LG Electronics 37LG50 37” Class LCD HDTV (37.0” diagonal) User Manual

Please read this manual carefully before operating

your set.

Retain it for future reference.

Record model number and serial number of the set.

See the label attached on the back cover and quote

this information to your dealer

when you require service.

LCD TV

OWNER’S MANUAL

37LG50

42LG50

47LG50

52LG50

42LG50DC

47LG50DC

52LG50DC

42LG55

47LG55

P/NO : SAC30708033 (0810-REV03)

www.lgusa.com / www.lg.ca

WARNING / CAUTION

To prevent fire or shock hazards, do not expose

this product to rain or moisture.

FCC NOTICE

Class B digital device

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to

radio or television reception, which can be determined

by turning the equipment off and on, the user is

encouraged to try to correct the interference by one

or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and

receiver.

- Connect the equipment to an outlet on a circuit

different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV

technician for help.

Any changes or modifications not expressly approved

by the party responsible for compliance could void

the user’s authority to operate the equipment.

CAUTION

Do not attempt to modify this product in any way

without written authorization from LG Electronics.

Unauthorized modification could void the user’s

authority to operate this product

The lightning flash with arrowhead

symbol, within an equilateral triangle, is

intended to alert the user to the presence

of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

The exclamation point within an equilateral

triangle is intended to alert the user to

the presence of important operating and

maintenance (servicing) instructions in the litera-

ture accompanying the appliance.

TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK). NO

USER SERVICEABLE PARTS INSIDE. REFER TO

QUALIFIED SERVICE PERSONNEL.

WARNING/CAUTION

TO REDUCE THE RISK OF FIRE AND ELECTRIC

SHOCK, DO NOT EXPOSE THIS PRODUCT TO

RAIN OR MOISTURE.

NOTE TO CABLE/TV INSTALLER

This reminder is provided to call the CATV system

installer’s attention to Article 820-40 of the National

Electric Code (U.S.A.). The code provides guidelines for

proper grounding and, in particular, specifies that the

cable ground shall be connected to the grounding system

of the building, as close to the point of the cable entry

as practical.

IMPORTANT SAFETY INSTRUCTIONS

SAFETY INSTRUCTIONS

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

Do not install near any heat sources such as

radiators, heat registers, stoves, or other

apparatus (including amplifiers)that produce

heat.

Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has

two blades with one wider than the other. A

grounding type plug has two blades and a

third grounding prong, The wide blade or the

third prong are provided for your safety. If the

provided plug does not fit into your outlet,

consult an electrician for replacement of the

obsolete outlet.

Protect the power cord from being walked on

or pinched particularly at plugs, convenience

receptacles, and the point where they exit from

the apparatus.

Only use attachments/accessories specified by

the manufacturer.

Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold

with the apparatus. When a cart is used, use

caution when moving the cart/apparatus com-

bination to avoid injury from tip-over.

Unplug this apparatus during lighting storms

or when unused for long periods of time.

Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has

been damaged in any way, such as power-

supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or

has been dropped.

SAFETY INSTRUCTIONS

Never touch this apparatus or antenna during

a thunder or lighting storm.

When mounting a TV on the wall, make sure

not to install the TV by the hanging power and

signal cables on the back of the TV.

Do not allow an impact shock or any objects to

fall into the product, and do not drop onto the

screen with something.

CAUTION concerning the Power Cord:

It is recommend that appliances be placed

upon a dedicated circuit; that is, a single

outlet circuit which powers only that appliance

and has no additional outlets or branch

circuits. Check the specification page of this

owner's manual to be certain.

Do not connect too many appliances to the

same AC power outlet as this could result in

fire or electric shock.

Do not overload wall outlets. Overloaded wall

outlets, loose or damaged wall outlets, extension

cords, frayed power cords, or damaged or

cracked wire insulation are dangerous. Any of

these conditions could result in electric shock

or fire. Periodically examine the cord of your

appliance, and if its appearance indicates damage

or deterioration, unplug it, discontinue use of

the appliance, and have the cord replaced with

an exact replacement part by an authorized

servicer. Protect the power cord from physical

or mechanical abuse, such as being twisted,

kinked, pinched, closed in a door, or walked

upon. Pay particular attention to plugs, wall

outlets, and the point where the cord exits the

appliance.

Do not make the TV with the power cord

plugged in. Do not use a damaged or loose

power cord. Be sure do grasp the plug when

unplugging the power cord. Do not pull on the

power cord to unplug the TV.

WARNING - To reduce the risk of fire or electrical

shock, do not expose this product to rain,

moisture or other liquids. Do not touch the TV

with wet hands. Do not install this product

near flammable objects such as gasoline or

candles or expose the TV to direct air

conditioning.

Do not expose to dripping or splashing and do

not place objects filled with liquids, such as

vases, cups, etc. on or over the apparatus (e.g.

on shelves above the unit).

GGRROOUUNNDDIINNGG

Ensure that you connect the earth ground wire

to prevent possible electric shock (i.e. a TV

with a three-prong grounded AC plug must be

connected to a three-prong grounded AC out-

let). If grounding methods are not possible,

have a qualified electrician install a separate

circuit breaker.

Do not try to ground the unit by connecting it

to telephone wires, lightening rods, or gas

pipes.

DDIISSCCOONNNNEECCTTIINNGG DDEEVVIICCEE FFRROOMM MMAAIINNSS

Mains plug is the disconnecting device. The

plug must remain readily operable.

Keep the product away from direct sunlight.

Power

Supply

Short-circuit

Breaker

AANNTTEENNNNAASS

OOuuttddoooorr aanntteennnnaa ggrroouunnddiinngg

If an outdoor antenna is installed, follow the

precautions below. An outdoor antenna system

should not be located in the vicinity of over-

head power lines or other electric light or

power circuits, or where it can come in contact

with such power lines or circuits as death or

serious injury can occur.

Be sure the antenna system is grounded so as

to provide some protection against voltage

surges and built-up static charges.

Section 810 of the National Electrical Code

(NEC) in the U.S.A. provides information with

respect to proper grounding of the mast and

supporting structure, grounding of the lead-in

wire to an antenna discharge unit, size of

grounding conductors, location of antenna dis-

charge unit, connection to grounding elec-

trodes and requirements for the grounding

electrode.

AAnntteennnnaa ggrroouunnddiinngg aaccccoorrddiinngg ttoo tthhee

NNaattiioonnaall EElleeccttrriiccaall CCooddee,, AANNSSII//NNFFPPAA 7700

CClleeaanniinngg

When cleaning, unplug the power cord and

scrub gently with a soft cloth to prevent

scratching. Do not spray water or other liquids

directly on the TV as electric shock may occur.

Do not clean with chemicals such as alcohol,

thinners or benzene.

MMoovviinngg

Make sure the product is turned off,

unplugged and all cables have been removed. It

may take 2 or more people to carry larger TVs.

Do not press against or put stress on the front

panel of the TV.

VVeennttiillaattiioonn

Install your TV where there is proper ventila-

tion. Do not install in a confined space such as

a bookcase. Do not cover the product with

cloth or other materials (e.g.) plastic while

plugged in. Do not install in excessively dusty

places.

If you smell smoke or other odors coming from

the TV or hear strange sounds, unplug the power

cord contact an authorized service center.

Do not press strongly upon the panel with

hand or sharp object such as nail, pencil or

pen, or make a scratch on it.

Antenna Lead in Wire

Antenna Discharge Unit

(NEC Section 810-20)

Grounding Conductor

(NEC Section 810-21)

Ground Clamps

Power Service Grounding

Electrode System (NEC

Art 250, Part H)

Ground Clamp

Electric Service

Equipment

NEC: National Electrical Code

CONTENTS

WARNING / CAUTION

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

SAFETY INSTRUCTIONS

. . . . . . . . . . . . . . . . . . . . . . . . . . 3

FEATURE OF THIS TV

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

PREPARATION

Accessories

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Front Panel Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Back Panel Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Stand Instruction

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

VESA Wall Mounting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cable Management

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Desktop Pedestal Installation

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Swivel Stand

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Attaching the TV to a Desk

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Securing the TV to the wall to prevent falling when

the TV is used on a stand

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Antenna or Cable Connection

. . . . . . . . . . . . . . . . . . . . . . . . . .

EXTERNAL EQUIPMENT SETUP

HD Receiver Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DVD Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

VCR Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Other A/V Source Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

PC Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USB Connection

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Audio Out Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

WATCHING TV / CHANNEL CONTROL

Remote Control Functions

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Turning On the TV

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Channel Selection

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Volume Adjustment

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Quick Menu / Favorite Channel Setup

. . . . . . . . . . . . . .

Initial Setting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

On-Screen Menus Selection

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Channel Setup

- Auto Scan (Auto Tuning)

. . . . . . . . . . . . . . . . . . . . . . . . . . . 40

- Add / Delete Channel (Manual Tuning) . . . . . . 41

- Channel Editing

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Input List

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Input Label

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

AV Mode

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

SIMPLINK

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USB

Entry Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Photo List

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Music List

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

PICTURE CONTROL

Picture Size (Aspect Ratio) Control

. . . . . . . . . . . . . . . . . . 56

Preset Picture Settings

- Picture Mode - Preset

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

- Color Tone - Preset

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Manual Picture Adjustment

- Picture Mode - User Mode

. . . . . . . . . . . . . . . . . . . . . . . .

- Picture Mode - Expert Control

. . . . . . . . . . . . . . . . . . .

Picture Improvement Technology

. . . . . . . . . . . . . . . . . . . . . 62

Advanced Control - Black (Darkness) Level

. . . . . . .

Advanced Control - Eye Care

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Advanced Control - Real Cinema

. . . . . . . . . . . . . . . . . . . . . . 65

Picture Reset

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Power Indicator

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SOUND & LANGUAGE CONTROL

Auto Volume Leveler (Auto Volume) . . . . . . . . . . . . . . . . . 68

Preset Sound Settings (Sound Mode)

. . . . . . . . . . . . . . 69

Sound Setting Adjustment - User Mode

. . . . . . . . . . .

Clear Voice

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Balance

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TV Speakers On/Off Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Audio Reset

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Stereo/SAP Broadcast Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Audio Language

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

On-Screen Menus Language Selection

. . . . . . . . . . . . . . 77

Caption Mode

- Analog Broadcasting System Captions

. . . . . . .

- Digital Broadcasting System Captions

. . . . . . . .

- Caption Option

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

TIME SETTING

Clock Setting

- Auto Clock Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

- Manual Clock Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Auto On/Off Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Sleep Timer Setting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Auto Shut-off Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

PARENTAL CONTROL / RATINGS

Set Password & Lock System

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Channel Blocking

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Movie & TV Rating

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Downloadable Rating

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Input Blocking

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Key lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

APPENDIX

Troubleshooting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Maintenance

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 0

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

101

Programming the Remote Control

. . . . . . . . . . . . . . . . . 102

IR Codes

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

External Control Through RS-232C

. . . . . . . . . . . . . . . . .10 7

FEATURE OF THIS TV

is a trademark of SRS Labs, Inc.

TruSurround XT technology is incorporated under

license from SRS Labs, Inc.

Manufactured under license from Dolby Laboratories.

“

Dolby

“and the double-D symbol are trademarks of

Dolby Laboratories.

FOR LCD TV

■

If the TV feels cold to the touch, there may be a small “flicker” when it is turned on. This is normal, there is

nothing wrong with TV.

■

Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they

have no adverse effect on the monitor's performance.

■

Avoid touching the LCD screen or holding your finger(s) against it for long periods of time. Doing so may produce

some temporary distortion effects on the screen.

On Disposal (Only Hg lamp used LCD TV)

The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this product with

general household waste. Disposal of this product must be carried out in accordance to the regulations of your local

authority.

CALIBRATE LIKE A PRO: Sophisticated and detailed

calibrations can be made through the ISFccc mode.

Detailed calibration requires a licensed technician.

Please contact your local dealer to inquire about an

ISF certified technician.

PREPARATION

ACCESSORIES

Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the

dealer where you purchased the TV.

The accessories included may differ from the images below.

OOppttiioonn EExxttrraass

* Wipe spots on the exterior only with

the polishing cloth.

* Do not wipe roughly when removing

stain. Excessive pressure may cause

scratch or discoloration.

Polishing Cloth

(This feature is not available

for all models.)

D-sub 15 pin Cable

1.5V 1.5V

Owner’s Manual Power Cord

Remote Control,

Batteries

FAV

ENTER

123

456

CD Manual

When using the VGA (D-sub 15 pin

cable) PC connection, the user

must use shielded signal interface

cables with ferrite cores to maintain

standards compliance.

Protection Cover

Protective Bracket and Bolt for

Power Cord

(This feature is not available for all models.)

(Refer to P.14)

OOnnllyy 3377//4422LLGG55**

Bolts for stand assembly

(Refer to P.12)

Screw for stand fixing

(Refer to P.15)

x 4 x 4

PREPARATION

FRONT PANEL INFORMATION

PREPARATION

■

Image shown may differ from your TV.

■

NOTE: If your TV has a protection tape attached, remove the tape.

And then wipe the TV with a cloth (If a polishing cloth is included with your TV, use it).

POWER Button

Power/Standby Indicator

Illuminates red in standby mode.

Illuminates blue when the set is switched on.

(Can be adjusted using

PPoowweerr IInnddiiccaattoorr

the OPTION menu.

pp..6677

)

VOL

INPUT

ENTER

CHANNEL ( , )

Buttons

VOLUME (+, -)

Buttons

ENTER Button

MENU Button

INPUT Button

Intelligent Sensor

Adjusts picture according to the

surrounding conditions

Remote Control Sensor

PREPARATION

BACK PANEL INFORMATION

■

Image shown may differ from your TV.

AV IN 2

L/MONO

AUDIO

VIDEO

HDMI IN 3 USB IN

( )

RGB IN

COMPONENT IN

AUDIO

(RGB/DVI)

RGB(PC)

REMOTE

CONTROL IN

ANTENNA/

CABLE IN

RS-232C IN

(CONTROL & SERVICE)

VIDEO

AUDIO

OPTICAL COAXIAL

DIGITAL AUDIO OUT

AUDIO OUT

AV IN 1

HDMI/DVI IN

VIDEO

MONO

( )

AUDIO

S-VIDEO

( )

HDMI/DVI IN, HDMI IN

Digital Connection.

Supports HD video and Digital audio. Doesn’t

support 480i.

Accepts DVI video using an adapter or HDMI to

DVI cable (not included).

COMPONENT IN

Analog Connection.

Supports HD.

Uses a red, green, and blue cable for video & red

and white for audio.

RGB (PC)

Analog PC Connection. Uses a D-sub 15 pin cable

(VGA cable).

AUDIO (RGB/DVI)

1/8” headphone jack for analog PC audio input.

REMOTE CONTROL IN PORT

For a wired remote control.

RS-232C IN (CONTROL & SERVICE) PORT

Used by third party devices.

ANTENNA/CABLE IN

Connect over-the air signals to this jack.

Connect cable signals to this jack.

DIGITAL AUDIO OUT

Digital audio output for use with amps and home

theater systems.

Includes an optical and coaxial connection.

Note: In standby mode, these ports do not work.

AUDIO OUT

Analog audio output for use with amps and home

theater systems.

AV (Audio/Video) IN

Analog composite connection. Supports standard

definition video only (480i).

S-VIDEO

Better quality than standard composition.

Supports standard definition video only (480i).

USB INPUT

Used for viewing photos and listening to MP3s.

Power Cord Socket

For operation with AC power.

Caution: Never attempt to operate the TV on DC

power.

(Except

42/47/52LG50DC)

PREPARATION

STAND INSTRUCTION

PREPARATION

■

Image shown may differ from your TV.

Assemble the parts of the

SSTTAANNDD BBOODDYY

with

CCOOVVEERR BBAASSEE

of the TV.

Assemble the TV as shown.

Fix the 4 bolts securely using the holes in the

back of the TV.

SSTTAANNDD BBOODDYY

CCOOVVEERR BBAASSEE

Carefully place the TV screen side down on a cush-

ioned surface to protect the screen from damage.

INSTALLATION

(

Only 37/42LG5*)

DETACHMENT

Carefully place the TV screen side down on a

cushioned surface to protect the screen from

damage.

Loose the bolts from TV.

Detach the stand from TV.

