INSTRUCTION MANUAL
Built-in oven
B57CR22.0
Loading ...
Loading ...
Loading ...
1
2
3
4
5
6
>
Summary of Contents for Neff B57CR22N0/01:
[en] Instruction manual
1
Table of contents
3
[en] Instruction manual
3
( Important safety information 5
3
] Causes of damage 6
3
7 Environmental protection 7
3
* Getting to know your appliance 8
3
_ Accessories 10
3
K Before using for the first time 12
3
1 Operating the appliance 13
3
O Time-setting options 15
3
A Childproof lock 16
3
Q Basic settings 17
3
F Sabbath mode 18
3
D Cleaning agent 18
3
. Cleaning function 20
3
p Rails 22
3
q Appliance door 22
3
3 Trouble shooting 25
3
4 Customer service 26
3
J Tested for you in our cooking studio 27
3
8 Intended use
4
Intended use
4
( Important safety information
5
Important safety information
5
General information
5
: Warning
5
Risk of fire!
5
: Warning
5
Risk of burns!
5
: Warning
5
Risk of scalding!
5
: Warning
5
Risk of injury!
5
: Warning
5
Risk of electric shock!
5
: Warning
5
Hazard due to magnetism!
5
Halogen lamp
5
: Warning
5
Risk of electric shock!
5
Cleaning function
6
: Warning
6
Risk of fire!
6
: Warning
6
Risk of serious damage to health!
6
: Warning
6
Risk of burns!
6
] Causes of damage
6
Causes of damage
6
General information
6
Caution!
6
7 Environmental protection
7
Environmental protection
7
Saving energy
7
Environmentally-friendly disposal
7
* Getting to know your appliance
8
Getting to know your appliance
8
Note:
8
Control panel
8
Controls
8
Touch buttons
8
Touch button
8
Use
8
ShiftControl control
9
Button
9
Use
9
Note:
9
Main menu
9
Menu
9
Use
9
Menu for the types of heating
9
Type of heating
9
Temperature
9
Use
9
--------
9
Cooking compartment functions
10
Opening the appliance door
10
Note:
10
Interior lighting
10
Note:
10
Cooling fan
10
Caution!
10
Note:
10
_ Accessories
10
Accessories
10
Accessories included
10
Note:
10
Inserting accessories
10
Notes
10
Locking function
11
Combining accessories
11
Optional accessories
11
Note:
11
Accessories
11
Order number
11
K Before using for the first time
12
Before using for the first time
12
Initial use
12
Setting the language
12
1. Use the & button to navigate to the bottom line.
12
2. Use the ( or ) button to select the language.
12
3. Use the % button to return to "Language".
12
4. Use the ) button to select the next setting.
12
Setting the time
12
1. Use the & button to navigate to the next line.
12
2. Use the ( or ) button to select the current time.
12
3. Press the % button.
12
4. Use the ) button to select the next setting.
12
Setting the date
12
1. Use the & button to navigate to the next line.
12
2. Use the ( or ) button to select the current day.
12
3. Use the % button to return to "Day".
12
4. Use the ) button to select the next setting.
12
5. Use the & button to navigate to the next line.
12
6. Use the ( or ) button to select the current month.
12
7. Use the % button to return to "Month".
12
8. Use the ) button to select the next setting.
12
9. Use the & button to navigate to the next line.
12
10. Use the ( or ) button to select the current year.
12
11. Use the % button to return to "Year".
12
12. Use the ) button to apply the settings.
12
Notes
12
Cleaning the cooking compartment
12
1. Remove the accessories from the cooking compartment.
12
2. Remove leftover packaging, such as polystyrene pellets, from the cooking compartment.
12
3. Before heating the appliance, wipe the smooth surfaces in the cooking compartment with a soft, wet cloth.
12
4. Use the # touch button to switch on the appliance.
12
5. Set the heating type and temperature, then start the appliance operation. ~ "Setting and starting the appliance operation" on page 13
12
Settings
12
6. Keep the kitchen ventilated while the appliance is heating up.
12
7. Use the # touch button to switch off the appliance after the indicated cooking time.
12
8. Wait until the cooking compartment has cooled down.
12
9. Clean the smooth surfaces with soapy water and a dish cloth.
12
Cleaning the accessories
12
1 Operating the appliance
13
Operating the appliance
13
Switching the appliance on and off
13
Display
13
Meaning
13
Notes
13
Setting and starting the appliance operation
13
1. Touch the # touch button to switch on the appliance.
13
2. Use the ( or ) button to select the type of heating.
13
3. Use the & button to navigate to the next line.
13
4. Use the ( or ) button to select the temperature.
13
Note:
13
5. Touch the # touch button to start the appliance operation.
13
Note:
13
Default values
13
Heating bar
13
Run time
13
Displaying the current temperature
13
Further information
13
Changing or cancelling the appliance operation
14
Changing the appliance operation
14
1. Use the # button to stop the operation.
14
2. Use the & or % button to navigate to the line for the setting that should be changed.
14
3. Use the ( or ) button to change the setting.
14
4. Use the # touch button to start the changed operation.
14
Notes
14
Note:
14
Heating up the appliance quickly
14
Function
14
Type of heating
14
Place the food in the cooking compartment
14
Notes
14
Activating the "Rapid heat-up" function
14
1. Set top/bottom heating ƒ and the temperature.
14
Note:
14
2. Touch the # touch button to start the appliance operation.
14
3. Touch the ° touch button to activate the "Rapid heat-up" function.
14
4. Once the set temperature has been reached, the "Rapid heat-up" function switches itself off automatically. The ° symbol disappears from the display. Place the food in the cooking compartment
