Thank you for purchasing a Canon product.
EF50mm f/1.8 STM is a compact, lightweight, low-profile high quality standard
lens.
●
“STM” stands for Stepping Motor.
Safety Precautions
●
Do not look at the sun or a bright light source through the lens or
camera. Doing so could result in loss of vision.
Looking at the sun directly through the lens is especially hazardous.
●
Whether it is attached to the camera or not, do not leave the lens under
the sun without the lens cap attached.
This is to prevent the lens from
concentrating the sun’s rays, which could cause a fire.
Handling Cautions
●
If the lens is taken from a cold environment into a warm one,
condensation may develop on the lens surface and internal parts.
To
prevent condensation in this case, first put the lens into an airtight plastic
bag before taking it from a cold to warm environment. Then take out the lens
after it has warmed gradually. Do the same when taking the lens from a warm
environment into a cold one.
●
Do not leave the lens in excessive heat such as in a car in direct sunlight.
High temperatures can cause the lens to malfunction.
Usage Precautions
●
When using this lens, please check the Canon website for the latest camera
firmware. If the camera’s firmware is not the latest version, be sure to update
to the latest firmware.
●
For details on updating firmware, please check the Canon website.
Cautions during shooting
●
This lens uses a stepping motor to drive the focusing lens (the lens that has
the job of focusing the shot).
1. Cautions when the power is off
Since the motor does not operate when the camera is off or has been
turned by the auto power-off function, take note of the following points.
•Thefocuscannotbeadjustedinmanualfocusmode.
2. Cautions when the lens is in sleep mode
This lens has a sleep mode separate from the camera auto power-off
function for saving power when the lens has not been operated for a period
of time.
Since the motor does not operate when the lens is in sleep mode, even if
the camera is turned on, take note of the following points.
•Thefocuscannotbeadjustedinmanualfocusmode.
•Torecoverthelensfromsleepmode,presstheshutterbuttonhalfway.
●
To retract the lens if extended, keep the lens attached to the camera, and
then autofocus at infinity or turn the focusing ring.
Conventions used in this instruction
Warning to prevent lens or camera malfunction or damage.
Supplementary notes on using the lens and taking pictures.
1. Mounting and Detaching the Lens
See your camera’s instructions for details on mounting and detaching the
lens.
●
After detaching the lens, place the lens with the rear end up to prevent
the lens surface and contacts from getting scratched.
●
If the contacts get soiled, scratched, or have fingerprints on them,
corrosion or faulty connections can result. The camera and lens may not
operate properly.
●
If the contacts get soiled or have fingerprints on them, clean them with a
soft cloth.
●
If you remove the lens, cover it with the dust cap. To attach it properly,
align the lens mount index and the
○
index of the dust cap, and turn
clockwise
●❶
. To remove it, reverse the order.
Nomenclature
●①
Focusing ring
●②
Hood mount
●③
Filter mounting thread
●④
Focus mode switch
●⑤
Lens mount index
●⑥
Contacts
EF Lenses
EF50mm f/1.8 STM
Instructions