After removing the stand, install the included

pprrootteeccttiioonn ccoovveerr

over the hole for the stand.

Press the

PPRROOTTEECCTTIIOONN CCOOVVEERR

into the TV

until you hear it click.

PROTECTION COVER

When assembling the desk type stand, make sure

the bolt is fully tightened (If not tightened fully,

the TV can tilt forward after the product installa-

tion). Do not over tighten.

NOTE

PREPARATION

VESA WALL MOUNTING

Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materials, please

contact your nearest dealer.

If installed on a ceiling or slanted wall, it may fall and result in severe personal injury.

We recommend that you use an LG brand wall mount when mounting the TV to a wall.

LG recommends that wall mounting be performed by a qualified professional installer.

Do not install your wall mount kit while your TV is turned on. It may result in personal injury due to electric

shock.

CAUTION

Screw length needed depends on the wall mount

used. For further information, refer to the instruc-

tions included with the mount.

Standard dimensions for wall mount kits are shown

in the table.

When purchasing our wall mount kit, a detailed

installation manual and all parts necessary for

assembly are provided.

Do not use screws longer then the standard dimen-

sion, as they may cause damage to the inside to

the TV.

For wall mounts that do not comply with the VESA

standard screw specifications, the length of the

screws may differ depending on their specifica-

tions.

Do not use screws that do not comply with the

VESA standard screw specifications.

Do not use fasten the screws too strongly, this may

damage the TV or cause the TV to a fall, leading to

personal injury. LG is not liable for these kinds of

accidents.

LG is not liable for TV damage or personal injury

when a non-VESA or non specified wall mount is

used or the consumer fails to follow the TV installa-

tion instructions.

NOTE

Product Model

VESA

Standard Screw Quantity

37LG5*

42LG5*

47LG5*

52LG5*

200

800

400

LCD TV

PREPARATION

CABLE MANAGEMENT

PREPARATION

Connect the cables as necessary.

To connect additional equipment, see the

EXTERNAL EQUIPMENT SETUP section.

Secure the power cable with the PROTECTIVE

BRACKET and the screw as shown. It will help

prevent the power cable from being removed

by accident.

Install the CABLE MANAGEMENT CLIP as

shown.

CABLE MANAGEMENT CLIP

PROTECTIVE BRACKET

(This featur

e is no

t available for all models.)

Put the cables inside the CABLE MANAGEMENT

CLIP and snap it closed.

■

Image shown may differ from your TV.

PREPARATION

DESKTOP PEDESTAL INSTALLATION

For proper ventilation, allow a clearance of 4 inches on all four sides from the wall.

■

Image shown may differ from your TV.

4 inches

SWIVEL STAND

After installing the TV, you can adjust the TV set manually to the left or right direction by 20 degrees to suit

your viewing position.

Ensure adequate ventilation by following the clearance recommendations.

Do not mount near or above any type of heat source.

CAUTION

ATTACHING THE TV TO A DESK (Only 37/42LG5*)

The TV must be attached to a desk so it cannot be pulled in a forward/backward direction, potentially causing

injury or damaging the product.

To prevent TV from falling over, the TV should be securely attached to the floor/wall per installation

instructions. Tipping, shaking, or rocking the machine may cause injury.

WARNING

1-Screw

(provided as parts of the product)

Desk

Stand

We recommend that you set up the TV close to a wall so it cannot fall over if pushed backwards.

Additionally, we recommend that the TV be attached to a wall so it cannot be pulled in a forward direction,

potentially causing injury or damaging the product.

Caution: Please make sure that children don’t climb on or hang from the TV.

■

Insert the eye-bolts (or TV brackets and bolts) to tighten the product to the wall as shown in the picture.

*If your product has the bolts in the eye-bolts position before inserting the eye-bolts, loosen the bolts.

* Insert the eye-bolts or TV brackets/bolts and tighten them securely in the upper holes.

Secure the wall brackets with the bolts (sold separately) to the wall. Match the height of the bracket that is

mounted on the wall to the holes in the product.

Ensure the eye-bolts or brackets are tightened securely.

■

Use a sturdy rope (sold separately) to tie the product. It is safer to tie

the rope so it becomes horizontal between the wall and the product.

■

You should purchase necessary components to prevent TV from falling off of the stand.

■

Image shown may differ from your TV.

Use a platform or cabinet strong enough and large enough to support the size and weight of the TV.

To use the TV safely make sure that the height of the bracket on the wall and the one on the TV are the same.

NOTE

PREPARATION

SECURING THE TV TO THE WALL TO PREVENT FALLING

WHEN THE TV IS USED ON A STAND

PREPARATION

ANTENNA OR CABLE CONNECTION

1. Antenna (Analog or Digital)

Wall Antenna Socket or Outdoor Antenna without a Cable Box

Connection.

For optimum picture quality, adjust the antenna direction if needed.

2. Cable

Wall

Antenna

Socket

Outdoor

Antenna

(VHF, UHF)

Cable TV

Wall Jack

Multi-family Dwellings/Apartments

(Connect to wall antenna socket)

RF Coaxial Wire (75 ohm)

Single-family Dwellings /Houses

(Connect to wall jack for outdoor antenna)

Be careful not to bend the copper wire

when connecting the antenna.

Copper Wire

■

To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.

■

If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.

■

If the antenna is not installed properly, contact your dealer for assistance.

ANTENNA/

CABLE IN

( )

ANTENNA/

CABLE IN

( )

■

To prevent damage do not connect to the power outlet until all connections are made between the devices.

EXTERNAL EQUIPMENT SETUP

HD RECEIVER SETUP

EXTERNAL EQUIPMENT SETUP

This TV can receive digital over-the-air/digital cable signals without an external digital set-top box. However, if

you do receive digital signals from a digital set-top box or other digital external device.

Component Connection

1. How to connect

Connect the video outputs

(

Y, P

B, P

)

of the digital set-

top box to the

CCOOMMPPOONNEENNTT IINN VVIIDDEEOO 11

jacks on

the TV. Match the jack colors (Y = green, P

= blue, and

= red).

Connect the audio output of the digital set-top box to

the

CCOOMMPPOONNEENNTT IINN AAUUDDIIOO 11

jacks on the TV.

2. How to use

■

Turn on the digital set-top box.

(

Refer to the owner’s manual for the digital set-top box. operation

)

■

Select the

CCoommppoonneenntt 11

input source on the TV using

the

IINNPPUUTT

button on the remote control.

■

If connected to

CCOOMMPPOONNEENNTT IINN22

input, select the

CCoommppoonneenntt 22

input source on the TV.

■

To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.

■

Image shown may differ from your TV.

Y, C

B, CR/

Supported Resolutions

Horizontal Vertical

Frequency

(

KHz

)

Frequency

(

)

15.73 59.94

15.73 60.00

31.47 59.94

31.50 60.00

44.96 59.94

45.00 60.00

33.72 59.94

33.75 60.00

26.97 23.976

27.00 24.00

33.71 29.97

33.75 30.00

67.432 59.94

67.50 60.00

Resolution

720x480i

720x480p

1280x720p

1920x1080i

1920x1080p

Signal

480i

480p

720p

1080 i

1080 p

Component

Yes

HDMI

Yes

RGB IN

AUDIO

(RGB/DVI)

RGB(PC)

REMOTE

CONTROL

DVI IN

COMPONENT IN

VIDEO

LYP

AUDIO

Y L RPB PR

EXTERNAL EQUIPMENT SETUP

HDMI Connection

Connect the digital set-top box to

HHDDMMII//DDVVII IINN11

, or

* jack on the TV.

No separate audio connection is necessary.

HDMI supports both audio and video.

1. How to connect

2. How to use

■

Turn on the digital set-top box.

(

Refer to the owner’s manual for the digital set-top box.

)

■

Select the

HHDDMMII11

HHDDMMII22

,or

HHDDMMII33

* input source on the

TV using the

IINNPPUUTT

button on the remote control.

HDMI-DTV

Horizontal Vertical

Frequency

(

KHz

)

Frequency

(

)

31.47 59.94

31.50 60.00

44.96 59.94

45.00 60.00

33.72 59.94

33.75 60.00

26.97 23.976

27.00 24.00

33.71 29.97

33.75 30.00

67.432 59.939

67.50 60.00

Resolution

720x480p

1280x720p

1920x1080i

1920x1080p

RGB IN

COMPONENT

(RG

RGB(PC)

VIDEO

HDMI/DVI IN

HDMI-DTV OUTPUT

* HDMI 3: Except 42/47/52LG50DC

EXTERNAL EQUIPMENT SETUP

Connect the DVI output of the digital set-top box to

the

HHDDMMII//DDVVII IINN 11

, or

* jack on the TV.

Connect the PC audio output to the

AAUUDDIIOO

((

RRGGBB//DDVVII

))

jack on the TV.

1. How to connect

2. How to use

■

Turn on the digital set-top box.

(

Refer to the owner’s manu-

al for the digital set-top box.

)

■

Select the

HHDDMMII11

HHDDMMII22

,or

HHDDMMII33

* input source on the

TV using the

IINNPPUUTT

button on the remote control.

DVI to HDMI Connection

A DVI to HDMI cable or adapter is required for this

connection. DVI doesn't support audio, so a separate

audio connection is necessary.

NOTE

RGB IN

COMPONENT IN

AUDIO

(RGB/DVI)

RGB(PC)

REMO

CONTRO

VIDEO

LYP

B PR R

AUDIO

HDMI/DVI IN

L R

DVI-DTV OUTPUT

* HDMI 3: Except 42/47/52LG50DC

EXTERNAL EQUIPMENT SETUP

DVD SETUP

Component Connection

Component Input ports

To get better picture quality, connect a DVD player to the component input ports as shown below.

Component ports on the TV

Video output ports

on DVD player

B-Y

R-Y

Connect the video outputs

(

Y, P

B, P

)

of the DVD to the

CCOOMMPPOONNEENNTT IINN VVIIDDEEOO11

jacks on the TV.

Match the jack colors

(

Y = green, P

B = blue, and PR

= red

)

Connect the audio outputs of the DVD to the

CCOOMMPPOONNEENNTT IINN AAUUDDIIOO11

jacks on the TV.

1. How to connect

2. How to use

■

Turn on the DVD player, insert a DVD.

■

Select the

CCoommppoonneenntt 11

input source on the TV using

the

IINNPPUUTT

button on the remote control.

■

If connected to

CCOOMMPPOONNEENNTT IINN 22

input, select the

CCoommppoonneenntt 22

input source on the TV.

■

Refer to the DVD player's manual for operating instructions.

RGB IN

AUDIO

(RGB/DVI)

RGB(PC)

REMOT

CONTROL

(

VI IN

COMPONENT IN

VIDEO

LYP

AUDIO

Y L RPB PR

1 2

EXTERNAL EQUIPMENT SETUP

S-Video Connection

DIO

B/DVI)

REMOTE

CONTROL IN

ANTENNA/

CABLE IN

RS-232C IN

(CONTROL & SERVICE)

L R

AUDIO

OPTICAL COAXIAL

DIGITAL AUDIO OUT

L R

S-VIDEO

AUDIO

AUDIO OUT

AV IN 1

VIDEO LR

(MONO)

AUDIO

S-VIDEO

Connect the S-VIDEO output of the DVD to the

SS --VVIIDDEEOO

input on the TV.

Connect the audio outputs of the DVD to the

AAUUDDIIOO

input jacks on the TV.

1. How to connect

2. How to use

■

Turn on the DVD player, insert a DVD.

■

Select the

AAVV11

input source on the TV using the

IINNPPUUTT

button on the remote control.

■

Refer to the DVD player's manual for operating instructions.

HDMI Connection

Connect the HDMI output of the DVD to the

HHDDMMII//DDVVII IINN11

, or

* jack on the TV.

No separate audio connection is necessary.

HDMI supports both audio and video.

1. How to connect

2. How to use

■

Select the

HHDDMMII11

HHDDMMII22

, or

HHDDMMII33

* input source on

the TV using the

IINNPPUUTT

button on the remote control.

■

Refer to the DVD player's manual for operating instructions.

COMPONENT IN

AUDIO

(RGB/D

RGB(PC)

VIDEO

LYP

HDMI/DVI IN

HDMI-DVD OUTPUT

* HDMI 3: Except 42/47/52LG50DC

EXTERNAL EQUIPMENT SETUP

VCR SETUP

Antenna Connection

■

To avoid picture noise

(

interference

)

, leave an adequate distance between the VCR and TV.

■

If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible on the screen.

This phenomenon is common to all TVs and is not covered by warranty.

ANTENNA/

CABLE IN

COAXIAL

UDIO OUT

L R

S-VIDEO VIDEO

OUTPUT

SWITCH

ANT IN

ANT OUT

EO L R

(MONO)

AUDIO

AUDIO OUT

Wall Jack

Antenna

Connect the RF antenna out socket of the

VCR to the

AANNTTEENNNNAA//CCAABBLLEE IINN

sock-

et on the TV.

Connect the antenna cable to the RF

antenna in socket of the VCR.

1. How to connect

2. How to use

■

Set VCR output switch to 3 or 4 and then

tune TV to the same channel number.

■

Insert a video tape into the VCR and press

PLAY on the VCR.

(

Refer to the VCR owner’s

manual.

)

EXTERNAL EQUIPMENT SETUP

Composite (RCA) Connection

If you have a mono VCR, connect the audio cable from

the VCR to the

AAUUDDIIOO LL//MMOONNOO

jack of the TV.

NOTE

NT IN

AUDIO

(RGB/DVI)

REMOTE

CONTROL IN

ANTENNA/

CABLE IN

RS-232C IN

(CONTROL & SERVICE)

L R

AUDIO

OPTICAL COAXIAL

DIGITAL AUDIO OUT

AV IN 1

VIDEO L R

(MONO)

AUDIO

S-VIDEO

AUDIO OUT

L R

S-VIDEO VIDEO

OUTPUT

SWITCH

ANT IN

ANT OUT

Connect the

AAUUDDIIOO

VVIIDDEEOO

jacks between TV and

VCR. Match the jack colors (Video = yellow, Audio Left

= white, and Audio Right = red)

1. How to connect

2. How to use

■

Insert a video tape into the VCR and press PLAY on the VCR.

(

Refer to the VCR owner’s manual.

)

■

Select the

AAVV11

input source on the TV using the

IINNPPUUTT

button on the remote control.

■

If connected to

AAVV IINN22

, select

AAVV22

input source on the TV.

Do not connect to both Video and S-Video at the same

time. In the event that you connect both Video and the

S-Video cables, only the S-Video will work.

CAUTION

S-Video provides better quality

than composite. Use it when

available.

NOTE

S-Video Connection

NT IN

AUDIO

(RGB/DVI)

REMOTE

CONTROL IN

ANTENNA/

CABLE IN

RS-232C IN

(CONTROL & SERVICE)

L R

AUDIO

OPTICAL COAXIAL

DIGITAL AUDIO OUT

AV IN 1

VIDEO LR

(MONO)

AUDIO

S-VIDEO

AUDIO OUT

L R

S-VIDEO VIDEO

OUTPUT

SWITCH

ANT IN

ANT OUT

Connect the S-VIDEO output of the VCR to the

SS --VVIIDDEEOO

input on the TV.

Connect the audio outputs of the VCR to the

AAUUDDIIOO

input jacks on the TV.

1. How to connect

2. How to use

■

Insert a video tape into the VCR and press PLAY on the VCR.

(

Refer to the VCR owner’s manual.

)

■

Select the

AAVV11

input source on the TV using the

IINNPPUUTT

button on the remote control.

EXTERNAL EQUIPMENT SETUP

OTHER A/V SOURCE SETUP

AV IN 2

L/MONO

AUDIO

VIDEO

HDMI IN 3 USB IN

L R

VIDEO

Camcorder

Video Game Set

Connect the

AAUUDDIIOO

VVIIDDEEOO

jacks

between TV and external equipment.

Match the jack colors

(

Video = yellow, Audio Left = white, and

Audio Right = red

)

1. How to connect

2. How to use

■

Select the

AAVV22

input source on the TV using

the

IINNPPUUTT

button on the remote control.

■

If connected to

AAVV IINN11

input, select the

AAVV11

input source on the TV.

■

Operate the corresponding external equipment.

