HTS3264D
Register your product and get support at
www.philips.com/welcome
EN DVD Home Theater System 6
FR_CA Système Home Cinéma DVD 56
ES_LA Sistema de Home Theater con DVD 108
Thank you for choosing Philips.
Need help fast?
Read your Quick Start Guide and/or
User Manual first for quick tips
that make using your Philips product
more enjoyable.
Register your product and
get support at
www.philips.com/welcome
or call
1-888-PHILIPS (744-5477)
while with your product
(and Model / Serial number)
STO
P
Philips vous remercie de
votre confiance.
Besoin d'une aide
rapide?
Le Guide rapide de début et
Manuel de l'utilisateur regorgent
d'astuces destinées à simplifier
l'utilisation de votre produit Philips.
ou formez le
1-800-661-6162 (Francophone)
1-888-PHILIPS (744-5477)
(English speaking)
Veillez à avoir votre produit à
portée de main
(et model / serial nombre)
A
R
RÊT
Gracias por escoger Philips
Necesita ayuda
inmediata?
Lea primero la Guía rápida del
comienzo o el Manual del usuario,
en donde encontrará consejos que
le ayudarán a disfrutar plenamente
de su producto Philips.
o llame al teléfono
1-888-PHILIPS (744-5477)
y tenga a mano el producto
(y número de model / serial)
ALTO
Enregistrez votre produit et
accédez à l'assistance sur
www.philips.com/welcome
Visite
www.philips.com/welcome
para registrar su producto y
obtener información de
contacto y asistencia.
1_hts3264D_37_eng4_final810.indd1 11_hts3264D_37_eng4_final810.indd1 1 2008-03-13 10:29:29 AM2008-03-13 10:29:29 AM
2
Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don't miss out.
Complete and return your Product Registration Card at once, or register online at www.philips.com/welcome to
ensure:
Return your Product Registration Card or register online at
www.philips.com/welcome today to get the very most from your purchase.
Visit our World Wide Web Site at http://www.philips.com/welcome
Congratulations on your purchase,
and welcome to the “family!”
Dear PHILIPS product owner:
Thank you for your confidence in PHILIPS.You’ve selected one of
the best-built, best-backed products available today.We’ll do every-
thing in our power to keep you happy with your purchase for many
years to come.
As a member of the PHILIPS “family,” you’re entitled to protection
by one of the most comprehensive warranties and outstanding
service networks in the industry.What’s more, your purchase guar-
antees you’ll receive all the information and special offers for which
you qualify, plus easy access to accessories from our convenient
home shopping network.
Most importantly, you can count on our uncompromising commit-
ment to your total satisfaction.
All of this is our way of saying welcome - and thanks for investing
in a PHILIPS product.
P.S. To get the most from your PHILIPS purchase, be
sure to complete and return your Product Registration
Card at once, or register online at:
www.philips.com/welcome
For Customer Use
Enter below the Serial No. which is locat-
ed on the rear of the cabinet. Retain this
information for future reference.
Model No.__________________________
Serial No. ________________________
Know these
safetysymbols
This “bolt of lightning” indicates unin-
sulated material within your unit may
cause an electrical shock. For the safety of
everyone in your household, please do not
remove product covering.
The “exclamation point” calls atten-
tion to features for which you should
read the enclosed literature closely to pre-
vent operating and maintenance problems.
WARNING: To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects
filled with liquids, such as vases, should not
be placed on this apparatus.
CAUTION: To prevent electric shock,
match wide blade of plug to wide slot, fully
insert.
ATTENTION: Pour éviter les choc élec-
triques, introduire la lame la plus large de la
fiche dans la borne correspondante de la
prise et pousser jusqu’au fond.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
*Proof of
Purchase
Returning the enclosed card guarantees
that your date of purchase will be on file,
so no additional paperwork will be
required from you to obtain warranty
service.
*Product Safety
Notification
By registering your product, you'll receive
notification - directly from the manufac-
turer - in the rare case of a product
recall or safety defect.
*Additional Benefits
Registering your product guarantees that
you'll receive all of the privileges to
which you're entitled, including special
money-saving offers.
1_hts3264D_37_eng4_final810.indd2 21_hts3264D_37_eng4_final810.indd2 2 2008-03-13 10:29:32 AM2008-03-13 10:29:32 AM
3
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near
water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance with
the manufacturer´s instructions.
8. Do not install near any heat sources
such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the
safety purpose of the
polarized or
grounding-type plug.
A polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong are
provided for your safety. If the provided plug
does not fit into your outlet, consult an
electrician for replacement of the obsolete
outlet.
10.
Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11.
Only use attachments/accessories
specified by the manufacturer.
12.
Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13 .
Unplug this apparatus during lightning
storms or when unused for long periods of
time.
14 .
Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15.
Battery usage CAUTION – To
prevent battery leakage which may result in
bodily injury, property damage, or damage
to the unit:
● Install all batteries correctly, + and - as
marked on the unit.
● Do not mix batteries (old and new or
carbon and alkaline, etc.).
● Remove batteries when the unit is not used
for a long time.
IMPORTANT SAFETY INSTRUCTIONS
AC Polarized
Plug
16. Apparatus shall not be exposed to
dripping or splashing.
17. Do not place any sources of danger
on the apparatus (e.g. liquid filled
objects, lighted candles).
18. This product may contain lead and mercury.
Disposal of these materials may be regulated
due to environmental considerations.
For disposal or recycling information,
please contact your local authorities
or the Electronic Industries Alliance :
www.eiae.org.
EL 6475-E005: 04/01
Class II equipment symbol
This symbol indicates that the unit has
a double insulation system
Ensure that the power outlet is always within
reach. If abnormal situations occur, fully
disconnect power: unplug the power cord
from the power outlet.
1_hts3264D_37_eng4_final810.indd3 31_hts3264D_37_eng4_final810.indd3 3 2008-03-13 10:29:34 AM2008-03-13 10:29:34 AM
4
LASER
Type Semiconductor laser
GaAIAs
Wave length 645 - 660 nm (DVD)
770 - 800 nm (CD)
Output Power 6 mW (DVD)
7 mW (VCD/CD)
Beam divergence 60 degrees
Canada
English:
This digital apparatus does not exceed
the Class B limits for radio noise
emissions from digital apparatus as set
out in the Radio Interference
Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies
with Canadian ICES-003.
Français:
Cet appareil numérique n’emet pas de
bruits radioélectriques dépassant les
limites applicables aux appareils
numériques de Class B prescrites dans
le Règlement sur le Brouillage
Radioélectrique édicté par le Ministère
des Communications du Canada.
Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
This warning label is located on the rearside
and inside this laser product.
CAUTION
:
INVISIBLE
LASER RADIATION
WHEN OPEN. DO NOT STARE INTO BEAM.
DANGER
:
INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
VARO!
AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET
ALTTIINANAKYMATTOMAALLE LASERSATEILYLLE. ALA
KATSO SATEESEEN.
VARNING!
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD.
OCH SPARREN AR URKOPPLAD. BETRAKTA EJ STRÅLEN.
DANGER - Invisible laser radiation when open.
AVOID DIRECT EXPOSURE TO BEAM.
or
CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
ATTENTION
L’utilisation des commandes ou réglages
ou le non-respect des procédures ciincluses
peuvent se traduire par une
exposition dangereuse à l’irradiation.
ATENCIÓN
El uso de mando o ajustes o la ejecucción
de métodos que no sean los aquí descritos
puede ocasionar peligro de exposición a
radiación.
Declaration of Conformity
Model number: HTS3264D
Trade Name: Philips
Responsible Party: Philips Consumer Electronics
A Division of Philips Electronics
North America Corp.
