User Manual Whirlpool UXT5536AAS 36" Convertible Under-Cabi

Documents for Whirlpool UXT5536AAS

The following documents are available:
User Manual

User Manual - (English, French) Read Online | Download pdf

Photos

Photos: View Photos

User Manual

For UXT5536AAS.

30" AND 36" (76.2 AND 91.4 CM) RANGE HOOD

Installation Instructions and Use & Care Guide

HOTTE DE CUISINIÈRE

DE 30" ET 36" (76,2 ET 91,4 CM)

Instructions d’installation et Guide d’utilisation et d’entretien

Table of Contents/Table des matières .....................................2

IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.

FOR RESIDENTIAL USE ONL

Y.

IMPOR

TANT : LIRE ET CONSERVER CES INSTRUCTIONS.

POUR UTILISA

TION RÉSIDENTIELLE UNIQUEMENT

.

LI3VQD/W10274302E

Loading ...

File type: PDF

File name: Whirlpool UXT5536AAS 36" Convertible Under-Cabinet Hood.pdf

File size: 2.24 MB

File Language: English, French

Pages: 28

Author: Whirlpool

Published: 2019-06-07 17:00:00

Updated: 2023-08-03

Verified by Clementina Bode on 2023-08-03

Download File

Specifications

Brand: Whirlpool

Model: UXT5536AAS

Category: Hoods

Whirlpool UXT5536AAS Questions and Answers

#1 Is there a stainless steel plate behind this range as shown in photo?

This unit will not have the stainless plate in the back.

#2 what does covertible pertain to on this product.

The convertible means it can recirculate the air back into your home through a filter or it can be vented to the outside.

#3 Is the duct rectangular?

No the duct for this unit is a cylinder. The initial connection is a rectangle however.

#4 Does this item comes with a set of charcoal filters for starters?

The Whirlpool range hood will come with a grease filter.

#5 Distance from cooking surface?

Per the installation guide, the below specifications are listed for the distance between the cooking surface and the bottom of the vent. 24" (61.0 cm) min. for electric cooking surfaces 27" (68.6 cm) min. for gas cooking surfaces 30" (76.2 cm) suggested max. - bottom of range hood to cooking surface