EXTERNAL EQUIPMENT SETUP

PC SETUP

EXTERNAL EQUIPMENT SETUP

This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.

VGA (D-Sub 15 pin) Connection

COMPONENT IN

REMOT

CONTROL

(

VIDEO

LYP

AUDIO

DVI IN

RGB IN

AUDIO

(RGB/DVI)

RGB(PC)

RGB OUTPUT

AUDIO

Connect the VGA output of the PC to the

RRGGBB

((

PPCC

))

jack on the TV.

Connect the PC audio output to the

AAUUDDIIOO

((

RRGGBB//DDVVII

))

jack on the TV.

1. How to connect

2. How to use

■

Turn on the PC and the TV.

■

Select the

RRGGBB--PPCC

input source on the TV using the

IINNPPUUTT

button on the remote control.

DVI to HDMI Connection

Connect the DVI output of the PC to the

HHDDMMII//DDVVII

IINN 11

, or

* jack on the TV.

Connect the PC audio output to the

AAUUDDIIOO

((RRGGBB//DDVVII))

jack on the TV.

1. How to connect

2. How to use

■

Turn on the PC and the TV.

■

Select the

HHDDMMII11

HHDDMMII22

, or

HHDDMMII33

* input source on

the TV using the

IINNPPUUTT

button on the remote control.

COMPONENT IN

VIDEO

LYP

AUDIO

HDMI/DVI IN

RGB IN

AUDIO

(RGB/DVI)

RGB(PC)

DVI-PC OUTPUT

AUDIO

* HDMI 3: Except 42/47/52LG50DC

EXTERNAL EQUIPMENT SETUP

Supported Display Specifications (RGB-PC, HDMI-PC)

Resolution

720x400

640x350

640x480

1920x1080

HDMI-PC

Horizontal Vertical

Frequency

(

KHz

)

Frequency

(

)

31.468 70.09

31.469 70.08

31.469 59.94

35.156 56.25

37.879 60.31

48.363 60.00

56.476 70.06

47.776 59.87

63.981 60.02

47.712 60.015

75.00 60.00

66.587 59.934

67.5 60.00

To get the the best picture quality, adjust the PC

graphics card to 1920x1080.

Depending on the graphics card, DOS mode may

not work if a HDMI to DVI Cable is in use.

In PC mode, there may be noise associated with

the resolution, vertical pattern, contrast or bright-

ness. If noise is present, change the PC output to

another resolution, change the refresh rate to

another rate or adjust the brightness and contrast

on the PICTURE menu until the picture is clear.

Avoid keeping a fixed image on the screen for a

long period of time. The fixed image could

become permanently imprinted on the screen.

The synchronization input form for Horizontal and

Vertical frequencies is separate.

Depending on the graphics card, some resolution

settings may not allow the image to be posi-

tioned on the screen properly.

If there are overscan in HDMI-PC 1920x1080,

change aspect ratio to

JJuusstt ssccaann

NOTES

800x600

1024x768

1280x768

1280x1024

1360x768

1600x1200

1920x1080

RGB-PC

EXTERNAL EQUIPMENT SETUP

Screen Setup for PC mode

Selecting Resolution

You can choose the resolution in RGB-PC mode.

The

PPoossiittiioonn

PPhhaassee

, and

SSiizzee

can also be adjusted.

Select

PPIICCTTUURREE

Select

SSccrreeeenn ((RRGGBB--PPCC))

Select

RReessoolluuttiioonn

Select the desired resolution.

1024 x 768

1280 x 768

1360 x 768

Auto config.

Resolution

Position

Size

Phase

Reset

SCREEN

Move

Prev.

ENTER

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

EXTERNAL EQUIPMENT SETUP

Auto Configure

Automatically adjusts picture position and minimizes image instability. After adjustment, if the image is still

not correct, try using the manual settings or a different resolution or refresh rate on the PC.

Select

SSccrreeeenn ((RRGGBB--PPCC))

Select

AAuuttoo ccoonnffiigg..

Auto config.

Resolution

Position

Size

Phase

Reset

SCREEN

Move

Prev.

To Set

ENTER

Select

YYeess

ENTER

Start Auto Configuration.

ENTER

Select

PPIICCTTUURREE

• If the position of the image is still not

correct, try Auto adjustment again.

• If picture needs to be adjusted again

after Auto adjustment in RGB-PC, you

can adjust the

PPoossiittiioonn

SSiizz ee

PPhhaassee

Yes No

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

EXTERNAL EQUIPMENT SETUP

Adjustment for screen Position, Size, and Phase

If the picture is not clear after auto adjustment and especially if characters are still trembling, adjust the picture

phase manually.

This feature operates only in RGB-PC mode.

Select

PPoossiittiioonn

SSiizzee

, or

PPhhaassee

Make appropriate adjustments.

Auto config.

Resolution

Position

Size

Phase

Reset

SCREEN

Move

Prev.

ENTER

■

PPoossiittiioonn

: This function is to adjust pic-

ture to left/right and up/down as you

prefer.

■

SSiizzee

: This function is to minimize any

vertical bars or stripes visible on the

screen background. And the horizontal

screen size will also change.

■

PPhhaassee

: This function allows you to

remove any horizontal noise and clear or

sharpen the image of characters.

Select

PPIICCTTUURREE

Select

SSccrreeeenn ((RRGGBB--PPCC))

ENTER

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

EXTERNAL EQUIPMENT SETUP

Screen Reset (Reset to original factory values)

Returns

PPoossiittiioonn

SSiizzee

, and

PPhhaassee

to the default factory settings.

This feature operates only in RGB-PC mode.

Auto config.

Position

Resolution

Size

Phase

Reset

SCREEN

Move

Prev.

To Set

Select

RReesseett

ENTER

Select

PPIICCTTUURREE

Select

SSccrreeeenn ((RRGGBB--PPCC))

ENTER

Select

YYeess

ENTER

Yes No

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

EXTERNAL EQUIPMENT SETUP

USB CONNECTION

EXTERNAL EQUIPMENT SETUP

AV IN 2

L/MONO

AUDIO

VIDEO

HDMI IN 3 USB IN

Connect the USB device to the

UUSSBB IINN

jack on the side

of TV.

1. How to connect

2. How to use

■

After connecting the

UUSSBB IINN

jack, you use the USB function.

(

pp..4488

)

(Except 42/47/52LG50DC)

EXTERNAL EQUIPMENT SETUP

AUDIO OUT CONNECTION

Send the TV’s audio to external audio equipment via the Audio Output port.

GB/DVI)

RS-232C IN

(CONTROL & SERVICE)

L R

AUDIO

L R

AUDIO

AUDIO OUT

AV IN 1

VIDEO L R

(MONO)

AUDIO

S-VIDEO

DVI)

REMOTE

CONTROL IN

ANTENNA/

CABLE IN

RS-232C IN

(CONTROL & SERVICE)

AUDIO

OPTICAL COAXIAL

DIGITAL AUDIO OUT

AV IN 1

VIDEO L R

(MONO)

AUDIO

S-VIDEO

AUDIO OUT

When connecting with external audio equipments, such as

amplifiers or speakers, you can turn the TV speakers off in

the menu. (

pp..7733

)

NOTE

Do not look into the optical output port. Looking at the

laser beam may damage your vision.

Block the SPDIF out (optical/coaxial) about the contents

with ACP(Audio Copy Protection) function.

CAUTION

Connect one end of the optical or coaxial cable to the

TV’s

OOPPTTIICCAALL

CCOOAAXXIIAALL

port of

DDIIGGIITTAALL AAUUDDIIOO

OOUUTT

Connect the other end of the optical or coaxial cable to

the digital audio input on the audio equipment.

Set the “TV Speaker option - Off” in the AUDIO menu. (

pp..7733

). See the external audio equipment instruction man-

ual for operation.

1. How to connect

Connect audio outputs to the TV’s

AAUUDDIIOO OOUUTT

jacks.

Set the “TV Speaker option - Off” in the AUDIO menu.

(

pp..7733

). See the external audio equipment instruction

manual for operation.

1. How to connect

Analog

Digital

WATCHING TV / CHANNEL CONTROL

REMOTE CONTROL FUNCTIONS

WATCHING TV / CHANNEL CONTROL

When using the remote control, aim it at the remote control sensor on the TV.

INPUT

FAV

MUTE

STB

POWER

Q. MENU MENU

AV MODERETURN

ENTER

VOL

123

456

FLASHBK

DVD

VCR

TV/STB/DVD/VCR

POWER

Q.MENU

INPUT

VOLUME UP

/DOWN

FAV

MUTE

CHANNEL

UP/DOWN

PAGE

UP/DOWN

— (DASH)

FLASHBK

Select the remote operating mode: TV, STB, DVD, or VCR.

Turns your TV or any other programmed equipment on or

off, depending on the mode.

Select the desired quick menu source.

pp..3377

Displays the main menu.

Clear all on-screen displays and return to TV viewing from

any menu.

External input modes rotate in regular sequence.

Increase/decrease the sound level.

Scroll through the programmed Favorite channels.

pp..3377

Switch the sound on or off.

pp..3366

Select available channels.

Move from one full set of screen information to the next one.

Used to enter a program number for multiple

program channels such as 2-1, 2-2, etc.

Tune to the last channel viewed.

Control video cassette recorders or DVD players.

Control USB menu (Photo List and Music List.)

Control the SIMPLINK compatible devices.

NUMBER button

VCR/DVD, USB,

SIMPLINK

Control buttons

WATCHING TV / CHANNEL CONTROL

Installing Batteries

■

Open the battery compartment cover on the back side and install

the batteries matching correct polarity

(

+with +,-with -

)

■

Install two 1.5V AAA batteries. Don’t mix old or used batteries with

new ones.

■

Close cover.

THUMBSTICK

(Up/Down/Left

Right/ENTER)

RETURN

SIMPLINK

AV MODE

Navigate the on-screen menus and adjust the system settings to your preference.

Allows the user to move return one step in an interactive application or other user interaction

function.

See a list of AV devices connected to TV.

When you toggle this button, the SIMPLINK menu appears at the screen.

pp..4466--4477

It helps you select and set images and sounds.

pp..4455

WATCHING TV / CHANNEL CONTROL

TURNING ON THE TV

WATCHING TV / CHANNEL CONTROL

NOTE

If you intend to be away on vacation, disconnect the power plug from the wall power outlet.

First, connect power cord correctly.

At this moment, the TV switches to standby mode.

■

In standby mode to turn TV on, press the ,

IINNPPUUTT

CCHH (( ))

button

on the TV or press the

PPOOWWEERR

IINNPPUUTT

CCHH((

))

NNuummbbeerr ((00

99))

but-

ton on the remote control.

Select the viewing source by using the

IINNPPUUTT

button on the remote control.

■

This TV is programmed to remember which power state it was last set to,

even if the power cord is out.

When finished using the TV, press the

PPOOWWEERR

button on the remote control.

The TV reverts to standby mode.

Press the

CCHH ((

))

NNUUMMBBEERR

buttons to select a channel number.

VOLUME ADJUSTMENT

CHANNEL SELECTION

Press the

VVOOLL ((++

--))

button to adjust the volume.

If you want to switch the sound off, press the

MMUUTTEE

button.

You can cancel the Mute function by pressing the

MMUUTTEE

VVOOLL ((++

--))

button.

Adjust the volume to suit your personal preference.

WATCHING TV / CHANNEL CONTROL

QUICK MENU / FAVORITE CHANNEL SETUP

Display each menu.

Make appropriate adjustments.

■

AAssppeecctt RRaattiioo

: Selects your desired picture format.

■

BBaacckklliigghhtt

: Adjust the brightness of LCD panel to

control the brightness of the screen.

■

CClleeaarr VVooiiccee

: By differentiating the human sound

range from others, it helps make human voices

sound better.

■

PPiiccttuurree MMooddee

: Selects the factory preset picture

depend on the viewing environment.

■

SSoouunndd MMooddee

: Selects the factory preset sound for

type of program.

■

CCaappttiioonn

: Select on or off.

■

MMuullttii AAuuddiioo

: Changes the audio language (Digital

signal).

SSAAPP

: Selects MTS sound (Analog signal).

■

SSlleeeepp TTiimmeerr

: Select the amount of time before

your TV turns off automatically.

■

DDeell//AAdddd//FFaavv

: Select channel you want to add/delete

or add the channel to the Favorite List.

■

UUSSBB EEjjeecctt

: Select “USB Eject” in order to eject

USB device.

Your TV's OSD (On Screen Display) may differ slightly from what is shown in this manual.

Q.Menu (Quick Menu) is a menu of features which users might use frequently.

Q. MENU

Q.Menu

16:9

Vivid

Off

Standard

Off

English

Off

Add

Eject

Aspect Ratio

Backlight

Clear Voice

Picture Mode

Sound Mode

Caption

Multi Audio

Sleep Timer

Del/Add/Fav

USB Eject

Q. MENU

Return to TV viewing.

Favorite Channle Setup

Select

DDeell//AAdddd//FFaavv

■

To tune to a favorite channel, press the

FFAAVV

(Favorite) button repeatedly.

Q. MENU

456

Select your desired channel.or

Select

FFaavvoorriittee

Q. MENU

Return to TV viewing.

WATCHING TV / CHANNEL CONTROL

INITIAL SETTING

WATCHING TV / CHANNEL CONTROL

This Function guides the user to easily set the essential items for viewing the TV for the first time when

purchasing the TV. It will be displayed on the screen when turning the TV on for the first time. It can also be

activated from the user menus.

Select

HHoommee

Mode.

ENTER

Select

AAuuttoo

MMaannuuaall

Select desired time option.

ENTER

Year

Current Time Setting

2007

Month

Date

Hour

5 PM

Minute

Time Zone

Eastern

Daylight Saving

Off

Auto

ExitEnter

RETURN

Step2. Time Setting

Selecting the environment.

Choose the setting mode you want.

In Store

Home

ExitEnter

RETURN

Step1. Mode Setting

Step2. Time Setting

■

Default selection is “

HHoommee

”. We recommend setting the TV to “

HHoommee

” mode for the best picture in your

home environment.

■

“

IInn--ssttoorree

” Mode is only intended for use in retail environments. Customers can adjust the “

PPiiccttuurree

PPiiccttuurree mmooddee

” manually while inspecting the TV, but the TV will automatically return to preset in-store

mode after 5 minutes.

Select

OOSSDD LLaanngguuaaggee SSeettttiinngg

AAuuddiioo LLaanngguuaaggee SSeettttiinngg

Start

AAuuttoo TTuunniinngg

Select your desired language.

ENTER

Auto Tuning can change channel map.

Do you want to start Auto Tuning?

Enter

Exit

Enter

RETURN

Step4. Auto Tuning

ExitEnter

RETURN

Step3. Option Setting

1. OSD Language Setting

English

2. Audio Language Setting

French

Step3. Option Setting

Step4. Auto Tuning

■

You can also adjust

IInniittiiaall SSeettttiinngg

in the

OOPPTTIIOONN

NOTE

WATCHING TV / CHANNEL CONTROL

ON-SCREEN MENUS SELECTION

Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual.

Display each menu.

Select a menu item.

Enter to the pop up menu.

ENTER

Return to TV viewing.

CHANNEL

OPTION


LOCK

AUDIO

INPUT

TIME

USB

Enter

Move

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

AUDIO

Enter

Move

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

TIME

Enter

Move

Photo List

Music List

USB

Enter

Move

Antenna

Cable

AV1

AV2

Component1

Component2

RGB-PC

HDMI1

HDMI2

INPUT

Enter

Move

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Enter

Move

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

OPTION

For USA For Canada

Enter

Move

Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control


Enter

Move

Auto Tuning

Manual Tuning

Channel Edit

CHANNEL

WATCHING TV / CHANNEL CONTROL

CHANNEL SETUP

WATCHING TV / CHANNEL CONTROL

Auto Scan (Auto Tuning)

Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the

channel list.

Run Auto Tuning again after any Antenna/Cable connection changes.

Select

CCHHAANNNNEELL

Select

AAuuttoo TTuunniinngg

Select

YYeess

Run

AAuuttoo ttuunniinngg

ENTER

■

A password is required to gain access to

Auto Tuning menu if the Lock System is

turned on.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Press ‘Yes’ button to begin

auto tuning.