P. O. Box 671539
Marietta, GA 30006-0026
1-800-PHILIPS (744-5477)
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard
(box), polystyrene foam (buffer) and
polyethylene (bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
1_hts3264D_37_eng4_final810.indd4 41_hts3264D_37_eng4_final810.indd4 4 2008-03-13 10:29:34 AM2008-03-13 10:29:34 AM
5
Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic and the
double-D symbol are trademarks of Dolby
Laboratories.
DivX, DivX Ultra Certi ed, and associated
logos are trademarks of DivX, Inc. and are
used under license.
Of cial DivX® Ultra Certi ed product.
Plays all versions of DivX® video (including
DivX® 6) with enhanced playback of DivX®
media les and the DivX® Media Format.
Windows Media and the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
The USB-IF Logos are trademarks of
Universal Serial Bus Implementers Forum,
Inc.
ENERGY STAR and the ENERGY STAR mark are
registered U.S. marks
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual property
rights owned by Macrovision Corporation and
other rights owners. Use of this copyright
protection technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reserve engineering or disassembly is prohibited.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH
DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE
ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE
PROBLEMS, IT IS RECOMMENDED THAT THE USER
SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS
REGARDING OUR TV SET COMPATIBILITY WITH THIS
MODEL 525p AND 625p DVD PLAYER, PLEASE
CONTACT OUR CUSTOMER SERVICE CENTER.’
Index
English ------------------------------------ 6
Français ---------------------------------- 56
Español -------------------------------- 108
EnglishFrançaisEspañol
iPod is a trademark of Apple Computer, Inc.,
registered in the U.S. and other countries.
1_hts3264D_37_eng4_final810.indd5 51_hts3264D_37_eng4_final810.indd5 5 2008-03-13 10:29:35 AM2008-03-13 10:29:35 AM
6
English
Table of contents
General
General Information ........................................................................................................ 8
Setup precautions .................................................................................................................................................8
Accessories supplied ...........................................................................................................................................8
Cleaning discs ........................................................................................................................................................8
About recycling .....................................................................................................................................................8
Product Overview
Main Unit ...........................................................................................................................9
Remote Control .........................................................................................................10-12
Using the remote control ................................................................................................................................12
Connections
Basic Connections .....................................................................................................13-18
Step 1: Placing the speakers .............................................................................................................................13
Step 2: Connecting to TV ..........................................................................................................................14-16
Option 1: Connecting to theVideo jack ................................................................................................14
Option 2: Connecting to a Progressive Scan TV or component video input ............................15
Option 3: Using an accessory RF modulator ......................................................................................16
Step 3: Connecting speakers and subwoofer .............................................................................................17
Step 4: Connecting the FM antenna ..............................................................................................................18
Step 5: Connecting the power cord ..............................................................................................................18
Optional Connections .................................................................................................... 19
Connecting audio from other devices ..........................................................................................................19
Basic Setup
Getting Started ......................................................................................................... 20-24
Finding the correct viewing channel ............................................................................................................ 20
Switching to different play source ................................................................................................................ 20
Setting language preferences .....................................................................................................................21-22
On-screen display (OSD) language ........................................................................................................21
Audio, Subtitle and Menu language for DVD playback ...............................................................21-22
Setting up Progressive Scan feature ..............................................................................................................23
Setting the speakers’ channels ........................................................................................................................24
Disc Playback
Disc Operations ........................................................................................................ 25-32
Playable discs ...................................................................................................................................................... 25
Playing a disc ....................................................................................................................................................... 25
Basic playback controls .....................................................................................................................................26
Selecting various repeat/shuf e functions ...................................................................................................26
Other playback features for video discs (DVD/VCD/SVCD) ..........................................................27-29
Using the Disc menu ..................................................................................................................................27
Viewing playback information ..................................................................................................................27
Zooming........................................................................................................................................................ 28
Changing subtitle language ...................................................................................................................... 28
Switching camera angles ........................................................................................................................... 28
Changing sound track language .............................................................................................................. 28
Setting the delay times for audio playback .......................................................................................... 28
Playback Control (VCD only) ..................................................................................................................29
Preview function (VCD/SVCD only) .....................................................................................................29
1_hts3264D_37_eng4_final810.indd6 61_hts3264D_37_eng4_final810.indd6 6 2008-03-13 10:29:36 AM2008-03-13 10:29:36 AM
7
English
Table of contents
Playing a MP3/ WMA disc ............................................................................................................................... 30
Playing a JPEG image le (slide show) ...........................................................................................................31
Preview function ..........................................................................................................................................31
Zooming.........................................................................................................................................................31
Skip/Rotate picture .....................................................................................................................................31
Playing music and photo les simultaneously .............................................................................................32
Playing a DivX
®
disc ...........................................................................................................................................32
Playback other supported devices
Playback - iPod ................................................................................................................33
Playing music from compatible iPod device ................................................................................................33
Preparing the docking station ..................................................................................................................33
Playing from iPod .........................................................................................................................................33
Playback - USB Device ................................................................................................... 34
Playing from a USB device ............................................................................................................................... 34
Playback - Other Audio Player .....................................................................................35
Playing from other portable audio player ....................................................................................................35
Setup Options
Setup Menu Options ................................................................................................. 36-43
Accessing the setup menu ................................................................................................................................36
General Setup ..............................................................................................................................................37
Audio Setup ................................................................................................................................................. 38
Video Setup ............................................................................................................................................39-40
Preferences ............................................................................................................................................ 41-43
Radio Tuning
Radio Operations ...................................................................................................... 44-45
Tuning to radio stations ................................................................................................................................... 44
Presetting radio stations ................................................................................................................................. 44
Using auto install ........................................................................................................................................ 44
Using automatic preset ............................................................................................................................. 45
Using manual preset .................................................................................................................................. 45
Selecting a preset radio station ..................................................................................................................... 45
Deleting a preset radio station ...................................................................................................................... 45
Others
Sound and Volume Controls .........................................................................................46
Volume control .................................................................................................................................................. 46
Selecting surround sound ................................................................................................................................46
Selecting digital sound effects ........................................................................................................................ 46
Other Features................................................................................................................ 47
Installing the latest software ...........................................................................................................................47
Troubleshooting ........................................................................................................ 48-50
Speci cations .................................................................................................................. 51
Glossary...................................................................................................................... 52-53
1_hts3264D_37_eng4_final810.indd7 71_hts3264D_37_eng4_final810.indd7 7 2008-03-13 10:29:36 AM2008-03-13 10:29:36 AM
8
English
General Information
WARNING!
This unit does not contain any user-
serviceable parts. Please leave all
maintenance work to quali ed
personnel.
Setup precautions
Finding a suitable location
– Place this unit on a at, hard and
stable surface. Never place the unit on a
carpet.
– Never place this unit on top of other
equipment that might heat it up (e.g.,
receiver or ampli er).
– Never put anything under this unit
(e.g., CDs, magazines).
– Install this unit near the AC outlet
where the AC power plug can be easily
reached.
Space for ventilation
– Place this unit in a location with
adequate ventilation to prevent internal
heat build up. Allow at least 10 cm (4”)
clearance from the rear and the top of
this unit and 5cm (2”) from the left and
right to prevent overheating.
Avoid high temperature, moisture,
water and dust
– This unit must not be exposed to
dripping or splashing.
– Never place any object or items that
can damage this unit (e.g., liquid lled
objects, lighted candles).
Accessories supplied
– 1 subwoofer
– 2 front speakers
– 2 rear speakers
– 1 center speaker
– 1 remote control with batteries
– 1 composite video cable (yellow)
– 1 docking station for Apple iPod
– 1 FM wire antenna
– Quick Start Guide
Cleaning discs
To clean a disc, use a micro bre cleaning
cloth and wipe the disc from the center
to the edge in a straight line.
CAUTION!
