VIZIO
USER MANUAL
Model D43-C1
This product qualifies for ENERGY STAR in the “factory
default” setting and this is the setting in which power
savings will be achieved. Changing the factory default
picture settings or enabling other features will increase
power consumption that could exceed the limits necessary
to qualify for ENERGY STAR rating. For more information on
the ENERGY STAR program, refer to energystar.gov.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
For DTS patents, see
http://patents.dts.com.
Manufactured under license from DTS Licensing Limited. DTS,
the Symbol, & DTS and the Symbol together are registered
trademarks, and DTS Studio Sound is a trademark of
DTS, Inc. © DTS, Inc. All Rights Reserved.
Manufactured under license from Dolby Laboratories. Dolby and
the double-D symbol are trademarks of Dolby Laboratories.
THANK YOU FOR CHOOSING VIZIO
Congratulations on the purchase of your new VIZIO HDTV.
To get the most out of your new VIZIO product, read these
instructions before using your product and retain them for future
reference. Be sure to inspect the package contents to ensure there
are no missing or damaged parts.
PRODUCT REGISTRATION
To purchase or inquire about accessories and installation services
for your VIZIO product, visit our website at www.VIZIO.com or call
toll free at (877) 698-4946.
We recommend that you either:
• Register your VIZIO product at www.VIZIO.com
• Complete and mail the enclosed registration card
Extended Warranties
For peace of mind, and to protect your investment beyond the
VWDQGDUGZDUUDQW\9Ζ=Ζ2RHUVRQVLWHH[WHQGHGZDUUDQW\VHUYLFH
plans. These plans provide additional coverage during the standard
ZDUUDQW\ SHULRG7R SXUFKDVH DQH[WHQGHGZDUUDQW\VHUYLFH SODQ
visit www.VIZIO.com.
WHEN READING THIS MANUAL
When you see this symbol, please read the
accompanying helpful tip.
IMPORTANT SAFETY INSTRUCTIONS
<RXU79 LV GHVLJQHG DQG PDQXIDFWXUHG WR RSHUDWH ZLWKLQ GHȴQHG
GHVLJQOLPLWV0LVXVHPD\UHVXOWLQHOHFWULFVKRFNRUȴUH7RSUHYHQW
your TV from being damaged, the following instructions should be
observed for the installation, use, and maintenance of your TV.
Read the following safety instructions before operating your TV.
Keep these instructions in a safe place for future reference.
• To reduce the risk of electric shock or component damage,
VZLWFKRWKHSRZHUEHIRUHFRQQHFWLQJRWKHUFRPSRQHQWV
to your TV.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
UHJLVWHUVVWRYHVRURWKHUDSSDUDWXVLQFOXGLQJDPSOLȴHUV
that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
SOXJGRHVQRWȴWLQWR\RXURXWOHWFRQVXOWDQHOHFWULFLDQIRU
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
ZKHUHWKH\H[LWIURPWKHDSSDUDWXV
• 2QO\XVHDWWDFKPHQWVDFFHVVRULHVVSHFLȴHGE\WKH
manufacturer.
When you see this symbol, please read the
accompanying important warning or notice. It is
intended to alert you to the presence of important
operating instructions.
• Do not apply pressure or throw objects at your TV. This may
compromise the integrity of the display. The manufacturer’s
warranty does not cover user abuse or improper
installations.
• 7KHSRZHUFRUGPXVWEHUHSODFHGZKHQXVLQJGLHUHQW
YROWDJHWKDQWKHYROWDJHVSHFLȴHG)RUPRUHLQIRUPDWLRQ
contact your dealer.
• :KHQFRQQHFWHGWRDSRZHURXWOHWSRZHULVDOZD\VȵRZLQJ
into your TV. To totally disconnect power, unplug the power
cord.
• 7KHOLJKWQLQJȵDVKZLWKDUURZKHDGV\PEROZLWKLQDQ
equilateral triangle is intended to alert the user to the
presence of un-isolated, dangerous voltage within the
LQVLGHRI\RXU79WKDWPD\EHRIVXɝFLHQWPDJQLWXGHWR
constitute a risk of electric shock to persons.
• 'RQRWRYHUORDGSRZHUVWULSVDQGH[WHQVLRQFRUGV
2YHUORDGLQJFDQUHVXOWLQȴUHRUHOHFWULFVKRFN
• The wall socket should be installed near your TV and easily
accessible.
• Only power of the marked voltage can be used for your TV.
$Q\RWKHUYROWDJHWKDQWKHVSHFLȴHGYROWDJHPD\FDXVHȴUH
or electric shock.
• Do not touch the power cord during lightning. To avoid
electric shock, avoid handling the power cord during
electrical storms.
• Unplug your TV during a lightning storm or when it will not
be used for long period of time. This will protect your TV
from damage due to power surges.
• Do not attempt to repair or service your TV yourself.
2SHQLQJRUUHPRYLQJWKHEDFNFRYHUPD\H[SRVH\RXWR
high voltages, electric shock, and other hazards. If repair
is required, contact your dealer and refer all servicing to
TXDOLȴHGVHUYLFHSHUVRQQHO
• WARNING: Keep your TV away from moisture. Do not
H[SRVH\RXU79WRUDLQRUPRLVWXUHΖIZDWHUSHQHWUDWHVLQWR
your TV, unplug the power cord and contact your dealer.
• Use only with the cart, stand, tripod, bracket,
RU WDEOH VSHFLȴHG E\ WKH PDQXIDFWXUHU RU
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• 5HIHUDOOVHUYLFLQJWRTXDOLȴHGVHUYLFHSHUVRQQHO6HUYLFLQJ
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
WKHDSSDUDWXVKDVEHHQH[SRVHGWRUDLQRUPRLVWXUHGRHV
not operate normally, or has been dropped.
• Unplug the power cord before cleaning your TV.
• When moving your TV from an area of low temperature to
an area of high temperature, condensation may form in the
housing. Wait before turning on your TV to avoid causing
ȴUHHOHFWULFVKRFNRUFRPSRQHQWGDPDJH
• A distance of at least three feet should be maintained
between your TV and any heat source, such as a radiator,
KHDWHURYHQDPSOLȴHUHWF'RQRWLQVWDOO\RXU79FORVHWR
smoke. Operating your TV close to smoke or moisture may
FDXVHȴUHRUHOHFWULFVKRFN
• 6ORWVDQGRSHQLQJVLQWKHEDFNDQGERWWRPRIWKHFDELQHW
are provided for ventilation. To ensure reliable operation of
your TV and to protect it from overheating, be sure these
openings are not blocked or covered. Do not place your
TV in a bookcase or cabinet unless proper ventilation is
provided.
• Never push any object into the slots and openings on your
TV cabinet. Do not place any objects on the top of your TV.
'RLQJVRFRXOGVKRUWFLUFXLWSDUWVFDXVLQJDȴUHRUHOHFWULF
shock. Never spill liquids on your TV.
• Your TV should be operated only from the type of power
source indicated on the label. If you are not sure of the type
of power supplied to your home, consult your dealer or
local power company.
&RQWLQXRXVXVHLQWKLVFDVHPD\UHVXOWLQȴUHRUHOHFWULF
shock.
• Do not use your TV if any abnormality occurs. If any smoke
or odor becomes apparent, unplug the power cord and
contact your dealer immediately. Do not try to repair your
TV yourself.
• Avoid using dropped or damaged appliances. If your TV
is dropped and the housing is damaged, the internal
components may function abnormally. Unplug the power
cord immediately and contact your dealer for repair.
&RQWLQXHGXVHRI\RXU79PD\FDXVHȴUHRUHOHFWULFVKRFN
• Do not install your TV in an area with heavy dust or high
humidity. Operating your TV in environments with heavy
GXVWRUKLJKKXPLGLW\PD\FDXVHȴUHRUHOHFWULFVKRFN
• Follow instructions for moving your TV. Ensure that the
power cord and any other cables are unplugged before
moving your TV.
• When unplugging your TV, hold the AC/DC power adapter,
not the cord. Pulling on the power cord may damage the
ZLUHVLQVLGHWKHFRUGDQGFDXVHȴUHRUHOHFWULFVKRFN:KHQ
\RXU79ZLOOQRWEHXVHGIRUDQH[WHQGHGSHULRGRIWLPH
unplug the power cord.
• To reduce risk of electric shock, do not touch the connector
with wet hands.
• Insert batteries in accordance with instructions. Incorrect
polarities may cause the batteries to leak which can
damage the remote control or injure the operator. Do not
H[SRVHEDWWHULHVWRH[FHVVLYHKHDWVXFKDVVXQVKLQHȴUHRU
the like.
• If any of the following occurs, contact the dealer:
- The power cord fails or frays.
- Liquid sprays or any object drops into your TV.
<RXU79LVH[SRVHGWRUDLQRURWKHUPRLVWXUH
- Your TV is dropped or damaged in any way.
- The performance of your TV changes substantially.
• 7KLVDSSDUDWXVVKDOOQRWEHH[SRVHGWRGULSSLQJRU
VSODVKLQJDQGQRREMHFWVȴOOHGZLWKOLTXLGVVXFKDVYDVHV
shall be placed on the apparatus.
• The mains plug or appliance coupler is used as the
disconnect device, the disconnect device shall remain
readily operable.
• CAUTION - These servicing instructions are for use by
TXDOLȴHGVHUYLFHSHUVRQQHORQO\7RUHGXFHWKHULVNRI
electric shock, do not perform any servicing other than
that contained in the operating instructions unless you are
TXDOLȴHGWRGRVR
• 7KHOLJKWQLQJȵDVKZLWKDUURZKHDGV\PEROZLWKLQDQ
equilateral triangle is intended to alert the user to the
SUHVHQFHRIXQLQVXODWHG'$1*(528692/7$*(ZLWKLQWKH
SURGXFWȇVHQFORVXUHWKDWPD\EHRIVXɝFLHQWPDJQLWXGHWR
constitute a risk of electrical shock to persons.
h
TELEVISION ANTENNA CONNECTION
PROTECTION
If an outside antenna/satellite dish or cable system is to be
connected to the TV, make sure that the antenna or cable system
is electrically grounded to provide some protection against voltage
surges and static charges.
$UWLFOHRIWKH1DWLRQDO(OHFWULFDO&RGH$16Ζ1)36$SURYLGHV
information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of the grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements of the grounding electrode.
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
1(&6HFWLRQ
Grounding Conductors
1(&6HFWLRQ
Ground Clamps
3RZHU6HUYLFH*URXQGLQJ(OHFWURGH6\VWHP
1(&$57SDUW+
(OHFWULF6HUYLFH(TXLSPHQW
Lightning Protection
For added protection of the TV during a lightning storm or when it
is left unattended or unused for long periods of time, unplug the TV
from the wall outlet and disconnect the antenna or cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or
where it could fall into such power lines or circuits. Remember, the
VFUHHQRIWKHFRD[LDOFDEOHLVLQWHQGHGWREHFRQQHFWHGWRHDUWKLQ
the building installation.
