Camera User Guide
ENGLISH
©CANON INC. 2013 CDD-E555-010
• Click the buttons in the lower right to access other pages.
: Next page
: Previous page
: Page before you clicked a link
• To jump to the beginning of a chapter, click the chapter
title at right.
From chapter title pages, you can access topics by
clicking their titles.
• Make sure you read this guide, including the “Safety
Precautions” (=
7) section, before using the camera.
• Reading this guide will help you learn to use the camera
properly.
• Store this guide safely so that you can use it in the
future.
2
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Package Contents
Before use, make sure the following items are included in the package.
If anything is missing, contact your camera retailer.
Camera Battery Pack
NB-6LH
Battery Charger
CB-2LY/CB-2LYE
Neck Strap Lens Cap
(with cord)
Getting Started
Warranty Card
•A memory card is not included (=
2).
Compatible Memory Cards
The following memory cards (sold separately) can be used, regardless of
capacity.
• SD memory cards*
• SDHC memory cards*
• SDXC memory cards*
* CardsconformingtoSDstandards.However,notallmemorycardshavebeenveried
to work with the camera.
Preliminary Notes and Legal
Information
• Take and review some test shots initially to make sure the images were
recorded correctly. Please note that Canon Inc., its subsidiaries and
afliates,anditsdistributorsarenotliableforanyconsequentialdamages
arising from any malfunction of a camera or accessory, including memory
cards, that result in the failure of an image to be recorded or to be
recorded in a way that is machine readable.
• Images recorded by the camera are intended for personal use. Refrain
from unauthorized recording that infringes on copyright law, and note that
even for personal use, photography may contravene copyright or other
legal rights at some performances or exhibitions, or in some commercial
settings.
• The camera warranty is valid only in the area of purchase. In case of
camera problems while abroad, return to the area of purchase before
contacting a Canon Customer Support Help Desk.
• Although the LCD monitor is produced under extremely high-precision
manufacturing conditions and more than 99.99% of the pixels meet
designspecications,inrarecasessomepixelsmaybedefectiveormay
appear as red or black dots. This does not indicate camera damage or
affect recorded images.
• TheLCDmonitormaybecoveredwithathinplasticlmforprotection
againstscratchesduringshipment.Ifcovered,removethelmbefore
using the camera.
• When the camera is used over an extended period, it may become warm.
This does not indicate damage.
3
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Part Names and Conventions in This
Guide
Zoom lever
Shooting: <i (telephoto)> /
<j (wide angle)>
Playback: <k (magnify)> /
<g (index)>
Shutter button
Strap mount
Mode dial
Power button
Flash
Wi-Fi antenna area
Lamp
Speaker
< (Framing Assist – Seek)>
button
Lens
Tripod socket
DC coupler terminal cover
Memory card/battery cover
• Shooting modes and on-screen icons and text are indicated in brackets.
•
: Important information you should know
•
: Notes and tips for expert camera use
• = xx: Pages with related information (in this example, “xx” represents a
page number)
• Instructions in this guide apply to the camera under default settings.
• For convenience, all supported memory cards are simply referred to as
the “memory card”.
• The tabs shown above titles indicate whether the function is used for still
images, movies, or both.
Still Images
: Indicates that the function is used when shooting or
viewing still images.
Movies
: Indicates that the function is used when shooting or
viewing movies.
4
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Screen (LCD monitor)
Microphone
<1 (Playback)> button
Movie button
AV OUT (Audio/video output) /
DIGITAL terminal
HDMI
TM
terminal
<b (Exposure compensation)> /
<a (Single-image erase)> button
Indicator
<l (Display)> button
<n> button
< (ISO speed)> / < (Wi-Fi)> /
Up button
<e (Macro)> /
<f (Manual focus)> /
Left button
Control dial
FUNC./SET button
<h (Flash)> / Right button
<Q (Self-timer)> / Down button
Turning the control dial is one way to
choose setting items, switch images, and
perform other operations. Most of these
operations are also possible with the
<o><p><q><r> buttons.
• In this guide, icons are used to represent the corresponding camera
buttons and dials on which they appear or which they resemble.
• The following camera buttons and controls are represented by icons.
<o> Up button
on back
<q> Left button on back
<r> Right button on back
<p> Down button on back
<5> Control dial on back
5
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
5 Tv, Av, and M Mode .............. 68
Specic Shutter Speeds
([Tv] Mode)...................................69
Specic Aperture Values
([Av] Mode) ..................................69
Specic Shutter Speeds and
Aperture Values ([M] Mode) .........70
6 Playback Mode ....................72
Viewing ........................................73
Browsing and Filtering Images ....76
Image Viewing Options ................78
Protecting Images ........................80
Erasing Images ............................83
Rotating Images ...........................85
Tagging Images as Favorites .......87
Editing Still Images ......................88
Editing Movies..............................91
7 Wi-Fi Functions ...................93
What You Can Do with Wi-Fi .......94
Preparing to Share Images
via Wi-Fi .......................................95
Registering Web Services ............96
Installing CameraWindow
on a Smartphone .........................99
Preparing to Register
a Computer ................................100
Accessing the Wi-Fi Menu .........101
Connecting via an Access Point 102
Connecting without an Access
Point ...........................................106
Connecting to Another Camera .108
Sending Images .........................109
Saving Images to a Computer ... 111
Sending Images Automatically
(Image Sync)..............................112
Geotagging Images
on the Camera ........................... 114
Editing or Erasing Wi-Fi Settings
...................................................114
8 Setting Menu ...................... 117
Adjusting Basic Camera
Functions ................................... 118
9 Accessories .......................124
System Map ...............................125
Optional Accessories .................126
Using Optional Accessories .......127
Using the Software ....................131
Printing Images ..........................133
10 Appendix ............................142
Troubleshooting .........................143
On-Screen Messages ................146
On-Screen Information ..............149
Functions and Menu Tables .......151
Handling Precautions .................159
Specications .............................159
Index ..........................................163
Wi-Fi (Wireless LAN)
Precautions ................................165
Table of Contents
Package Contents .........................2
Compatible Memory Cards ............2
Preliminary Notes and Legal
Information .....................................2
Part Names and Conventions
in This Guide ..................................3
Table of Contents ...........................5
Common Camera Operations ........6
Safety Precautions .........................7
Basic Guide .................... 10
Initial Preparations ....................... 11
Trying the Camera Out ................16
Advanced Guide ............. 19
1 Camera Basics .....................19
On/Off ..........................................20
Shutter Button ..............................21
Shooting Modes ...........................21
Shooting Display Options ............22
Using the FUNC. Menu ................22
Using Menus ................................23
On-Screen Keyboard ...................24
Indicator Display ..........................25
Clock ............................................25
2 Auto Mode ............................26
Shooting with Camera-Determined
Settings ........................................27
Common, Convenient Features ...31
Image Customization Features ....36
Helpful Shooting Features ...........38
Customizing Camera Operation ..40
3 Other Shooting Modes ........42
Discreet Mode ..............................43
Auto Clip Recording
(Movie Digest) ..............................43
Brightness / Color Customization
(Live View Control) .......................44
Specic Scenes ...........................45
Image Effects (Creative Filters) ...46
Special Modes for Other
Purposes ......................................49
Shooting Various Movies .............51
4 P Mode ..................................53
Shooting in Program AE
([P] Mode) ....................................54
Image Brightness (Exposure) ......54
Color and Continuous Shooting ...56
Shooting Range and Focusing ....59
Flash ............................................65
Other Settings ..............................66
6
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Common Camera Operations
4 Shoot
Use camera-determined settings
(Auto Mode, Movie Digest Mode) ..................................................27, 43
Shooting people well
I
Portraits
(=
45)
P
Against Snow
(=
45)
Matching specic scenes
Low Light
(=
45)
t
Fireworks
(=
45)
Applying special effects
Vivid Colors
(=
46)
Poster Effect
(=
46)
Fish-Eye Effect
(=
46)
Miniature Effect
(=
47)
Toy Camera Effect
(=
48)
Monochrome
(=
48)
Where sound and ash are not allowed (Discreet Mode) ....................43
While adjusting image settings (Live View Control) ............................. 44
Focus on faces ...................................................................27, 45, 61, 62
Without using the ash (Flash Off) .......................................................27
Include yourself in the shot (Self-Timer) ........................................ 34, 49
Add a date stamp .................................................................................35
Movie clips and photos together (Movie Digest) ..................................43
7
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
1 View
View images (Playback Mode) .............................................................73
Automatic playback (Slideshow) ..........................................................78
On a TV ..............................................................................................127
On a computer ................................................................................... 131
Browse through images quickly ........................................................... 76
Erase images ....................................................................................... 83
E Shoot/View Movies
Shoot movies ................................................................................. 27, 51
View movies (Playback Mode) .............................................................73
Fast-moving subjects, slow-motion playback .......................................51
c Print
Print pictures ...................................................................................... 133
Save
Save images to a computer via a cable .............................................132
Save images to a computer ............................................................... 132
Use Wi-Fi Functions
Send images to a smartphone .............................................................95
Share images online ............................................................................ 96
Send images to a computer ................................................................112
Safety Precautions
• Before using the product, please ensure that you read the safety
precautions described below. Always ensure that the product is used
correctly.
• The safety precautions noted on the following pages are intended
to prevent injuries to yourself and other persons, or damage to the
equipment.
• Be sure to also check the guides included with any separately sold
accessories you use.
Warning
Denotes the possibility of serious injury or death.
• Donottriggertheashincloseproximitytopeople’seyes.
Exposure to the intense light produced by the ash could damage eyesight.
In particular, remain at least 1 meter (39 inches) away from infants when
using the ash.
• Storethisequipmentoutofthereachofchildrenandinfants.
Strap: Putting the strap around a child’s neck could result in asphyxiation.
Date/time battery (if removable): Dangerous if swallowed. If this occurs,
contact a doctor immediately.
• Useonlyrecommendedpowersources.
• Donotattempttodisassemble,alterorapplyheattotheproduct.
• Avoiddroppingorsubjectingtheproducttosevereimpacts.
• To avoid the risk of injury, do not touch the interior of the product if
ithasbeendroppedorotherwisedamaged.
• Stop using the product immediately if it emits smoke, a strange
smell,orotherwisebehavesabnormally.
• Do not use organic solvents such as alcohol, benzine, or thinner to
cleantheproduct.
• Donotlettheproductcomeintocontactwithwater(e.g.seawater)
orotherliquids.
8
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Donotallowliquidsorforeignobjectstoenterthecamera.
This could result in electrical shock or re.
If liquids or foreign objects come into contact with the camera interior,
immediately turn the camera off and remove the battery pack/batteries.
If the battery charger (for cameras that use one) becomes wet, unplug
it from the outlet and consult your camera retailer or a Canon Customer
Support Help Desk.
• Donotlookthroughtheviewnder(ifyourmodelhasone)atbright
lightsources,suchasthesunonaclearday.
This could damage your eyesight.
• Useonlytherecommendedbatterypack/batteries.
• Donotplacethebatterypack/batteriesnearorindirectame.
• If your camera uses a battery charger, note the following
precautions.
- Unplug the power cord periodically, and using a dry cloth, wipe
away any dust and dirt that has collected on the plug, the exterior
ofthepoweroutlet,andthesurroundingarea.
- Donothandlethepowercordwithwethands.
- Do not use the equipment in a manner that exceeds the rated
capacityoftheelectricaloutletorwiringaccessories.Donotuseif
the power cord or plug are damaged, or not fully plugged into the
outlet.
- Donotallowdirtormetalobjects(suchaspinsorkeys)tocontact
theterminalsorplug.
The battery pack/batteries may explode or leak, resulting in electrical shock
or re. This could cause injury and damage the surroundings. In the event
that a battery pack leaks and the battery electrolyte contacts eyes, mouth,
skin or clothing, immediately ush with water.
• Turnthecameraoffinplaceswherecamerauseisprohibited.
The electromagnetic waves emitted by the camera may interfere with the
operation of electronic instruments and other devices. Exercise adequate
caution when using the camera in places where use of electronic devices is
restricted, such as inside airplanes and medical facilities.
Caution
Denotes the possibility of injury.
• When holding the camera by the strap, be careful not to bang it,
subject it to strong impacts or shocks, or let it get caught on other
objects.
• Becarefulnottobumporpushstronglyonthelens.
This could lead to injury or damage the camera.
• Becarefulnottosubjectthescreentostrongimpacts.
If the screen cracks, injury may result from the broken fragments.
• Whenusingtheash,becarefulnottocoveritwithyourngersor
clothing.
This could result in burns or damage to the ash.
• Avoid using, placing or storing the product in the following places:
- Places subject to direct sunlight
- Placessubjecttotemperaturesabove40°C(104°F)
- Humid or dusty areas
These could cause leakage, overheating or an explosion of the battery
pack/batteries, resulting in electrical shock, re, burns or other injuries.
High temperatures may deform the product.
• The slideshow transition effects may cause discomfort when viewed
forprolongedperiods.
• Whenusingoptionallenses,lenslters,orlteradapters(if
applicable),besuretoattachtheseaccessoriesrmly.
If the lens becomes loose and falls off, it may crack, and the shards of glass
may lead to cuts.
• Oncamerasthatraiseandlowertheashautomatically,makesure
yourngerisoutofthewaywhentheashislowered,toavoid
pinchingit.
This could result in injury.
9
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Caution
Denotes the possibility of damage to the equipment.
• Do not aim the camera at bright light sources (such as the sun on a
clearday).
Doing so may damage the image sensor.
• When using the camera on a beach or at a windy location, be careful
nottoallowdustorsandtoenterthecamera.
• Oncamerasthatraiseandlowertheashautomatically,donotpush
theashdownorpryitopen.
This may cause the product to malfunction.
• In regular use, small amounts of smoke may be emitted from the
ash.
This is due to the high intensity of the ash burning dust and foreign
materials stuck to the front of the unit. Please use a cotton swab to remove
dirt, dust or other foreign matter from the ash to prevent heat build-up and
damage to the unit.
• Remove and store the battery pack/batteries when you are not using
thecamera.
If the battery pack or batteries are left inside the camera, damage caused
by leakage may occur.
• Before you discard the battery pack/batteries, cover the terminals
withtapeorotherinsulators.
Contacting other metal materials may lead to re or explosions.
• If your camera is used with a battery charger, keep the charger
unpluggedwhennotinuse.Whenchargingthebatterypack,donot
leaveitcoveredwithaclothorputotherobjectsonit.
Leaving the unit plugged in for a long period of time may cause it to
overheat and distort, resulting in re.
• Donotleavethebatterypacknearpets.
Pets biting the battery pack could cause leakage, overheating or explosion,
resulting in re or damage.
• If your camera uses multiple batteries, do not use batteries that have
different levels of charge together, do not use old and new batteries
together, and do not insert the batteries with the + and – terminals
reversed.
This may cause the product to malfunction.
• Donotsitdownwiththecamerainyourpocket.
Doing so may cause malfunctions or damage the screen.
• When putting the camera in your bag, ensure that hard objects do
notcomeintocontactwiththescreen.Alsoclosethescreen(sothat
itfacesthecamerabody),ifyourcamerahasascreenthatcloses.
• Donotattachanyhardobjectstothecamera.
Doing so may cause malfunctions or damage the screen.
10
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Basic Guide
Basic information and instructions, from initial preparations to shooting and
playback
Initial Preparations ........................................... 11
Attaching Accessories ...........................................11
Holding the Camera .............................................. 11
Charging the Battery Pack .................................... 11
Inserting the Battery Pack and Memory Card .......12
Setting the Date and Time .....................................14
Display Language .................................................15
Trying the Camera Out .....................................16
Shooting (Smart Auto) ...........................................16
Viewing ..................................................................17
11
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Initial Preparations
Prepare for shooting as follows.
Attaching Accessories
1 Attach the strap.
Attach the included strap to the camera
as shown.
On the other side of the camera, attach
the strap the same way.
2 Attach the lens cap to the strap.
Remove the lens cap from the lens and
attach the lens cap cord to the strap.
Always remove the lens cap before
turning the camera on.
Keep the lens cap on the lens when the
camera is not in use.
Holding the Camera
Place the strap around your neck.
When shooting, keep your arms close to
your body and hold the camera securely
to prevent it from moving. If you have
raised the ash, do not rest your ngers
on it.
Charging the Battery Pack
Before use, charge the battery pack with the included charger. Be sure to
charge the battery pack initially, because the camera is not sold with the
battery pack charged.
1 Insert the battery pack.
After aligning the ▲ marks on the battery
pack and charger, insert the battery pack
by pushing it in (
) and down ( ).
2 Charge the battery pack.
CB-2LY: Flip out the plug ( ) and plug
the charger into a power outlet (
).
CB-2LYE: Plug the power cord into the
charger, then plug the other end into a
power outlet.
The charging lamp turns orange and
charging begins.
When charging is nished, the lamp turns
green.
CB-2LY
CB-2LYE
12
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Remove the battery pack.
After unplugging the battery charger,
remove the battery pack by pushing it in
(
) and up ( ).
• To protect the battery pack and keep it in optimal condition, do not
charge it continuously for more than 24 hours.
• For battery chargers that use a power cord, do not attach the
charger or cord to other objects. Doing so could result in malfunction
or damage to the product.
• For details on charging time and the number of shots and recording time
possible with a fully charged battery pack, see “Number of Shots/Recording
Time, Playback Time” (=
160).
• Charged battery packs gradually lose their charge, even when they are not
used. Charge the battery pack on (or immediately before) the day of use.
• The charger can be used in areas with 100 – 240 V AC power (50/60 Hz). For
power outlets in a different format, use a commercially available adapter for
the plug. Never use an electrical transformer designed for traveling, which may
damage the battery pack.
Inserting the Battery Pack and Memory Card
Insert the included battery pack and a memory card (sold separately).
Note that before using a new memory card (or a memory card formatted
in another device), you should format the memory card with this camera
(=
121).
1 Check the card’s write-protect
tab.
Recording is not possible on memory
cards with a write-protect tab when the
tab is in the locked (downward) position.
Slide the tab up until it clicks into the
unlocked position.
2 Open the cover.
Slide the cover ( ) and open it ( ).
3 Insert the battery pack.
While pressing the battery lock in the
direction of the arrow, insert the battery
pack as shown and push it in until it clicks
into the locked position.
If you insert the battery pack facing the
wrong way, it cannot be locked into the
correct position. Always conrm that the
battery pack is facing the right way and
locks when inserted.
Terminals Battery
Lock
13
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Insert the memory card.
Insert the memory card facing as shown
until it clicks into the locked position.
Make sure the memory card is facing the
right way when you insert it. Inserting
memory cards facing the wrong way may
damage the camera.
5 Close the cover.
Lower the cover ( ) and hold it down as
you slide it, until it clicks into the closed
position (
).
• For guidelines on how many shots or hours of recording can be saved on one
memory card, see “Number of 4:3 Shots per Memory Card” (=
160).
Label
Removing the Battery Pack and Memory Card
Remove the battery pack.
Open the cover and press the battery
lock in the direction of the arrow.
The battery pack will pop up.
Remove the memory card.
Push the memory card in until it clicks,
and then slowly release it.
The memory card will pop up.
14
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Setting the Date and Time
Set the current date and time correctly as follows if the [Date/Time] screen
is displayed when you turn the camera on. Information you specify this way
is recorded in image properties when you shoot, and it is used when you
manage images by shooting date or print images showing the date.
You can also add a date stamp to shots, if you wish (=
35).
1 Turn the camera on.
Press the power button.
The [Date/Time] screen is displayed.
2 Set the date and time.
Press the <q><r> buttons to choose an
option.
Press the <o><p> buttons or turn the
<5> dial to specify the date and time.
When nished, press the <m> button.
3 Set the home time zone.
Press the <q><r> buttons or turn the
<5> dial to choose your home time
zone.
4 Finish the setup process.
Press the <m> button to complete the
setting. The setting screen is no longer
displayed.
To turn off the camera, press the power
button.
• Unless you set the date, time, and home time zone, the [Date/Time]
screen will be displayed each time you turn the camera on. Specify
the correct information.
• To set daylight saving time (1 hour ahead), choose [ ] in step 2 and then
choose [
] by pressing the <o><p> buttons or turning the <5> dial.
Changing the Date and Time
Adjust the date and time as follows.
1 Access the camera menu.
Press the <n> button.
15
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
2 Access the setting screen.
Press and hold the <m> button, and
then immediately press the <n>
button.
3 Set the display language.
Press the <o><p><q><r> buttons or
turn the <5> dial to choose a language,
and then press the <m> button.
Once the display language has been set,
the setting screen is no longer displayed.
• The current time is displayed if you wait too long in step 2 after pressing the
<m> button before you press the <n> button. In this case, press the
<m> button to dismiss the time display and repeat step 2.
• You can also change the display language by pressing the <n> button
and choosing [Language
] on the [3] tab.
2 Choose [Date/Time].
Move the zoom lever to choose the [3]
tab.
Press the <o><p> buttons or turn the
<5> dial to choose [Date/Time], and
then press the <m> button.
3 Change the date and time.
Follow step 2 in “Setting the Date and
Time” (=
14) to adjust the settings.
Press the <n> button to close the
menu.
• Date/time settings can be retained for about 3 weeks by the camera’s built-in
date/time battery (backup battery) after the battery pack is removed.
• The date/time battery will be charged in about 4 hours once you insert a
charged battery pack or connect the camera to an AC adapter kit (sold
separately, =
126), even if the camera is left off.
• Once the date/time battery is depleted, the [Date/Time] screen will be
displayed when you turn the camera on. Set the correct date and time as
described in “Setting the Date and Time” (=
14).
Display Language
Change the display language as needed.
1 Enter Playback mode.
Press the <1> button.
16
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Trying the Camera Out
Follow these instructions to turn the camera on, shoot still images or
movies, and then view them.
Shooting (Smart Auto)
For fully automatic selection of the optimal settings for specic scenes,
simply let the camera determine the subject and shooting conditions.
1 Turn the camera on.
Press the power button.
The startup screen is displayed.
2 Enter [ ] mode.
Set the mode dial to [ ].
Aim the camera at the subject. The
camera will make a slight clicking noise
as it determines the scene.
Icons representing the scene and image
stabilization mode are displayed in the
upper right of the screen.
Frames displayed around any detected
subjects indicate that they are in focus.
3 Compose the shot.
To zoom in and enlarge the subject, move
the zoom lever toward <i> (telephoto),
and to zoom away from the subject, move
it toward <j> (wide angle).
4 Shoot.
Shooting Still Images
Focus.
Press the shutter button lightly, halfway
down. The camera beeps twice after
focusing, and AF frames are displayed to
indicate image areas in focus.
If [Raise the ash] is displayed, lift the
ash with your nger to prepare it for use.
If you prefer not to use the ash, push it
down with your nger, into the camera.
17
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shoot.
Press the shutter button all the way
down.
As the camera shoots, a shutter sound
is played, and in low-light conditions
when you have raised the ash, it res
automatically.
Keep the camera still until the shutter
sound ends.
After displaying your shot, the camera will
revert to the shooting screen.
Even while the shot is displayed, you can
take another shot by pressing the shutter
button again.
Shooting Movies
Start shooting.
Press the movie button. The camera
beeps once as recording begins, and
[
Rec] is displayed with the elapsed
time.
Black bars displayed on the top and
bottom edges of the screen indicate
image areas not recorded.
Frames displayed around any detected
faces indicate that they are in focus.
Once recording begins, take your nger
off the movie button.
Elapsed Time
Finish shooting.
Press the movie button again to stop
shooting. The camera beeps twice as
recording stops.
Viewing
After shooting images or movies, you can view them on the screen as
follows.
1 Enter Playback mode.
Press the <1> button.
Your last shot is displayed.
2 Browse through your images.
To view the previous image, press
the <q> button or turn the <5> dial
counterclockwise. To view the next
image, press the <r> button or turn the
<5> dial clockwise.
Press and hold the <q><r> buttons to
browse through images quickly. Images
appear grainy at this time.
18
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
To access Scroll Display mode, turn the
<5> dial rapidly. In this mode, turn the
<5> dial to browse through images.
To return to single-image display, press
the <m> button.
Movies are identied by a [ ] icon. To
play movies, go to step 3.
3 Play movies.
Press the <m> button, choose [ ]
(either press the <o><p> buttons or
turn the <5> dial), and then press the
<m> button again.
Playback now begins, and after the movie
is nished, [
] is displayed.
To adjust the volume, press the <o><p>
buttons.
• To switch to Shooting mode from Playback mode, press the shutter button
halfway.
Erasing the Images
You can choose and erase unneeded images one by one. Be careful when
erasing images, because they cannot be recovered.
1 Choose an image to erase.
Press the <q><r> buttons or turn the
<5> dial to choose an image.
2 Erase the image.
Press the <a> button.
After [Erase?] is displayed, press the
<q><r> buttons or turn the <5> dial to
choose [Erase], and then press the <m>
button.
The current image is now erased.
To cancel erasure, press the <q><r>
buttons or turn the <5> dial to choose
[Cancel], and then press the <m>
button.
• You can also erase all images at once (=
84).
19
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Advanced Guide
1
Camera Basics
Practical guide that introduces other camera basics and describes shooting and playback
options
On/Off ................................................................20
Power-Saving Features (Auto Power Down) ........20
Shutter Button ..................................................21
Shooting Modes ............................................... 21
Shooting Display Options ............................... 22
Using the FUNC. Menu ....................................22
Using Menus .....................................................23
On-Screen Keyboard .......................................24
Indicator Display .............................................. 25
Clock .................................................................25
20
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
On/Off
Shooting Mode
Press the power button to turn the
camera on and prepare for shooting.
To turn the camera off, press the power
button again.
Playback Mode
Press the <1> button to turn the camera
on and view your shots.
To turn the camera off, press the <1>
button again.
• To switch to Playback mode from Shooting mode, press the <1> button.
• To switch to Shooting mode from Playback mode, press the shutter button
halfway (=
21).
• The lens will be retracted after about one minute once the camera is in
Playback mode. You can turn the camera off when the lens is retracted by
pressing the <1> button.
Power-Saving Features (Auto Power Down)
As a way to conserve battery power, the camera automatically deactivates
the screen (Display Off) and then turns itself off after a specic period of
inactivity.
Power Saving in Shooting Mode
The screen is automatically deactivated after about one minute of inactivity.
In about two more minutes, the lens is retracted and the camera turns itself
off. To activate the screen and prepare for shooting when the screen is off
but the lens is still out, press the shutter button halfway (=
21).
Power Saving in Playback Mode
The camera turns itself off automatically after about ve minutes of
inactivity.
• You can deactivate Auto Power Down and adjust the timing of Display Off, if
you prefer (=
120).
• Power saving is not active while the camera is connected to a computer
(=
132), or when connected to other devices via Wi-Fi (=
93).
21
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shutter Button
To ensure your shots are in focus, always begin by holding the shutter
button halfway down, and once the subject is in focus, press the button all
the way down to shoot.
In this manual, shutter button operations are described as pressing the
button halfway or all the way down.
1 Press halfway. (Press lightly to
focus.)
Press the shutter button halfway. The
camera beeps twice, and AF frames are
displayed around image areas in focus.
2 Press all the way down. (From
the halfway position, press fully
to shoot.)
The camera shoots, as a shutter sound
is played.
Keep the camera still until the shutter
sound ends.
• Images may be out of focus if you shoot without initially pressing the
shutter button halfway.
• Length of shutter sound playback varies depending on the time
required for the shot. It may take longer in some shooting scenes,
and images will be blurry if you move the camera (or the subject
moves) before the shutter sound ends.
Shooting Modes
Use the mode dial to access each shooting mode.
P, Tv, Av, and M Modes
Take a variety of shots
using your preferred
settings (=
53, 68).
Movie Mode
For shooting
movies (=
51).
You can also shoot
movies when the
mode dial is not
set to Movie mode,
simply by pressing
the movie button.
Auto Mode
Fully automatic shooting, with camera-
determined settings (=
16, 27).
Scene Mode
Shoot with optimal settings
for specic scenes (=
45).
Creative Filters Mode
Add a variety of effects to images
when shooting (=
46).
Discreet Mode
Shoot without the ash or
camera sounds (=
43).
Movie Digest Mode
You can make a short movie of a day just
by shooting still images (=
43).
Live View Control Mode
Customize image brightness or colors
when shooting (=
44).
• You can turn the mode dial to switch to Shooting mode from Playback mode.
22
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shooting Display Options
Press the <l> button to view other information on the screen, or to hide
the information. For details on the information displayed, see “On-Screen
Information” (=
149).
Information is displayed No information is
displayed
• Screen brightness is automatically increased by the night display function
when you are shooting under low light, making it easier to check how shots
are composed. However, on-screen image brightness may not match the
brightness of your shots. Note that any on-screen image distortion or jerky
subject motion will not affect recorded images.
• For playback display options, see “Switching Display Modes” (=
74).
Using the FUNC. Menu
Congure commonly used functions through the FUNC. menu as follows.
Note that menu items and options vary depending on the shooting mode
(=
153 – 154) or playback mode (=
158).
