. only)
• If accessories are lost, customers can visit us at http://shop.panasonic.com/support for
further information about obtaining replacement parts.
(For Canada only)
• If any accessories are lost, customers in Canada should visit our support page at
www.panasonic.ca/english/support
for further information about obtaining replacement
parts.
∫ Digital Camera Accessory
• Some optional accessories may not be available in some countries.
(For U.S.A. only)
• To order optional accessories please visit http://shop.panasonic.com or your local Photo
Specialty Dealer.
1
Battery Pack
(Indicated as battery pack or battery in the
text)
• Charge the battery before use.
2
AC Adaptor
• This is used for charging.
3 USB Connection Cable
4 Hand Strap
Battery Pack DMW-BCM13
13
24
DMW-BCM13PP K1HY04YY0106
DVPW1015ZSAE0012A
DC-FT7-TS7PPP-DVQX1500_eng.book 13 ページ ２０１８年５月１０日 木曜日 午後２時４０分
14
DVQX1500 (ENG)
Preparation/Basic
About cards that can be used with this
unit
∫ About motion picture/4K photo recording and speed class ratings
Use a card that meets the following ratings of the SD Speed Class or UHS Speed
Class.
• SD Speed Class and UHS Speed Class are the speed standards regarding continuous
writing. To check the class, see the labeled side, etc. of the card.
• Please confirm the latest information on the following website.
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
• Keep the memory card out of reach of children to prevent swallowing.
SD Memory Card
(512 MB to 2 GB)
• This unit is compatible with UHS-I UHS Speed Class 3
standard SDHC/SDXC memory cards.
• Operation of the cards on the left has been confirmed
with Panasonic’s cards.
SDHC Memory Card
(4 GB to 32 GB)
SDXC Memory Card
(48 GB to 128 GB)
Size in [Rec Quality] Speed class Label example
4K UHS Speed Class 3
FHD/HD Class 4 or higher
When recording in 4K Photo/
[Post Focus]
UHS Speed Class 3
DC-FT7-TS7PPP-DVQX1500_eng.book 14 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
15
(ENG) DVQX1500
(Important) About the Waterproof/
Dustproof and Anti-shock Performance
of the Camera
This does not guarantee no destruction, no malfunction, or waterproofing in
all conditions.
¢1 This means that the camera can be used underwater for specified time in specified
pressure in accordance with the handling method established by Panasonic.
¢2 “MIL-STD 810F Method 516.5-Shock” is the test method standard of the U.S.
Defense Department, which specifies performing drop tests from a height of 122 cm
(4 feet), at 26 orientations (8 corners, 12 ridges, 6 faces) using 5 sets of devices, and
passing the 26 orientation drops within 5 devices. (If failure occurs during the test, a
new set is used to pass the drop orientation test within a total of 5 devices)
Panasonic’s test method is based on the above “MIL-STD 810F Method
516.5-Shock”. However, the drop height was changed from 122 cm (4 feet) to
200 cm (6.6 feet) dropping onto 3 cm (0.1 feet) thick plyboard. This drop test was
passed.
(Disregarding appearance change such as loss of paint or distortion of the part where
drop impact is applied.)
¢3 According to the test conditions specified by Panasonic.
Waterproof/Dustproof Performance
This camera’s waterproof/dustproof rating complies with the “IPX8” and
“IP6X” ratings. Provided the care and maintenance guidelines described
in this document are strictly followed, this camera can operate
underwater, to a depth not exceeding 31 m (102 feet) for a time not
exceeding 60 minutes. (¢1)
Anti-shock Performance
This camera also complies with “MIL-STD 810F Method 516.5-Shock”.
The camera has cleared a drop test from a height of 2 m (6.6 feet) onto
3 cm (0.1 feet) thick plywood. In most cases this camera should not
sustain any damage if dropped from a height not exceeding 2 m
(6.6 feet). (¢2)
Withstand Load Performance
This camera complies with 100 kgf / 220.5 lbf load tests. (¢3)
DC-FT7-TS7PPP-DVQX1500_eng.book 15 ページ ２０１８年５月１０日 木曜日 午後２時４０分
16
DVQX1500 (ENG)
Preparation/Basic
∫ Handling of the camera
• Waterproofing is not guaranteed if the unit is subject to an impact as a result of being hit
or dropped etc. If an impact to the camera occurs, it should be inspected (subject to a
fee) by a Panasonic to verify that the waterproofing is still effective.
• When the camera is splashed with detergent, soap, hot spring, bath additive, sun oil,
sun screen, chemical, etc., wipe it off immediately.
• Waterproof function of the camera is for sea water and fresh water only.
• Any malfunction caused by customer misuse, or mishandling will not be covered by the
warranty.
• Panasonic offers no compensation for any accidents caused by use of the product
(including both personal and property damage).
• The inside of this unit is not waterproof. Water leakage will cause malfunction.
• Supplied accessories such as battery pack etc. are not waterproof.
(excluding hand strap)
• Card and battery are not waterproof. Do not handle with a wet hand. Also, do not insert
wet card or battery into the camera.
• Do not leave the camera for a long period of time in cold places where the temperature
reaches s10 oC (14 oF) or lower (ski resorts, places at high altitude, etc.) or hot places
where the temperature reaches 40 oC (104 oF) or higher (in particular, places exposed to
strong sunlight, inside a sun-heated automobile, near a heater, on a boat or beach,
etc.). (Doing so will deteriorate the waterproof performance)
∫ About the [Precautions] display
• [Precautions] is displayed when the power is turned on for the first time after purchase,
with the side door completely closed.
• Please check beforehand to maintain the waterproof performance.
1 Press 2 to select [Yes], and press [MENU/SET].
2 Press 2/1 to select the picture.
• It can be forcefully ended by pressing [MENU/SET].
• When it is forcefully ended while checking by turning the unit off or pressing
[MENU/SET], [Precautions] is displayed every time the power is turned on.
2: Return to the previous screen
1: View the next screen
DC-FT7-TS7PPP-DVQX1500_eng.book 16 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
17
(ENG) DVQX1500
3 After the final screen (12/12), press [MENU/SET] to finish.
• When [MENU/SET] is pressed after the final screen (12/12), [Precautions] is not
displayed from the next time the power is turned on.
• This can also be viewed from [Precautions] in the [Setup] menu.
1 Check that there are no foreign objects on the inner side of the side
door.
• If there is any foreign object, such as lint, hair, sand, etc., on the surrounding area,
water will leak within a few seconds, causing malfunction.
• Wipe it off with a soft, dry cloth if there is any liquid.
It may cause water leaks and malfunction if you use the camera with liquid
adhered.
• If foreign objects are present, wipe them off with a dry, lint-free cloth.
• Be extremely careful to remove the small sand etc. that may adhere to the sides
and corners of the rubber seal.
2 Check for cracks and deformation of the rubber seal on the side door.
• The integrity of the rubber seals may decrease after about 1 year, with use and
age. To avoid permanently damaging the camera, the seals should be replaced
once each year. Please contact Panasonic for related costs and other information.
Check before using underwater
Always wipe the rubber seal on the side door and the area where rubber
seal sits with a dry, lint-free cloth.
DC-FT7-TS7PPP-DVQX1500_eng.book 17 ページ ２０１８年５月１０日 木曜日 午後２時４０分
18
DVQX1500 (ENG)
Preparation/Basic
3 Close the side door securely.
A Red part
B [LOCK] switch
C Released state
D Locked state
• Lock the [LOCK] switch securely until
the red part is no longer visible.
• To prevent water intrusion, be careful
not to catch foreign objects such as
liquids, sand, hair, dust, or the strap
cord.
• Use the camera underwater to 31 m (102 feet) with the water temperature between 0 oC
and 40 oC (32 oF and 104 oF).
• Do not use the camera at a depth of over 31 m (102 feet).
• Do not use it in the hot water over 40 oC (104 oF) (in the bath or hot spring).
• Do not use the camera underwater longer than 60 minutes continuously.
• Do not open or close the side door underwater.
• Do not apply shock to the camera underwater. (Waterproof performance may not be
maintained, and there is a chance of water leak.)
• Do not dive into the water holding the camera. Do not use the camera in a location
where the water will splash strongly, such as rapid flow or waterfall. It may cause
malfunction.
• The camera will sink in the water. Take care not to drop the camera and lose it
underwater by securely placing the strap around your wrist or similar measure.
Do not open or close the side door in places with sand and dust, close to
water, or with wet hands. Sand or dust adhering may cause water leaks.
Using the camera underwater
DC-FT7-TS7PPP-DVQX1500_eng.book 18 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
19
(ENG) DVQX1500
1 Rinse with fresh water with the side door closed.
• After use at the seaside or underwater, soak the unit in
fresh water pooled in a shallow container for 10 minutes
or less.