Table of Contents
1
Installing the TV .....................................................3
Inspecting the Package Contents . . . . . . . . . . . . . . . . . . . . . . 3
Installing the TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing the TV Stand ........................................................... 3
Installing the Stand ................................................................ 4
Installing the TV on a Wall ..................................................... 6
Controls and Connections .....................................7
Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Replacing the Batteries ........................................................ 11
Connecting Your Devices .....................................12
Connecting A Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting an Audio Device . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting an Audio Device - ARC . . . . . . . . . . . . . . . . . . . . 17
Completing the First-Time Setup ........................18
Using the On-Screen Menu .................................19
Navigating the On-Screen Menu . . . . . . . . . . . . . . . . . . . . . . 19
Changing the Input Source . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing the Screen Aspect Ratio . . . . . . . . . . . . . . . . . . . . 20
Adjusting the Picture Settings . . . . . . . . . . . . . . . . . . . . . . . . 21
Adjusting the More Picture Settings ................................... 22
Adjusting the Picture Mode Edit Settings ........................... 23
Creating a Custom Picture Mode ........................................ 23
Locking and Unlocking the Custom Picture Modes ........... 24
Deleting a Custom Picture Mode ........................................ 24
Adjusting the Color Calibration Settings ............................ 25
Adjusting the Color Tuner Settings ..................................... 26
Adjusting the Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . . 29
Changing the Equalizer Settings ......................................... 30
Deleting the Custom Audio Mode ....................................... 30
Setting Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setting the Sleep Timer........................................................ 31
6HWWLQJWKH$XWR3RZHU2)HDWXUH .................................... 31
Setting Up Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Selecting a Channel Source ................................................. 32
Finding Channels .................................................................. 32
Adding New Channels .......................................................... 33
Skipping Channels ................................................................ 34
Listening to Alternate Audio . . . . . . . . . . . . . . . . . . . . . . . . . 35
Changing the Analog Audio Language ................................ 35
Changing the Digital Audio Language................................. 35
Setting Up Closed Captioning . . . . . . . . . . . . . . . . . . . . . . . . 36
Changing the Appearance of Digital Closed Captions ....... 36
Renaming Devices on the Input Menu . . . . . . . . . . . . . . . . . 38
Changing the TV Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Viewing System Information ............................................... 39
Changing the On-Screen Menu Language .......................... 40
Setting the Time and Local Settings .................................... 40
Using the Parental Controls ................................................ 41
Accessing the Parental Controls Menu ............................... 41
Enabling or Disabling Program Ratings .............................. 41
Locking and Unlocking Channels ........................................ 41
Blocking and Unblocking Content by Rating ...................... 42
Changing the Parental Control Passcode ........................... 42
2
2
Resetting the Content Locks ................................................ 42
Adjusting the Wide Mode (Aspect Ratio) ............................ 43
Controlling Other Devices with CEC .................................... 44
7XUQLQJWKH3RZHUΖQGLFDWRU2QRU2 ............................... 45
Using the Reset & Admin Menu . . . . . . . . . . . . . . . . . . . . . . 45
Restoring the TV to Factory Default Settings ..................... 45
Using the Guided Setup Menu . . . . . . . . . . . . . . . . . . . . . . . 46
Using the Info Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Using the USB Media Player ................................48
Using the USB Media Player . . . . . . . . . . . . . . . . . . . . . . . . . 48
Preparing your USB drive to play USB media .................... 48
Playing USB media ............................................................... 48
Removing the USB drive from the TV ................................. 48
6SHFLȴFDWLRQV .......................................................53
Limited Warranty .................................................55
Legal & Compliance .............................................56
3
1
3
Installing the TV
INSPECTING THE PACKAGE CONTENTS
Before installing your new TV, take a moment to inspect the package
contents. Use the images below to ensure nothing is missing or
damaged.
Remote control
with batteries
VIZIO LED HDTV
INSTALLING THE TV
After removing the TV from the box and inspecting the package
contents you can begin installing the TV. Your TV can be installed in
two ways:
• 2QDȵDWVXUIDFHXVLQJWKHLQFOXGHGVWDQG
• On a wall, using a VESA-standard wall mount (not included)
Installing the TV Stand
Your TV includes a stand designed to support the weight of the TV
and keep it from falling over. However, the TV can still fall over if:
• It is placed on an uneven, unstable, or non-level surface
• It is pushed, pulled, or otherwise improperly moved
• If an earthquake occurs and the TV is not properly secured.
Power cord
TV ON STANDS
4 x M4 28mm
Phillips screws
PACKAGE CONTENTS
Quick Start Guides
(1 English, 1 French/Spanish)
TV stands
1
4
4
It is recommended that two people take part in the stand installation.
Remove any plastic wrapping from the TV and the stand.
3ODFHWKH79VFUHHQGRZQRQDFOHDQȵDWVXUIDFH7RSUHYHQWVFUDWFKHVRUGDPDJHWRWKHVFUHHQ
place the TV on a soft surface such as a blanket and avoid any sharp edges.
Installing the Stand
1
5
5
Insert the left and right stands into the base of the TV.
Insert two (2) M4 28 mm Phillips screws (included) into the back of the TV
and tighten them using a Phillips screwdriver, to secure each stand to the TV.
:KHQ\RXDUHȴQLVKHGSODFHWKH79RQDVWDEOHOHYHOVXUIDFH
1
6
6
Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult
WKH LQIRUPDWLRQEHORZWR ȴQG WKH DSSURSULDWH PRXQWIRU \RXU 79
model:
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
D43-C1
Screw Size: M6 (not included)
Hole Pattern: ɋPP9[ɋPP+
Weight w/o Stand: 19.40 lbs
Be sure the mount you choose is capable of supporting the weight
of the TV. After you have determined that you have the correct
mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. 3ODFHWKH79IDFHGRZQRQDFOHDQȵDWVWDEOHVXUIDFH%HVXUH
the surface is clear of debris that can scratch or damage the
TV.
3. Remove the base by loosening and removing the screws.
4. Attach your TV and wall mount to the wall, carefully following
the instructions that came with your mount.
Use only with a UL-listed wall mount bracket rated for the
weight/load of this TV.
For some wall mounts, you may want to use cables with
right-angle connectors. This allows the TV to rest closer
to the wall.
WALL MOUNT SCREW LOCATIONS
2
7
Controls and Connections
BACK PANEL
HDMI - Connect an HDMI device.
Coaxial - Connect a coaxial cable from cable, satellite, or antenna.
Component/Composite - Connect a component or composite device.
Optical Audio Out - Connect an optical/SPDIF audio device, such as a
home audio receiver or sound bar.
Stereo Audio Out - Connect an RCA audio device, such as sound bar.
HDMI - Connect an HDMI device.
USB - Connect a USB thumb drive to display photos.
2
8
SIDE PANEL
Power - Press once to turn on the TV.
3UHVVDQGKROGWRWXUQRWKH79
Input - Press once to access the INPUT menu.
2
9
FRONT PANEL
FRONT PANEL
REMOTE SENSOR & POWER INDICATOR
When using the remote, aim it directly at this sensor.
7KHSRZHULQGLFDWRUȵDVKHVRQZKHQWKH79WXUQVRQWKHQJRHVRXWDIWHUVHYHUDOVHFRQGV
To keep the power indicator on as long as the TV is on, see
Turning the Power Indicator On
RU2
on page 45
.
2
10
USING THE REMOTE
INPUT
Change the currently-displayed input.
ARROW
Navigate the on-screen menu.
Exit
Close the on-screen menu.
CLOSED CAPTIONS
Open the closed caption menu.
A/V CONTROLS
Control USB media player.
WIDE
Switch the display mode.
MUTE
7XUQWKHDXGLRRRURQ
BACK
Go to the previous on-screen menu.
POWER
7XUQWKH79RQRUR
MENU
Display the on-screen menu.
INFO
Display the info window.
DASH
Use with number pad to manually enter
a digital sub-channel.
(For example, 18-4 or 18-5.)
CHANNEL UP/DOWN
Change the channel.
GUIDE
Display the info window.
LAST
Return to the channel last viewed.
NUMBER PAD
Manually enter a channel.
VOLUME UP/DOWN
Increase or decrease loudness of
the audio.
Ok
Select the highlighted menu option.
V BUTTON
Open the USB media player.
REMOTE CONTROL
2
11
Replacing the Batteries
1. Remove the battery cover.
2. Insert two batteries into the remote control. Make sure that
the (+) and (-) symbols on the batteries match the (+) and (-)
symbols inside the battery compartment.
3. Replace the battery cover.
3
12
Connecting Your Devices
CONNECTING A DEVICE
* Maximum resolution
Game Console
Cable/Satellite Box
DVD/Blu-ray Player
Your TV can be used to display output from most devices.
1. Verify that your device has a video port that matches an
available port on the TV (HDMI, Component, etc.).
2. 7XUQWKH79DQG\RXUGHYLFHR
3. Connect the appropriate cable (not included) to the TV and the
device.
4. Turn the TV and your device on. Set the TV’s input to match the
connection you used (HDMI-1, HDMI-2, etc.).
BEST
HDMI CABLE
• DIGITAL
• HD VIDEO (1080p)*
• HD AUDIO
GOOD
AV CABLE
• ANALOG
• VIDEO (480i)*
• STEREO AUDIO
BETTER
COAXIAL CABLE
• ANALOG
• HD VIDEO (1080i)*
• STEREO AUDIO
BETTER
COMPONENT CABLE
• ANALOG
• HD VIDEO (1080p)*
• STEREO AUDIO
3
13
COAXIAL CABLE
Coaxial cables are the traditional way of connecting
antennas and cable television signals to your TV. Coaxial
cables carry both audio and video signals through a
single connector.
AV CABLE
AV cables (or composite cables) are the traditional way
of connecting your devices to your TV. Video signals are
sent over the yellow connector while audio is sent over
the red and white connectors.
GOOD BETTER
Y/V L R
• HD Video Resolutions up to 1080i
• Analog Connection
• Audio and Video Signals
• Video Resolutions up to 480i
• Analog Connection
• Audio and Video Signals
CONNECTING A DEVICE - AUDIO AND VIDEO CABLE TYPES
Coaxial
3
14
HDMI CABLE
HDMI is the intelligent, all-digital interface that delivers
both dazzling quality and unmatched ease of use. HDMI
technology transmits crystal-clear digital video along with
multi-channel surround audio. HDMI-connected devices
have the ability to automatically adjust themselves for
optimal viewing.
COMPONENT CABLE
&RPSRQHQWFDEOHVDUHGHVLJQHGWRFDUU\KLJKGHȴQLWLRQ
video signals along with additional audio connections.
Colors are delivered with color information split up
WKUHH GLHUHQW ZD\V RYHU WKUHH FRQQHFWRUV IRU YLGHR
(separated into red, blue and green signals) and the left
and right audio connectors (red and white).
BETTER
R L Pr/Cr Pb/Cb Y/V HDMI
• HD Video Resolutions up to 1080p
• HD Audio
• Digital Connection
• Audio and Video Signals
• HD Video Resolutions up to 1080p
• Analog Connection
• Audio and Video Signals
BEST
3
15
GOOD
RCA CABLE
• ANALOG STEREO CONNECTION
• 2.0 CHANNEL
CONNECTING AN AUDIO DEVICE
Home Audio Receiver
VIZIO Sound Bar
Your TV can output sound to an audio device, such as a receiver or
sound bar.
1. Verify that your device has an audio port that matches an
available port on the TV (optical, RCA, etc.).
2. 7XUQWKH79DQG\RXUDXGLRGHYLFHR
3. Connect the appropriate cable (not included) to the TV and the
device.
4. Turn the TV and your device on.
BETTER
OPTICAL/SPDIF CABLE
• PCM STREAM
• DOLBY DIGITAL 5.1 CHANNEL
• DTS 5.1 CHANNEL
BEST
HDMI CABLE
• CEC 2-WAY COMMUNICATION
• 2.0-5.1 DIGITAL AUDIO
• PCM, DTS, DOLBY DIGITAL
3
16
HDMI CABLE
HDMI technology transmits crystal-clear digital
multi-channel surround audio through a single
HDMI cable. Audio Return Channel-enabled
(ARC) TVs allow audio to be sent over an already
connected HDMI cable, eliminating the need for
a separate audio cable. See
Connecting an Audio
Device - ARC
on page 17.
OPTICAL/SPDIF CABLE
Optical/SPDIF cables transmit audio signals as
pulses of light through a cable made of plastic
ȴEHUV $XGLR VLJQDOV DUH GLJLWDOO\ WUDQVPLWWHG
between devices.
RCA CABLE
AV cables (or composite cables) are the traditional
way of connecting your devices to your audio
device. Audio signals are sent over the red and
white connectors.
