LG Electronics LUV350P Kompressor® Lightweight Upright User Manual

P/NO : MFL67230701 www.lg.com

OWNER’S MANUAL

VACUUM CLEANER

Please read this owner's manual thoroughly before

operating and keep it handy for reference at all times.

ENGLISH

ESPAÑOL

LuV350P*

FRANÇAIS

ENGLISH

TABLE OF CONTENTS

3 VACUUM CLEANER WARRANTY

4 IMPORTANT SAFETY INFORMATION

6 PARTS AND FEATURES

7 ASSEMBLY

7 Unpacking the Vacuum Cleaner

7 Assembly Parts

7 Attaching the Wand

8 Attaching the Hose

8 Accessory Storage

8 Cord Storage

9 OPERATION

9 Wand Release Operation

9 Body Release Operation

1 0 Accessories

1 0 Accessory Use Chart

1 1 Using the Wand

1 1 Installing Attachments

1 1 Tips and Tricks

1 2 Using the Pet Hair Turbine Tool

1 2 Stairways and Landings

1 2 Using the Wand

1 2 Agitator Motor Overload Protection

1 2 Thermal Overload Protection

13 CARE & CLEANING

1 3 Storing the Vacuum Cleaner

1 3 Dust Tank Components

1 4 Emptying the Dust Tank

1 4 Cleaning the Dust Tank

1 5 Cleaning the Foam Filter

1 5 Cleaning the HEPA Filter

1 6 Pet Hair Turbine Tool

1 6 Agitator Maintenance

1 6 Replacing the Agitator Belt

1 7 Removing Clogs

1 8 Cleaning the Exterior of the Vacuum Cleaner

19 TROUBLESHOOTING

ENGLISH

WARRANTY (USA)

LG Electronics Inc. will repair or replace your product, at LG’s option, if it proves to be defective in material or workmanship under personal household use,

during the warranty period set forth below, eective from the date of original consumer purchase of the product. This limited warranty is good only to the

original purchaser of the product and eective only when used in U.S.A. and Canada.

WARRANTY PERIOD HOW SERVICE IS HANDLED

Five Year

From the date of the original purchase

Any part of the vacuum cleaner which fails due to a defect in materials or workmanship. During this

full ve-year warranty, LG will also provide, free of charge, all labor and shop service to replace

the defective part.

THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MER-

CHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURA-

TION TO THE EXPRESS WARRANTY PERIOD ABOVE. LG WILL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF

ANY KIND, INCLUDING LOST REVENUES OR PROFITS, IN CONNECTION WITH THE PRODUCT. SOME STATES DO NOT ALLOW LIMITATION ON HOW

LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EX-

CLUSIONS MAY NOT APPLY TO YOU.

THIS WARRANTY COVERS ONLY DEFECTS IN MATERIAL AND WORKMANSHIP. LGE WILL NOT PAY FOR:

1. Expendable items that can wear out, including but not limited to lters, and belts.

2. A service technician to instruct the user in correct product assembly, operation or maintenance.

3. A service technician to clean or maintain this product.

4. Damage to or failure of this product if it is not assembled, operated or maintained according to all instructions supplied with this product.

5. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.

6. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those recommended in all instructions

supplied with this product.

7. Damage to or failure of parts or systems resulting from unauthorized modications made to this product.

This warranty is extended to the original purchaser for products purchased for home use within the U.S.A. In Alaska, the warranty excludes the cost of ship-

ping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so this exclusion or limitation may not apply to you. This war-

ranty gives you specic legal rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local

or state consumer aairs or your state’s Attorney General.

CUSTOMER ASSISTANCE INFORMATION:

To Prove Warranty Coverage Retain your Sales Receipt to prove date of purchase.

A copy of your Sales Receipt must be submitted at the time warranty service is

provided.

To Obtain Nearest Authorized Service Center or Sales Dealer, or

to Obtain Product, Customer, or Service Assistance

Call 1-800-243-0000 (24 hours - 365 days a year) and choose the appropriate

prompt from the menu; or visit our website at http://www.lg.com

(In Canada Call 1-888-542-2623, website http://www.lg.com)

WARRANTY

ENGLISH

IMPORTANT SAFETY INFORMATION

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE - SAVE THESE INSTRUCTIONS

Read and follow all instructions before using your vacuum cleaner to prevent the risk of re, electric shock, personal injury, or damage when using the

vacuum cleaner. This guide does not cover all possible conditions that may occur. Always contact your service agent or manufacturer regarding problems

that you do not understand.

This is the safety alert symbol. This symbol alerts you to potential hazards that can result in property damage and / or serious bodily harm or death.

All safety messages will follow the safety alert symbol and either the word WARNING or CAUTION.

Indicates a hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.

WARNING

y Disconnect electrical supply before servicing or cleaning the vacuum

cleaner or when the vacuum cleaner is not in use. Failure to do so could

result in electrical shock or personal injury.

y Do not use the vacuum cleaner to pick up anything that is burning

or smoking such as cigarettes, or hot ashes. Doing so could result in

death, fire or electrical shock.

y Do not vacuum flammable or explosive substances such as

gasoline, benzene, thinners, propane (liquids or gases). The

fumes from these substances can create a fire hazard or explosion.

Doing so could result in death or personal injury.

y Do not handle the plug or vacuum cleaner with wet hands. Doing

so could result in death or electrical shock.

y Do not unplug the vacuum cleaner by pulling on the cord. Doing

so could result in product damage or electrical shock. To unplug,

grasp the plug, not the cord.

y Keep hair, loose clothing, fingers, and all parts of the body away

from openings and moving parts. Failure to do so could result in

electrical shock or personal injury.

y Do not pull or carry the vacuum cleaner by its cord, use the cord

as a handle, close a door on the cord or pull the cord around sharp

edges or corners.

y Do not run the vacuum cleaner over the cord. Keep the cord away

from heated surfaces. Failure to do so could result in electrical shock,

personal injury, re, or product damage.

y The vacuum cleaner is not a toy and should not be operated by

children. Pay close attention when operating the vacuum cleaner

near children. Personal injury or product damage could result.

y Do not use the vacuum cleaner if the power cord or plug is

damaged or faulty. Personal injury or product damage could result.