• Do not use chemicals such as benzine, thinner, alcohol
or cleanser, soap or detergents.
• If the diopter adjustment dial, shutter button, the camera
[ON/OFF] button or other parts are not moving smoothly,
there may be trapped foreign objects. As continued use
may cause these parts to get stuck or cause other
malfunctions, shake the camera in fresh water to wash off any foreign objects.
After that, check that the parts of the camera are moving smoothly.
• Bubbles may come out of the drainage hole when you immerse the camera in
water, but this is not a malfunction.
Caring of the camera after using it underwater
Do not open or close the side door until the sand and dust is removed by
rinsing the camera with water.
Make sure to clean the camera after using it.
• Thoroughly wipe off any water droplets, sand, and saline matter on your hands, body,
hair, etc.
• It is recommended to clean the camera indoors, avoiding places where water spray
or sand may fall.
After using it underwater, always clean the camera rather than leaving it in
a dirty state.
• Leaving the camera with foreign objects or saline matter on it may cause damage,
discoloration, corrosion, unusual odour, or deterioration of the waterproof
performance.
DC-FT7-TS7PPP-DVQX1500_eng.book 19 ページ ２０１８年５月１０日 木曜日 午後２時４０分
20
DVQX1500 (ENG)
Preparation/Basic
2 Tap the camera lightly against your palm while holding it upside down
and then with the illustrated side facing down, and then wipe off the
water droplets with a soft, dry cloth.
• Repeat this step a few times if water is left in the microphone A or speaker B
hole.
If water is left in the microphone or speaker hole, weak or distorted audio may be
recorded and played back.
• Fasten the strap firmly to your wrist to avoid dropping the camera.
3 Dry the camera by standing it on a
dry cloth in a well ventilated shaded
area.
• This unit incorporates drain design,
draining water in gaps in the camera
[ON/OFF] button and zoom button etc.
• Do not dry the camera with hot air from
dryer or similar. Waterproof performance
will deteriorate due to deformation.
4 Confirm that there are no water droplets, open the side door, and wipe
off any water droplets or sand left inside using a soft, dry cloth.
• Water droplets may adhere to the card or battery when the side door is opened
without thoroughly drying. Also, water may accumulate in the gap around the
card/battery slot or the terminal connector. Be sure to wipe any water off with a
soft, dry cloth.
• The water droplets may seep into the camera when the side door is closed while it
is still wet, causing condensation or failure.
DC-FT7-TS7PPP-DVQX1500_eng.book 20 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
21
(ENG) DVQX1500
Names and Functions of Components
1
9
14
15
16
2 3 4 5 5 76
10
11
12
13
8
1
Camera [ON/OFF] button (P26)
2
Motion picture button (P42)
3
Shutter button (P29)
4
Flash
5
Stereo microphone
• Be careful not to cover the microphone
with your finger. Doing so may make
sound difficult to record.
6
Self-timer indicator/AF Assist Lamp/LED
light
7
Lens surface
8
Speaker
9
Side door (P17, 23)
10 [USB/CHARGE] socket (P24)
11
Card slot (P23)
12 [HDMI] socket
13
Battery slot (P23)
14
[LOCK] switch (P18, 23)
15 Release lever (P23)
16
Strap eyelet
• Be sure to attach the strap when using
the camera to ensure that you will not
drop it.
• After placing the strap around your
wrist, slide the adjuster A to fasten the
strap.
• Be sure to attach the strap to the strap
eyelet.
DC-FT7-TS7PPP-DVQX1500_eng.book 21 ページ ２０１８年５月１０日 木曜日 午後２時４０分
22
DVQX1500 (ENG)
Preparation/Basic
18 19 212017
31 2728
23
24
26
25
22
30
29
31 3132
17 Monitor (P54)
18
[ ] (Post Focus) button (P40)/[Fn2]
button (P34)
19
[LVF] button (P27)
20
Viewfinder (P27, 54)
21
Diopter adjustment dial
• Adjust until you can see the characters
displayed in the viewfinder clearly.
22
Zoom button (P28)
23
[(] (Playback) button (P45)
24
[DISP.] button
• Each time this is pressed, the display
on the monitor is switched.
25
Cursor buttons (P30)
26 [MENU/SET] button (P30)
27
Charging lamp (P25)/
Wi-Fi
®
connection lamp (P48)
28
[ ] (Delete) button (P45)/[ ]
(Cancel) button/[Q.MENU] button
29
[ ] (4K Photo Mode) button (P37)/
[Fn1] button (P34)
30
[MODE] button (P31)
31 Drainage hole
32
Tripod mount
• It may not be possible to attach and
securely fasten a tripod with a screw
length of 5.5 mm (0.22 inch) or more
to the camera. Doing so may also
damage the camera.
DC-FT7-TS7PPP-DVQX1500_eng.book 22 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
23
(ENG) DVQX1500
Preparations before Recording
• Check that this unit is turned off.
1 1: Slide the [LOCK] switch A, and release
the lock.
2: Slide the release lever B and open the
side door.
• Always use genuine Panasonic batteries
(DMW-BCM13PP).
• If you use other batteries, we cannot
guarantee the quality of this product.
2 Battery: Being careful about the battery
orientation, insert all the way until you hear a
locking sound and then check that it is
locked by lever C. Pull the lever C in the
direction of the arrow to remove the battery.
Card: Push it securely all the way until you
hear a “click” while being careful about the
direction in which you insert it. To remove
the card, push the card until it clicks, then
pull the card out upright.
D: Do not touch the connection terminals of the
card.
Check the orientation of the card.
3 Close the side door until it clicks, and then
lock the [LOCK] switch by sliding it toward
[2].
• Confirm that the red part E on the [LOCK] switch
is not showing.
Inserting and Removing the Card (optional)/the Battery
DC-FT7-TS7PPP-DVQX1500_eng.book 23 ページ ２０１８年５月１０日 木曜日 午後２時４０分
24
DVQX1500 (ENG)
Preparation/Basic
The battery that can be used with this unit is DMW-BCM13PP.
• Charge the battery in areas with an ambient temperature, between 10 oC and 30 oC
(50 oF and 86 oF) (same as the battery temperature), is recommended.
Connect the camera and the AC adaptor (supplied) B or a PC D.
• The AC adaptor (supplied) and USB connection cable (supplied) are for this camera
only. Do not use them with other devices.
• Do not use any other USB connection cables except the supplied one.
• Do not use any other AC adaptors except the supplied one.
Charging the Battery
Insert the battery into this unit.
Check that this unit is turned off.
[USB/CHARGE] socket
• Place the camera in an upright position, and find the
terminal at the bottom.
• Check the direction of the terminals and plug in/out
straight holding onto the plug.
(It may result in malfunction by the deforming of the
terminal if it is plugged in obliquely or in wrong direction.)
Do not connect devices to incorrect terminals. Doing so
may cause malfunction.
A Charging lamp
B AC adaptor (supplied)
C To power outlet
D PC (Turned on)
E USB connection cable
(supplied)
DC-FT7-TS7PPP-DVQX1500_eng.book 24 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
25
(ENG) DVQX1500
∫ Charging from the power outlet
Connect the AC adaptor (supplied) and this camera with the USB connection
cable (supplied), and insert the AC adaptor (supplied) into the power outlet.
∫ Charging from a computer
Connect the computer and this camera with the USB connection cable
(supplied).
∫ About the charging lamp
∫ Charging time
When using the AC adaptor (supplied)
• The indicated charging time is for when the battery has been discharged
completely.
The charging time may vary depending on how the battery has been used.
The charging time for the battery in hot/cold environments or a battery that has
not been used for a long time may be longer than normal.
• When power is supplied from a computer, the power supply capacity of the computer
determines the charging time.
Lit: Charging.
Off: Charging has completed.
(When charging is complete, disconnect the camera from the
power outlet or computer.)
• When the charging lamp flashes
– Reconnect the USB connection cable (supplied) in a location where the ambient
temperature (and the temperature of battery) is in a 10 oC to 30 oC (50 oF to 86 oF)
range, and try charging again.
– If your PC is not capable of supplying sufficient power, charging is not possible.
Charging time Approx. 170 min
DC-FT7-TS7PPP-DVQX1500_eng.book 25 ページ ２０１８年５月１０日 木曜日 午後２時４０分
26
DVQX1500 (ENG)
Preparation/Basic
• The clock is not set when the camera is shipped.
1 Press camera [ON/OFF] button.
2 Press [MENU/SET].
3 Press 3/4 to select the language, and press
[MENU/SET].
4 Press [MENU/SET].
5 Press 2/1 to select the items (year, month,
day, hour, minute), and press 3/4 to set.
6 Press [MENU/SET] to set.
7 When [The clock setting has been completed.] is
displayed, press [MENU/SET].