GOOD BETTER
• CEC 2-way Communication
(Auto setup)
• PCM, DTS, Dolby Digital
• 2.0-5.1 Scaleable Lossless
Digital Audio Connection
• Audio and Video Signals
• PCM Stream (Lossless)
• Dolby Digital 5.1 Channel
• Digital Connection
• Audio Signal Only
• Quality Stereo Connection
• 2.0 Channel
• Analog Connection
• Audio Signal Only
BEST
L R
Optical/SPDIF HDMI
CONNECTING AN AUDIO DEVICE - AUDIO CABLE TYPES
3
17
Without HDMI ARC With HDMI ARC
CONNECTING AN AUDIO DEVICE - ARC
HDMI
HDMI
Your Home Audio Receiver
Your Blu-ray Player
RCA (Audio)
Your TV
HDMI
HDMI
Your Home Audio Receiver
Your Blu-ray Player
Your TV
With an HDMI ARC setup, the
audio connection between
your TV and home audio
receiver can be removed.
The HDMI cable will transmit
audio signal to and from
your TV with an all-digital
audio/video connection.
Built-in Tuner
Built-in Tuner
Without an HDMI ARC setup,
your TV will transmit audio
signals from the built-in
tuner and VIA apps to your
home audio receiver through
a separate audio connection.
18
4
7KH ȴUVW WLPH \RX WXUQ RQ WKH 79 WKH 6HWXS $SS ZLOO JXLGH \RX
WKURXJKHDFKRIWKHVWHSVQHFHVVDU\WRJHW\RXU79UHDG\IRUXVH
%HIRUH\RXEHJLQWKHȴUVWWLPHVHWXS
• <RXU79VKRXOGEHLQVWDOOHGDQGWKHSRZHUFRUGVKRXOGEH
FRQQHFWHGWRDQHOHFWULFDORXWOHW
• <RXUGHYLFHVVKRXOGEHFRQQHFWHG
7RFRPSOHWHWKHȴUVWWLPHVHWXS
3UHVVWKHPower/Standby
EXWWRQRQWKHUHPRWH7KH79
SRZHUVRQDQGWKH6HWXS$SS
VWDUWV
8VHWKHArrowEXWWRQVRQWKH
UHPRWHWRKLJKOLJKWHome Use
DQGSUHVVOK
8VHWKHArrowEXWWRQVRQ
WKHUHPRWHWRKLJKOLJKW\RXU
SUHIHUUHGODQJXDJHDQGWKHQ
SUHVVWKHOKEXWWRQ
Choose your mode.
Select Store Demo for in-store display.
Select Home Use for in-home use.
Seleccione "Home Use" para Modo de Casa o "Store Demo" para Demostración en la Tienda.
Choisissez "Home Use" pour le Mode Domicile ou "Store Demo" pour la Démo en Magasin.
Store Demo Home Use
Completing the First-Time Setup
8VHWKHArrowEXWWRQVRQWKH
UHPRWHWRKLJKOLJKW\RXU79
VRXUFHDQGSUHVVOK
ΖI\RXKDYHFDEOH79VHOHFW
ZKHWKHU\RXKDYHDFDEOHER[RU
LI\RXFRQQHFWWKH79GLUHFWO\WR
DFDEOHIURPWKHZDOO
ΖIWKH796LJQDOFKDQQHOVFDQ
VFUHHQDSSHDUVWKH79ZLOOVFDQ
IRUFKDQQHOVZKLFKWDNHVVHYHUDO
PLQXWHV8VHWKHDUURZEXWWRQV
RQWKHUHPRWHWRKLJKOLJKWBegin
ScanDQGSUHVVOK
2WKHUZLVHXVHWKHArrowDQG
OKEXWWRQVRQWKHUHPRWHWR
VHOHFWWKHLQSXW\RXU79VRXUFH
LVFRQQHFWHGWR
7KHQXPEHURILQSXWVPD\YDU\
GHSHQGLQJRQ\RXU79
:KHQ\RXDUHȴQLVKHGWKHPHVVDJHȊ<RXU9Ζ=Ζ279LVVHWXSȋ
ZLOODSSHDU
The First-Time Setup is complete.
5
19
NAVIGATING THE ON-SCREEN MENU
To open the on-screen menu, press
the MENU button on the remote.
Use the Arrow buttons to highlight
a menu option, and press the OK
button to select that option.
Using the On-Screen Menu
Your TV features an easy-to-use on-screen menu.
To open the on-screen menu, press the MENU button on the
remote.
From this menu, you can:
• Adjust the Picture settings
• Adjust the Audio settings
• Set the Sleep Timer
• Adjust the Channel settings
• Set up Closed Captioning
• Select input devices
• Adjust TV settings
• Access the Guided Setup
While navigating the on-screen menu, you can press the
BACK button at any time to return to the previous menu
screen. The EXIT button will close the
on-screen menu.
VIZIO
TV SETTINGS
Audio
Timers
Channels
Closed Captions
Devices
System
Guided Setup
CC
5
20
CHANGING THE INPUT SOURCE
External devices such as DVD players, Blu-ray Players, and video
game consoles can be connected to your TV. To use one of these
GHYLFHVZLWK\RXU79\RXPXVWȴUVWFKDQJHWKHLQSXWVRXUFHXVLQJ
the Input menu.
To change the input source:
1. Press the INPUT button on
the remote. The Input menu is
displayed.
2. Use the Up/Down Arrow
buttons or the INPUT button on
the remote to highlight the input
you wish to view and press OK.
The selected input is displayed.
You can change the input names that appear on the
Input menu to make your devices easy to recognize. See
Renaming Devices on the Input Menu
on page 38 for
more information.
CHANGING THE SCREEN ASPECT RATIO
7KH79FDQGLVSOD\LPDJHVLQȴYHGLHUHQWPRGHV1RUPDO6WUHWFK
Panoramic, Wide, and Zoom. Each mode displays the picture
GLHUHQWO\
To change the screen aspect ratio:
1. Press the WIDE button on the
remote.
2. Use the Arrow buttons to
highlight the aspect ratio you
wish to view and press OK.
• Normal preserves the content’s
original aspect ratio. Since the 4:3
aspect ratio is not large enough
WRȴOOWKH79ȇVVFUHHQEODFNEDUV
are added to the left and right of
the display image.
• StretchH[SDQGVWKHGLVSOD\LPDJHWRȴOOWKHVFUHHQΖPDJHV
may appear wider than intended. If you are watching
widescreen (1.85:1 or 2.35:1) content, black bars will still
appear on the top and bottom of the display image. This
option is only available when the TV is displaying a
720p/1080i source.
• Panoramic H[SDQGVWKHGLVSOD\LPDJHWRȴOOWKHVFUHHQ
Images may appear wider than intended. If you are
watching widescreen (1.85:1 or 2.35:1) content, black bars
will still appear on the top and bottom of the display image.
This option is only available when the TV is displaying a
480i/480p source.
• Wide stretches a 4:3 aspect ratio picture to the edges of
the screen. Since the picture is being stretched, the display
image may appear distorted. If the program is already
formatted for widescreen viewing (1.85:1 or 2.35:1), then
black bars will appear on the top and bottom of the display
image.
• Zoom H[SDQGVLPDJHVZLWKEODFNEDUVWRȴWWKHVFUHHQ
Panoramic
Wide
Zoom
Normal
Stretch
Wide
Zoom
Normal
Note: Aspect ratio settings may
vary by Input source.
COMP
HDMI-1
HDMI-2
TV
Input Name
5
21
ADJUSTING THE PICTURE SETTINGS
Your TV display can be adjusted to suit your preferences and viewing
conditions.
To adjust the picture settings:
1. Press the MENU button on the
remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the
remote to highlight Picture and
press OK. The PICTURE menu is
displayed.
3. Use the Arrow buttons on the
remote to highlight Picture
Mode, then use the Left/Right
Arrow buttons to change the
picture mode:
• Standard sets the various
picture settings to values
that meet
(1(5*<67$5
®
requirements.
• Calibrated sets the picture
settings to values perfect for
watching TV in a brightly-lit
room.
• Calibrated Dark sets the picture settings to values perfect
for watching TV in a dark room.
• Vivid sets the picture settings to values that produce a
When changes are made while a preset picture mode
is selected, an asterisk appears after the name of the
picture mode. These settings can be saved as a new
custom picture mode and the preset mode can be reset
to its default settings.
(see Creating a Custom Picture
Mode on page 23).
brighter, more vivid picture.
• Game reduces throughput delays and optimizes the picture
settings for displaying game console output.
• Computer optimizes the picture settings for displaying
computer output.
4. To manually change each of the picture settings, use the Up/
Down Arrow buttons on the remote to highlight that picture
setting, then use the Left/Right Arrow buttons to adjust the
setting:
• Auto Brightness Control - Detects the light levels in the
room and automatically adjusts the backlight for the best
picture. Select 2, Low, Medium, or High.
• Backlight$GMXVWVWKH/('EULJKWQHVVWRDHFWWKHRYHUDOO
brilliance of the picture. Backlight cannot be adjusted when
starting from some picture modes.
• Brightness - Adjusts the black level of the picture. When
this setting is too low, the picture may be too dark to
distinguish details. When this setting is too high, the picture
may appear faded or washed out.
• Contrast - Adjusts the white level of the picture. When this
setting is too low, the picture may appear dark. When this
setting is too high, the picture may appear faded or washed
out. If the setting is too high or too low, detail may be
GLɝFXOWWRGLVWLQJXLVKLQGDUNRUEULJKWDUHDVRIWKHSLFWXUH
• Color - Adjusts the intensity of the picture colors.
• Tint - Adjusts the hue of the picture. This setting is useful in
DGMXVWLQJWKHȵHVKWRQHVLQWKHSLFWXUHΖIȵHVKDSSHDUVWRR
orange, reduce the level of color before adjusting tint.
• Sharpness - Adjusts the edge sharpness of picture
elements. It can be used to sharpen non-HD (high
GHȴQLWLRQFRQWHQWKRZHYHULWZLOOQRWSURGXFHGHWDLOWKDW
does not otherwise exist.
5. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKHSLFWXUHVHWWLQJVSUHVV
BACK to adjust additional settings or EXIT.
VIZIO
Picture Mode Standard
Auto Brightness Control Medium
Backlight 85
Brightness 50
Contrast 50
Color 59
Tint 0
Sharpness 9
More Picture
Picture Mode Edit
Color Calibration
-
+
+
-
-
+
-
+
-
+
-
+
Select from preset picture modes. Standard
picture mode meets ENERGY STAR
®
requirements. For the best picture, use
Calibrated mode. To reduce video delay
(lag) when gaming, use Game mode.
5
22
Adjusting the More Picture Settings
To adjust the More Picture settings:
1. From the PICTURE menu, use
the Arrow buttons to highlight
More Picture, and then press
OK. The MORE PICTURE menu is
displayed.
2. Use the Arrow buttons to
highlight the setting you wish
to adjust, then press the Left/
Right Arrow buttons to change
the setting:
• Color Temperature -
Adjusts the 'warmness' and
'coolness' of the white areas
of the picture. Select Cool,
Normal, or Computer.
• Cool produces a blue-hued
picture.
• Normal is optimized for
television viewing.
• Computer optimizes the
picture for use as a
PC monitor.
• Black Detail - Adjusts the average brightness of the picture
to compensate for large areas of brightness. Select 2,
Low, Medium, or High.
• Clear Action - Reduces blur in scenes with fast action. Some
VHQVLWLYHYLHZHUVPD\QRWLFHȵLFNHU6HOHFWOn or 2.
• Backlight Control - Dynamically improves the contrast
ration of the picture by adusting the backlight. Select 2 or
On.
• Reduce Signal Noise - Reduces background picture noise
when viewing analog sources. The function helps to correct
"speckle" noise with a slight reduction in sharpness.Select
2, Low, Medium, or High.
• Reduce Block Noise - Reduces pixelation and distortion for
PSHJȴOHV6HOHFW2, Low, Medium, or High.