In these cases, contact LG Electronics Service Agent to avoid hazard.

y Do not use vacuum cleaner if it has been under water. Personal

injury or product damage could result. In these cases, contact LG

Electronics Service Agent to avoid hazard.

y Do not continue to vacuum if any parts appear missing or

damaged. Personal injury or product damage could result. In these

cases, contact LG Electronics Service Agent to avoid

hazard.

y Do not use an extension cord with this vacuum cleaner. Fire hazard

or product damage could result.

y Use proper voltage. Using improper voltage may result in damage to

the motor and possible injury to the user. Proper voltage is listed on

the bottom of the vacuum cleaner.

y Turn o all controls before unplugging. Failure to do so could result

in electrical shock or personal injury.

y Do not change the plug in any way. Failure to follow this warning

could result in electrical shock, personal injury, product damage or

death. If plug does not t, contact a qualied electrician to install the

proper outlet.

y Repairs to electrical appliances may only be performed by

qualied service engineers. Improper repairs may lead to serious

hazards for the user.

y Do not put ngers near the gear. Failure to follow this warning could

result in personal injury.

y Do not use out doors or on wet surfaces. Failure to follow this

warning could result in electrical shock or personal injury.

y Do not put anything between the vacuum cleaner body and

agitator head space. Personal injury or product damage could result.

y This product contains chemicals known to the State of California to

cause cancer and birth defects or other reproductive harm. Wash

hands after handling.

y Use extra care when cleaning on stairs.

y Do not leave the appliance when it is plugged in. Unplug from the

outlet when not in use and before servicing.

WARNING

ENGLISH

IMPORTANT SAFETY INFORMATION

CAUTION

y Do not insert objects into vacuum openings. Failure to follow this

instruction could result in product damage.

y Do not use the vacuum cleaner if any of the openings are blocked.

Keep vacuum openings free of dust, lint, hair and anything that

may reduce air ow. Failure to follow instruction could result in

product damage.

y Do not use the vacuum cleaner without the tank and / or lters

properly installed. Failure to follow instruction could result in

product damage.

y Always clean the dust tank and lters after vacuuming carpet

cleaners or fresheners, powders and ne dust. These products can

clog the lters, reduce airow and / or cause damage to the vacuum.

Failure to clean the dust tank and lters could cause permanent

damage to the vacuum.

y Do not use the vacuum cleaner to pick up sharp or hard objects

such as small toys, pins, paper clips, etc. They may damage the

vacuum or dust tank.

y Store the vacuum cleaner indoors. Put the vacuum cleaner away

after use to prevent tripping over it.

y The vacuum cleaner should not be operated by young children.

Failure to follow this instruction could result in personal injury or

product damage.

y Only use parts produced or recommended by Qualied Service

Technicians. Failure to do so could result in product damage.

y Follow all instructions in the owner’s manual. Only use LG

recommended or approved attachments and accessories. Failure

to do so could result in product damage.

y Never place the vacuum cleaner at the top of stairs. Failure to

follow instruction could result in personal injury or product damage.

y Make sure the lters (exhaust lter and motor safety lter) are

completely dry before placing in the vacuum. Failure to do so could

result in product damage.

y Do not dry the lters in an oven or microwave. Failure follow

instruction could result in a re hazard.

y Do not dry the lters in a clothes dryer. Failure to follow instruction

could result in a re hazard.

y Do not dry the lters near an open ame. Failure to follow

instruction could result in a re hazard.

y Always turn the vacuum cleaner o before connecting or

disconnecting the hose. Personal injury or product damage could

result.

y The vacuum cleaner is only intended for household use.

y You are responsible for proper assembly and use of your vacuum

cleaner.

Thermal Protector:

This vacuum cleaner has a special thermostat that protects the vacuum cleaner in case of motor overheating. If the vacuum cleaner suddenly shuts

o, turn o the switch and unplug the vacuum cleaner.

Check the vacuum cleaner for possible source of overheating such as a full dust tank, a blocked hose or clogged lter. If theses conditions are found,

x them and wait at least 30 minutes before attempting to use the vacuum cleaner. After 30 minutes, plug the vacuum cleaner back in and turn on

the switch. If the vacuum cleaner still does not run, contact a qualied electrician.

ESPAÑOL

INSTRUCCIONES DE SEGURIDAD IMPORTANTES

GUARDE ESTAS INSTRUCCIONES

LEA TODAS LAS INDICACIONES ANTES DE USAR EL PRODUCTO

Lea y siga todas las instrucciones antes de usar la aspiradora para prevenir riesgos de incendio, descarga eléctrica, lesión personal o daños cuando use

la aspiradora. Esta guía no cubre todos los posibles inconvenientes que puedan surgir. Siempre debe ponerse en contacto con su agente de servicio o

fabricante en caso de que surjan problemas que no comprenda.

Este es el símbolo de alerta de seguridad. Este símbolo lo alertará en caso de que existan riesgos que puedan acarrear daños a la propiedad y/o

lesiones corporales graves o muerte.

Todos los mensajes de seguridad seguirán al símbolo de alerta de seguridad y a los términos ADVERTENCIA o PRECAUCIÓN.

ADVERTENCIA

Indica una situación peligrosa que, si no se evita, podría ocasionar la muerte o lesiones graves.