14
Activating the "PowerBoost" function
14
1. Set CircoTherm hot air ‚ or the bread baking setting … and the temperature.
14
Note:
14
2. Place the food on a single level in the cooking compartment.
14
3. Touch the # touch button to start the appliance operation.
14
4. Touch the ° touch button to activate the "PowerBoost" function.
14
O Time-setting options
15
Time-setting options
15
Time-setting option
15
Use
15
Note:
15
Showing and hiding the time-setting options
15
Note:
15
Setting the timer
15
1. Touch the 0 touch button.
15
2. Select the cooking time using the ) button.
15
Note:
15
3. Touch the 0 touch button to start the timer.
15
Note:
15
Setting the cooking time
15
1. Touch the # touch button.
15
2. Set the type of heating and temperature.
15
3. Touch the 0 touch button.
15
4. Use the ( or ) button to set the cooking time.
15
5. Touch the # touch button to start the set cooking time.
15
Start delay – "Ready at"
15
Notes
15
1. Slide food into the cooking compartment on a suitable accessory and close the appliance door.
15
2. Touch the # touch button.
15
3. Set the type of heating and temperature.
15
4. Touch the 0 touch button.
15
5. Select the cooking time using the ) button.
15
6. Use the & button to navigate to the "* Ready at" line.
15
7. Select the end time using the ) button.
15
8. Touch the # touch button.
15
Checking, changing or deleting settings
15
1. Touch the 0 touch button.
15
2. Use the & or % button to navigate through the lines.
15
3. If necessary, change the setting using the ( or ) button. Set "00:00" to delete a time function.
15
A Childproof lock
16
Childproof lock
16
Lock
16
Activate/deactivate
16
Note:
16
Automatic childproof lock
16
Activating
16
1. Touch the ± touch button.
16
2. Touch the 0 touch button.
16
3. Use the ( or ) button to select the "Settings".
16
4. Use the & button to navigate to the next line.
16
5. Use the ( or ) button to select "Automatic childproof lock".
16
6. Use the & button to navigate to the next line.
16
7. Use the ( or ) button to select "Activated".
16
8. Touch the 0 touch button.
16
9. Use the & button to navigate to the next line to save the setting.
16
Cancelling
16
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
2. Touch the ± touch button.
16
3. Switch on the required appliance operation.
16
Deactivating
16
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
2. Touch the ± touch button.
16
3. Touch the 0 touch button.
16
4. Use the ( or ) button to select the "Settings".
16
5. Use the & button to navigate to the next line.
16
6. Use the ( or ) button to select "Automatic childproof lock".
16
7. Use the & button to navigate to the next line.
16
8. Use the ( or ) button to select "Deactivated".
16
9. Touch the 0 touch button.
16
10. Use the & button to navigate to the next line to save the setting.
16
11. Touch the ± touch button.
16
One-time childproof lock
16
Activating and deactivating
16
1. Press and hold the 0 touch button until "Childproof lock activated" appears on the display.
16
2. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
Q Basic settings
17
Basic settings
17
Changing the basic settings
17
1. Touch the # touch button.
17
2. Touch the 0 touch button.
17
3. Use the ( or ) button to select the "" Settings".
17
4. Use the & button to navigate to the next line.
17
5. Use the ( or ) button to select the setting.
17
6. Use the & button to navigate to the next line.
17
7. Use the ( or ) button to select the setting.
17
8. Touch the 0 touch button.
17
9. To save the setting, use the & button to select "Save".
17
List of basic settings
17
Setting
17
Selection
17
Setting favourites
17
Note:
17
1. Touch the # touch button.
17
2. Touch the 0 touch button.
17
3. Use the ( or ) button to select the "" Settings".
17
4. Use the & button to navigate to the next line.
17
5. Use the ( or ) button to select "Favourites".
17
6. Use the & button to navigate to the next line.
17
7. Use the ( or ) button to select the type of heating.
17
8. Use the & button to navigate to the next line.
17
9. Use the ( or ) button to select "Activated" or "Deactivated".
17
Note:
17
10. Touch the 0 touch button.
17
11. To save the setting, use the & button to select "Save".
17
F Sabbath mode
18
Sabbath mode
18
Starting Sabbath mode
18
1. Touch the # touch button.
18
2. Use the ( or ) button to select "Sabbath mode".
18
3. Use the & button to navigate to the next line.
18
4. Use the ( or ) button to select the temperature.
18
5. Use the & button to navigate to the next line.
18
6. Use the ( or ) button to select the cooking time.
18
7. Touch the # touch button.
18
Notes
18
Cancelling Sabbath mode
18
D Cleaning agent
18
Cleaning agent
18
Suitable cleaning agents
18
Caution!
18
Risk of surface damage
18
Tip:
18
: Warning
18
Risk of burns!
18
Area
18
Cleaning
18
Notes
19
Keeping the appliance clean
19
Tips
19
. Cleaning function
20
Cleaning function
20
Self-cleaning
20
Setting
20
Cleaning level
20
Duration
20
Note:
20
: Warning
20
Risk of burns!
20
Prior to initiating the cleaning function
20
Note:
20
: Warning
20
Risk of fire!
20
: Warning
20
Risk of serious damage to health!
20
Starting
20
1. Touch the # touch button.
20
2. Touch the 0 touch button.
20
3. Use the ( or ) button to select "Self-cleaning ˜".
20
4. Use the & button to navigate to the next line.
20
5. Use the ( or ) button to select the cleaning setting.
20
Note:
20
6. Use the & button to navigate to the next line.
20
7. Touch the # touch button.
20
Note:
20
Cancelling
20
Finishing
20
Once the cleaning function has ended
20
EasyClean
21
: Warning
21
Risk of scalding!