• Game Low Latency - Reduces video delay (lag) when
gaming. Select 2, or On. This option is not available for
devices connected using a coaxial cable.
• Picture Size & Position - Picture Size increases or
decreases the vertical and horizontal size of the displayed
picture. Picture Position adjusts the vertical and horizontal
positions of the picture to ensure the image is centered
DQGFRPSOHWHO\ȴOOVWKHVFUHHQ8VHWKHLeft/Right Arrow
buttons to adjust the horizontal position of the displayed
picture. Use the Up/Down Arrow buttons to adjust the
vertical position of the displayed picture. Press the OK
EXWWRQZKHQ\RXDUHȴQLVKHG
• Film Mode2SWLPL]HVWKHSLFWXUHIRUZDWFKLQJȴOP6HOHFW
Auto or 2.
• Gamma - Sets the shape of the gamma curve. Use lower
values for bright room conditions and higher values when it
is dark. Select 1.8, 2.0, 2.1, 2.2, or 2.4.
3. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKH0RUH3LFWXUHVHWWLQJV
press BACK to adjust additional settings or EXIT.
VIZIO
MORE PICTURE
Color Temperature Cool
Black Detail Medium
Clear Action Off
Backlight Control
Reduce Signal Noise Low
Reduce Block Noise Low
Game Low Latency
Picture Size & Position
Film Mode Auto
Gamma 2.2
5
23
Adjusting the Picture Mode Edit Settings
To adjust the Picture Mode Edit settings:
1. From the PICTURE menu, use
the Arrow buttons to highlight
Picture Mode Edit, and then
press the OK button. The
PICTURE MODE EDIT menu is
displayed.
2. Use the Arrow buttons to
highlight the setting you wish
to adjust, then press the Left/
Right Arrow buttons to change
the setting:
• Save Picture Mode - Saves
the settings for a custom
picture mode.
• Lock Picture Mode - Prevent/
allow changes to the
currently selected custom
picture mode. Select On or
2.
• Reset Picture Mode
- Resets
the picture mode settings to
factory default values.
3. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKH3LFWXUH0RGH(GLW
settings, press BACK to adjust additional settings or EXIT.
VI
ZI
O
PICTURE MODE EDIT
Save Picture Mode
Lock Picture Mode
Reset Picture Mode
Creating a Custom Picture Mode
Custom picture modes allow you to save a group of custom settings
for various viewing conditions and video sources.
When changes are made while a preset picture mode is selected, an
asterisk appears after the name of the picture mode. These settings
can be saved as a new custom picture mode and the preset mode
can be reset to its default settings.
A custom picture mode only applies to the input (HDMI-
1, HDMI-2, COMP, AV, etc.) in use when it was created.
Each input can have up to six custom picture modes.
To create a custom picture mode:
1. Set the Picture Mode to an
existing custom setting. See
Adjusting the Picture Settings
on
page 21.
2. From the PICTURE menu, use
the Arrow buttons to highlight
Picture Mode Edit and press
OK. The PICTURE MODE EDIT
menu is displayed.
3. On the PICTURE MODE EDIT
menu, select Save Picture
Mode. The
SAVE PICTURE MODE menu is
displayed.
4. Use the Arrow buttons to
enter a custom name using the
on-screen keyboard.
5. Highlight Save and press OK.
6. Press the EXIT button to exit the
menu screens.
VIZIO
SAVE PICTURE MODE
<type custom name>
Save
a b c d e f g h i
j k l m n o p q r
s t u v w x y z 0
1 2 3 4 5 6 7 8 9
.@# äêí Space
5
24
Locking and Unlocking the Custom Picture Modes
&XVWRPSLFWXUHPRGHVFDQEHORFNHGZLWKDXQLTXH3Ζ1WRSUHYHQW
accidental changes to their settings.
To lock all custom picture modes:
1. From the PICTURE menu, use
the Arrow buttons to highlight
Picture Mode Edit and select
Lock or Unlock Picture
Mode, then press OK. The
LOCK PICTURE MODE menu is
displayed.
2. Use the Number Pad on your
remote to enter a unique 4-digit
3Ζ1
3. Highlight Save and then press
the OK button.
4. Press the EXIT button to exit the
menu screens.
To unlock all custom picture modes:
5. From the PICTURE menu, use
the Arrow buttons to highlight
Picture Mode Edit and select
Lock or Unlock Picture
Mode, then press OK. The
LOCK PICTURE MODE menu is
displayed.
6. Use the Number PadRQ\RXUUHPRWHWRHQWHU\RXUGLJLW3Ζ1
7. Make any desired changes to the picture modes.
8. 7RUHORFNSLFWXUHPRGHV\RXPXVWFUHDWHDQHZGLJLW3Ζ1
VIZIO
LOCK PICTURE MODE
Create a picture control PIN to
prevent change to all custom
picture modes.
Save
Create a 4 digit passcode using the num-
ber keys on the remote.
Deleting a Custom Picture Mode
Custom picture modes that are no longer needed can be deleted.
To delete a custom picture mode:
1. From the PICTURE menu, use
the Arrow buttons to highlight
Picture Mode Edit and select
Lock or Unlock Picture Mode,
then press OK. The DELETE
PICTURE MODE window is
displayed.
2. Use the Left/Right Arrow buttons to highlight Delete and
press OK.
3. Press the BACK button to adjust additional settings or EXIT.
Inputs assigned to a deleted custom picture mode
become assigned to the
Calibrated
picture mode.
To delete the user created Custom 1 picture mode,
select the Delete button.
Delete
Cancel
5
25
• Reset Color Tuner - Resets the color tuner settings for the
current color temperature mode.
• If the current picture mode is a pre-set, the color
temperature is reset for all pre-set picture modes using
WKHFXUUHQWFRORUWHPSHUDWXUHPRGHΖWGRHVQRWDHFW
saved custom picture modes.
• If the current picture mode is a saved custom picture
mode, the color temperature only reset for that custom
SLFWXUHPRGHVΖWGRHVQRWDHFWSUHVHWSLFWXUHPRGHV
or other custom picture modes.
For example, suppose that:
• You have created two custom picture modes: “My Picture
6HWWLQJVȋDQGȊ2OLYHUȋ7KH\ERWKXVHWKH1RUPDOFRORU
temperature, but you have adjusted it for each of the
modes.
• You have changed the Color Tuner settings for the
1RUPDOFRORUWHPSHUDWXUHZKLOHLQWKH&DOLEUDWHGSLFWXUH
mode.
6R\RXKDYHȊ0\3LFWXUH6HWWLQJVȋZLWKDPRGLȴHG1RUPDO
FRORUWHPSHUDWXUHȊ2OLYHUȋZLWKGLHUHQWFKDQJHVWRWKH
1RUPDOFRORUWHPSHUDWXUHDQGDWKLUGVHWRIFKDQJHVWRWKH
1RUPDOFRORUWHPSHUDWXUHWKDWDSSO\WRDOORIWKHSUHVHW
picture modes.
The Calibrated and Calilbrated Dark picture modes both
XVHWKH1RUPDOFRORUWHPSHUDWXUHΖI&DOLEUDWHGLVWKH
FXUUHQWSLFWXUHPRGHZKHQWKH1RUPDOFRORUWHPSHUDWXUH
LVUHVHWWKHFKDQJHDHFWVERWKRIWKHVHSLFWXUHPRGHV
but does not undo the changes to the color temperature for
the “My Picture Settings” or “Oliver” custom picture modes.
If “My Picture Settings is the current picture mode when the
1RUPDOFRORUWHPSHUDWXUHLVUHVHWWKHFKDQJHonlyDHFWV
“My Picture Settings” picture mode. The color temperature
changes to the “Oliver,” Calibrated, and Calibrated Dark
picture modes stay as they are.
Adjusting the Color Calibration Settings
Color Calibration Settings allow you to make precise adjustments to
the picture and to create picture modes to save groups of picture
settings.
The Color Tuner, 11 Point White Balance, and test
patterns allow technicians to manually calibrate the TV.
Calibration requires specialized training, an input with
precisely set colors, and a specialized light meter.
To adjust the color calibra picture settings:
1. From the PICTURE menu, use
the Arrow buttons to highlight
Color Calibration and press
the OK button. The COLOR
&$/Ζ%5$7Ζ21 menu is displayed.
2. Use the Arrow buttons to
highlight the setting you wish to
adjust, then press the OK button
to change the setting:
• Picture Mode - 1RWGLUHFWO\
selectable (reference only).
Changes to Hue,
Saturation, and Brightness are
saved here and indicated with
an asterisk (*).
• Color Temperature - 1RWGLUHFWO\
VHOHFWDEOHUHIHUHQFHRQO\&KDQJHVWR2VHWDQG*DLQDUH
saved here and indicated with an asterisk (*).
• Color Tuner - $GMXVWWKH+6%FRORU5*%RVHWVDQG
11-point white balance, and display calibration test
patterns.
VI
ZI
O
COLOR CALIBRATION
Picture Mode*
Color Temperature*
Color Tuner
Reset Color Tuner
5
26
7RWXUQFRORUFKDQQHOVRDQGRQ
1. From the PICTURE menu, use the Arrow buttons to highlight
Color Calibration and press the OK button. The COLOR
&$/Ζ%5$7Ζ21 menu is displayed.
2. Use the Arrow buttons to highlight Color Tuner, and then
press the OK button. The Color Tuner menu is displayed ..
3. Use the Arrow buttons on the remote to highlight Red, Green,
or Blue.
4. Press the OKEXWWRQWRWXUQWKHFRORUFKDQQHORRURQ$Q;
DSSHDUVRYHUDFRORUFKDQQHOWKDWKDVEHHQWXUQHGR
5. Use the Arrow buttons to highlight another color channel to
WXUQRRURQ2QO\WZRFRORUFKDQQHOVFDQEHWXUQHGRDWWKH
same time.
6. :KHQ\RXDUHȴQLVKHGZLWKWKHFRORUFKDQQHOVSUHVVWKHBACK
button to adjust additional settings or EXIT.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
Adjusting the Color Tuner Settings
The Color Tuner settings allow you to adjust the Hue, Saturation,
and Brightness (HSB) color and 11 point white balance, turn color
FKDQQHOVRIRU WHVWLQJDQGGLVSOD\ FRORUEDUȵDWDQGUDPSWHVW
patterns.
To adjust the HSB color settings:
1. From the PICTURE menu, use the Arrow buttons to highlight
Color Calibration and press the OK button. The COLOR
&$/Ζ%5$7Ζ21 menu is displayed.
2. Use the Arrow buttons to highlight Color Tuner, and press the
OK button. The Color Tuner menu is displayed.
3. Use the Arrow buttons on the remote to highlight the Hue,
Saturation, Brightness, (these 3 adjust the color) 2VHW, or
Gain (these two adjust the color temperature) of the color you
wish to adjust. Press the OK button.
4. Use the Left/Right Arrow buttons to adjust the value. When
\RXDUHȴQLVKHGSUHVVWKHOK button to save the setting.
5. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKH&RORU7XQHUVHWWLQJV
press the BACK button to adjust additional settings or EXIT.
Changes to Hue, Saturation, and Brightness are indicated with
an asterisk (*) on the Picture Mode setting.
&KDQJHVWR2VHWDQG*DLQDUHLQGLFDWHGZLWKDQDVWHULVNRQ
the Color Temperature setting.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
5
27
To show or hide the Color Bar Test Pattern:
1. Ensure that you are on an input that is displaying active
content. From the Color Tuner menu, use the Arrow buttons
to highlight Color Tuner, and then press the Left/Right Arrow
buttons until the SMPTE Test Pattern menu is displayed.
Color Bar Test Pattern
Off
2. Use the Arrow buttons on the remote to highlight 2. Use the
Left/Right Arrow buttons to highlight On to show the Color
Bar.
—or—
To hide the Color Bar Test Pattern, use the Left/Right Arrow
buttons to highlight 2.