1 Access the FUNC. menu.
Press the <m> button.
2 Choose a menu item.
Press the <o><p> buttons or turn the
<5> dial to choose a menu item, and
then press the <m> or <r> button.
Depending on the menu item, functions
can be specied simply by pressing the
<m> or <r> button, or another screen is
displayed for conguring the function.
3 Choose an option.
Press the <o><p> buttons or turn the
<5> dial to choose an option.
To return to the menu items, press the
<q> button.
Options
Menu Items
23
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Finish the setup process.
Press the <m> button.
The screen before you pressed the
<m> button in step 1 is displayed again,
showing the option you congured.
• To undo any accidental setting changes, you can restore the camera’s default
settings (=
123).
Using Menus
Congure a variety of camera functions through other menus as follows.
Menu items are grouped by purpose on tabs, such as shooting [4],
playback [1], and so on. Note that available menu items vary depending
on the selected shooting or playback mode (=
155 – 158).
1 Access the menu.
Press the <n> button.
2 Choose a tab.
Move the zoom lever to choose a tab.
After you have pressed the <o><p>
buttons to choose a tab initially, you can
switch between tabs by pressing the
<q><r> buttons.
24
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Choose a menu item.
Press the <o><p> buttons or turn the
<5> dial to choose a menu item.
For menu items with options not shown,
rst press the <m> or <r> button to
switch screens, and then either press the
<o><p> buttons or turn the <5> dial
to select the menu item.
To return to the previous screen, press
the <n> button.
4 Choose an option.
Press the <q><r> buttons to choose an
option.
5 Finish the setup process.
Press the <n> button to return to the
screen displayed before you pressed the
<n> button in step 1.
• To undo any accidental setting changes, you can restore the camera’s default
settings (=
123).
On-Screen Keyboard
The keyboard is displayed when you must enter information, such as a
camera nickname for Wi-Fi connections. Note that the length and type of
information you can enter varies depending on the function you are using.
Entering Characters
Press the <o><p><q><r> buttons or
turn the <5> dial to choose a character,
and then press the <m> button to enter
it.
Moving the Cursor
Choose [ ] or [ ] and press the <m>
button.
Deleting Characters
To delete the previous character, either
press the <a> button or choose [
] and
press the <m> button.
ConrmingInputandReturningto
the Previous Screen
Press the <n> button.
Number of
Available Characters
25
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Indicator Display
The indicator on the back of the camera (=
4) lights up or blinks
depending on the camera status.
Color
Indicator
Status
Camera Status
Green
On
Connected to a computer (=
132), or display off
(=
20, 119)
Blinking
Starting up, recording/reading/transmitting images,
shooting long exposures (=
69, 70), or connecting/
transmitting via Wi-Fi
• When the indicator blinks green, never turn the camera off, open the
memory card/battery cover, or shake or jolt the camera, which may
corrupt images or damage the camera or memory card.
Clock
You can check the current time.
Press and hold the <m> button.
The current time appears.
If you hold the camera vertically while
using the clock function, it will switch
to vertical display. Press the <q><r>
buttons or turn the <5> dial to change
the display color.
Press the <m> button again to cancel
the clock display.
• When the camera is off, press and hold the <m> button, then press the power
button to display the clock.
26
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Auto Mode
Convenient mode for easy shots with greater control over shooting
2
Shooting with Camera-Determined Settings .27
Shooting (Smart Auto) ...........................................27
Scene Icons ..........................................................30
Image Stabilization Icons ......................................30
On-Screen Frames ................................................31
Common, Convenient Features ......................31
Zooming In Closer on Subjects (Digital Zoom) .....31
Reacquiring Subjects Lost after Zooming
(Framing Assist – Seek) ....................................... 32
Constantly Displaying Faces at the Same Size ....33
Using the Self-Timer..............................................34
Adding a Date Stamp ............................................ 35
Image Customization Features .......................36
Changing the Aspect Ratio ....................................36
Changing Image Resolution (Size) .......................37
Red-Eye Correction ...............................................37
Changing Movie Image Quality ............................. 38
Helpful Shooting Features ..............................38
Displaying Grid Lines ............................................38
Magnifying the Area in Focus ................................39
Checking for Closed Eyes .....................................39
Customizing Camera Operation .....................40
Deactivating the AF-Assist Beam ..........................40
Deactivating the Red-Eye Reduction Lamp ..........40
Changing the Image Display Style after Shots ......40
27
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Compose the shot.
To zoom in and enlarge the subject, move
the zoom lever toward <i> (telephoto),
and to zoom away from the subject, move
it toward <j> (wide angle). (A zoom bar
showing the zoom position is displayed.)
To zoom in or out quickly, move the zoom
lever all the way toward <i> (telephoto)
or <j> (wide angle), and to zoom in
or out slowly, move it just a little in the
desired direction.
4 Shoot.
Shooting Still Images
Focus.
Press the shutter button halfway. The
camera beeps twice after focusing, and
AF frames are displayed to indicate
image areas in focus.
Several AF frames are displayed when
multiple areas are in focus.
If [Raise the ash] is displayed, lift the
ash with your nger to prepare it for use.
If you prefer not to use the ash, push it
down with your nger, into the camera.
Zoom Bar
Focus Range (approx.)
Shooting with Camera-Determined
Settings
For fully automatic selection of the optimal settings for specic scenes,
simply let the camera determine the subject and shooting conditions.
Still Images Movies
Shooting (Smart Auto)
1 Turn the camera on.
Press the power button.
The startup screen is displayed.
2 Enter [ ] mode.
Set the mode dial to [ ].
Aim the camera at the subject. The
camera will make a slight clicking noise
as it determines the scene.
Icons representing the scene and image
stabilization mode are displayed in the
upper right of the screen (=
30).
Frames displayed around any detected
subjects indicate that they are in focus.
28
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shoot.
Press the shutter button all the way
down.
As the camera shoots, a shutter sound
is played, and in low-light conditions
when you have raised the ash, it res
automatically.
Keep the camera still until the shutter
sound ends.
After displaying your shot, the camera will
revert to the shooting screen.
Even while the shot is displayed, you can
take another shot by pressing the shutter
button again.
Shooting Movies
Start shooting.
Press the movie button. The camera
beeps once as recording begins, and
[
Rec] is displayed with the elapsed
time.
Black bars displayed on the top and
bottom edges of the screen indicate
image areas not recorded.
Frames displayed around any detected
faces indicate that they are in focus.
Once recording begins, take your nger
off the movie button.
Elapsed Time
Resize the subject and
recompose the shot as needed.
To resize the subject, repeat the
operations in step 3 (=
27).
However, note that the sound of camera
operations will be recorded, and movies
shot at zoom factors shown in blue will
look grainy.
When you recompose shots, the
focus, brightness, and colors will be
automatically adjusted.
Finish shooting.
Press the movie button again to stop
shooting. The camera beeps twice as
recording stops.
Recording will stop automatically when
the memory card becomes full.
Still Images/Movies
• If the camera is turned on while the <l> button is held down,
the camera will no longer sound. To activate sounds again, press
the <n> button and choose [Mute] on the [3] tab, and then
press the <q><r> buttons to choose [Off].
29
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
• A blinking [ ] icon warns that images are more likely to be blurred
by camera shake. In this case, mount the camera on a tripod or take
other measures to keep it still.
• If your shots are dark despite the ash ring, move closer to the
subject. For details on the ash range, see “Flash Range” (=
161).
• The subject may be too close if the camera only beeps once when
you press the shutter button halfway. For details on the focusing
range (shooting range), see “Shooting Range” (=
161).
• To reduce red-eye and to assist in focusing, the lamp may be
activated when shooting in low-light conditions.
• A blinking [h] icon displayed when you attempt to shoot indicates
that shooting is not possible until the ash has nished recharging.
Shooting can resume as soon as the ash is ready, so either press
the shutter button all the way down and wait, or release it and press
it again.
• Although you can shoot again before the shooting screen is
displayed, your previous shot may determine the focus, brightness,
and colors used.
• You can change how long images are displayed after shots (=
40).
Movies
• Before shooting a movie, lower the ash
with your nger. Be careful not to touch
the microphone when shooting a movie.
Leaving the ash raised, or blocking
the microphone may prevent audio
from being recorded or may cause the
recording to sound mufed.
• Avoid touching camera controls other than the movie button when
shooting movies, because sounds made by the camera will be
recorded.
• Once movie recording begins, a smaller image display area is
shown, with the subject enlarged. This change is due to rotational
image stabilization. To shoot subjects at the same size shown
before shooting, adjust the image stabilization setting (=
67).
• Audio is recorded in stereo.
• Distorted audio caused by recording when the wind is strong can be reduced.
However, the recording may sound unnatural when this option is used when
there is no wind. When the wind is not strong, press the <n> button,
choose [Wind Filter] on the [4] tab, and then choose [Off] (=
23).
Microphone
30
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Scene Icons
In [ ] mode, shooting scenes determined by the camera are indicated
by the icon displayed, and corresponding settings are automatically
selected for optimal focusing, subject brightness, and color.
Subject
Background
People Other Subjects
Icon
Background
Color
In
Motion*
1
Shadows
on Face*
1
In
Motion*
1
At Close
Range
Bright
Gray
Backlit
–
With Blue
Sky
Light Blue
Backlit
–
Sunsets – – Orange
Spotlights
Dark Blue
Dark
Tripod
Used
*
2
–
*
2
–
*1 Not displayed for movies.
*2 Displayed in dark scenes when the camera is held still, as when mounted on a tripod.
• Try shooting in [G] mode (=
53) if the scene icon does not match
actual shooting conditions, or if it is not possible to shoot with your
expected effect, color, or brightness.
Still Images Movies
Image Stabilization Icons
Optimal image stabilization for the shooting conditions is automatically
applied (Intelligent IS). Additionally, the following icons are displayed in
[ ] mode.
Image stabilization for still
images
Image stabilization for movies,
reducing strong camera shake,
as when shooting while walking
(Dynamic IS)
Image stabilization for still
images when panning*
Image stabilization for slow
camera shake, such as when
shooting movies at telephoto
(Powered IS)
Image stabilization for macro
shots (Hybrid IS)
No image stabilization, because
the camera is mounted on
a tripod or held still by other
means. However, some shooting
conditions will activate image
stabilization.
* Displayed when you pan, following moving subjects with the camera. When you follow
subjects moving horizontally, image stabilization only counteracts vertical camera
shake, and horizontal stabilization stops. Similarly, when you follow subjects moving
vertically, image stabilization only counteracts horizontal camera shake.
• To cancel image stabilization, set [IS Mode] to [Off] (=
67). In this case, an
IS icon is not displayed.
31
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
On-Screen Frames
A variety of frames are displayed once the camera detects subjects you are
aiming the camera at.
• A white frame is displayed around the subject (or person’s face)
determined by the camera to be the main subject, and gray frames are
displayed around other detected faces. Frames follow moving subjects
within a certain range to keep them in focus.
However, if the camera detects subject movement, only the white frame
will remain on the screen.
• When you are pressing the shutter button halfway and the camera
detects subject movement, a blue frame is displayed, and the focus and
image brightness are constantly adjusted (Servo AF).
• Try shooting in [G] mode (=
53) if no frames are displayed, if
frames are not displayed around desired subjects, or if frames are
displayed on the background or similar areas.
Common, Convenient Features
Still Images Movies
Zooming In Closer on Subjects (Digital Zoom)
When distant subjects are too far away to enlarge using the optical zoom,
use digital zoom for up to about 120x enlargement.
1 Move the zoom lever toward
<i>.
Hold the lever until zooming stops.
Zooming stops at the largest possible
zoom factor (before the image becomes
noticeably grainy), which is then indicated
on the screen.
2 Move the zoom lever toward
<i> again.
The camera zooms in even closer on the
subject.
Zoom Factor
32
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Moving the zoom lever will display the zoom bar (which indicates
the zoom position). The color of the zoom bar will change depending
on the zoom range.
- White range: optical zoom range where the image will not appear
grainy.
- Yellow range: digital zoom range where the image is not noticeably
grainy (ZoomPlus).
- Blue range: digital zoom range where the image will appear grainy.
Because the blue range will not be available at some resolution
settings (=
37), the maximum zoom factor can be achieved by
following step 1.
• Focal length when optical and digital zoom are combined is as follows (35mm
lm equivalent).
24 – 2880 mm (24 – 720 mm with optical zoom alone)
• To deactivate digital zoom, press the <n> button, choose [Digital Zoom]
on the [4] tab, and then choose [Off].
Still Images Movies
Reacquiring Subjects Lost after Zooming
(Framing Assist – Seek)
If you lose track of a subject while zooming in, you can nd it more easily by
temporarily zooming out.
1 Look for the lost subject.
Press and hold the < > button.
The camera zooms out and displays a
white frame around the area previously
shown (before you pressed the <
>
button).
2 Reacquire the subject.
Aim the camera so that the subject enters
the white frame, and then release the
<
> button.
The previous magnication is now
restored, so that the area outlined in
white lls the screen again.
• Some shooting information is not displayed while the camera is
zoomed out.
• During movie shooting, the white frame is not displayed if you press
the <
> button. Also note that camera operating sounds such as
zooming will be recorded.
33
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• If you prefer to shoot at the zoom factor of the screen in step 1, press the
shutter button all the way down.
• You can adjust the zoom factor that the camera will revert to after Zoom
Framing Assist (when you release the <
> button) by moving the zoom lever
as you hold the <
> button to resize the white frame.
• To adjust how much the camera zooms out when the <
> button is pressed,
press the <n> button and choose one of the three levels in [
Display
Area] on the [4] tab.
• The zoom factor cannot be changed with the <
> button after you press the
shutter button all the way down in self-timer mode (=
34).
Still Images Movies
Constantly Displaying Faces at the Same Size
When a person’s face is detected, the camera will try to maintain a constant
face size relative to the screen. If the person moves closer, the camera will
automatically zoom out, and vice versa.
Enter Auto mode.
Aim the camera at the person’s face.
Press and release the <
> button
quickly.
After [ Auto: On] is displayed, a frame
[
] is displayed around the face detected
as the main subject, which the camera will
continue to display at the same size.
To adjust the face size relative to the
screen, move the zoom lever. The
camera will track the subject’s face at the
new size.
To cancel constant face size display,
press the <
> button again. [ Auto:
Off] is displayed.
• Faces may not be displayed at a constant size if the subject’s head
is tilted or facing the camera indirectly.
• Similarly, it may not be possible to maintain a constant face display
size at some zoom factors.
• This feature is not activated even if you press the < > button when
you have disabled [ Auto] (by pressing the <n> button and
choosing [4] tab > [
Auto] > [Off] (=
23)).
• In Auto mode, some shooting information is not displayed, and
some shooting settings cannot be congured.
• During movie recording, camera operating sounds such as zooming
will be recorded.
• To shoot continuously, access [W]. Note that continuous shooting is
not available if you choose [ ].
• If the person moves toward the edge of the screen, the camera will zoom out
automatically to keep the person in view.
• You can switch from tracking one face to another when several faces are
detected by pressing the <b> button. [
] is displayed around the new
subject. However, switching the [
] frame with the <b> button is not possible
during movie recording.
• The zoom factor will remain the same after you press the shutter button all the
way down in self-timer mode (=
34), even if the relative face size changes.
• [AF Frame] is set to [Face AiAF] and cannot be changed.
34
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Using the Self-Timer
With the self-timer, you can include yourself in group photos or other timed
shots. The camera will shoot about 10 seconds after you press the shutter
button.
1 Congurethesetting.
Press the <p> button, choose []] (either
press the <o><p> buttons or turn the
<5> dial), and then press the <m>
button.
Once the setting is complete, []] is
displayed.
2 Shoot.
For Still Images: Press the shutter button
halfway to focus on the subject, and then
press it all the way down.
For Movies: Press the movie button.
Once you start the self-timer, the lamp
will blink and the camera will play a self-
timer sound.
Two seconds before the shot, the blinking
and sound will speed up. (The lamp will
remain lit in case the ash res.)
To cancel shooting after you have
triggered the self-timer, press the
<n> button.
To restore the original setting, choose
[
] in step 1.
Still Images Movies
Using the Self-Timer to Avoid Camera Shake
This option delays shutter release until about two seconds after you have
pressed the shutter button. If the camera is unsteady while you are pressing
the shutter button, it will not affect your shot.
Follow step 1 in “Using the Self-Timer”
(=
34) and choose [[].
Once the setting is complete, [[] is
displayed.
Follow step 2 in “Using the Self-Timer”
(=
34) to shoot.
35
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Customizing the Self-Timer
You can specify the delay (0 – 30 seconds) and number of shots (1 – 10).
1 Choose [$].
Following step 1 in “Using the Self-Timer”
(=
34), choose [$] and press the
<n> button immediately.
2 Congurethesetting.
Press the <o><p> buttons to choose
[Delay] or [Shots].
Press the <q><r> buttons or turn the
<5> dial to choose a value, and then
press the <m> button.
Once the setting is complete, [$] is
displayed.
Follow step 2 in “Using the Self-Timer”
(=
34) to shoot.
• For movies shot using the self-timer, [Delay] represents the delay
before recording begins, but the [Shots] setting has no effect.
• When you specify multiple shots, image brightness and white balance are
determined by the rst shot. More time is required between shots when the
ash res or when you have specied to take many shots. Shooting will stop
automatically when the memory card becomes full.
• When a delay longer than two seconds is specied, two seconds before the
shot, the lamp blinking and self-timer sound will speed up. (The lamp will
remain lit in case the ash res.)
Still Images
Adding a Date Stamp
The camera can add the shooting date to images, in the lower-right corner.
However, note that date stamps cannot be edited or removed, so conrm
beforehand that the date and time are correct (=
14).
1 Congurethesetting.
Press the <n> button, choose [Date
Stamp
] on the [4] tab, and then
choose the desired option (=
23).
Once the setting is complete, [ ] is
displayed.
2 Shoot.
As you take shots, the camera adds the
shooting date or time to the lower-right
corner of images.
To restore the original setting, choose
[Off] in step 1.
• Date stamps cannot be edited or removed.
36
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Shots taken without adding a date stamp can be printed with one as follows.
However, adding a date stamp this way to images that already have one may
cause it to be printed twice.
- Print using printer functions (=
133)
- Use camera DPOF print settings (=
137) to print
- Use the software downloaded from the Canon website to print (=
131)
Image Customization Features
Still Images
Changing the Aspect Ratio
Change the image aspect ratio (ratio of width to height) as follows.
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
Once the setting is complete, the screen
aspect ratio will be updated.
To restore the original setting, repeat this
process but choose [
].
Used for display on widescreen HDTVs or similar display devices.
Same aspect ratio as 35mm lm, used for printing images at 5 x 7-inch or
postcard sizes.
Native aspect ratio of the camera screen, also used for display on standard-
denition televisions or similar display devices, or for printing images at 3.5 x
5-inch or A-series sizes.
Square aspect ratio.
37
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Changing Image Resolution (Size)
Choose from 4 levels of image resolution, as follows. For guidelines on
how many shots at each resolution setting can t on a memory card, see
“Number of 4:3 Shots per Memory Card” (=
160).
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
The option you congured is now
displayed.
To restore the original setting, repeat this
process but choose [
].
Guidelines for Choosing Resolution Based on Paper
Size (for 4:3 Images)
[ ]: For e-mailing images.
A2 (16.5 x 23.4 in.)
A3 – A5 (11.7 x
16.5 – 5.8 x 8.3 in.)
5 x 7 in.
Postcard
3.5 x 5 in.
Still Images
Red-Eye Correction
Red-eye that occurs in ash photography can be automatically corrected as
follows.
1 Access the [Flash Settings]
screen.
Press the <n> button, choose [Flash
Settings] on the [4] tab, and then press
the <m> button (=
23).
2 Congurethesetting.
Choose [Red-Eye Corr.], and then
choose [On] (=
24).
Once the setting is complete, [R] is
displayed.
To restore the original setting, repeat this
process but choose [Off].
• Red-eye correction may be applied to image areas other than eyes
(if the camera misinterprets red eye makeup as red pupils, for
example).
• You can also correct existing images (=
90).
• You can also access the screen in step 2 when the ash is up by pressing the
<r> button and immediately pressing the <n> button.
38
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Movies
Changing Movie Image Quality
3 image quality settings are available. For guidelines on the maximum
movie length at each level of image quality that will t on a memory card,
see “Recording Time per Memory Card” (=
161).
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
The option you congured is now
displayed.
To restore the original setting, repeat this
process but choose [
].
Image Quality Resolution Frame Rate Details
1920 x 1080 24 fps For shooting in Full HD
1280 x 720 30 fps For shooting in HD
640 x 480 30 fps For shooting in standard denition
• In [
] and [ ] modes, black bars displayed on the top and bottom edges of
the screen indicate image areas not recorded.
Helpful Shooting Features
Still Images Movies
Displaying Grid Lines
Grid lines can be displayed on the screen for vertical and horizontal
reference while shooting.
Press the <n> button, choose [Grid
Lines] on the [4] tab, and then choose
[On] (=
23).
Once the setting is complete, grid lines
are displayed on the screen.
To restore the original setting, repeat this
process but choose [Off].
• Grid lines are not recorded in your shots.
39
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Magnifying the Area in Focus
You can check the focus by pressing the shutter button halfway, which will
enlarge the portion of the image in focus in the AF frame.
1 Congurethesetting.
Press the <n> button, choose
[AF-Point Zoom] on the [4] tab, and
then choose [On] (=
23).
2 Check the focus.
Press the shutter button halfway. The
face detected as the main subject is now
magnied.
To restore the original setting, choose
[Off] in step 1.
• The area in focus will not be magnied when you press the shutter
button halfway if a face was not detected, if the person is too close
to the camera and their face is too large for the screen, or if the
camera detects subject movement.
• The display will not magnify when using the digital zoom (=
31) or Tracking
AF (=
62).
Still Images
Checking for Closed Eyes
[ ] is displayed when the camera detects that people may have closed
their eyes.
1 Congurethesetting.
Press the <n> button, choose [Blink
Detection] on the [4] tab, and then
choose [On] (=
23).
2 Shoot.
[ ] ashes when the camera detects a
person whose eyes are closed.
To restore the original setting, choose
[Off] in step 1.
• When you have specied multiple shots in [$] mode, this function is only
available for the nal shot.
• A frame is displayed around people whose eyes are closed when you have
selected [2 sec.], [4 sec.], [8 sec.], or [Hold] in [Display Time] (=
40).
40
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Customizing Camera Operation
Customize shooting functions on the MENU [4] tab as follows.
For instructions on menu functions, see “Using Menus” (=
23).
Still Images
Deactivating the AF-Assist Beam
You can deactivate the lamp that normally lights up to help you focus when
you press the shutter button halfway in low-light conditions.
Press the <n> button, choose
[AF-assist Beam] on the [4] tab, and
then choose [Off] (=
23).
To restore the original setting, repeat this
process but choose [On].
Still Images
Deactivating the Red-Eye Reduction Lamp
You can deactivate the red-eye reduction lamp that lights up to reduce red-
eye when the ash is used in low-light shots.
1 Access the [Flash Settings]
screen.
Press the <n> button, choose [Flash
Settings] on the [4] tab, and then press
the <m> button (=
23).
2 Congurethesetting.
Choose [Red-Eye Lamp], and then
choose [Off] (=
24).
To restore the original setting, repeat this
process but choose [On].
Still Images
Changing the Image Display Style after Shots
You can change how long images are displayed and what information is
displayed immediately after shooting.
1 Access the [Review image after
shooting] screen.
Press the <n> button, choose
[Review image after shooting] on the
[4] tab, and then press the <m> button
(=
23).
2 Congurethesetting.
Choose [Display Time], and then choose
the desired option.
To restore the original setting, repeat this
process but choose [Quick].
Quick Displays images only until you can shoot again.
2 sec.,
4 sec.,
8 sec.
Displays images for the specied time. Even while the shot is displayed, you
can take another shot by pressing the shutter button halfway again.
Hold Displays images until you press the shutter button halfway.
Off No image display after shots.
41
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Changing the Screen Displayed after Shots
Change the way images are displayed after shots as follows.
1 Set [Display Time] to [2 sec.],
[4 sec.], [8 sec.], or [Hold]
(=
40).
2 Congurethesetting.
Choose [Display Info], and then choose
the desired option.
To restore the original setting, repeat this
process but choose [Off].
Off Displays only the image.
Detailed
Displays shooting details (=
150).
• When [Display Time] (=
40) is set to [Off] or [Quick], [Display Info] is set to
[Off] and cannot be changed.
• By pressing the <p> button while an image is displayed after shooting, you
can switch the display information. Note that the settings of [Display Info] on
the [4] tab are not changed. You can also erase images by pressing the <a>
button, or protect (=
80) or tag images as favorites (=
87) by pressing
the <m> button.
42
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Other Shooting Modes
Shoot more effectively in various scenes, and take shots enhanced with unique image effects or
captured using special functions
3
Discreet Mode ...................................................43
Auto Clip Recording (Movie Digest) ...............43
Brightness / Color Customization
(Live View Control) .........................................44
Specic Scenes ................................................45
Image Effects (Creative Filters) ......................46
Shooting with a Fish-Eye Lens Effect
(Fish-Eye Effect) ...................................................46
Shots Resembling Miniature Models
(Miniature Effect) ................................................... 47
Shooting with a Toy Camera Effect
(Toy Camera Effect) ..............................................48
Shooting in Monochrome ......................................48
Special Modes for Other Purposes ................49
Using the Face Self-Timer.....................................49
High-Speed Continuous Shooting
(High-Speed Burst) ...............................................50
Shooting Various Movies ................................51
Shooting Movies in [E] Mode ..............................51
Shooting Super Slow Motion Movies ....................51
43
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Discreet Mode
Shoot without activating camera sounds, the ash, or lamp as follows. Use
this mode where camera sounds, the ash, and lights are prohibited.
1 Enter [ ] mode.
Set the mode dial to [ ].
2 Shoot.
• In [ ] mode, even playback sounds are muted. Sounds of camera operations
are muted, and movie audio is also muted.
Still Images Movies
Auto Clip Recording (Movie Digest)
You can make a short movie of a day just by shooting still images.
Before each shot, the camera will automatically record a movie clip of the
scene. Each clip recorded that day is combined into a single le.
1 Enter [ ] mode.
Set the mode dial to [ ].
2 Shoot.
To shoot a still image, press the shutter
button all the way down.
Before shooting, the camera will
automatically record a clip about 2 – 4
seconds long.
• Clips may not be recorded if you shoot a still image immediately
after turning the camera on, choosing [
] mode, or operating the
camera in other ways.
• Battery life is shorter in this mode than in [ ] mode, because
clips are recorded for each shot.
• Any sounds from camera operations during movie recording will be
included in the movie.
44
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Movies created in [ ] mode can be viewed by date (=
92).
• [
] mode movie quality is [ ] and cannot be changed.
• Although the clips recorded on a particular day are combined into a single le,
individual clips (chapters) can be edited (=
92).
• Clips are saved as separate movie les in the following cases even if they
were recorded on the same day in [
] mode.
- The movie le size reaches about 4 GB or the total recording time reaches
approx. 1 hour.
- A movie is protected (=
80).
- Daylight saving time (=
14) or time zone (=
119) settings are changed.
- A new folder is created (=
122).
• Some camera sounds will be muted. Sounds are not played when you press
the shutter button halfway, use camera controls, or trigger the self-timer
(=
118).
Still Images Movies
Brightness / Color Customization
(Live View Control)
Image brightness or colors when shooting can be easily customized as
follows.
1 Enter [ ] mode.
Set the mode dial to [ ].
2 Congure the setting.
Press the <m> button to access the
setting screen. Press the <o><p>
buttons to choose a setting item, and
then press the <q><r> buttons or turn
the <
5
> dial to adjust the value as you
watch the screen.
Press the <m> button.
3 Shoot.
Brightness
For brighter images, adjust the level to the right, and for darker
images, adjust it to the left.
Color
For more vivid images, adjust the level to the right, and for more
subdued images, adjust it to the left.
Tone
For a warm, reddish tone, adjust the level to the right, and for a cool,
bluish tone, adjust it to the left.
• Regardless of any brightness adjustment in this setting, movies will
be recorded with optimal image brightness.
45
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Specic Scenes
Choose a mode matching the shooting scene, and the camera will
automatically congure the settings for optimal shots.
1 Enter [K] mode.
Set the mode dial to [K].
2 Choose a shooting mode.
Press the <m> button, choose [I] in the
menu, and then choose a shooting mode
(=
22).
3 Shoot.
Still Images Movies
I Shoot portraits (Portrait)
Take shots of people with a softening
effect.
Still Images
Shoot under low light
(Low Light)
Shoot with minimal camera shake and
subject blur even in low-light conditions.
Still Images Movies
P Shoot with snowy backgrounds
(Snow)
Bright, natural-colored shots of people
against snowy backgrounds.
Still Images Movies
t Shoot reworks (Fireworks)
Vivid shots of reworks.
