Installation
NOTES
NOTES
• Make sure you have a personal computer with any open USB port before
connecting the drive to your computer.
• Power for all device should be turn off before attaching the cables.
• Please do not connect the AC adapter and USB cable by any means other than specied above.
• “Use only power supplies listed in the user instructions” or
“For applicable power supplies see user instructions”.
Adapter information
- Model name: WA-36A12S
- Manufacturer: Asian Power devices Inc.
- Rating: 36 W (3.0 A, 12 V)
• The appliance is not intended for use by young children or inrm persons without supervision.
Young children should be supervised to ensure that they do not play with appliance.
• If the appliance is supplied from a cord extension set or an electrical portable outlet device, the cord extension set on electrical portable outlet device must be
positioned so that it is not subject to splashing or ingress of moisture.
• Please pay attention to handling Electrostatic Sensitive Devices, you may use anti-static products such as wrist straps, heel straps, mats to protect your body
from electrostatic.
Connecting to computer
Connect the drive to the computer as shown in gure.
Connect the USB cable to the External Writer.
Connect the other end of the USB cable to your computer.
Connect the AC adapter plug to the power connector at
the rear of the drive. Attach the AC adapter to the AC
wall outlet.
Make sure the power switch is turned on.
When the computer is ready, conrm that the drive is
detected.
And then, insert the supplied software CD into the
External Writer and install the software.
To AC wall outlet.
USB cable
Hardware Installation