3. :KHQ\RXDUHȴQLVKHGpress the BACK button to adjust
additional settings or EXIT.
To adjust the 11 Point White Balance settings:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the 11 Point White Balance menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Gain
and Color values you wish to adjust. Press the OK button and
use the Left/Right Arrow buttons to adjust the value. When
\RXDUHȴQLVKHGSUHVVWKHOK button to save the setting.
3. :KHQ\RXDUHȴQLVKHGSUHVVWKHBACK button to adjust
additional settings or EXIT.
All changes here are saved to Color Temperature.
11 Point White Balance
Gain Red Green Blue
5% 0 0 0
5
28
To show or hide the Ramp Test Pattern:
1. Ensure that you are on an input that is displaying active
content. From the Color Tuner menu, use the Arrow buttons to
highlight Color Tuner, and then press the Left/Right Arrow
buttons until the Ramp Test Pattern menu is displayed.
2. Use the Arrow buttons on the remote to highlight 2. Use the
Left/Right Arrow buttons to select the color for the ramp test
pattern. Selecting a color immediately shows that color ramp.
—or—
To hide the Ramp Test Pattern, use the Left/Right Arrow
buttons to highlight 2.
3. :KHQ\RXDUHȴQLVKHGSUHVVWKHBACK button to adjust
additional settings or EXIT.
Ramp Test Pattern
Off
To show or hide the Flat Test Pattern:
1. Ensure that you are on an input that is displaying active
content. From the Color Tuner menu, use the Arrow buttons
to highlight Color Tuner, and then press the Left/Right Arrow
buttons until the Flat Test Pattern menu is displayed.
Flat Test Pattern
Off
2. Use the Arrow buttons on the remote to highlight 2. Use the
Left/Right Arrow buttons to select the percentage brightness
IRUWKHȵDWWHVWSDWWHUQSelecting a percentage immediately
VKRZVWKHȵDWSDWWHUQDWWKDWbrightness.
—or—
To disable the Flat Test Pattern, use the Left/Right Arrow
buttons to highlight 2.
3. :KHQ\RXDUHȴQLVKHGpress the BACK button to adjust
additional settings or EXIT.
5
29
ADJUSTING THE AUDIO SETTINGS
To adjust the audio settings:
1. Press the MENU button on the
remote. The on-screen menu
is displayed.
2. Use the Arrow buttons on the
remote to highlight Audio and
press OK. The AUDIO menu
is displayed.
3. Use the Arrow buttons to
highlight the setting you wish
to adjust, then press Left/Right
Arrow buttons to change
the setting:
• TV Speakers - Turns the
EXLOWLQVSHDNHUVRQRUR
• Surround Sound - Surround sound uses DTS TruSurround
™
to deliver an immersive surround sound experience from
the TV’s internal speakers. TruSurround completes the
entertainment experience by providing deep, rich bass
and by delivering crisp details and clear, intelligible dialog.
Select On or 2.
• Volume Leveling - Volume leveling uses DTS TruVolume
™
to maintain consistent volume levels during transitions
between program content, AV formats, and input sources.
Select On or 2. In a few cases, volume leveling may
DUWLȴFLDOO\ VXSSUHVV YROXPH LQFUHDVHVPDNLQJ LW GLɝFXOW WR
KHDUGLDORJ RUȵDWWHQLQJVXGGHQQRLVHVΖI WKLVRFFXUVWXUQ
YROXPHOHYHOLQJR
VIZIO
AUDIO
TV Speakers On
Surround Sound On
Volume Leveling On
Balance 0
Lip Sync 0
Digital Audio Out PCM
Analog Audio Out Fixed
Equalizer
Delete Audio Mode
-
+
-
+
When the TV speakers are set to On, DTS signals cannot
be passed through digital audio outputs.
• Balance - Adjusts the loudness of the audio output from
the left and right speakers.
• Lip Sync - Adjusts the synchronization between the display
image and the accompanying audio track.
• Digital Audio Out - Changes the type of processing for
HDMI ARC or optical output when connected to a home
theater audio system. Select PCM or Bitstream.
• Analog Audio Out - Sets the volume control properties for
the 3.5mm (headphone jack) connector when connected
to a home theater audio system. Select Variable to control
the headphones’ volume from the TV’s volume controls, or
select Fixed to control the headphones’ volume from your
home theater system controls. (Some external speakers can
also be connected to the 3.5mm connector.)
• Equalizer$GMXVWVWKHERRVWRUDWWHQXDWLRQRIGLHUHQW
frequencies using either preset or custom settings. See
Changing the Equalizer Settings
on page 30.
• Delete Audio Mode - Deletes a custom audio mode created
using the Equalizer Settings. See
Deleting the Custom Audio
Mode on page 30
.
This option is cannot be selected if no custom audio
mode has been created.
4. :KHQ\RXKDYHȴQLVKHGDGMXVWLQJWKHDXGLRVHWWLQJVSUHVVWKH
BACK button to adjust additional settings or EXIT.
You must select Bitstream for audio with more than
two channels (3.0, 5.0, or 5.1, for example).
5
30
Deleting the Custom Audio Mode
To delete the custom audio mode that has been created:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Audio and
press OK. The AUDIO menu is displayed.
3. Use the Arrow buttons to highlight Delete Audio Mode and
press OK. The TV displays, “To delete the user created custom
audio mode, select the Delete button.”
4. Highlight Delete and press OK.
5. Press the BACK button to adjust additional settings or EXIT.
Changing the Equalizer Settings
The graphic equalizer has several pre-set modes and allows you to
create one custom mode.
To select a pre-set audio mode:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Audio and
press OK. The AUDIO menu is displayed.
3. Use the Arrow buttons to highlight Equalizer and press OK.
The Audio Mode and equalizer settings screen appears.
4. Use the Left and Right Arrow buttons to select an audio mode
(Flat, Dynamic, Center, Bass Boost, or Bright). The equalizer
EDUVFKDQJHWRUHȵHFWWKHPRGH
5. Press the BACK button to adjust additional settings or EXIT.
To create, modify, or replace the single custom equalizer setting:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Audio and
press OK. The AUDIO menu is displayed.
3. Use the Arrow buttons to highlight Equalizer and press OK.
The Audio Mode and equalizer settings screen appears.
4. Use the Left and Right Arrow buttons to select any audio
mode as a starting point.
5. Use the Arrow buttons to highlight a frequency and then press
OK.
6. Use the Up and Down Arrow buttons to adjust the boost (up)
and attenuation (down) for the frequency.
7. Use the Left and Right Arrow buttons to select another
frequency, if desired, and adjust it.
8. Press the BACK button to adjust additional settings or EXIT.
5
31
6HWWLQJWKH$XWR3RZHU2)HDWXUH
7R KHOS VDYH HQHUJ\ \RXU 79 LV VHW E\ GHIDXOW WR WXUQ R DIWHU
10 minutes without a video or audio signal. This feature can be
deactivated.
7RVHWWKH$XWR3RZHU2IHDWXUH
1. From the TIMERS menu, use the Up/Down Arrow buttons on
the remote to highlight $XWR3RZHU2.
2. Use the Left/Right Arrow buttons on the remote to change
ZKHWKHUWKH79ZLOOWXUQR If you don’t want the TV to turn
RZKHQWKHUHLVQRVLJQDOFKDQJHWKHVHWWLQJWR2or 10
minutes.
3. :KHQ\RXKDYHȴQLVKHGVHWWLQJWKHDXWRSRZHURWLPHSUHVV
the BACK button to adjust additional settings or EXIT.
SETTING TIMERS
7KLV79KDVVHYHUDOWLPHUVWRVDYHHQHUJ\DQGWRWXUQRZKHQ\RX
go to sleep.
Setting the Sleep Timer
:KHQDFWLYDWHGWKH79ȇVVOHHSWLPHUZLOOWXUQWKH79RDIWHUDVHW
period of time.
1. Press the MENU button on the
remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the
remote to highlight Timers and
press OK. The TIMERS menu is
displayed.
3. Use the Left/Right Arrow
buttons on the remote to
highlight the period of time after
which you want the TV to go to
sleep: 30, 60, 90, 120, or 180
minutes. If you don’t want the
sleep timer to activate, change
the setting to 2.
4. :KHQ\RXKDYHȴQLVKHGVHWWLQJ
the sleep timer, press the BACK
button to adjust additional
settings or EXIT.
VIZIO
TIMERS
Sleep Timer Off
Auto Power Off 10 minutes
5
32
SETTING UP CHANNELS
You can use the TV’s Channels menu to:
• Select a Channel Source
• Find channels
• Perform a partial channel scan
• Manually add channels
• Select channels to skip
• Select language for analog
and digital channels
VIZIO
CHANNELS
Channel Source Antenna
Find Channels
Partial Channel Search
Add Analog Channel
Skip Channel
Analog Audio Stereo
Digital Language English
VIZIO
FIND CHANNELS
Channels Found
Digital: 0
Analog: 19
18% Complete
Cancel
Cancel the channel scan.
Selecting a Channel Source
1. On the remote control, press Input and use the Arrow button
to highlight TV (antenna icon), then press OK.
2. Press the MENU button, select Channels and press OK. The
&+$11(/6PHQXLVGLVSOD\HG
3. 2QWKH&+$11(/6PHQXKLJKOLJKWChannel Source and using
the left/right Arrow buttons to select either Antenna or Cable.
Finding Channels
The TV may need to scan for channels before it can display programs
and their associated information. A channel scan is required for
free over-the-air channels (using an antenna) and cable channels
from an out-of-the-wall connection (without a cable box). Moving
WKH79WRDQDUHDZLWKGLHUHQWFKDQQHOVUHTXLUHVWKH79WRVFDQIRU
channels again.
To perform an Auto Channel Scan:
1. )URPWKH&+$11(/6 menu,
highlight Find Channels and
press OK. The auto channel scan
begins.
2. Wait until the channel scan is
100% complete. Highlight Done
and press OK.
3. Press the EXIT button on the
remote.
If the channel scan is cancelled,
the channels that were already
discovered are retained. A new
channel scan will clear all channels.
5
33
Adding New Channels
Occasionally, you may need to add a new range of channels or add
a new analog channel. You can do this by using the Partial Channel
Scan and Add Analog Channel options. This is quicker than scanning
all possible channels.
To add a range of new channels:
1. )URPWKH&+$11(/6 menu, highlight Partial Channel Search,
and press OK. The 3$57Ζ$/&+$11(/6($5&+ menu is
displayed.
2. Highlight Scan Mode and select the type of channel you are
adding: Analog, Digital, or Analog/Digital.
3. Highlight From Channel and type the channel where you want
to begin the scan. (Use the left Arrow button to backspace.
Use the Number Pad on the remote to type the channel.)
4. Highlight To Channel and enter the channel where you want to
end the scan. (Use the left Arrow button to backspace. Use the
Number Pad on the remote to enter the channel.)
5. Highlight Start and press OK. The partial channel search
begins.
6. Wait until the partial channel search is 100% complete.
Highlight Done and press OK.
7. Press the EXIT button on the remote.
To add a single new analog channel:
1. )URPWKH&+$11(/6PHQX
highlight Add Analog Channel
and press OK. The $''$1$/2*
&+$11(/ menu is displayed.
2. Highlight Enter Channel # and
use the Number Pad on the
remote to type the number of
the channel to be added.
3. Highlight Add Channel and
press OK. The TV scans for the
channel.
4. When the TV is done scanning
for the channel, press the EXIT
button on the remote.
VIZIO
ADD ANALOG CHANNEL
Enter Channel #
Add Channel
5
34
Skipping Channels
$IWHUDFKDQQHOVFDQLVFRPSOHWHG\RXPD\ȴQGWKDWVRPHFKDQQHOV
are too weak to watch comfortably. There may also be some
channels you do not want to view. You can remove these channels
from the TV’s memory with the Skip Channel feature.