Never use solvents e.g. benzene, thinner,
commercially available cleaners, or anti-
static sprays intended for discs.
About recycling
These operating instructions have been
printed on non-polluting paper. The
electronic equipment contains a large
number of materials that can be recycled.
If you are disposing of an old machine,
please take it to a recycling center.
Please observe the local regulations
regarding disposal of packaging materials,
exhausted batteries and old equipment.
1_hts3264D_37_eng4_final810.indd8 81_hts3264D_37_eng4_final810.indd8 8 2008-03-13 10:29:36 AM2008-03-13 10:29:36 AM
9
English
Main Unit
a 2 (Standby-On)
– Turns on this unit or turns off to standby
mode.
b Disc Tray
c ç (Open/Close)
– Opens/closes the disc tray.
d Display panel
– Shows information about the current
status of the unit.
e VOLUME +-
– Adjusts the volume level.
f SOURCE
– Selects the relevant active source mode:
DISC, FM, AUX 1, AUX 2 or MP3 LINK.
g u (Play/ Pause)
– DISC: starts/pauses playback.
– RADIO: starts auto radio installation for
rst time setup.
. / > (Previous / Next)
– DISC: skips to the previous or next title/
chapter/track.
– DISC: press and hold this button for fast
forward and backward search.
– RADIO: selects a preset radio station.
(Stop)
– Exits an operation.
– DISC: stops playback.
– RADIO: press and hold this button to
erase the current preset radio station.
Note:
The following jacks are under the ap at the
right corner of the front panel, OPEN .
h (USB) jack
– Input for USB ash drive or USB memory
card reader.
i MP3 LINK jack
– Phono input for connecting to the
headphone out jack on your portable
audio player.
MP3 LINK
1
2
7
3
8
54 6
9
Front Panel View
Inside VIew
1_hts3264D_37_eng4_final810.indd9 91_hts3264D_37_eng4_final810.indd9 9 2008-03-13 10:29:36 AM2008-03-13 10:29:36 AM
10
English
Remote Control
8
1
2
3
4
5
6
7
9
10
11
a 2 (Standby-On)
– Turns on this unit or turns off to standby
mode.
b ç (Open/Close)
– Opens/closes the disc tray.
c Source buttons
– AUX (MP3 LINK): switches to
AUX1, AUX2 or MP3 LINK external
source mode.
– RADIO: switches to FM band.
– USB: switches to USB mode.
– DISC: switches to DISC mode.
– DOCK: switches to the iPod that is
connected to the docking station.
d INFO
– Displays the current status or disc
information.
e OPTIONS
– Enters or exits the system setup menu.
f u (Play/Pause)
– DISC: starts/pauses playback.
– RADIO: starts auto radio installation for
rst time setup.
g Ç (Stop)
– Exits an operation.
– DISC: stops playback.
– RADIO: press and hold this button to
erase the current preset radio station.
h SOUND MODES +/-
– Selects a prede ned sound effect.
i AUDIO SYNC
– Selects an audio language/channel.
– Sets the audio output delay times if the
video playback is slower than the audio
output.
j ZOOM
– Zoom in or out the picture on the TV.
k SLEEP
– Sets the sleep timer.
1_hts3264D_37_eng4_final810.indd10 101_hts3264D_37_eng4_final810.indd10 10 2008-03-13 10:29:37 AM2008-03-13 10:29:37 AM
11
English
Remote Control (continued)
l
OK
– Con rms an entry or selection.
m b B vV
– DISC: selects movement direction in the
menu.
– DISC: press left or right for fast forward
and backward search.
– RADIO: press up or down to tune the
radio frequency.
– RADIO: press left or right to start auto
search.
n MENU (BACK)
– DVD: go back to title menu.
– VCD/SVCD:
During playback (PBC ON mode only)
return to the PBC menu.
o í / ë (Previous/Next)
– DISC: skips to the previous or next title/
chapter/track.
– RADIO: selects a preset radio station.
p % (Mute)
– Mutes or restores the volume.
q VOL +/-
– Adjusts the volume level.
r SURROUND
– Selects multi-channel surround, stereo or
party mode.
s Numeric keypad 0-9
– Enters a track/title/chapter number of the
disc.
– Enters a number of a preset radio station.
t SUBTITLE
– Selects a DVD subtitle language.
u REPEAT (PROGRAM)
– DISC: selects various repeat or shuf e
modes; turns off repeat or shuf e mode.
– RADIO: press this button to start manual
preset programming.
– RADIO: press and hold this button to
start automatic preset programming.
v REPEAT A-B
– Repeat playback a speci c section on a
disc.
19
20
22
21
18
17
16
12
13
14
15
1_hts3264D_37_eng4_final810.indd11 111_hts3264D_37_eng4_final810.indd11 11 2008-03-13 10:29:37 AM2008-03-13 10:29:37 AM
12
English
Remote Control (continued)
Using the remote control
A Push to open the battery compartment.
B Insert two batteries type R03 or AAA,
following the indications (+-) inside
the compartment.
C Close the cover.
D Point the remote control directly at the
remote sensor (iR) on the front panel.
E Select the source you wish to control by
pressing the AUX (MP3 LINK), RADIO,
DOCK or DISC button on the remote
control.
F Then select the desired function (for
example í, ë).
CAUTION!
– Remove batteries if they are
exhausted or if the remote control
is not to be used for a long time.
– Never mix batteries (old and new
or carbon and alkaline, etc).
– Batteries contain chemical
substances, they should be disposed
of properly.
1_hts3264D_37_eng4_final810.indd12 121_hts3264D_37_eng4_final810.indd12 12 2008-03-13 10:29:37 AM2008-03-13 10:29:37 AM
13
English
Basic Connections
Step 1: Placing the speakers
The Philips Home Theater System is
simple to install. However, proper system
placement is critical to ensure an
optimum sound experience.
A Place the front left and right speakers at
equal distances from the TV and at an
angle of approximately 45 degrees from
the listening position.
B Place the center speaker above the TV or
the main unit such that the center
channel’s sound is localized.
C Place the rear speakers at normal
listening ear level facing each other or
hang on the wall.
D Place the subwoofer at the corner of the
room. Otherwise, keep it at least one
metre away from the TV.
Helpful Hints:
– The placement diagram shown here is
only a guideline that provides great system
performance. You may nd other placement
choices that are more suitable for your room
layout that provide the sound experience you
enjoy.
– To avoid magnetic interference, never
position the front speakers too close to your
TV.
– The rear speakers are labelled as REAR
LEFT or REAR RIGHT.
– The front speakers are labelled as
FRONT LEFT or FRONT RIGHT.
– For speaker setting, see ‘Getting Started -
Setting the speakers’ channels’.
FRONT
RIGHT
SUBWOOFER
FRONT
LEFT
CENTER
REAR
RIGHT
REAR
LEFT
1_hts3264D_37_eng4_final810.indd13 131_hts3264D_37_eng4_final810.indd13 13 2008-03-13 10:29:37 AM2008-03-13 10:29:37 AM
14
English
Main Unit (rear)
Step 2: Connecting to TV
This connection enables you to view the
video playback from this unit. You only
need to choose one of the options
below to make the video connection.
– For a standard TV, follow option 1.
– For a progressive scan TV, follow
option 2.
– For TV with only a single antenna
input jack, follow option 3.
Helpful Hint:
– It is important to connect this unit directly
to the TV in order to enjoy optimum video
quality.
– To hear the TV audio through this unit,
connect AUDIO IN-AUX jacks on the unit to
the audio output on your TV (cables not
supplied). Then press AUX (MP3 LINK) until
‘AUX 1’ or ‘AUX 2’ is displayed on the front
panel.