Yes

WATCHING TV / CHANNEL CONTROL

Select

CCHHAANNNNEELL

ENTER

If selecting DTV or CADTV input signal, you can view the on-screen signal strength monitor to see the quality

of the signal being received.

Add/Delete Channel (Manual Tuning)

Select

MMaannuuaall TTuunniinngg

Select

DDTTVV

TT VV

CCAADDTTVV

, or

CCAATTVV

Select channel you want to add

or delete.

ENTER

Select

AAdddd

DDeelleettee

ENTER

■

A password is required to gain access to

Manual Tuning menu if the Lock System

is turned on.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

Channel

Select channel type and

RF-channel number.

DTV

Delete

DTV 2-1

Bad Normal Good

WATCHING TV / CHANNEL CONTROL

CHANNEL SETUP

WATCHING TV / CHANNEL CONTROL

Select a channel.

Select channel you want to add or

delete.

ENTER

A custom list can be created by toggling each channel on or off with ENTER button. The channels in the Custom

List are displayed in black and the channels deleted from the Custom List are displayed in gray.

Once a channel is highlighted you can add or delete the channel by referring to the small window at the top-

right corner of the screen.

Channel Editing

Select

CCHHAANNNNEELL

ENTER

Select

CChhaannnneell EEddiitt

RETURN

Return to TV viewing.

Return to the previous menu.

Add/Delete

Move Page

Move

Exit

RETURN

Enter

Move

CHANNEL

Auto Tuning

Manual Tuning

Channel Edit

WATCHING TV / CHANNEL CONTROL

INPUT LIST

Only these input signals which are connected to a TV can be activated and selected.

Select the desired input source.

■

You can also select the desired input source in the

IINNPPUUTT

menu.

INPUT

Antenna Cable AV1 AV2 Component1

HDMI3 HDMI2 HDMI1 RGB-PC

Component2

Antenna Cable AV1 AV2 Component1

ENTER

■

AAnntteennnnaa

: Select it to watch over-the-air broadcasts.

■

CCaabbllee

: Select it to watch cable and digital cable.

■

AAVV

: Select them to watch a VCR or other external equipment.

■

CCoommppoonneenntt

: Select them to watch DVD or a Digital set-top box.

■

RRGGBB--PPCC

: Select it to view PC input.

■

HHDDMMII

: Select them to watch high definition devices.

Antenna Cable AV1 AV2 Component1

Input Label

Q.MENU

Exit

RETURN

Select a desired input source (except

AAnntteennnnaa

CCaabbllee

). Then, you can select

your desired Input Label with using Q. MENU

button.

pp..4444

Disconnected inputs are inactive (grayed out)

Except 42/47/52LG50DC

WATCHING TV / CHANNEL CONTROL

INPUT LABEL

WATCHING TV / CHANNEL CONTROL

You can set a label for each input source when it's not in use.

Select

OOPPTTIIOONN

Select

IInnppuutt LLaabbeell

Select the label.

ENTER

Select the source.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

With using OPTION menu

Select the source.

Select the label.

INPUT

Q. MENU

RETURN

Return to the previous menu.

Return to TV viewing.

With using INPUT button

■

When new external device is connected, this popup menu is displayed automatically.

If selecting

YYeess

, you can select input source that you want to appreciate.

■

But, when selecting “

SSIIMMPPLLIINNKK

OO nn

”, popup menu for HDMI input will not be displayed.

Yes

New external device is connected.

Do you want to enjoy this?

Select input source that you want to appreciate.

AV1

AV2

Component1

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

AV1

FF GG

AV2

Component1

HDMI1

RGB-PC

Component2

HDMI2

HDMI3

Except

42/47/52LG50DC

WATCHING TV / CHANNEL CONTROL

AV MODE

You can select the optimal images and sounds.

AV MODE

Off Cinema

Game Sport

Press the

AAVV MMOODDEE

button repeatedly to select the desired source.

ENTER

■

If you select “

CCiinneemmaa

” in AV mode,

CCiinneemmaa

will be selected both for “PIC-

TURE menu - Picture Mode” and “AUDIO

menu - Sound Mode” respectively.

■

If you select “

OOffff

” in AV mode, the

“

PPiiccttuurree MMooddee

” and “

SSoouunndd MMooddee

”

return to previous selected value.

WATCHING TV / CHANNEL CONTROL

This function operates only with devices with the logo.

The TV might not function properly when using it with other products with HDMI-CEC function.

This allows you to control and play other AV devices connected with HDMI cable without additional cables and

settings.

To start using SIMPLINK, turn it on in the user menus.

Select

OOPPTTIIOONN

Select

SSIIMMPPLLIINNKK

Select

OOnn

OOffff

ENTER

NOTE

Connect the HDMI/DVI IN or HDMI IN terminal of the TV to the rear terminal (HDMI terminal) of the

SIMPLINK device with the HDMI cable.

When you switch the Input source with the INPUT button on the remote control, the SIMPLINK device

will stop.

When you select a device with home theater functionality, the sound output automatically switches to

the home theater speakers.

If a connected SIMPLINK home theater system doesn't play the audio from the TV, connect the DIGITAL

AUDIO OUT terminal on the back of the TV to the DIGITAL AUDIO IN terminal on the back of the SIM-

PLINK device with an OPTICAL cable.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Off

WATCHING TV / CHANNEL CONTROL

■

DDiirreecctt PPllaayy::

After connecting AV devices to the TV, you can directly control the devices and play media with-

out additional settings.

■

SSeelleecctt AAVV ddeevviiccee::

Enables you to select one of the AV devices connected to TV.

■

DDiisscc ppllaayybbaacckk::

Control connected AV devices by pressing the ,

ENTER,

ll ll

and

buttons.

■

PPoowweerr ooffff aallll ddeevviicceess::

When you power off the TV, all connected devices are turned off.

■

SSwwiittcchh aauuddiioo--oouutt::

Offers an easy way to switch audio-out.

■

SSyynncc PPoowweerr oonn::

When you play the connected AV device, TV will automatically turn on.

(A device, which is connected to the TV through a HDMI cable but does not support SIMPLINK, does not provide

this function)

SIMPLINK Menu

TTVV vviieewwiinngg

: Switch to the previous TV

channel regardless of the current mode.

DDIISSCC ppllaayybbaacckk

: Select and play discs.

When multiple discs are available, the titles

of discs are conveniently displayed at the

bottom of the screen.

VVCCRR ppllaayybbaacckk

: Control the connected

VCR.

HHDDDD RReeccoorrddiinnggss ppllaayybbaacckk

: Control

recordings stored in HDD.

AAuuddiioo OOuutt ttoo HHoommee TThheeaatteerr ssppeeaakk--

eerr//AAuuddiioo OOuutt ttoo TTVV

: Select Home

Theater speaker or TV speaker for Audio

Out.

SIMPLINK Functions

When no device is connected

(displayed in gray)

Selected Device

When a device is connected

(displayed in bright color)

Display

SSIIMMPPLLIINNKK

menu.

Select the desired device.

Control connected AV devices.

ENTER

USB

ENTRY MODES

When you connect a USB device, this screen is displayed automatically.

In USB device, you can not add a new folder or delete the existing folder.

Precautions when using the USB device

Only a USB storage device is recognizable.

If the USB storage device is connected through a

USB hub, the device is not recognizable.

A USB storage device using an automatic recogni-

tion program may not be recognized.

A USB storage device which uses its own driver

may not be recognized.

USB multi-card reader or USB hard drive may not

operate smoothly or may not operate at all.

The recognition speed of a USB storage device

may depend on each device.

Please do not turn off the TV or unplug the USB

device when the connected USB storage device is

working. When such device is suddenly separated

or unplugged, the stored files or the USB storage

device may be damaged.

Please do not connect the USB storage device

which was artificially maneuvered on the PC. The

device may cause the product to malfunction or

fail to be played. Never forget to use only a USB

storage device which has normal music files or

image files.

Please use only a USB storage device which was

formatted as a FAT or NTFS file system provided

with the Windows operating system. In case of a

storage device formatted as a different utility pro-

gram which is not supported by Windows, it may

not be recognized.

Please connect power to a USB storage device

which requires an external power supply. If not,

the device may not be recognized.

Please connect a USB storage device with cable is

offered by USB maker. If connected with cable is

not offered by USB maker or an excessively long

cable, the device may not be recognized.

Some USB storage devices may not be supported

or operated smoothly.

Because the TV doesn’t support file sorting for

USB storage device, the file on the storage device

will be displayed in the order saved.

Please backup important files because data on

USB device may be damaged. Data management is

consumer's responsibility and as a result, the man-

ufacturer does not cover data damage.

When removing the USB device

Connect the USB device to the

UUSSBB IINN

jacks on the side of TV.

Select

PPhhoottoo LLiisstt

MMuussiicc LLiisstt

USB IN

Photo List Music List

Select

UUSSBB EEjjeecctt

Select the

UUSSBB EEjjeecctt

menu before removing the

USB device.

ENTER

Q. MENU

ENTER

■

It doesn’t support USB HDD

■

This TV supports JPG and MP3.

PHOTO LIST

USB

You can view .JPG files from USB storage devices.

The On Screen Display on your model may be slightly different.

Screen Components

Moves to upper level folder

Preview: Display the

thumbnail/folder name of

the photo in the selected

folder

Current page/Total pages

Total number of marked photos

Usable USB memory

Corresponding buttons on

the remote control

Supported photo file:

.JPG

■

You can play JPG files only.

■

Only baseline scan is supported among JPG.

Select

UUSSBB

Select

PPhhoottoo LLiisstt

ENTER

Move PopUp Menu Move Page Mark Exit

FAV

RETURN

USB Device

Page 2/3

No Marked

Photo List

Upper

Free Space 150MB

1366

768, 125KB

KY101

06/10/2008

KY102

04/03/2008

JMJ001

01/01/2000

JMJ002

06/15/2008

JMJ003

04/03/2008

JMJ004

02/18/2008

KY103

03/30/2008

KY104

06/19/2008

KY105

01/31/2008

JMJ005

05/13/2008

JMJ006

05/26/2008

JMJ007

02/18/2008

JMJ008

02/18/2008

Upper

Drive1

JMJ001

3 4

• Non-supported files are displayed in the

form of bitmap.

• Some files may be displayed the preview

image by icon only.

USB Device

Page 2/3

No Marked

Photo List

Upper

Free Space 150MB

0, 0KB

KY101

06/10/2008

KY102

04/03/2008

JMJ001

01/01/2000

JMJ002

06/15/2008

JMJ003

04/03/2008

JMJ004

02/18/2008

KY103

03/30/2008

KY104

06/19/2008

KY105

01/31/2008

JMJ005

05/13/2008

JMJ006

05/26/2008

JMJ007

02/18/2008

JMJ008

02/18/2008

Upper

Drive1

JMJ001

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

USB Device

Page 2/3

No Marked

Photo List

Upper

Free Space 150MB

1366

768, 125KB

KY101

06/10/2008

KY102

04/03/2008

JMJ001

01/01/2000

JMJ002

06/15/2008

JMJ003

04/03/2008

JMJ004

02/18/2008

KY103

03/30/2008

KY104

06/19/2008

KY105

01/31/2008

JMJ005

05/13/2008

JMJ006

05/26/2008

JMJ007

02/18/2008

JMJ008

02/18/2008

Upper

Drive1

JMJ001

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

USB

Photo Selection and Popup Menu

Select the target folder or drive.

Select the desired photos.

Show the Popup menu.

■

Use the

CCHH

button to navigation in the

photo page.

■

Use the

FFAAVV

button to mark or unmark a

photo. When one or more photos are marked,

you can view individual photos or a slide show

of the marked photos. If no photos are marked,

you can view all photos individually or all pho-

tos in the folder in a slide show.

Select the desired Popup menu.

ENTER

When you select a file (not folder), this PopUp

menu is displayed.

VViieeww

: Display the selected item.

MMaarrkk AAllll

: Mark all photos on the screen.

UUnnmmaarrkk AAllll

: Deselect all marked photos.

DDeelleettee

: Delete the selected photo item.

CClloossee

: Close the pop-up menu.

USB Device

Page 2/3

No Marked

Photo List

Upper

Free Space 150MB

1366

768, 125KB

KY101 06/10/2008

KY102 04/03/2008

JMJ001 01/01/2000

JMJ002 06/15/2008

JMJ003 04/03/2008

JMJ004

02/18/2008

KY103 03/30/2008

KY104 06/19/2008

KY105 01/31/2008

JMJ005 05/13/2008

JMJ006 05/26/2008

JMJ007 02/18/2008

JMJ008 02/18/2008

Upper

USB Device

Page 2/3

No Marked

Photo List

Upper

Free Space 150MB

1366

768, 125KB

KY101 06/10/2008

KY102

04/03/2008

JMJ001

01/01/2000

JMJ002

06/15/2008

JMJ003

04/03/2008

JMJ004

02/18/2008

KY103 03/30/2008

KY104 06/19/2008

KY105

01/31/2008

JMJ005

05/13/2008

JMJ006

05/26/2008

JMJ007

02/18/2008

JMJ008

02/18/2008

Upper

Drive1

JMJ001

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

1366x768

125KB

View

Mark All

Delete

USB

Full Screen Menu

You can change the Photo List view so that it fills the screen. More operations are available in full

screen mode.

■

Use the

CCHH

button to navigation in the

photo page.

The aspect ratio of a photo may change the size of

the photo displayed on the screen in full size.

Select the target folder or drive.

Select the desired photos.

Show the Popup menu.

Select

VViieeww

The selected photo is displayed in

full size.

ENTER

USB Device

Page 2/3

No Marked

Photo List

Upper

Free Space 150MB

1366

768, 125KB

KY101

06/10/2008

KY102

04/03/2008

JMJ001

01/01/2000

JMJ002

06/15/2008

JMJ003

04/03/2008

JMJ004

02/18/2008

KY103

03/30/2008

KY104

06/19/2008

KY105

01/31/2008

JMJ005

05/13/2008

JMJ006

05/26/2008

JMJ007

02/18/2008

JMJ008

02/18/2008

Upper

USB Device

Page 2/3

No Marked

Photo List

Upper

Free Space 150MB

1366

768, 125KB

KY101 06/10/2008

KY102 04/03/2008

JMJ001 01/01/2000

JMJ002

06/15/2008

JMJ003

04/03/2008

JMJ004

02/18/2008

KY103 03/30/2008

KY104 06/19/2008

KY105 01/31/2008

JMJ005 05/13/2008

JMJ006

05/26/2008

JMJ007

02/18/2008

JMJ008

02/18/2008

Upper

Drive1

JMJ001

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

1366x768

125KB

View

Mark All

Delete

1/17

Slide Show

Delete Option Hide

USB

Select the

SSiiddee SShhooww

((RRoottaattee))

DDeelleettee

OOppttiioonn

, or

HHiiddee..

■

Use button to select the previous or

next photo.

■

Use button to select and control

the menu on the full-sized screen.

ENTER

NOTE

This TV will not be able to decode

most JPG images saved using the

Progressive option.

1/17

Slide Show

Delete Option Hide

Press

FF GG

to set the time interval between

slides.

Slide Speed

Fast

Cancel

Enter

SSlliiddee SShhooww

: Selected photos are displayed during the

slide show. If no photo is selected, all photos in the cur-

rent folder are displayed during slide show.

■

Set the time interval of the slide show in

OOppttiioonn

■

A slide show continues for a maximum of 4 hours.

After 4 hours, the slide show will end and go to TV

mode or external input mode.

((RRoottaattee))

: Rotate photos.

■

Rotates the photo 90°, 180 °, 270°, 360° clockwise.

DDeelleettee

: Delete photos.

OOppttiioonn

: Set values for

SSlliiddee SSppeeeedd

■

Use button and

EENNTTEERR

button to set values.

Then go to and press

EENNTTEERR

to save the set-

tings.

HHiiddee

: Hide the menu on the full-sized screen.

■

To see the menu again on the full-sized screen, press

EENNTTEERR

button to display.

MUSIC LIST

USB

You can use the Music List menu to play MP3 files form a USB storage device.

This TV cannot play back copy-protected files.

The On Screen Display on your model may be slightly different.