8 When [Please set the home area] is displayed,
press [MENU/SET].
9 Press 2/1 to select the home area, and then
press [MENU/SET].
• [Precautions] will be displayed. (P16)
Format the card before recording a picture with this unit.
After formatting, all data stored on the card will be deleted and cannot be
recovered. Back up necessary data on a PC or similar device first, and then
format the card.
Setting Date/Time (Clock Set)
Formatting the card (initialization)
> [Setup] > [Format]
&ORFN6HW
'(&
6W\OH
$0
6HW
*07
7RURQWR
1HZ<RUN
0LDPL
/LPD
6HW
MENU
DC-FT7-TS7PPP-DVQX1500_eng.book 26 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
27
(ENG) DVQX1500
Basic Operations
Hold the camera gently with both hands, keep your arms still at your side and
stand with your feet slightly apart.
• Before using the camera, be sure to attach the supplied strap and fasten it to your
wrist to avoid dropping the camera. (P21)
• Be careful not to put your fingers on the flash, AF assist lamp/LED light A,
microphone B, speaker C or lens etc.
• Make sure your footing is stable and there is no danger of colliding with another person
or object in the vicinity while taking pictures.
Press [LVF] to switch between the Monitor and
Viewfinder.
Press [LVF].
Tips for taking good pictures
[LVF] button (Switching the Monitor/Viewfinder)
DC-FT7-TS7PPP-DVQX1500_eng.book 27 ページ ２０１８年５月１０日 木曜日 午後２時４０分
28
DVQX1500 (ENG)
Preparation/Basic
You can zoom in to make people and objects appear closer or zoom out to record
landscapes in wide angle.
Zooms in without deteriorating the image quality.
Maximum magnification: 4.6k
This function works when any of the picture sizes indicated with is selected.
You can zoom in further than you can with the Optical Zoom without deteriorating
the image quality.
Maximum magnification: 9k
(This includes the optical zoom magnification. The magnification level differs
depending on [Picture Size] setting.)
You can zoom in up to twice the original zoom magnification while minimizing the
deterioration of the image quality.
Although the image quality deteriorates every time you zoom in further, you can
zoom in up to four times the original zoom magnification.
Zoom button (zoom operations)
[W]: To make subjects appear further away use (Wide)
[T]: To make subjects appear closer use (Tele)
Optical Zoom
Extended Optical Zoom
Intelligent Zoom
> [Rec]/ [Motion Picture] > [i.Zoom] > [ON]/[OFF]
[Digital Zoom]
> [Rec]/ [Motion Picture] > [Digital Zoom] > [ON]/[OFF]
MENU
MENU
DC-FT7-TS7PPP-DVQX1500_eng.book 28 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
29
(ENG) DVQX1500
1 Press the shutter button halfway to focus.
• Aperture value and shutter speed are displayed.
• Once the subject is in focus, the focus indication is
displayed. (When the subject is not in focus, the
indication flashes.)
A Aperture value
B Shutter speed
C Focus indication
2 Press the shutter button fully (push it in
further), and take the picture.
• Be careful not to move the camera when you
press the shutter button.
∫ Check the picture you have taken
Press [(] to display the recorded image. (P45)
Shutter button (Taking pictures)
DC-FT7-TS7PPP-DVQX1500_eng.book 29 ページ ２０１８年５月１０日 木曜日 午後２時４０分
30
DVQX1500 (ENG)
Preparation/Basic
Pressing the cursor button:
Selection of items or setting of values etc., is performed.
• This owner's manual expresses the up, down, left, and right of the
cursor button as 3/4/2/1.
Pressing [MENU/SET]:
Confirmation of setting contents, etc., is performed.
∫ Pressing the cursor button while recording
3/[È] (Exposure Compensation)
Use this function when you cannot achieve appropriate exposure due to the
difference in brightness between the subject and the background.
1/[‰] (Flash Mode)
Set the flash to match the recording.
• If you set the [LED Light] to [ON], and press and hold down 1 on the recording standby
screen, the LED light will come on for 60 seconds.
2/[#] (Macro Mode)
• [ ]([AF Macro])
– You can take pictures of a subject as close as 5 cm (0.16 feet) from the lens by
pressing the zoom button upmost to Wide (1k).
• [ ]([Macro Zoom])
– Use this setting to get close to the subject and then further enlarge when taking the
picture.
You can take a picture with the Digital Zoom up to 3k while maintaining the distance
to the subject for the extreme Wide position (5 cm (0.16 feet)).
4/[ ] (Drive Mode)
You can change what the camera will do when you press the shutter button.
• [Single]/[Burst]/[4K PHOTO] (P37)/[Post Focus] (P40)/[Auto Bracket]/[Self Timer]
Cursor buttons/[MENU/SET] button
DC-FT7-TS7PPP-DVQX1500_eng.book 30 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
31
(ENG) DVQX1500
1 Press [MODE].
2 Press 3/4/2/1 to select the Recording Mode.
3 Press [MENU/SET].
[MODE] button (Selecting a Recording Mode)
DC-FT7-TS7PPP-DVQX1500_eng.book 31 ページ ２０１８年５月１０日 木曜日 午後２時４０分
32
DVQX1500 (ENG)
Preparation/Basic
Intelligent Auto Mode (P36)
Program AE Mode
Records at the aperture value and shutter speed set by the camera.
Manual Exposure Mode
The exposure is adjusted by the aperture value and the shutter speed which
are manually adjusted.
Creative Control Mode
Record while checking the image effect.
Scene Guide Mode
This mode allows you to take pictures that match the scene being recorded.
Sports Mode
Use this mode to take pictures of sporting events, etc.
Snow Mode
This allows you to take pictures that show the snow as white as possible at a
ski resort or a snow-covered mountain.
Beach & Surf Mode
This is optimal for recording images underwater at a depth of up to 3 m
(9.8 feet) and at the beach.
Underwater Mode
This is optimal for recording images underwater at a depth exceeding 3 m
(9.8 feet).
Panorama Shot Mode
This mode allows you to take panorama pictures.
DC-FT7-TS7PPP-DVQX1500_eng.book 32 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
33
(ENG) DVQX1500
Setting menu items
1
Press [MENU/SET].
2
Press 2.
3
Press 3/4 to select a menu selector
icon, such as [ ].
4
Press [MENU/SET].
5
Press 3/4 of the cursor button to
select the menu item and press [MENU/
SET].
6
Press 3/4 of the cursor button to
select the setting and press [MENU/
SET].
• Depending on the menu item, its setting may not appear or it may be displayed
in a different way.
∫ Close the menu
Press [ ] or press the shutter button halfway.
[Rec] (P46)
[Motion Picture] (P46)
[Custom] (P47)
[Setup] (P47)
[Playback] (P47)
3KRWR6W\OH
$VSHFW5DWLR
$872
3LFWXUH6L]H
67'
4XDOLW\
6HQVLWLYLW\
0
/
6HWFRPSUHVVLRQOHYHORISLFW
3KRWR6W\OH
$VSHFW5DWLR
$872
3LFWXUH6L]H
67'
4XDOLW\
6HQVLWLYLW\
0
/
,QFUHDVHWKHQXPEHURIUHFR
U
DC-FT7-TS7PPP-DVQX1500_eng.book 33 ページ ２０１８年５月１０日 木曜日 午後２時４０分
34
DVQX1500 (ENG)
Preparation/Basic
Assigning frequently used functions to
the buttons (function buttons)
You can assign recording functions, etc. to specific buttons.
1
Select the menu.
2
Press 3/4 to select the function
button you want to assign a function to
and then press [MENU/SET].
3
Press 3/4 to select the function you
want to assign and then press [MENU/
SET].
• If you press and hold a function button (any of [Fn1] to [Fn2]) for 2 seconds, the screen
displayed in step
3 can be displayed. In some cases, however, the screen cannot be
displayed depending on the currently selected mode or the currently displayed screen.
Using the Compass and Altimeter
Applicable modes:
• Information measured on this unit is only a rough indication. Do not use it for
technical purposes.
• When using this unit for full-scale mountain climbing, trekking, use the measured
information (direction, altitude) only as a rough indication, and always carry a
map and purpose-built measurement tools.
∫ Activate the sensors
The direction and altitude can be measured and recorded in the recorded images.
> [Custom] > [Fn Button Set] > [Setting in REC
mode]/[Setting in PLAY mode]
> [Setup] > [Sensor Settings] > [ON]
MENU
)Q
)Q
MENU
DC-FT7-TS7PPP-DVQX1500_eng.book 34 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Preparation/Basic
35
(ENG) DVQX1500
∫ Display the compass and altimeter
The current bearing and altitude are displayed during recording, while the bearing
and altitude at the time of recording are displayed during playback.
To switch the environment information screen, press [DISP.] several times.