Channels that have been removed with the Skip Channel
feature can still be viewed if the channel is entered
XVLQJWKH1XPEHU3DGΖI\RXZLVKWRFRPSOHWHO\EORFN
a channel from being viewed, use the parental controls.
See
Locking and Unlocking Channels on page 41
.
To remove a channel:
1. )URPWKH&+$11(/6PHQX
highlight Skip Channel, and
press OK. The 6.Ζ3&+$11(/
menu is displayed.
2. For each channel you wish to
remove, use the Up/Down
Arrow buttons on the remote to
highlight the channel and press
OK. A
3 appears to the right of
each channel you select.
3. When you have selected all
of the channels you wish to
remove, press BACK to adjust
additional settings or EXIT.
VIZIO
SKIP CHANNEL
1
Test 0
1
Test 1
3
1-2
Test 2
3
2
Test 3
2-2
Test 4
3
2-3
Test 5
5
35
Changing the Digital Audio Language
Some digital over-the-air (free), cable, and satellite channels
broadcast programs in more than one language. The TV’s Digital
Audio feature allows you to listen to audio in alternate languages.
1RWDOOSURJUDPVDUHEURDGFDVWLQDOWHUQDWHODQJXDJHV
The Digital Audio Language feature only works when
the program being viewed is being broadcast in the
language you select.
1. )URPWKH&+$11(/6menu,
highlight Digital Language
and press OK. The DIGITAL
/$1*8$*( menu is displayed.
2. Select your preferred language:
English, Français, or Español
and press OK.
3. Press BACK to adjust additional
settings or EXIT.
VIZIO
DIGITAL LANGUAGE
English
Español
Français
LISTENING TO ALTERNATE AUDIO
Changing the Analog Audio Language
Some analog over-the-air (free) and cable channels broadcast
programs in more than one language. The TV’s Analog Audio
feature allows you to listen to audio in an alternate language using
Secondary Audio Programming (SAP).
1RWDOOSURJUDPVDUHEURDGFDVWLQ6$37KH$QDORJ
Audio Language feature only works when the program
being viewed is being broadcast with Secondary Audio
Programming.
To use the Analog Audio feature:
1. )URPWKH&+$11(/6menu,
highlight Analog Audio and
press OK. The $1$/2*$8'Ζ2
menu is displayed.
2. Select Stereo, SAP (secondary
audio programming), or Mono.
Press OK.
3. Press BACK to adjust additional
settings or EXIT.
VIZIO
ANALOG AUDIO
Stereo
SAP
Mono
5
36
SETTING UP CLOSED CAPTIONING
Your TV can display closed captions for programs that include them.
Closed captions display a transcription of a program’s dialogue.
The Closed Captions menu does not appear when an
HDMI input is selected.
To activate or deactivate closed captions:
1. Press the MENU button on the
remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the
remote to highlight Closed
Captions and press OK. The
&/26('&$37Ζ216 menu is
displayed.
3. Use the Arrow buttons on the
remote to highlight Closed
Captions and then use the Left/
Right Arrow buttons to select
On or 2.
4. Use the Arrow buttons on
the remote to highlight either
Analog or Digital Closed
Captions.
5. Use the Left/Right Arrow
buttons on the remote to select
the caption channel you wish to
display, then press BACK to adjust
additional settings or EXIT.
If the program you are viewing is not being broadcast
with closed captions, the TV will not display them.
VIZIO
CLOSED CAPTIONS
Closed Captions Off
Analog Closed Captions CC1
Digital Closed Captions CS1
Digital Style
Changing the Appearance of Digital Closed Captions
Digital closed captions can be displayed according to your
preference. See the diagram on the next page for an explanation of
the parts of the closed caption area.
To change the appearance of digital closed captions:
1. From the &/26('&$37Ζ21S
menu, use the Arrow buttons to
highlight Digital Style and press
OK.
2. Use the Left/Right Arrow
buttons on the remote to
select Custom and press OK.
The DIGITAL STYLE menu is
displayed.
3. Use the Up/Down Arrow
buttons on the remote to
highlight the setting you wish to
change, then use the Left/Right
Arrow buttons to change the
setting:
• Caption Style - Choose
As Broadcast to keep
default settings or Custom
to manually change each
setting.
• Text Style - Change the
font used for the closed
captioning text.
• Text Size - Make the text larger or smaller.
• Text Color - Change the color of the text.
• Text Opacity - Change the transparency of the text.
• Text Edges&KDQJHWKHHHFWVDWWKHHGJHVRIWKHWH[W
such as raising the edges or adding drop shadows.
VIZIO
DIGITAL STYLE
Caption Style
Custom
Text Style
As Broadcast
Text Size
Large
Text Color
Green
Text Opacity
As Broadcast
Text Edges
As Broadcast
Text Edges Color
As Broadcast
Background Color
Black
Background Opacity
As Broadcast
Window Color
Red
Window Opacity
As Broadcast
Select As Braodcase to display digital captions
as sent by the caption provider. The color and
size for the caption text and background can
still be customized.
5
37
• Text Edges Color - Change the color of the text edge
HHFWV
• Background Color - Change the color of the background
directly behind the text.
• Background Opacity - Change the transparency of the
background directly behind the text.
• Window Color - Change the color of the closed captioning
box.
• Window Opacity - Change the transparency of the closed
captioning box.
4. :KHQ\RXDUHVDWLVȴHGZLWKWKHDSSHDUDQFHRIWKHFORVHG
captions, press the EXIT button on the remote.
Typical choices include:
• Opaque background, transparent window—Only a strip of
background appears behind the text, expanding as the text
appears. This is the typical "As Broadcast" mode.
• Opaque background and window in the same color—When
WH[WDSSHDUVWKHHQWLUHOLQHȴOOVZLWKFRORUDWRQFH
In the example below, the closed caption text is green, the
background is black, and the window is red.
CLOSED CAPTIONS SCREEN LAYOUT
Text
Window
Background
&/26('&$37Ζ217(;76$03/(
5
38
RENAMING DEVICES ON THE INPUT MENU
Inputs can be renamed to make them easier to recognize on the
Input menu (see
Changing the Input Source
on page 20). For
example, if you have a DVD player connected to the Component
input, you can rename that input to display “DVD Player.”
To change the name of an input:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight Devices and
press the OK button. The DEVICES menu is displayed.
3. Highlight the input port that you want to name and press OK.
4. To use a preset input name:
a. Highlight the Input Port row and press OK.
b. Highlight the input name you want to use (HDMI-1, Blu-ray,
Cable Box, Computer, DVD, DVR, Game, or Satellite) and
press OK.
—or—
To enter a custom name:
a. Enter your custom name using the on-screen keyboard.
b. Highlight OK and press OK.
c. 7KHΖQSXW1DPHFKDQJHVWRVKRZWKHFXVWRPQDPHWKDW
you created.
5. :KHQ\RXKDYHȴQLVKHGQDPLQJ\RXULQSXWSUHVVthe BACK
button to adjust additional settings or EXIT.
VIZIO
NAME INPUT
HDMI-1 DVD
DVD_
OK
Cancel
Select the input name from a list of
common device names (Blu-ray, Cable
Box, DVD, etc).
a b c d e f g h i
j k l m n o p q r
s t u v w x y z 0
1 2 3 4 5 6 7 8 9
.@# äêí Space
Input Port
Custom Name
Input Name
5
39
CHANGING THE TV SETTINGS
Using the System menu, you can:
• View system information
• Change the on-screen menu
language
• Set the time zone and local
settings
• Set up parental controls
• Change the Wide settings
• Adjust the California Energy
Commission (CEC) settings
• Adjust when the power
indicator is illuminated
• Reset the TV settings and set
up administrative controls
VIZIO
SYSTEM
System Information
Menu Language English
Time & Local Settings
Parental Controls
Wide
CEC
Power Indicator Off
Reset & Admin
Viewing System Information
To view a summary of the TV settings:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight System and
press OK. The SYSTEM menu is displayed.
3. Highlight System Information and press OK.
4. Use the Up/Down Arrow buttons to scroll through the system
information.
System information is used verify settings and the
ȴUPZDUHYHUVLRQ
5. :KHQ\RXDUHȴQLVKHGUHYLHZLQJWKHV\VWHPLQIRUPDWLRQSUHVV
the BACK button to view or change additional settings or EXIT.
View status information for the TV and
current input.
5
40
Changing the On-Screen Menu Language
<RXU79FDQGLVSOD\WKHRQVFUHHQPHQXLQGLHUHQWODQJXDJHV
To change the on-screen menu language:
1. Press the button on the
remote. The on-screen menu is
displayed.
2. Use the buttons on the remote
to highlight and press . The
SYSTEM menu is displayed.
3. Use the buttons on the remote
to highlight and press . The
0(18/$1*8$*( menu is
displayed.
4. Highlight your preferred
language (, , or ) and press . All
screens will now be displayed in
the selected language.
5. Press the button to change
additional settings or .
VIZIO
MENU LANGUAGE
English
Español
Français
Setting the Time and Local Settings
When your TV signal come from an antenna, your TV receives time
information as part of the broadcast signal. The time is displayed as
part of the information when you press the INFO button. However,
you need to set your time zone and Daylight Saving Time state to
ensure that the correct time is displayed.
To set the TV’s time zone and whether Daylight Saving Time is in
HHFW
1. Press the MENU button on the
remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the
remote to highlight System and
press OK. The SYSTEM menu is
displayed.
3. Use the Arrow buttons on the
remote to highlight Time & Local
Settings and press OK. The
menu headed by the local date
and time is displayed.
4. Highlight Time Zone and press
OK. The 7Ζ0(=21( menu is
displayed.
5. Highlight your time zone and press OK.
6. Highlight Daylight Saving Time and press OK. The DAYLIGHT
6$9Ζ1*7Ζ0( menu is displayed. Choose On if it is currently
Daylight Saving Time, 2 if it is Standard Time.
7. Press the EXIT button on the remote.
VIZIO
Nov 06, 2014 12:44 PM
Time Zone Pacific
Daylight Saving Time Off
You'll need to change the Daylight Saving Time setting at
the start and end of Daylight Saving time.
5
41
Using the Parental Controls
The TV’s parental controls allow you to prevent the TV from
displaying certain channels or programs without a password.
The Parental Controls menu only appears when:
• You are using the tuner to receive your TV signals, such as
when you are using an antenna for Over-the-Air signals or
when connected to cable TV directly from the wall (no cable
box).
• You have a device connected using a composite video cable
or a coaxial cable, such as a VCR, satellite or cable box, or
DVR.
Accessing the Parental Controls Menu
To access the Parental Controls menu:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight System and
press OK. The SYSTEM menu is displayed.
3. Use the Arrow buttons on the remote to highlight Parental
Controls and press OK.
4. Enter your parental passcode. If you have not set a passcode,
enter the default, 0000. The 3$5(17$/&21752/6 menu is
displayed.
To set a custom parental passcode, see
Changing the
Parental Control Passcode
on page 42.
Enabling or Disabling Program Ratings
To manage program content according to its rating, you must
enable the Program Rating feature.
To enable or disable the Program Rating feature:
From the 3$5(17$/&21752/6 menu, highlight Locks and use the
left/right Arrow buttons to select On (enable) or 2 (disable).
Locking and Unlocking Channels
When a channel is locked, it will be inaccessible. Locking a channel
is a good way to prevent children from viewing inappropriate
material.
To lock or unlock a channel:
1. From the 3$5(17$/&21752/6 menu, highlight Channel
Locks and press OK. The &+$11(//2&.6 menu is displayed.
2. Highlight the channel you want to lock or unlock and press OK.
3. When a channel is locked, the Lock icon appears locked.
The channel is not accessible unless the parental passcode is
entered.
4. When a channel is unlocked, the Lock icon appears unlocked.
The channel is accessible.