• In [t] mode, mount the camera on a tripod or take other measures
to keep it still and prevent camera shake. Additionally, you should
set [IS Mode] to [Off] when using a tripod or other means to secure
the camera (=
67).
• [ ] mode resolution is [ ] (1984 x 1488) and cannot be changed.
• In [t] mode, although no frames are displayed when you press the shutter
button halfway, optimal focus is still determined.
46
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Image Effects (Creative Filters)
Add a variety of effects to images when shooting.
1 Enter [ ] mode.
Set the mode dial to [ ].
2 Choose a shooting mode.
Press the <m> button, choose [ ] in
the menu, and then choose a shooting
mode (=
22).
3 Shoot.
Still Images Movies
Shoot in vivid colors
(Super Vivid)
Shots in rich, vivid colors.
Still Images Movies
Posterized shots (Poster Effect)
Shots that resemble an old poster or
illustration.
• In [ ] and [ ] modes, try taking some test shots rst, to make sure
you obtain the desired results.
Still Images
Shooting with a Fish-Eye Lens Effect
(Fish-Eye Effect)
Shoot with the distorting effect of a sh-eye lens.
1 Choose [ ].
Follow steps 1 – 2 in “Image Effects
(Creative Filters)” (=
46) and choose
[
].
2 Choose an effect level.
Press the <l> button, choose an
effect level (either press the <q><r>
buttons or turn the <5> dial), and then
press the <l> button again.
3 Shoot.
• Try taking some test shots rst, to make sure you obtain the desired
results.
47
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Shots Resembling Miniature Models
(Miniature Effect)
Creates the effect of a miniature model, by blurring image areas above and
below your selected area.
You can also make movies that look like scenes in miniature models by
choosing the playback speed before the movie is recorded. People and
objects in the scene will move quickly during playback. Note that sound is
not recorded.
1 Choose [ ].
Follow steps 1 – 2 in “Image Effects
(Creative Filters)” (=
46) and choose
[
].
A white frame is displayed, indicating the
image area that will not be blurred.
2 Choose the area to keep in
focus.
Press the <l> button.
Move the zoom lever to resize the frame,
and press the <o><p> buttons to move
it.
3 For movies, choose the movie
playback speed.
Press the <n> button, and then
choose the speed by pressing the
<q><r> buttons or turning the <5>
dial.
4 Return to the shooting screen
and shoot.
Press the <n> button to return to the
shooting screen, and then shoot.
Playback Speed and Estimated Playback Time
(for One-Minute Clips)
Speed Playback Time
Approx. 12 sec.
Approx. 6 sec.
Approx. 3 sec.
• The zoom is not available when shooting movies. Be sure to set the
zoom before shooting.
• Try taking some test shots rst, to make sure you obtain the desired
results.
• To switch the orientation of the frame (from horizontal to vertical or vice-versa),
press the <m> button in step 2. You can move the frame in vertical orientation
by pressing the <q><r> buttons.
• Holding the camera vertically will change the orientation of the frame.
• Movie image quality is [
] at an aspect ratio of [ ] and [ ] at an aspect
ratio of [
] (=
36). These quality settings cannot be changed.
• The zoom factor cannot be changed with the <
> button on the screens in
steps 2 and 3, or while shooting movies.
48
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Shooting with a Toy Camera Effect
(Toy Camera Effect)
This effect makes images resemble shots from a toy camera by vignetting
(darker, blurred image corners) and changing the overall color.
1 Choose [ ].
Follow steps 1 – 2 in “Image Effects
(Creative Filters)” (=
46) and choose
[
].
2 Choose a color tone.
Press the <l> button, choose a color
tone (either press the <q><r> buttons or
turn the <5> dial), and then press the
<l> button again.
A preview is shown of how your shot will
look with the effect applied.
3 Shoot.
Standard Shots resemble toy camera images.
Warm Images have a warmer tone than with [Standard].
Cool Images have a cooler tone than with [Standard].
• Try taking some test shots rst, to make sure you obtain the desired
results.
Still Images Movies
Shooting in Monochrome
Shoot images in black and white, sepia, or blue and white.
1 Choose [ ].
Follow steps 1 – 2 in “Image Effects
(Creative Filters)” (=
46) and choose
[
].
2 Choose a color tone.
Press the <l> button, choose a color
tone (either press the <q><r> buttons or
turn the <5> dial), and then press the
<l> button again.
A preview is shown of how your shot will
look with the effect applied.
3 Shoot.
B/W Black and white shots.
Sepia Sepia tone shots.
Blue Blue and white shots.
49
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Special Modes for Other Purposes
Still Images
Using the Face Self-Timer
The camera will shoot about two seconds after detecting that the face of
another person (such as the photographer) has entered the shooting area
(=
62). This is useful when including yourself in group photos or similar
shots.
1 Choose [ ].
Follow steps 1 – 2 in “Specic Scenes”
(=
45) and choose [ ].
2 Compose the shot and press
the shutter button halfway.
Make sure a green frame is displayed
around the face you focus on and white
frames around other faces.
3 Press the shutter button all the
way down.
The camera now enters shooting standby
mode, and [Look straight at camera to
start count down] is displayed.
The lamp blinks and the self-timer sound
is played.
4 Join the subjects in the
shooting area and look at the
camera.
After the camera detects a new face, the
lamp blinking and self-timer sound will
speed up. (When the ash res, the lamp
will remain lit.) About two seconds later,
the camera will shoot.
To cancel shooting after you have
triggered the self-timer, press the
<n> button.
• Even if your face is not detected after you join the others in the shooting area,
the camera will shoot about 15 seconds later.
• To change the number of shots, after choosing [
] in step 1, press the
<l> button, choose the number of shots (either press the <q><r>
buttons or turn the <5> dial), and then press the <l> button again. [Blink
Detection] (=
39) is only available for the nal shot.
• The zoom factor cannot be changed with the <
> button after you press the
shutter button all the way down.
50
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
High-Speed Continuous Shooting (High-Speed
Burst)
You can shoot a series of shots in rapid succession by holding the shutter
button all the way down. For details on the continuous shooting speed, see
“Continuous Shooting Speed” (=
161).
1 Choose [ ].
Follow steps 1 – 2 in “Specic Scenes”
(=
45) and choose [ ].
2 Shoot.
Hold the shutter button all the way down
to shoot continuously.
• The resolution is [ ] (1984 x 1488) and cannot be changed.
• Focus, image brightness, and color are determined by the rst shot.
• Shooting may stop momentarily or continuous shooting may slow down
depending on shooting conditions, camera settings, and the zoom position.
• As more shots are taken, shooting may slow down.
Images Displayed during Playback
Each set of images shot continuously is managed as a single group, and
only the rst image in that group will be displayed. To indicate that the
image is part of a group, [ ] is displayed in the upper left of the screen.
• If you erase a grouped image (=
83), all images in the group are
also erased. Be careful when erasing images.
• Grouped images can be played back individually (=
77) and ungrouped
(=
77).
• Protecting (=
80) a grouped image will protect all images in the group.
• Grouped images can be viewed individually when played back using Image
Search (=
76) or Smart Shufe (=
79). In this case, images are
temporarily ungrouped.
• These actions are not available for grouped images: magnifying (=
78),
tagging as favorites (=
87), editing (=
88 – 90), printing (=
133),
setting up individual image printing (=
138), or adding to a photobook
(=
140). To do these things, either view grouped images individually
(=
77) or cancel grouping (=
77) rst.
51
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Movies
Shooting Various Movies
Movies
Shooting Movies in [E] Mode
1 Enter [E] mode.
Set the mode dial to [E].
Black bars displayed on the top and
bottom edges of the screen indicate
image areas not recorded.
2 Congure the settings to suit
the movie (=
151 – 157).
3 Shoot.
Press the movie button.
To stop movie recording, press the movie
button again.
Movies
Locking or Changing Image Brightness before Shooting
Before shooting, you can lock the exposure or change it in 1/3-stop
increments within a range of –2 to +2.
1 Lock the exposure.
Press the <o> button to lock the
exposure. The exposure shift bar is
displayed.
To unlock the exposure, press the <o>
button again.
2 Adjust the exposure.
Turn the <5> dial to adjust the
exposure, as you watch the screen.
3 Shoot (=
51).
Movies
Shooting Super Slow Motion Movies
You can shoot fast-moving subjects for playback later in slow motion. Note
that sound is not recorded.
1 Choose [ ].
Set the mode dial to [E].
Press the <m> button, choose [E]
in the menu, and then choose [
]
(=
22).
2 Choose a frame rate.
Press the <m> button, choose [ ] in
the menu, and choose the desired frame
rate (=
22).
The option you congured is now
displayed.
3 Shoot (=
51).
52
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Frame Rate Image Quality
Playback Time
(For a 30-sec. Clip)
240 fps (320 x 240)
Approx. 4 min.
120 fps (640 x 480)
Approx. 2 min.
• Zooming is not available during recording, even if you move the
zoom lever.
• Focus, exposure, and color are determined when you press the
movie button.
• When you play the movie (=
73), it will be played back in slow motion.
• You can change the playback speed of movies by using the software
(=
131).
53
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Before using a function introduced in this chapter in modes other than [G],
make sure the function is available in that mode (=
151 – 157).
P Mode
More discerning shots, in your preferred shooting style
4
Shooting in Program AE ([P] Mode) ............... 54
Image Brightness (Exposure) ......................... 54
Adjusting Image Brightness
(Exposure Compensation) ....................................54
Locking Image Brightness / Exposure (AE Lock) ..54
Changing the Metering Method .............................55
Changing the ISO Speed ......................................55
Correcting Image Brightness (i-Contrast) ..............56
Color and Continuous Shooting .....................56
Adjusting White Balance .......................................56
Changing Image Color Tones (My Colors) ............ 57
Continuous Shooting .............................................58
Shooting Range and Focusing ....................... 59
Shooting Close-Ups (Macro) .................................59
Shooting in Manual Focus Mode ...........................60
Digital Tele-Converter ............................................61
Changing the AF Frame Mode .............................. 61
Changing the Focus Setting ..................................64
Shooting with the AF Lock .....................................64
Flash ..................................................................65
Changing the Flash Mode ..................................... 65
Adjusting the Flash Exposure Compensation .......65
Shooting with the FE Lock ....................................66
Other Settings ..................................................66
Changing the Compression Ratio
(Image Quality) ......................................................66
Changing the IS Mode Settings ............................67
• Instructions in this chapter apply to the camera with the mode dial set to
[G] mode.
• [G]: Program AE; AE: Auto Exposure
54
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Shooting in Program AE ([P] Mode)
You can customize many function settings to suit your preferred shooting
style.
1 Enter [G] mode.
Set the mode dial to [G].
2 Customize the settings as
desired (=
54 – 67), and
then shoot.
• If adequate exposure cannot be obtained when you press the shutter button
halfway, shutter speeds and aperture values are displayed in orange. In this
case, try adjusting the ISO speed (=
55) or activating the ash (if subjects
are dark, =
65), which may enable adequate exposure.
• Movies can be recorded in [G] mode as well, by pressing the movie button.
However, some FUNC. (=
22) and MENU (=
23) settings may be
automatically adjusted for movie recording.
• For details on the shooting range in [G] mode, see “Shooting Range”
(=
161).
Image Brightness (Exposure)
Still Images
Adjusting Image Brightness (Exposure
Compensation)
The standard exposure set by the camera can be adjusted in 1/3-stop
increments, in a range of –2 to +2.
Press the <b> button. As you watch
the screen, turn the <5> dial to adjust
brightness, and then press the <b>
button again when nished.
The correction level you specied is now
displayed.
Still Images
Locking Image Brightness / Exposure (AE Lock)
Before shooting, you can lock the exposure, or you can specify focus and
exposure separately.
1 Lock the exposure.
Aim the camera at the subject to shoot
with the exposure locked. With the
shutter button pressed halfway, press the
<b> button.
[ ] is displayed, and the exposure is
locked.
To unlock AE, release the shutter button
and press the <b> button again. In this
case, [
] is no longer displayed.
55
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
2 Compose the shot and shoot.
After one shot, AE is unlocked and [ ] is
no longer displayed.
• AE: Auto Exposure
• After the exposure is locked, you can adjust the combination of shutter speed
and aperture value by turning the <5> dial (Program Shift).
Still Images
Changing the Metering Method
Adjust the metering method (how brightness is measured) to suit shooting
conditions as follows.
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
The option you congured is now
displayed.
Evaluative
For typical shooting conditions, including backlit shots.
Automatically adjusts exposure to match the shooting conditions.
Center
Weighted Avg.
Determines the average brightness of light across the entire
image area, calculated by treating brightness in the central area
as more important.
Spot
Metering restricted to within the [
] (Spot AE Point frame),
displayed in the center of the screen.
Still Images
Changing the ISO Speed
Press the <o> button, choose an option
(either press the <o><p> buttons or
turn the <5> dial), and then press the
<m> button.
The option you congured is now
displayed.
Automatically adjusts the ISO speed to suit the shooting mode and
conditions.
Low
High
For shooting outdoors in fair weather.
For shooting in cloudy conditions, or at twilight.
For shooting night scenes, or in dark rooms.
• To view the automatically set ISO speed when the camera is set to [
], press
the shutter button halfway.
• Although choosing a lower ISO speed may reduce image graininess, there
may be a greater risk of subject blurriness in some shooting conditions.
• Choosing a higher ISO speed will increase shutter speed, which may reduce
subject blurriness and increase the ash range. However, shots may look
grainy.
56
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Correcting Image Brightness (i-Contrast)
Before shooting, excessively bright or dark image areas (such as faces or
backgrounds) can be detected and automatically adjusted to the optimal
brightness. Insufcient overall image contrast can also be automatically
corrected before shooting to make subjects stand out better.
Press the <n> button, choose
[i-Contrast] on the [4] tab, and then
choose [Auto] (=
23).
Once the setting is complete, [@] is
displayed.
• Under some shooting conditions, correction may be inaccurate or
may cause images to appear grainy.
• You can also correct existing images (=
90).
Color and Continuous Shooting
Still Images Movies
Adjusting White Balance
By adjusting white balance (WB), you can make image colors look more
natural for the scene you are shooting.
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
The option you congured is now
displayed.
Auto
Automatically sets the optimal white balance for the shooting
conditions.
Day Light For shooting outdoors in fair weather.
Cloudy For shooting in cloudy conditions, in the shade, or at twilight.
Tungsten
For shooting under ordinary incandescent (tungsten) lighting
and similarly colored uorescent lighting.
Fluorescent
For shooting under warm-white (or similarly colored) or cool-
white uorescent lighting.
Fluorescent H
For shooting under daylight uorescent and similarly colored
uorescent lighting.
Custom
For manually setting a custom white balance (=
57).
57
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Custom White Balance
For image colors that look natural under the light in your shot, adjust white
balance to suit the light source where you are shooting. Set the white
balance under the same light source that will illuminate your shot.
Follow the steps in “Adjusting White
Balance” (=
56) to choose [ ].
Aim the camera at a plain white subject,
so that the entire screen is white. Press
the <l> button.
The tint of the screen changes once the
white balance data has been recorded.
• Colors may look unnatural if you change camera settings after
recording white balance data.
Still Images Movies
Changing Image Color Tones (My Colors)
Change image color tones as desired, such as converting images to sepia
or black and white.
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
The option you congured is now
displayed.
My Colors Off
–
Vivid
Emphasizes contrast and color saturation, making images
sharper.
Neutral Tones down contrast and color saturation for subdued images.
Sepia Creates sepia tone images.
B/W Creates black and white images.
Positive Film
Combines the effects of Vivid Blue, Vivid Green, and Vivid
Red to produce intense yet natural-looking colors resembling
images on positive lm.
Lighter Skin Tone Lightens skin tones.
Darker Skin Tone Darkens skin tones.
Vivid Blue
Emphasizes blues in images. Makes the sky, ocean, and other
blue subjects more vivid.
Vivid Green
Emphasizes greens in images. Makes mountains, foliage, and
other green subjects more vivid.
Vivid Red Emphasizes reds in images. Makes red subjects more vivid.
Custom Color
Adjust contrast, sharpness, color saturation, and other
qualities as desired (=
58).
• White balance (=
56) cannot be set in [ ] or [ ] modes.
• With [ ] and [ ] modes, colors other than people’s skin tone may
change. These settings may not produce the expected results with
some skin tones.
58
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Custom Color
Choose the desired level of image contrast, sharpness, color saturation,
red, green, blue, and skin tones in a range of 1 – 5.
1 Access the setting screen.
Follow the steps in “Changing Image
Color Tones (My Colors)” (=
57) to
choose [
], and then press the <l>
button.
2 Congurethesetting.
Press the <o><p> buttons to choose
an option, and then specify the value by
pressing the <q><r> buttons or turning
the <5> dial.
For stronger or more intense effects,
adjust the value to the right, and for
weaker or lighter effects, adjust the value
to the left.
Press the <l> button to complete the
setting.
Still Images
Continuous Shooting
Hold the shutter button all the way down to shoot continuously.
For details on the continuous shooting speed, see “Continuous Shooting
Speed” (=
161).
1 Congurethesetting.
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
The option you congured is now
displayed.
2 Shoot.
Hold the shutter button all the way down
to shoot continuously.
Mode Description
W
Continuous
Continuous shooting, with the focus and exposure determined
when you press the shutter button halfway.
Continuous
Shooting AF*
Continuous shooting and focusing.
[AF Frame] is set to [Center] and cannot be changed.
* In [t] mode (=
45), manual focus mode (=
60), or when AF is locked (=
64),
[
] is changed to [ ].
59
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Cannot be used with the self-timer (=
34) or [Blink Detection]
(=
39).
• Shooting may stop momentarily or continuous shooting may slow
down depending on shooting conditions, camera settings, and the
zoom position.
• As more shots are taken, shooting may slow down.
• Shooting may slow down if the ash res.
• Continuous shooting is faster in [ ] mode (=
45).
Shooting Range and Focusing
Still Images
Shooting Close-Ups (Macro)
To restrict the focus to subjects at close range, set the camera to [e]. For
details on the focusing range, see “Shooting Range” (=
161).
Press the <q> button, choose [e] (either
press the <q><r> buttons or turn the
<5> dial), and then press the <m>
button.
Once the setting is complete, [e] is
displayed.
• If the ash res, vignetting may occur.
• Be careful to avoid damaging the lens.
• In the yellow bar display area below the zoom bar, [e] will turn gray
and the camera will not focus.
• To prevent camera shake, try mounting the camera on a tripod and shooting
with the camera set to [[] (=
34).
60
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Shooting in Manual Focus Mode
When focusing is not possible in AF mode, use manual focus. You can
specify the general focal position and then press the shutter button halfway
to have the camera determine the optimal focal position near the position
you specied. For details on the focusing range, see “Shooting Range”
(=
161).
1 Choose [f].
Press the <q> button, choose [f]
(either press the <q><r> buttons or turn
the <5> dial), and then press the <m>
button.
[f] and the MF indicator are displayed.
2 Specify the general focal
position.
Referring to the on-screen MF indicator
bar (which shows the distance and focal
position) and the magnied display area,
press the <o><p> buttons or turn the
<5> dial to specify the general focal
position, and then press the <m> button.
3 Fine-tune the focus.
Press the shutter button halfway to have
the camera ne-tune the focal position
(Safety MF).
MF Indicator
• When you focus manually, the AF frame mode (=
61) is [Center]
and AF frame size is [Normal], and these settings cannot be
changed.
• Focusing is possible when using the digital zoom (=
31) or digital
tele-converter (=
61), or when using a TV as a display (=
130),
but the magnied display will not appear.
• To focus more accurately, try attaching the camera to a tripod to stabilize it.
• To hide the magnied display area, press the <n> button and set
[MF-Point Zoom] on the [4] tab to [Off] (=
23).
• To deactivate automatic focus ne-tuning when the shutter button is pressed
halfway, press the <n> button and set [Safety MF] on the [4] tab to [Off]
(=
23).
61
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Digital Tele-Converter
The focal length of the lens can be increased by approximately 1.5x or 2.0x.
This can reduce camera shake because the shutter speed is faster than it
would be if you zoomed (including using digital zoom) in to the same zoom
factor.
Press the <n> button, choose
[Digital Zoom] on the [4] tab, and then
choose the desired option (=
23).
The view is enlarged and the zoom factor
is displayed on the screen.
• The digital tele-converter cannot be used with digital zoom
(=
31) or AF-point zoom (=
39).
• The respective focal lengths when using [1.5x] and [2.0x] are 36 – 1152 mm
and 48 – 1440 mm (35mm lm equivalent).
• The shutter speed may be equivalent when you move the zoom lever all the
way toward <i> for maximum telephoto, and when you zoom in to enlarge
the subject to the same size following step 2 in “Zooming In Closer on Subjects
(Digital Zoom)” (=
31).
Still Images Movies
Changing the AF Frame Mode
Change the AF (auto focus) frame mode to suit the shooting conditions as
follows.
Press the <n> button, choose [AF
Frame] on the [4] tab, and then choose
the desired option (=
23).
Still Images Movies
Center
One AF frame is displayed in the center. Effective for reliable focusing.
• A yellow AF frame is displayed with [
] if the camera cannot focus
when you press the shutter button halfway.
• To reduce the AF frame size, press the <n> button and set [AF Frame
Size] on the [4] tab to [Small] (=
23).
• The AF frame size is set to [Normal] when you use the digital zoom (=
31)
or digital tele-converter (=
61), and in manual focus mode (=
60).
• To compose shots so that subjects are positioned at the edge or in a corner,
rst aim the camera to capture the subject in an AF frame, and then hold
the shutter button halfway down. As you continue to hold the shutter button
halfway, recompose the shot as desired, and then press the shutter button all
the way down (Focus Lock).
• The AF frame position is enlarged when you press the shutter button halfway
and [AF-Point Zoom] (=
39) is set to [On].
62
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Face AiAF
• Detects people’s faces, and then sets the focus, exposure (evaluative
metering only), and white balance ([ ] only).
• After you aim the camera at the subject, a white frame is displayed
around the person’s face determined by the camera to be the main
subject, and up to two gray frames are displayed around other detected
faces.
• When the camera detects movement, frames will follow moving subjects,
within a certain range.
• After you press the shutter button halfway, up to nine green frames are
displayed around faces in focus.
• If faces are not detected, or when only gray frames are displayed
(without a white frame), up to nine green frames are displayed in the
areas in focus when you press the shutter button halfway.
• If faces are not detected when Servo AF (=
63) is set to [On], the
AF frame is displayed in the center of the screen when you press
the shutter button halfway.
• Examples of faces that cannot be detected:
- Subjects that are distant or extremely close
- Subjects that are dark or light
- Faces in prole, at an angle, or partly hidden
• The camera may misinterpret non-human subjects as faces.
• No AF frames are displayed if the camera cannot focus when you
press the shutter button halfway.
Still Images
Choosing Subjects to Focus On (Tracking AF)
Shoot after choosing a subject to focus on as follows.
1 Choose [Tracking AF].
Follow the steps in “Changing the AF
Frame Mode” (=
61) to choose
[Tracking AF].
[ ] is displayed in the center of the
screen.
2 Choose a subject to focus on.
Aim the camera so that [ ] is on the
desired subject, and then press the <q>
button.
When the subject is detected, the camera
beeps and [
] is displayed. Even if the
subject moves, the camera will continue
to track the subject within a certain range.
If no subject is detected, [ ] is
displayed.
To cancel tracking, press the <q> button
again.
63
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Shoot.
Press the shutter button halfway. [ ]
changes to a blue [
], which follows
the subject as the camera continues to
adjust the focus and exposure (Servo AF)
(=
63).
Press the shutter button all the way down
to shoot.
Even after your shot, [ ] is still
displayed and the camera continues to
track the subject.
• [Servo AF] (=
63) is set to [On] and cannot be changed.
• Tracking may not be possible when subjects are too small or move
too rapidly, or when subject color or brightness matches that of the
background too closely.
• [AF-Point Zoom] on the [4] tab is not available.
• [e] is not available.
• The camera can detect subjects even if you press the shutter button halfway
without pressing the <q> button. After your shot, [
] is displayed in the
center of the screen.
• When shooting in [f] mode (=
60), press and hold the <q> button for at
least one second.
Still Images
Shooting with Servo AF
This mode helps avoid missing shots of subjects in motion, because the
camera continues to focus on the subject and adjust the exposure as long
as you press the shutter button halfway.
1 Congurethesetting.
Press the <n> button, choose
[Servo AF] on the [4] tab, and then
choose [On] (=
23).
2 Focus.
The focus and exposure are maintained
where the blue AF frame is displayed
while you are pressing the shutter button
halfway.
• Focusing may not be possible in some shooting conditions.
• In low-light conditions, Servo AF may not be activated (AF frames
may not turn blue) when you press the shutter button halfway. In this
case, the focus and exposure are set according to the specied AF
frame mode.
• If adequate exposure cannot be obtained, shutter speeds and
aperture values are displayed in orange. Release the shutter button,
and then press it halfway again.
• AF lock shooting is not available.
• [AF-Point Zoom] on the [4] tab is not available.
• Not available when using the self-timer (=
34).
64
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Changing the Focus Setting
You can change default camera operation of constantly focusing on
subjects it is aimed at, even when the shutter button is not pressed. Instead,
you can limit camera focusing to the moment you press the shutter button
halfway.
Press the <n> button, choose
[Continuous AF] on the [4] tab, and then
choose [Off] (=
23).
On
Helps avoid missing sudden photo opportunities, because the camera
constantly focuses on subjects until you press the shutter button halfway.
Off Conserves battery power, because the camera does not focus constantly.
Still Images Movies
Shooting with the AF Lock
The focus can be locked. After you lock the focus, the focal position will not
change even when you release your nger from the shutter button.
1 Lock the focus.
With the shutter button pressed halfway,
press the <q> button.
The focus is now locked, and [f] and
the MF indicator are displayed.
To unlock the focus, after you release
the shutter button, press the <q> button
again, and then press the <q><r>
buttons to choose [
].
2 Compose the shot and shoot.
65
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Flash
Still Images
Changing the Flash Mode
You can change the ash mode to match the shooting scene. For details on
the ash range, see “Flash Range” (=
161).
1 Lifttheash.
2 Congurethesetting.
Press the <r> button, choose a ash
mode (either press the <q><r> buttons
or turn the <5> dial), and then press the
<m> button.
The option you congured is now
displayed.
[ ] Auto
Fires automatically in low-light conditions.
[h] On
Fires for each shot.
[Z] Slow Synchro
Fires to illuminate the main subject (such as people) while shooting at a
slower shutter speed to illuminate backgrounds out of ash range.
• The setting screen cannot be accessed by pressing the <r> button
when the ash is lowered. Lift the ash with your nger in advance.
• In [Z] mode, mount the camera on a tripod or take other measures
to keep it still and prevent camera shake. Additionally, you should
set [IS Mode] to [Off] when using a tripod or other means to secure
the camera (=
67).
• In [Z] mode, even after the ash res, ensure that the main subject
does not move until the shutter sound is nished playing.
Still Images
Adjusting the Flash Exposure Compensation
Just as with regular exposure compensation (=
54), you can adjust the
ash exposure from –2 to +2 stops, in 1/3-stop increments.
Press the <m> button, choose [X] in
the menu, and adjust the setting by either
pressing the <o><p> buttons or turning
the <5> dial (=
22).
Once the setting is complete, [X] is
displayed.
• When there is a risk of overexposure, the camera automatically adjusts the
shutter speed or aperture value during the ash shots to reduce washed-
out highlights and shoot at optimal exposure. However, you can deactivate
automatic adjustment of the shutter speed and aperture value by accessing
MENU (=
23) and choosing [4] tab > [Flash Settings] > [Safety FE] > [Off].
• You can also congure the ash exposure compensation by accessing MENU
(=
23) and choosing [4] tab > [Flash Settings] > [Flash Exp. Comp].
• You can also access the [Flash Settings] MENU screen when the ash is up by
pressing the <r> button and immediately pressing the <n> button.
66
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Shooting with the FE Lock
Just as with the AE lock (=
54), you can lock the exposure for the ash
shots.
1 Lifttheashandsettheashto
[h] (=
65).
2 Locktheashexposure.
Aim the camera at the subject to shoot
with the exposure locked. With the
shutter button pressed halfway, press the
<b> button.
The ash res, and when [ ] is displayed,
the ash output level is retained.
To unlock FE, release the shutter button
and press the <b> button again. In this
case, [
] is no longer displayed.
3 Compose the shot and shoot.
After one shot, FE is unlocked and [ ] is
no longer displayed.
• FE: Flash Exposure
Other Settings
Still Images
Changing the Compression Ratio (Image Quality)
Choose from two compression ratios, [ ] (Super Fine) and [ ] (Fine), as
follows. For guidelines on how many shots at each compression ratio can t
on a memory card, see “Number of 4:3 Shots per Memory Card” (=
160).
Press the <m> button, choose [ ] in
the menu, and choose the desired option
(=
22).
