EN
1
PRODUCT DESCRIPTION
CONTROL PANEL
1. Control panel
2. Fan
3. Circular heating element
(not visible)
4. Shelf guides
(the level is indicated on the front
of the oven)
5. Door
6. Upper heating element/grill
7. Lamp
8. Meat probe insert point
(if present)
9. Identification plate
(do not remove)
10. Lower heating element
(not visible)
1. LEFTHAND DISPLAY
2. LIGHT
For switching the lamp on/off.
3. ON/OFF
For switching the oven on and off
and for stopping an active function
at any time.
4. BACK
For returning to the previous menu
when configuring settings.
5. ROTARY KNOB / 6
TH
SENSE
BUTTON
Turn this to navigate through the
functions and adjust all of the
cooking parameters. Press
to select, set, access or confirm
functions or parameters and
eventually start the cooking
program.
6. TEMPERATURE
For setting the temperature.
7. T I M E
For setting or changing the time
and adjusting the cooking time.
8. START
For starting functions and
confirming settings.
9. RIGHTHAND DISPLAY
DAILY REFERENCE
GUIDE
Before using the appliance carefully read the Health and Safety guide.
THANK YOU FOR PURCHASING A
WHIRLPOOL PRODUCT
To receive more comprehensive help and
support, please register your product at
www.whirlpool.eu/register
WWW
You can download the Safety Instructions
and the Use and Care Guide by visiting our
website docs.whirlpool.eu and following
the instructions on the back of this booklet.
5
4
3
2
1
5
4
3
2
1
1
2
3
4
5
9
10
7
6
1 2 5 6 93 4 7 8
8