PRECAUCIÓN

Indica una situación peligrosa que, si no se evita, podría ocasionar lesiones menores o moderadas.

INFORMACIÓN IMPORTANTE DE SEGURIDAD

ADVERTENCIA

y Desconecte el suministro eléctrico antes de realizar el mantenimiento

o la limpieza de la aspiradora o cuando no se la esté usando. Si no lo

hace, correrá riesgo de sufrir una descarga eléctrica o lesiones personales.

y No use la aspiradora para recoger objetos que estén quemándose

o lanzando humo, como cigarrillos o cenizas calientes. Esto podría

ocasionar la muerte, un incendio o una descarga eléctrica.

y No aspire sustancias inflamables ni explosivas, como nafta,

benceno, diluyentes, propano (en estado líquido o gaseoso).

Los gases de estas sustancias pueden generar riesgo de incendio

o explosión. Hacer esto puede conducir a la muerte o a lesiones

personales.

y No manipule el enchufe ni la aspiradora con las manos mojadas.

Esto podría ocasionar la muerte o una descarga eléctrica.

y No desenchufe la aspiradora tirando del cable. Podría dañar

el producto o sufrir una descarga eléctrica. Para desenchufar la

aspiradora, tome el enchufe, no el cable.

y Mantenga el cabello, la ropa holgada, los dedos y todas las

partes del cuerpo alejadas de las aberturas y las piezas móviles.

Si no lo hace, correrá riesgo de sufrir una descarga eléctrica o lesiones

personales.

y No tire ni transporte la aspiradora por el cable; no use el cable

como manija; no cierre puertas dejando el cable atrapado; no tire

del cable cuando esté alrededor de bordes o esquinas filosas.

y No pase la aspiradora por encima del cable. Mantenga el cable

alejado de supercies calientes. Si no lo hace, pueden ocasionarse

descargas eléctricas, lesiones personales, incendios o daños al

producto.

y La aspiradora no es un juguete y no debe ser operada por niños.

Preste mucha atención cuando esté usando la aspiradora cerca de

niños. De lo contrario, podría ocasionar lesiones personales o daños

al producto.

y No use la aspiradora si el cable de alimentación o el enchufe están

dañados. De lo contrario, podría ocasionar lesiones personales o

daños al producto. En estos casos, póngase en contacto con el agente

de servicios de LG Electronics para evitar los riesgos.

y No use la aspiradora si ha estado bajo agua. De lo contrario, podría

ocasionar lesiones personales o daños al producto. En estos casos,

póngase en contacto con el agente de servicios de LG Electronics para

evitar los riesgos.

y No siga aspirando si sospecha que faltan piezas o que están

dañadas. De lo contrario, podría ocasionar lesiones personales o daños

al producto. En estos casos, póngase en contacto con el agente de

servicios de LG Electronics para evitar los riesgos.

y No use un cable de extensión con esta aspiradora. Esto podría

acarrear riesgos de incendio o daños al producto.

y Use la tensión adecuada. El uso de tensión incorrecta podría acarrear

daños en el motor y posibles lesiones al usuario. La tensión adecuada

se especica en la parte inferior de la aspiradora.

y Apague todos los controles antes de desenchufarla. Si no lo hace,

correrá riesgo de sufrir una descarga eléctrica o lesiones personales.

y No modique el enchufe de ninguna manera. Si lo hace, se

pueden ocasionar descargas eléctricas, lesiones personales, daños

al producto o muerte. Si el enchufe no entra en el tomacorriente,

póngase en contacto con un electricista calicado para que instale un

tomacorriente adecuado.

y Las reparaciones de electrodomésticos deben realizarlas

únicamente ingenieros de mantenimiento calicados. Una

reparación inadecuada puede generar graves peligros para el usuario.

y No coloque los dedos cerca del engranaje. Si lo hace, puede sufrir

lesiones personales.

y No use la aspiradora en exteriores ni en supercies húmedas. Si

lo hace, puede provocar descargas eléctricas o lesiones personales.

y No coloque ningún objeto entre el cuerpo de la aspiradora y el

espacio del cabezal del agitador. De lo contrario, podría ocasionar

lesiones personales o daños al producto.

y Este producto contiene sustancias químicas que el estado de

California reconoce que pueden causar cáncer y toxicidad

reproductiva. Lávese las manos después de manipularlo.

y Tome precauciones adicionales cuando limpie escaleras.

y No deje electrodomésticos enchufados mientras no estén en uso.

Desenchúfelos mientras no los esté usando y antes de realizar tareas

de mantenimiento.

ENGLISH

It is important to know your vacuum cleaner parts and features to assure its proper and safe use. Review these before using your vacuum cleaner.

PARTS AND FEATURES

Common Replacement Parts

HEPA Filter ADQ73353501

Foam Filter

ADV74067001

Filter Frame ADV74067001

Foam Filter MDJ61980604

Agitator Belt MAS62064002

To order these parts call:

1-800-243-0000 (U.S.A.)

1-888-542-2623 (Canada)

Accessory Tools

Dusting brush & Crevice tool

Pet hair turbine tool

Hose

Handle

Carry handle

Wand

Cord

Wand release

button

Body release

Agitator

Dusting brush

& Crevice tool

Dust tank

release

Dust

separator

Dust tank

Viewing

window

Exhaust

lter

Upholstery tool

Floor/Carpet

button

Quick release

cord hanger

Power button

ENGLISH

ASSEMBLY

To reduce the risk shipping damage, your vacuum cleaner is shipped partially assembled.

ASSEMBLY

Unpacking the Vacuum Cleaner

Carefully unpack the vacuum cleaner and make sure that you have all

parts before discarding of any packaging.

Remove any tape, cardboard inserts and protective lm before assembly.