Screen Components

Supported music file:

.MP3

Bit rate range 40Kbps ~ 320Kbps

• Sampling rate (Sampling Frequency)

MPEG1 : 32000, 44100, 48000Hz

MPEG2 : 16000, 24000, 22050Hz

MPEG2.5 : 16 ~ 48KHz

Moves to upper level folder

Preview: If any album jacket

for the file exists, this jack-

et is displayed.

Current page/Total pages

Total number of marked

musics

Usable USB memory

Corresponding buttons on

the remote control

Select

UUSSBB

Select

MMuussiicc LLiisstt

ENTER

USB Device

Music List

Upper

Free Space 150MB

3945 KB, 128 Kbps

Title Play Time

Upper

Good Bye

Arirang 04:12

05:30

3 4

Move PopUp Menu Move Page Mark Exit

FAV

RETURN

Page 1/1

No Marked

Drive1

Arirang

USB

Music Selection and Popup Menu

■

Use the

CCHH

button to navigation in

the music page.

■

Use

FFAAVV

button to mark or unmark a music

file. If no music is marked, all the music in the

folder will be played in sequence. When one or

more music files are marked, the marked music

files will be played in sequence. If you want to

listen to only one song repeatedly, just mark

that one file and play.

Up to 6 music titles are listed per page.

Select the target folder or drive.

Select the desired musics.

Show the Popup menu.

Select the desired Popup menu.

ENTER

RETURN

Return to TV viewing

USB Device

Page 1/1

No Marked

Music List

Upper

Free Space 150MB

3945 KB, 128 Kbps

Drive1

Arirang

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

Play TimeTitle

Upper

Good Bye

Arirang

USB Device

Page 1/1

No Marked

Music List

Upper

Free Space 150MB

3945 KB, 128 Kbps

Drive1

Arirang

Move Move Page Mark Exit

FAV

RETURN

PopUp Menu

Play TimeTitle

Upper

Good Bye

Arirang

05:30

04:12

3945 KB

128 Kbps

Play

Mark All

Delete

PPllaayy

(During stop): Play the selected music.

Once a song finishes playing, the next selected

one will be played. When there are no selected

musics to play, the next one in the current fold-

er will be played. If you go to a different folder

and press the

EENNTTEERR

button, the current

music in playback will stop.

SSttoopp PPllaayy

(During playback): Stop the play-

ing musics.

MMaarrkk AAllll

: Mark all musics in the folder.

UUnnmmaarrkk AAllll

: Deselect all marked music.

DDeelleettee

: Delete the selected music.

CClloossee

: Close the pop-up menu.

USB

■

The play information box (as shown below) will automatically

move across the screen when there is no user input to pre-

vent a fixed image remaining on the screen for a extended

period of time.

NOTE

When music is playing, is displayed in front of the music play time.

A damaged or corrupted music file that does not play displays 00:00 as the play time.

Music files with copy-protection will not play.

Press

EENNTTEERR

, or

RREETTUURRNN

button to stop the screen saver.

This TV can not play music files less than 16 Kbytes.

PICTURE CONTROL

PICTURE SIZE (ASPECT RATIO) CONTROL

PICTURE CONTROL

This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV.

■

RGB-PC input source use 4:3 or 16:9 aspect ratio.

NOTE

If a fixed image is displayed on the screen for a long time, the image could become imprinted on the

screen and remain visible.

This phenomenon is common to all manufacturers and is not covered by warranty. Although, after watch-

ing video that did not fill the screen, any after-image from the black bars will normally dissipate after a few

minutes.

■

You can also adjust

AAssppeecctt RRaattiioo

the

QQ--MMeennuu

Select

PPIICCTTUURREE

Select

AAssppeecctt RRaattiioo

Select the desired picture format.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Set By Program

4:3

16:9

Zoom1

Zoom2

Just Scan

PICTURE CONTROL

Set by program

Selects the proper picture proportion to match

the source’s image.

4:3

Choose 4:3 when you want to view a picture

with an original 4:3 aspect ratio.

16:9

Adjust the picture horizontally, in a linear pro-

portion to fill the entire screen.

Zoom 1

Choose Zoom 1 when you want to view the pic-

ture without any alteration. However, the top and

bottom portions of the picture will be cropped.

Zoom 2

Choose Zoom 2 when you want the picture to be

altered, both vertically extended and cropped.

The picture taking a halfway trade off between

alteration and screen coverage.

Just Scan

Normally the edges of video signals are cropped

1-2%. Just Scan turns off this cropping and

shows the complete video.

Notes: If there is noise on the edges of the original

signal, it will be visible when Just Scan is activated.

JJuusstt SSccaann

operates only in

DTV/CADTV/Component/HDMI-DTV/DVI-DTV

(720p/1080i/1080p) input source.

(4:3 4:3)

(16:9 16:9)

PICTURE CONTROL

PRESET PICTURE SETTINGS

PICTURE CONTROL

Picture Mode - Preset

There are factory presets for picture settings available in the user menus. You can use a preset, change each

setting manually, or use the Intelligent Sensor.

Select

PPIICCTTUURREE

Select

PPiiccttuurree MMooddee

Select

IInntteelllliiggeenntt SSeennssoorr

VViivviidd

SSttaannddaarrdd

CCiinneemmaa

SSppoorrtt

, or

GGaammee

■

When selecting

IInntteelllliiggeenntt SSeennssoorr

the most suitable picture is automatically

adjusted according to the surrounding

conditions.

■

VViivviidd

SSttaannddaarrdd

CCiinneemmaa

SSppoorrtt

, and

GGaammee

Settings are preset for the optimum

picture quality at the factory and are not

adjustable.

■

You can also adjust

PPiiccttuurree MMooddee

the

QQ.. MMeennuu

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Intelligent Sensor

Vivid

Standard

Cinema

Sport

Game

Expert1

Expert2

PICTURE CONTROL

Color Tone - Preset

Choose one of three automatic color adjustments. Set to warm to enhance hotter colors such as red, or set to

cool to see less intense colors with more blue.

Select

PPIICCTTUURREE

Select

CCoolloorr TTeemmppeerraattuurree

ENTER

Select

CCooooll

MMeeddiiuumm

, or

WWaarrmm

Select

AAddvvaanncceedd CCoonnttrrooll

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Color Temperature

Medium

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Off

Gamma

Medium

Black Level

Low

Eye Care

Off

Real Cinema

Off

PICTURE CONTROL

MANUAL PICTURE ADJUSTMENT

PICTURE CONTROL

Picture Mode - User Mode

Adjust the picture appearance to suit your preference and viewing situations.

This feature is disable in “

PPiiccttuurree MMooddee--IInntteelllliiggeenntt SSeennssoorr

”.

Select

PPIICCTTUURREE

Make appropriate adjustments.

Select

BBaacckklliigghhtt

CCoonnttrraasstt

BBrriigghhttnneessss

SShhaarrppnneessss

CCoolloorr

, or

TTiinntt

Select

PPiiccttuurree MMooddee

ENTER

Select

VViivviidd

SSttaannddaarrdd

CCiinneemmaa

SSppoorrtt

, or

GGaammee

ENTER

• Backlight 80

Enter

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

PICTURE CONTROL

Select your desired menu option.

Select

PPIICCTTUURREE

Select

PPiiccttuurree MMooddee

Select

EExxppeerrtt CCoonnttrrooll

Select

EExxppeerrtt11

EExxppeerrtt22

ENTER

Make appropriate adjustments.

Picture Mode - Expert Control

By segmenting categories,

EExxppeerrtt11

and

EExxppeerrtt22

provide more categories which users can set as they see

fit, offering the optimal picture quality for users.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Expert Control

Intelligent Sensor

Vivid

Standard

Cinema

Sport

Game

Expert1

Expert2

Off

Fresh Contrast

Noise Reduction

Off

Gamma

Medium

Black Level

Off

Real Cinema

Color Standard

White Balance

Normal

• Method

2 Points

PICTURE CONTROL

PICTURE IMPROVEMENT TECHNOLOGY

PICTURE CONTROL

Fresh Contrast: Optimizes the contrast automatically according to the brightness of the reflection.

Fresh Color: Adjusts the color of the reflection automatically to reproduce as close as possible natural colors.

Noise Reduction: Removes interference up to the point where it does not damage the original picture.

Gamma: High gamma values display whitish images and low gamma values display high contrast images.

Select

PPIICCTTUURREE

Select

AAddvvaanncceedd CCoonnttrrooll

Select

FFrreesshh CCoonnttrraasstt

FFrreesshh CCoolloorr

NNooiissee

RReedduuccttiioonn

, or

GGaammmmaa

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Select your desired options.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Color Temperature

Medium

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Off

Gamma

Medium

Black Level

Low

Eye Care

Off

Real Cinema

Off

PICTURE CONTROL

ADVANCED CONTROL - BLACK (DARKNESS) LEVEL

Adjusting the contrast and the brightness of the screen using the black level of the screen.

This feature is disabled in DTV and RGB-PC mode.

Select

PPIICCTTUURREE

Select

AAddvvaanncceedd CCoonnttrrooll

Select

BBllaacckk LLeevveell

ENTER

Select

LLooww

HHiigghh

■

LLooww

: The reflection of the screen gets

darker.

■

HHiigghh

: The reflection of the screen gets

brighter.

■

AAuuttoo

: Realizing the black level of the

screen and set it to High or Low auto-

matically.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Color Temperature

Medium

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Auto

Gamma

Medium

Black Level

Low

Eye Care

Off

Real Cinema

Off

PICTURE CONTROL

ADVANCED CONTROL - EYE CARE

PICTURE CONTROL

Dims extremely bright pictures.

This feature is disabled in “

PPiiccttuurree MMooddee--VViivviidd

CCiinneemmaa

”.

Select

PPIICCTTUURREE

Select

AAddvvaanncceedd CCoonnttrrooll

Select

EEyyee CCaarree

ENTER

Select

OO nn

OOffff

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Color Temperature

Medium

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Off

Gamma

Medium

Black Level

Low

Eye Care

Off

Real Cinema

Auto

PICTURE CONTROL

ADVANCED CONTROL - REAL CINEMA

Set up the TV for the best picture appearance for viewing movies.

When you operate Real Cinema (3:2 Pull-Down Mode or Cinema Correction Mode), the TV will adjust 24 fps

video from movies to 30 fps video for display.

This feature operates only in TV (Analog TV/CATV, Digital DTV/CADTV), AV1, AV2, Component 480i/1080i,

and HDMI 1080i mode.

This TV ouputs 48Hz in DTV, Component, and HDMI 1080p (24Hz).

Select

PPIICCTTUURREE

Select

AAddvvaanncceedd CCoonnttrrooll

Select

RReeaall CCiinneemmaa

ENTER

Select

OO nn

OOffff

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Enter

Move


Aspect Ratio : 16:9

Picture Mode : Standard

• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

Color Temperature

Medium

Fresh Contrast

Off

Fresh Color

Off

Noise Reduction

Off

Gamma

Medium

Black Level

Low

Eye Care

Off

Real Cinema

Off

PICTURE CONTROL

PICTURE RESET

PICTURE CONTROL

Settings of the selected picture modes return to the default factory settings.

Select

PPIICCTTUURREE

Select

RReesseett

Initialize the adjusted value.

ENTER

Return to TV viewing.

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Enter

Move


• Backlight 80

• Contrast 90

• Brightness 50

• Sharpness 60

• Color 60

• Tint 0

• Advanced Control

• Reset

Screen (RGB-PC)

Resetting video configuration...

PICTURE CONTROL

POWER INDICATOR

Select

OOPPTTIIOONN

Select

PPoowweerr IInnddiiccaattoorr

ENTER

Select

SSttaannddbbyy LLiigghhtt

PPoowweerr LLiigghhtt

ENTER

Select your desired options.

RETURN

Return to the previous menu.

Return to TV viewing.

■

SSttaannddbbyy LLiigghhtt

: You can set the

brightness of the LED on the front side

of the TV during power standby.

■

PPoowweerr LLiigghhtt

: You can set the the LED

on the front side of the TV to be turned

on or off while watching the TV.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Power Light

Standby Light

Off

SOUND & LANGUAGE CONTROL

AUTO VOLUME LEVELER (AUTO VOLUME)

Auto Volume makes sure that the volume level remains consistent whether you are watching a commercial or a

regular TV program.

Select

AAUUDDIIOO

Select

AAuuttoo VVoolluummee

Select

OO nn

OOffff

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Off

SOUND & LANGUAGE CONTROL

PRESET SOUND SETTINGS (SOUND MODE)

Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate

sound options based on the program content.

SSttaannddaarrdd

MMuussiicc

CCiinneemmaa

SSppoorrtt

, and

GGaammee

are preset for optimum sound quality at the factory and are

not adjustable.

Select

AAUUDDIIOO

Select

SSoouunndd MMooddee

Select

SSttaannddaarrdd

MMuussiicc

CCiinneemmaa

SSppoorrtt

, or

GGaammee

ENTER

■

You can also adjust

SSoouunndd MMooddee

the

QQ.. MMeennuu

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Standard

Music

Cinema

Sport

Game

SOUND & LANGUAGE CONTROL

SOUND SETTING ADJUSTMENT - USER MODE

SRS TRUSURROUND XT

Adjust the sound to suit your taste and room situations.

Select

AAUUDDIIOO

Select

SSoouunndd MMooddee

Select

TTrreebbllee

BBaassss

ENTER

Select

SSttaannddaarrdd

MMuussiicc

CCiinneemmaa

SSppoorrtt

, or

GGaammee

ENTER

Select

AAUUDDIIOO

Select

SSRRSS TTrruuSSuurrrroouunndd XXTT

Select

OO nn

OOffff

ENTER

■

SSRRSS TTrruuSSuurrrroouunndd XXTT

: Takes advantage of

any multi-channel format without needing to

add extra speakers or equipment. Dialog clarity,

bass enrichment, and the addition of stereo

audio enhancement produces an immersive

sound experience from standard stereo material.

RETURN

Return to the previous menu.

Return to TV viewing.

RETURN

Return to the previous menu.

Return to TV viewing.

Make appropriate adjustments.

ENTER

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Treble 50

Bass 50

SRS TruSurround XT

Off

SOUND & LANGUAGE CONTROL

CLEAR VOICE

By differentiating the human sound range from others, it improves the sound quality of voices.

■

If you select “

CClleeaarr VVooiiccee--OOnn

”,

SSRRSS

TTrruuSSuurrrroouunndd XXTT

feature will not

work.

■

You can also adjust

CClleeaarr VVooiiccee

in the

QQ--MMeennuu

Select

AAUUDDIIOO

Select

CClleeaarr VVooiiccee

Select

OO nn

OOffff

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Off

SOUND & LANGUAGE CONTROL

BALANCE

SOUND & LANGUAGE CONTROL

Select

AAUUDDIIOO

Select

BBaallaannccee

Make appropriate adjustments.

ENTER

Adjust the left/right sound of speaker to suit your taste and room situations.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Balance 0

SOUND & LANGUAGE CONTROL

TV SPEAKERS ON/OFF SETUP

Turn the TV speakers off if using external audio equipment.

Select

AAUUDDIIOO

Select

TTVV SSppeeaakkeerr

Select

OO nn

OOffff

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Off

SOUND & LANGUAGE CONTROL

AUDIO RESET

SOUND & LANGUAGE CONTROL

Settings of the selected Sound Mode return to the default factory settings.

Select

AAUUDDIIOO

Select

RReesseett

ENTER

Initialize the adjusted value.

ENTER

Return to TV viewing.

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Enter

Move

AUDIO

Auto Volume : Off

Clear Voice : On

Balance 0

Sound Mode : Standard

•

SRS TruSurround XT:

Off

• Treble 50

• Bass 50

• Reset

TV Speaker : On

Resetting audio configuration...

SOUND & LANGUAGE CONTROL

STEREO/SAP BROADCAST SETUP

For Analog only: This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accom-

panies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used

if the broadcast is only in Mono.

Select

SSAAPP

Select

MMoonnoo

SStteerreeoo

, or

SSAAPP

Return to TV viewing.

Q. MENU

Select

MMuullttii AAuuddiioo

Select other languages.

Return to TV viewing.