21
Starting
21
Notes
21
1. Remove the accessories from the cooking compartment.
21
2. Mix 0.4 litres of water (not distilled water) with a drop of washing-up liquid and pour into the middle of the cooking compartment floor.
21
3. Touch the # touch button.
21
4. Touch the 0 touch button.
21
5. Use the ( or ) button to select "EasyClean š".
21
6. Use the & button to navigate to the next line.
21
7. Touch the # touch button.
21
Finishing
21
Final cleaning
21
1. Open the appliance door and remove the remaining water with an absorbent sponge cloth.
21
2. Clean the smooth surfaces in the cooking compartment with a dish cloth or a soft brush. Stubborn residues can be removed using a stainless steel scouring pad.
21
3. Remove limescale with a cloth soaked in vinegar. Then wipe with clean water and rub dry with a soft cloth (including under the door seal).
21
4. Use the # touch button to switch off the appliance.
21
5. Leave the appliance door ajar in the locking position (approx. 30°) for approx. 1 hour to allow the enamel surfaces in the cooking compartment to dry. Alternatively, you can also run the rapid drying function for the cooking compartment.
21
Running the rapid drying function for the cooking compartment
21
1. After the cleaning aid process has finished, leave the appliance door ajar in the locking position (approx. 30°).
21
2. Touch the # touch button.
21
3. Start CircoTherm hot air at 50 °C.
21
4. After 5 minutes, switch off the appliance and close the appliance door.
21
Removing heavy deposits of dirt
21
p Rails
22
Rails
22
Detaching and refitting the rails
22
: Warning
22
Risk of burns!
22
Detaching the rails
22
1. Lift the rail slightly at the front ‚ and detach it ƒ (figure !).
22
2. Then pull the whole rail towards you and take it out (figure ").
22
Attaching the rails
22
1. First, insert the rail in the middle of the rear socket ‚, until the rail rests against the cooking compartment wall, and push it back ƒ (figure !).
22
2. Then insert the rail into the front socket „, until the rail also rests against the cooking compartment wall here, and press it downwards … (figure ").
22
q Appliance door
22
Appliance door
22
Removing and fitting the appliance door
22
: Warning
22
Risk of injury!
22
: Warning
22
Risk of injury!
22
Removing the appliance door
22
1. Open the left- and right-hand hinge lock (Fig. !).
22
Tip:
22
2. Open the appliance door a little (Fig. %).
22
3. Using a coin, fully turn both the left- and right-hand locks on the inside of the appliance at the bottom (Fig. &).
23
4. Close the appliance door a little, until you feel the locks engage.
23
5. Lift the door handle slightly on the left- and right- hand side using both thumbs ‚ and pull the appliance door out upwards ƒ (Fig. ').
23
6. Lay the appliance door on an even, soft and clean surface.
23
Fitting the appliance door
23
1. Fit the appliance door (Fig. !).
23
2. Fit the appliance door in the left and right-hand guide rollers simultaneously (Fig. ").
23
3. Turn the door handle upwards slightly ‚ so that the appliance door slides downwards fully ƒ (Fig. #).
23
4. Use a coin to release both locks on the appliance door (Fig. $).
23
5. Open the appliance door a little wider and then close it.
23
: Warning
23
Risk of injury from hinge locks which have not been properly closed!
23
6. Close the left- and right-hand hinge locks (Fig. %).
23
Removing and installing the door panels
23
: Warning
23
Risk of injury!
23
: Warning
23
Risk of injury!
23
Removal
24
Note:
24
1. Remove the appliance door.
24
2. Lay the appliance door with the front side facing down on an even, soft and clean surface.
24
3. Push on the left- and right-hand side on the outside of the appliance door until the inner glass is released on both sides (Fig. !).
24
4. Carefully lift the inner glass and remove it in the direction of the arrow (Fig. ").
24
5. Push the intermediate panel downwards in the ‚ area, carefully lift the ƒ holder until it can be pulled out (Fig. #).
24
6. Lift the first and second intermediate panels from below (Fig. $) and remove them in the direction of the arrow (Fig. %).
24
7. If required, remove the spacers (Fig. &) and seals (Fig. ') for cleaning.
24
8. Clean the door panels on both sides with glass cleaner and a soft cloth.
24
: Warning
24
Risk of injury!
24
9. Dry and refit the door panels.
24
Installation
24
Note:
24
1. Insert the intermediate glass so that the ‚ arrow is facing upwards on the right-hand side (Fig. !).
24
2. Check the fit of the four spacers and two seals on the intermediate panel:
24
3. Insert the intermediate panel with the seals and spacers. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. $).
24
4. Insert the second intermediate panel without the seals and spacers and push it in the direction of the arrow until it is fitted in the frame. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. %).
24
5. Push the intermediate panel downwards in the ƒ area, insert the „ holder at an angle and push down until it locks into place (Fig. &).
25
6. Insert the inner glass into the mounting rail … at an angle towards the back (Fig. ().
25
7. Push the inner glass downwards until it locks into place (Fig. )).
25
3 Trouble shooting
25
Trouble shooting
25
Tip:
25
: Warning
25
Risk of electric shock!
25
Fault table
25
: Warning
25
Risk of electric shock!
25
Fault
25
Possible cause
25
Notes/remedy
25
--------
25
Maximum operating time exceeded
26
Replacing the bulb in the top of the cooking compartment
26
: Warning
26
Risk of electric shock!
26
: Warning
26
Risk of burns!
26
1. Place a tea towel in the cold cooking compartment to prevent damage.
26
2. Turn the glass cover anti-clockwise to remove it (figure !).
26
3. Pull out the bulb – do not turn it (figure "). Insert the new bulb, making sure that the pins are in the correct position. Push the bulb in firmly.