Items that are packed in the box:

1. Vacuum Cleaner Body

2. Dusting Brush & Crevice Tool

3. Handle and Wand

4. Hose

5. Pet Hair Turbine Tool

6. Additional Foam Filter

7. Upholstery Tool

Assembly Parts

1. Vacuum Cleaner Body

2. Dusting Brush and

Crevice Tool

3. Handle and

Wand

4. Hose

5. Pet Hair

Turbine Tool

6. Additional Foam

Filter

Attaching the Wand

1. Insert the wand onto the wand-locator knob.

2. Snap the wand into the body.

7. Upholstery

Tool

ENGLISH

ASSEMBLY

Attaching the Hose

1. Attached the top side of the hose to the handle. The top side of the

hose can be recognized by the two holes.

Accessory Storage

Your vacuum cleaner features convenient on-board storage for the

dusting brush & crevice tool.

y Insert the dusting brush & crevice tool onto the main body

2. Insert the bottom side of the hose to the main body. The bottom side

of the hose can be recognized by the two release clips.

3. Clip the hose into its holder on the back side of the vacuum.

WARNING

Personal injury and Product Damage Hazard! DO NOT use

outlets above counters. Not following this warning could

result in damage to the surrounding items.

Cord Storage

To store the cord:

1. Make sure the cord hanger is in the UP position.

2. Wrap the cord around the cord hanger and hook into place. Clip the

plug onto the cord.

NOTE: To reduce the risk of electric shock, this vacuum cleaner has a

polarized plug; one blade is wider than the other. This plug will t in a

polarized outlet only one way. If the plug does not t fully in the outlet,

reverse the plug. If it still does not t, contact a qualied electrician to

install the proper outlet. Do not change the plug in any way.

To release the cord:

1. Rotate the upper cord holder to the DOWN position.

2. Unclip the plug and extend the cord.

ENGLISH

OPERATION

Wand Extension

Press

the

extension

button

the

wand

and

extend

the

wand

handle.

WARNING

Do not place anything in the space between the body and

agitator head.

Personal

injury

product

damage

could

result.

WARNING

Personal injury Hazard!

not

set

the

vacuum

cleaner

stairs;

always

keep

the

oor.

Control Operation

Floor/Carpet

Press

this

button

turn

the

agitator

(carpet)

OFF

(oor).

The

Floor/Carpet

button

also

resets

the

agitator

motor.

Power:

Turns

the

vacuum

and

o.

Note:

The

agitator

will

not

spin

when

the

vacuum

the

upright

position

Body Release Operation

begin

vacuuming,

press

the

pedal

the

left

side

the

vacuum

and

pull

the

handle

down.

Note:

When

the

vacuum

the

upright

position

the

agitator

will

not

run.

ENGLISH

OPERATION

Accessories

Pet Hair Turbine Tool

This

air-turbine

powered

brush

designed

for

removing

pet

hair,

lint,

etc.

from

fabrics

and

carpets.

Do NOT use on pets.

Dusting Brush

Use

the

dusting

brush

clean

furniture,

walls,

etc.

Crevice Tool

The

crevice

tool

can

used

for

tight

corners,

between

cushions

and

other

hard

reach

places.

Upholstery Tool

Use

the

upholstery

tool

clean

fabric

furniture.

Accessory Use Chart

Accessory

CLEANING AREA

Between

Cushions

Upholstered

Surfaces*

Furniture

and Hard

Surfaces*

Drapes*

Stairs/

Cushions

Carpeted

Floors/Rugs

Walls

Pet

Hair

Turbine

Tool

Dusting

Brush

Crevice

Tool

Upholstery

Tool

Always

make

sure

attachments

are

clean

before

using

fabrics.

ENGLISH

OPERATION

Never pull the vacuum cleaner by the hose.

CAUTION

Using the Wand

Release the wand and handle:

1. Make sure that the vacuum cleaner is locked in the upright position

on a at, stable surface.

2. Press the wand release button on the body and tilt the wand handle.

3. Lift the wand up and out.

4. Press the wand extension button on the wand and pull the wand

down.

Installing Attachments

Crevice Tool:

Slide the crevice tool into the end of the wand.

Dusting Brush:

Press the brush release button on the crevice tool and slide the brush

forward.

Tips and Tricks

Carpet Edges and Corners:

For tight corners, carpet edges and along base boards, use the dusting

brush. For especially hard to reach areas, use the crevice tool.

Crevice tool

Dusting brush

Upholstery Tool:

Slide the upholstery tool into the end of the wand.

ENGLISH

OPERATION

Using the Pet Hair Turbine Tool

The Pet Hair Turbine Tool features a turbine-powered agitator to provide

extra cleaning power on carpets and fabrics. It is great for cleaning stairs,

cushions and vehicle upholstery.

Thermal Overload Protection

This vacuum cleaner has a thermal overload protector that automatically

activates to protect the vacuum cleaner from overheating. If a clog

disturbs the normal ow of air to the motor, the thermal protector turns

the motor o automatically to allow the motor to cool in order to prevent

possible damage to the vacuum cleaner.

To correct the problem: Turn the vacuum cleaner o and unplug the

power cord. Check for and remove clogs, if necessary. Also check and

clean any dirty lters.

Wait approximately 30 minutes and then plug the vacuum cleaner in

and turn it back on to see if the motor protector has reset. The thermal

protector system will not reset until the vacuum cleaner has completely

cooled down.

When using the pet hair turbine tool, check the brush area frequently for

buildup of hair, bers, lint and other debris.

Excessive buildup can reduce performance and could damage the pet hair

turbine tool. See the Care and Cleaning section for cleaning instructions.

Stairways and Landings

Use the dusting brush or pet hair turbine tool on stairs and landings. Make

sure that the vacuum cleaner is placed so that it cannot tip or fall.