Q. MENU

Analog TV Digital TV

Q.Menu

16:9

Vivid

Off

Standard

Off

English

Off

Add

Eject

Aspect Ratio

Backlight

Clear Voice

Picture Mode

Sound Mode

Caption

Multi Audio

Sleep Timer

Del/Add/Fav

USB Eject

SOUND & LANGUAGE CONTROL

AUDIO LANGUAGE

SOUND & LANGUAGE CONTROL

Other languages may be available if a digital signal is provided by the broadcasting station.

This feature operates only in DTV/CADTV mode.

Select

OOPPTTIIOONN

Select

LLaanngguuaaggee

Select

AAuuddiioo

ENTER

Select your desired language:

EEnngglliisshh

SSppaanniisshh

, or

FFrreenncchh

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

English

Audio

English

SOUND & LANGUAGE CONTROL

ON-SCREEN MENUS LANGUAGE SELECTION

The menus can be shown on the screen in the selected language.

Select

OOPPTTIIOONN

Select

LLaanngguuaaggee

Select

MMeennuu

ENTER

Select your desired language.

From this point on, the on-screen menus

will be shown in the selected language.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

English

Audio

English

SOUND & LANGUAGE CONTROL

CAPTION MODE

SOUND & LANGUAGE CONTROL

Caption must be provided to help people with hearing loss watch TV. Select a caption mode for displaying cap-

tioning information if provided on a program. Analog caption displays information at any position on the screen

and is usually the program's dialog. Caption/Text, if provided by the broadcaster, would be available for both

digital and analog channels on the Antenna/Cable. This TV is programmed to memorize the caption/text mode

which was last set when you turned the power off. This function is only available when

CCaappttiioonn

Mode is set

OOnn

Select

OOPPTTIIOONN

Select

CCaappttiioonn

Select

OO nn

ENTER

Select

CCCC11

TTeexxtt11

Analog Broadcasting System Captions

■

When selecting

OOffff

, Sub-menus for

Analog, DTV, and Digital Option

become disabled.

■

CCAAPPTTIIOONN

The term for the words that scroll

across the bottom of the TV screen;

usually the audio portion of the pro-

gram provided for the hearing impaired.

■

TTEEXXTT

The term for the words that appear in a

large black frame and almost cover the

entire screen; usually messages provid-

ed by the broadcaster.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Mode

CC1

Digital Option

SOUND & LANGUAGE CONTROL

Digital Broadcasting System Captions

Choose the language you want the DTV/CADTV Captions to appear in.

Other Languages can be chosen for digital sources only if they are included on the program.

This function in only available when Caption Mode is set On.

Select

OOPPTTIIOONN

Select

CCaappttiioonn

Select

OO nn

ENTER

Select

CCCC11

TTeexxtt11

, or

SSeerrvviiccee11

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : CC1

Set ID : 1

Power Indicator

Initial Setting : Home

Mode

CC1

Digital Option

SOUND & LANGUAGE CONTROL

Caption Option

Customize the DTV/CADTV captions that appear on your screen.

This function in only available when Caption Mode is set On.

Select

OOPPTTIIOONN

Select

CCaappttiioonn

Select

OO nn

ENTER

Select

CCuussttoomm

ENTER

Customize the

SSttyyllee

FFoonntt

, etc., to your

preference. A preview icon is provided at

the bottom of the screen, use it to see the

caption language.

Select

DDiiggiittaall OOppttiioonn

Size

A Standard

Font

Font 1

Text Color

White

Text Opacity

Solid

Edge Type

None

Edge Color

Black

Bg Color

Black

Bg Opacity

Solid

Custom

■

SSiizzee

: Set the word size.

■

FFoonntt

: Select a typeface for the text.

■

TTeexxtt CCoolloorr

: Choose a color for the

text.

■

TTeexxtt OOppaacciittyy

: Specify the opacity

for the text color.

■

BBgg ((BBaacckkggrroouunndd)) CCoolloorr

: Select a

background color.

■

BBgg ((BBaacckkggrroouunndd)) OOppaacciittyy

: Select

the opacity for the background color.

■

EEddggee TTyyppee

: Select an edge type.

■

EEddggee CCoolloorr

: Select a color for the

edges.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : CC1

Set ID : 1

Power Indicator

Initial Setting : Home

Mode

Service1

Digital Option

TIME SETTING

CLOCK SETTING

TIME SETTING

Auto Clock Setup

The time is set automatically from a digital channel signal.

The digital channel signal includes information for the current time provided by the broadcasting station.

Set the clock manually if the current time is set incorrectly by the auto clock function.

Select

TTIIMMEE

Select

CClloocckk

Select

AAuuttoo

ENTER

Select your viewing area time zone.

• U.S.A:

EEaasstteerrnn

CCeennttrraall

MMoouunnttaaiinn

PPaacciiffiicc

AAllaasskkaa

, or

HHaawwaaiiii

• Canada:

EEaasstteerrnn

CCeennttrraall

MMoouunnttaaiinn

PPaacciiffiicc

NNeeww FF..llaanndd

, or

AAttllaannttiicc

Select

AAuuttoo

OOffff

, or

OO nn

(depending on

whether or not your viewing area observes

Daylight Saving time).

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Year

Month

Date

Hour

2 AM

2008

Minute

Time Zone

Eastern

Daylight

Saving

Auto

TIME SETTING

Manual Clock Setup

If the current time setting is wrong, set the clock manually.

Select

TTIIMMEE

Select

CClloocckk

Select

MMaannuuaall

ENTER

Select the Year, Month, Date, Hour, or Minutes

option.

Set the Year, Month, Date, Hour, or Minutes

option.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Year

Month

Date

Hour

2 AM

2008

Minute

Time Zone

Eastern

Daylight

Saving

Auto

Manual

TIME SETTING

AUTO ON/OFF TIME SETTING

This function operates only if the current time has been set.

The

OOffff TTiimmee

function overrides the

OOnn TTiimmee

function if they are both set to the same time.

The TV must be in standby mode for the

OOnn TTiimmee

to work.

If you do not press any button within 2 hours after the TV turns on with the

OOnn TTiimmee

function, the TV will

automatically revert to standby mode.

■

To cancel

OOnn//OOffff TTiimmee

function, select

OOffff

■

Only for On Time function

Select

IInnppuutt

Select the desired input source.

Select

TTIIMMEE

Select

OOffff ttiimmee

OOnn ttiimmee

Select

RReeppeeaatt

ENTER

Select

OOffff

OOnnccee

EEvveerryyddaayy

MMoonn

FFrrii

MMoonn

SSaatt

WWeeeekkeenndd

, or

SSuunnddaayy

Select and set

HHoouurr

MMiinnuuttee

ENTER

When Selecting

TTVV

set the channel at turn-on.

Adjust to sound level at

turn-on.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : 6:30 AM (Once)

Sleep Timer : Off

Auto Sleep : Off

Repeat

Once

Hour

6 AM

Minute

Input

Channel

TV 2-0

Volume

TIME SETTING

SLEEP TIMER SETTING

The Sleep Timer turns the TV off at the preset time.

Note that this setting is cleared when the TV is turned off.

■

You can also adjust

SSlleeeepp TTiimmeerr

the

QQ--MMeennuu

Select

TTIIMMEE

Select

SSlleeeepp TTiimmeerr

Select

OOffff

11 00

22 00

33 00

66 00

99 00

112200

118800

, or

224400

minutes.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Off

TIME SETTING

AUTO SHUT-OFF SETTING

TV will be automatically turned off, in case of no signal for 10 minutes.

Select

TTIIMMEE

Select

AAuuttoo SSlleeeepp

Select

OO nn

OOffff

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Enter

Move

TIME

Clock :

Feb/21/2008/ 2:10 AM

Off Time : Off

On Time : Off

Sleep Timer : Off

Auto Sleep : Off

Off

TV will be automatically turned off,

in case of No Signal for 10 minutes.

PARENTAL CONTROL / RATING

PARENTAL CONTROL / RATINGS

Parental Control can be used to block specific channels, ratings and other viewing sources.

The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broad-

casting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the

type of the program and the categories. It is also possible to block all program viewing for a time period. To use

this function, the following must be done :

1. Set ratings and categories to be blocked.

2. Specify a password

3. Enable the lock

V-Chip rating and categories

Rating guidelines are provided by broadcasting stations. Most television programs and television movies can be

blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-to-

video movies use the Movie Rating System

(

MPAA

)

only.

Ratings for Television programs including made-for-TV movies :

■

TV-G

(

General audience

)

■

TV-PG

(

Parental guidance suggested

)

■

TV-14

(

Parents strongly cautioned

)

■

TV-MA

(

Mature audience only

)

■

TV-Y

(

All children

)

■

TV-Y7

(

Children 7 years older

)

Set up blocking schemes to block specific channels, ratings, and external viewing sources.

A password is required to gain access to this menu.

Setting up Your Password

Enter Password

* * * *

Select

LLOOCCKK

ENTER

Input the password.

456

■

Enter the password as requested.

■

The TV is set up with the initial pass-

word “0-0-0-0”.

SET PASSWORD & LOCK SYSTEM

For USA For Canada

Enter

Move

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

LOCK

Enter

Move

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

LOCK

PARENTAL CONTROL / RATING

Enables or disables the blocking scheme you set up previously.

Lock System

Select

LLoocckk SSyysstteemm

Select

OO nn

OOffff

ENTER

■

When you select

OOnn

, the Lock System

is enable.

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Off

PARENTAL CONTROL / RATING

PARENTAL CONTROL / RATINGS

Change the password by inputting a new password twice.

Set Password

Select

SSeett ppaasssswwoorrdd

Choose any 4 digits for your new password.

As soon as the 4 digits are entered, re-enter

the same 4 digits on the

CCoonnffiirrmm

ENTER

456

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

New

* * * *

Confirm

* * * *

PARENTAL CONTROL / RATING

CHANNEL BLOCKING

Select

BBlloocckk CChhaannnneell

Select a channel to block or unblock.

ENTER

Block or unblock a channel.

ENTER

Blocks any channels that you do not want to watch or that you do not want your children to watch.

Select

LLOOCCKK

ENTER

Input the password.

456

Return to the previous menu.

RETURN

Return to TV viewing.

Block/Unblock

Move Page

Move

Exit

RETURN

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

PARENTAL CONTROL / RATING

MOVIE & TV RATING

PARENTAL CONTROL / RATINGS

Movie Rating (MPAA)

For USA only

Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can

set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that

the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.

Select

MMoovviiee RRaattiinngg

Select

PPGG

PPGG--1133

NNCC--1177

, or

BBlloocckkiinngg OOffff

ENTER

■

G (General audience)

■

PG (Parental guidance suggested)

■

PG-13 (Parents strongly cautioned)

■

R (Restricted)

■

NC-17 (No one 17 and under admitted)

■

X (Adult only)

■

Blocking Off (Permits all programs)

If you set PG-13: G and PG movies will

be available, PG-13, R, NC-17 and X will

be blocked.

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Blocking off : Permits all

programs

PG-13

NC-17

Blocking Off

PARENTAL CONTROL / RATING

Select

TTVV RRaattiinngg--CChhiillddrreenn

Select

AAggee

FFaannttaassyy VViioolleennccee

ENTER

Select block options.

ENTER

■

Age (applies to TV-Y, TV-Y7)

■

Fantasy Violence (applies to TV-Y7)

TV Rating Children

For USA only

Prevents children from watching certain children's TV programs, according to the ratings limit set. The children

rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audi-

ences in the TV Rating - sub menu, your children can view those programs.

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Age

Fantasy Violence

PARENTAL CONTROL / RATING

PARENTAL CONTROL / RATINGS

TV Rating General

For USA only

Based on the ratings, blocks certain TV programs that you and your family do not want to view.

Select

TTVV RRaattiinngg--GGeenneerraall

Select

AAggee

DDiiaalloogguuee

LLaanngguuaaggee

SSeexx

VViioolleennccee

ENTER

Select block options.

ENTER

■

Age (applies to TV-G,TV-PG,TV-14,TV-

MA).

■

Dialogue-sexual dialogue (applies to

TV-PG,TV-14).

■

Language-adult language (applies to

TV-PG, TV-14, TV-MA).

■

Sex-sexual situations (applies to TV-PG,

TV-14, TV-MA).

■

Violence (applies to TV-PG, TV-14, TV-

MA).

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Age

Dialogue

Language

Sex

Violence

PARENTAL CONTROL / RATING

TV Rating English

For CANADA only

Selecting canadian english language rating system.

Select

TTVV RRaattiinngg--EEnngglliisshh

Select

CC88++

PPGG

1144++

1188++

, or

BBlloocckkiinngg OOffff

ENTER

■

E (Exempt)

■

C (Children)

■

C8+ (Children eight years and older)

■

G (General programming, suitable for

all audiences)

■

PG (Parental Guidance)

■

14+ (Viewers 14 years and older)

■

18+ (Adult programming)

■

Blocking Off (Permits all programs)

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Blocking off : Permits all

programs

C8+

14+

18+

Blocking Off

PARENTAL CONTROL / RATING

PARENTAL CONTROL / RATINGS

TV Rating French

For CANADA only

Selecting canadian french language rating system.

Select

TTVV RRaattiinngg--FFrreenncchh

Select

88aannss++

1133aannss++

1166aannss++

1188aannss++

, or

BBlloocckkiinngg ooffff

ENTER

■

E (Exempt)

■

G (General)

■

8ans+ (General-Not convenient for lit-

tle children)

■

13ans+ (Not convenient for children of

13 years and younger)

■

16ans+ (Not convenient for children of

16 years and younger)

■

18ans+ (This programs is only for

adults)

■

Blocking off (Permits all programs)

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

TV Rating-English

TV Rating-French

Downloadable Rating

Input Block

Blocking off : Permits all

programs

8ans+

13ans+

16ans+

18ans+

Blocking Off

PARENTAL CONTROL / RATING

DOWNLOADABLE RATING

This function may become available in the future and will be available only for digital channels.

This function operates only when TV has received Region5 Rating data.

Select

DDoowwnnllooaaddaabbllee RRaattiinngg

Select desired

DDoowwnnllooaaddaabbllee

RRaattiinngg

option.

ENTER

Select desired option and block it.

ENTER

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Humor

Sport

Cruelty

Language

Sadness

Genre

Age

■

Based on rating table, your TV's OSD

(On Screen Display) may differ slightly

from what is shown in this manual.

PARENTAL CONTROL / RATING

PARENTAL CONTROL / RATINGS

EXTERNAL INPUT BLOCKING

Enables you to block an input.

Select

IInnppuutt BBlloocckk

Select input source.

Select

OO nn

OOffff

ENTER

Select

LLOOCCKK

ENTER

Input the password.

456

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

Enter

Move

LOCK

Lock System : Off

Set Password

Block Channel

Movie Rating

TV Rating-Children

TV Rating-General

Downloadable Rating

Input Block

AV1

Off

AV2

Off

Component1

Off

HDMI1

Off

RGB-PC

Off

Component2

Off

HDMI2

Off

HDMI3

Off

Except

42/47/52LG50DC

PARENTAL CONTROL / RATING

KEY LOCK

The TV can be set up so that it can only be used with the remote control.

This feature can be used to prevent unauthorized viewing by locking out the front panel controls.

This TV is programmed to remember which option it was last set to even if you turn the TV off.

Select

OOPPTTIIOONN

Select

KKeeyy LLoocckk

ENTER

Select

OO nn

OOffff

ENTER

■

KKeeyy LLoocckk

‘

OO nn

’, if the TV is turned

off, press the

/ I, INPUT, CH

(( ))

button on the TV or POWER, INPUT,

CH or NUMBER buttons on the

remote control.

■

With the

KKeeyy LLoocckk OOnn

, the display

‘

KKeeyy LLoocckk

’ appears on the screen

if any button on the front panel is

pressed while viewing the TV.

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Off

APPENDIX

TROUBLESHOOTING

TThhee ooppeerraattiioonn ddooeess nnoott wwoorrkk nnoorrmmaallllyy..

TThhee vviiddeeoo ffuunnccttiioonn ddooeess nnoott wwoorrkk..

No picture &No sound

No or poor color

or poor picture

Poor reception on

some channels

Lines or streaks

in pictures

No picture

when connecting HDMI

Horizontal/vertical bars

or picture shaking

Picture appears slowly

after switching on

The remote control

doesn’t work

Power is suddenly

turned off

■

Check to see if there is any object between the product and the remote control

causing obstruction. Ensure you are pointing the remote control directly at the TV.