Option 1: Connecting to theVideo
jack
Use a composite video cable (yellow -
supplied) to connect the CVBS jack on
the main unit to the video input jack (or
labeled as A/V In, Video In, Composite or
Baseband) on the TV.
It provides good picture quality.
Basic Connections (continued)
Option 1
1_hts3264D_37_eng4_final810.indd14 141_hts3264D_37_eng4_final810.indd14 14 2008-03-13 10:29:38 AM2008-03-13 10:29:38 AM
15
English
Option 2: Connecting to a
Progressive Scan TV or component
video input
The progressive scan video quality is only
available when using Y Pb Pr connection
and a progressive scan TV is required. It
provides superior picture quality when
watching DVD movies.
A Use the component video cables (red/
blue/green - not supplied) to connect the
Y Pb Pr jacks on the main unit to the
corresponding component video input
jacks (or labeled as Y Pb/Cb Pr/Cr or
YUV) on the TV.
It provides better picture quality.
B If your TV accepts progressive signals,
proceed to chapter ‘Getting Started -
Setting up Progressive Scan feature’ for
detailed progressive feature setup.
Option 2
Basic Connections (continued)
1_hts3264D_37_eng4_final810.indd15 151_hts3264D_37_eng4_final810.indd15 15 2008-03-13 10:29:38 AM2008-03-13 10:29:38 AM
16
English
C Connect the Antenna or Cable TV
service signal to the ANTENNA IN or
RF IN jack on the RF modulator. (It may
have been connected to your TV
previously. Disconnect it from the TV.)
Option 3: Using an accessory RF
modulator
If your TV has only a single Antenna Input
jack (labeled as 75 ohm or RF In,) you
need an RF modulator in order to view
the DVD playback on the TV. See your
electronics retailer or contact Philips for
details about RF modulator availability and
operations.
A Use the supplied composite video cable
(yellow) to connect the CVBS jack on
the main unit to the video input jack on
the RF modulator.
B Use an RF coaxial cable (not supplied) to
connect ANTENNA OUT or TO TV jack
on the RF modulator to the ANTENNA
IN jack on the TV.
Antenna
Basic Connections (continued)
Back of RF Modulator
(example only)
1_hts3264D_37_eng4_final810.indd16 161_hts3264D_37_eng4_final810.indd16 16 2008-03-13 10:29:38 AM2008-03-13 10:29:38 AM
17
English
Basic Connections (continued)
Step 3: Connecting speakers
and subwoofer
Connect all the speakers and subwoofer
to the matching jacks at the rear of the
main unit, Make sure that the colors of
the cables and jacks are matched.
Helpful Hint:
– To prevent unwanted noise, never place
the speakers too close to the main unit,
subwoofer, AC power adapter, TV or any
other radiation sources.
REAR
LEFT
REAR
RIGHT
SUBWOOFER
FRONT CENTRE
FRONT
LEFT
FRONT
RIGHT
1_hts3264D_37_eng4_final810.indd17 171_hts3264D_37_eng4_final810.indd17 17 2008-03-13 10:29:39 AM2008-03-13 10:29:39 AM
18
English
Basic Connections (continued)
Step 4: Connecting the
FM antenna
A Connect the FM antenna (supplied) to
the FM 75 Ω jack. (For some models, it
has been connected in the factory.)
B Extend the FM antenna and x its ends to
the wall.
For better FM stereo reception, connect
an external FM antenna (not supplied).
Helpful Hints:
– Adjust the position of the antenna for
optimal reception.
– Position the antenna as far away as
possible from your TV, VCR or other
radiation source to prevent any unwanted
interference.
Main Unit (rear)
FM antenna
Main Unit (rear)
Step 5: Connecting the
power cord
After everything is connected
properly, connect the AC power
cord into the power outlet.
The standby LED on the main unit lights
up.
Helpful Hints:
– Refer to the type plate at the rear or
bottom of the product for identi cation and
supply ratings.
– Before making or changing any
connections, make sure that all the devices
are disconnected from the power outlet.
1_hts3264D_37_eng4_final810.indd18 181_hts3264D_37_eng4_final810.indd18 18 2008-03-13 10:29:39 AM2008-03-13 10:29:39 AM
19
English
Optional Connections
Connecting audio from other
devices
This unit provides analogue audio
connection. You can connect the audio
output from an audio/video device (e.g.
DVD Recorder, VCR, Cable/Satellite
Box, game console or TV) to the main
unit in order to enjoy the multi-channel
surround sound capabilities.
Use an audio cable (not supplied) to
connect the AUDIO IN-AUX1 or
AUDIO IN-AUX2 jacks on the main
unit to the AUDIO OUT jacks on the
connected device.
To listen to the audio output from this
connection, press AUX (MP3 LINK)
repeatedly until ‘AUX 1’ or ‘AUX 2’ is
displayed on the front panel.
DVD Recorder/VCR
Cable/Satellite Box
1_hts3264D_37_eng4_final810.indd19 191_hts3264D_37_eng4_final810.indd19 19 2008-03-13 10:29:39 AM2008-03-13 10:29:39 AM
20
English
Finding the correct viewing
channel
A Press STANDBY-ON to turn on the
unit.
B Press DISC on the remote control.
C Turn on the TV and switch it to the
correct video-in channel.
You may go to the lowest channel on
your TV, then press the Channel Down
button on your TVs remote control until
you see the Video In channel.
You may press
°
button repeatedly
on your TV’s remote control.
Usually this channel is between the
lowest and highest channels and may be
called FRONT, A/V IN, VIDEO, etc..
If you are using a RF modulator, set
the TV to channel 3 or 4.
Refer to your TVs user manual on
how to select the correct input on your
TV.
Getting Started
Switching to different play
source
On the main unit
Press the SOURCE button on the main
unit repeatedly to select:
DISC FM AUX1 AUX2
MP3 LINK DOCK DISC ...
Or
On the remote control
Press AUX (MP3 LINK) repeatedly to
hear the audio output from the external
device.
‘AUX1’ for device connected to
AUDIO IN-AUX1 jacks.
‘AUX2’ for device connected to
AUDIO IN-AUX2 jacks.
‘MP3 LINK’ for device connected to
MP3 LINK jack.
Press RADIO to switch to FM band.
Press USB to switch to USB mode.
Press DOCK to switch to iPod mode.
Press DISC to switch to DISC mode.
1_hts3264D_37_eng4_final810.indd20 201_hts3264D_37_eng4_final810.indd20 20 2008-03-13 10:29:40 AM2008-03-13 10:29:40 AM
21
English
Setting language preferences
The language options are different
depending on your country or region. It
may not correspond to the illustrations
shown on the user manual.
On-screen display (OSD) language
The OSD (On-Screen Display) language
for this unit remains as you have set it,
regardless of the changes made to the
DVD disc language.
A In disc mode, press OPTIONS on the
remote control.
{ General Setup } appears.
B Press .
C Press keys to select { OSD
Language } icon in the menu and
press .
Press OPTIONS to exit menu
General Setup
Disc Lock
Display Dim
OSD Language
Screen Saver
DivX(R) VOD Code
Sleep
Français
Español
English
D Use keys to select a language and
press OK to con rm.
Audio, Subtitle and Menu language
for DVD playback
You can select your preferred language
settings for DVD playback. If the selected
language is recorded on the DVD disc,
this unit automatically plays the disc in
that language. Otherwise, the disc’s
default language will be used instead.
A Press Ç twice to stop playback (if any),
then press OPTIONS.
B Press repeatedly to select
{ Preferences } icon, and press .
C Use keys to select one of the
options below and press .
Press OPTIONS to exit menu
English
Chinese (Simp)
French
Spanish
Portuguese
Polish
Italian
Turkish
Audio
Subtitle
Disc Menu
Parental
PBC
MP3/JPEG Nav
Password
DivX Subtitle
Preferences
{ Audio }
Select the preferred audio language for
DVD playback.