Agitator Motor Overload Protection

The agitator has a built-in protection against motor damage

should the agitator jam. If the agitator slows down or stops, the

agitator overload protector shuts o the agitator and suction

motor.

To correct problem: Turn o and unplug the vacuum cleaner. Remove

the obstruction and turn on the vacuum cleaner by pressing the Power

button, and then press the Floor/Carpet button.

ENGLISH

CARE & CLEANING

Always follow all safety precautions when cleaning and servicing the vacuum cleaner.

Storing the Vacuum Cleaner

When not in use, wrap the cord around the cord hanger as shown. The

hose can be wrapped around the handle/wand if the wand is being

stored un-extended. Store the dusting brush/crevice tool in its proper

place on the left of the vacuum cleaner.

Dust Tank Components

The dust tank consists of several key components. Always make sure that

all parts are properly reinstalled after emptying the dust tank.

NEVER operate the vacuum cleaner without all lters in place.

NEVER operate the vacuum cleaner with wet lters or components.

Key components:

1. Filter frame and foam lter:

Captures medium to ne particles. It consists of Filter frame &

Foam lter. These are washable.

2. Foam lter

3. Dust tank lid: Open to access the foam lter.

4. Dust separator: Separates dust from air coming in.

5. Side door: Open to remove dirt from the dust separator.

6. Prevention tab: Prevents the lid from closing without a foam lter

installed.

7. Dust tank: Where dirt is collected.

8. Bottom plate: Open to empty the dust tank.

y Electrical shock and personal injury hazard.

y Take care when wrapping the cord. Wrapping the cord too tightly

puts stress on the cord and can cause cord damage. Do not

crisscross when wrapping the cord. A damaged cord could cause

an electrical shock hazard, personal injury or damage.

WARNING

1. Filter frame

2. Foam lter

3. Dust tank

lid

4. Dust separator

5. Side door

6. Prevention

Tab

7. Dust tank

8. Bottom plate

ENGLISH

CARE & CLEANING

Always follow all safety precautions when cleaning and servicing the vacuum cleaner.

Storing the Vacuum Cleaner

When not in use, wrap the cord around the cord hanger as shown. The

hose can be wrapped around the handle/wand if the wand is being

stored un-extended. Store the dusting brush/crevice tool in its proper

place on the left of the vacuum cleaner.

Dust Tank Components

The dust tank consists of several key components. Always make sure that

all parts are properly reinstalled after emptying the dust tank.

NEVER operate the vacuum cleaner without all lters in place.

NEVER operate the vacuum cleaner with wet lters or components.

Key components:

1. Filter frame and foam lter:

Captures medium to ne particles. It consists of Filter frame &

Foam lter. These are washable.

2. Foam lter

3. Dust tank lid: Open to access the foam lter.

4. Dust separator: Separates dust from air coming in.

5. Side door: Open to remove dirt from the dust separator.

6. Prevention tab: Prevents the lid from closing without a foam lter

installed.

7. Dust tank: Where dirt is collected.

8. Bottom plate: Open to empty the dust tank.

y Electrical shock and personal injury hazard.

y Take care when wrapping the cord. Wrapping the cord too tightly

puts stress on the cord and can cause cord damage. Do not

crisscross when wrapping the cord. A damaged cord could cause

an electrical shock hazard, personal injury or damage.

WARNING

1. Filter frame

2. Foam lter

3. Dust tank

lid

4. Dust separator

5. Side door

6. Prevention

Tab

7. Dust tank

8. Bottom plate

ENGLISH

CARE & CLEANING

Emptying the Dust Tank

Electrical shock and personal injury hazard.

Always unplug the power cord from the electrical outlet

before servicing or performing maintenance on the vacuum

cleaner. Failure to do so could result in electrical shock or

personal injury.

WARNING

For

maximum

performance,

always

empty

the

dust

tank

when

the

dirt

level

reaches

the

MAX

line.

TO REMOVE THE DUST TANK

Press

the

dust

tank

release,

tilt

the

dust

tank

back,

then

lift

out

the

vacuum

cleaner.

TO EMPTY DUST TANK

Press

the

dirt

release

and

open

the

bottom

plate,

shown.

TO REINSTALL THE DUST TANK

Place

the

dust

tank

the

holder,

and

tilt

forward

until

clicks

into

place.

Make

sure

that

the

dust

tank

properly

seated.

Cleaning the Dust Tank

For

optimal

performance,

clean

the

dust

tank

regularly.

To Clean the Dust Tank:

Remove

the

dust

tank

from

the

vacuum

cleaner.

Press

the

emptying

dirt

release

and

open

the

bottom

plate.

Wipe

out

the

dust

tank

with

soft

cloth

paper

towel.

Release

the

latch

the

side

door

both

the

right

and

left

sides.

Remove

any

hair,

bers

other

debris

from

the

dust

separator.

not

remove

the

cones

attached

the

side

door

for

cleaning.

NEVER operate the vacuum cleaner with wet lters or com

ponents.

not

touch

the

inner

gear

and

button

ENGLISH

CARE & CLEANING

Cleaning the Foam Filter

For optimal performance, check the lters every month and clean

when necessary. Don’t close the dusk tank lid without the foam

lter.

To clean the foam ﬁlter:

1. Remove the dusk tank from the vacuum cleaner.

2. Lift up on the dust tank lid release and open the lid.

y A wet lter can cause permanent damage to the

vacuum cleaner.

y Be sure lters are completely dry before reinstalling.

CAUTION

3. Lift out the foam lter.

4. Separate the foam lter from the lter frame.

5. Shake out any excess dirt or debris and rinse the foam lter and lter

frame with clean water. Squeeze out water from the foam lter.

6. Dry completely away from sunlight.

NEVER operate the vacuum cleaner with wet lters or

components.