E North
A Altimeter
You can check the altitude of the current location.
Altimeter is not adjusted at the time of purchase.
• Displaying range is j500 m (j1640 feet) to 9000 m (29530 feet).
• The displayed altitude is a relative altitude. The altitude is a value calculated by
converting an atmospheric pressure within the unit to an altitude with 0 m (0 feet) (sea
level) u 1013 hPa as a reference.
• Altitude value may show errors depending on the change in atmospheric pressure
compared to areas such as locations with altimeter reference signs. Adjust frequently
with [Altimeter Adjust].
• For details, refer to the “Owner’s Manual for advanced features (PDF format)”.
B Compass
• 16 bearings are displayed based on the direction the lens of the camera is pointing in.
• The colored portion of the needle points north.
C Location information (only during playback)
• Location information added from the smartphone is displayed. (P53)
D Recording date (only during playback)
IW
1
(
'(&
1
DC-FT7-TS7PPP-DVQX1500_eng.book 35 ページ ２０１８年５月１０日 木曜日 午後２時４０分
36
DVQX1500 (ENG)
Recording
Taking Pictures using the Automatic
Function (Intelligent Auto Mode)
Recording Mode:
In this mode, the camera makes the optimal settings for the subject and scene, so
we recommend it when you wish to leave the settings to the camera and record
without thinking about them.
1
Press [MODE].
2
Press 3/4/2/1 to select [ ], and
then press [MENU/SET].
3
Hold the camera with the lens facing
toward the subject.
• When the camera identifies the optimum scene, the icon
of the scene concerned will change.
(Automatic Scene Detection)
∫ Scene Detection
When taking pictures
¦
>
[i-Portrait] [i-Scenery]
[i-Macro] [i-Night Portrait]
¢1
[i-Night Scenery] [iHandheld Night Shot]
¢2
[i-Sunset]
¢1 Only displayed when the flash is set to [ ].
¢2 Only displayed when [iHandheld Night Shot] is set to [ON].
DC-FT7-TS7PPP-DVQX1500_eng.book 36 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Recording
37
(ENG) DVQX1500
When recording motion pictures
•[¦] is set if none of the scenes are applicable, and the standard settings are set.
∫ Face Detection
The Auto Focus Mode is automatically set to [š].
∫ Flash
When [ ] is selected, [ ], [ ], [ ] or [ ] is set depending on the type
of subject and brightness.
Recording 4K Photos
Applicable modes:
The camera allows you to take burst pictures of 8 million pixels (approx.) at
30 frames/second. After taking these pictures, you can save the desired moment
extracted from their burst file.
• Use a UHS Speed Class 3 card.
• The angle of view may become narrower during recording.
1
Press [ ].
2
Select the recording method with 2/
1, and then press [MENU/SET].
¦
>
[i-Portrait] [i-Scenery]
[i-Macro] [i-Low Light]
DC-FT7-TS7PPP-DVQX1500_eng.book 37 ページ ２０１８年５月１０日 木曜日 午後２時４０分
38
DVQX1500 (ENG)
Recording
3
Press the shutter button to perform recording.
• The camera will perform burst recording of a 4K photo and saves it as a 4K
burst file in MP4 format.
• When [Auto Review] is enabled, the picture selection screen will be displayed
automatically.
[]
[4K Burst]
For capturing the best shot of
a fast-moving subject
Burst recording is performed
while the shutter button is
pressed and held.
A Press and hold
B Recording is performed
[]
[4K Burst(S/S)]
“S/S” is an
abbreviation of
Start/Stop.
For capturing unpredictable
photo opportunities
Burst recording starts when the
shutter button is pressed and
stops when pressed again.
C Start (First)
D Stop (Second)
E Recording is performed
Adding markers to select and save pictures
You can add markers if you press [Fn1] during recording. (Up to
40 markers per recording) When selecting and saving pictures
from a 4K burst file, you can skip to the positions where you
added markers.
[]
[4K Pre-Burst]
For recording as needed whenever
a photo opportunity arises
Burst recording is performed for
approximately 1 second before
and after the moment that the
shutter button is pressed.
F Approximately 1 second
G Recording is performed
DC-FT7-TS7PPP-DVQX1500_eng.book 38 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Recording
39
(ENG) DVQX1500
∫ Canceling 4K Photo
In step
2, select [ ].
• When [ ] ([4K Pre-Burst]) is set, the battery drains faster and the camera
temperature rises. Select [ ] ([4K Pre-Burst]) only when recording.
• Recording stops when the continuous recording time exceeds 29 minutes and
59 seconds.
When using an SDHC memory card, you can continue the recording of a 4K photo
without interruption even if the file size exceeds 4 GB, but the 4K photo will be recorded
and played back in separate burst files.
With an SDXC memory card, you can save a 4K photo with a burst file size exceeding
4 GB as a single file.
1 Select an image with the [ ] icon on the
playback screen, and press 3.
• The slide view screen, where you select pictures, is
displayed.
2 Press 2/1 to select the frame to be saved as a
picture.
• Select [ ]/[ ] and press [MENU/SET] to switch
to the previous or next slide view.
• Press [Fn1] to switch to marker operation. You can
press 2/1 to skip to the next marker position. ([4K
Burst(S/S)] only)
• You can also select scenes on the 4K burst playback
screen by pressing [Fn2]. ([4K Burst]/[4K Burst(S/S)] only)
For details, refer to the “Owner’s Manual for advanced features (PDF format)”.
3 Press [MENU/SET] to save the picture.
• The picture will be saved in JPEG format.
Selecting pictures from 4K burst file and saving
You can save pictures taken during a 5 second period at once by using
[4K PHOTO Bulk Saving] in the [Playback] menu.
DC-FT7-TS7PPP-DVQX1500_eng.book 39 ページ ２０１８年５月１０日 木曜日 午後２時４０分
40
DVQX1500 (ENG)
Recording
Controlling Focus After Recording (Post Focus)
Applicable modes:
The camera allows you to take 4K burst pictures while shifting the focus to different
areas. After taking these pictures, you can select the desired focus area.
This function is suited for recording still objects.
• Use a UHS Speed Class 3 card.
• The angle of view may become narrower during recording.
1
Press [ ].
2
Press 2/1 to select [ON] and press
[MENU/SET].
3
Decide on the composition, and
press the shutter button halfway.
• Auto Focus will detect focus areas on the
screen. (Excluding the edges of the screen)
• If no areas on the screen can be brought into
focus, the focus display (
A
) will flash.
Recording is not possible in this case.
4
Press the shutter button fully to start
recording.
• The focus point changes automatically while
recording. When the icon (
B
) disappears,
recording automatically ends.
• A motion picture in MP4 format will be recorded. (Audio will not be recorded.)
• When [Auto Review] is enabled, a screen that lets you select the desired focus
area will be displayed. (P41)
∫ Canceling [Post Focus]
Select [OFF] in step
2.
From the time you press the shutter button halfway until the end of recording:
• Maintain the same distance to the subject and the same composition.
4K
4:3
DC-FT7-TS7PPP-DVQX1500_eng.book 40 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Recording
41
(ENG) DVQX1500
1 Select an image with the [ ] icon on the
playback screen, and press 3.
2 Press 3/4/2/1 to select the focus area.
• If a picture that is in focus is not available for the
selected area, a red frame will be displayed. You
cannot save a picture in this case.
• You cannot select the edges of the screen.
• You can fine-adjust the focus by pressing 2/1
during enlarged display.
3 Press [MENU/SET] to save the picture.
• The picture will be saved in JPEG format.
Selecting the desired focus area and saving a picture
Description of operation
3/4/2/1
Selects a focus area.
• It cannot be selected during enlarged display.
Enlarges the display.
Reduces the display (during enlarged display).
[Fn2]
In-focus portions are highlighted with color. (Peaking)
• Switches in order of [OFF] > [ ] ([LOW]) > [ ]
([HIGH]).
[MENU/SET] Saves the picture.
)Q
)Q
)Q
DC-FT7-TS7PPP-DVQX1500_eng.book 41 ページ ２０１８年５月１０日 木曜日 午後２時４０分
42
DVQX1500 (ENG)
Recording
Recording Motion Picture/4K Motion
Applicable modes:
You can record motion pictures and 4K motion pictures in MP4 recording format.
Audio is recorded in stereo.
1
Start recording by pressing the motion
picture button.
A Elapsed recording time
B Available recording time
• Recording of motion picture appropriate for each
mode is possible.
• The recording state indicator (red) C will flash
while recording motion pictures.
• Release the motion picture button right after you
press it.
2
Stop the recording by pressing the
motion picture button again.
• Still picture recording is also possible during the
motion picture recording by fully pressing the
shutter button. (Excluding during 4K motion picture recording)
• When recording motion pictures in 4K, use a card rated as UHS Speed Class 3.