5
42
Blocking and Unblocking Content by Rating
A channel may sometimes broadcast programs that are meant for
children, and at other times broadcast programs that are meant
for mature audiences. You may not want to block the channel
completely using a channel lock, but you may wish to block certain
programs from being viewed.
When this is the case, you can use the TV’s Rating Block feature to
block content based on its rating.
)RUDOLVWRIFRQWHQWUDWLQJVDQGWKHLUGHȴQLWLRQVYLVLW
www.tvguidelines.org.
To block or unblock content by its rating:
1. From the 3$5(17$/&21752/6 menu, highlight the content
type you want to adjust and press OK:
USA TV - USA television program broadcasts.
USA MOVIE - USA movie broadcasts.
Canadian English - Canadian English television program
broadcasts.
Canadian French - Canadian French television program
broadcasts.
2. For each rating type you want to block or unblock, use the
Up/Down and Left/Right Arrow buttons on the remote to
highlight the rating type and press OK.
3. When the rating type is blocked, the Lock icon appears
locked. Content with this rating and all higher ratings cannot
be viewed.
4. When the rating type is unblocked, the Lock icon appears
unlocked. Content with this rating and all lower ratings can be
viewed.
If you want to block all unrated content, highlight Block
Unrated Shows and use the Arrow buttons on the remote to
select On.
5. :KHQ\RXDUHȴQLVKHGDGMXVWLQJWKHUDWLQJOHYHOEORFNVSUHVV
the EXIT button on the remote.
Changing the Parental Control Passcode
If you use the parental controls, you should change the passcode to
prevent children from accessing inappropriate material.
To change the parental control passcode:
1. From the 3$5(17$/&21752/6 menu, highlight Change PIN
and press OK. The &+$1*(3Ζ1 menu is displayed.
2. In the New PINȴHOGXVHWKHNumber Pad on the remote to
enter your new 4-digit parental control passcode.
3. In the &RQȴUP3Ζ1ȴHOGXVHWKHNumber Pad on the remote
to re-enter your new 4-digit parental control passcode.
4. Write down your new parental control passcode and save it in
a secure location.
5. Press the EXIT button on the remote.
Resetting the Content Locks
To reset the content locks to the factory-default settings:
1. From the 3$5(17$/&21752/6 menu, highlight Reset Locks
and press OK. The TV displays, “Select Reset to restore Parental
Controls to factory defaults.”
2. Highlight Reset and press OK.
5
43
Adjusting the Wide Mode (Aspect Ratio)
7KH79FDQGLVSOD\LPDJHVLQȴYHGLHUHQWPRGHV1RUPDO6WUHWFK
Panoramic, Wide, and Zoom. Each mode displays the picture
GLHUHQWO\
To change the screen aspect ratio:
1. Press the MENU button on the
remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the
remote to highlight System and
press OK. The SYSTEM menu is
displayed.
3. Use the Arrow buttons on the
remote to highlight Wide and
press OK. The wide mode menu
appears at the top of the screen.
4. Use the Arrow buttons to highlight the aspect ratio you wish to
use and the press OK.
• Normal preserves the content’s original aspect ratio. Since
WKHDVSHFWUDWLRLVQRWODUJHHQRXJKWRȴOOWKH79ȇV
screen, black bars are added to the left and right of the
display image.
• StretchH[SDQGVWKHGLVSOD\LPDJHWRȴOOWKHVFUHHQΖPDJHV
may appear wider than intended. If you are watching
widescreen (1.85:1 or 2.35:1) content, black bars will still
appear on the top and bottom of the display image. This
option is only available when the TV is displaying a
720p/1080i source.
• PanoramicH[SDQGVWKHGLVSOD\LPDJHWRȴOOWKHZLGWKRI
the screen. Images may appear wider than intended. If
you are watching widescreen (1.85:1 or 2.35:1) content,
black bars will still appear on the top and bottom of the
display image. This option is only available when the TV is
displaying a 480i/480p source.
Panoramic
Wide
Zoom
Normal
Stretch
Wide
Zoom
Normal
Note: Aspect ratio settings may
vary by Input source.
• Wide stretches a 4:3 aspect ratio picture to the edges of
the screen. Since the picture is being stretched, the display
image may appear distorted. If the program is already
formatted for widescreen viewing (1.85:1 or 2.35:1), then
black bars will appear on the top and bottom of the display
image.
• ZoomH[SDQGVLPDJHVZLWKEODFNEDUVWRȴWWKHVFUHHQ
5
44
To begin device discovery:
• From the CEC menu, highlight Device Discovery and press
OK.
Your TV begins looking for CEC devices connected to all of its
HDMI inputs. When discovery is complete:
• The CEC-compatible devices are listed below Device
Discovery.
• The names of these devices now appear on the Input
menu.
• If an audio device was discovered, the TV's speakers are
WXUQHGR
• The VIZIO TV remote controls an attached VIZIO sound
bar or other audio system.
Controlling Other Devices with CEC
The CEC function on your TV enables you to control devices
connected to the HDMI (ARC) input with the included remote,
without any programming. Using CEC, your VIZIO TV remote can
control:
• 3RZHURQR
• Volume
• Mute
1RWDOO+'0ΖGHYLFHVVXSSRUW&(&6HH\RXUGHYLFHȇV
user manual for details.
To enable, disable, or adjust CEC settings:
1. Set up your audio device and connect it to the HDMI-1 (HDMI
ARC) input on the TV.
2. On your audio device, select the HDMI ARC input.
3. Press the MENU button on the remote. The on-screen menu is
displayed.
4. Use the Arrow buttons on the remote to highlight System and
press OK. The SYSTEM menu is displayed.
5. Use the Arrow buttons on the remote to highlight CEC and
press OK. The CEC Settings menu is displayed.
6. Highlight CEC and press OK. Select a setting and then press OK.
• CEC Function - To use CEC, you must select On.
• System Audio Control - To control your device’s audio
using the TV’s remote control, select On.
• Device Discovery - To determine if your device is
connected and supports CEC, select Device Discovery and
then press OK.
7. Press the EXIT button on the remote.
5
45
7XUQLQJWKH3RZHUΖQGLFDWRU2QRU2
The Power Indicator on the front of your TV normally does not glow
when the TV is on. You can change this setting if you prefer the light
to be on.
7RWXUQWKH3RZHUΖQGLFDWRU/LJKWRQRUR
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight System and
press OK. The SYSTEM menu is displayed.
3. Highlight Power Indicator and press OK. The POWER
Ζ1'Ζ&$725 menu is displayed.
4. Use the Up/Down Arrow buttons to select On or 2, then
press OK.
USING THE RESET & ADMIN MENU
Restoring the TV to Factory Default Settings
All of the on-screen menu settings can be reset to the factory default
settings.
If you restore the TV to the factory default settings, all
changes you have made to the settings will be lost!
To restore the TV to its factory default settings:
1. Press the MENU button on the remote. The on-screen menu is
displayed.
2. Use the Arrow buttons on the remote to highlight System and
press OK. The SYSTEM menu is displayed.
3. Highlight Reset & Admin and press OK. The 5(6(7$'0Ζ1
menu is displayed.
4. Highlight Reset TV to Factory Defaults and press OK.
If you have changed the default parental control passcode,
type it now.
The TV displays, “Select Reset to restore all TV settings to
factory defaults.”
5. Highlight Reset and press OK.
6. :DLWIRUWKH79WRWXUQR7KH79ZLOOWXUQEDFNRQVKRUWO\
afterward and the Setup App will begin.
7. To view a demonstration of TV functions on start-up, select
Store Demo > On.
5
46
USING THE GUIDED SETUP MENU
The TV’s Setup App can be used to easily set up channels on the TV.
To use guided setup:
1. Press the MENU button on the
remote. The on-screen menu is
displayed.
2. Highlight Guided Setup and
press OK. The GUIDED SETUP
menu is displayed.
3. Highlight Channel Setup and
press OK:
4. Follow the on-screen
LQVWUXFWLRQV:KHQȴQLVKHG
press the BACK button to
change additional settings or
EXIT.
VIZIO
GUIDED SETUP
Channel Setup
5
47
USING THE INFO WINDOW
The Info Window can be displayed by pressing the INFO or GUIDE
button on the remote:
• Press the INFO or GUIDE button one time to display
channel, input, and display information.
• Press the INFO or GUIDE button two times to display the
program title, program rating, audio information, and the
start and end times of the program.
DIGITAL EPISODE GUIDE & INFO WINDOW
Oliver’s Holiday Surprise
1080p 6:15pm
11:00AM - 12:00PM
TV-PG-V
Dolby Digital+ Stereo
Oliver wakes up one morning only to discover that his pals are missing. In this
hour-long holiday special, Oliver goes on a journey in search of his pals. Who
knows what he’ll encounter on the way?
Program Description
Program Title/Rating Information
Display Information
28-1
KCET-HD
Normal
Channel/Input Information
6
48
Using the USB Media Player
USING THE USB MEDIA PLAYER
The USB Media Player allows you to connect a USB thumb drive to
your TV and view photos.
Preparing your USB drive to play USB media
7RSOD\86%PHGLD\RXPXVWȴUVWVDYH\RXUȴOHVRQD86%WKXPE
drive:
• The USB thumb drive must be formatted as FAT32.
• )LOHVRQWKH86%WKXPEGULYHPXVWHQGLQDVXSSRUWHGȴOH
extension (.jpg or .jpeg).
• The USB media player is not designed to play media
from external hard drives, MP3 players, cameras, or
smartphones.
Playing USB media
To play your USB media:
1. Connect your USB thumb drive to the USB port on the side of
the TV.
2. Use the Arrow buttons to highlight Yes and press the OK.
3.
If the dialog box disappears, press the V button on the
remote to go the next step.
Use the Arrow buttons to highlight your USB device in the list
and press OK.
4. Use the Arrow buttons to highlight Photo and press OK.
5. Use the Arrow buttons to highlight the photo you want to
display. Press OK. The photo displays.
You can display your photos in fullscreen. Select the
photo, press OK, then highlight Fullscreen and press
OK.
Removing the USB drive from the TV
Do not remove the USB thumb drive while the TV is on.
Doing so may damage the drive.
To safely remove your USB drive from the TV:
1. 7XUQRWKH79
2. Disconnect your USB thumb drive from the USB port on the
side of the TV.
USB PORT
6
49
Start Slideshow
Name A-Z
Folders
Settings
View:
Sort:
VIZIO_2GB\Photo\root
File Name: D 1920x1080
Resolution: 1920x1080
Size: 1607270KB
USB1:
root
B.jpg C.jpg
E.jpg F.jpg
H.jpg I.jpg
Page 1 of 1
Current Folder
Displays the folder path.
Page Information
If your USB thumb drive has more
ȴOHVWKDQFDQEHGLVSOD\HGRQD
single screen, the page information is
displayed here.
Back Button
Highlight and press OK to return to left column.
Connected
Sources
Displays
connected USB
devices.
Current Folder
Sort by Name or Date
View Thumbnails/Folders
Adjust Slideshow Settings
Start Fullscreen
Slideshow
Photo Information
Displays the name,
UHVROXWLRQDQGȴOH
size of the currently
selected photo.
PHOTO VIEWER
Back Button
Highlight this button and
press OK to return to
the previous screen.
Folder Contents
This area displays the
contents of the currently
selected folder. You can
EURZVHȴOHVDQGIROGHUV
using the Arrow and OK
buttons on the remote.
VIZIO
A
Do you have questions? Find answers here:
SUPPORT.VIZIO.COM
Find help with:
•New product setup
•Connecting your devices
•Technical problems
•Product updates and more.
Live chat
support available
You can also contact our
award-winning support team:
Phone:
Email:
(877) 698-4946 (toll-free)
techsupport@VIZIO.com
Hours of Operation:
Monday - Friday: 7
AM TO 11 PM (CST)
Saturday - Sunday: 9 AM TO 6 PM (CST)
A
51
The TV displays “No Signal.”