{ Subtitle }
Select the preferred subtitle language for
DVD playback.
{ Disc Menu }
Select the preferred disc menu language
for DVD playback.
D Use keys to select a language and
press OK to con rm.
Getting Started (continued)
1_hts3264D_37_eng4_final810.indd21 211_hts3264D_37_eng4_final810.indd21 21 2008-03-13 10:29:40 AM2008-03-13 10:29:40 AM
22
English
If the language you want is not
available in the list, select { Others }.
Use the numeric keypad (0-9) on the
remote control to enter the 4-digit
language code ‘XXXX’ (see Language
Code page) and press OK to con rm.
E Repeat steps C ~ D for other settings.
Helpful Hints:
– During DVD playback, you can press the
AUDIO SYNC and SUBTITLE on the remote
control to change the audio and subtitle
languages respectively. However, this does
not change the default settings you have
made here.
– For some DVDs, the subtitle/audio/disc
menu language can only be changed via the
DVD disc menu.
Getting Started (continued)
1_hts3264D_37_eng4_final810.indd22 221_hts3264D_37_eng4_final810.indd22 22 2008-03-13 10:29:40 AM2008-03-13 10:29:40 AM
23
English
Setting up Progressive Scan
feature
(for Progressive Scan TV only)
The progressive scan displays twice the
number of frames per second than
interlaced scanning (ordinary normal TV
system). With nearly double the number
of lines, progressive scan offers higher
picture resolution and quality.
Before you start...
Ensure that you have connected this unit
to a progressive scan TV (see ‘Option 2:
Connecting to a Progressive Scan TV or
component video input’.)
A Turn on the TV to the correct viewing
channel for this unit.
Make sure that the TVs progressive
scan mode is turned off (or set to
interlaced mode). Refer to your TVs user
manual.
B Turn on this unit and press DISC on the
remote control.
C Press OPTIONS on the remote control.
D Press repeatedly to select { Video
Setup }
icon, and press .
Press OPTIONS to exit menu
Video Setup
TV Type
TV Display
Progressive
Picture Setting
Closed Caption
Off
On
E Move to { Progressive } > { On } in the
menu and press OK to con rm.
F Read the noti cation message on the TV
and con rm your action by selecting the
{ OK } in the menu and press OK.
There will be no picture on your TV
at this state until you have turned
on the progressive scan mode on
your TV.
G Turn on your TV progressive scan mode,
refer to your TVs user manual.
A message appears on the TV.
H Con rm your action by selecting the
{ OK } in the menu and press OK.
The setup is now completed and you
can start to enjoy the high quality picture.
If no picture is displayed
A Press ç on the main unit.
B Press on the remote control.
C Press AUDIO SYNC on the remote
control.
Helpful Hints:
– If a blank/distorted screen appears, wait
for 15 seconds for the auto recovery.
– There are some progressive scan TVs that
are not fully compatible with this unit,
resulting in an unnatural picture when
playing back a DVD VIDEO disc in the
progressive scan mode. In such a case, turn
off the progressive scan feature on this unit
and your TV.
Getting Started (continued)
1_hts3264D_37_eng4_final810.indd23 231_hts3264D_37_eng4_final810.indd23 23 2008-03-13 10:29:40 AM2008-03-13 10:29:40 AM
24
English
Setting the speakers’
channels
You can adjust the delay times (center
and surround only) and volume level for
individual speakers. These adjustments let
you optimize the sound according to
your surroundings and setup.
Before you start...
Stop the disc playback by pressing x
button twice or remove the disc from
the disc tray. Otherwise, the settings are
not accessible.
A In disc mode, press OPTIONS on the
remote control.
B Press repeatedly to select { Audio
Setup }
icon, and press .
C Select { Speakers Volume } and press
.
Press OPTIONS to exit menu
Audio Setup
Front Left
Front Right
Center
Subwoofer
Rear Left
Rear Right
0dB
0dB
0dB
0dB
0dB
0dB
Speakers Level Setup
Speakers Volume
Speakers Delay
CD Upsampling
Audio Sync
D Use keys to set the volume level for
each speaker (-6dB ~ +6dB) and press
OK to con rm.
Getting Started (continued)
E
Use keys to highlight { Speakers
Delay } and press
.
Press OPTIONS to exit menu
Audio Setup
Center
Rear Left
Rear Right
Speakers Distance Setup
0ms
0ms
0ms
Speakers Volume
Speakers Delay
CD Upsampling
Audio Sync
F Use keys to set the delay times
(0 ms ~ 15 ms) for center and rear
speakers that best suit your surround
sound needs.
G Press OK to con rm.
Helpful Hints:
– A 1ms increase/decrease of delay time is
equivalent to 30 cm change in distance.
– Use the longer delay time settings when
the rear speakers are closer to the listener
than the front speakers.
– The test tone will be generated to help you
judge the sound level of each speaker.
1_hts3264D_37_eng4_final810.indd24 241_hts3264D_37_eng4_final810.indd24 24 2008-03-13 10:29:41 AM2008-03-13 10:29:41 AM
25
English
Disc Operations
Playable discs
Your DVD home theater system
plays:
– Digital Versatile Discs (DVDs)
– Video CDs (VCDs)
– Super Video CDs (SVCDs)
– Finalized DVD Recordable (DVD±R),
DVD Rewritable (DVD±RW)
– Audio Compact Discs (CDs)
– MP3/ Windows Media™ Audio discs,
picture (Kodak, JPEG) les on
CD-R(W)
– ISO 9660/UDF format
– JPEG resolution support up to
3072 x 2048
– Supported sampling frequencies:
32 kHz, 44.1 kHz, 48 kHz
– Supported Bit-rates: 32~256 (kbps),
variable bit rates (average 128 kbps)
– DivX
®
les on CD-R(W)/DVD+R(W):
– DivX
®
3/4/5/6, DivX
®
Ultra
Region Codes for DVD discs
DVD discs and players are designed with
regional restrictions. Before playing a disc,
make sure the disc is for the same region
as the unit. The regional code for this unit
is indicated at the rear or bottom panel.
Notes:
– If the inhibit icon (ø or X) appears
on the TV when a button is pressed,
it means the function is not
available on the current disc or at
the current time.
– Never put any objects other than
discs on the disc tray. Doing so may
cause the unit to malfunction.
Playing a disc
A Press SOURCE repeatedly until ‘DISC’
appears on the display panel (or press
DISC on the remote control).
B Turn on the TV to the correct viewing
channel for this unit.
The blue DVD background screen
appears on the TV.
C Press ç to open the disc tray.
D Load a disc and press ç to close the disc
tray.
Make sure the disc label is facing up.
For double-sided discs, load the side
which you want to play facing up.
E Playback starts automatically.
See the following pages for more
playback options and features.
Helpful Hints:
– If you are having trouble playing a certain
disc, remove the disc and try a different one.
Improperly formatted discs cannot be played
on this unit.
– Some discs cannot be played on this unit
due to the con guration and characteristics
of the disc, or due to the condition of
recording and authoring software that was
used.
1_hts3264D_37_eng4_final810.indd25 251_hts3264D_37_eng4_final810.indd25 25 2008-03-13 10:29:41 AM2008-03-13 10:29:41 AM
26
English
Disc Operations (continued)
Basic playback controls
Pausing playback
During playback, press u.
While in pause mode, you can press
to step forward one frame at each
press.
To resume playback, press u again.
Selecting another track/chapter
Press í / ë or use the numeric
keypad 0-9 to key in a track/chapter
number.
If the repeat track mode is active, press
again to replay the same track/chapter.
Searching backward/forward
Press m / M on the remote control.
While searching, press m / M
repeatedly to increase the search speed.