• The angle of view of motion pictures in 4K is narrower than those of motion pictures in
other sizes.
• To ensure highly accurate focus, 4K motion pictures are recorded at reduced Auto
Focus speeds. It may be difficult to focus on the subject with Auto Focus, but this is not
a malfunction.
5
P
V5
P
V
V
V
V
DC-FT7-TS7PPP-DVQX1500_eng.book 42 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Recording
43
(ENG) DVQX1500
• Continuous motion picture recordable times
¢1 You can continue recording without interruption.
∫ Setting the size and recording frame rate
¢2 4K motion picture
[Rec Quality]
Continuous
recordable time
Size interval for dividing files
4K
29 minutes and
59 seconds
When an SDHC card is used: Files exceeding
4 GB in size will be divided into smaller files for
recording and playback.
¢1
When an SDXC card is used: Files are not
divided for recording.
FHD
HD
Files exceeding 4 GB in size will be divided into
smaller files for recording and playback.
¢1
> [Motion Picture] > [Rec Quality]
Item Size
Recording
frame rate
Sensor output Bit rate
[4K/100M/30p]
¢2
3840k2160 30p 30 frames/second 100 Mbps
[4K/100M/24p]
¢2
3840k2160 24p 24 frames/second 100 Mbps
[FHD/28M/60p] 1920k1080 60p 60 frames/second 28 Mbps
[FHD/20M/30p] 1920k1080 30p 30 frames/second 20 Mbps
[HD/10M/30p] 1280k720 30p 30 frames/second 10 Mbps
MENU
DC-FT7-TS7PPP-DVQX1500_eng.book 43 ページ ２０１８年５月１０日 木曜日 午後２時４０分
44
DVQX1500 (ENG)
Recording
You can record motion pictures in approximately 1/4k slow motion by performing
high-speed recording at 120 frames/second. The motion is displayed slower during
playback.
• Recording will be performed at [HD/10M/30p].
1 Select the menu.
2 Start recording by pressing the motion picture button.
3 Stop the recording by pressing the motion picture button again.
• Audio is not recorded.
• You can continuously record a High Speed Video up to 7 minutes and 29 seconds or the
file size of 4 GB.
• Under fluorescent lighting, flicker or horizontal bars may be seen.
Recording slow motion pictures ([High Speed Video])
> [Motion Picture] > [High Speed Video] > [ON]
MENU
DC-FT7-TS7PPP-DVQX1500_eng.book 44 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Playback
45
(ENG) DVQX1500
Playing Back Pictures
1
Press [(].
2
Press 2/1.
∫ To finish playback
Press [
(] again or press the shutter button halfway.
• When the camera is turned off, press and hold [(]. If you turn it on this way, the
playback screen will be displayed automatically.
∫ Playing Back Motion Pictures
This unit was designed to play motion pictures using the MP4 format.
• Motion pictures are displayed with the motion picture icon ([ ]).
Press 3 to play back.
A Motion picture recording time
∫ Deleting Pictures
Once deleted, pictures cannot be recovered.
1 In Playback Mode, select the picture to delete
and then press [ ].
2 Press 3 to select [Delete Single] and then
press [MENU/SET].
2: Play back the previous picture
1: Play back the next picture
VVVV
DC-FT7-TS7PPP-DVQX1500_eng.book 45 ページ ２０１８年５月１０日 木曜日 午後２時４０分
46
DVQX1500 (ENG)
Menu
Menu list
• The description of each menu or setting item is displayed
on the menu screen.
[Rec] menu
[Photo Style] [4K PHOTO] (P37) [Shutter Type]
[Aspect Ratio] [Auto Bracket] [Red-Eye Removal]
[Picture Size] [Self Timer] [ISO Limit Set]
[Quality] [i.Dynamic] [Extended ISO]
[Sensitivity] [iHandheld Night Shot] [i.Zoom]
[White Balance] [iHDR] [Digital Zoom]
[AF Mode] [HDR] [Stabilizer]
[Metering Mode] [Time Lapse Shot]
[Burst Rate] [Panorama Settings]
[Motion Picture] menu
[Photo Style] [Continuous AF] [Digital Zoom]
[Rec Quality] (P43) [Metering Mode] [Wind Cut]
[High Speed Video] (P44) [i.Dynamic]
[AF Mode] [i.Zoom]
3KRWR6W\OH
$VSHFW5DWLR
$872
3LFWXUH6L]H
67'
4XDOLW\
6HQVLWLYLW\
0
/
6HWFRPSUHVVLRQOHYHORISLFW
DC-FT7-TS7PPP-DVQX1500_eng.book 46 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Menu
47
(ENG) DVQX1500
¢ This allows you to set the volume for electronic sound and the electronic shutter
sound.
[Custom] menu
[AF Assist Lamp] [Rec Area] [Fn Button Set] (P34)
[Histogram] [Remaining Disp.]
[Guide Line] [Auto Review]
[Setup] menu
[Precautions] (P16) [Beep]
¢
[Version Disp.]
[Online Manual] [Live View Mode] [Exposure Comp. Reset]
[Clock Set] (P26)
[Monitor Display]/
[Viewfinder]
[Self Timer Auto Off]
[World Time] [Monitor Luminance] [No.Reset]
[Wi-Fi] (P50) [LED Light] [Reset]
[Sensor Settings] (P34) [Economy] [Reset Wi-Fi Settings]
[Altimeter Adjust] [m/ft] [Format] (P26)
[Calibrate compass] [Language]
[Playback] menu
[Slide Show] [Title Edit] [Resize]
[Playback Mode] [Text Stamp] [Cropping]
[Location Logging] [Video Divide] [Protect]
[4K PHOTO Bulk Saving] [Time Lapse Video]
DC-FT7-TS7PPP-DVQX1500_eng.book 47 ページ ２０１８年５月１０日 木曜日 午後２時４０分
48
DVQX1500 (ENG)
Wi-Fi
What you can do with the Wi-Fi
®
function
• The camera cannot be used to connect to a public wireless LAN connection.
• For details, refer to the “Owner’s Manual for advanced features (PDF format)”.
This owner's manual refers to both smartphones and tablets as “smartphones”
from this point on unless noted otherwise.
∫ About the Wi-Fi connection lamp
∫ About the [Wi-Fi] button
In this owner's manual, a function button to which [Wi-Fi] is assigned is referred to
as the [Wi-Fi] button.
• For information about the function button, refer to P34
Controlling with a Smartphone/Tablet (P49)
• Recording with a smartphone (P51)
• Playing back or saving images stored on the
camera, or uploading them on social media
sites (P52)
• Writing location information on images stored
in the camera (P53)
When sending images to PC
Lit: When the Wi-Fi function is ON or connected by
Wi-Fi
Blinking: When sending image data by operating the
camera
DC-FT7-TS7PPP-DVQX1500_eng.book 48 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Wi-Fi
49
(ENG) DVQX1500
Controlling with a Smartphone/Tablet
The “Panasonic Image App” (hereafter “Image App”) is an application provided by
Panasonic.
• Use the latest version.
• Supported OSs are current as of May 2018 and are subject to change.
• Read the [Help] in the “Image App” menu for further details on how to operate.
• When you operate the “Image App” on the smartphone that is connected to the camera
via Wi-Fi, [Help] in the “Image App” may not be displayed depending on the
smartphone. In this case, after terminating the connection to the camera, reconnect the
smartphone to a mobile phone network such as the 3G or LTE network or to a Wi-Fi
router, and then display [Help] in the “Image App”.
• Some of the screens and information provided in this owner's manual may differ from
your device depending on the supported OS and “Image App” version.
• The service may not be able to be used properly depending on the type of smartphone
being used.
For information on the “Image App”, refer to the support site below.
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
• When downloading the app on a mobile network, high packet communication fees may
be incurred depending on the details of your contract.
Installing the smartphone/tablet app “Image App”
•OS
App for Android
TM
: Android 4.2 or higher
App for iOS: iOS 9.0 or higher
1 Connect the smartphone to a network.
2 (Android) Select “Google Play
TM
Store”.
(iOS) Select “App Store”.
3 Enter “ Panasonic Image App” or “LUMIX” into the search box.
4 Select “Panasonic Image App” and install it.
DC-FT7-TS7PPP-DVQX1500_eng.book 49 ページ ２０１８年５月１０日 木曜日 午後２時４０分
50
DVQX1500 (ENG)
Wi-Fi
You can easily set up a direct connection to your smartphone without entering a
password.
A SSID
• When the camera is ready to be connected to the
smartphone, the SSID is displayed.
• You can also display the information by pressing [Wi-Fi] on
the camera.
1 Turn on the Wi-Fi function in the setting menu.
2 On the Wi-Fi setting screen, select the SSID
displayed on the camera.