• Press the INPUT button on the remote control to select a
GLHUHQWLQSXWVRXUFH
• If you are using an antenna or cable TV connected directly
to the TV, scan for channels. See
Finding Channels
on
page 32.
There is no power.
• Ensure the TV is plugged into a working electrical outlet.
• Ensure the power cable is securely attached to the TV.
• Press the POWER button on the remote or on the side of
the TV to turn the TV on.
The power is on, but there is no image on the screen.
• Ensure all cables are securely attached to the TV.
• (QVXUHDOOGHYLFHVDUHFRQQHFWHGFRUUHFWO\'HYLFHVGLHU
see your device’s user manual for details.
• Adjust Brightness, Contrast, or Backlight. See
Adjusting
the Picture Settings
on page 21.
• Press the INPUT button on the remote to select a
GLHUHQWLQSXWVRXUFH
There is no sound.
• Press VOLUME UP on the remote control.
• Press the MUTE button on the remote to ensure mute is
R
• Check the audio settings. See
Adjusting the Audio Settings
on page 29.
• Ensure the speakers are set to On.
• Ensure no headphones are connected to the TV.
• Check the audio connections of external devices (Blu-ray
player, game console, cable/satellite box) that are
connected to the TV.
• If you are using an antenna, the signal strength of the
channel may be low. Ensure your antenna is connected
securely to the TV and move the antenna around the
room or close to a window for the best signal.
7KHVRXQGLVȵDWRUGLDORJLVQRWDXGLEOH
• 7XUQR6RXQG/HYHOLQJ6HH
Adjusting the Audio Settings
on page 29.
The colors on the TV don’t look right.
• Adjust the Color and Tint settings in the Picture menu. See
Adjusting the Picture Settings
on page 21.
• Check all cables to ensure they are securely attached.
A
52
The buttons on the remote aren’t working.
• The Red and Yellow hot key buttons below the V button
do not operate with this model.
• Ensure you are only pressing one button at a time.
• Point the remote directly at the TV when pressing a
button.
• Replace the remote batteries with new ones. See
Replacing the Batteries on page 11.
The image quality is not good.
• )RUWKHEHVWLPDJHTXDOLW\YLHZKLJKGHȴQLWLRQSURJUDPV
using digital sources. Connect your devices with HDMI
cables.
• If you are using an antenna, the signal strength of the
channel may be low. Ensure your antenna is connected
securely to the TV and move the antenna around the
room or close to a window for the best signal.
The picture is distorted.
• Nearby electrical devices may be interfering with the
TV. Separate the TV from electrical appliances, cars, or
ȵXRUHVFHQWOLJKWV
• Ensure all cables are securely attached.
The display image does not cover the entire screen.
• If you are using TV, AV, or Component with 480i input,
press the WIDE button on the remote to change the
screen mode.
The TV has pixels (dots) that are always dark or always lit.
• Your HDTV is precision-manufactured using an extremely
high level of technology. However, sometimes pixels may
not display correctly. These types of occurrences are
inherent to this type of product and do not constitute a
defective product.
I see “noise” or static on the screen.
• When your TV’s digital capabilities exceed a digital
broadcast signal, the signal is up-converted (improved) to
match your TV’s display capabilities. This up-converting
can sometimes cause irregularities in the image.
• If you are using an antenna, the signal strength of the
channel may be low. Ensure your antenna is connected
securely to the TV and move the antenna around the
room or close to a window for the best signal.
When I change input source, the display image changes size.
• The TV remembers the viewing mode on each input
source. If the viewing mode on the new input source
GLHUVIURPWKHRQHRQWKHLQSXWVRXUFH\RXVZLWFKIURP
WKHGLHUHQFHPD\EHQRWLFHDEOH
• See
Changing the Screen Aspect Ratio on page 20.
B
53
D43-C1
Screen Size: 43" Class
Viewable Area: 42.5"
Dimensions w/ Stand:
w/o Stand:
37.99" x 24.53" x 8.27"
37.99" x 22.36" x 2.52"
Weight w/ Stand:
w/o Stand:
19.84 lbs
19.40 lbs
TV Type: Direct LED
Refresh Rate: +]+](HFWLYH5HIUHVK5DWH
Maximum Resolution: [)XOO+'
Pixel Pitch: PP+[PP9
Dynamic Contrast Ratio: 200,000: 1
Clear Action 240
Viewing Angle: 178°/ 178°
HDMI Inputs: 2
Component Video Inputs: 1
Composite Inputs: VKDUHGZLWK&RPSRQHQW
RF Antenna Input: 1
USB 2.0 Ports: 1
Audio Outputs:
5&$6WHUHR
2SWLFDO'LJLWDO
OSD Language: (QJOLVK6SDQLVK)UHQFK
6SHFLȴFDWLRQV
B
54
D43-C1
Remote Control Model: ;57
&HUWLȴFDWLRQV
8/F8/120%(76Ζ&(6&ODVV%
+'0Ζ&(&$5&'ROE\'LJLWDO
Compliance:
(QHUJ\6WDU
COUNEE
15&DQ
120
Voltage Range: ɋ9#ɋ+]
Power-On Consumption: ɋ:
Standby Power Consumption: ɋ:
Zero Bright Pixels Guarantee: Yes
C
55
Limited Warranty
ON PARTS AND LABOR
Covers units purchased as new in United States and Puerto Rico Only.
VIZIO provides a warranty to the original purchaser of a new Product
against defects in materials and workmanship for a period of one (1) year
of non-commercial usage and ninety (90) days of commercial use. If a
Product covered by this warranty is determined to be defective within the
warranty period, VIZIO will either repair or replace the Product at its sole
option and discretion.
To obtain warranty service, contact VIZIO Technical Support via e-mail:
TechSupport@VIZIO.com or via phone at 877 MY VIZIO (877.698.4946)
from 7:00AM to 11:00PM Monday through Friday and 9:00AM to 6:00PM
Saturday and Sunday, Central Standard Time, or visit www.VIZIO.com. PRE-
AUTHORIZATION MUST BE OBTAINED BEFORE SENDING ANY PRODUCT TO
A VIZIO SERVICE CENTER. Proof of purchase in the form of a purchase
receipt or copy thereof is required to show that a Product is within the
warranty period.
PARTS AND LABOR
There will be no charge for parts or labor during the warranty period.
5HSODFHPHQW SDUWV DQG 3URGXFWV PD\ EH QHZ RU UHFHUWLȴHG DW 9Ζ=Ζ2ȇV
option and sole discretion. Replacement parts and Products are warranted
for the remaining portion of the original warranty or for ninety (90) days
from warranty service or replacement, whichever is greater.
TYPE OF SERVICE
Defective Products must be sent to a VIZIO service center to obtain
warranty service. VIZIO is not responsible for transportation costs to the
service center, but VIZIO will cover return shipping to the customer. PRE-
AUTHORIZATION IS REQUIRED BEFORE SENDING ANY PRODUCT TO A
VIZIO SERVICE CENTER FOR WARRANTY SERVICE.
3URGXFWUHWXUQVWR9Ζ=Ζ2ȇVVHUYLFHFHQWHUVPXVWXWLOL]HHLWKHUWKHRULJLQDO
FDUWRQ ER[ DQG VKLSSLQJ PDWHULDO RU SDFNDJLQJ WKDW DRUGV DQ HTXDO
degree of protection. VIZIO Technical Support will provide instructions for
packing and shipping the covered Product to the VIZIO service center.
LIMITATIONS AND EXCLUSIONS
9Ζ=Ζ2ȇV RQH\HDU OLPLWHG ZDUUDQW\ RQO\ FRYHUV GHIHFWV LQ PDWHULDOV DQG
workmanship. This warranty does not cover, for example: cosmetic
damage, normal wear and tear, improper operation, improper voltage
supply or power surges, signal issues, damages from shipping, acts of
*RGDQ\W\SHRIFXVWRPHUPLVXVHPRGLȴFDWLRQVRUDGMXVWPHQWVDVZHOO
as installation and set-up issues or any repairs attempted by anyone
RWKHUWKDQE\D9Ζ=Ζ2DXWKRUL]HGVHUYLFHFHQWHU3URGXFWVZLWKXQUHDGDEOH
or removed serial numbers, or requiring routine maintenance are not
covered. This one year limited warranty does not cover Products sold “AS
Ζ6ȋȊ)$&725<5(&(57Ζ)Ζ('ȋRUE\DQRQDXWKRUL]HGUHVHOOHU
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED OR
DESCRIBED ABOVE. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME SET
)257+ $%29( 9Ζ=Ζ2ȇ6 727$/ /Ζ$%Ζ/Ζ7< )25 $1< $1' $// /266(6 $1'
'$0$*(65(68/7Ζ1*)520$1<&$86(:+$762(9(5Ζ1&/8'Ζ1*9Ζ=Ζ2ȇ6
NEGLIGENCE, ALLEGED DAMAGE, OR DEFECTIVE GOODS, WHETHER SUCH
DEFECTS ARE DISCOVERABLE OR LATENT, SHALL IN NO EVENT EXCEED THE
PURCHASE PRICE OF THE PRODUCT. VIZIO SHALL NOT BE RESPONSIBLE FOR
LOSS OF USE, LOSS OF INFORMATION OR DATA, COMMERCIAL LOSS, LOST
REVENUE OR LOST PROFITS, OR OTHER INCIDENTAL OR CONSEQUENTIAL
DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS
MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM
STATE TO STATE. THIS WARRANTY IS SUBJECT TO CHANGE WITHOUT
NOTICE.
CHECK WWW.VIZIO.COM FOR THE MOST CURRENT VERSION.
PERSONAL DATA
If your VIZIO product is capable of storing personal data and other
information, ALL CONTENTS AND INFORMATION WILL BE DELETED IN
THE COURSE OF SOME IN-HOME AND ALL SHIP-IN WARANTY SERVICE. If
WKLVRFFXUV\RXUSURGXFWZLOOEHUHVWRUHGWR\RXFRQȴJXUHGDVRULJLQDOO\
purchased. You will be responsible for restoring all applicable data and
passwords. Recovery and reinstallation of user data is not covered under
this Limited Warranty. In order to protect your personal information, VIZIO
recommends that you always clear all personal information from the unit
before it is serviced, regardless of the servicer.
ZERO BRIGHT PIXEL DEFECT GUARANTEE
7KLVSROLF\FRYHUVȊ]HUREULJKWSL[HOȋGHIHFWVIRUWKHGXUDWLRQRIWKHOLPLWHG
“ONE YEAR WARRANTY” on select new product purchases. To determine if
this guarantee applies to your product, refer to the “DETAILS” tab of the
PRGHOȇVSURGXFWLQIRUPDWLRQSDJHZZZ9Ζ=Ζ2FRPRUORRNIRUWKHȊ]HUR
bright pixel” guarantee on the box.
D
56
Legal & Compliance
FCC Class B Radio Interference Statement
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
WHOHYLVLRQ UHFHSWLRQZKLFKFDQEHGHWHUPLQHGE\WXUQLQJWKH HTXLSPHQWR
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. &RQQHFWWKHHTXLSPHQWLQWRDQRXWOHWRQDFLUFXLWGLHUHQWIURPWKDW
to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Notice
1. 7KHFKDQJHVRUPRGLȴFDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\
responsible for compliance could void the user’s authority to operate
the equipment.
2. Shielded interface cables and AC power cord, if any, must be used in
order to comply with the emission limits.
3. The manufacturer is not responsible for any radio or TV interference
FDXVHGE\XQDXWKRUL]HGPRGLȴFDWLRQWRWKLVHTXLSPHQWΖWLVWKH
responsibilities of the user to correct such interference.
FCC Warning
&KDQJHVRUPRGLȴFDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHSDUW\UHVSRQVLEOHIRU
compliance with the FCC Rules could void the user’s authority to operate this
equipment.
Other
Image(s) used under license from Shutterstock.com
© 2015 VIZIO INC. ALL RIGHTS RESERVED.
140223EM-US-NC