67
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Changing the IS Mode Settings
1 Access the setting screen.
Press the <n> button, choose [IS
Settings] on the [4] tab, and then press
the <m> button (=
23).
2 Congurethesetting.
Choose [IS Mode], and then choose the
desired option (=
23).
Continuous
Optimal image stabilization for the shooting conditions is automatically
applied (Intelligent IS) (=
30).
Shoot Only* Image stabilization is active only at the moment of shooting.
Off Deactivates image stabilization.
* The setting is changed to [Continuous] for movie recording.
• If image stabilization cannot prevent camera shake, mount the
camera on a tripod or take other measures to hold it still. In this
case, set [IS Mode] to [Off].
Movies
Shooting Movies with Subjects at the Same Size Shown
before Shooting
Normally, once movie recording begins, a smaller image display area
is shown, with the subject slightly enlarged due to rotational image
stabilization. To shoot subjects at the same size shown before shooting, you
can disable this image stabilization.
Follow the steps in “Changing the IS
Mode Settings” (=
67) to access the
[IS Settings] screen.
Choose [Dynamic IS], and then choose
[2] (=
30).
• You can also set [IS Mode] to [Off], so that subjects are recorded at
the same size shown before shooting.
68
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Tv, Av, and M Mode
Take smarter, more sophisticated shots
• Instructions in this chapter apply to the camera as set to the respective mode.
5
SpecicShutterSpeeds([Tv]Mode) ..............69
SpecicApertureValues([Av]Mode) ............69
SpecicShutterSpeedsandApertureValues
([M]Mode) ........................................................70
Adjusting the Flash Output ....................................71
69
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Specic Shutter Speeds ([Tv] Mode)
Set your preferred shutter speed before shooting as follows. The camera
automatically adjusts the aperture value to suit your shutter speed.
For details on available shutter speeds, see “Shutter Speed” (=
162).
1 Enter[M]mode.
Set the mode dial to [M].
2 Set the shutter speed.
Turn the <5> dial to set the shutter
speed.
• With shutter speeds of 1.3 seconds or slower, there will be a delay
before you can shoot again, as images are processed to remove
noise.
• When shooting at low shutter speeds on a tripod, you should set [IS
Mode] to [Off] (=
67).
• With shutter speeds of 1.3 seconds or slower, ISO speed is [ ] and
cannot be changed.
• Orange display of aperture values when you press the shutter
button halfway indicates that the settings deviate from standard
exposure. Adjust the shutter speed until the aperture value is
displayed in white, or use safety shift (=
69).
• [M]: Time value
Still Images
Specic Aperture Values ([Av] Mode)
Set your preferred aperture value before shooting as follows. The camera
automatically adjusts the shutter speed to suit your aperture value.
For details on available aperture values, see “Aperture” (=
162).
1 Enter[B]mode.
Set the mode dial to [B].
2 Set the aperture value.
Turn the <5> dial to set the aperture
value.
• Orange display of shutter speeds when you press the shutter button
halfway indicates that the settings deviate from standard exposure.
Adjust the aperture value until the shutter speed is displayed in
white, or use safety shift (see below).
• [B]: Aperture value (size of the opening made by the iris in the lens)
• To avoid exposure problems in [M] and [B] modes, you can have the
camera automatically adjust the shutter speed or aperture value, even when
standard exposure cannot otherwise be obtained. Press the <n> button
and set [Safety Shift] on the [4] tab to [On] (=
23).
However, safety shift is disabled when the ash res.
70
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Specic Shutter Speeds and Aperture
Values ([M] Mode)
Follow these steps before shooting to set your preferred shutter speed and
aperture value to obtain the desired exposure.
For details on available shutter speeds and aperture values, see “Shutter
Speed” (=
162) and “Aperture” (=
162).
1 Enter[D]mode.
Set the mode dial to [D].
2 Congurethesetting.
Press the <b> button, choose
adjustment of shutter speed or aperture
value, and turn the <5> dial to specify
a value.
An exposure level mark based on your
specied value is shown on the exposure
level indicator for comparison to the
standard exposure level.
The exposure level mark is shown
in orange when the difference from
standard exposure exceeds 2 stops. [–2]
or [+2] is displayed in orange in the lower
right when you press the shutter button
halfway.
Aperture
Value
Shutter Speed
Standard
Exposure Level
Exposure Level Mark
Exposure Level
Indicator
• After you set the shutter speed or aperture value, the exposure level
may change if you adjust the zoom or recompose the shot.
• Screen brightness may change depending on your specied shutter
speed or aperture value. However, screen brightness remains the
same when the ash is up and the mode is set to [h].
• With shutter speeds of 1.3 seconds or slower, ISO speed is [ ] and
cannot be changed.
• To have the setting you did not congure in step 2 (whether shutter
speed or aperture value) automatically adjusted to obtain standard
exposure, hold the shutter button halfway and press the <b>
button. Note that standard exposure may not be possible with some
settings.
• [D]: Manual
• Calculation of standard exposure is based on the specied metering method
(=
55).
71
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Adjusting the Flash Output
Choose from the three ash levels in [D] mode.
1 Enter[D]mode.
Set the mode dial to [D].
2 Congurethesetting.
Press the <m> button, choose [X] in
the menu, and adjust the setting by either
pressing the <o><p> buttons or turning
the <
5
> dial (=
22).
Once the setting is complete, [X] is
displayed.
• You can also set the ash level by choosing [X] in the FUNC. menu (=
22),
or by accessing MENU (=
23) and choosing [4] tab > [Flash Settings] >
[Flash Output].
• You can set the ash level in [M] or [B] mode by accessing MENU
(=
23) and choosing [4] tab > [Flash Settings] > [Flash Mode] > [Manual].
• You can also access the [Flash Settings] MENU screen by pressing the <r>
button and then the <n> button.
72
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Playback Mode
Have fun reviewing your shots, and browse or edit them in many ways
• To prepare the camera for these operations, press the <1> button to enter Playback mode.
• It may not be possible to play back or edit images that were renamed or already edited on a computer, or images from
other cameras.
6
Viewing ..............................................................73
Switching Display Modes ......................................74
Viewing Short Movies Created When Shooting
Still Images (Digest Movies) ..................................75
Browsing and Filtering Images .......................76
Navigating through Images in an Index.................76
Finding Images Matching Specied Conditions ....76
Viewing Individual Images in a Group ................... 77
Image Viewing Options ....................................78
Magnifying Images ................................................ 78
Viewing Slideshows ..............................................78
Auto Playback of Related Images
(Smart Shufe) ...................................................... 79
Protecting Images ............................................80
Using the Menu ..................................................... 81
Choosing Images Individually ...............................81
Selecting a Range .................................................82
Specifying All Images at Once ..............................83
Erasing Images .................................................83
Erasing Multiple Images at Once ..........................84
Rotating Images ............................................... 85
Using the Menu ..................................................... 86
Deactivating Auto Rotation ....................................86
Tagging Images as Favorites .......................... 87
Editing Still Images ..........................................88
Resizing Images ....................................................88
Cropping ................................................................88
Changing Image Color Tones (My Colors) ............ 89
Correcting Image Brightness (i-Contrast) ..............90
Correcting Red-Eye ...............................................90
Editing Movies ..................................................91
Editing Digest Movies ............................................92
73
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Viewing
After shooting images or movies, you can view them on the screen as
follows.
1 Enter Playback mode.
Press the <1> button.
Your last shot is displayed.
2 Browse through your images.
To view the previous image, press
the <q> button or turn the <5> dial
counterclockwise. To view the next
image, press the <r> button or turn the
<5> dial clockwise.
Press and hold the <q><r> buttons to
browse through images quickly. Images
appear grainy at this time.
To access Scroll Display mode, turn the
<5> dial rapidly. In this mode, turn
the <5> dial to browse through images.
To return to single-image display, press
the <m> button.
To browse images grouped by shooting
date, press the <o><p> buttons in
Scroll Display mode.
Movies are identied by a [ ] icon. To
play movies, go to step 3.
3 Play movies.
To start playback, press the <m> button,
choose [
] (either press the <o><p>
buttons or turn the <5> dial), and then
press the <m> button again.
4 Adjust the volume.
Press the <o><p> buttons to adjust the
volume.
To adjust the volume when the volume
indicator is no longer displayed, press the
<o><p> buttons.
5 Pause playback.
To pause or resume playback, press the
<m> button.
After the movie is nished, [ ] is
displayed.
Volume Indicator
74
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• To switch to Shooting mode from Playback mode, press the shutter button
halfway.
• To deactivate Scroll Display, press the <n> button, choose [Scroll
Display] on the [1] tab, and then choose [Off].
• If you prefer to have the most recent shot displayed when you enter Playback
mode, press the <n> button, and on the [1] tab, choose [Resume] and
then [Last shot].
• To change the transition shown between images, press the <n> button,
choose [Transition] on the [1] tab, and then choose the desired effect.
Still Images Movies
Switching Display Modes
Press the <l> button to view other information on the screen, or to hide
the information. For details on the information displayed, see “Playback
(Detailed Information Display)” (=
150).
No Information
Display
Simple
Information
Display
Detailed
Information
Display
Still Images Movies
Overexposure Warning (for Image Highlights)
Washed-out highlights in the image ash on the screen in detailed
information display (=
74).
Still Images Movies
Histogram
The graph in detailed information display
(=
74) is a histogram showing the
distribution of brightness in the image.
The horizontal axis represents the degree
of brightness, and the vertical axis, how
much of the image is at each level of
brightness. Viewing the histogram is a
way to check exposure.
Still Images Movies
GPS Information Display
Using a smartphone connected to the
camera via Wi-Fi, you can geotag images
on the camera, adding information such
as latitude, longitude, and elevation
(=
114). Geotagged images are labeled
with a [
] icon in detailed information
display. Press the <o> button to view the
information recorded.
Latitude, longitude, elevation, and UTC
(shooting date and time) are listed from
top to bottom.
Press the <o> button again to return to
detailed information display.
• [---] is shown instead of numerical values for items not available on
your smartphone or items not recorded correctly.
• UTC: Coordinated Universal Time, essentially the same as Greenwich Mean
Time
High
Dark
Low
Bright
75
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Movies
Viewing Short Movies Created When Shooting
Still Images (Digest Movies)
View digest movies recorded automatically in [ ] mode (=
43) on a day
of still image shooting as follows.
1 Choose an image.
Still images shot in [ ] mode are labeled
with an [
] icon.
2 Play the movie.
Press the <m> button, and then choose
[
] in the menu (=
22).
The movie recorded automatically on the
day of still image shooting is played back,
from the beginning.
• After a moment, [ ] will no longer be displayed when you are using the
camera with information display deactivated (=
74).
Viewing by Date
Digest movies can be viewed by date.
1 Choose a movie.
Press the <n> button, choose [List/
Play Digest Movies] on the [1] tab, and
then choose a date (=
23).
2 Play the movie.
Press the <m> button to start playback.
76
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Finding Images Matching Specied Conditions
Find desired images quickly on a memory card full of images by ltering
image display according to your specied conditions. You can also protect
(=
80) or delete (=
83) these images all at once.
People Displays images with detected faces.
Shot Date Displays the images shot on a specic date.
Favorites
Displays images tagged as favorites (=
87).
Still image/Movie
Displays still images, movies, or movies shot in
[
] mode (=
43).
1 Choose a search condition.
Press the <m> button, choose
[
] in the menu, and choose a condition
(=
22).
When you have selected [ ] or [ ], you
can choose the condition on the screen
displayed.
2 Viewthelteredimages.
Images matching your conditions are
displayed in yellow frames. To view
only these images, press the <q><r>
buttons.
To cancel ltered display, choose [ ] in
step 1.
• When the camera has found no corresponding images for some
conditions, those conditions will not be available.
Browsing and Filtering Images
Still Images Movies
Navigating through Images in an Index
By displaying multiple images in an index, you can quickly nd the images
you are looking for.
1 Display images in an index.
Move the zoom lever toward <g> to
display images in an index. Moving the
lever again will increase the number of
images shown.
To display fewer images, move the zoom
lever toward <k>. Fewer images are
shown each time you move the lever.
2 Choose an image.
Turn the <5> dial to scroll through the
images.
Press the <o><p><q><r> buttons to
choose an image.
An orange frame is displayed around the
selected image.
Press the <m> button to view the
selected image in single-image display.
77
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• To show or hide information, press the <l> button in step 2.
• Options for viewing the images found (in step 2) include “Navigating through
Images in an Index” (=
76), “Magnifying Images” (=
78), and “Viewing
Slideshows” (=
78). You can protect, erase, or print all images found or add
them to a photobook by choosing [Select All Images in Search] in “Protecting
Images” (=
80), “Erasing Multiple Images at Once” (=
84), “Adding
Images to the Print List (DPOF)” (=
137), or “Adding Images to a Photobook”
(=
140).
• If you edit images and save them as new images (=
88 – 90), a message
is displayed, and the images that were found are no longer shown.
Still Images
Viewing Individual Images in a Group
Images shot in [ ] mode (=
50) are grouped for display, and these
grouped images can be viewed one at a time.
1 Choose a grouped image.
Press the <q><r> buttons or turn the
<5> dial to choose an image labeled
with [
].
2 Choose [ ].
Press the <m> button, and then choose
[
] in the menu (=
22).
3 View images in the group
individually.
Pressing the <q><r> buttons or turning
the <5> dial will display only images in
the group.
To cancel group playback, press the
<m> button, choose [
] in the menu,
and press the <m> button again
(=
22).
• During group playback (step 3), you can use the menu functions accessed
by pressing the <m> button. You can also browse through images quickly
“Navigating through Images in an Index” (=
76) and magnify them
“Magnifying Images” (=
78). By choosing [All Images in Group] for
“Protecting Images” (=
80), “Erasing Multiple Images at Once” (=
84),
“Adding Images to the Print List (DPOF)” (=
137), or “Adding Images to a
Photobook” (=
140), all images in the group can be manipulated at once.
• To ungroup images so that they are displayed only as single still images,
press the <n> button, choose [Group Images] on the [1] tab, and then
choose [Off] (=
23). However, grouped images cannot be ungrouped during
individual playback.
78
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Image Viewing Options
Still Images
Magnifying Images
1 Magnify an image.
Moving the zoom lever toward <k> will
zoom in and magnify the image. You
can magnify images up to about 10x by
continuing to hold the zoom lever.
To zoom out, move the zoom lever
toward <g>. You can return to single-
image display by continuing to hold it.
2 Move the display position and
switch images as needed.
To move the display position, press the
<o><p><q><r> buttons.
To switch to other images while zoomed,
turn the <5> dial.
• You can return to single-image display from magnied display by pressing the
<n> button.
Approximate Position
of Displayed Area
Still Images Movies
Viewing Slideshows
Automatically play back images from a memory card as follows. Each
image is displayed for about three seconds.
Choose a slideshow transition and
start playback.
Press the <m> button, choose [.] in
the menu, and choose the desired option
(=
22).
The slideshow will start after [Loading
image] is displayed for a few seconds.
Press the <n> button to stop the
slideshow.
• The camera’s power-saving functions (=
20) are deactivated
during slideshows.
• To pause or resume slideshows, press the <m> button.
• You can switch to other images during playback by pressing the <q><r>
buttons or turning the <5> dial. For fast-forward or fast-rewind, hold the
<q><r> buttons down.
• In image search mode (=
76), only images matching search conditions are
played.
79
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Changing Slideshow Settings
You can set up slideshows to repeat, and you can change the transitions
between images and the display duration of each image.
1 Access the setting screen.
Press the <n> button, and then
choose [Slideshow] on the [1] tab
(=
23).
2 Congurethesettings.
Choose a menu item to congure, and
then choose the desired option (=
23).
To start the slideshow with your settings,
choose [Start] and press the <m>
button.
To return to the menu screen, press the
<n> button.
• [Play Time] cannot be modied when [Bubble] is chosen in [Effect].
Still Images
Auto Playback of Related Images (Smart
Shufe)
Based on the current image, the camera offers four images that you may
wish to view. After you choose to view one of those images, the camera
offers four more images. This is an enjoyable way to play back images in
an unexpected order. Try this feature after you have taken many shots, in
many kinds of scenes.
1 ChooseSmartShufe.
Press the <m> button, and then choose
[
] in the menu (=
22).
Four candidate images are displayed.
2 Choose an image.
Press the <o><p><q><r> buttons to
choose the image you want to view next.
Your chosen image is displayed in the
center, surrounded by the next four
candidate images.
For full-screen display of the center
image, press the <m> button. To restore
the original display, press the <m>
button again.
Press the <n> button to restore
single-image display.
80
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Only still images shot with this camera are played back using Smart
Shufe.
• Smart Shufe is not available in the following cases:
- There are less than 50 shots taken with this camera
- An unsupported image is currently displayed
- Images are shown in ltered display (=
76)
- During group playback (=
77)
Still Images Movies
Protecting Images
Protect important images to prevent accidental erasure by the camera
(=
83).
Press the <m> button, and then choose
[:] in the menu (=
22). [Protected]
is displayed.
To cancel protection, repeat this process
and choose [:] again, and then press
the <m> button.
• Protected images on a memory card will be erased if you format the
card (=
121).
• Protected images cannot be erased using the camera’s erasure function. To
erase them this way, rst cancel protection.
81
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Using the Menu
1 Access the setting screen.
Press the <n> button and choose
[Protect] on the [1] tab (=
23).
2 Choose a selection method.
Choose a menu item and an option as
desired (=
23).
To return to the menu screen, press the
<n> button.
Choosing Images Individually
1 Choose [Select].
Following step 2 in “Using the Menu”
(=
81), choose [Select] and press the
<m> button.
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button. [
] is displayed.
To cancel selection, press the <m>
button again. [
] is no longer displayed.
Repeat this process to specify other
images.
3 Protect the image.
Press the <n> button. A
conrmation message is displayed.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
• Images will not be protected if you switch to Shooting mode or turn
the camera off before nishing the setup process in step 3.
82
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Selecting a Range
1 Choose [Select Range].
Following step 2 in “Using the Menu”
(=
81), choose [Select Range] and
press the <m> button.
2 Choose a starting image.
Press the <m> button.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
3 Choose an ending image.
Press the <r> button to choose [Last
image], and then press the <m> button.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
Images before the rst image cannot be
selected as the last image.
4 Protect the images.
Press the <p> button to choose
[Protect], and then press the <m>
button.
• You can also choose the rst or last image by turning the <5> dial when the
top screen in steps 2 and 3 is displayed.
83
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Specifying All Images at Once
1 Choose [Select All Images].
Following step 2 in “Using the Menu”
(=
81), choose [Select All Images] and
press the <m> button.
2 Protect the images.
Press the <o><p> buttons or turn the
<5> dial to choose [Protect], and then
press the <m> button.
• To cancel protection for groups of images, choose [Unlock] in step 4 of
“Selecting a Range” or in step 2 of “Specifying All Images at Once”.
Still Images Movies
Erasing Images
You can choose and erase unneeded images one by one. Be careful when
erasing images, because they cannot be recovered. However, protected
images (=
80) cannot be erased.
1 Choose an image to erase.
Press the <q><r> buttons or turn the
<5> dial to choose an image.
2 Erase the image.
Press the <a> button.
After [Erase?] is displayed, press the
<q><r> buttons or turn the <5> dial to
choose [Erase], and then press the <m>
button.
The current image is now erased.
To cancel erasure, press the <q><r>
buttons or turn the <5> dial to choose
[Cancel], and then press the <m>
button.
84
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Erasing Multiple Images at Once
You can choose multiple images to erase at once. Be careful when erasing
images, because they cannot be recovered. However, protected images
(=
80) cannot be erased.
Choosing a Selection Method
1 Access the setting screen.
Press the <n> button, and then
choose [Erase] on the [1] tab (=
23).
2 Choose a selection method.
Press the <o><p> buttons or turn the
<5> dial to choose a selection method,
and then press the <m> button.
To return to the menu screen, press the
<n> button.
Choosing Images Individually
1 Choose [Select].
Following step 2 in “Choosing a Selection
Method” (=
84), choose [Select] and
press the <m> button.
2 Choose an image.
Once you choose an image following
step 2 in “Choosing Images Individually”
(=
81), [ ] is displayed.
To cancel selection, press the <m>
button again. [
] is no longer displayed.
Repeat this process to specify other
images.
3 Erase the image.
Press the <n> button. A
conrmation message is displayed.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
85
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Selecting a Range
1 Choose [Select Range].
Following step 2 in “Choosing a Selection
Method” (=
84), choose [Select
Range] and press the <m> button.
2 Choose images.
Follow steps 2 – 3 in “Selecting a Range”
(=
82) to specify images.
3 Erase the images.
Press the <p> button to choose [Erase],
and then press the <m> button.
Specifying All Images at Once
1 Choose [Select All Images].
Following step 2 in “Choosing a Selection
Method” (=
84), choose [Select All
Images] and press the <m> button.
2 Erase the images.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
Still Images Movies
Rotating Images
Change the orientation of images and save them as follows.
1 Choose [\].
Press the <m> button, and then choose
[\] in the menu (=
22).
2 Rotate the image.
Press the <q> or <r> button, depending
on the desired direction. Each time you
press the button, the image is rotated
90°. Press the <m> button to complete
the setting.
86
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Using the Menu
1 Choose [Rotate].
Press the <n> button and choose
[Rotate] on the [1] tab (=
23).
2 Rotate the image.
Press the <q><r> buttons or turn the
<5> dial to choose an image.
The image is rotated 90° each time you
press the <m> button.
To return to the menu screen, press the
<n> button.
• Movies with an image quality of [
] or [ ] cannot be rotated.
• Rotation is not possible when [Auto Rotate] is set to [Off] (=
86).
Deactivating Auto Rotation
Follow these steps to deactivate automatic image rotation, which rotates
images based on the current camera orientation.
Press the <n> button, choose [Auto
Rotate] on the [1] tab, and then choose
[Off] (=
23).
• Images cannot be rotated (=
85) when you set [Auto Rotate] to
[Off]. Additionally, images already rotated will be displayed in the
original orientation.
• In Smart Shufe (=
79) mode, even if [Auto Rotate] is set to
[Off], images shot vertically will be displayed vertically, and rotated
images will be displayed in the rotated orientation.
87
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images Movies
Tagging Images as Favorites
You can organize images by tagging them as favorites. By choosing a
category in ltered playback, you can restrict the following operations to all
of those images.
• Viewing (=
73), Viewing Slideshows (=
78), Protecting Images
(=
80), Erasing Images (=
83), Adding Images to the Print List
(DPOF) (=
137), Adding Images to a Photobook (=
140)
Press the <m> button, and then choose
[
] in the menu (=
22).
[Tagged as Favorite] is displayed.
To untag the image, repeat this process
and choose [
] again, and then press
the <m> button.
Using the Menu
1 Choose [Favorites].
Press the <n> button and choose
[Favorites] on the [1] tab (=
23).
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button. [
] is displayed.
To untag the image, press the <m>
button again. [
] is no longer displayed.
Repeat this process to choose additional
images.
3 Finish the setup process.
Press the <n> button.
A conrmation message is displayed.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
• Images will not be tagged as favorites if you switch to Shooting
mode or turn the camera off before nishing the setup process in
step 3.
• Favorite images will have a three-star rating ( ) when transferred
to computers running Windows 8, Windows 7, or Windows Vista. (Does not
apply to movies.)
88
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Editing Still Images
• Image editing (=
88 – 91) is only available when the memory
card has sufcient free space.
Still Images
Resizing Images
Save a copy of images at a lower resolution.
1 Choose [Resize].
Press the <n> button and choose
[Resize] on the [1] tab (=
23).
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
3 Choose an image size.
Press the <q><r> buttons or turn the
<5> dial to choose the size, and then
press the <m> button.
[Save new image?] is displayed.
4 Save the new image.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
The image is now saved as a new le.
5 Review the new image.
Press the <n> button. [Display new
image?] is displayed.
Press the <q><r> buttons or turn the
<5> dial to choose [Yes], and then
press the <m> button.
The saved image is now displayed.
• Editing is not possible for images shot at a resolution of [
]
(=
37) or saved as [ ] in step 3.
• Images cannot be resized to a higher resolution.
Still Images
Cropping
You can specify a portion of an image to save as a separate image le.
1 Choose [Cropping].
Press the <n> button, and then
choose [Cropping] on the [1] tab
(=
23).
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
89
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Adjust the cropping area.
A frame is displayed around the portion of
the image to be cropped.
The original image is shown in the upper
left, and a preview of the image as
cropped is shown in the lower right.
To resize the frame, move the zoom
lever.
To move the frame, press the
<o><p><q><r> buttons.
To change the frame orientation, press
the <l> button.
Faces detected in the image are
enclosed in gray frames in the upper-left
image. To crop the image based on this
frame, turn the <5> dial to switch to the
other frame.
Press the <m> button.
4 Save as a new image and
review.
Follow steps 4 – 5 in “Resizing Images”
(=
88).
• Editing is not possible for images shot at a resolution of [
]
(=
37) or resized to [ ] (=
88).
• Images supported for cropping will have the same aspect ratio after cropping.
• Cropped images will have a lower resolution than uncropped images.
Resolution After Cropping
Preview of Image
After Cropping
Cropping Area
Still Images
Changing Image Color Tones (My Colors)
You can adjust image colors and then save the edited image as a separate
le. For details on each option, see “Changing Image Color Tones (My
Colors)” (=
57).
1 Choose [My Colors].
Press the <n> button, and then
choose [My Colors] on the [1] tab
(=
23).
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
3 Choose an option.
Press the <q><r> buttons or turn the
<5> dial to choose an option, and then
press the <m> button.
4 Save as a new image and
review.
Follow steps 4 – 5 in “Resizing Images”
(=
88).
• Image quality of pictures you repeatedly edit this way will be a little
lower each time, and you may not be able to obtain the desired
color.
• The color of images edited using this function may vary slightly from the color
of images shot using My Colors (=
57).
90
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Correcting Image Brightness (i-Contrast)
Excessively dark image areas (such as faces or backgrounds) can be
detected and automatically adjusted to the optimal brightness. Insufcient
overall image contrast is also automatically corrected, to make subjects
stand out better. Choose from four correction levels, and then save the
image as a separate le.
1 Choose [i-Contrast].
Press the <n> button, and then
choose [i-Contrast] on the [1] tab
(=
23).
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
3 Choose an option.
Press the <q><r> buttons or turn the
<5> dial to choose an option, and then
press the <m> button.
4 Save as a new image and
review.
Follow steps 4 – 5 in “Resizing Images”
(=
88).
• For some images, correction may be inaccurate or may cause
images to appear grainy.
• Images may look grainy after repeated editing using this function.
• If [Auto] does not produce the expected results, try correcting images using
[Low], [Medium], or [High].
Still Images
Correcting Red-Eye
Automatically corrects images affected by red-eye. You can save the
corrected image as a separate le.
1 Choose [Red-Eye Correction].
Press the <n> button, and then
choose [Red-Eye Correction] on the [1]
tab (=
23).
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image.
3 Correct the image.
Press the <m> button.
Red-eye detected by the camera is now
corrected, and frames are displayed
around corrected image areas.
Enlarge or reduce images as needed.
Follow the steps in “Magnifying Images”
(=
78).
91
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Save as a new image and
review.
Press the <o><p><q><r> buttons or
turn the <5> dial to choose [New File],
and then press the <m> button.
The image is now saved as a new le.
Follow step 5 in “Resizing Images”
(=
88).
• Some images may not be corrected accurately.
• To overwrite the original image with the corrected image, choose
[Overwrite] in step 4. In this case, the original image will be erased.
• Protected images cannot be overwritten.
Movies
Editing Movies
You can cut movies to remove unneeded portions at the beginning or end.
1 Choose [*].
Following steps 1 – 5 in “Viewing”
(=
73), choose [*] and press the
<m> button.
The movie editing panel and editing bar
are now displayed.
2 Specify portions to cut.
Press the <o><p> buttons to choose
[
] or [ ].
To view the portions you can cut
(identied by [
] on the screen), press
the <q><r> buttons or turn the <5>
dial to move [
]. Cut the beginning of the
movie (from [
]) by choosing [ ], and
cut the end of the movie by choosing
[
].
If you move [ ] to a position other than a
[
] mark, in [ ] the portion before the
nearest [
] mark on the left will be cut,
while in [
] the portion after the nearest
[
] mark on the right will be cut.
Movie Editing Panel
Movie Editing Bar
92
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Review the edited movie.
Press the <o><p> buttons to choose
[
], and then press the <m> button.
The edited movie is now played.
To edit the movie again, repeat step 2.
To cancel editing, press the <o><p>
buttons to choose [
]. Press the <m>
button, choose [OK] (either press the
<q><r> buttons or turn the <5> dial),
and then press the <m> button again.
4 Save the edited movie.
Press the <o><p> buttons to choose
[
], and then press the <m> button.
Press the <o><p><q><r> buttons or
turn the <5> dial to choose [New File],
and then press the <m> button.
The movie is now saved as a new le.
• To overwrite the original movie with the cut one, choose [Overwrite]
in step 4. In this case, the original movie will be erased.