26
4. Screw the glass cover back in.
26
5. Remove the tea towel and switch on the circuit breaker.
26
Glass cover
26
4 Customer service
26
Customer service
26
E number and FD number
26
To book an engineer visit and product advice
26
J Tested for you in our cooking studio
27
Tested for you in our cooking studio
27
Note:
27
Silicone moulds
27
Cakes and small baked items
27
Shelf positions
27
Accessories
27
Recommended setting values
28
Note:
28
Dish
28
Accessories/cookware
28
Shelf position
28
Type of heating
28
Temperature in °C
28
Cooking time in mins.
28
Tips on baking
30
Bread and rolls
31
Shelf positions
31
Accessories
31
Frozen products
31
Recommended setting values
31
Note:
31
Caution!
31
Dish
32
Accessories
32
Shelf position
32
Type of heating
32
Temperature in °C
32
Cooking time in mins.
32
Pizza, quiche and savoury cakes
33
Shelf positions
33
Accessories
33
Frozen products
33
Recommended setting values
33
Note:
33
Dish
34
Accessories
34
Shelf position
34
Type of heating
34
Temperature in °C
34
Cooking time in mins.
34
Bakes and soufflés
34
Shelf positions
34
Accessories
34
Recommended setting values
35
Note:
35
Bakes & soufflés
35
Accessories/cookware
35
Shelf position
35
Type of heating
35
Temperature in °C
35
Cooking time in mins.
35
Poultry
35
Roasting on the wire rack
35
Roasting in cookware
35
Grilling
36
Note:
36
Notes
36
Recommended setting values
36
Note:
36
Tips
36
Dish
36
Accessories/cookware
36
Shelf position
36
Type of heating
36
Temperature in °C
36
Cooking time in mins.
36
Meat
37
Roasting and braising
37
Roasting on the wire rack
37
Roasting and braising in cookware
37
Grilling
37
Note:
37
Notes
37
Recommended setting values
37
Dish
38
Accessories/cookware
38
Shelf position
38
Type of heating
38
Temperature in °C
38
Cooking time in mins.
38
Tips on roasting and braising
39
Fish
39
Roasting and grilling on the wire rack
39
Note:
39
Notes
39
Roasting and stewing in cookware
39
Recommended setting values
39
Note:
40
Dish
40
Accessories/cookware
40
Shelf position
40
Type of heating
40
Temperature in °C
40
Cooking time in mins.
40
Vegetables and side dishes
40
Shelf positions
40
Accessories
40
Recommended setting values
40
Dish
41
Accessories
41
Shelf position
41
Type of heating
41
Temperature in °C
41
Cooking time in mins.
41
Yogurt
41
Preparing yogurt
41
1. Heat 1 litre of milk (3.5 % fat) to 90 °C on the hob and then cool down to 40 °C.
41
2. Stir in 150 g (chilled) yogurt.
41
3. Pour into cups or small jars and cover with cling film.
41
4. Place the cups or jars onto the cooking compartment floor and use the settings indicated in the table.
41
5. After preparation, leave the yogurt to cool in the refrigerator.
41
Dish
41
Accessories
41
Shelf position
41
Type of heating
41
Temperature in °C
41
Cooking time in hours
41
Save energy with Eco heating types
41
Accessories
41
Recommended setting values
42
Note:
42
Dish
42
Accessories/cookware
42
Shelf position
42
Type of heating
42
Temperature in °C
42
Cooking time in mins.
42
Acrylamide in foodstuffs
43
Tips for keeping acrylamide to a minimum
43
Slow cook
43
Note:
43
Cookware
43
Recommended setting values
44
Dish
44
Cookware
44
Shelf position
44
Type of heating
44
Searing time in mins.
44
Temperature in °C
44
Cooking time in mins.
44
Tips for slow cooking
44
Drying
44
Recommended setting values
45
Fruit, vegetables and herbs
45
Accessories
45
Type of heating
45
Temperature in °C
45
Cooking time in hours
45
Preserving
45
: Warning
45
Risk of injury!
45
Jars
45
Preparing fruit and vegetables
45
Ending the preserving process
45
Recommended setting values
46
Preserving
46
Cookware
46
Shelf position
46
Type of heating
46
Temperature in °C
46
Cooking time in mins.
46
Allowing the dough to prove at dough proving setting
46
Caution!
46
Surface damage
46
Recommended setting values
46
Dish
46
Accessories/cookware
46
Shelf position
46
Type of heating
46
Step
46
Temperature in °C
46
Cooking time in mins.
46
Defrosting
47
Recommended setting values
47
Tip:
47
Dish
47
Accessories
47
Shelf position
47
Type of heating
47
Temperature in °C
47
Cooking time in mins.
47
Keeping warm
47
Test dishes
47
Baking
47
Notes
47
Dish
48
Accessories
48
Shelf position
48
Type of heating
48
Temperature in °C
48
Cooking time in mins.
48
Grilling
48
Dish
48
Accessories
48
Shelf position
48
Type of heating
48
Temperature in °C
48
Cooking time in mins.