3 Start “Image App”.
• When the connection confirmation screen is displayed on
the camera, select [Yes] to connect. (For first time
connection only)
Connecting to a smartphone/tablet
Connecting without using the password
On the camera
> [Setup] > [Wi-Fi] > [Wi-Fi
Function] > [New Connection] >
[Remote Shooting & View]
On your smartphone
At the time of purchase, [Wi-Fi Password] is set to [OFF].
Before connecting to a Wi-Fi network, ensure that the device displayed on the
connection confirmation screen is the one you actually want to connect to. When
a wrong device is displayed, if you select [Yes], the camera will automatically
connect to that device.
We recommend that you set [Wi-Fi Password] to [ON] if, for example, there is
another Wi-Fi device nearby.
',63&KDQJHPHWKRG
6HOHFW>:L)L@RI>6HWWLQJV@IURP
VPDUWSKRQH3OHDVHFRQQHFWWR
WKHIROORZLQJ
MENU
Wi-Fi
0123456789ABC
DC-FT7-TS7PPP-DVQX1500_eng.book 50 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Wi-Fi
51
(ENG) DVQX1500
1 Press any button on the camera, and press [MENU/SET].
• Confirmation screen is displayed. It is executed when [Yes] is selected.
2 On the smartphone, close “Image App”.
1 Connect to a smartphone. (P50)
2 Operate the smartphone.
Terminating the connection
Taking images via a smartphone (remote recording)
1 Select [ ].
2 Record an image.
• The recorded images are saved in the
camera.
• Some settings are not available.
A
DC-FT7-TS7PPP-DVQX1500_eng.book 51 ページ ２０１８年５月１０日 木曜日 午後２時４０分
52
DVQX1500 (ENG)
Wi-Fi
1 Connect to a smartphone. (P50)
2 Operate the smartphone.
Playing back/saving images stored on the camera, or
uploading them on social media sites
1 Select [ ].
• You can switch the images to be
displayed by selecting the icon (A) on
the top left of the screen. To display
images stored in the camera, select
[LUMIX].
(To play back the image)
2 Touch the image to enlarge it.
(To save the image or upload it on a social
media site or other web service)
3 Touch and hold an image, and drag it
to save it.
• When you play a motion picture, image quality
differs from that of the actual recorded motion
picture. The image quality may deteriorate or the
sound may skip during motion picture or picture
playback.
• You cannot save the following types of images:
– When the MP4 motion picture size is set to [4K]
in [Rec Quality]
– 4K burst files
– Images recorded with the Post Focus function
DC-FT7-TS7PPP-DVQX1500_eng.book 52 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Wi-Fi
53
(ENG) DVQX1500
You can send location information acquired with a smartphone to the camera. After
sending the information, you can also write it on images stored in the
camera.
1 Start recording location information
2 Start recording images
3 Finish recording the location information
4 Sending and writing location information
∫ Operate the smartphone
1 Connect to a smartphone. (P50)
2 Select [ ].
3 Select [Geotagging].
4 Select an icon.
Adding location information to images stored in the
camera from a smartphone
Start/stop recording location information.
• The smartphone battery drains faster while location information is being
recorded.
When recording of location information is not necessary, stop it.
Sending and writing location information.
• Follow the on-screen messages to operate the smartphone.
• Images with location information are indicated with [ ].
GPS
DC-FT7-TS7PPP-DVQX1500_eng.book 53 ページ ２０１８年５月１０日 木曜日 午後２時４０分
54
DVQX1500 (ENG)
Others
Monitor Display/Viewfinder Display
• The descriptions in this section use the monitor screen as examples.
In recording
L
4:3
00
AWBAWBAWB
MP4
60
p
ラュンラュン
3.33.3
3.3
1
Recording Mode (P31)
Photo Style
‰
Œ
Flash Mode
LED light
Recording quality (P43)
Picture size/Aspect Ratio
EXPSEXPS
1
60
p
L
4:3
Image size (Panorama
Shot Mode)
Image effect (filter)
adjustment display
Image effect (filter) setting
Card (displayed only during
recording)
Elapsed recording time
¢1
(P42)
Simultaneous recording
indicator
HDR/iHDR
Electronic shutter
Overheat indicator
STD.
WIDE
EXPS
8
m
30
s
ラュン
DC-FT7-TS7PPP-DVQX1500_eng.book 54 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
55
(ENG) DVQX1500
¢1 m: minute, s: second
¢2 This is displayed for about 5 seconds
when the camera is turned on, after
setting the clock and after switching
from Playback Mode to Recording
Mode.
2
A › Quality
šØ
Ù
AF Mode
Post Focus (P40)
Burst
4K Photo (P37)
Auto Bracket
Self-timer
Battery indication
Macro recording
High Speed Video (P44)
Image Stabilizer
Jitter alert
Recording state (Flashes
red.)/Focus (Lights green.)
(P29, 42)
Focus (Under low
illumination)
Connected to Wi-Fi
Histogram
3
Current date and time/Travel destination
setting
¢2
: “
Exposure meter
Zoom
120fps
LOW
4
AF area
Spot metering target
Self-timer
Metering Mode
3.3
Aperture value (P29)
60
Shutter speed (P29)
Exposure compensation
value
Manual Exposure
Assistance
ISO sensitivity
5
White Balance Fine
Adjustment
VÐîÑ
Ò
White Balance
98
Number of recordable
pictures
Available recording time
¢1
(P42)
AWB
R
8
m
30
s
DC-FT7-TS7PPP-DVQX1500_eng.book 55 ページ ２０１８年５月１０日 木曜日 午後２時４０分
56
DVQX1500 (ENG)
Others
Troubleshooting
First, try out the following procedures.
• Please also refer to the “Owner’s Manual for advanced features (PDF format)”, which
describes more detailed information.
• Is the drive mode set to a mode other than [Single]? (P30)
• The subject is beyond the focus range of the camera.
• If you record a moving subject when using the electronic shutter or recording motion
picture or a 4K photo, the subject may appear distorted on the picture. This is
characteristic of MOS sensors which serve as the camera’s pickup sensors. This is not
a malfunction.
• This is characteristic of MOS sensors which serve as the camera’s pickup sensors.
This is not a malfunction.
If the problem is not resolved, it may be improved by selecting [Reset] on
the [Setup] menu.
Multiple pictures are taken at one time.
The subject is not focused properly.
The subject appears distorted on the picture.
Striping or flicker may appear under lighting such as fluorescent lighting
and LED lighting fixture.
DC-FT7-TS7PPP-DVQX1500_eng.book 56 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
57
(ENG) DVQX1500
• Is the flash setting set to [Œ]?
> Change the flash setting.
• When the electronic shutter is used, the flash is not activated.
> Set [Shutter Type] to [MSHTR]. (P46)
• Use within the communication range of the device to be connected.
• Is any device, such as microwave oven, cordless phone, etc., that uses 2.4 GHz
frequency operated nearby?
> Radio waves may get interrupted when used simultaneously. Use them sufficiently
away from the device.
• When the battery indicator is flashing red, the connection with other equipment may not
start or the connection may be disrupted.
• If you place the camera on a metal table or shelf, the radio waves may be adversely
affected. In such cases, you may not be able to establish a connection. Move the
camera away from the metal surface.
• Press [MENU/SET] after viewing the last screen (12/12). For details, refer to P16.
• This is the sound of the lens moving and not a malfunction in the following cases:
> A rattling sound is heard when you shake the camera while the camera is turned off
or in Playback Mode.
> A rattling or similar sound is heard when you turn on or off the camera or switch
between Recording Mode and Playback Mode.
The flash is not activated.
A Wi-Fi connection cannot be established.
Radio waves get disconnected.
Wireless access point is not displayed.
[Precautions] is displayed repeatedly whenever this unit is turned on.
A rattling or similar sound is heard from the camera.
DC-FT7-TS7PPP-DVQX1500_eng.book 57 ページ ２０１８年５月１０日 木曜日 午後２時４０分
58
DVQX1500 (ENG)
Others
• Water is left in the speaker or microphone hole. Drain the water. (P20)
• Have foreign objects become trapped?
> Remove the foreign objects. (P17)
• When closing, do not set the [LOCK] switch to the locked side. Doing so may cause
damage or leaks.
> Release the lock. (P23)
• When using the camera in cold places such as ski resorts or places at high altitude, do
not leave the camera with snow or water droplets sticking to it. Some parts of the
camera may become hard to move with snow or water droplets freezing in narrow
spaces, such as the gaps of the buttons, dial, and side door. This is not a malfunction.
When the camera returns to normal temperature it will function as normal.
• When using the camera in places with large amounts of sand or dust, some parts of the
camera may become hard to move with foreign objects getting in narrow spaces, such
as the gaps of the diopter adjustment dial, shutter button, and camera [ON/OFF] button.