To resume normal playback, press
u.
Stopping playback
Press x.
Helpful Hints:
– If the message ‘Playback from the
beginning, pressí’ appears on the TV while
you load in a disc, you can press í to start
playback from the beginning.
– This is a power-saving feature, this unit
automatically switches to standby mode if
you do not press any buttons within 15
minutes after a disc has stopped playing.
– Screen saver starts automatically if the
disc playback is stopped for about 5 minutes.
Selecting various repeat/
shuf e functions
The available of the repeat play options
and shuf e play mode are vary depending
on the disc type.
While playing a disc, press
REPEAT (PROGRAM) on the remote
control repeatedly to choose a repeat or
shuf e play mode.
DVD
RPT ONE (repeat chapter)
RPT TT (repeat title)
SHUFFLE (random play)
RPT SHF (repeat random play)
RPT OFF (exit repeat mode)
VCD/SVCD/CD
RPT ONE (repeat track)
RPT ALL (repeat disc)
SHUFFLE (random play)
RPT SHF (repeat random play)
RPT OFF (exit repeat mode)
MP3/ Windows Media™ Audio/ DivX
®
RPT ONE (repeat track)
RPT ALL/FLD (repeat folder)
SHUFFLE (random play)
RPT OFF (exit repeat mode)
Helpful Hint:
– Repeat playback is not possible on VCDs /
SVCDs when the PBC mode is turned on.
1_hts3264D_37_eng4_final810.indd26 261_hts3264D_37_eng4_final810.indd26 26 2008-03-13 10:29:41 AM2008-03-13 10:29:41 AM
27
English
Other playback features
for video discs (DVD/VCD/
SVCD)
OPTIONS
INFO
AUDIO SYNC
BACK
MENU
DISC
SUBTITLE
Note:
The operating features described here
might not be possible for certain discs.
Always refer to the instructions supplied
with the discs.
Using the Disc menu
Depending on the disc format, a menu
may appear on the TV screen once you
load the disc.
To select a playback feature or item
Use keys or numeric keypad
0-9 on the remote control, then press
OK to start playback.
To access or remove the menu
Press DISC on the remote control.
Disc Operations (continued)
Viewing playback information
This unit can display the disc playback
information (for example, title or chapter
number, audio/subtitle language) and a
number of operations can be done
without interrupting disc playback.
A During playback, press INFO.
A list of available disc information
appears on the TV.
DVD
Menu
Title
Chapter
Audio
Subtitle
01/01
02/99
2ch Chi
Off
Bitrate 7
Title Elapsed
VCD/SVCD
Bitrate 8
Total Elapsed
Track
Disc Time
Track Time
Repeat
09/16
1:16:05
0:04:32
Off
Menu
B Use keys to view the information
and press OK to access.
C Use the numeric keypad 0-9 to input
the number/time or use keys to
make the selection.
D Press OK to con rm.
Playback changes according to the
chosen time or to the selected title/
chapter/track.
E To exit, press INFO.
1_hts3264D_37_eng4_final810.indd27 271_hts3264D_37_eng4_final810.indd27 27 2008-03-13 10:29:42 AM2008-03-13 10:29:42 AM
28
English
Disc Operations (continued)
Zooming
This option allows you to zoom and pan
through the picture on the TV.
A During playback, press ZOOM
repeatedly to select a different zoom
factor.
Playback continues.
B Use keys to pan through the
enlarged image.
C Press ZOOM repeatedly to return to
the original size.
Changing subtitle language
This operation works only on DVDs with
multiple subtitle languages. You can
change the language you want while
playing a DVD.
Press SUBTITLE repeatedly to select
different subtitle languages.
Switching camera angles
This option is only available on DVDs
that contain sequences recorded from
different camera angles. This allows you
to view the picture from different angles.
A During playback, press INFO.
Playback information menu appears.
B Press to highlight ‘ANGLE’ option in
the menu.
C If different camera angles choices are
available, press and use the numeric
keypad 0-9 to select.
Changing sound track language
This operation works only on DVDs with
multiple sound track languages, or VCDs/
SVCDs with multiple audio channels.
For DVD
Press AUDIO SYNC repeatedly to
select the available audio languages.
For VCD and SVCD
Press AUDIO SYNC repeatedly to
select the available audio channels
provided by the disc (STEREO, MONO
LEFT, MONO RIGHT or MIX MONO).
Setting the delay times for audio
playback
This feature allows you to adjust the
audio delay times if the video playback is
slower than the audio output streams,
hence resulting in ‘Lip-sync’. The only
way to correct ‘Lip-sync’ error caused by
delayed video is to delay audio by an
equal amount.
A Press and hold AUDIO SYNC until
‘Audio Sync’ appears on the TV.
B Within ve seconds, use the VOL +-
to set the audio output delay times
(0 ~ 200 ms).
If the volume control is not used
within ve seconds, it resumes its normal
volume control function.
Helpful Hint:
– Set your preferred default AUDIO SYNC
setting in the setup menu, see ‘Setup Menu
Options - { Audio Setup > Audio Sync } for
details.’
1_hts3264D_37_eng4_final810.indd28 281_hts3264D_37_eng4_final810.indd28 28 2008-03-13 10:29:42 AM2008-03-13 10:29:42 AM
29
English
Playback Control (VCD only)
Playback Control (PBC) playback allows
you to play VCDs/SVCDs interactively,
following the menu on the display. The
PBC feature on this unit is turned on by
default.
For VCDs with PBC feature
(version 2.0 only) and SVCDs
During playback (PBC ON mode only),
press MENU (BACK) to return to PBC
menu.
Helpful Hint:
– Set your preferred default PBC setting in
the setup menu, see ‘Setup Menu Options -
{ Preferences > PBC } for details.’
Preview function (VCD/SVCD only)
This function allows you to preview the
contents of a VCD/SVCD.
A
Press DISC.
Select Digest Type:
Track Digest
Disc Interval
Track Interval
B Use keys to select one of the
following options and press OK.
{ Track Digest }
View six different tracks on one screen
each time. It allows you to have a quick
glance at all the tracks on the disc.
{ Disc Interval }
View the whole disc in six thumbnail
pictures. It divides a disc into six portions
at regular intervals and displays them on
one screen.
{ Track Interval }
View the content of a single track in six
thumbnail pictures. It divides a single
track into six portions at regular intervals
and displays them on one screen.
This option is only available during
playback mode.
Exit Menu
01 02 03
04 05 06
To go to the previous or next page, press
í / ë.
To return to the main menu, select
{ Menu } on the screen and press OK.
Press OK on the selected thumbnail
picture to start playback from there.
C To exit the preview menu, select
{ Exit } on the screen and press OK.
Disc Operations (continued)
1_hts3264D_37_eng4_final810.indd29 291_hts3264D_37_eng4_final810.indd29 29 2008-03-13 10:29:42 AM2008-03-13 10:29:42 AM
30
English
Playing a MP3/ WMA disc
This unit can playback most of the MP3
and Windows Media™ Audio les
recorded on a recordable disc or
commercial CD.
Before you start ...
Turn on your TV to the correct Video In
channel. See ‘Finding the correct viewing
channel’ for details.
A Load a MP3/WMA disc.
The disc reading time may exceed 30
seconds due to the complexity of the
directory/ le con guration.
The disc menu appears on the TV.
00:06 04:04 001/036
\UDF_MP3\
000 018 000
Previous
08-AudioTrack
09-AudioTrack
10-AudioTrack
11-AudioTrack
12-AudioTrack
13-AudioTrack
14-AudioTrack
Disc
B If the disc main menu contains various
folders, use keys to select a desired
folder and press OK to open the folder.
C Use keys to select a le and press
OK to start playback.