48
File type: PDF
File name: 64594514_b57cr22n0-01.pdf
File size: 2.56 MB
File Language: English
Pages: 52
Author: Neff
Published: 2020-06-17
Updated: 2023-08-07
Download File
Specifications
Brand:
Neff
Model: B57CR22N0/01
Category:
Ovens
See other models:
K7791X0/15
B46C74N3/01
D69B21S0GB/01
S31M63W0EU/14
K8625X1IE/01
Photos
Download User Manual
Related Products
Neff B57CR22N0/40
Neff B57CR22N0/38
Neff B57CR22N0/35
Neff B57CR22N0/08
Neff B57CR22N0/71
Neff B57CR22N0/19
Neff B57CR22N0/63
Neff B57CR22N0/49
Neff B57CR22N0/24
Neff B57CR22N0/43
Neff B57CR22N0/30
Neff B57CR22N0/23
Neff B57CR22N0B
Neff B55CR22N0/30
Neff B55CR22N0/38
Table of Contents
×
[en] Instruction manual
1
Table of contents
3
[en] Instruction manual
3
( Important safety information 5
3
] Causes of damage 6
3
7 Environmental protection 7
3
* Getting to know your appliance 8
3
_ Accessories 10
3
K Before using for the first time 12
3
1 Operating the appliance 13
3
O Time-setting options 15
3
A Childproof lock 16
3
Q Basic settings 17
3
F Sabbath mode 18
3
D Cleaning agent 18
3
. Cleaning function 20
3
p Rails 22
3
q Appliance door 22
3
3 Trouble shooting 25
3
4 Customer service 26
3
J Tested for you in our cooking studio 27
3
8 Intended use
4
Intended use
4
( Important safety information
5
Important safety information
5
General information
5
: Warning
5
Risk of fire!
5
: Warning
5
Risk of burns!
5
: Warning
5
Risk of scalding!
5
: Warning
5
Risk of injury!
5
: Warning
5
Risk of electric shock!
5
: Warning
5
Hazard due to magnetism!
5
Halogen lamp
5
: Warning
5
Risk of electric shock!
5
Cleaning function
6
: Warning
6
Risk of fire!
6
: Warning
6
Risk of serious damage to health!
6
: Warning
6
Risk of burns!
6
] Causes of damage
6
Causes of damage
6
General information
6
Caution!
6
7 Environmental protection
7
Environmental protection
7
Saving energy
7
Environmentally-friendly disposal
7
* Getting to know your appliance
8
Getting to know your appliance
8
Note:
8
Control panel
8
Controls
8
Touch buttons
8
Touch button
8
Use
8
ShiftControl control
9
Button
9
Use
9
Note:
9
Main menu
9
Menu
9
Use
9
Menu for the types of heating
9
Type of heating
9
Temperature
9
Use
9
--------
9
Cooking compartment functions
10
Opening the appliance door
10
Note:
10
Interior lighting
10
Note:
10
Cooling fan
10
Caution!
10
Note:
10
_ Accessories
10
Accessories
10
Accessories included
10
Note:
10
Inserting accessories
10
Notes
10
Locking function
11
Combining accessories
11
Optional accessories
11
Note:
11
Accessories
11
Order number
11
K Before using for the first time
12
Before using for the first time
12
Initial use
12
Setting the language
12
1. Use the & button to navigate to the bottom line.
12
2. Use the ( or ) button to select the language.
12
3. Use the % button to return to "Language".
12
4. Use the ) button to select the next setting.
12
Setting the time
12
1. Use the & button to navigate to the next line.
12
2. Use the ( or ) button to select the current time.
12
3. Press the % button.
12
4. Use the ) button to select the next setting.
12
Setting the date
12
1. Use the & button to navigate to the next line.
12
2. Use the ( or ) button to select the current day.
12
3. Use the % button to return to "Day".
12
4. Use the ) button to select the next setting.
12
5. Use the & button to navigate to the next line.
12
6. Use the ( or ) button to select the current month.
12
7. Use the % button to return to "Month".
12
8. Use the ) button to select the next setting.
12
9. Use the & button to navigate to the next line.
12
10. Use the ( or ) button to select the current year.
12
11. Use the % button to return to "Year".
12
12. Use the ) button to apply the settings.
12
Notes
12
Cleaning the cooking compartment
12
1. Remove the accessories from the cooking compartment.
12
2. Remove leftover packaging, such as polystyrene pellets, from the cooking compartment.
12
3. Before heating the appliance, wipe the smooth surfaces in the cooking compartment with a soft, wet cloth.
12
4. Use the # touch button to switch on the appliance.
12
5. Set the heating type and temperature, then start the appliance operation. ~ "Setting and starting the appliance operation" on page 13
12
Settings
12
6. Keep the kitchen ventilated while the appliance is heating up.
12
7. Use the # touch button to switch off the appliance after the indicated cooking time.
12
8. Wait until the cooking compartment has cooled down.
12
9. Clean the smooth surfaces with soapy water and a dish cloth.
12
Cleaning the accessories
12
1 Operating the appliance
13
Operating the appliance
13
Switching the appliance on and off
13
Display
13
Meaning
13
Notes
13
Setting and starting the appliance operation
13
1. Touch the # touch button to switch on the appliance.
13
2. Use the ( or ) button to select the type of heating.
13
3. Use the & button to navigate to the next line.
13
4. Use the ( or ) button to select the temperature.
13
Note:
13
5. Touch the # touch button to start the appliance operation.
13
Note:
13
Default values
13
Heating bar
13
Run time
13
Displaying the current temperature
13
Further information
13
Changing or cancelling the appliance operation
14
Changing the appliance operation
14
1. Use the # button to stop the operation.
14
2. Use the & or % button to navigate to the line for the setting that should be changed.
14
3. Use the ( or ) button to change the setting.
14
4. Use the # touch button to start the changed operation.
14
Notes
14
Note:
14
Heating up the appliance quickly
14
Function
14
Type of heating
14
Place the food in the cooking compartment
14
Notes
14
Activating the "Rapid heat-up" function
14
1. Set top/bottom heating ƒ and the temperature.
14
Note:
14
2. Touch the # touch button to start the appliance operation.
14
3. Touch the ° touch button to activate the "Rapid heat-up" function.
14
4. Once the set temperature has been reached, the "Rapid heat-up" function switches itself off automatically. The ° symbol disappears from the display. Place the food in the cooking compartment
14
Activating the "PowerBoost" function
14
1. Set CircoTherm hot air ‚ or the bread baking setting … and the temperature.
14
Note:
14
2. Place the food on a single level in the cooking compartment.
14
3. Touch the # touch button to start the appliance operation.
14
4. Touch the ° touch button to activate the "PowerBoost" function.
14
O Time-setting options
15
Time-setting options
15
Time-setting option
15
Use
15
Note:
15
Showing and hiding the time-setting options
15
Note:
15
Setting the timer
15
1. Touch the 0 touch button.
15
2. Select the cooking time using the ) button.
15
Note:
15
3. Touch the 0 touch button to start the timer.
15
Note:
15
Setting the cooking time
15
1. Touch the # touch button.
15
2. Set the type of heating and temperature.
15
3. Touch the 0 touch button.
15
4. Use the ( or ) button to set the cooking time.
15
5. Touch the # touch button to start the set cooking time.
15
Start delay – "Ready at"
15
Notes
15
1. Slide food into the cooking compartment on a suitable accessory and close the appliance door.
15
2. Touch the # touch button.
15
3. Set the type of heating and temperature.
15
4. Touch the 0 touch button.
15
5. Select the cooking time using the ) button.
15
6. Use the & button to navigate to the "* Ready at" line.
15
7. Select the end time using the ) button.
15
8. Touch the # touch button.
15
Checking, changing or deleting settings
15
1. Touch the 0 touch button.
15
2. Use the & or % button to navigate through the lines.
15
3. If necessary, change the setting using the ( or ) button. Set "00:00" to delete a time function.
15
A Childproof lock
16
Childproof lock
16
Lock
16
Activate/deactivate
16
Note:
16
Automatic childproof lock
16
Activating
16
1. Touch the ± touch button.
16
2. Touch the 0 touch button.
16
3. Use the ( or ) button to select the "Settings".
16
4. Use the & button to navigate to the next line.
16
5. Use the ( or ) button to select "Automatic childproof lock".
16
6. Use the & button to navigate to the next line.
16
7. Use the ( or ) button to select "Activated".
16
8. Touch the 0 touch button.
16
9. Use the & button to navigate to the next line to save the setting.
16
Cancelling
16
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
2. Touch the ± touch button.
16
3. Switch on the required appliance operation.
16
Deactivating
16
1. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
2. Touch the ± touch button.
16
3. Touch the 0 touch button.
16
4. Use the ( or ) button to select the "Settings".
16
5. Use the & button to navigate to the next line.
16
6. Use the ( or ) button to select "Automatic childproof lock".
16
7. Use the & button to navigate to the next line.
16
8. Use the ( or ) button to select "Deactivated".
16
9. Touch the 0 touch button.
16
10. Use the & button to navigate to the next line to save the setting.
16
11. Touch the ± touch button.
16
One-time childproof lock
16
Activating and deactivating
16
1. Press and hold the 0 touch button until "Childproof lock activated" appears on the display.
16
2. Press and hold the 0 touch button until "Childproof lock deactivated" appears on the display.
16
Q Basic settings
17
Basic settings
17
Changing the basic settings
17
1. Touch the # touch button.
17
2. Touch the 0 touch button.
17
3. Use the ( or ) button to select the "" Settings".
17
4. Use the & button to navigate to the next line.
17
5. Use the ( or ) button to select the setting.
17
6. Use the & button to navigate to the next line.
17
7. Use the ( or ) button to select the setting.
17
8. Touch the 0 touch button.
17
9. To save the setting, use the & button to select "Save".
17
List of basic settings
17
Setting
17
Selection
17
Setting favourites
17
Note:
17
1. Touch the # touch button.
17
2. Touch the 0 touch button.
17
3. Use the ( or ) button to select the "" Settings".
17
4. Use the & button to navigate to the next line.
17
5. Use the ( or ) button to select "Favourites".
17
6. Use the & button to navigate to the next line.
17
7. Use the ( or ) button to select the type of heating.
17
8. Use the & button to navigate to the next line.
17
9. Use the ( or ) button to select "Activated" or "Deactivated".
17
Note:
17
10. Touch the 0 touch button.
17
11. To save the setting, use the & button to select "Save".
17
F Sabbath mode
18
Sabbath mode
18
Starting Sabbath mode
18
1. Touch the # touch button.
18
2. Use the ( or ) button to select "Sabbath mode".
18
3. Use the & button to navigate to the next line.
18
4. Use the ( or ) button to select the temperature.
18
5. Use the & button to navigate to the next line.
18
6. Use the ( or ) button to select the cooking time.
18
7. Touch the # touch button.
18
Notes
18
Cancelling Sabbath mode
18
D Cleaning agent
18
Cleaning agent
18
Suitable cleaning agents
18
Caution!
18
Risk of surface damage
18
Tip:
18
: Warning
18
Risk of burns!
18
Area
18
Cleaning
18
Notes
19
Keeping the appliance clean
19
Tips
19
. Cleaning function
20
Cleaning function
20
Self-cleaning
20
Setting
20
Cleaning level
20
Duration
20
Note:
20
: Warning
20
Risk of burns!
20
Prior to initiating the cleaning function
20
Note:
20
: Warning
20
Risk of fire!
20
: Warning
20
Risk of serious damage to health!