• If the memory card lacks sufcient space, only [Overwrite] will be
available.
• Movies may not be saved if the battery pack runs out while saving
is in progress.
• When editing movies, you should use a fully charged battery pack or
an AC adapter kit (sold separately, =
126).
Movies
Editing Digest Movies
Individual chapters (clips) (=
43) recorded in [ ] mode can be erased,
as needed. Be careful when erasing clips, because they cannot be recovered.
1 Select the clip to erase.
Follow steps 1 – 2 in “Viewing Short
Movies Created When Shooting Still
Images (Digest Movies)” (=
75) to
play a movie created in [
] mode, and
then press the <m> button to access the
movie control panel.
Press the <q><r> buttons or turn the
<5> dial to choose [
] or [ ], and
then press the <m> button.
2 Choose [ ].
Press the <q><r> buttons or turn the
<5> dial to choose [
], and then press
the <m> button.
The selected clip is played back
repeatedly.
3 Conrmerasure.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
The clip is erased, and the short movie is
overwritten.
• [ ] is not displayed if you select a clip when the camera is connected to a
printer.
93
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Wi-Fi Functions
Send images wirelessly from the camera to a variety of compatible devices, and use the camera
with Web services
7
What You Can Do with Wi-Fi ...........................94
Preparing to Share Images via Wi-Fi ..............95
Uploading Images to Web Services ...................... 95
Sending Images to a Smartphone .........................95
Sending Images to Another Camera ..................... 95
Sending Images to a Computer ............................96
Printing Images Wirelessly ....................................96
Registering Web Services ............................... 96
Registering CANON iMAGE GATEWAY ...............97
Registering Other Web Services ........................... 99
Installing CameraWindow on a Smartphone
..........................................................................99
Preparing to Register a Computer ................100
Checking Your Computer Environment ............... 100
Installing the Software .........................................100
Conguring the Computer for a Wi-Fi Connection
(Windows Only) ...................................................101
Accessing the Wi-Fi Menu .............................101
Initial Connection via Wi-Fi ..................................101
After the Initial Wi-Fi Connection .........................102
Connecting via an Access Point ...................102
Conrming Access Point Compatibility ................102
Connecting to WPS-Compatible Access Points .. 103
Connecting to Access Points in the List .............. 105
Connecting without an Access Point ...........106
Previous Access Points .......................................108
Connecting to Another Camera ....................108
Sending Images ..............................................109
Sending Images Individually ...............................109
Sending Multiple Images .....................................110
Adding Comments ................................................111
Saving Images to a Computer ........................111
Sending Images Automatically
(Image Sync) ................................................. 112
Initial Preparations .............................................. 112
Sending Images .................................................. 113
Geotagging Images on the Camera .............. 114
Editing or Erasing Wi-Fi Settings ................. 114
Editing Connection Information ...........................114
Returning the Wi-Fi Settings to Default ...............116
94
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Connecting to a Computer
Use the software to wirelessly send images from the camera to
a computer.
Connecting to a Printer
Send images wirelessly to a PictBridge-compatible printer
(supporting DPS over IP) to print them.
• Before using Wi-Fi, be sure to read “Wi-Fi (Wireless LAN)
Precautions” (=
165) and “Security Precautions” (=
166).
What You Can Do with Wi-Fi
This camera is an approved Wi-Fi
®
* product. You can wirelessly connect to
and send images to the following devices and services.
Note that, in this chapter, wireless LAN functions other than Wi-Fi may be
referred to as Wi-Fi.
* Wi-Fi is a brand name that indicates interoperability certication of wireless
LAN devices.
Connecting to Web Services
Images can be sent to social network services and other Web
services via CANON iMAGE GATEWAY*. Unsent images on
the camera can also be sent automatically to a computer or
Web service via CANON iMAGE GATEWAY.
* CANON iMAGE GATEWAY is an online photo service available to
those who have purchased this product.
Connecting to a Smartphone
Send images to smartphones and tablet computers that
have Wi-Fi functions. You can also geotag your shots from a
connected smartphone or tablet.
For convenience in this manual, smartphones, tablets, and
other compatible devices are collectively referred to as
“smartphones”.
Connecting to Another Camera
Use the Wi-Fi function to send images between Canon-brand,
compact digital cameras.
95
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Preparing to Share Images via Wi-Fi
Sending images via Wi-Fi requires some initial preparation on the camera
and target devices. Preparations and methods of sending images vary
depending on the destination.
Note that before using Wi-Fi (=
101), you will need to register a camera
nickname on the camera.
Uploading Images to Web Services
SNS, video-sharing
sites, e-mail
Access point
Camera
Computer or smartphone
browsers
CANON iMAGE GATEWAY
Register Web services (=
96)
Connect via an access point (=
102)
Send images (=
109)*
* You can send images to a computer or Web service (=
112).
Sending Images to a Smartphone
Internet
Smartphone
Tablet computer
Access point
Camera
CameraWindow
Install CameraWindow on a smartphone (=
99)
Connect directly (=
106) or via an access point (=
102)
Send images (=
109)
Sending Images to Another Camera
Camera Camera
Connect to another camera (=
108)
Send images (=
109)
96
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Sending Images to a Computer
Camera
Computer
Access point
Internet
CameraWindow
Check your computer environment (=
100)
Install CameraWindow on a computer (=
100)
Congure the computer for a Wi-Fi connection (Windows only, =
101)
Connect via an access point (=
102)
Save images to a computer (=
111)
Printing Images Wirelessly
Camera
Printer
Access point
Connect directly (=
106) or via an access point (=
102)
Print images (=
133)
Registering Web Services
Use a smartphone or computer to add to the camera Web services that you
want to use.
• A smartphone or computer with a browser and Internet connection is
required to complete camera settings for CANON iMAGE GATEWAY and
other Web services.
• Check the CANON iMAGE GATEWAY website for details on browser
(Microsoft Internet Explorer, etc.) requirements, including settings and
version information.
• For information on countries and regions where CANON iMAGE
GATEWAY is available, visit the Canon website (http://www.canon.com/
cig/).
• You must have an account with Web services other than CANON iMAGE
GATEWAY if you desire to use them. For further details, check the
websites for each Web service you want to register.
• Separate ISP connection and access point fees may be applicable.
97
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Choose [ ].
Press the <o><p><q><r> buttons or
turn the <5> dial to choose [
], and
then press the <m> button.
5 Establish a connection with the
access point.
Press the <q><r> buttons or turn the
<5> dial to choose [Authenticate], and
then press the <m> button.
6 Choose an access point.
Press the <o><p> buttons or turn the
<5> dial to choose a network (access
point), and then press the <m> button.
7 Enter the access point
password.
Press the <m> button to access the
keyboard, and then enter the password
(=
103).
Press the <o><p> buttons or turn the
<5> dial to choose [Next], and then
press the <m> button.
Registering CANON iMAGE GATEWAY
After linking the camera and CANON iMAGE GATEWAY, add CANON
iMAGE GATEWAY as a destination Web service on the camera.
1 Log in to CANON iMAGE
GATEWAY and access the
camera settings page.
From a computer or smartphone, access
http://www.canon.com/cig/ and visit the
CANON iMAGE GATEWAY site for your
region.
Access the camera settings page.
Once the login screen is displayed,
enter your user name and password
to log in. If you do not have a CANON
iMAGE GATEWAY account, follow
the instructions to complete member
registration (free of charge).
2 Choose your camera model.
On this camera model, [ ] is displayed
in the Wi-Fi menu.
Once you choose the model, a page is
displayed for entering the authentication
code. On this page in step 9, you will
enter the authentication code displayed
on the camera after steps 3 – 8.
3 Access the Wi-Fi menu.
On the camera, access the Wi-Fi menu
(=
101).
98
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
8 Choose [Auto] and establish the
connection.
Press the <o><p> buttons or turn the
<5> dial to choose [Auto], and then
press the <m> button.
Once the camera is connected to CANON
iMAGE GATEWAY via the access point,
an authentication code is displayed.
9 Enter the authentication code.
On the smartphone or computer, enter
the authentication code displayed on the
camera and go to the next step.
A six-digit conrmation number is
displayed.
10
Checktheconrmation
numbers and complete the
setup process.
Make sure the conrmation number on
the camera matches the number on the
smartphone or computer.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
Complete the setup process on the
smartphone or computer.
[ ] (=
112) and CANON iMAGE
GATEWAY are now added as
destinations, and the [
] icon changes
to [
].
A message is displayed on the
smartphone or computer to indicate that
this process is nished. To add other
Web services, follow the procedure
in “Registering Other Web Services”
(=
99) from step 2.
• You can connect to WPS-compatible access points by choosing [WPS
Connection] in step 6. For details, see steps 6 – 8 in “Connecting to WPS-
Compatible Access Points” (=
103).
99
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Registering Other Web Services
You can also add Web services besides CANON iMAGE GATEWAY to the
camera. Note that CANON iMAGE GATEWAY must be registered on the
camera rst (=
97).
1 Access the Web service
settings screen.
Follow step 1 in “Registering CANON
iMAGE GATEWAY” (=
97) to log in
to CANON iMAGE GATEWAY, and then
access the Web service settings screen.
2 ConguretheWebserviceyou
want to use.
Follow the instructions displayed on the
smartphone or computer to set up the
Web service.
3 Choose [ ].
Access the Wi-Fi menu (=
101),
choose [
] (either press the
<o><p><q><r> buttons or turn the
<5> dial), and then press the <m>
button.
The Web service settings are now
updated.
• If any congured settings change, follow these steps again to update the
camera settings.
Installing CameraWindow on a
Smartphone
Before connecting your camera to a smartphone, rst install the free
dedicated application, CameraWindow, on your smartphone.
1 Connect the smartphone to a
network.
2 Install CameraWindow.
For an iPhone, iPad, or iPod touch,
download and install CameraWindow
from the App Store.
For an Android device, download and
install CameraWindow from Google Play.
After installation, use the camera
to establish a connection with the
smartphone (= 102, 106).
• For details on this application (supported smartphones and included functions),
refer to the Canon website.
100
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Preparing to Register a Computer
Prepare to register a computer. To save images to the computer wirelessly,
you must install CameraWindow.
Checking Your Computer Environment
The camera can connect via Wi-Fi to computers running the following
operating systems. For detailed system requirements and compatibility
information, including support in new operating systems, visit the Canon
website.
Operating
System
Windows Macintosh
Windows 8
Windows 7 SP1
Mac OS X 10.6.8
Mac OS X 10.7
Mac OS X 10.8.2 or later
• Windows 7 Starter and Home Basic editions are not supported.
• Windows 7 N (European version) and KN (South Korean version)
require a separate download and installation of Windows Media
Feature Pack.
For details, check the following website.
http://go.microsoft.com/fwlink/?LinkId=159730
Installing the Software
Windows 7 and Mac OS X 10.6 are used here for the sake of illustration.
1 Download the software.
With a computer connected to the
Internet, access http://www.canon.com/
icpd/.
Access the site for your country or region.
Download the software.
2 Install the software.
Click [Easy Installation] and follow the
on-screen instructions to complete the
installation process.
Installation may take some time,
depending on computer performance and
the Internet connection.
Click [Finish] or [Restart] on the screen
after installation.
• Using the software, you can update to the latest version, and download new
functions via the Internet (some software excluded).
• The rst time you connect the camera to the computer, drivers will be installed,
so it may take a few minutes until camera images are accessible.
101
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Conguring the Computer for a Wi-Fi
Connection (Windows Only)
On a computer running Windows, congure the following settings before
connecting the camera to the computer wirelessly.
1 Conrmthatthecomputeris
connected to the access point.
For instructions on checking your network
connection, refer to the computer user
manual.
2 Congurethesetting.
Click in the following order: [Start] menu
►
[All Programs]
►
[Canon Utilities]
►
[CameraWindow]
►
[Wi-Fi connection
setup].
In the application that opens, follow the
on-screen instructions and congure the
setting.
• The following Windows settings are congured when you run the utility in
step 2.
- Turn on media streaming.
This will enable the camera to see (nd) the computer to access via Wi-Fi.
- Turn on network discovery.
This will enable the computer to see (nd) the camera.
- Turn on ICMP (Internet Control Message Protocol).
This allows you to check the network connection status.
- Enable Universal Plug & Play (UPnP).
This will enable network devices to detect each other automatically.
• Some security software may prevent you from completing the settings as
described here. Check the settings of your security software.
Accessing the Wi-Fi Menu
Initial Connection via Wi-Fi
To start with, register a camera nickname.
This nickname will be displayed on the screen of target devices when
connecting to other devices via Wi-Fi.
1 Access the Wi-Fi menu.
Press the <1> button to turn the camera
on.
Press the <o> button.
2 Enter a nickname.
Press the <m> button to access the
keyboard, and then enter a nickname
(=
24).
Up to 16 characters can be used.
Press the <o><p> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
The Wi-Fi menu is displayed.
102
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• When connecting wirelessly to any device other than a computer, a memory
card must be inserted in the camera. Additionally, the memory card must
contain images in order for you to access Web services or connect to a
smartphone or printer wirelessly.
• To change the camera’s nickname, choose [Wi-Fi Settings] on the [3] tab, and
then choose [Change Device Nickname].
• If the Wi-Fi menu is not displayed but only the information changes when
you press the <o> button, rst press the <p> button to switch from detailed
information display (=
74).
• Nicknames beginning with a space cannot be entered in step 2. If you attempt
to do this and press the <n> button on the keyboard screen, a message
will be displayed. Press the <m> button to access the keyboard, and then
enter a new nickname.
After the Initial Wi-Fi Connection
• Once you have connected to devices via Wi-Fi, recent destinations will
be listed rst when you access the Wi-Fi menu by pressing the <o>
button. You can easily connect again by pressing the <o><p> buttons
to choose the device name and then pressing the <m> button.
• To add a new device, display the device selection screen by pressing the
<q><r> buttons, and then congure the setting.
• If you prefer not to display recent target devices, press the <n> button,
and on the [3] tab, choose [Wi-Fi Settings] > [Target History] > [Off].
Connecting via an Access Point
Connect to your access point via Wi-Fi as follows.
Also refer to the access point user manual.
Conrming Access Point Compatibility
Conrm that the Wi-Fi router or base station conforms to the Wi-Fi
standards in “Specications” (=
159).
If you are already using Wi-Fi, conrm the following items. For instructions
on checking network settings, refer to the access point user manual.
• If system administrator status is needed to adjust network settings,
contact the system administrator for details.
• These settings are very important for network security. Exercise
adequate caution when changing these settings.
103
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Check sheet
Network name (SSID/ESSID)
The SSID or ESSID for the access point you use.
Also called the “access point name” or “network name”.
Network authentication / data encryption
(encryption method / encryption mode)
The method for encrypting data during wireless transmission.
○ None
○ WEP (open system
authentication)
○ WPA-PSK (TKIP)
○ WPA-PSK (AES)
○ WPA2-PSK (TKIP)
○ WPA2-PSK (AES)
Password (encryption key / network key)
The key used when encrypting data during wireless
transmission. Also called the “encryption key” or “network
key”.
Key index (transmit key)
The key set when WEP is used for network authentication /
data encryption.
○ 1
Connection methods vary depending on whether the access point supports
Wi-Fi Protected Setup (WPS) or not. Refer to the user manual provided with
your access point to check if it supports WPS.
• A router is a device that creates a network (LAN) structure for connecting
multiple computers. A router that contains an internal Wi-Fi function is called a
“Wi-Fi router”.
• This guide refers to all Wi-Fi routers and base stations as “access points”.
• If you use MAC address ltering on your Wi-Fi network, be sure to add the
camera’s MAC address to your access point. You can check your camera’s
MAC address by choosing the [3] tab, [Wi-Fi Settings], and then [Check MAC
Address].
Connecting to WPS-Compatible Access Points
WPS makes it easy to complete settings when connecting devices over
Wi-Fi. You can use either Push Button Conguration Method or PIN Method
for settings on a WPS supported device.
1 Conrmthatthetargetdeviceis
connected to the access point.
This step is not required when connecting
to Web services.
For instructions on checking the
connection, refer to the device and
access point user manuals.
2 Access the Wi-Fi menu
(=
101).
3 Choose the target device.
Choose the target device (either press
the <o><p><q><r> buttons or turn
the <5> dial), and then press the <m>
button.
To connect to a smartphone, choose [ ].
To connect to a computer, choose [ ].
To connect to a printer, choose [2].
To connect to a Web service, choose
the service icon. If multiple recipients
or sharing options are used with a Web
service, choose the desired item on the
[Select Recipient] screen (either press
the <o><p> buttons or turn the <5>
dial), and then press the <m> button.
104
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Choose [Add a Device].
Press the <o><p> buttons or turn the
<5> dial to choose [Add a Device], and
then press the <m> button.
5 To connect to a smartphone or
printer:
Choose [Switch Network].
When the [Waiting to connect] screen
is displayed (=
106), choose [Switch
Network] (either press the <q><r>
buttons or turn the <5> dial), and then
press the <m> button.
6 Choose [WPS Connection].
Press the <o><p> buttons or turn the
<5> dial to choose [WPS Connection],
and then press the <m> button.
7 Choose [PBC Method].
Press the <o><p> buttons or turn the
<5> dial to choose [PBC Method], and
then press the <m> button.
8 Establish the connection.
On the access point, hold down the WPS
connection button for a few seconds.
On the camera, press the <m> button.
The camera will connect to the access
point.
If you have selected [ ], [2], or [ ] in
step 3, devices connected to the access
point are listed on the [Select a Device]
screen displayed next.
If you have selected a Web service in
step 3, go to step 11.
9 To connect to a smartphone,
printer, or computer:
Choose the target device.
Press the <o><p> buttons or turn the
<5> dial to choose the computer name,
and then press the <m> button.
If you have selected a smartphone,
printer, or Macintosh computer, go to
step 11.
10
If you have selected a computer
running Windows in step 9 for
thersttime:
Install a driver.
When the screen at left is displayed on
the camera, click the Start menu on the
computer, click [Control Panel], and then
click [Add a device].
105
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Double-click the connected camera icon.
Driver installation will begin.
After driver installation is complete, and
the camera and computer connection
is enabled, the AutoPlay screen will be
displayed. Nothing will be displayed on
the camera screen.
11
Send or print the images.
The screen displayed when the devices
are connected varies depending on the
target device.
When the camera is connected to a
smartphone or Web service, an image
transfer screen is displayed.
For instructions on sending images, see
“Sending Images” (=
109).
When the camera is connected to a
computer, the camera screen is blank.
Follow the steps in “Saving Images to a
Computer” (=
111) to save images to
the computer.
When the camera is connected to a
printer, you can print by following the
same steps as for printing via USB. For
details, see “Printing Images” (=
133).
• If you chose [PIN Method] in step 7, a PIN code will be displayed on the
screen. Be sure to set this code in the access point. Choose a device in the
[Select a Device] screen. For further details, refer to the user manual included
with your access point.
• To add multiple destinations, repeat this procedure from the rst step.
Previous Access Points
You can reconnect to any previous access points automatically by following
step 4 in “Connecting to WPS-Compatible Access Points” (=
104).
• To reconnect to the access point, conrm that the target device is already
connected to it, and then follow the procedure from step 9. Note that this
step is not required when connecting to Web services.
• To switch access points, choose [Switch Network] on the screen
displayed when you establish a connection, and then follow the
procedure from step 6.
Connecting to Access Points in the List
1 View the listed access points.
View the listed networks (access
points) as described in steps 1 – 5 of
“Connecting to WPS-Compatible Access
Points” (=
103 – 104).
2 Choose an access point.
Press the <o><p> buttons or turn the
<5> dial to choose a network (access
point), and then press the <m> button.
106
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Enter the access point
password.
Press the <m> button to access the
keyboard, and then enter the password
(=
103).
Press the <o><p> buttons or turn the
<5> dial to choose [Next], and then
press the <m> button.
4 Choose [Auto].
Press the <o><p> buttons or turn the
<5> dial to choose [Auto], and then
press the <m> button.
If you selected [ ], [2], or [ ] as the
target device, see “Connecting to WPS-
Compatible Access Points”, starting with
step 9 (=
104).
If you selected a Web service as the
destination, see “Connecting to WPS-
Compatible Access Points”, starting with
step 11 (=
105).
• To determine the access point password, check on the access point itself or
refer to the user manual.
• Up to 16 access points will be displayed. If no access points are detected,
choose [Manual Settings] in step 2 to manually set an access point. Follow
on-screen instructions and enter an SSID, security settings, and a password.
• When you use an access point that you have already connected to for
connecting to another device, [*] is displayed for the password in step 3. To
use the same password, choose [Next] (either press the <o><p> buttons or
turn the <5> dial) and press the <m> button.
Connecting without an Access Point
When connecting to a smartphone or printer via Wi-Fi, you can use the
camera as an access point (Camera Access Point mode) instead of using
another access point.
Similarly, no access point is used in camera-to-camera connections
(=
108).
1 Access the Wi-Fi menu
(=
101).
2 Choose the target device.
Choose the target device (either press
the <o><p><q><r> buttons or turn
the <5> dial), and then press the <m>
button.
To connect to a smartphone, choose [ ].
To connect to a printer, choose [2].
3 Choose [Add a Device].
Press the <o><p> buttons or turn the
<5> dial to choose [Add a Device], and
then press the <m> button.
The camera’s SSID is displayed.
107
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 On the target device, connect
tothenetworkidentiedonthe
camera.
In the smartphone or printer’s Wi-Fi
setting menu, choose the SSID (network
name) displayed on the camera.
5 For a smartphone connection:
Start CameraWindow on the
smartphone.
The rst time CameraWindow starts
up, register a smartphone nickname for
display on the camera.
Once the smartphone is recognized on
the camera, the device connection screen
will be displayed on the camera.
6 Choose the target device.
Choose the target device name (either
press the <o><p> buttons or turn the
<5> dial), and then press the <m>
button.
7 For a smartphone connection:
Adjust the privacy setting.
Press the <q><r> buttons or turn the
<5> dial to choose [Yes], and then
press the <m> button.
You can now use the smartphone to
receive images sent from the camera,
or to geotag images on the camera
(=
114).
8 Send or print the images.
The screen displayed when the devices
are connected varies depending on the
target device.
When the camera is connected to a
smartphone, an image transfer screen is
displayed.
For instructions on sending images, see
“Sending Images” (=
109).
When the camera is connected to a
printer, you can print by following the
same steps as for printing via USB. For
details, see “Printing Images” (=
133).
• All images in the camera can be viewed from the connected
smartphone when you choose [Yes] in step 7. To keep camera
images private, so that they cannot be viewed from the smartphone,
choose [No] in step 7.
• To change privacy settings for smartphones added to the list,
choose the smartphone whose settings you want to change from
[Edit a Device] in step 3, and then choose [View Settings].
• To add multiple devices, repeat this procedure from the rst step.
• For better security, you can require password input on the screen in step 3 by
accessing MENU and choosing [3] tab > [Wi-Fi Settings] > [Password] > [On].
In this case, in the password eld on the device in step 4, enter the password
displayed on the camera.
108
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Previous Access Points
You can reconnect to any previous access points automatically by following
step 3 in “Connecting without an Access Point” (=
106).
• To use the camera as an access point, choose [Switch Network] on the
screen displayed when you establish a connection, and then choose [Set
Camera As Access Point].
• When reconnecting via a previous access point, connect the target
device to the access point in step 4.
• To switch access points, choose [Switch Network] on the screen
displayed when you establish a connection, and then follow the
procedure in “Connecting to WPS-Compatible Access Points” from step 6
(=
104).
Connecting to Another Camera
Connect two cameras via Wi-Fi and send images between them as follows.
• Only Canon-brand cameras equipped with a Wi-Fi function can be connected
to wirelessly. Even Canon-brand cameras that support Eye-Fi cards cannot
be connected to if they do not have a Wi-Fi function. You cannot connect to
PowerShot SD430 DIGITAL ELPH WIRELESS/DIGITAL IXUS WIRELESS
cameras with this camera.
1 Access the Wi-Fi menu
(=
101).
2 Choose camera.
Press the <o><p><q><r> buttons or
turn the <5> dial to choose [4], and
then press the <m> button.
3 Choose [Add a Device].
Press the <o><p> buttons or turn the
<5> dial to choose [Add a Device], and
then press the <m> button.
Follow steps 1 – 3 on the target camera
too.
Camera connection information will be
added when [Start connection on target
camera] is displayed on both camera
screens.
109
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
When the target camera has been added
successfully, the image transfer screen
will be displayed. Proceed to “Sending
Images” (=
109).
• To add multiple cameras, repeat the above procedures starting from step 1.
• Once a camera is added, the camera name will be displayed on the screen in
step 3. To connect to a camera again, simply choose the camera name from
the list.
Sending Images
Send images wirelessly to destinations registered on the camera as follows.
Note that when images are sent to a computer, the computer is used
instead of the camera (=
111).
Sending Images Individually
1 Choose an image.
Turn the <5> dial to choose an image
to send.
2 Send the image.
Press the <q><r> buttons to choose
[Send this image], and then press the
<m> button.
When uploading to YouTube, read the
terms of service, choose [I Agree], and
press the <m> button.
Image transfer will begin. The screen
darkens during image transfer.
After images are uploaded to a Web
service, [OK] is displayed. Press the
<m> button to return to the playback
screen.
After sending images to a camera or
smartphone, [Transfer completed] will be
displayed, and the display will return to
the image transfer screen.
110
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Keep your ngers or other objects off the Wi-Fi antenna area (=
3).
Covering this may decrease the speed of your image transfers.
• Depending on the condition of the network you are using, it may take a long
time to send movies. Be sure to keep an eye on the camera battery level.
• When sending movies to smartphones, note that the supported image quality
varies depending on the smartphone. For details, refer to the smartphone user
manual.
• To disconnect from the camera, press the <n> button, choose [OK] on
the conrmation screen (either press the <q><r> buttons or turn the <5>
dial), and then press the <m> button. You can also use the smartphone to
end the connection.
• On the screen, wireless signal strength is indicated by the following icons.
[
] high, [ ] medium, [ ] low, [ ] weak
• Sending images to Web services will take less time when resending images
you have already sent that are still on the CANON iMAGE GATEWAY server.
Choosing the Image Resolution (Size)
On the image transfer screen, choose [ ] by pressing the <o><p>
buttons, and then press the <m> button. On the next screen, choose the
resolution by pressing the <o><p> buttons, and then press the <m>
button.
• To send images at original size, select [No] as the resizing option.
• Choosing [ ] or [ ] will resize images that are larger than the selected
size before sending.
• Movies cannot be resized.
Sending Multiple Images
1 Choose [Select and send].
Press the <q><r> buttons to choose
[Select and send], and then press the
<m> button.
2 Choose images.
Press the <o><p><q><r> buttons to
choose an image to send, and then press
the <m> button. [
] is displayed.
To cancel selection, press the <m>
button again. [
] is no longer displayed.
Repeat this process to choose additional
images.
After you nish choosing images, press
the <n> button.
3 Send the images.
Press the <q><r> buttons or turn the
<5> dial to choose [Send], and then
press the <m> button.
• Up to 50 images can be sent together at once. You can send movies together
as long as the total playback time is within two minutes.
• Web services may limit the number of images you can send. For details, refer
to the Web service you are using.
• You can also choose images in step 2 by moving the zoom lever twice toward
<k> to access single-image display and then pressing the <q><r> buttons or
turning the <5> dial.
• In step 3, you can choose the desired resolution (size) of your images before
sending (=
37).
111
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Adding Comments
Using the camera, you can add comments (alphanumeric characters and
symbols) to images that you send to e-mail addresses, social networking
services, etc. The number of characters and symbols that can be entered
may differ depending on the Web service.
1 Access the screen for adding
comments.
Press the <o><p><q><r> buttons to
choose [
], and then press the <m>
button.
2 Add a comment (=
24).
3 Send the image.
Follow the steps in “Sending Images
Individually” (=
109) to send the image.
• When a comment is not entered, the comment set in CANON iMAGE
GATEWAY is automatically sent.
Saving Images to a Computer
When sending images to a computer, use the computer instead of the
camera.
Windows 7 and Mac OS X 10.6 are used here for the sake of illustration.
For other functions, refer to the help system of the relevant software (some
software excluded).
1 Display CameraWindow.
In Windows, access CameraWindow by
clicking [Downloads Images From Canon
Camera].
On a Macintosh computer,
CameraWindow is automatically
displayed when a Wi-Fi connection is
established between the camera and
computer.
2 Import images.
Click [Import Images from Camera], and
then click [Import Untransferred Images].
Images are now saved to the Pictures
folder on the computer, in separate
folders named by date.
Click [OK] in the screen that is displayed
after image import is complete. For
instructions on viewing images on a
computer, refer to “Software Instruction
Manual” (=
131).
112
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Sending Images Automatically
(Image Sync)
Images on the memory card that have not been transferred already can be
sent to a computer or Web services via CANON iMAGE GATEWAY.
Note that images cannot be sent only to Web services.