If you notice a loss of suction and cleaning the foam lter does not

help, you may need to replace the foam lter. You can purchase

additional foam lters from LG by calling 1-800-243-0000 (U.S.A.),

1-888-542-2623 (Canada) and asking for parts on page 6.

Cleaning the HEPA Filter

To Clean the HEPA Filter:

1. Remove the exhaust lter cover.

Exhaust Filter

Cover

2. Remove the lter from the body.

3. Wash the lter thoroughly in owing water.

4. Remove moisture.

5. Dry completely away from sunlight.

Filter

ENGLISH

CARE & CLEANING

Cleaning the Foam Filter

For optimal performance, check the lters every month and clean

when necessary. Don’t close the dusk tank lid without the foam

lter.

To clean the foam ﬁlter:

1. Remove the dusk tank from the vacuum cleaner.

2. Lift up on the dust tank lid release and open the lid.

y A wet lter can cause permanent damage to the

vacuum cleaner.

y Be sure lters are completely dry before reinstalling.

CAUTION

3. Lift out the foam lter.

4. Separate the foam lter from the lter frame.

5. Shake out any excess dirt or debris and rinse the foam lter and lter

frame with clean water. Squeeze out water from the foam lter.

6. Dry completely away from sunlight.

NEVER operate the vacuum cleaner with wet lters or

components.

If you notice a loss of suction and cleaning the foam lter does not

help, you may need to replace the foam lter. You can purchase

additional foam lters from LG by calling 1-800-243-0000 (U.S.A.),

1-888-542-2623 (Canada) and asking for parts on page 6.

Cleaning the HEPA Filter

To Clean the HEPA Filter:

1. Remove the exhaust lter cover.

Exhaust Filter

Cover

2. Remove the lter from the body.

3. Wash the lter thoroughly in owing water.

4. Remove moisture.

5. Dry completely away from sunlight.

Filter

ENGLISH

CARE & CLEANING

Pet Hair Turbine Tool

To clean the pet hair turbine tool:

1. Remove the four screws on the bottom of the pet hair turbine tool.

2. Lift o the cover.

3. Remove any debris.

To reassemble:

4. Carefully press the cover onto the tabs until they snap into place.

5. Insert and tighten the screws that were removed in step 1. Do NOT

overtighten the screws.

y Electrical shock and personal injury hazard.

y Always unplug the power cord from the electrical outlet

before servicing. Failure to do so could result in electrical

shock or personal injury.

WARNING

y Electrical shock and personal injury hazard.

y Always unplug the power cord from the electrical outlet

before servicing.

y Failure to do so could result in electrical shock or personal

injury.

WARNING

Do Not use the pet hair turbine tool on animals.

Agitator Maintenance

Frequently check the agitator brush area for hair, string and line buildup.

Remove the Agitator Brush Cover:

1. Unplug the vacuum cleaner. Press the left foot pedal to release the

head. Lower the handle until the vacuum cleaner is lying at on the

oor.

2. Turn the vacuum cleaner so that the agitator is facing up.

3. Set the head on a cloth or a smooth surface. Remove the six screws on

the bottom of the head and remove the cover.

4. Carefully remove any accumulated string, hair, etc. from the agitator

and the agitator area.

To reinstall the cover, reverse the steps above.

Replacing the Agitator Belt

If the belt breaks, follow the steps below to replace the agitator belt.

To Replace the Belt:

1. Remove the agitator brush cover.

2. Lift the agitator straight out.

3. Unhook the old belt from the drive pulley. Make sure no pieces of the

broken belt are trapped in the agitator or drive pulley area.

4. Hook the new belt over the drive pulley of the agitator motor.

ENGLISH

y Electrical shock and personal injury hazard.

y Always unplug the power cord from the electrical outlet

before servicing.

y Failure to do so could result in electrical shock or personal

injury.

WARNING

CARE & CLEANING

5. Fit the agitator through the belt, making sure the belt is aligned with

the pulley section of the agitator.

6. Lower the agitator into place, making sure that the oval shaped tabs t

into the indents on the head.

7. Reinstall the agitator brush cover as described above.

For a replacement belt, order LG service center belt part

#MAS62064002.

Removing Clogs

If you notice a loss in suction, rst check the lters as described on page

13. If the lters are clean, there may be a clog. The arrows show areas

where clogs are most likely to occur.

To Check for Clogs:

1. Check the hose where it connects to the handle by pressing the two

release buttons on the top end of the hose.

2. Remove the dust tank and check the dust tank inlet and body inlet

where it connects to the vacuum cleaner body.

ENGLISH

CARE & CLEANING

3. Check the hose where it connects to the back of the body by pressing

the release buttons on the bottom end of the hose.

4. Turn the vacuum cleaner over and check the agitator inlet.

Cleaning the Exterior of the Vacuum

Cleaner

Wipe the exterior of the vacuum cleaner with a clean, soft cloth that has

been dipped in water and wrung dry.

DO NOT allow water to enter any openings in the vacuum cleaner.

DO NOT clean tools in dishwasher or clothes washer. Wash tools in warm

soapy water, rinse and allow to air dry completely.

DO NOT use tools if they are wet.

y Electrical shock and personal injury hazard.

y Always unplug the power cord from the electrical outlet

before servicing. Failure to do so could result in electrical

shock or personal injury.

WARNING

5. To check more thoroughly, remove the screw on the port.

ENGLISH

y Electrical shock and personal injury hazard.

y Always unplug the power cord from the electrical outlet before servicing. Failure to do so could result in electrical shock or personal

injury.

WARNING

TROUBLESHOOTING

Problem Possible Causes Solutions

Vacuum cleaner will not run. Vacuum unplugged at wall outlet. Make sure cord is plugged into a functioning outlet.