Wipe off with a dry, lint-free cloth or rinse with fresh water.
The sound from the speaker is weak. Difficult to hear the recorded sound.
The side door will not close.
Cannot move some parts of the camera, such as the buttons, dial, and
side door.
DC-FT7-TS7PPP-DVQX1500_eng.book 58 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
59
(ENG) DVQX1500
Specifications
Specifications are subject to change without notice.
Digital Camera:
Information for your safety
Power source: 5V
Power consumption: 4.4 W (When recording with Monitor)
4.4 W (When recording with Viewfinder)
2.0 W (When playing back with Monitor)
2.0 W (When playing back with Viewfinder)
Camera effective
pixels
20,400,000 pixels
Image sensor 1/2.3q MOS sensor, total pixel number
21,100,000 pixels, Primary color filter
Lens Optical 4.6k zoom, fl4.9 mm to 22.8 mm (35 mm film
camera equivalent: 28 mm to 128 mm)
Wide: F3.3/F10
Tele: F5.9/F18
Image stabilizer Optical method
Focus range Normal 30 cm (0.98 feet) to ¶
Macro / Intelligent auto /
Motion Picture
5 cm (0.16 feet) (Wide) /
30 cm (0.98 feet) (Tele) to
¶
Shutter system Electronic shutteriMechanical shutter
Minimum illumination Approx. 12 lx (when i-Low light is used, the shutter
speed is 1/30th of a second)
DC-FT7-TS7PPP-DVQX1500_eng.book 59 ページ ２０１８年５月１０日 木曜日 午後２時４０分
60
DVQX1500 (ENG)
Others
Shutter speed Still picture:
4 seconds to 1/1300th of a second (Mechanical
shutter),
1 second to 1/16000th of a second (Electronic shutter)
Motion picture:
1/30th of a second to 1/16000th of a second
Exposure (AE) Program AE (P) / Manual Exposure (M)
Exposure
compensation
1/3 EV Step, j5 EV to i5EV
Light metering mode Multiple / Center weighted / Spot
Monitor 3.0q TFT LCD (3:2)
(Approx. 1,040,000 dots) (field of view ratio about
100%)
Viewfinder Live Viewfinder (4:3) (Approx. 1,170,000 dots
equivalent)
(field of view ratio about 100%)
(Magnification approx. 2.53k, 0.45k (35 mm film
camera equivalent))
(with diopter adjustment j4 to i4 diopter)
Flash AUTO / AUTO/Red-Eye Reduction / Forced ON /
Forced ON/Red-Eye Reduction / Slow Sync. / Slow
Sync./Red-Eye Reduction / Forced OFF
Microphone Stereo
Speaker Monaural
Recording media SD Memory Card / SDHC Memory Card / SDXC
Memory Card
• This unit is compatible with UHS-I UHS Speed Class 3
standard SDHC/SDXC memory cards.
DC-FT7-TS7PPP-DVQX1500_eng.book 60 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
61
(ENG) DVQX1500
Recording file format
Still picture JPEG (based on “Design rule for Camera File system”,
based on “Exif 2.31” standard)
Motion picture MP4
Audio compression AAC (2 ch)
Interface
[HDMI] microHDMI Type D
[USB/CHARGE] USB 2.0 (High Speed) Micro-B
Dimensions Approx. 116.7 mm (W)k76.1 mm (H)k37.3 mm (D)
[4.59q (W)k2.99q (H)k1.46q (D)]
Mass (Weight) Approx. 319 g / 0.70 lb (with card and battery)
Approx. 293 g / 0.65 lb (excluding card and battery)
Operating
temperature
j10 oC
¢
to 40 oC (14 oF
¢
to 104 oF)
¢ The performance of the battery (number of recordable
pictures/operating time) may decrease temporarily
when using in a temperature between j10 oC and 0 oC
(14 oF and 32 oF) (cold places such as ski resorts or
places at high altitude).
Operating humidity 10%RH to 80%RH
Bearing sensor 16 bearing detection
Language select [ENGLISH] / [DEUTSCH] / [FRANÇAIS] / [ESPAÑOL] /
[ITALIANO] / [繁體中文] / [PORTUGUÊS] / [¢]
DC-FT7-TS7PPP-DVQX1500_eng.book 61 ページ ２０１８年５月１０日 木曜日 午後２時４０分
62
DVQX1500 (ENG)
Others
Altitude sensor Convert atmospheric pressure to altitude using “ISA
(International Standard Atmosphere)”,
accuracy: n25 m (82 feet)
Waterproof
performance
Equivalent to IEC 60529 “IPX8”.
(Usable for 60 minutes in 31 m (102 feet) water depth)
Crash resistance
perfomance
The test method of the camera is in compliance with
“MIL-STD 810F Method 516.5-Shock”
¢
.
¢ “MIL-STD 810F Method 516.5-Shock” is the test
method standard of the U.S. Defense Department,
which specifies performing drop tests from a height of
122 cm (4 feet), at 26 orientations (8 corners,
12 ridges, 6 faces) using 5 sets of devices, and passing
the 26 orientation drops within 5 devices.
(If failure occurs during the test, a new set is used to
pass the drop orientation test within a total of 5 devices)
• Panasonic’s test method is based on the above “MIL-STD
810F Method 516.5-Shock”. However, the drop height was
changed from 122 cm (4 feet) to 200 cm (6.6 feet)
dropping onto 3 cm (0.1 feet) thick plyboard. This drop
test was passed.
(Disregarding appearance change such as loss of paint or
distortion of the part where drop impact is applied.)
There is no guarantee of not breaking or
malfunctioning under all conditions.
Withstand load
performance
100 kgf / 220.5 lbf (According to the test conditions
specified by Panasonic)
Dustproof
performance
Equivalent to IEC 60529 “IP6X”.
DC-FT7-TS7PPP-DVQX1500_eng.book 62 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
63
(ENG) DVQX1500
Wireless transmitter
AC adaptor (Panasonic SAE0012A):
Information for your safety
Battery pack (lithium-ion) (Panasonic DMW-BCM13PP):
Information for your safety
The symbols on this product (including the accessories) represent the following:
Compliance standard IEEE 802.11b/g/n (standard wireless LAN protocol)
Frequency range used
(central frequency)
2412 MHz to 2462 MHz (1 to 11ch)
Encryption method Wi-Fi compliant WPA
TM
/ WPA2
TM
Access method Infrastructure mode
Input: 110 V–240 V 50/60 Hz 0.2 A
Output: 5V 1.0A
Operating temperature: 0 oC to 40 oC (32 oF to 104 oF)
Voltage/capacity: 3.6 V / 1250 mAh
AC
DC
Class II equipment (The construction of the product is double-insulated.)
DC-FT7-TS7PPP-DVQX1500_eng.book 63 ページ ２０１８年５月１０日 木曜日 午後２時４０分
64
DVQX1500 (ENG)
Others
Reading the Owner's Manual (PDF
format)
More detailed owner's manual is available in “Owner’s Manual for advanced
features (PDF format)”. To read it, download it from the website.
• Click the desired language.
∫ To check the URL and QR code on the camera
• You will need Adobe Reader to browse or print the “Owner’s Manual for advanced
features (PDF format)”.
You can download and install a version of Adobe Reader that you can use with your OS
from the following website. (As of May 2018)
http://www.adobe.com/products/acrobat/readstep2.html
http://panasonic.jp/support/dsc/oi/index.html?model=DC-TS7&dest=P
> [Setup] > [Online Manual]
[URL display] Displays the URL of the website on the camera’s monitor.
[QR Code display] Displays the QR code on the camera’s monitor.
MENU
DC-FT7-TS7PPP-DVQX1500_eng.book 64 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
65
(ENG) DVQX1500
Limited Warranty (ONLY FOR U.S.A.)
Panasonic Products Limited Warranty
Limited Warranty Coverage (For USA Only)
If your product does not work properly because of a defect in materials or
workmanship, Panasonic Corporation of North America (referred to as “the
warrantor”) will, for the length of the period indicated on the chart below, which
starts with the date of original purchase (“warranty period”), at its option either (a)
repair your product with new or refurbished parts, (b) replace it with a new or a
refurbished equivalent value product, or (c) refund your purchase price. The
decision to repair, replace or refund will be made by the warrantor.
During the “Labor” warranty period there will be no charge for labor. During the
“Parts” warranty period, there will be no charge for parts. This Limited Warranty
excludes both parts and labor for non-rechargeable batteries, antennas, and
cosmetic parts (cabinet). This warranty only applies to products purchased and
serviced in the United States. This warranty is extended only to the original
purchaser of a new product which was not sold “as is”.