20
Starting
20
1. Touch the # touch button.
20
2. Touch the 0 touch button.
20
3. Use the ( or ) button to select "Self-cleaning ˜".
20
4. Use the & button to navigate to the next line.
20
5. Use the ( or ) button to select the cleaning setting.
20
Note:
20
6. Use the & button to navigate to the next line.
20
7. Touch the # touch button.
20
Note:
20
Cancelling
20
Finishing
20
Once the cleaning function has ended
20
EasyClean
21
: Warning
21
Risk of scalding!
21
Starting
21
Notes
21
1. Remove the accessories from the cooking compartment.
21
2. Mix 0.4 litres of water (not distilled water) with a drop of washing-up liquid and pour into the middle of the cooking compartment floor.
21
3. Touch the # touch button.
21
4. Touch the 0 touch button.
21
5. Use the ( or ) button to select "EasyClean š".
21
6. Use the & button to navigate to the next line.
21
7. Touch the # touch button.
21
Finishing
21
Final cleaning
21
1. Open the appliance door and remove the remaining water with an absorbent sponge cloth.
21
2. Clean the smooth surfaces in the cooking compartment with a dish cloth or a soft brush. Stubborn residues can be removed using a stainless steel scouring pad.
21
3. Remove limescale with a cloth soaked in vinegar. Then wipe with clean water and rub dry with a soft cloth (including under the door seal).
21
4. Use the # touch button to switch off the appliance.
21
5. Leave the appliance door ajar in the locking position (approx. 30°) for approx. 1 hour to allow the enamel surfaces in the cooking compartment to dry. Alternatively, you can also run the rapid drying function for the cooking compartment.
21
Running the rapid drying function for the cooking compartment
21
1. After the cleaning aid process has finished, leave the appliance door ajar in the locking position (approx. 30°).
21
2. Touch the # touch button.
21
3. Start CircoTherm hot air at 50 °C.
21
4. After 5 minutes, switch off the appliance and close the appliance door.
21
Removing heavy deposits of dirt
21
p Rails
22
Rails
22
Detaching and refitting the rails
22
: Warning
22
Risk of burns!
22
Detaching the rails
22
1. Lift the rail slightly at the front ‚ and detach it ƒ (figure !).
22
2. Then pull the whole rail towards you and take it out (figure ").
22
Attaching the rails
22
1. First, insert the rail in the middle of the rear socket ‚, until the rail rests against the cooking compartment wall, and push it back ƒ (figure !).
22
2. Then insert the rail into the front socket „, until the rail also rests against the cooking compartment wall here, and press it downwards … (figure ").
22
q Appliance door
22
Appliance door
22
Removing and fitting the appliance door
22
: Warning
22
Risk of injury!
22
: Warning
22
Risk of injury!
22
Removing the appliance door
22
1. Open the left- and right-hand hinge lock (Fig. !).
22
Tip:
22
2. Open the appliance door a little (Fig. %).
22
3. Using a coin, fully turn both the left- and right-hand locks on the inside of the appliance at the bottom (Fig. &).
23
4. Close the appliance door a little, until you feel the locks engage.
23
5. Lift the door handle slightly on the left- and right- hand side using both thumbs ‚ and pull the appliance door out upwards ƒ (Fig. ').
23
6. Lay the appliance door on an even, soft and clean surface.
23
Fitting the appliance door
23
1. Fit the appliance door (Fig. !).
23
2. Fit the appliance door in the left and right-hand guide rollers simultaneously (Fig. ").
23
3. Turn the door handle upwards slightly ‚ so that the appliance door slides downwards fully ƒ (Fig. #).
23
4. Use a coin to release both locks on the appliance door (Fig. $).
23
5. Open the appliance door a little wider and then close it.
23
: Warning
23
Risk of injury from hinge locks which have not been properly closed!
23
6. Close the left- and right-hand hinge locks (Fig. %).
23
Removing and installing the door panels
23
: Warning
23
Risk of injury!
23
: Warning
23
Risk of injury!
23
Removal
24
Note:
24
1. Remove the appliance door.
24
2. Lay the appliance door with the front side facing down on an even, soft and clean surface.
24
3. Push on the left- and right-hand side on the outside of the appliance door until the inner glass is released on both sides (Fig. !).
24
4. Carefully lift the inner glass and remove it in the direction of the arrow (Fig. ").
24
5. Push the intermediate panel downwards in the ‚ area, carefully lift the ƒ holder until it can be pulled out (Fig. #).
24
6. Lift the first and second intermediate panels from below (Fig. $) and remove them in the direction of the arrow (Fig. %).
24
7. If required, remove the spacers (Fig. &) and seals (Fig. ') for cleaning.
24
8. Clean the door panels on both sides with glass cleaner and a soft cloth.
24
: Warning
24
Risk of injury!
24
9. Dry and refit the door panels.
24
Installation
24
Note:
24
1. Insert the intermediate glass so that the ‚ arrow is facing upwards on the right-hand side (Fig. !).
24
2. Check the fit of the four spacers and two seals on the intermediate panel:
24
3. Insert the intermediate panel with the seals and spacers. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. $).
24
4. Insert the second intermediate panel without the seals and spacers and push it in the direction of the arrow until it is fitted in the frame. The arrow on the intermediate panel must line up with the arrow on the frame (Fig. %).
24
5. Push the intermediate panel downwards in the ƒ area, insert the „ holder at an angle and push down until it locks into place (Fig. &).
25
6. Insert the inner glass into the mounting rail … at an angle towards the back (Fig. ().
25
7. Push the inner glass downwards until it locks into place (Fig. )).
25
3 Trouble shooting
25
Trouble shooting
25
Tip:
25
: Warning
25
Risk of electric shock!