Playback starts from the selected le
and continue till the end of the folder.
During playback;
Press í / ë to playback another l e in
the current folder.
Press m / M to fast reverse/forward
search for a track.
To select another folder from the
current disc, press repeatedly to
highlight ‘Previous’ folder and press OK
to return to the root menu.
D To stop playback, press x.
Helpful Hints:
– You can set to display or skip the folders
when you load a MP3/JPEG disc. Press
OPTIONS, then go to { Preferences > MP3/
JPEG NAV }.
– Only the rst session of a multi-session CD
will be played back.
– It is normal to experience an occasional
‘skip’ while listening to your MP3/WMA disc
due to poor clarity of digital contents during
internet downloading.
– If any special characters are present in the
MP3/WMA track name (ID3) or album
name, it might not be displayed correctly on
the screen because this unit does not support
the characters.
Disc Operations (continued)
1_hts3264D_37_eng4_final810.indd30 301_hts3264D_37_eng4_final810.indd30 30 2008-03-13 10:29:42 AM2008-03-13 10:29:42 AM
31
English
Playing a JPEG image le
(slide show)
Before you start ...
Turn on your TV to the correct Video In
channel. See ‘Finding the correct viewing
channel’ for details.
A Load a JPEG photo CD (or Kodak Picture
CD).
For a Kodak disc, the slide show
begins automatically.
For a JPEG disc, the picture menu
appears on the TV. Press u to start the
slide-show playback.
Helpful Hint:
– It may require longer time to display the
disc content due to the large number of
songs/pictures compiled into the disc.
Supported le format:
– The le extension has to be ‘*.JPG’ and
not ‘*.JPEG’.
– This unit can only display digital camera
pictures according to the JPEG-EXIF
format, typically used by almost all digital
cameras. It cannot display progressive
JPEG, Motion JPEG, or pictures in
formats other than JPEG, or sound clips
associated with pictures.
Preview function
A During playback, press INFO.
12 thumbnail pictures will be displayed
on the TV.
B Press í / ë to display the other
pictures on the previous/next page.
C Use keys to select one of the
pictures and press OK to start playback.
D Press MENU (BACK) to return to
Picture CD menu.
Zooming
A During playback, press ZOOM
repeatedly to select a different zoom
factor.
B Use keys to pan through the
enlarged image.
Skip/Rotate picture
During playback, use keys to
skip/rotate the picture on the TV.
Action Remote
Control
Skip to previous picture.
Skip to next picture.
Rotate the picture clockwise.
Rotate the picture anti-
clockwise.
Disc Operations (continued)
1_hts3264D_37_eng4_final810.indd31 311_hts3264D_37_eng4_final810.indd31 31 2008-03-13 10:29:42 AM2008-03-13 10:29:42 AM
32
English
Playing music and photo les
simultaneously
You can create a musical slide show
playback if the disc contains both the
MP3/WMA music and JPEG picture les.
A Load a disc that contains both MP3/WMA
and JPEG les.
B Use keys to select a MP3/WMA le
from the disc menu and press OK to
start playback.
C During MP3/WMA playback, use
keys to select a JPEG le from
the disc menu and press OK.
Slideshow begins and continues till the
end of the photo folder or album.
To return to the menu, press MENU
(BACK),
D To stop simultaneous playback, press x
twice.
Disc Operations (continued)
Playing a DivX
®
disc
You can only play those DivX
®
videos
that were rented or purchased using the
DivX
®
registration code of this unit (see
‘Setup Menu Options - { General Setup >
DivX(R) VOD Code }’ for details.)
A Load a DivX
®
disc.
B Use keys to navigate to the le
you want to play.
C Press OK to start playback.
During playback;
If the DivX
®
disc has multilingual subtitles,
you can press SUBTITLE on the
remote control to change the subtitle
language.
If the DivX
®
title has different audio
tracks, you can press AUDIO SYNC on
the remote control to change the audio
stream.
Use m / M keys on the remote
control to perform fast reverse/forward
search.
Press INFO repeatedly until the Time
Search menu appears, key in the time
where playback should start.
Playback skips to the time entered.
Helpful Hints:
– Subtitle les with the following le name
extensions (.srt, .smi, .sub, .ssa, .ass) are
supported but do not appear on the le
navigation menu.
– The subtitle le name has to be the same
as the le name of the movie.
– The subtitle can only be displayed up to an
average of 45 characters.
1_hts3264D_37_eng4_final810.indd32 321_hts3264D_37_eng4_final810.indd32 32 2008-03-13 10:29:43 AM2008-03-13 10:29:43 AM
33
English
Playback - iPod
Playing music from
compatible iPod device
Music on your Apple iPod can be played
on this unit with the support of the
docking station. It enables you to enjoy
the superior sound output from the
speaker system.
The docking station supports the
following iPod range:
iPod 4th gen iPod Nano 3rd
gen
iPod 5th gen iPod Mini
iPod Nano 1st gen iPod Touch
iPod Nano 2nd
gen
iPod Classic
Preparing the docking station
The supplied docking station has an
adjustable support to t varies iPod
range.
If your iPod cannot be xed to the
docking station, adjust the support
as below:
A Turn the knob at the bottom of the
docking station anti-clockwise to loosen
the support.
B Adjust the support until it can t your
iPod.
C Turn the knob clockwise to tighten it.
Playing from iPod
A Connect the docking station (supplied) to
the DOCK jack on this unit.
B Dock your iPod in the docking station
and turn it on.
C Press DOCK on the remote control.
D Start playback on your iPod.
The music will be heard through the
speakers.
During playback, you can use the remote
control to control the music:
Action Remote
control
Press to display the menu. MENU
(BACK)
Press to play/pause
playback.
u
Press to go to previous/
next track.
í / ë
Press and hold to reverse/
forward search
m / M
Helpful Hint:
– Whenever this unit is powered up and the
docking station is connected to it, the battery
of the docked iPod will be charged
automatically.
support
knob
1_hts3264D_37_eng4_final810.indd33 331_hts3264D_37_eng4_final810.indd33 33 2008-03-13 10:46:37 AM2008-03-13 10:46:37 AM
34
English
Playback - USB Device
Playing from a USB device
You can play or view the data les (JPEG,
MP3, Windows Media™ Audio or DivX
®
)
in the USB ash drive or USB memory
card reader. However, editing or copying
the data le is not possible.
MP3 LINK
A Connect the USB ash drive/USB
memory card reader directly to the
(USB) jack on this unit.
B A message appears on the TV for 5 ( ve)
seconds when the device is detected.
Press USB to select device
C Press USB on the remote control to
access the data in the drive.
When using multiple drives on a single
card reader, only one of the connected
cards can be accessed.
The device numbers may vary from
different card readers.
D Select the le to play and press u.
For more playback information, see
‘Playing a DivX disc’, ‘Playing a JPEG
photo le (slide show)’ or ‘Playing a MP3/
WMA disc’ for details.
E Before you remove the USB device, press
Ç to stop playback or press DISC to
switch to disc mode.
Helpful Hints:
– The USB jack does not support the
connection of other USB devices except to a
USB ash drive/USB memory card reader.
– When the USB device does not t into the
USB jack, a USB extension cable (not
supplied) is required.
– This unit can only support up to a
maximum of 300 folders and 648 les.
– You can only read and playback the
content from the USB device.
– Copy-protected contents are not playable.
1_hts3264D_37_eng4_final810.indd34 341_hts3264D_37_eng4_final810.indd34 34 2008-03-13 10:29:43 AM2008-03-13 10:29:43 AM
35
English
Playback - Other Audio Player
Playing from other portable
audio player
You can connect your portable audio
player to this unit to get the best
immersion sound experience through the
speaker system. However, controlling of
playback is only possible on the portable
audio player.