■

Ensure that the batteries are installed with correct polarity (+ to +, - to -).

■

Ensure that the correct remote operating mode is set: TV, VCR etc.

■

Install new batteries.

■

Is the sleep timer set?

■

Check the power control settings. Power interrupted.

■

Check whether the product is turned on.

■

Try another channel. The problem may be with the broadcast.

■

Is the power cord inserted into wall power outlet?

■

Check your antenna direction and/or location.

■

Test the wall power outlet, plug another product’s power cord into the outlet

where the product’s power cord was plugged in.

■

This is normal, the image is muted during the product startup process. Please

contact your service center, if the picture has not appeared after five minutes.

■

Adjust Color in menu option.

■

Keep a sufficient distance between the product and the VCR.

■

Try another channel. The problem may be with the broadcast.

■

Are the video cables installed properly?

■

Activate any function to restore the brightness of the picture.

■

Check for local interference such as an electrical appliance or power tool.

■

Station or cable product experiencing problems, tune to another station.

■

Station signal is weak, reorient antenna to receive weaker station.

■

Check for sources of possible interference.

■

Check antenna (Change the direction of the antenna).

■

Check HDMI cable over version 1.3.

The HDMI cables don’t support HDMI version 1.3, it cause flickers or no screen

display. In this case use the latest cables that support HDMI version 1.3.

APPENDIX

TThheerree iiss aa pprroobblleemm iinn PPCC mmooddee.. ((OOnnllyy PPCC mmooddee aapppplliieedd))

■

Adjust resolution, horizontal frequency, or vertical frequency.

■

Check the input source.

■

Work the Auto configure or adjust clock, phase, or H/V position. (Option)

■

Check the signal cable.

■

Reinstall the PC video card.

The signal is out of range

Screen color is unstable

or single color

Vertical bar or stripe on

background &

Horizontal Noise &

Incorrect position

Picture OK & No sound

Unusual sound from

inside the product

No sound

when connecting

HDMI/USB

No output from one

of the speakers

TThhee aauuddiioo ffuunnccttiioonn ddooeess nnoott wwoorrkk..

■

Press the VOL or VOLUME button.

■

Sound muted? Press MUTE button.

■

Try another channel. The problem may be with the broadcast.

■

Are the audio cables installed properly?

■

Adjust Balance in menu option.

■

A change in ambient humidity or temperature may result in an unusual noise

when the product is turned on or off and does not indicate a fault with the

product.

■

Check HDMI cable over version 1.3.

■

Check USB cable over version 2.0.

■

Use normal MP3 file.

APPENDIX

100

APPENDIX

MAINTENANCE

Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can

enjoy your new TV.

Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning.

Cleaning the Screen

Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of lukewarm

water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost dry, and then

use it to wipe the screen.

Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.

Cleaning the Cabinet

■

To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.

■

Please be sure not to use a wet cloth.

Extended Absence

If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea to unplug

the power cord to protect against possible damage from lightning or power surges.

CAUTION

APPENDIX

101

PRODUCT SPECIFICATIONS

■

The specifications shown above may be changed without prior notice for quality improvement.

MODELS

AC100-240V ~ 50/60Hz

NTSC-M, ATSC, 64 & 256 QAM

VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135

75 ohm

32 ~ 104°F (0 ~ 40°C)

Less than 80%

-4 ~ 140°F (-20 ~ 60°C)

Less than 85%

Dimensions

(Width x Height

x Depth)

Weight

Power requirement

Television System

Program Coverage

External Antenna Impedance

Environment

condition

With stand

Without stand

With stand

Without stand

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

37LG50

(37LG50-UG)

42LG50 (42LG50-UG)

42LG50DC (42LG50DC-UG)

42LG55 (42LG55-UE)

36.8 x 26.9 x 11.5 inches

936.4 x 685.4 x 293.4 mm

36.8 x 24.1 x 3.4 inches

936.4 x 612.8 x 88.0 mm

40.3 pounds / 18.3 kg

34.3 pounds / 15.6 kg

40.7 x 28.9 x 11.5 inches

1034.0 x 735.0 x 294.0 mm

40.7 x 26.1 x 3.5 inches

1034.0 x 663.0 x 91.0 mm

54.0 pounds / 24.5 kg

48.5 pounds / 22.0 kg

MODELS

47LG50 (47LG50-UG)

47LG50DC (47LG50DC-UG)

47LG55 (47LG55-UE)

52LG50 (52LG50-UG)

52LG50DC (52LG50DC-UG)

Dimensions

(Width x Height

x Depth)

Weight

With stand

Without stand

With stand

Without stand

45.5 x 32.0 x 13.5 inches

1156.2 x 813.1 x 342.9 mm

45.5 x 29.1 x 4.0 inches

1156.2 x 739.2 x 103.0 mm

64.3 pounds / 29.2 kg

54.2 pounds / 24.6 kg

50.8 x 35.1 x 13.5 inches

1291.7 x 892.2 x 342.9 mm

50.8 x 32.1 x 4.5 inches

1291.7 x 817.0 x 115.3 mm

87.0 pounds / 39.5 kg

76.9 pounds / 34.9 kg

APPENDIX

102

PROGRAMMING THE REMOTE CONTROL

APPENDIX

The provided universal remote control can be programmed to operate most remote-controllable devices.

Note that the remote may not control all models of other brands.

Programming a code into a remote mode

Testing your remote control.

To find out whether your remote control can operate other components without programming, turn on a

component such as a STB and press the corresponding mode button (such as a

SSTTBB

) on the remote con-

trol, while pointing at the component. Test the

PPOOWWEERR

and

CC HH

buttons to see if the component

responds correctly. If the component does not operate correctly, the remote control requires programming

to operate the device.

Turn on the component to be programmed, then press the corresponding mode button (such as

SSTTBB

) on

the remote control. The remote control button of the desired device is illuminated.

Press the

MMEENNUU

and

MMUUTTEE

buttons simultaneously, and the remote control is ready to be programmed with

the code.

Enter a code number using the number buttons on the remote control. Programming code numbers for the

corresponding component can be found on the following pages. If the code is correct, the device will turn

off.

Press the

MMEENNUU

button to store the code.

Test the remote control functions to see if the component responds correctly. If not, repeat from step 2.

APPENDIX

103

Remote Control Code

Brand Codes Brand Codes Brand Codes

AIWA 034

AKAI 016 043 046 124

12 5 146

AMPRO 072

ANAM 031 033 103

AUDIO DYNAMICS

012 023 039 043

BROKSONIC 035 037 129

CANON 028 031 033

CAPEHART 108

CRAIG 003 040 135

CURTIS MATHES 031 033 041

DAEWOO 005 007 010 064

065 108 110 111

112 11 6 117 119

DAYTRON 108

DBX 012 023 039 043

DYNATECH 034 053

ELECTROHOME 059

EMERSON 006 017 025 027

029 031 034 035

036 037 046 101

129 131 13 8 153

FISHER 003 008 009 010

FUNAI 034

GE 031 033 063 072

10 7 109 14 4 14 7

GO VIDEO 132 136

HARMAN KARDON 012 045

HITACHI 004 018 026 034

043 063 137 150

INSTANTREPLAY 031 033

JCL 031 033

JCPENNY 012 013 015 033

040 066 101

JENSEN 043

JVC 012 031 033 043

048 050 055 060

130 150 152

KENWOOD 014 034 039 043

047 048

LG (GOLDSTAR) 001 012 013 020

101 106 114 123

LLOYD 034

LXI 003 009 013 014

017 034 101 106

MAGIN 040

MAGNAVOX 031 033 034 041

067 068

MARANTZ 012 031 033 067

069

MARTA 101

MATSUI 027 030

MEI 031 033

MEMOREX 003 010 014 031

033 034 053 072

101 102 13 4 13 9

MGA 045 046 059

MINOLTA 013 020

MITSUBISHI 013 020 045 046

049 051 059 061

151

MTC 034 040

MULTITECH 024 034

NEC 012 023 039 043

048

NORDMENDE 043

OPTONICA 053 054

PANASONIC 066 070 074 083

13 3 14 0 145

PENTAX 013 020 031 033

063

PHILCO 031 034 067

PHILIPS 031 033 034 054

067 071 101

PILOT 101

PIONEER 013 021 048

PORTLAND 108

PULSAR 072

QUARTZ 011 014

QUASAR 033 066 075 145

RCA 013 020 033 034

040 041 062 063

107 109 140 144

14 5 14 7

REALISTIC 003 008 010 014

031 033 034 040

053 054 101

RICO 058

RUNCO 148

SALORA 014

SAMSUNG 032 040 102 104

10 5 10 7 10 9 112

113 115 120 122

12 5

SANSUI 022 043 048 135

SANYO 003 007 010 014

10 2 13 4

SCOTT 017 037 112 129

131

SEARS 003 008 009 010

013 014 017 020

031 042 073 081

101

SHARP 031 054 149

SHINTOM 024

SONY 003 009 031 052

056 057 058 076

077 078 149

SOUNDESIGN 034

STS 013

SYLVANIA 031 033 034 059

067

SYMPHONIC 034

TANDY 010 034

TATUNG 039 043

TEAC 034 039 043

TECHNICS 031 033 070

TEKNIKA 019 031 033 034

101

THOMAS 034

TMK 006

TOSHIBA 008 013 042 047

059 082 112 131

TOTEVISION 040 101

UNITECH 040

VECTOR RESEARCH

012

VICTOR 048

VIDEO CONCEPTS

012 034 046

VIDEOSONIC 040

WARDS 003 013 017 024

031 033 034 040

053 054 131

YAMAHA 012 034 039 043

ZENITH 034 048 056

058 072 080 101

VCR

APPENDIX

104

APPENDIX

Brand Codes Brand Codes Brand Codes

ALPHASTAR DSR 123

AMPLICA 050

BIRDVIEW 051 126 129

CHANNEL MASTER

013 014 015 018

036 055

CHAPARRAL 008 009 012 077

CITOH 054

CURTIS MATHES 050 145

DRAKE 005 006 007 010

011 052 112 116

141

DX ANTENNA 024 046 056 076

ECHOSTAR 038 040 057 058

093 094 095 096

097 098 099 100

122

ELECTRO HOME 089

EUROPLUS 114

FUJITSU 017 021 022 027

13 3 134

GENERAL INSTRUMENT

003 004 016 029

031 059 101

HITACHI 139 140

HOUSTON TRACKER

033 037 039 051

057 104

HUGHES 068

JANIEL 060 147

JERROLD 061

KATHREIN 108

LEGEND 057

LG 001

LUTRON 132

LUXOR 062 144

MACOM 010 059 063 064

065

MEMOREX 057

NEXTWAVE 028 124 125

NORSAT 069 070

PACE SKY SATELLITE

14 3

PANASONIC 060 142

PANSAT 121

PERSONAL CABLE 117

PHILIPS 071

PICO 105

PRESIDENT 019 102

PRIMESTAR 030 110 111

PROSAT 072

RCA 066 106

REALISTIC 043 074

SAMSUNG 123

SATELLITE SERVICE CO

028 035 047 057

085

SCIENTIFIC ATLANTA

032 138

SONY 103

STARCAST 041

SUPER GUIDE 020 124 125

TEECOM 023 026 075 087

088 090 107 130

137

TOSHIBA 002 127

UNIDEN 016 025 042 043

044 045 048 049

078 079 080 086

101 135 136

VIEWSTAR 115

WINEGARD 128 146

ZENITH 081 082 083 084

091 120

HDSTB

DVD

Brand Codes Brand Codes Brand Codes

APEX DIGITAL 022

DENON 020 014

GE 005 006

HARMAN KARDON 027

JVC 012

LG 001 010 016 025

MAGNAVOX 013

MARANTZ 024

MITSUBISHI 002

NAD 023

ONKYO 008 017

PANASONIC 003 009

PHILIPS 013

PIONEER 004 026

PROCEED 021

PROSCAN 005 006

RCA 005 006

SAMSUNG 011 015

SONY 007

THOMPSON 005 006

TOSHIBA 019 008

YAMAHA 009 018

ZENITH 010 016 025

APPENDIX

105

IR CODES

■

Configuration of frame

1st frame

Repeat frame

■

Lead code

■

Repeat code

■

BBiitt ddeessccrriippttiioonn

■

FFrraammee iinntteerrvvaall:: TTff

The waveform is transmitted as long as a key is depressed.

C0 C1 C2 C3 C4 C5 C6 C7 C0 C1 C2 C3 C4 C5 C6 C7 D0 D1 D2 D3 D4 D5 D6 D7 D0 D1 D2 D3 D4 D5 D6 D7

Lead code Low custom code High custom code Data code Data code

Repeat code

4.5 ms

9 ms

2.25 ms

9 ms

0.55 ms

0.56 ms

1.12 ms

0.56 ms

2.24 ms

Tf Tf

Tf=108ms @455KHz

Bit ”0” Bit ”1”

1. How to Connect

■

Connect your wired remote control to the Remote Control port on the TV.

2. Remote Control IR Codes

■

Output waveform

Single pulse, modulated with 37.917KHz signal at 455KHz

Carrier frequency

FCAR = 1/TC = fOSC/12

Duty ratio = T1/TC = 1/3

APPENDIX

106

APPENDIX

Code

Function Note

(Hexa)

Code

Function Note

(Hexa)

08 POWER

Remote control Button (Power On/Off)

45 Q.MENU Remote control Button

43 MENU Remote control Button

0B INPUT Remote control Button

10-19 Number Key 0-9 Remote control Button

4C - (Dash) Remote control Button

1A FLASHBK Remote control Button

09 MUTE Remote control Button

02 VOL + Remote control Button

03 VOL - Remote control Button

00 CH Remote control Button

01 CH Remote control Button

1E FAV Remote control Button

40 Remote control Button

41 Remote control Button

07 Remote control Button

06 Remote control Button

44 ENTER Remote control Button

5B RETURN Remote control Button

7E SIMPLINK Remote control Button

30 AV MODE Remote control Button

B0 PLAY Remote control Button

BA PAUSE Remote control Button

B1 STOP Remote control Button

BD REC Remote control Button

8F REW Remote control Button

8E FF Remote control Button

Except 42/47/52LG50DC

D6 TV Discrete IR Code

(TV Input Selection)

C4 POWER ON Discrete IR Code

(Only Power On)

C5 POWER OFF Discrete IR Code

(Only Power Off)

5A AV1 Discrete IR Code

(AV1 Input Selection)

D0 AV2 Discrete IR Code

(AV2 Input Selection)

BF COMPONENT1 Discrete IR Code

(Component1 Input Selection)

D4 COMPONENT2 Discrete IR Code

(Component2 Input Selection)

D5 RGB-PC Discrete IR Code

(RGB-PC Input Selection)

CE HDMI1 Discrete IR Code

(HDMI1 Input Selection)

CC HDMI2 Discrete IR Code

(HDMI2 Input Selection)

E9 HDMI3 Discrete IR Code

(HDMI3 Input Selection)

76 Ratio 4:3 Discrete IR Code

(Only 4:3 Mode)

77 Ratio 16:9 Discrete IR Code

(Only 16:9 Mode)

AF Ratio Zoom Discrete IR Code

(Only Zoom1 Mode)

APPENDIX

107

EXTERNAL CONTROL THROUGH RS-232C

RS-232C Setup

The RS-232C port allows you connect the RS-232C input jack to an external control device (such as a computer

or an A/V control system) to control the TV’s functions externally.

■

Note: RS-232C on this unit is intended to be used with third party RS-232C control hardware and software.

The instructions below are provided to help with programming software or to test functionality using telenet

software.

VI)

REMOTE

CONTROL IN

AUDIO

OPTICAL COAXIAL

DIGITAL AUDIO OUT

AV IN 1

VIDEO L R

(MONO)

AUDIO

S-VIDEO

AUDIO OUT

RS-232C IN

(CONTROL & SERVICE)

Type of Connector; D-Sub 9-Pin Male

No. Pin Name

1 No connection

2 RXD

(

Receive data

)

3 TXD

(

Transmit data

)

4 DTR

(

DTE side ready

)

5 GND

6 DSR

(

DCE side ready

)

7 RTS

(

Ready to send

)

8 CTS

(

Clear to send

)

9 No Connection

Communication Parameters

■

Baud rate : 9600 bps

(

UART

)

■

Data length : 8 bits

■

Parity : None

■

Stop bit : 1 bit

■

Communication code : ASCII code

■

Use a crossed (reverse) cable.

