Alphard
Wind deectors
Installation Instructions
Model year: 2015/01
Vehicle code: GGH30*-PFT*K
Part number: 08162-58810
Manual reference number: AIM 003 374-0

Fr x4 Rr x4
3M VHB
3M
VHB
SURFACE
CLEANER
3M Adhesion Promoter
UV 4298
(4x) PZ415-00000-00
Manual reference number: AIM 003 374-0 2 of 7
Revision record
Rev. No. Date Page Picture Update New Deleted steps
C D
4x4x
1x 1x
1x 1x
A A
B B

1
1
DRY
MIN 90 sec.
MAX 60 min.
3M
VHB
SURFACE
CLEANER
2 3 4
3M Adhesion Promoter
UV 4298
(4x) PZ415-00000-00
MSDS
40°C
18°C
Manual reference number: AIM 003 374-0 3 of 7
2
1

50 mm
50 mm
50 mm
Manual reference number: AIM 003 374-0 4 of 7
4
3
A
B

0 mm
A
A
A-A
1 2 3
A-A
A
A
A
A
1,5 mm
1,5 mm
Manual reference number: AIM 003 374-0 5 of 7
6
5
B
A

G
G
40 º
G
G
40 º
G-G
1
2
3
Manual reference number: AIM 003 374-0 6 of 7
9
8
7
D
C

CHECK SHEET
VIN n°
Model / Year Alphard 2015/01
Wind deflectors
Installation Date: Stamp:Technician Name & Signature:
. . / . . / . . . .
= OK
P/N = OK
= OK
Manual reference number: AIM 003 374-0 7 of 7