Agitator motor overload protection. Unplug the vacuum cleaner and check the agitator for

obstructions and reset the unit.

Thermal protector activated. Allow the vacuum cleaner to cool down.

Poor dirt pickup. Full or clogged dust tank. Empty dust tank and clean lters.

Dust tank improperly installed. Make sure all dust tank components and lters are installed

correctly.

Clogged hose, wand or head. Check for clogs.

Belt broken/not installed properly. Check belt and replace if needed.

Agitator motor overload protection activated. Unplug the vacuum cleaner and check the agitator for

obstructions. Press the reset button.

Hole in hose. Inspect hose carefully. Replace if needed.

Worn agitator. Contact service.

Agitator does not turn Switch is o (unit is in oor mode). Turn on agitator power switch.

Cleaner is in upright position. Press the body release and tilt until back.

Agitator motor overload protection is tripped (brush

is jammed).

Unplug the vacuum cleaner and check the agitator for

obstructions and reset the unit.

Belt is broken. Replace belt.

Dust escapes the dust tank. Dust tank improperly installed. Make sure all dust tank components and lters are installed

correctly.

The dust tank lid is not closed. Check the

dust tank lid.

The bottom plate is not latched. Make sure the bottom plate is closed and latched.

Agitator on pet hair turbine

tool will not run when

attached.

Dirty agitator or agitator supports. Clean the inside of the pet hair turbine tool.

Obstruction in turbine air path. Clean the inside of the pet hair turbine tool.

Low suction from vacuum cleaner. Check for clogs.

Accessory has no suction

when using with the handle.

Main wand still connected to body base. Remove wand.

Dust tank feels loose when

lifting by the carry handle.

This is normal. The vacuum is designed like this to prevent the tank from

separating

Review this section to nd do-it-yourself solutions for minor performance problems. Any service or repair needed, other than as described in this owner’s

manual, should be performed through your local LGE service center.

P/NO : MFL67230701 www.lg.com

MANUAL DEL PROPIETARIO

ASPIRADORA

Por favor, lea atentamente este manual antes de operar su

aparato y guárdelo para futuras referencias.

ESPAÑOL

LuV350P*

P/NO : MFL67230701 www.lg.com

OWNER’S MANUAL

VACUUM CLEANER

Please read this owner's manual thoroughly before

operating and keep it handy for reference at all times.

ENGLISH

ESPAÑOL

LuV350P*

FRANÇAIS

ESPAÑOL

ÍNDICE

23 GARANTÍA DE LA ASPIRADORA

24 INFORMACIÓN IMPORTANTEDE SE-

GURIDAD

26 PIEZAS Y CARACTERÍSTICAS

ARMADO

27 Cómo desembalar la aspiradora

27 Piezas de montaje

27 Colocación de la vara

28 Conexión de la manguera

28 Guardado de accesorios

28 Guardado del cable

29 OPERACIÓN

29 Desbloqueo de la vara

29 Desbloqueo del cuerpo de la aspiradora

30 Accesorios

30 Cuadro de uso de accesorios

31 Uso de la vara

31 Instalación de los accesorios

31 Consejos y trucos

32 Uso del accesorio de turbina para remover pelos

de mascotas

32 Escaleras y rellanos

32 Uso de la vara

32 Protección contra sobrecarga del motor del

agitador

32 Protección de sobrecarga térmica

33 CUIDADO Y LIMPIEZA

33 Cómo guardar la aspiradora

33 Componentes del tanque de polvo

34 Vaciado del tanque de polvo

34 Limpieza del tanque de polvo

35 Limpieza del filtro de espuma

35 Limpieza del filtro HEPA

36 Accesorio de turbina para remover pelos de

mascotas

36 Mantenimiento del agitador

36 Reemplazo de la correa del agitador

37 Eliminación de obstrucciones

38 Limpieza del exterior de la aspiradora

39 RESOLUCIÓN DE PROBLEMAS

ESPAÑOL

ÍNDICE

23 GARANTÍA DE LA ASPIRADORA

24 INFORMACIÓN IMPORTANTEDE SE-

GURIDAD

26 PIEZAS Y CARACTERÍSTICAS

ARMADO

27 Cómo desembalar la aspiradora

27 Piezas de montaje

27 Colocación de la vara

28 Conexión de la manguera

28 Guardado de accesorios

28 Guardado del cable

29 OPERACIÓN

29 Desbloqueo de la vara

29 Desbloqueo del cuerpo de la aspiradora

30 Accesorios

30 Cuadro de uso de accesorios

31 Uso de la vara

31 Instalación de los accesorios

31 Consejos y trucos

32 Uso del accesorio de turbina para remover pelos

de mascotas

32 Escaleras y rellanos

32 Uso de la vara

32 Protección contra sobrecarga del motor del

agitador

32 Protección de sobrecarga térmica

33 CUIDADO Y LIMPIEZA

33 Cómo guardar la aspiradora

33 Componentes del tanque de polvo

34 Vaciado del tanque de polvo

34 Limpieza del tanque de polvo

35 Limpieza del filtro de espuma

35 Limpieza del filtro HEPA

36 Accesorio de turbina para remover pelos de

mascotas

36 Mantenimiento del agitador

36 Reemplazo de la correa del agitador

37 Eliminación de obstrucciones

38 Limpieza del exterior de la aspiradora

39 RESOLUCIÓN DE PROBLEMAS

ESPAÑOL

GARANTÍA (EE. UU.)

LG Electronics Inc. reparará o reemplazará su producto, a discreción de LG, si llegara a encontrar defectos en los materiales o defectos de fabricación en

condiciones de uso personal y doméstico de la aspiradora, durante el período de la garantía que se indica a continuación, en vigencia a partir de la fecha de

compra original del producto por parte del consumidor. Esta garantía limitada es válida únicamente para el comprador original del producto, y solo si éste

se usa en EE. UU. o Canadá.