Product or Part Name Parts Labor
Digital Camera 1 Year 1 Year
All included Accessories
(Except Non-Rechargeable Batteries)
90 Days Not Applicable
Only Non-Rechargeable Batteries 10 Days Not Applicable
DC-FT7-TS7PPP-DVQX1500_eng.book 65 ページ ２０１８年５月１０日 木曜日 午後２時４０分
66
DVQX1500 (ENG)
Others
Mail-In Service--Online Repair Request
Online Repair Request
To submit a new repair request and for quick repair status visit our Web Site at
http://shop.panasonic.com/support
.
When shipping the unit, carefully pack, include all supplied accessories listed in the
Owner’s Manual, and send it prepaid, adequately insured and packed well in a
carton box. When shipping Lithium Ion batteries please visit our Web Site at
http://shop.panasonic.com/support
as Panasonic is committed to providing the
most up to date information. Include a letter detailing the complaint, a return
address and provide a daytime phone number where you can be reached. A valid
registered receipt is required under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER
WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE
INDICATING DATE OF PURCHASE, AMOUNT PAID AND PLACE OF
PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR OF ANY
UNIT RECEIVED WITHOUT SUCH PROOF OF PURCHASE.
Limited Warranty Limits and Exclusions
This warranty ONLY COVERS failures due to defects in materials or workmanship, and
DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO
DOES NOT COVER damages which occurred in shipment, or failures which are
caused by products not supplied by the warrantor, or failures which result from
accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, introduction of sand,
humidity or liquids, commercial use such as hotel, office, restaurant, or other business
or rental use of the product, or service by anyone other than a Factory Service Center
or other Authorized Servicer, or damage that is attributable to acts of God.
DC-FT7-TS7PPP-DVQX1500_eng.book 66 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
67
(ENG) DVQX1500
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING
OUT OF ANY BREACH OF THIS WARRANTY.
(As examples, this excludes damages for lost time, travel to and from the servicer,
loss of or damage to media or images, data or other memory or recorded content.
The items listed are not exclusive, but for illustration only.)
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY
OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED
WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, or limitations on how long an implied warranty lasts, so the exclusions
may not apply to you.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state. If a problem with this product develops during or
after the warranty period, you may contact your dealer or Service Center. If the
problem is not handled to your satisfaction, then write to:
Consumer Affairs Department
Panasonic Corporation of North America
661 Independence Pkwy
Chesapeake, VA 23320
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
DC-FT7-TS7PPP-DVQX1500_eng.book 67 ページ ２０１８年５月１０日 木曜日 午後２時４０分
68
DVQX1500 (ENG)
Others
As of July 2015
DC-FT7-TS7PPP-DVQX1500_eng.book 68 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
69
(ENG) DVQX1500
Limited Warranty (ONLY FOR CANADA)
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
PANASONIC PRODUCT – LIMITED WARRANTY
Panasonic Canada Inc. warrants this product to be free from defects in material
and workmanship under normal use and for a period as stated below from the date
of original purchase agrees to, at its option either (a) repair your product with new
or refurbished parts, (b) replace it with a new or a refurbished equivalent value
product, or (c) refund your purchase price. The decision to repair, replace or refund
will be made by Panasonic Canada Inc.
This warranty is given only to the original purchaser, or the person for whom it was
purchased as a gift, of a Panasonic brand product mentioned above sold by an
authorized Panasonic dealer in Canada and purchased and used in Canada, which
product was not sold “as is”, and which product was delivered to you in new
condition in the original packaging.
IN ORDER TO BE ELIGIBLE TO RECEIVE WARRANTY SERVICE
HEREUNDER, A PURCHASE RECEIPT OR OTHER PROOF OF DATE OF
ORIGINAL PURCHASE, SHOWING AMOUNT PAID AND PLACE OF
PURCHASE IS REQUIRED
Digital Camera One (1) year, parts and labour
Digital Camera Peripherals One (1) year, parts and labour
Digital Camera Accessories Ninety (90) days, parts and labour
DC-FT7-TS7PPP-DVQX1500_eng.book 69 ページ ２０１８年５月１０日 木曜日 午後２時４０分
70
DVQX1500 (ENG)
Others
LIMITATIONS AND EXCLUSIONS
This warranty ONLY COVERS failures due to defects in materials or workmanship, and
DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO
DOES NOT COVER damages which occurred in shipment, or failures which are
caused by products not supplied by Panasonic Canada Inc., or failures which result
from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, improper batteries, power line surge, lightning damage, modification,
introduction of sand, humidity or liquids, commercial use such as hotel, office,
restaurant, or other business or rental use of the product, or service by anyone other
than a Authorized Servicer, or damage that is attributable to acts of God.
Dry cell batteries, printer ink cartridge and paper are also excluded from coverage
under this warranty.
Rechargeable batteries are warranted for ninety (90) days from date of original purchase.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR
ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES RESULTING
FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY. (As examples, this warranty excludes
damages for lost time, travel to and from the Authorized Servicer, loss of or
damage to media or images, data or other memory or recorded content. This list of
items is not exhaustive, but for illustration only.)
In certain instances, some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages, or the exclusion of implied warranties, so the
above limitations and exclusions may not be applicable. This warranty gives you
specific legal rights and you may have other rights which vary depending on your
province or territory.
WARRANTY SERVICE
For product operation, repairs and information assistance, please visit our
Support page:
www.panasonic.ca/english/support
DC-FT7-TS7PPP-DVQX1500_eng.book 70 ページ ２０１８年５月１０日 木曜日 午後２時４０分
Others
71
(ENG) DVQX1500
This product incorporates the following software:
(1) the software developed independently by or for Panasonic Corporation,
(2) the software owned by third party and licensed to Panasonic Corporation,
(3) the software licensed under the GNU General Public License, Version 2.0 (GPL V2.0),
(4) the software licensed under the GNU LESSER General Public License, Version 2.1
(LGPL V2.1), and/or
(5) open source software other than the software licensed under the GPL V2.0 and/or
LGPL V2.1.
The software categorized as (3) - (5) are distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY, without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. Please refer to
the detailed terms and conditions thereof displayed by selecting [MENU/SET] >
[Setup] > [Version Disp.] > [Software info].
At least three (3) years from delivery of this product, Panasonic will give to any third
party who contacts us at the contact information provided below, for a charge no more
than our cost of physically performing source code distribution, a complete machine-
readable copy of the corresponding source code covered under GPL V2.0 or LGPL
V2.1, as well as the respective copyright notice thereof.
Contact Information: [email protected]
The source code and the copyright notice are also available for free in our website below.
https://panasonic.net/cns/oss/index.html
• SDXC Logo is a trademark of SD-3C, LLC.
• The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator,
Inc. in the United States and other countries.
• Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the
United States and/or other countries.
• Windows is a registered trademark or trademark of Microsoft Corporation in the
United States and/or other countries.
• Mac, OS X and macOS are trademarks of Apple Inc., registered in the U.S. and other
countries.
• iPad, iPhone, iPod, and iPod touch are trademarks of Apple Inc., registered in the
U.S. and other countries.
• App Store is a service mark of Apple Inc.
• Android and Google Play are trademarks or registered trademarks of Google Inc.
DC-FT7-TS7PPP-DVQX1500_eng.book 71 ページ ２０１８年５月１０日 木曜日 午後２時４０分
• The Wi-Fi CERTIFIED™ Logo is a certification mark of
Wi-Fi Alliance
®
.
• The Wi-Fi Protected Setup™ Logo is a certification mark
of Wi-Fi Alliance
®
.
• “Wi-Fi
®
” is a registered trademarks of Wi-Fi Alliance
®
.
• “Wi-Fi Protected Setup™”, “WPA™”, and “WPA2™” are
trademarks of Wi-Fi Alliance
®
.
• This product uses “DynaFont” from DynaComware
Corporation. DynaFont is a registered trademark of
DynaComware Taiwan Inc.
• QR Code is a registered trademark of DENSO WAVE
INCORPORATED.
• Other names of systems and products mentioned in these instructions are usually the
registered trademarks or trademarks of the manufacturers who developed the system
or product concerned.
This product is licensed under the AVC Patent Portfolio License for the personal use of
a consumer or other uses in which it does not receive remuneration to (i) encode video
in compliance with the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that
was encoded by a consumer engaged in a personal activity and/or was obtained from a
video provider licensed to provide AVC Video. No license is granted or shall be implied
for any other use. Additional information may be obtained from MPEG LA, L.L.C.
See http://www.mpegla.com
Printed in China
Two Riverfront Plaza, Newark, NJ 07102-5490
Panasonic Corporation of North America
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
Panasonic Corporation 2018
www.panasonic.com
http://shop.panasonic.com
DC-FT7-TS7PPP-DVQX1500_eng.book 72 ページ ２０１８年５月１０日 木曜日 午後２時４０分
