Before installing the drive, turn off
the system power.
Disconnect the power cord,
and remove the cover.
• Remove a vacant 5.25” drive bay panel from
the computer. Slide the drive into the drive
bay.
Connecting the SATA Power
Cable
• Connect the power cable so the projection of
the cable connector side to come to the left
side. Be careful not to connect upside down.
NOTE:
Improper connection may damage the drive
and void the warranty. Generally, the power
connector can only fit one way.
Installing the Drive
Connect to the power connector of the PC.
Red