Initial Preparations
Install and congure the software on the destination computer.
1 Install the software.
Install the software on a computer
connected to the Internet (=
100).
2 Register the camera.
Windows: In the taskbar, right-click [ ],
and then click [Add new camera].
Macintosh: In the menu bar, click [ ],
and then click [Add new camera].
Choose a source camera from one of
the cameras listed, which are linked to
CANON iMAGE GATEWAY (=
97).
Once the camera is registered and ready
to receive images, the icon changes to
[
].
• Movies will take longer to import since the le size is larger than still images.
• To disconnect from the camera, turn off the camera.
• You can also specify to save all images or only selected images to the
computer, and you can change the destination folder. Refer to “Software
Instruction Manual” (=
131) for details.
• In Windows 7, if the screen in step 2 is not displayed, click the [
] icon in the
taskbar.
• On a Macintosh computer, if CameraWindow is not displayed, click the
[CameraWindow] icon in the Dock (the bar at the bottom of the desktop).
• Although you can save images to a computer simply by connecting your
camera to the computer without using the software, the following limitations
apply.
- It may take a few minutes after you connect the camera to the computer until
camera images are accessible.
- Images shot in vertical orientation may be saved in horizontal orientation.
- Image protection settings may be cleared from images saved to a computer.
- Some problems may occur when saving images or image information,
depending on the operating system version, the software in use, or image
le sizes.
- Some functions provided by the software may not be available, such as
movie editing.
113
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
When the images have been sent
successfully to the CANON iMAGE
GATEWAY server, [
] is displayed on
the screen.
Images are automatically saved to the
computer when you turn it on.
Images are automatically sent to Web
services from the CANON iMAGE
GATEWAY server, even if the computer
is off.
• When sending images, you should use a fully charged battery pack
or an AC adapter kit (sold separately, =
126).
• Even if images were imported to the computer through a different method, any
images not sent to the computer via CANON iMAGE GATEWAY will be sent to
the computer.
• Sending is faster when the destination is a computer on the same network
as the camera, because images are sent via the access point instead of
CANON iMAGE GATEWAY. Note that images stored on the computer are
sent to CANON iMAGE GATEWAY, so the computer must be connected to the
Internet.
3 Choose the type of images
to send (only when sending
movies with images).
Press the <n> button, and then
choose [Wi-Fi Settings] on the [3] tab
(=
23).
Press the <o><p> buttons to choose
[Image Sync], and then press the
<q><r> buttons to choose [Stills/
Movies].
• To choose a Web service as the destination, follow the steps in “Registering
Other Web Services” (=
99) to update the camera settings.
Sending Images
Images sent from the camera are automatically saved to the computer.
If the computer that you intend to send images to is turned off, the images
will be stored temporarily on the CANON iMAGE GATEWAY server. Stored
images are regularly erased, so make sure to turn on the computer and
save the images.
Follow the steps in “Connecting to WPS-
Compatible Access Points” (=
103) to
choose [
].
Once the connection is established, the
images are sent.
114
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Editing or Erasing Wi-Fi Settings
Edit or erase Wi-Fi settings as follows.
Editing Connection Information
1 Access the Wi-Fi menu
(=
101).
2 Choose a device to edit.
Press the <o><p><q><r> buttons or
turn the <5> dial to choose the icon
of the device to edit, and then press the
<m> button.
3 Choose [Edit a Device].
Press the <o><p> buttons or turn the
<5> dial to choose [Edit a Device], and
then press the <m> button.
4 Choose a device to edit.
Press the <o><p> buttons or turn the
<5> dial to choose the device to edit,
and then press the <m> button.
Geotagging Images on the Camera
GPS data recorded on a smartphone using the dedicated CameraWindow
application (=
99) can be added to images on the camera. Images are
tagged with information including the latitude, longitude, and elevation.
• Before shooting, make sure the date and time and your home time
zone are set correctly. (See “Setting the Date and Time” (=
14).)
Additionally, in [Time Zone] (=
119), specify any shooting
destinations that are in other time zones.
• The smartphone you will use for geotagging must be authorized to
view the images on the camera (=
107).
• Others may be able to locate or identify you by using location data
in your geotagged still images or movies. Be careful when sharing
these images with others, as when posting images online where
many others can view them.
115
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Erasing Connection Information
Erase connection information (information about devices that you have
connected to) as follows.
Following step 5 in “Editing Connection
Information” (=
115), choose [Erase
Connection Info] and press the <m>
button.
After [Erase?] is displayed, press the
<q><r> buttons or turn the <5> dial to
choose [OK], and then press the <m>
button.
The connection information will be
erased.
5 Choose an item to edit.
Press the <o><p> buttons or turn the
<5> dial to choose an item to edit, and
then press the <m> button.
The items you can change depend on
what device or service the camera will
access.
CongurableItems
Connection
4
c
Web
Services
[Change Device Nickname] (=
115)
O O O O
–
[View Settings] (=
107)
–
O
– – –
[Erase Connection Info] (=
115)
O O O O
–
O
: Congurable
–
: Not congurable
Changing a Device Nickname
You can change the device nickname (display name) that is displayed on
the camera.
Following step 5 in “Editing Connection
Information” (=
115), choose [Change
Device Nickname] and press the <m>
button.
Select the input eld and press the <m>
button. Use the keyboard displayed to
enter a new nickname (=
24).
116
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Returning the Wi-Fi Settings to Default
Return the Wi-Fi settings to default if you transfer ownership of the camera
to another person, or dispose of it.
1 Choose [Wi-Fi Settings].
Press the <n> button, and then
choose [Wi-Fi Settings] on the [3] tab
(=
23).
2 Choose [Reset Settings].
Press the <o><p> buttons or turn the
<5> dial to choose [Reset Settings],
and then press the <m> button.
3 Restore the default settings.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
The Wi-Fi settings are now reset.
• Resetting the Wi-Fi settings will also clear all Web service settings. Be sure
that you want to reset all Wi-Fi settings before using this option.
• To reset other settings (aside from Wi-Fi) to defaults, choose [Reset All] in the
[3] tab (=
123).
117
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Setting Menu
Customize or adjust basic camera functions for greater convenience
8
Adjusting Basic Camera Functions .............. 118
Silencing Camera Operations ............................. 118
Adjusting the Volume .......................................... 118
Hiding Hints and Tips .......................................... 118
Date and Time .....................................................118
World Clock .........................................................119
Lens Retraction Timing .......................................119
Using Eco Mode ..................................................119
Power-Saving Adjustment ................................... 120
Screen Brightness ...............................................120
Hiding the Start-Up Screen .................................120
Formatting Memory Cards ..................................121
File Numbering ....................................................122
Date-Based Image Storage .................................122
Metric / Non-Metric Display ................................. 122
Checking Certication Logos ..............................123
Display Language ...............................................123
Adjusting Other Settings .....................................123
Restoring Defaults ...............................................123
118
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Adjusting Basic Camera Functions
Functions can be congured on the [3] tab. Customize commonly used
functions as desired, for greater convenience (=
23).
Silencing Camera Operations
Silence camera sounds and movies as follows.
Choose [Mute], and then choose [On].
• Operation can also be silenced by holding down the <l> button as you
turn the camera on.
• Sound is not played during movies (=
73) if you mute camera sounds. To
restore sound during movies, press the <o> button. Adjust volume with the
<o><p> buttons, as needed.
• Sound settings cannot be changed in [
] mode (=
43).
Adjusting the Volume
Adjust the volume of individual camera sounds as follows.
Choose [Volume], and then press the
<m> button.
Choose an item, and then press the
<q><r> buttons to adjust the volume.
Hiding Hints and Tips
Hints and tips are normally shown when you choose FUNC. (=
22) or
MENU (=
23) items. If you prefer, you can deactivate this information.
Choose [Hints & Tips], and then choose
[Off].
Date and Time
Adjust the date and time as follows.
Choose [Date/Time], and then press the
<m> button.
Press the <q><r> buttons to choose an
option, and then adjust the setting, either
by pressing the <o><p> buttons or
turning the <5> dial.
119
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
World Clock
To ensure that your shots will have the correct local date and time when you
travel abroad, simply register the destination in advance and switch to that
time zone. This convenient feature eliminates the need to change the Date/
Time setting manually.
Before using the world clock, be sure to set the date and time and your
home time zone, as described in “Setting the Date and Time” (=
14).
1 Specify your destination.
Choose [Time Zone], and then press the
<m> button.
Press the <o><p> buttons or turn the
<5> dial to choose [
World], and then
press the <m> button.
Press the <q><r> buttons or turn the
<5> dial to choose the destination.
To set daylight saving time (1 hour
ahead), press the <o><p> buttons to
choose [
].
Press the <m> button.
2 Switch to the destination time
zone.
Press the <o><p> buttons or turn the
<5> dial to choose [
World], and then
press the <n> button.
[ ] is now shown on the shooting screen
(=
149).
• Adjusting the date or time while in [ ] mode (=
14) will automatically
update your [
Home] time and date.
Lens Retraction Timing
The lens is normally retracted for safety about one minute after you press
the <1> button in Shooting mode (=
20). To have the lens retracted
immediately after you press the <1> button, set the retraction timing to
[0 sec.].
Choose [Lens Retract], and then choose
[0 sec.].
Using Eco Mode
This function allows you to conserve battery power in Shooting mode. When
the camera is not in use, the screen quickly darkens to reduce battery
consumption.
1 Congurethesetting.
Choose [Eco Mode], and then choose
[On].
[ ] is now shown on the shooting
screen (=
149).
The screen darkens when the camera
is not used for approximately two
seconds; approximately ten seconds
after darkening, the screen turns off.
The camera turns off after approximately
three minutes of inactivity.
120
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
2 Shoot.
To activate the screen and prepare for
shooting when the screen is off but the
lens is still out, press the shutter button
halfway.
Power-Saving Adjustment
Adjust the timing of automatic camera and screen deactivation (Auto Power
Down and Display Off, respectively) as needed (=
20).
Choose [Power Saving], and then press
the <m> button.
After choosing an item, press the
<q><r> buttons to adjust it as needed.
• To conserve battery power, you should normally choose [On] for
[Auto Power Down] and [1 min.] or less for [Display Off].
• The [Display Off] setting is applied even if you set [Auto Power Down] to [Off].
• These power-saving functions are not available when you have set Eco mode
(=
119) to [On].
Screen Brightness
Adjust screen brightness as follows.
Choose [LCD Brightness], and then
press the <q><r> buttons to adjust the
brightness.
• For maximum brightness, press and hold the <l> button for at least one
second when the shooting screen is displayed or when in single-image display.
(This will override the [LCD Brightness] setting on the [3] tab.) To restore the
original brightness, press and hold the <l> button again for at least one
second or restart the camera.
Hiding the Start-Up Screen
If you prefer, you can deactivate display of the start-up screen normally
shown when you turn the camera on.
Choose [Start-up Image], and then
choose [Off].
121
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Formatting Memory Cards
Before using a new memory card or a card formatted in another device, you
should format the card with this camera.
Formatting erases all data on a memory card. Before formatting, copy
images on the memory card to a computer, or take other steps to back them
up.
1 Access the [Format] screen.
Choose [Format], and then press the
<m> button.
2 Choose [OK].
Press the <o><p> buttons to choose
[Cancel], choose [OK] (either press the
<q><r> buttons or turn the <5> dial),
and then press the <m> button.
3 Format the memory card.
To begin the formatting process, press
the <o><p> buttons or turn the <5>
dial to choose [OK], and then press the
<m> button.
When formatting is nished, [Memory
card formatting complete] is displayed.
Press the <m> button.
• Formatting or erasing data on a memory card only changes le
management information on the card and does not erase the data
completely. When transferring or disposing of memory cards, take
steps to protect personal information if necessary, as by physically
destroying cards.
• The total card capacity indicated on the formatting screen may be less than
the advertised capacity.
Low-Level Formatting
Perform low-level formatting in these cases: [Memory card error] is
displayed, the camera is not working correctly, card image reading/writing is
slower, continuous shooting is slower, or movie recording suddenly stops.
Low-level formatting erases all data on a memory card. Before low-level
formatting, copy images on the memory card to a computer, or take other
steps to back them up.
On the screen in step 1 of “Formatting
Memory Cards” (=
121), press the
<o><p> buttons or turn the <5> dial
to choose [Low Level Format], and then
press the <q><r> buttons to select this
option. A [
] icon is displayed.
Follow steps 2 – 3 in “Formatting Memory
Cards” (=
121) to continue with the
formatting process.
• Low-level formatting takes longer than “Formatting Memory Cards” (=
121),
because data is erased from all storage regions of the memory card.
• You can cancel low-level formatting in progress by choosing [Stop]. In this
case, all data will be erased, but the memory card can be used normally.
122
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
File Numbering
Your shots are automatically numbered in sequential order (0001 – 9999)
and saved in folders that store up to 2,000 images each. You can change
how the camera assigns le numbers.
Choose [File Numbering], and then
choose an option.
Continuous
Images are numbered consecutively (until the 9999th shot is taken/
saved) even if you switch memory cards.
Auto Reset
Image numbering is reset to 0001 if you switch memory cards, or
when a new folder is created.
• Regardless of the option selected in this setting, shots may be numbered
consecutively after the last number of existing images on newly inserted
memory cards. To start saving shots from 0001, use an empty (or formatted
(=
121)) memory card.
• Refer to “Software Instruction Manual” (=
131) for information on the card
folder structure and image formats.
Date-Based Image Storage
Instead of saving images in folders created each month, you can have the
camera create folders each day you shoot to store shots taken that day.
Choose [Create Folder], and then choose
[Daily].
Images will now be saved in folders
created on the shooting date.
Metric / Non-Metric Display
Change the unit of measurement shown in GPS elevation information
(=
114), the zoom bar (=
27), the MF indicator (=
60), and
elsewhere from m/cm to ft/in as needed.
Choose [Units], and then choose [ft/in].
123
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Checking Certication Logos
Some logos for certication requirements met by the camera can be viewed
on the screen. Other certication logos are printed in this guide, on the
camera packaging, or on the camera body.
Choose [Certication Logo Display], and
then press the <m> button.
Display Language
Change the display language as needed.
Choose [Language ], and then press
the <m> button.
Press the <o><p><q><r> buttons or
turn the <5> dial to choose a language,
and then press the <m> button.
• You can also access the [Language] screen in Playback mode by pressing and
holding the <m> button and immediately pressing the <n> button.
Adjusting Other Settings
The following settings can also be adjusted on the [3] tab.
• [Video System] (=
129)
• [Ctrl via HDMI] (=
128)
• [Wi-Fi Settings] (=
93)
Restoring Defaults
If you accidentally change a setting, you can restore default camera
settings.
1 Access the [Reset All] screen.
Choose [Reset All], and then press the
<m> button.
2 Restore default settings.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
Default settings are now restored.
• The following functions are not restored to default settings.
- [3] tab settings [Date/Time] (=
118), [Language ] (=
123), [Time
Zone] (=
119), and [Video System] (=
129)
- Custom white balance data you have recorded (=
57)
- Shooting mode chosen in [K] (=
45) or [ ] (=
46) mode
- Wi-Fi settings (=
93)
124
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Accessories
Enjoy the camera in more ways with optional Canon accessories and other compatible
accessories sold separately
9
System Map .................................................... 125
Optional Accessories.....................................126
Power Supplies ...................................................126
Flash Unit ............................................................ 126
Other Accessories ............................................... 126
Printers ................................................................127
Using Optional Accessories.......................... 127
Playback on a TV ................................................ 127
Powering the Camera with Household Power .....130
Using the Software .........................................131
Software .............................................................. 131
Computer Connections via a Cable ....................131
Saving Images to a Computer .............................132
Printing Images .............................................. 133
Easy Print ............................................................133
Conguring Print Settings ...................................134
Printing Movie Scenes ........................................137
Adding Images to the Print List (DPOF) ..............137
Adding Images to a Photobook ........................... 140
125
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
System Map
Neck Strap Battery Pack
NB-6LH*
1
Battery Charger
CB-2LY/
CB-2LYE*
1
Lens Cap
(with cord)
USB Cable (camera end: Mini-B)*
2
Memory Card Card Reader
Windows/
Macintosh
Computer
TV/Video
System
AC Adapter Kit
ACK-DC40
Included Accessories
Power
Cables
HDMI Cable HTC-100
Stereo AV Cable AVC-DC400ST
Flash Unit
Canon-Brand PictBridge-
Compatible Printers
High-Power Flash
HF-DC2
*1 Also available for purchase separately.
*2 A genuine Canon accessory is also available (Interface Cable IFC-400PCU).
Use of genuine Canon accessories is recommended.
This product is designed to achieve excellent performance when used with genuine
Canon accessories.
Canon shall not be liable for any damage to this product and/or accidents such as re,
etc., caused by the malfunction of non-genuine Canon accessories (e.g., a leakage
and/or explosion of a battery pack). Please note that this warranty does not apply to
repairs arising out of the malfunction of non-genuine Canon accessories, although you
may request such repairs on a chargeable basis.
Note that availability varies by area, and some accessories may no longer be
available.
126
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Optional Accessories
The following camera accessories are sold separately. Note that availability
varies by area, and some accessories may no longer be available.
Power Supplies
Battery Pack NB-6LH
Rechargeable lithium-ion battery
Battery Charger CB-2LY/CB-2LYE
Charger for Battery Pack NB-6LH
• The battery pack includes a convenient cover which you can attach to know
the charging status at a glance. Attach the cover so that ▲ is visible on a
charged battery pack, and attach it so that ▲ is not visible on an uncharged
battery pack.
• Battery Pack NB-6L is also supported.
AC Adapter Kit ACK-DC40
For powering the camera using
household power. Recommended when
using the camera over extended periods,
or when connecting the camera to a
printer or computer. Cannot be used to
charge the battery pack in the camera.
• The battery charger and AC adapter kit can be used in areas with
100 – 240 V AC power (50/60 Hz).
• For power outlets in a different format, use a commercially available
adapter for the plug. Never use an electrical transformer designed
for traveling, which may damage the battery pack.
Flash Unit
High-Power Flash HF-DC2
External ash for illuminating subjects
that are out of range of the built-in ash.
Other Accessories
Interface Cable IFC-400PCU
For connecting the camera to a computer
or printer.
Stereo AV Cable AVC-DC400ST
Connect the camera to a TV to enjoy
playback on the larger TV screen.
HDMI Cable HTC-100
For connecting the camera to an HDMI
input of a high-denition TV.
127
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Printers
Canon-Brand PictBridge-
Compatible Printers
Printing images without a computer is
possible by connecting the camera to
a Canon-brand PictBridge-compatible
printer.
For details, visit your nearest Canon
retailer.
Still Images Movies
Using Optional Accessories
Still Images Movies
Playback on a TV
By connecting the camera to a TV, you can view your shots on the larger
screen of the TV.
For details on connection or how to switch inputs, refer to the TV manual.
• Some information may not be displayed on the TV (=
150).
Still Images Movies
PlaybackonaHigh-DenitionTV
Connecting the camera to an HDTV with the HDMI Cable HTC-100 (sold
separately) enables you to view your shots on the larger screen of the TV.
Movies shot at a resolution of [ ] or [ ] can be viewed in high denition.
1 Make sure the camera and TV
are off.
2 Connect the camera to the TV.
On the TV, insert the cable plug fully into
the HDMI input as shown.
128
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
On the camera, open the terminal cover
and insert the cable plug fully into the
camera terminal.
3 Turn the TV on and switch to
video input.
Switch the TV input to the video input you
connected the cable to in step 2.
4 Turn the camera on.
Press the <1> button to turn the camera
on.
Images from the camera are now
displayed on the TV. (Nothing is
displayed on the camera screen.)
When nished, turn off the camera and
TV before disconnecting the cable.
• Camera operating sounds are not played while the camera is connected to an
HDTV.
Still Images Movies
Controlling the Camera with a TV Remote
Connecting the camera to an HDMI CEC-compatible TV enables playback
(including slideshow playback) using the TV remote control.
Depending on the TV, you may need to adjust some TV settings. For
details, refer to the TV manual.
1 Congurethesetting.
Press the <n> button, choose
[Ctrl via HDMI] on the [3] tab, and then
choose [Enable] (=
23).
2 Connect the camera to the TV.
Follow steps 1 – 2 in “Playback on a
High-Denition TV” (=
127) to connect
the camera to the TV.
3 Display images.
Turn on the TV. On the camera, press the
<1> button.
Images from the camera are now
displayed on the TV. (Nothing is
displayed on the camera screen.)
129
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Control the camera with the TV
remote.
Press the <q><r> buttons on the remote
to browse images.
To display the camera control panel,
press the OK/Select button. Select
control panel options by pressing the
<q><r> buttons to choose an option,
and then pressing the OK/Select button
again.
Camera Control Panel Options Shown on the TV
Return Closes the menu.
Group Playback
Displays sets of images shot in [
] mode (=
50).
(Only displayed when a grouped image is selected.)
Play Movie
Starts movie playback. (Only displayed when a movie
is selected.)
.
Slideshow
Starts slideshow playback. To switch images during
playback, press the <q><r> buttons on the remote
control.
Index Playback Displays multiple images in an index.
l
Change Display
Switches display modes (=
22).
• Pressing buttons, such as the <n> button, on the camera will switch
control to the camera itself, which will prevent remote control until you return to
single-image display.
• Moving the zoom lever on the camera will switch control to the camera itself,
which will prevent remote control until you return to single-image display.
• The camera may not always respond correctly even if the remote is for an
HDMI CEC-compatible TV.
Still Images Movies
PlaybackonaStandard-DenitionTV
Connecting the camera to a TV with the Stereo AV Cable AVC-DC400ST
(sold separately) enables you to view your shots on the larger screen of the
TV as you control the camera.
1 Make sure the camera and TV
are off.
2 Connect the camera to the TV.
On the TV, insert the cable plugs fully into
the video inputs as shown.
On the camera, open the terminal cover
and insert the cable plug fully into the
camera terminal.
3 Display images.
Follow steps 3 – 4 in “Playback on a
High-Denition TV” (=
128) to display
images.
Red
Red
White
Yellow
Yellow
White
130
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Correct display is not possible unless the camera video output
format (NTSC or PAL) matches the TV format. To change the
video output format, press the <n> button and choose [Video
System] on the [3] tab.
• When the camera and TV are connected, you can also shoot while previewing
shots on the larger screen of the TV. To shoot, follow the same steps as when
using the camera screen. However, AF-Point Zoom (=
39) and MF-Point
Zoom (=
60) are not available.
Still Images Movies
Powering the Camera with Household Power
Powering the camera with AC Adapter Kit ACK-DC40 (sold separately)
eliminates the need to monitor the remaining battery level.
1 Make sure the camera is off.
2 Insert the coupler.
Follow step 2 in “Inserting the Battery
Pack and Memory Card” (=
12) to
open the cover.
Insert the coupler facing the direction
shown, just as you would a battery pack
(following step 3 in “Inserting the Battery
Pack and Memory Card” (=
12)).
Follow step 5 in “Inserting the Battery
Pack and Memory Card” (=
13) to
close the cover.
Terminals
3 Connect the adapter to the
coupler.
Open the cover and insert the adapter
plug fully into the coupler.
4 Connect the power cord.
Insert one end of the power cord into the
compact power adapter, and then plug
the other end into a power outlet.
Turn the camera on and use it as desired.
When nished, turn the camera off and
unplug the power cord from the outlet.
• Do not disconnect the adapter or unplug the power cord while
the camera is still on. This may erase your shots or damage the
camera.
• Do not attach the adapter or adapter cord to other objects. Doing so
could result in malfunction or damage to the product.
131
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Using the Software
The software available for download from the Canon website is introduced
below, with instructions for installation and saving images to a computer.
Software
After downloading the software from the Canon website and installing it, you
can do the following things on your computer.
CameraWindow
Import images and change camera settings
ImageBrowser EX
Manage images: view, search, and organize
Print and edit images
• Internet access is required, and any ISP account charges and
access fees must be paid separately.
Software Instruction Manual
Refer to the instruction manual when using the software. The manual can
be accessed from the help system of software (some software excluded).
Computer Connections via a Cable
Checking Your Computer Environment
The software can be used on the following computers. For detailed system
requirements and compatibility information, including support in new
operating systems, visit the Canon website.
Operating
System*
Windows Macintosh
Windows 8
Windows 7 SP1
Windows Vista SP2
Windows XP SP3
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8
* When sending images to a computer via Wi-Fi, check the system requirements in
“Checking Your Computer Environment” (=
100).
• Check the Canon website for the latest system requirements, including
supported OS versions.
Installing the Software
For software installation instructions, see “Installing the Software” (=
100).
132
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Saving Images to a Computer
Windows 7 and Mac OS X 10.6 are used here for the sake of illustration.
For other functions, refer to the help system of the relevant software (some
software excluded).
1 Connect the camera to the
computer.
With the camera turned off, open the
cover (
). With the smaller plug of the
USB cable in the orientation shown,
insert the plug fully into the camera
terminal (
).
Insert the larger plug of the USB cable
in the computer’s USB port. For details
about USB connections on the computer,
refer to the computer user manual.
2 Turn the camera on to access
CameraWindow.
Press the <1> button to turn the camera
on.
On a Macintosh computer,
CameraWindow is displayed when a
connection is established between the
camera and computer.
For Windows, follow the steps introduced
below.
In the screen that displays, click the [ ]
link to modify the program.
Choose [Downloads Images From Canon
Camera] and then click [OK].
Double-click [ ].
3 Save the images to the
computer.
Click [Import Images from Camera], and
then click [Import Untransferred Images].
Images are now saved to the Pictures
folder on the computer, in separate
folders named by date.
After images are saved, close
CameraWindow, press the <1> button
to turn the camera off, and unplug the
cable.
For instructions on viewing images on a
computer, refer to “Software Instruction
Manual” (=
131).
CameraWindow
133
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• In Windows 7, if the screen in step 2 is not displayed, click the [ ] icon in the
taskbar.
• To start CameraWindow in Windows Vista or XP, click [Downloads Images
From Canon Camera] on the screen displayed when you turn the camera on
in step 2. If CameraWindow is not displayed, click the [Start] menu and choose
[All Programs]
►
[Canon Utilities]
►
[CameraWindow]
►
[CameraWindow].
• On a Macintosh computer, if CameraWindow is not displayed after step 2, click
the [CameraWindow] icon in the Dock (the bar at the bottom of the desktop).
• Although you can save images to a computer simply by connecting your
camera to the computer without using the software, the following limitations
apply.
- It may take a few minutes after you connect the camera to the computer until
camera images are accessible.
- Images shot in vertical orientation may be saved in horizontal orientation.
- Image protection settings may be cleared from images saved to a computer.
- Some problems may occur when saving images or image information,
depending on the operating system version, the software in use, or image
le sizes.
- Some functions provided by the software may not be available, such as
movie editing.
Still Images Movies
Printing Images
Your shots can easily be printed by connecting the camera to a printer. On
the camera, you can specify images to set up batch printing, prepare orders
for photo development services, and prepare orders or print images for
photobooks.
A Canon SELPHY CP series compact photo printer is used here for the
sake of illustration. Screens displayed and available functions vary by
printer. Also refer to the printer manual for additional information.
Still Images
Easy Print
Easily print your shots by connecting the camera to a PictBridge-compatible
printer (sold separately) with the USB cable.
1 Make sure the camera and
printer are off.
2 Connect the camera to the
printer.
Open the cover. Holding the smaller
cable plug in the orientation shown, insert
the plug fully into the camera terminal.
Connect the larger cable plug to the
printer. For other connection details, refer
to the printer manual.
134
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Turn the printer on.
4 Turn the camera on.
Press the <1> button to turn the camera
on.
5 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image.
6 Access the printing screen.
Press the <m> button, choose [c], and
press the <m> button again.
7 Print the image.
Press the <o><p> buttons or turn the
<5> dial to choose [Print], and then
press the <m> button.
Printing now begins.
To print other images, repeat the above
procedures starting from step 5 after
printing is nished.
When you are nished printing, turn the
camera and printer off and disconnect
the cable.
• For Canon-brand PictBridge-compatible printers (sold separately), see
“Printers” (=
127).
Still Images
Conguring Print Settings
1 Access the printing screen.
Follow steps 1 – 6 in “Easy Print”
(=
133 – 134) to access the screen
at left.
2 Congurethesettings.
Press the <o><p> buttons or turn
the <5> dial to choose an item, and
then choose an option by pressing the
<q><r> buttons.
Default Matches current printer settings.
Date Prints images with the date added.
File No. Prints images with the le number added.
Both Prints images with both the date and le number added.
Off
–
Default Matches current printer settings.
Off
–
On
Uses information from the time of shooting to print under
optimal settings.
Red-Eye 1 Corrects red-eye.
No. of Copies Choose the number of copies to print.
Cropping
–
Specify a desired image area to print (=
135).
Paper
Settings
–
Specify the paper size, layout, and other details
(=
135).
135
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Cropping Images before Printing
By cropping images before printing, you can print a desired image area
instead of the entire image.