25
Fault table
25
: Warning
25
Risk of electric shock!
25
Fault
25
Possible cause
25
Notes/remedy
25
--------
25
Maximum operating time exceeded
26
Replacing the bulb in the top of the cooking compartment
26
: Warning
26
Risk of electric shock!
26
: Warning
26
Risk of burns!
26
1. Place a tea towel in the cold cooking compartment to prevent damage.
26
2. Turn the glass cover anti-clockwise to remove it (figure !).
26
3. Pull out the bulb – do not turn it (figure "). Insert the new bulb, making sure that the pins are in the correct position. Push the bulb in firmly.
26
4. Screw the glass cover back in.
26
5. Remove the tea towel and switch on the circuit breaker.
26
Glass cover
26
4 Customer service
26
Customer service
26
E number and FD number
26
To book an engineer visit and product advice
26
J Tested for you in our cooking studio
27
Tested for you in our cooking studio
27
Note:
27
Silicone moulds
27
Cakes and small baked items
27
Shelf positions
27
Accessories
27
Recommended setting values
28
Note:
28
Dish
28
Accessories/cookware
28
Shelf position
28
Type of heating
28
Temperature in °C
28
Cooking time in mins.
28
Tips on baking
30
Bread and rolls
31
Shelf positions
31
Accessories
31
Frozen products
31
Recommended setting values
31
Note:
31
Caution!
31
Dish
32
Accessories
32
Shelf position
32
Type of heating
32
Temperature in °C
32
Cooking time in mins.
32
Pizza, quiche and savoury cakes
33
Shelf positions
33
Accessories
33
Frozen products
33
Recommended setting values
33
Note:
33
Dish
34
Accessories
34
Shelf position
34
Type of heating
34
Temperature in °C
34
Cooking time in mins.
34
Bakes and soufflés
34
Shelf positions
34
Accessories
34
Recommended setting values
35
Note:
35
Bakes & soufflés
35
Accessories/cookware
35
Shelf position
35
Type of heating
35
Temperature in °C
35
Cooking time in mins.
35
Poultry
35
Roasting on the wire rack
35
Roasting in cookware
35
Grilling
36
Note:
36
Notes
36
Recommended setting values
36
Note:
36
Tips
36
Dish
36
Accessories/cookware
36
Shelf position
36
Type of heating
36
Temperature in °C
36
Cooking time in mins.
36
Meat
37
Roasting and braising
37
Roasting on the wire rack
37
Roasting and braising in cookware
37
Grilling
37
Note:
37
Notes
37
Recommended setting values
37
Dish
38
Accessories/cookware
38
Shelf position
38
Type of heating
38
Temperature in °C
38
Cooking time in mins.
38
Tips on roasting and braising
39
Fish
39
Roasting and grilling on the wire rack
39
Note:
39
Notes
39
Roasting and stewing in cookware
39
Recommended setting values
39
Note:
40
Dish
40
Accessories/cookware
40
Shelf position
40
Type of heating
40
Temperature in °C
40
Cooking time in mins.
40
Vegetables and side dishes
40
Shelf positions
40
Accessories
40
Recommended setting values
40
Dish
41
Accessories
41
Shelf position
41
Type of heating
41
Temperature in °C
41
Cooking time in mins.
41
Yogurt
41
Preparing yogurt
41
1. Heat 1 litre of milk (3.5 % fat) to 90 °C on the hob and then cool down to 40 °C.
41
2. Stir in 150 g (chilled) yogurt.
41
3. Pour into cups or small jars and cover with cling film.
41
4. Place the cups or jars onto the cooking compartment floor and use the settings indicated in the table.
41
5. After preparation, leave the yogurt to cool in the refrigerator.
41
Dish
41
Accessories
41
Shelf position
41
Type of heating
41
Temperature in °C
41
Cooking time in hours
41
Save energy with Eco heating types
41
Accessories
41
Recommended setting values
42
Note:
42
Dish
42
Accessories/cookware
42
Shelf position
42
Type of heating
42
Temperature in °C
42
Cooking time in mins.
42
Acrylamide in foodstuffs
43
Tips for keeping acrylamide to a minimum
43
Slow cook
43
Note:
43
Cookware
43
Recommended setting values
44
Dish
44
Cookware
44
Shelf position
44
Type of heating
44
Searing time in mins.
44
Temperature in °C
44
Cooking time in mins.
44
Tips for slow cooking
44
Drying
44
Recommended setting values
45
Fruit, vegetables and herbs
45
Accessories
45
Type of heating
45
Temperature in °C
45
Cooking time in hours
45
Preserving
45
: Warning
45
Risk of injury!
45
Jars
45
Preparing fruit and vegetables
45
Ending the preserving process
45
Recommended setting values
46
Preserving
46
Cookware
46
Shelf position
46
Type of heating
46
Temperature in °C
46
Cooking time in mins.
46
Allowing the dough to prove at dough proving setting
46
Caution!
46
Surface damage
46
Recommended setting values
46
Dish
46
Accessories/cookware
46
Shelf position
46
Type of heating
46
Step
46
Temperature in °C
46
Cooking time in mins.
46
Defrosting
47
Recommended setting values
47
Tip:
47
Dish
47
Accessories
47
Shelf position
47
Type of heating
47
Temperature in °C
47
Cooking time in mins.
47
Keeping warm
47
Test dishes
47
Baking
47
Notes
47
Dish
48
Accessories
48
Shelf position
48
Type of heating
48
Temperature in °C
48
Cooking time in mins.
48
Grilling
48
Dish
48
Accessories
48
Shelf position
48
Type of heating
48
Temperature in °C
48
Cooking time in mins.
48
Search:
×
Search