PERÍODO DE VIGENCIA DE LA GARANTÍA CÓMO SE MANEJA EL SERVICIO

Cinco años

A partir de la fecha original de compra

Cualquier pieza de la aspiradora que falle por algún defecto en los materiales o de fabricación. Du-

rante este período de vigencia de la garantía de cinco años, LG cubrirá también, y sin cargo,todo

servicio y trabajo realizado para reemplazar la pieza defectuosa.

ESTA GARANTÍA SE BRINDA EN LUGAR DE OTRAS GARANTÍAS, EXPRESAS O IMPLÍCITAS, QUE INCLUYEN, ENTRE OTRAS, CUALQUIER GARANTÍA DE

COMERCIABILIDAD O IDONEIDAD PARA UN FIN PARTICULAR. EN LA MEDIDA EN QUE LA LEY EXIJA UNA DETERMINADA GARANTÍA IMPLÍCITA, SU

DURACIÓN SE LIMITA AL PERÍODO DE GARANTÍA EXPRESO MENCIONADO ANTERIORMENTE. LG NO SERÁ RESPONSABLE DE DAÑOS CONSECUEN-

TES, INDIRECTOS O INCIDENTALES DE NINGUNA ÍNDOLE, INCLUSO LA PÉRDIDA DE INGRESOS O GANANCIAS, RELACIONADAS CON EL PRODUCTO.

ALGUNOS ESTADOS NO AUTORIZAN LIMITACIONES DEL PERÍODO DE VIGENCIA DE UNA GARANTÍA IMPLÍCITA NI LA EXCLUSIÓN DE DAÑOS INCI-

DENTALES O CONSECUENTES, POR LO QUE ES POSIBLE QUE LAS LIMITACIONES O EXCLUSIONES ANTERIORES NO SE APLIQUEN A SU CASO.

ESTA GARANTÍA CUBRE SÓLO DEFECTOS DE MATERIALES Y FABRICACIÓN. LGE NO PAGARÁ LO SIGUIENTE:

1. Los bienes desechables que pueden gastarse, como los ltros y las correas, entre otros.

2. Un técnico de servicio para instruir al usuario sobre el armado, el funcionamiento o el mantenimiento correctos del producto.

3. Un técnico de servicio para limpiar o mantener este producto.

4. Por daños al producto o fallas de este producto si no se lo ha armado, operado o mantenido de acuerdo con todas las instrucciones suministradas con

producto.

5. Por daños al producto o fallas de este producto que resultasen de accidentes, abuso, mal uso o usos que no sean aquellos para los que fue diseñado el

producto.

6. Por daños al producto o fallas de este producto causadas por el uso de detergentes, limpiadores, sustancias químicas o utensilios que no sean los reco-

mendados en todas las instrucciones suministradas con este producto.

7. Por daños a piezas o sistemas, o fallas en ellos, que resultasen de modicaciones no autorizadas realizadas en este producto.

Esta garantía se extiende al comprador original para productos comprados para uso doméstico dentro de EE. UU. En Alaska, la garantía excluye el costo de

envío o de visitas de servicio a domicilio.

Algunos estados no permiten la exclusión o limitación de daños incidentales o consecuentes, por lo que es posible que esta limitación no se aplique a su

caso. Esta garantía le otorga derechos legales especícos y es posible que usted cuente con otros derechos que pueden variar de un estado a otro. Para

conocer sus derechos legales, consulte a su ocina de asuntos de consumidores local o estatal o al procurador general de su estado.

INFORMACIÓN DE ASISTENCIA A CLIENTES:

Para probar la cobertura de la garantía: Conserve su recibo de compra para comprobar la fecha de compra.

Deberá presentar una copia del recibo de compra cuando

se le brinde el servicio

técnico cubierto por la garantía.

Para averiguar cuál es el centro de servicios o el distribuidor

autorizado más cercano, o para recibir asistencia del producto,

cliente o servicio,

llame al 1-800-243-0000 (las 24 horas del día, los 365 días del año) y elija la opción

correspondiente del menú. También puede visitar nuestro sitio web http://www.lg.com

(En Canadá, llame al 1-888-542-2623 o visite http://www.lg.com)

GARANTÍA

ESPAÑOL

ÍNDICE

23 GARANTÍA DE LA ASPIRADORA

24 INFORMACIÓN IMPORTANTEDE SE-

GURIDAD

26 PIEZAS Y CARACTERÍSTICAS

ARMADO

27 Cómo desembalar la aspiradora

27 Piezas de montaje

27 Colocación de la vara

28 Conexión de la manguera

28 Guardado de accesorios

28 Guardado del cable

29 OPERACIÓN

29 Desbloqueo de la vara

29 Desbloqueo del cuerpo de la aspiradora

30 Accesorios

30 Cuadro de uso de accesorios

31 Uso de la vara

31 Instalación de los accesorios

31 Consejos y trucos

32 Uso del accesorio de turbina para remover pelos

de mascotas

32 Escaleras y rellanos

32 Uso de la vara

32 Protección contra sobrecarga del motor del

agitador

32 Protección de sobrecarga térmica

33 CUIDADO Y LIMPIEZA

33 Cómo guardar la aspiradora

33 Componentes del tanque de polvo

34 Vaciado del tanque de polvo

34 Limpieza del tanque de polvo

35 Limpieza del filtro de espuma

35 Limpieza del filtro HEPA

36 Accesorio de turbina para remover pelos de

mascotas

36 Mantenimiento del agitador

36 Reemplazo de la correa del agitador

37 Eliminación de obstrucciones

38 Limpieza del exterior de la aspiradora

39 RESOLUCIÓN DE PROBLEMAS