1 Choose [Cropping].
After following step 1 in “Conguring Print
Settings” (=
134) to access the printing
screen, choose [Cropping] and press the
<m> button.
A cropping frame is now displayed,
indicating the image area to print.
2 Adjust the cropping frame as
needed.
To resize the frame, move the zoom lever
or turn the <5> dial.
To move the frame, press the
<o><p><q><r> buttons.
To rotate the frame, press the <l>
button.
When nished, press the <m> button.
3 Print the image.
Follow step 7 in “Easy Print” (=
134)
to print.
• Cropping may not be possible at small image sizes, or at some
aspect ratios.
• Dates may not be printed correctly if you crop images shot with
[Date Stamp
] selected.
Still Images
Choosing Paper Size and Layout before Printing
1 Choose [Paper Settings].
After following step 1 in “Conguring Print
Settings” (=
134) to access the printing
screen, choose [Paper Settings] and
press the <m> button.
2 Choose a paper size.
Press the <o><p> buttons or turn the
<5> dial to choose an option, and then
press the <m> button.
3 Choose a type of paper.
Press the <o><p> buttons or turn the
<5> dial to choose an option, and then
press the <m> button.
136
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Choose a layout.
Press the <o><p> buttons or turn the
<5> dial to choose an option.
When choosing [N-up], press the
<q><r> buttons to specify the number of
images per sheet.
Press the <m> button.
5 Print the image.
Available Layout Options
Default Matches current printer settings.
Bordered Prints with blank space around the image.
Borderless Borderless, edge-to-edge printing.
N-up Choose how many images to print per sheet.
ID Photo
Prints images for identication purposes.
Only available for images with a resolution of L and an aspect ratio of
4:3.
Fixed Size
Choose the print size.
Choose from 3.5 x 5 in., postcard, or wide-format prints.
Still Images
Printing ID Photos
1 Choose [ID Photo].
Following steps 1 – 4 in “Choosing Paper
Size and Layout before Printing” (=
135
– 136), choose [ID Photo] and press the
<m> button.
2 Choose the long and short side
length.
Press the <o><p> buttons or turn the
<5> dial to choose an item. Choose the
length by pressing the <q><r> buttons,
and then press the <m> button.
3 Choose the printing area.
Follow step 2 in “Cropping Images before
Printing” (=
135) to choose the printing
area.
4 Print the image.
137
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Movies
Printing Movie Scenes
1 Access the printing screen.
Follow steps 1 – 6 in “Easy Print”
(=
133 – 134) to choose a movie. The
screen at left is displayed.
2 Choose a printing method.
Press the <o><p> buttons or turn
the <5> dial to choose [
], and then
press the <q><r> buttons to choose the
printing method.
3 Print the image.
Movie Printing Options
Single Prints the current scene as a still image.
Sequence
Prints a series of scenes, a certain interval apart, on a single sheet of
paper. You can also print the folder number, le number, and elapsed
time for the frame by setting [Caption] to [On].
• To cancel printing in progress, press the <m> button.
• [ID Photo] and [Sequence] cannot be chosen on Canon-brand PictBridge-
compatible printers from CP720/CP730 and earlier models.
Still Images
Adding Images to the Print List (DPOF)
Batch printing (=
139) and ordering prints from a photo development
service can be set up on the camera. Choose up to 998 images on a
memory card and congure relevant settings, such as the number of copies,
as follows. The printing information you prepare this way will conform to
DPOF (Digital Print Order Format) standards.
Still Images
ConguringPrintSettings
Specify the printing format, whether to add the date or le number, and
other settings as follows. These settings apply to all images in the print list.
Press the <n> button, and then
choose [Print Settings] on the [2] tab.
Choose and congure items as desired
(=
23).
Print Type
Standard One image is printed per sheet.
Index
Smaller versions of multiple images are printed
per sheet.
Both Both standard and index formats are printed.
Date
On Images are printed with the shooting date.
Off
–
File No.
On Images are printed with the le number.
Off
–
Clear DPOF
data
On
All image print list settings are cleared after
printing.
Off
–
138
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
• Not all of your DPOF settings may be applied in printing by the
printer or photo development service, in some cases.
• [ ] may be displayed on the camera to warn you that the memory
card has print settings that were congured on another camera.
Changing the print settings using this camera may overwrite all
previous settings.
• Setting [Date] to [On] may cause some printers to print the date
twice.
• Specifying [Index] will prevent you from choosing [On] for both [Date] and [File
No.] at the same time.
• The date is printed in a format matching setting details in [Date/Time] on the
[3] tab, accessible by pressing the <n> button (=
14).
• Index printing is not available on some Canon-brand PictBridge-compatible
printers (sold separately).
Still Images
Setting Up Printing for Individual Images
1 Choose [Select Images & Qty.].
Press the <n> button, choose
[Select Images & Qty.] on the [2] tab,
and then press the <m> button.
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
You can now specify the number of
copies.
If you specify index printing for the image,
it is labeled with a [
] icon. To cancel
index printing for the image, press the
<m> button again. [
] is no longer
displayed.
3 Specify the number of prints.
Press the <o><p> buttons or turn the
<5> dial to specify the number of prints
(up to 99).
To set up printing for other images and
specify the number of prints, repeat steps
2 – 3.
Printing quantity cannot be specied for
index prints. You can only choose which
images to print, by following step 2.
When nished, press the <n> button
to return to the menu screen.
139
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Setting Up Printing for a Range of Images
Following step 1 in “Setting Up Printing
for Individual Images” (=
138), choose
[Select Range] and press the <m>
button.
Follow steps 2 – 3 in “Selecting a Range”
(=
82) to specify images.
Press the <o><p> buttons to choose
[Order], and then press the <m> button.
Still Images
Setting Up Printing for All Images
Following step 1 in “Setting Up Printing
for Individual Images” (=
138), choose
[Select All Images] and press the <m>
button.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
Still Images
Clearing All Images from the Print List
Following step 1 in “Setting Up Printing
for Individual Images” (=
138), choose
[Clear All Selections] and press the <m>
button.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
Still Images
Printing Images Added to the Print List (DPOF)
When images have been added to the
print list (=
137 – 139), the screen
at left is displayed after you connect
the camera to a PictBridge-compatible
printer. Press the <o><p> buttons to
choose [Print now], and then simply press
the <m> button to print the images in the
print list.
Any DPOF print job that you temporarily
stop will be resumed from the next image.
140
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Adding Images to a Photobook
Photobooks can be set up on the camera by choosing up to 998 images
on a memory card and importing them into the software on your computer,
where they are stored in their own folder. This is convenient when ordering
printed photobooks online or printing photobooks with your own printer.
Choosing a Selection Method
Press the <n> button, choose
[Photobook Set-up] on the [1] tab, and
then choose how you will select images.
• [
] may be displayed on the camera to warn you that the memory
card has print settings that were congured on another camera.
Changing the print settings using this camera may overwrite all
previous settings.
• After importing images to your computer, also refer to “Software Instruction
Manual” (=
131) and the printer manual for further information.
Still Images
Adding Images Individually
1 Choose [Select].
Following the procedure in “Choosing
a Selection Method” (=
140), choose
[Select] and press the <m> button.
2 Choose an image.
Press the <q><r> buttons or turn the
<5> dial to choose an image, and then
press the <m> button.
[ ] is displayed.
To remove the image from the photobook,
press the <m> button again. [
] is no
longer displayed.
Repeat this process to specify other
images.
When nished, press the <n> button
to return to the menu screen.
141
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Still Images
Adding All Images to a Photobook
Following the procedure in “Choosing
a Selection Method” (=
140), choose
[Select All Images] and press the <m>
button.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
Still Images
Removing All Images from a Photobook
Following the procedure in “Choosing
a Selection Method” (=
140), choose
[Clear All Selections] and press the <m>
button.
Press the <q><r> buttons or turn the
<5> dial to choose [OK], and then press
the <m> button.
142
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Appendix
Helpful information when using the camera
10
Troubleshooting .............................................143
On-Screen Messages .....................................146
On-Screen Information .................................. 149
Shooting (Information Display) ............................149
Playback (Detailed Information Display) .............150
Functions and Menu Tables .......................... 151
Functions Available in Each Shooting Mode ....... 151
FUNC. Menu .......................................................153
4 Shooting Tab Menu........................................155
3 Set Up Tab Menu ...........................................158
1 Playback Tab Menu .......................................158
2 Print Tab Menu ...............................................158
Playback Mode FUNC. Menu ..............................158
Handling Precautions .................................... 159
Specications .................................................159
143
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Troubleshooting
If you think there is a problem with the camera, rst check the following.
If the items below do not solve your problem, contact a Canon Customer
Support Help Desk.
Power
Nothing happens when the power button is pressed.
• Conrm that the battery pack is charged (=
11).
• Conrm that the battery pack is inserted facing the correct way (=
12).
• Conrm that the memory card/battery cover is fully closed (=
13).
• Dirty battery terminals reduce battery performance. Try cleaning the terminals with a
cotton swab and reinserting the battery pack a few times.
The battery pack runs out of power quickly.
• Battery performance decreases at low temperatures. Try warming the battery pack a
little by putting it in your pocket, for example, ensuring that the terminals do not touch
any metal objects.
• If these measures do not help and the battery pack still runs out of power soon after
charging, it has reached the end of its life. Purchase a new battery pack.
The lens is not retracted.
• Do not open the memory card/battery cover while the camera is on. Close the cover,
turn the camera on, and then turn it off again (=
13).
The battery pack is swollen.
• Battery swelling is normal and does not pose any safety concerns. However, if
battery swelling prevents the battery pack from tting in the camera, contact a Canon
Customer Support Help Desk.
Display on a TV
Camera images look distorted or not displayed on a TV (=
130).
Shooting
Cannot shoot.
• In Playback mode (=
72), press the shutter button halfway (=
21).
Strange display on the screen under low light (=
22).
Strange display on the screen when shooting.
Note that the following display problems are not recorded in still images but are
recorded in movies.
• The screen may icker under uorescent or LED lighting.
No date stamp is added to images.
• Congure the [Date Stamp ] setting (=
14). Note that date stamps are not
added to images automatically, merely because you have congured the [Date/Time]
setting (=
35).
• Date stamps are not added in shooting modes (=
157) in which this setting cannot
be congured (=
35).
[h]ashesonthescreenwhentheshutterbuttonispressed,and
shooting is not possible (=
29).
[ ] is displayed when the shutter button is pressed halfway (=
29).
• Set [IS Mode] to [Continuous] (=
67).
• Raise the ash and set the ash mode to [h] (=
65).
• Increase the ISO speed (=
55).
• Mount the camera on a tripod or take other measures to keep it still. In this case, you
should set [IS Mode] to [Off] (=
67).
Shots are out of focus.
• Press the shutter button halfway to focus on subjects before pressing it all the way
down to shoot (=
21).
• Make sure subjects are within focusing range (=
161).
• Set [AF-assist Beam] to [On] (=
40).
• Conrm that unneeded functions such as macro are deactivated.
• Try shooting with focus lock or AF lock (=
61, 64).
144
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
No AF frames are displayed and the camera does not focus when the
shutter button is pressed halfway.
• To have AF frames displayed and the camera focus correctly, try composing the
shot with higher-contrast subject areas centered before you press the shutter button
halfway. Otherwise, try pressing the shutter button halfway repeatedly.
Subjects in shots look too dark.
• Raise the ash and set the ash mode to [h] (=
65).
• Adjust brightness by using exposure compensation (=
54).
• Adjust contrast by using i-Contrast (=
56, 90).
• Use AE lock or spot metering (=
54, 55).
Subjects look too bright, highlights are washed-out.
• Lower the ash and set the ash mode to [!] (=
27).
• Adjust brightness by using exposure compensation (=
54).
• Use AE lock or spot metering (=
54, 55).
• Reduce the lighting on subjects.
Shotslooktoodarkdespitetheashring(=
29).
• Shoot within ash range (=
161).
• Adjust brightness by using ash exposure compensation or changing the ash output
level (=
65, 66).
• Increase the ISO speed (=
55).
Subjectsinashshotslooktoobright,highlightsarewashed-out.
• Shoot within ash range (=
161).
• Lower the ash and set the ash mode to [!] (=
27).
• Adjust brightness by using ash exposure compensation or changing the ash output
level (=
65, 71).
Whitedotsorsimilarimageartifactsappearinashshots.
• This is caused by light from the ash reecting off dust or airborne particles.
Shots look grainy.
• Lower the ISO speed (=
55).
Subjects are affected by red-eye (=
37).
• Set [Red-Eye Lamp] to [On] (=
40) to activate the red-eye reduction lamp
(=
3) in ash shots. Note that while the red-eye reduction lamp is on (for about
one second), it is not possible to shoot, because the lamp is counteracting red-eye.
For best results, have subjects look at the red-eye reduction lamp. Also try increasing
the lighting in indoor scenes and shooting at closer range.
• Edit images using red-eye correction (=
90).
Recording to the memory card takes too long, or continuous shooting
is slower.
• Use the camera to perform low-level formatting of the memory card (=
121).
Shooting settings or FUNC. menu settings are not available.
• Available setting items vary by shooting mode. Refer to “Functions Available in Each
Shooting Mode”, “FUNC. Menu”, and “Shooting Tab Menu” (=
151 – 157).
Shooting Movies
The elapsed time shown is incorrect, or recording is interrupted.
• Use the camera to format the memory card, or switch to a card that supports high-
speed recording. Note that even if the elapsed time display is incorrect, the length
of movies on the memory card corresponds to the actual recording time (=
121,
161).
[ ] is displayed and shooting stops automatically.
The camera’s internal memory buffer lled up as the camera could not record to the
memory card quickly enough. Try one of the following measures.
• Use the camera to perform low-level formatting of the memory card (=
121).
• Lower the image quality (=
38).
• Switch to a memory card that supports high-speed recording (=
161).
Zooming is not possible.
• Zooming is not possible when shooting movies in [ ] (=
47) and [ ] (=
51)
modes.
Subjects look distorted.
• Subjects that pass in front of the camera quickly may look distorted. This is not a
malfunction.
145
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Playback
Playback is not possible.
• Image or movie playback may not be possible if a computer is used to rename les or
alter the folder structure. Refer to “Software Instruction Manual” (=
131) for details
on folder structure and le names.
Playback stops, or audio skips.
• Switch to a memory card that you have performed low-level formatting on with the
camera (=
121).
• There may be brief interruptions when playing movies copied to memory cards that
have slow read speeds.
• When movies are played on a computer, frames may be dropped and audio may skip
if computer performance is inadequate.
Sound is not played during movies.
• Adjust the volume (=
73) if you have activated [Mute] (=
118) or the sound in
the movie is faint.
• No sound is played for movies shot in [
] (=
47) or [ ] (=
51) mode
because audio is not recorded in these modes.
Memory Card
The memory card is not recognized.
• Restart the camera, with the memory card in it (=
20).
Computer
Cannot transfer images to a computer.
When attempting to transfer images to the computer via a cable, try reducing the
transfer speed as follows.
• Press the <1> button to enter Playback mode. Hold the <n> button down as
you press the <o> and <
m
> buttons at the same time. On the next screen, press
the <q><r> buttons to choose [B], and then press the <m> button.
Wi-Fi
Cannot access the Wi-Fi menu by pressing the <o> button.
• The Wi-Fi menu is not available in Shooting mode. Switch to Playback mode and try
again.
• In Playback mode, the Wi-Fi menu cannot be accessed during detailed information
display, magnied display, or index display. Switch to single-image display and a
viewing mode other than detailed information display. Similarly, the Wi-Fi menu
cannot be accessed during group playback or ltered image display according to
specied conditions. Cancel group or ltered image playback.
• The Wi-Fi menu cannot be accessed while the camera is connected to a printer,
computer, or TV via a cable. Disconnect the cable.
Cannot add a device/destination.
• A total of 20 items of connection information can be added to the camera. Erase
unneeded connection information from the camera rst, and then add new devices/
destinations (=
114).
• Use a computer or smartphone to register Web services (=
96).
• To add a smartphone, rst install the dedicated application CameraWindow on your
smartphone (=
99).
• To add a computer, rst install the CameraWindow application on your computer. Also
check your computer and Wi-Fi environment and settings (=
100, 102).
• Do not use the camera near sources of Wi-Fi signal interference, such as microwave
ovens, Bluetooth devices, or other equipment operating on the 2.4 GHz band.
• Bring the camera closer to the other device you are trying to connect to (such as the
access point), and make sure there are no objects between the devices.
Cannot connect to the access point.
• Conrm that the access point channel is set to a channel supported by the camera
(=
160). Note that instead of auto channel assignment, it is advisable to specify a
supported channel manually.
Cannot send images.
• The destination device has insufcient storage space. Increase the storage space on
the destination device and resend the images.
• The write-protect tab of the memory card in the destination camera is set to the
locked position. Slide the write-protect tab to the unlocked position.
146
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Cannot resize images for sending.
• Images cannot be resized to be bigger than the resolution setting of their original size.
• Movies cannot be resized.
Images take a long time to send./The wireless connection is disrupted.
• Multiple images may take a long time to send. Try resizing the image to [ ] or [ ]
to reduce sending time (=
110).
• Movies may take a long time to send.
• Do not use the camera near sources of Wi-Fi signal interference, such as microwave
ovens, Bluetooth devices, or other equipment operating on the 2.4 GHz band. Note
that images may take a long time to send even when [
] is displayed.
• Bring the camera closer to the other device you are trying to connect to (such as the
access point), and make sure there are no objects between the devices.
• When sending images to a computer from a memory card with a large amount
of images (approximately 1,000), the connection may be disrupted. Import any
necessary images to a computer, and then reduce the number of images on the
memory card by erasing unnecessary images.
Want to erase Wi-Fi connection information before disposing of the
camera or giving it to someone else.
• Reset the Wi-Fi settings (=
116).
On-Screen Messages
If an error message is displayed, respond as follows.
No memory card
• The memory card may be inserted facing the wrong way. Reinsert the memory card
facing the correct way (=
13).
Memory card locked
• The write-protect tab of the memory card is set to the locked position. Switch the
write-protect tab to the unlocked position (=
12).
Cannot record!
• Shooting was attempted without a memory card in the camera. To shoot, insert a
memory card facing the correct way (=
13).
Memory card error (=
121)
• If the same error message is displayed even after you have formatted a supported
memory card (=
2) and have inserted it facing the correct way (=
13), contact
a Canon Customer Support Help Desk.
Insufcientspaceoncard
• There is not enough free space on the memory card to shoot (=
27, 42, 53,
68) or edit images (=
88 – 90). Either erase unneeded images (=
83) or
insert a memory card with enough free space (=
12).
Charge the battery (=
11)
No Image.
• The memory card does not contain any images that can be displayed.
Protected! (=
80)
UnidentiedImage/IncompatibleJPEG/Imagetoolarge./Cannotplay
back MOV/Cannot play back MP4
• Unsupported or corrupt images cannot be displayed.
• It may not be possible to display images that were edited or renamed on a computer,
or images shot with another camera.
147
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Cannotmagnify!/CannotplaybackthiscontentinSmartShufe/
Cannot rotate/Cannot modify image/Cannot modify/Cannot assign to
category/Unselectable image.
• The following functions may be unavailable for images that were renamed or already
edited on a computer, or images shot with another camera. Note that starred (*)
functions are not available for movies.
Magnify* (
=
78), Smart Shufe* (
=
79), Rotate (
=
85), Favorites (
=
87),
Edit* (
=
88 – 91), Print List* (
=
137), and Photobook Set-up* (
=
140).
• Grouped images cannot be processed (
=
50).
Invalid selection range
• When specifying a range for image selection (=
82, 85, 139), you attempted to
choose an initial image that was after the nal image, or vice-versa.
Exceededselectionlimit
• More than 998 images were selected for Print List (=
137) or Photobook Set-up
(=
140). Choose 998 images or less.
• Print List (=
137) or Photobook Set-up (=
140) settings could not be saved
correctly. Reduce the number of selected images and try again.
• You attempted to choose more than 500 images in Protect (=
80), Erase
(=
83), Favorites (=
87), Print List (=
137), or Photobook Set-up (=
140).
Communication error
• An excessive amount of images (approx. 1,000) on the memory card prevented
printing or image transfer to a computer. To transfer the images, use a commercially
available USB card reader. To print, insert the memory card directly into the printer
card slot.
Naming error!
• The folder could not be created or images could not be recorded, because the highest
supported folder number (999) for storing images on the card has been reached and
the highest supported image number (9999) for images in folders has been reached.
On the [3] tab, change [File Numbering] to [Auto Reset] (=
122), or format the
memory card (=
121).
LensError
• This error may occur if the lens is held while it is moving, or when the camera is used
in dusty or sandy locations.
• Frequent display of this error message may indicate camera damage. In this case,
contact a Canon Customer Support Help Desk.
A camera error was detected (error number)
• If this error message is displayed immediately after a shot, the image may not have
been saved. Switch to Playback mode to check for the image.
• Frequent display of this error message may indicate camera damage. In this case,
write down the error number (Exx) and contact a Canon Customer Support Help
Desk.
FileError
• Correct printing (=
133) may not be possible for photos from other cameras or
images that have been altered using computer software, even if the camera is
connected to the printer.
Print error
• Check the paper size setting (=
135). If this error message is displayed when the
setting is correct, restart the printer and complete the setting on the camera again.
Ink absorber full
• Contact a Canon Customer Support Help Desk to request assistance with ink
absorber replacement.
Wi-Fi
Connection failed
• No access points were recognized. Check the access point settings (=
102).
• A device could not be found. Turn the camera off and on again, and retry the
connection.
• Check the device you want to connect to and make sure it is ready for connection.
Cannot determine access point
• The WPS buttons on numerous access points were pressed simultaneously. Try
reconnecting again.
148
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
No access points found
• Check to make sure that the access point is turned on.
• When connecting to an access point manually, make sure that you entered the
correct SSID.
Incorrect password/Incorrect Wi-Fi security settings
• Check the access point security settings (=
102).
IPaddressconict
• Reset the IP address so that it does not conict with another.
Disconnected/Receiving failed/Sending failed
• You may be in an environment where Wi-Fi signals are obstructed.
• Avoid using the camera’s Wi-Fi function around microwave ovens, Bluetooth devices,
and other devices that operate on the 2.4 GHz band.
• Bring the camera closer to the other device you are trying to connect to (such as the
access point), and make sure there are no objects between the devices.
• Check the connected device to make sure it is not experiencing errors.
Sending failed
Memory card error
• If the same error message is displayed even when you have inserted a formatted
memory card facing the correct way, contact a Canon Customer Support Help Desk.
Receiving failed
Insufcientspaceoncard
• There is not enough free space on the memory card in the target camera to receive
images. Erase images to create space on the memory card, or insert a memory card
with sufcient space.
Receiving failed
Memory card locked
• The write-protect tab of the memory card in the camera to receive the images is set to
the locked position. Slide the write-protect tab to the unlocked position.
Receiving failed
Naming error!
• When the highest folder number (999), and the highest image number (9999) have
been reached on the receiving camera, images cannot be received.
Insufcientspaceonserver
• Delete unnecessary images uploaded to CANON iMAGE GATEWAY to create space.
• Save the images sent via Image Sync (=
112) to your computer.
Check network settings
• Check to make sure your computer can connect to the Internet with the current
network settings.
149
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
On-Screen Information
Shooting (Information Display)
Battery level
(=
149)
White balance
(=
56)
My Colors (=
57)
Drive mode
(=
58)
Eco mode (=
119)
Self-timer (=
34)
Camera shake
warning (=
29)
Metering method
(=
55)
Still image
compression
(=
66),
Resolution (=
37)
Still images:
Recordable shots
(=
160)
Movie resolution
(=
38)
Movies: Remaining
time (=
161)
Digital zoom
magnication
(=
31),
Digital tele-converter
(=
61)
AF frame (=
61),
Spot AE point frame
(=
55)
Focusing range
(=
59, 60),
AF lock (=
64),
IS mode icon
(=
30)
Shooting mode
(=
151),
Scene icon
(=
30)
Flash mode
(=
65)
Red-eye correction
(=
37)
Flash exposure
compensation /
Flash output level
(=
65, 71)
Date stamp
(=
35)
ISO speed (=
55)
i-Contrast (=
56)
Exposure
compensation bar
(=
54)
AE lock (=
54),
FE lock (=
66)
Shutter speed
(=
69, 70)
Aperture value
(=
69, 70)
Exposure
compensation level
(=
54)
Grid lines (=
38)
Zoom bar (=
27)
Blink detection
(=
39)
Auto (=
32)
MF indicator
(=
60)
Exposure shift bar
Wind lter
Time zone (=
119)
Image stabilization
(=
67)
Battery Level
An on-screen icon or message indicates the battery charge level.
Display Details
Sufcient charge
Slightly depleted, but sufcient
(Blinking red)
Nearly depleted—charge the battery pack soon
[Charge the battery] Depleted—charge the battery pack immediately
150
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Playback (Detailed Information Display)
Movies
(=
27, 73),
High-speed burst
(=
50)
Shooting mode
(=
151)
ISO speed
(=
55),
Playback speed
(=
47, 51)
Exposure
compensation level
(=
54),
Exposure shift level
(=
51)
White balance
(=
56)
Histogram (=
74)
Group playback
(=
77)
Compression (image
quality) (=
66) /
Resolution (=
37),
MOV (movies)
Image Sync
(=
112)
Battery level
(=
149)
Metering method
(=
55)
Folder number - File
number (=
122)
Current image no. /
Total no. of images
Shutter speed (still
images) (=
69),
Image quality /
Frame rate (movies)
(=
38)
Aperture value
(=
69, 70)
Flash exposure
compensation
(=
65),
Flash (=
65)
Focusing range
(=
59, 60)
File size
Still images:
Resolution (=
160)
Movies: Playback
time (=
161)
Image editing
(=
88 – 90)
Favorites (=
87)
Protection (=
80)
My Colors
(=
57, 89)
Red-eye correction
(=
37, 90)
Shooting date/time
(=
14)
i-Contrast
(=
56, 90)
• Some information may not be displayed when viewing images on a TV
(=
127).
Summary of Movie Control Panel in “Viewing” (=
73)
Exit
Play
Slow Motion (To adjust the playback speed, press the <q><r> buttons or turn
the <5> dial. No sound is played.)
Skip Backward* or Previous Clip (=
92) (To continue skipping backward,
keep holding down the <m> button.)
Previous Frame (For fast-rewind, keep holding down the <m> button.)
Next Frame (For fast-forward, keep holding down the <m> button.)
Skip Forward* or Next Clip (=
92) (To continue skipping forward, keep
holding down the <m> button.)
* Edit (=
91)
Erase Clip (displayed when a digest movie is selected (=
92))
c
Shown when the camera is connected to a PictBridge-compatible printer
(=
133).
* Displays the frame approx. 4 sec. before or after the current frame.
• During movie playback, you can skip back or forward (or to the previous or
next clip) by pressing the <q><r> buttons.
151
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Functions and Menu Tables
Functions Available in Each Shooting Mode
Shooting Mode
Function
D B M G
K E
I
P t E
Exposure Compensation (=
54)
–
O O O
*1
–
O O O O O O O O O O O O
–
O
– –
ISO Speed (=
55)
–
O O O O O O O O O O O O O O O O O O O O O
O O O O
– –
O
– – – – – – – – – – – – – – –
Self-Timer (=
34)
O O O O O O O O O O O O O O O O O O O O O O
] [ $
O O O O O O O O
– –
O O O O O O O O O
–
O O
Self-Timer Settings (=
35)
Delay*
2
O O O O O O O O
– –
O O O O O O O O O
–
O O
Shots*
3
O O O O O O
–
O
– –
O O O O O O O O O
– – –
Flash (=
65)
– – –
O O O O O O
–
O O
–
O O O O O O
– – –
h
O O O O O
–
O O O
– –
O
–
O O O O O O
– – –
Z
–
O
–
O O
*4
O
– – – – – – – – – – – – – – –
!
– – – – – – – – –
O
– –
O
– – – – – –
O O O
Av/Tv Settings (=
69)
Aperture Value
O O
– – – – – – – – – – – – – – – – – – – –
Shutter Speed
O
–
O
– – – – – – – – – – – – – – – – – – –
*1 Settings [Dark - Light] (=
44).
*2 Cannot be set to 0 seconds in modes without selection of the number of shots.
*3 One shot (cannot be modied) in modes without selection of the number of shots.
*4 Not available, but switches to [Z] in some cases.
O
Available or set automatically.
–
Not available.
152
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shooting Mode
Function
D B M G
K E
I
P t E
Program Shift (=
55)
–
O O O
– –
O
– – – – – – – – – – – – – – –
AE Lock/FE Lock*
1
(=
54, 66)
–
O O O
– –
O
– – – – – – – – – – – – – – –
AE Lock (Movie)/Exposure Shift (=
51)
– – – – – – – – – – – – – – – – – – – –
O
–
Focusing Range (=
59, 60, 64)
O O O O O O O O O O O O O O O O O O O O O O
e f
O O O O O
–
O O
–
O O O
–
O O O O O O O O O
Tracking AF (=
62)
O O O O O
– –
O
–
O O O
– – – –
O O O O
– –
Screen Display (=
22)
Information Display/No Information Display
O O O O O O O O
–
O O O O
– – – –
O O O O O
*1 FE lock not available in [!] ash mode.