NOTE

This product has command echo back in the

RS-232C Command.

APPENDIX

108

RS-232C Configurations

APPENDIX

Use this function to specify a TV ID number.

Refer to ‘Real Data Mapping1’.

pp..111111

Either cable below can be used.

Set ID

PC TV

RXD 2 3 TXD

TXD 3 2 RXD

GND 5 5 GND

DTR 4 6 DSR

DSR 6 4 DTR

RTS 7 8 CTS

CTS 8 7 RTS

D-Sub 9 D-Sub 9

PC TV

RXD 2 3 TXD

TXD 3 2 RXD

GND 5 5 GND

DTR 4 6 DTR

DSR 6 4 DSR

RTS 7 7 RTS

CTS 8 8 CTS

D-Sub 9 D-Sub 9

7-Wire Configuration

(

Serial female-female NULL modem cable

)

3-Wire Configurations

(

Not standard

)

Select

OOPPTTIIOONN

Select

SSeett IIDD

Choose the desired TV ID number.

The adjustment range of Set ID is 1~99.

ENTER

RETURN

Return to the previous menu.

Return to TV viewing.

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

Enter

Move

OPTION

Language : English

Input Label

SIMPLINK : On

Key Lock : Off

Caption : Off

Set ID : 1

Power Indicator

Initial Setting : Home

APPENDIX

109

Command Reference List

CCOOMMMMAANNDD11 CCOOMMMMAANNDD22

19. Channel Tuning

DATA

(Hexadecimal)

CCOOMMMMAANNDD11 CCOOMMMMAANNDD22

DATA

(Hexadecimal)

CCOOMMMMAANNDD11 CCOOMMMMAANNDD22

DATA00

(Hexadecimal)

DATA01

(Hexadecimal)

DATA02

(Hexadecimal)

DATA03

(Hexadecimal)

DATA04

(Hexadecimal)

DATA05

(Hexadecimal)

physical major major low minor high minor low attribute

program high program low

01. Power k a 00 ~ 01

02. Input Select x b (

p.110)

03. Aspect Ratio k c (

p.110)

04. Screen Mute k d 00 ~ 01

05. Volume Mute k e 00 ~ 01

06. Volume Control k f 00 ~ 64

07. Contrast k g 00 ~ 64

08. Brightness k h 00 ~ 64

09. Color k i 00 ~ 64

10. Tint k j 00 ~ 64

11. Sharpness k k 00 ~ 64

12. OSD Select k l 00 ~ 01

13. Remote Control

Lock Mode

Transmission / Receiving Protocol

TTrraannssmmiissssiioonn

[Command 1] : First command to control the set.

(j, k, m or x)

[Command 2] : Second command to control the set.

[Set ID] : You can adjust the set ID to choose desired TV ID

number in Setup menu. Adjustment range is 1

~ 99.

When selecting Set ID ‘0’, every connected the TV is

controlled. Set ID is indicated as decimal

(

~ 99

)

menu and as Hexa decimal

(

0x0~ 0x63

)

on transmission

/receiving protocol.

[DATA] : To transmit the command data.

Transmit the ‘FF’ data to read status of command.

[Cr] : Carriage Return

ASCII code ‘0x0D’

[ ] : ASCII code ‘space (0x20)’

* In this model, TV will not send the status during the standby mode.

OOKK AAcckknnoowwlleeddggeemmeenntt

The TV transmits ACK (acknowledgement) based on this for-

mat when receiving normal data. At this time, if the data is

data read mode, it indicates present status data. If the data is

data write mode, it returns the data of the PC computer.

* In this model, TV will not send the status during the standby mode.

* Data Format

[Command 2] : Use as command.

[Set ID] : Use the small character, if set ID is 10, it will send the ‘0’, ‘a’.

[DATA] : Use the small character, if data is 0 x ab, it will send the ‘a’, ‘b’.

[OK] : Use the large character.

EErrrroorr AAcckknnoowwlleeddggeemmeenntt

The TV transmits ACK (acknowledgement) based on this for-

mat when receiving abnormal data from non-viable functions

or communication errors.

Data1: Illegal Code

Data2: Not supported function

Data3: Wait more time

* In this model, TV will not send the status during the standby mode.

* Data Format

[Command 2] : Use as command.

[Set ID] : Use the small character, if set ID is 10, it will send the ‘0’, ‘a’.

[DATA] : Use the small character, if data is 0 x ab, it will send the ‘a’, ‘b’.

[NG] : Use the large character

[[CCoommmmaanndd11]][[CCoommmmaanndd22]][[ ]][[SSeett IIDD]][[ ]][[DDaattaa]][[CCrr]]

[[CCoommmmaanndd22]][[ ]][[SSeett IIDD]][[ ]][[OOKK]][[DDaattaa]][[xx]]

[[CCoommmmaanndd22]][[ ]][[SSeett IIDD]][[ ]][[NNGG]][[DDaattaa]][[xx]]

14. Treble k r 00 ~ 64

15. Bass k s 00 ~ 64

16. Balance k t 00 ~ 64

17.

Color Temperature

k u 00 ~ 02

18. Auto Configuration j u (

p.112)

20. Channel Add/Del m b 00 ~ 01

21. K e y m c (

p.113)

22. Backlight m g 00 ~ 64

00 ~ 01

k m

APPENDIX

110

APPENDIX

0011.. PPoowweerr ((CCoommmmaanndd:: kk aa))

To control Power On/Off of the TV.

Transmission [k][a][ ][Set ID][ ][Data][Cr]

Data 00: Power Off Data 01: Power On

Acknowledgement [a][ ][Set ID][ ][OK/NG][Data][x]

* In a like manner, if other functions transmit ‘FF’ data

based on this format, Acknowledgement data feedback

presents status about each function.

* Note: In this model, TV will send the Acknowledge

after power on processing completion.

There might be a time delay between command and

acknowledge.

0022.. IInnppuutt SSeelleecctt ((CCoommmmaanndd:: xx bb))

To select input source for TV.

Transmission [x][b][ ][Set ID][ ][Data][Cr]

Data 00: DTV (Antenna) Data 01: DTV (Cable)

Data 10: Analog (Antenna) Data 11: Analog (Cable)

Data 20: AV1 Data 21: AV2

Data 40: Component 1 Data 41: Component 2

Data 60: RGB-PC Data 90: HDMI1

Data 91: HDMI2

Data 92: HDMI3 (Except 42/47/52LG50DC)

Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x]

0033.. AAssppeecctt RRaattiioo ((CCoommmmaanndd:: kk cc))

To adjust the screen format.

Transmission [k][c][ ][Set ID][ ][Data][Cr]

Data 01: 4:3 05: Zoom 2

02: 16:9 06: Set by program

04: Zoom 1 09: Just scan

Reserved

Acknowledgement [c][ ][Set ID][ ][OK/NG][Data][x]

0044.. SSccrreeeenn MMuuttee ((CCoommmmaanndd:: kk dd))

To select screen mute on/off.

Transmission [k][d][ ][Set ID][ ][Data][Cr]

Data 00: Screen mute off (Picture on)

Data 01: Screen mute on (Picture off)

Acknowledgement [d][ ][Set ID][ ][OK/NG][Data][x]

0055.. VVoolluummee MMuuttee ((CCoommmmaanndd:: kk ee))

To control volume mute on/off.

You can also adjust mute using the MUTE button on

remote control.

Transmission [k][e][ ][Set ID][ ][Data][Cr]

Data 00: Volume mute on (Volume off)

Data 01: Volume mute off (Volume on)

Acknowledgement [e][ ][Set ID][ ][OK/NG][Data][x]

0066.. VVoolluummee CCoonnttrrooll ((CCoommmmaanndd:: kk ff))

To adjust volume.

You can also adjust volume with the volume buttons on

remote control.

Transmission [k][f][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’. See page 111.

Acknowledgement [f][ ][Set ID][ ][OK/NG][Data][x]

0077.. CCoonnttrraasstt ((CCoommmmaanndd:: kk gg))

To adjust screen contrast.

You can also adjust contrast in the PICTURE menu.

Transmission [k][g][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’. See page 111.

Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x]

0088.. BBrriigghhttnneessss ((CCoommmmaanndd:: kk hh))

To adjust screen brightness.

You can also adjust brightness in the PICTURE menu.

Transmission [k][h][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’. See page 111.

Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x]

APPENDIX

111

0099.. CCoolloorr ((CCoommmmaanndd:: kk ii))

To adjust screen color.

You can also adjust color in the PICTURE menu.

Transmission [k][i][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’ as shown below.

Acknowledgement [i][ ][Set ID][ ][OK/NG][Data][x]

1100.. TTiinntt ((CCoommmmaanndd:: kk jj))

To adjust screen tint.

You can also adjust tint in the PICTURE menu.

Transmission [k][j][ ][Set ID][ ][Data][Cr]

Data Red: 00 ~ Green: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’ as shown below.

Acknowledgement [ j ][ ][Set ID][ ][OK/NG][Data][x]

1111.. SShhaarrppnneessss ((CCoommmmaanndd:: kk kk))

To adjust screen sharpness.

You can also adjust sharpness in the PICTURE menu.

Transmission [k][k][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’ as shown below.

Acknowledgement [k][ ][Set ID][ ][OK/NG][Data][x]

1122.. OOSSDD SSeelleecctt ((CCoommmmaanndd:: kk ll))

To select OSD (On Screen Display) on/off.

Transmission [k][l][ ][Set ID][ ][Data][Cr]

Data 00: OSD off Data 01: OSD on

Acknowledgement [l][ ][Set ID][ ][OK/NG][Data][x]

1133.. RReemmoottee CCoonnttrrooll LLoocckk MMooddee ((CCoommmmaanndd:: kk mm))

To lock the remote control and the front panel controls

on the set.

Transmission [k][m][ ][Set ID][ ][Data][Cr]

Data 00: Lock off Data 01: Lock on

Acknowledgement [m][ ][Set ID][ ][OK/NG][Data][x]

If you’re not using the remote control and front panel

controls on the TV, use this mode. When main power is

on/off, remote control lock is released.

1144.. TTrreebbllee ((CCoommmmaanndd:: kk rr))

To adjust treble.

You can also adjust treble in the AUDIO menu.

Transmission [k][r][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’ as shown.

Acknowledgement [r][ ][Set ID][ ][OK/NG][Data][x]

1155.. BBaassss ((CCoommmmaanndd:: kk ss))

To adjust bass.

You can also adjust bass in the AUDIO menu.

Transmission [k][s][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’ as shown below.

Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x]

1166.. BBaallaannccee ((CCoommmmaanndd:: kk tt))

To adjust balance.

You can also adjust balance in the AUDIO menu.

Transmission [k][t][ ][Set ID][ ][Data][Cr]

Data Min: 00 ~ Max: 64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping’ as shown below.

Acknowledgement [t][ ][Set ID][ ][OK/NG][Data][x]

1177.. CCoolloorr TTeemmppeerraattuurree ((CCoommmmaanndd:: kk uu))

To adjust color temperature.

You can also adjust color temperature in the PICTURE menu.

Transmission [k][u][ ][Set ID][ ][Data][Cr]

Data 00: Medium 01: Cool 02: Warm

Acknowledgement [u][ ][Set ID][ ][OK/NG][Data][x]

*Real data mapping

0 : Step 0

A : Step 10 (SET ID 10)

F : Step 15 (SET ID 15)

10 : Step 16 (SET ID 16)

63 : Step 99 (SET ID 99)

64 : Step 100

APPENDIX

112

APPENDIX

1188.. AAuuttoo CCoonnffiigguurraattiioonn ((CCoommmmaanndd:: jj uu))

To adjust picture position and minimize image shaking

automatically. Auto configuration only works in RGB-PC

mode.

Transmission [ j ][u][ ][Set ID][ ][Data][Cr]

Data 1: To set

Acknowledgement [u][ ][Set ID][ ][OK/NG][Data][x]

1199.. CChhaannnneell TTuunniinngg ((CCoommmmaanndd:: mm aa))

To tune channel to following physical/major/minor number.

Transmission [m][a][ ][Set ID][ ][Data00][ ][Data01]

[ ][Data02][ ][Data03][ ][Data04][ ][Data05][Cr]

Digital channels have a Physical, Major, and Minor channel

number. The Physical number is the actual digital channel

number, the Major is the number that the channel should

be mapped to, and the Minor is the sub-channel. Since

the ATSC tuner automatically maps the channel to the

Major number, the Physical number is not required when

sending a command.

Data 00: Physical Channel Number

NTSC air: 02~45, NTSC cable: 01, 0E~7D

ATSC air: 01~45, ATSC cable: 01~87

Data 01 & 02: Major Channel Number

Data 01: High byte Data 02: Low byte

Two bytes are available for the Major and Minor, nor-

mally only the second byte is used.

Data 03 & 04: Minor Channel Number

Not needed for NTSC.

APPENDIX

113

Data05:

The table above lists the binary code which must be

converted to Hexadecimal before sending. For example:

The binary code to tune the sub source to an NTSC

cable channel is “1000 0001”, which translates to “81”

in Hex.

* 7th bit : For which source do you want to change the

channel.

* 6th bit: Use a two part or one part channel. Most cases

just use 0 since it’s ignored when using NTSC.

* 5th bit: Use 0 with NTSC since it can only use the phys-

ical channel number. Normally use 1 for ATSC since most

times it doesn’t matter what the physical number is.

* 4th bit: Set to 0.

* 3-0 bits: Choose signal type.

* Tune Command Examples:

1. Tune to the analog (NTSC) cable channel 35.

Data 00 = Physical of 35 = 23

Data 01 & 02 = No Major = 00 00

Data 03 & 04 = No Minor = 00 00

Data 05 = 0000 0001 in binary = 01

Total = ma 00 23 00 00 00 00 01

2. Tune to the digital (ATSC) local channel 30-3.

Data 00 = Don’t know Physical = 00

Data 01 & 02 = Major is 30 = 00 1E

Data 03 & 04 = Minor is 3 = 00 03

Data 05 = 0010 0010 in binary = 22

Total = ma 00 00 00 1E 00 03 22

Acknowledgement[a][ ][Set ID][ ][OK][Data00][Data01]

[Data02][Data03][Data04][x][a][ ][Set ID]

[ ][NG][Data00][x]

2200.. CChhaannnneell AAdddd//DDeell ((CCoommmmaanndd:: mm bb))

To add and delete the channels

Transmission [m][b][ ][Set ID][ ][Data][Cr]

Data 00: Channel Delete Data 01: Channel Add

Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x]

2211.. KKeeyy ((CCoommmmaanndd:: mm cc))

To send IR remote key code.

Transmission [m][c][ ][Set ID][ ][Data][Cr]

Data Key code: Refer to page 106.

Acknowledgement [c][ ][Set ID][ ][OK/NG][Data][x]

2222.. BBaacckklliigghhtt ((CCoommmmaanndd:: mm gg))

To adjust screen backlight.

Transmission [m][g][ ][Set ID][ ][Data][Cr]

Data Min:00 ~ Max:64 (*transmit by Hexadecimal code)

*Refer to ‘Real data mapping ’. See page 111.

Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x]

Step

NTSC Air

NTSC Cable

ATSC Air

ATSC Cable_std

ATSC Cable_hrc

ATSC Cable_irc

ATSC cable_auto

Reserved

...

Reserved

Use

No Use

Using Physical

Channel

Two

One

Two/One

Part Channel

Main

Sub

Main/Sub


LG Electronics 37LG50 37” Class LCD HDTV (37.0” diagonal)

Product's Documents

User Manual

Specifications

LG Electronics 37LG50 Questions and Answers

Related Products

LG Electronics 52LB9DF 52” LCD HDTV with 1080p Resolution

LG Electronics 20LS7D 20” LCD HDTV

LG Electronics 23LS7D 23” LCD HDTV

LG Electronics 42LB9DF 42” LCD HDTV

LG Electronics 32LB9D 32” LCD HDTV

LG Electronics 42LB4DS 42” CLASS LCD HDTV