O
Available or set automatically.
–
Not available.
153
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
FUNC. Menu
Shooting Mode
Function
D B M G
K E
I
P t E
White Balance (=
56)
O O O O O O O O O O O O O O O O O O O O O O
O O O O
– –
O
–
O O O
– – – – – – – –
O O
–
My Colors (=
57)
O O O O O O O O O O O O O O O O O O O O O O
*
1
*
1
*
2
O O O O
– –
O
–
O
– – – – – – – – – –
O O
–
Drive Mode (=
58)
O O O O O O O O O
–
O O O O O O O O O O O O
O O O O
– – –
O
–
O O O O O O O O O O O
– –
*
3
O O O O
– – – – – –
O O O O O O O O O O
– –
Flash Exposure Compensation (=
65)
–
O O O
– –
O
– – – – – – – – – – – – – – –
Flash Output Level (=
71)
O O O
– – – – – – – – – – – – – – – – – – –
Metering Method (=
55)
O O O O O O O O O O O O O O O O O O O O O O
O O O O
– –
O
– – – – – – – – – – – – – – –
O O O O
– –
O
– – – – – – – – – – – – – – –
Still Image Aspect Ratio (=
36)
O O O O
–
O
–
O O
– –
O O
–
*4
–
O O O O
– –
*1 White balance is not available.
*2 Set in a range of 1 – 5: contrast, sharpness, color saturation, red, green, blue, and skin tone.
*3 [
] is set with [f], AF lock, or [t].
*4 Only [
] and [ ] are available.
O
Available or set automatically.
–
Not available.
154
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shooting Mode
Function
D B M G
K E
I
P t E
Resolution (=
37)
O O O O O O O O O
– –
O O O O O O O O O O O
O O O O
–
O O O O
– –
O O
– – – – – –
O O O
– – – – – – – – –
O O
– – – – – – – – – – –
O O O O
–
O O O O
– –
O O
– – – – – –
O O O
Compression (=
66)
O O O O
– – – – – – – – – – – – – – – – – –
O O O O O O O O O O O O O O O O O O O O O O
Movie Quality (=
38)
O O O O O O O O O O O O O O
–
O O O O O O
–
O O O O
–
O O O O O O O O O
*1
O O O O O O
–
O O O O
–
O O O O O O O O O
*1
O O O O O O
–
– – – – – – – – – – – – – – – – – – – – –
O
*1 Synchronizes with the aspect ratio setting and is automatically set (=
47).
O
Available or set automatically.
–
Not available.
155
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
4 Shooting Tab Menu
Shooting Mode
Function
D B M G
K E
I
P t E
AF Frame (=
61)
Face AiAF
O O O O O O O O O O O O
– – –
O O O O O O O
Tracking AF
O O O O O
– –
O
–
O O O
– – – –
O O O O
– –
Center
O O O O O
–
O O
–
O O O O O
–
O O O O O O O
AF Frame Size*
1
(=
61)
Normal
O O O O O
–
O O
–
O O O
–
O
–
O O O O O O O
Small
O O O O O
–
O O
–
O O O
– – –
O O O O O O O
Digital Zoom (=
31)
Standard
O O O O O O
–
O O
– –
O O
– – – – – –
O O
–
Off
O O O O O O O O O O O O O O O O O O O O O O
1.5x/2.0x
O O O O O
– – – – – – – – – – – – – – – – –
AF-Point Zoom (=
39)
On
O O O O O O
–
O O O O O
– – – –
O O O O
– –
Off
O O O O O O O O O O O O O O O O O O O O O O
Servo AF (=
63)
On
O O O O O
– –
O
– –
O O
– – – –
O O O O
– –
Off*
2
O O O O O O O O O O O O O O O O O O O O O O
Continuous AF (=
64)
On
O O O O O O O O O O
–
O
–
O O O O O O O O O
Off
O O O O O
– –
O
– –
O O O O O O O O O O
– –
AF-assist Beam (=
40)
On
O O O O O O O O O O O O
–
O O O O O O
–
O O
Off
O O O O O O O O O O O O O O O O O O O O O O
MF-Point Zoom (=
39)
On
O O O O O
– –
O
–
O O O
– – – –
O O O O
– –
Off
O O O O O O O O O O O O O O O O O O O O O O
*1 Available when the AF frame is set to [Center].
*2 [On] when subject movement is detected in [
] mode.
O
Available or set automatically.
–
Not available.
156
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shooting Mode
Function
D B M G
K E
I
P t E
Safety MF (=
60)
On
O O O O O
–
O O
–
O O O
–
O O O O O O O O O
Off
O O O O O O O O O O O O O O O O O O O O O O
Flash Settings (=
37, 40, 65, 66, 71)
Flash Mode
Auto
–
O O O O O O O O
–
O O
–
O O O O O O
– – –
Manual
O O O
– – – – – – – – – – – – – – – – – – –
Red-Eye Corr.
On
O O O O
–
O O O O
–
O O
– – – – – – – – – –
Off
O O O O O O O O O
–
O O
–
O O O O O O
– – –
Red-Eye Lamp On/Off
O O O O O O O O O
–
O O
–
O O O O O O
– – –
Flash Exp. Comp
–
O O O
– –
O
– – – – – – – – – – – – – – –
Flash Output
O O O
– – – – – – – – – – – – – – – – – – –
Safety FE
On
–
O O O O O O O O
–
O O
–
O O O O O O
– – –
Off
O O O O O
–
O
– – – – – – – – – – – – – – –
i-Contrast (=
56)
Auto
O O O O
–
O O
– –
O O
– – – – – – – – – – –
Off
O O O O O
–
O O O
– –
O O O O O O O O O O O
Safety Shift (=
69)
On
–
O O
– – – – – – – – – – – – – – – – – – –
Off
O O O O O O O O O O O O O O O O O O O O O O
Wind Filter
On/Off
O O O O O O O O O O O O O O
–
O O O O O O
–
Review image after shooting (=
40)
Display Time
Off/Quick/2 sec./
4 sec./8 sec./Hold
O O O O O O O O O O O O O O O O O O O O
– –
Display Info Off/Detailed
O O O O O O O O O O O O O O O O O O O O
– –
O
Available or set automatically.
–
Not available.
157
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Shooting Mode
Function
D B M G
K E
I
P t E
Blink Detection (=
39)
On
O O O O O O O O O
–
O O
– – – – –
O O O
– –
Off
O O O O O O O O O O O O O O O O O O O O O O
Grid Lines (=
38)
On
O O O O O O O O O O O O O O O O O O O O O O
Off
O O O O O O O O O O O O O O O O O O O O O O
IS Settings (=
67)
IS Mode
Off/Continuous
O O O O O O O O O O O O O O O O O O O O O O
Shoot Only
O O O O O
– –
O O O O O O O O O O O O O
– –
Dynamic IS
1
O O O O O O O O O O O O O O
–
O O O O O O
–
2
O O O O O O O O O O O O O O O O O O O O O O
Display Area (=
32)
Large/Medium/Small
O O O O O O O O O O O O O O O O O O O O O O
Auto (=
33)
Off/On
O O O O O O O O O O O O
– – –
O O O O O O
–
Date Stamp (=
35)
Off
O O O O O O O O O O O O O O O O O O O O O O
Date / Date & Time
O O O O O O O O O
– –
O O
– – – – – –
O
– –
O
Available or set automatically.
–
Not available.
158
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
3 Set Up Tab Menu
Item Ref. Page
Item Ref. Page
Mute
=
118
Format
=
121
Volume
=
118
File Numbering
=
122
Hints & Tips
=
118
Create Folder
=
122
Date/Time
=
14
Units
=
122
Time Zone
=
119
Video System
=
130
Lens Retract
=
119
Ctrl via HDMI
=
128
Eco Mode
=
119
Wi-Fi Settings
=
93
Power Saving
=
20, 120
Certication Logo
Display
=
123
LCD Brightness
=
120
Language
=
15
Start-up Image
=
120
Reset All
=
123
1 Playback Tab Menu
Item Ref. Page Item Ref. Page
List/Play Digest Movies
=
75
Rotate
=
85
Slideshow
=
78
Favorites
=
87
Erase
=
83
Photobook Set-up
=
140
Protect
=
80
i-Contrast
=
90
Red-Eye Correction
=
90
Group Images
=
77
Cropping
=
88
Auto Rotate
=
86
Resize
=
88
Resume
=
74
My Colors
=
89
Transition
=
74
Scroll Display
=
74
2 Print Tab Menu
Item Ref. Page Item Ref. Page
Print
–
Select All Images
=
139
Select Images & Qty.
=
138
Clear All Selections
=
139
Select Range
=
139
Print Settings
=
137
Playback Mode FUNC. Menu
Item Ref. Page Item Ref. Page
Rotate
=
85
Play Linked Digest Movie
=
75
Protect
=
80
Group Playback
=
77
Favorites
=
87
Smart Shufe
=
79
Print
=
133
Image Search
=
76
Play Movie
=
73
Slideshow
=
78
159
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Handling Precautions
• The camera is a high-precision electronic device. Avoid dropping it or
subjecting it to strong impact.
• Never bring the camera near magnets, motors, or other devices that
generate strong electromagnetic elds, which may cause malfunction or
erase image data.
• If water droplets or dirt adheres to the camera or screen, wipe with a dry
soft cloth, such as an eyeglass cloth. Do not rub hard or apply force.
• Never use cleaners containing organic solvents to clean the camera or
screen.
• Use a blower brush to remove dust from the lens. If cleaning is difcult,
contact a Canon Customer Support Help Desk.
• To prevent condensation from forming on the camera after sudden
temperature changes (when the camera is transferred from cold to warm
environments), put the camera in an airtight, resealable plastic bag and
let it gradually adjust to the temperature before removing it from the bag.
• If condensation does form on the camera, stop using it immediately.
Continuing to use the camera in this state may damage it. Remove
the battery pack and memory card, and wait until the moisture has
evaporated before resuming use.
• Before long-term battery storage, use up the battery pack’s remaining
charge, remove it from the camera, and store it in a plastic bag or similar
container. Storing a partially charged battery pack over extended periods
(about a year) may shorten its life or affect performance.
Specications
CameraEffective
Pixels (Max.)
Approx. 12.1 million pixels
Lens Focal Length
30x zoom: 4.3 (W) – 129.0 (T) mm
(35mm lm equivalent: 24 (W) – 720 (T) mm)
LCD Monitor
3.0-type color TFT LCD
Effective Pixels: Approx. 461,000 dots
File Format
Design rule for Camera File system, DPOF (version 1.1)
compliant
Data Type
Still Images: Exif 2.3 (JPEG)
Movies: MOV (Video: H.264; Audio: Linear PCM (stereo))
Interface
Hi-speed USB
HDMI output
Analog audio output (stereo)
Analog video output (NTSC/PAL)
Power Source
Battery Pack NB-6LH
AC Adapter Kit ACK-DC40
Dimensions (Based
on CIPA Guidelines)
104.0 x 69.5 x 80.2 mm (4.09 x 2.74 x 3.16 in.)
Weight (Based on
CIPA Guidelines)
Approx. 349 g (approx. 12.31 oz.; including the battery pack
and memory card)
Approx. 316 g (approx. 11.15 oz.; camera body only)
160
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Wi-Fi Functions
Standards
IEEE802.11b/g/n*
* 2.4 GHz band only
Transmission
Methods
OFDM modulation (IEEE 802.11g/n)
DSSS modulation (IEEE 802.11b)
Communication
Modes
Infrastructure mode*
1
, Ad hoc mode*
2
*1 Supports Wi-Fi Protected Setup
*2 Wi-Fi CERTIFIED IBSS
Supported Channels
1 – 11 (PC2009/PC2060) or 1 – 13 (PC2008)
Model numbers indicated in parentheses (=
165)
Security
WEP, WPA-PSK (AES/TKIP),
WPA2-PSK (AES/TKIP)
Number of Shots/Recording Time, Playback Time
Number of Shots Approx. 250
EcoModeOn Approx. 330
Movie Recording Time*
1
Approx. 50 minutes
Continuous
Shooting*
2
Approx. 1 hour, 30 minutes
Playback Time Approx. 5 hours
*1 Time under default camera settings, when normal operations are performed, such as
shooting, pausing, turning the camera on and off, and zooming.
*2 Time available when shooting the maximum movie length (until recording stops
automatically) repeatedly.
• The number of shots that can be taken is based on measurement guidelines of the
Camera & Imaging Products Association (CIPA).
• Under some shooting conditions, the number of shots and recording time may be less
than mentioned above.
• Number of shots/time with a fully charged battery pack.
Number of 4:3 Shots per Memory Card
Recording Pixels
Compression
Ratio
Number of Shots per Memory Card
(Approx. shots)
8 GB 32 GB
(Large)
12M/4000x3000
1497 6044
2505 10115
(Medium 1)
6M/2816x2112
2855 11526
4723 19064
(Medium 2)
2M/1600x1200
7442 30040
12927 52176
(Small)
0.3M/640x480
27291 110150
40937 165225
• The values in the table are measured according to Canon standards and may change
depending on the subject, memory card and camera settings.
• The values in the table are based on 4:3 aspect ratio. If the aspect ratio is changed
(=
36), more images can be shot because the data size per image will be smaller
than with 4:3 images. However, since [
] 16:9 images have a setting of 1920 x 1080
pixels, their data size will be larger than 4:3 images.
161
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Recording Time per Memory Card
Image Quality
Recording Time per Memory Card
8 GB 32 GB
29 min. 37 sec. 1 hr. 59 min. 41 sec.
42 min. 09 sec. 2 hr. 50 min. 17 sec.
1 hr. 28 min. 53 sec. 5 hr. 59 min. 05 sec.
• The values in the table are measured according to Canon standards and may change
depending on the subject, memory card and camera settings.
• Recording will automatically stop when the clip le size reaches 4 GB, or when the
recording time reaches approximately 29 minutes and 59 seconds when shooting in
[
] or [ ], or approximately 1 hour when shooting in [ ].
• Recording may stop even if the maximum clip length has not been reached on some
memory cards. SD Speed Class 6 or higher memory cards are recommended.
Flash Range
Maximum wide angle (j)
50 cm – 5.0 m (1.6 – 16 ft.)
Maximum telephoto (i)
50 cm – 3.0 m (1.6 – 9.8 ft.)
Shooting Range
Shooting Mode Focusing Range
Maximum Wide Angle
(j)
Maximum Telephoto
(i)
–
0 cm (0.0 in.) – innity 1.4 m (4.6 ft.) – innity
Other modes
5 cm (2.0 in.) – innity 1.4 m (4.6 ft.) – innity
e
*
0 cm (0.0 in.) –
50 cm (1.6 ft.)
–
f
*
0 cm (0.0 in.) – innity 1.4 m (4.6 ft.) – innity
* Not available in some shooting modes.
Continuous Shooting Speed
Shooting Mode
Continuous Shooting
Mode
Speed
G
W
Approx. 3.8 shots/sec.
Approx. 1.0 shots/sec.
Approx. 1.0 shots/sec.
–
Approx. 10.5 shots/sec.
162
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Battery Pack NB-6LH
Type: Rechargeable lithium-ion battery
Nominal Voltage: 3.7 V DC
Nominal Capacity: 1060 mAh
Charging Cycles: Approx. 300 times
Operating Temperatures: 0 – 40 °C (32 – 104 °F)
Dimensions: 34.4 x 41.8 x 6.9 mm (1.35 x 1.65 x 0.27 in.)
Weight: Approx. 22 g (approx. 0.78 oz.)
BatteryChargerCB-2LY/CB-2LYE
Rated Input: 100 – 240 V AC (50/60 Hz), 0.085 A (100 V) – 0.05 A (240 V)
Rated Output: 4.2 V DC, 0.7 A
Charging Time: Approx. 2 hr. (when using NB-6LH)
Charge Indicator: Charging: orange /
Fully charged: green (two-indicator system)
Operating Temperatures: 0 – 40 °C (32 – 104 °F)
Shutter Speed
[ ] mode, automatically set range
15 – 1/1600 sec.
[M] mode available values (sec.)
15, 13, 10, 8, 6, 5, 4, 3.2, 2.5, 2, 1.6, 1.3, 1,
0.8, 0.6, 0.5, 0.4, 0.3, 1/4, 1/5, 1/6, 1/8, 1/10,
1/13, 1/15, 1/20, 1/25, 1/30, 1/40, 1/50, 1/60,
1/80, 1/100, 1/125, 1/160, 1/200, 1/250, 1/320,
1/400, 1/500, 1/640, 1/800, 1/1000, 1/1250,
1/1600
Aperture
f/number f/3.4 / f/8.0 (W) – f/5.8 / f/8.0 (T)
[B] mode available values*
f/3.4, f/4.0, f/4.5, f/5.0, f/5.6, f/5.8, f/6.3, f/7.1,
f/8.0
* Depending on the zoom position, some aperture values may not be available.
163
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Focus lock ........................................... 61
FUNC. menu
Basic operations ............................ 22
Table .................................... 153, 158
G
GPS ..................................................... 74
Grid lines ............................................. 38
H
HDMI cable ........................................ 126
High-speed burst (shooting mode) ...... 50
Household power............................... 130
I
i-Contrast ....................................... 56, 90
Image quality
→
Compression ratio (image quality)
Images
Display period ............................... 40
Erasing .......................................... 83
Playback
→
Viewing
Protecting ...................................... 80
Image Sync.........................................112
Indicator ............................................... 25
ISO speed............................................ 55
L
Lamp.................................................... 40
Live View Control (shooting mode) ...... 44
Low light (shooting mode) ................... 45
A
AC adapter kit ............................ 126, 130
Accessories ....................................... 126
AE lock ................................................ 54
AF frames ............................................ 61
AF lock................................................. 64
Aspect ratio.......................................... 36
AUTO mode (shooting mode) .. 16, 21, 27
AV cable ............................................ 129
Av (shooting mode) ............................. 69
B
Battery charger .............................. 2, 126
Battery pack
Charging ......................................... 11
Eco mode .....................................119
Level ............................................ 149
Power saving ................................. 20
Black and white images ....................... 57
Blink detection ..................................... 39
C
Camera
Reset all ...................................... 123
Camera access point mode ............... 106
Camera shake ..................................... 67
CameraWindow (computer)............... 100
CameraWindow (smartphone)............. 99
CANON iMAGE GATEWAY ................. 94
Center (AF frame mode)...................... 61
Clock.................................................... 25
Color (white balance)........................... 56
Compression ratio (image quality) ....... 66
Connecting via an access point ......... 102
Connecting without an access point .. 106
Continuous shooting ............................ 58
High-speed burst
(shooting mode) ............................ 50
Creative lters (shooting mode)........... 46
Cropping ...................................... 88, 135
Custom white balance ......................... 57
D
Date/time
Adding date stamps ...................... 35
Changing ....................................... 14
Date/time battery ........................... 15
Settings ......................................... 14
World clock ...................................119
DC coupler......................................... 130
Defaults
→
Reset all
Digital tele-converter............................ 61
Digital zoom ......................................... 31
Discreet mode (shooting mode) .......... 43
Display language ................................. 15
DPOF ................................................. 137
Drive mode .......................................... 58
Index
E
Eco mode ...........................................119
Editing
Cropping ........................................ 88
i-Contrast ....................................... 90
My Colors ...................................... 89
Red-eye correction ........................ 90
Resizing images ............................ 88
Editing or erasing connection
information .......................................... 114
Erasing ................................................ 83
Error messages ................................. 146
Exposure
AE lock .......................................... 54
Compensation ............................... 54
FE lock .......................................... 66
F
Face AiAF (AF frame mode) ................ 62
Face self-timer (shooting mode) .......... 49
FE lock................................................. 66
File numbering ................................... 122
Fireworks (shooting mode) .................. 45
Fish-eye effect (shooting mode) .......... 46
Flash
Flash exposure compensation ...... 65
On ................................................. 65
Focusing
AF frames ...................................... 61
AF lock .......................................... 64
AF-point zoom ............................... 39
Servo AF ....................................... 63
Focusing range
Macro ............................................ 59
Manual focus ................................. 60
164
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
V
Viewing ................................................ 17
Image search ................................ 76
Index display ................................. 76
Magnied display .......................... 78
Single-image display ..................... 17
Slideshow ...................................... 78
Smart Shufe ................................ 79
TV display ................................... 127
W
White balance (color)........................... 56
Widescreen (resolution)....................... 37
Wi-Fi
Connecting and sending images ... 95
Wi-Fi functions ..................................... 93
Wi-Fi menu ........................................ 101
World clock .........................................119
Wrist strap
→
Strap
Z
Zoom ....................................... 16, 27, 31
Zoom framing assist ............................ 32
Sending images to a smartphone ........ 95
Sending images to Web services ........ 95
Sepia tone images ............................... 57
Servo AF .............................................. 63
Shooting
Shooting date/time
→
Date/time
Shooting information ................... 149
Slideshow ............................................ 78
Smart Shufe ....................................... 79
Snow (shooting mode)......................... 45
Software
Saving images to a computer ...... 132
Sounds ...............................................118
Stereo AV cable ................................. 127
Strap .................................................2, 11
Super slow motion movie
(movie mode)....................................... 51
Super vivid (shooting mode) ................ 46
T
Terminal ..................... 128, 129, 130, 133
Toy camera effect (shooting mode) ..... 48
Tracking AF ......................................... 62
Traveling with the camera ..................119
Troubleshooting ................................. 143
TV display .......................................... 127
Tv (shooting mode).............................. 69
Power ................................................ 126
→
AC adapter kit
→
Battery pack
Power saving ....................................... 20
Printing .............................................. 133
Program AE ......................................... 54
Protecting ............................................ 80
P (shooting mode) ............................... 54
R
Red-eye correction ........................ 37, 90
Reset all............................................. 123
Resizing images .................................. 88
Resolution (image size) ....................... 37
Rotating ............................................... 85
S
Saving images to a computer ............. 111
Screen
Display language ........................... 15
Icons .................................... 149, 150
Menu
→
FUNC. menu, Menu
SD/SDHC/SDXC memory cards
→
Memory cards
Searching ............................................ 76
Self-timer ............................................. 34
2-second self-timer ........................ 34
Customizing the self-timer ............. 35
Face self-timer (shooting mode) ... 49
Sending images ................................. 109
Sending images to a computer ............ 96
Sending images to another camera..... 95
Sending images to a printer................. 96
M
Macro (focus mode)............................. 59
Magnied display ................................. 78
Manual focus (focus mode) ................. 60
Memory cards ........................................ 2
Recording time ............................ 161
Menu
Basic operations ............................ 23
Table ............................................ 151
Metering method.................................. 55
Miniature effect (shooting mode) ......... 47
Monochrome (shooting mode)............. 48
Movie Digest (shooting mode) ............. 43
Movies
Editing ........................................... 91
Image quality
(resolution/frame rate) ................... 38
Recording time ............................ 161
M (shooting mode)............................... 70
My Colors ...................................... 57, 89
N
Neck strap
→
Strap
P
Package contents .................................. 2
Photobook set-up .............................. 140
PictBridge .................................. 127, 133
Playback
→
Viewing
Portrait (shooting mode) ...................... 45
Poster effect (shooting mode) ............. 46
165
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Wi-Fi (Wireless LAN) Precautions
• The camera’s model number is PC2009/
PC2060/PC2008 (including WLAN module
model WM219). To identify your model, check
the label on the bottom of the camera for a
number beginning with PC.
•
• Doing any of the following may incur legal penalties:
- Altering or modifying the product
- Removingthecerticationlabelsfromtheproduct
• According to foreign exchange and foreign trade law regulations, export
permission (or service transaction permission) from the Japanese
government is necessary to export strategic resources or services
(including this product) outside Japan.
• Because this product includes American encryption software, it falls
under U.S. Export Administration Regulations, and cannot be exported to
or brought into a country under U.S. trade embargo.
• Be sure to make notes of the wireless LAN settings you use.
The wireless LAN settings saved to this product may change or be
erased due to incorrect operation of the product, the effects of radio
waves or static electricity, or accident or malfunction. Be sure to make
notes of wireless LAN settings as a precaution. Please note that Canon
accepts no responsibility for direct or indirect damages or loss of
earnings resulting from a degradation or disappearance of content.
• When transferring this product to another person, disposing of it, or
sending it for repair, be sure to note the wireless LAN settings and reset
the product to its default settings (erase settings) if necessary.
• Canon will not make compensation for damages resulting from loss or
theft of the product.
Canon accepts no responsibility for damages or loss resulting from
unauthorized access or use of target devices registered on this product
due to loss or theft of the product.
• Be sure to use the product as directed in this guide.
Be sure to use the wireless LAN function of this product within the
guidelines noted in this guide. Canon accepts no responsibility for
damages or loss if the function and product are used in ways other than
as described in this guide.
• Do not use the wireless LAN function of this product near medical
equipment or other electronic equipment.
Use of the wireless LAN function near medical equipment or other
electronic equipment may affect operation of those devices.
Radio Wave Interference Precautions
• This product may receive interference from other devices that emit radio
waves. To avoid interference, be sure to use this product as far away as
possible from such devices, or avoid using the devices at the same time
as this product.
166
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Security Precautions
Because Wi-Fi uses radio waves to transmit signals, security precautions
more stringent than when using a LAN cable are required.
Keep the following points in mind when using Wi-Fi.
• Only use networks you are authorized to use.
This product searches for Wi-Fi networks in the vicinity and displays the
results on the screen. Networks you are not authorized to use (unknown
networks) may also be displayed. However, attempting to connect to or
using such networks could be regarded as unauthorized access. Be sure
to use only networks you are authorized to use, and do not attempt to
connect to other unknown networks.
If security settings have not been properly set, the following problems may
occur.
• Transmission monitoring
Third parties with malicious intent may monitor Wi-Fi transmissions and
attempt to acquire the data you are sending.
• Unauthorized network access
Third parties with malicious intent may gain unauthorized access to
the network you are using to steal, modify, or destroy information.
Additionally, you could fall victim to other types of unauthorized access
such as impersonation (where someone assumes an identity to gain
access to unauthorized information) or springboard attacks (where
someone gains unauthorized access to your network as a springboard to
covertheirtrackswheninltratingothersystems).
To prevent these types of problems from occurring, be sure to thoroughly
secure your Wi-Fi network.
Only use this camera’s Wi-Fi function with a proper understanding of
Wi-Fi security, and balance risk and convenience when adjusting security
settings.
The camera can print to PictBridge-compatible printers
via Wi-Fi. PictBridge technical standards make it easy
to connect digital cameras, printers, and other devices
directly. Additionally, a new standard called DPS over IP
enables PictBridge connections in network environments,
and the camera is also compatible with this standard.
Battery Charger CB-2LY
167
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
FCC/IC Notice
Model: PC2009 (including WLAN Module Model WM219, FCC ID: AZD219)
FCC Notice
(Digital Camera, Model PC2009 systems)
•
•
•
•
168
1
2
3
4
5
6
7
8
9
10
Cover
Before Use
Common Camera
Operations
Advanced Guide
Camera Basics
Auto Mode
Other Shooting
Modes
P Mode
Playback Mode
Wi-Fi Functions
Setting Menu
Accessories
Appendix
Index
Basic Guide
Tv, Av, and M
Mode
Trademark Acknowledgments
• Windows and the Windows logo are trademarks of the Microsoft group of
companies.
• Macintosh and Mac OS are trademarks of Apple Inc., registered in the
U.S. and other countries.
• App Store, iPhone, and iPad are trademarks of Apple Inc.
• The SDXC logo is a trademark of SD-3C, LLC.
• HDMI,theHDMIlogoandHigh-DenitionMultimediaInterfaceare
trademarks or registered trademarks of HDMI Licensing LLC.
• Wi-Fi
®
, Wi-Fi Alliance
®
, WPA™, WPA2™ and Wi-Fi Protected Setup™
are trademarks or registered trademarks of the Wi-Fi Alliance.
• All other trademarks are the property of their respective owners.
• This device incorporates exFAT technology licensed from Microsoft.
• This product is licensed under AT&T patents for the MPEG-4 standard
and may be used for encoding MPEG-4 compliant video and/or decoding
MPEG-4 compliant video that was encoded only (1) for a personal and
non-commercial purpose or (2) by a video provider licensed under the
AT&T patents to provide MPEG-4 compliant video. No license is granted
or implied for any other use for MPEG-4 standard.
Disclaimer
• Reprinting, transmitting, or storing in a retrieval system any part of this
guide without the permission of Canon is prohibited.
• Canon reserves the right to change the contents of this guide at any time
without prior notice.
• Illustrations and screenshots in this guide may differ slightly from the
actual equipment.
• The above items notwithstanding, Canon accepts no liability for damages
due to mistaken operation of the products.