MP3 LINK
A Use a 3.5mm stereo audio cable (not
supplied) to connect the MP3 LINK jack
on this unit to the ‘headphone’ output
jack on your portable audio player.
B Press AUX (MP3 LINK) repeatedly on
the remote control until ‘MP3 LINK’ is
displayed.
C Start playback on your portable audio
player.
The music will be heard through the
speakers.
D To stop playback, press the STOP button
on the portable audio player.
Helpful Hint:
– Stop playback on your portable audio
player before you switch this unit to another
input source (eg. DISC, USB).
1_hts3264D_37_eng4_final810.indd35 351_hts3264D_37_eng4_final810.indd35 35 2008-03-13 10:29:44 AM2008-03-13 10:29:44 AM
36
English
Press OPTIONS to exit menu
General Setup
Disc Lock
Display Dim
OSD Language
Screen Saver
DivX(R) VOD Code
Sleep
See ‘General Setup’ on this Chapter.
Press OPTIONS to exit menu
V
Audio Setup
Speakers olume
Speakers Delay
CD Upsampling
Audio Sync
See ‘Audio Setup’ on this Chapter.
Press OPTIONS to exit menu
Video Setup
TV Type
TV Display
Progressive
Picture Setting
Closed Caption
See ‘Video Setup’ on this Chapter.
Press OPTIONS to exit menu
Audio
Subtitle
Disc Menu
Parental
PBC
MP3/JPEG Nav
Password
DivX Subtitle
Preferences
See ‘Preferences’ on this Chapter.
Setup Menu Options
Accessing the setup menu
You can change the settings in this unit to
suit your particular requirements.
OPTIONS
OK
A In disc mode, press OPTIONS on the
remote control.
The setup menu appears.
B Use keys to select one of the setup
menu options, then press .
General Setup
Audio Setup
Video Setup
Preferences
If you are not able to access the
{ Preferences }, press OPTIONS to exit
the menu. Then, press x twice before
you press the OPTIONS again.
C Use keys to select an option and
press .
D Select the setting you wish to change and
press OK to con rm and go back to the
previously selected item.
Instructions and explanations of the
options are provided in the following
pages.
If the option in the menu is grayed
out, that means the setting is not
available or cannot be changed in the
current state.
E To exit, press OPTIONS.
1_hts3264D_37_eng4_final810.indd36 361_hts3264D_37_eng4_final810.indd36 36 2008-03-13 10:29:44 AM2008-03-13 10:29:44 AM
37
English
Setup Menu Options (continued)
General Setup (underlined options are the factory default settings)
Disc Lock
Not all discs are rated or coded by the disc maker. You can
prevent play of speci c discs with the disc lock function. Up to 40
discs can be locked.
{ Lock } – To block the playback of the current disc.
Subsequent access to a locked disc requires a
six-digit password. The default password is
‘136900’ (see { Preferences > Password } for
details).
{ Unlock } – All discs can be played.
Display Dim
Select the brightness of this unit’s display panel.
{ 100% } – Full brightness.
{ 70% } – Medium brightness.
{ 40% } – Dimmest display. This switches off all LEDs and
icons on the front display panel of this unit.
OSD Language
Select the menu language for this unit’s on-screen display.
Screen Saver
The screen saver prevents damage to the TV screen by avoiding
exposure to a static image for too long.
{ On } – Switch to TV screen saver mode when
playback has been stopped or paused for
about 5 minutes.
{ Off } – Disable the screen saver function.
Sleep
The sleep timer enables the unit to switch to standby mode
automatically after a preset time.
{ 15/30/45/60 mins } – Select the preset minutes for switching
the unit to standby mode
automatically.
{ Off } – Turn off the sleep mode function.
DivX(R) VOD Code
Philips provides you with the DivX
®
VOD (Video On Demand)
registration code that allows you to rent or purchase videos from
DivX
®
VOD service at www.divx.com/vod. All the downloaded
videos from DivX
®
VOD can only be played back on this unit.
Press
to see the registration code and press OK to exit.
1_hts3264D_37_eng4_final810.indd37 371_hts3264D_37_eng4_final810.indd37 37 2008-03-13 10:29:44 AM2008-03-13 10:29:44 AM
38
English
Audio Setup (underlined options are the factory default settings)
Speakers Volume
Access the speaker’s level setup menu. Use keys to adjust
the volume level for each connected speaker between -6dB to
+6dB.
See ‘Getting Started - Setting the speakers’ channels’.
Speakers Delay
Access the speaker’s distance setup menu. Use keys to set
the delay times for the center and rear speakers based on the
listening position and distance.
See ‘Getting Started - Setting
the speakers’ channels’.
Note: 1 ms increase/decrease of delay time is equivalent to one (1) foot
change in distance. Use the longer delay time settings when the rear
speakers are closer to the listener than the front speakers.
CD Upsampling
This feature enables you to convert the music CD to a
higher sampling rate using sophisticated digital signal
processing for better sound quality.
{ Off } – Turn off CD-upsampling.
{ 88.2 kHz (X2) } – To convert the sampling rate of the
CDs twice as high as the original rate.
Notes:
–
This function is not available if you switches to Multi-channel mode.
–
If you press SURROUND on the remote control, it turns off the
CD upsampling feature.
Audio Sync
This feature allows you to adjust the audio delay times if the
video playback is slower than the audio output streams.
Use keys to set the delay times for the audio output
between 0~200ms.
Setup Menu Options (continued)
1_hts3264D_37_eng4_final810.indd38 381_hts3264D_37_eng4_final810.indd38 38 2008-03-13 10:29:45 AM2008-03-13 10:29:45 AM
39
English
Video Setup (underlined options are the factory default settings)
TV Type
Select the color system that matches the connected TV. It
enables playback of a different type of disc (PAL or NTSC disc)
on this unit.
{ NTSC } – For NTSC-system TV.
{ Multi } – For TV that is compatible with both
PAL and NTSC.
TV Display
The picture shape can be adjusted to t your TV.
{ 4:3 Pan Scan } – For a full-height
picture with the
sides trimmed.
{ 4:3 Letter Box } – For a ‘wide-screen’
display with black bars
on the top and bottom.
{ 16:9 Wide Screen } – For wide-screen TV
(frame ratio 16:9).
Progressive
Before enabling the progressive scan feature, you must ensure that
your TV can accept progressive signals (a progressive scan TV is
required) and that you have connected this unit to your TV using
the Y Pb Pr. See ‘Getting Started > Setting up Progressive Scan
feature’ for details.
{ Off } – Turn off the progressive scan mode.
{ On } – Turn on progressive scan mode.
Read the instructions on the TV and con rm
your action by pressing OK on the remote
control.
Picture Setting
This unit provides three prede ned sets of picture color settings
and one personal setting which you can de ne yourself.
{ Standard } – Original color setting.
{ Bright } – Vibrant color setting.
{ Soft } – Warm color setting.
{ Personal } – Select this to personalize the picture color
setting. Use keys to adjust to the setting
that best suits your personal preference and
press OK to con rm. For an average setting,
select { 0 }.
Setup Menu Options (continued)
Brightness
Contrast
Tint
Color
Personal Picture Setup
1_hts3264D_37_eng4_final810.indd39 391_hts3264D_37_eng4_final810.indd39 39 2008-03-13 10:29:45 AM2008-03-13 10:29:45 AM
40
English
Video Setup (underlined options are the factory default settings)
Closed Caption
This feature is only available if the disc contains of special video
signal data. It shows sound effects on the screen if your TV
supports this feature, such as ‘phone ringing’ and ‘footsteps.’
{ On } – Turn on closed caption feature.
{ Off } – Turn off closed caption feature.
Setup Menu Options (continued)
1_hts3264D_37_eng4_final810.indd40 401_hts3264D_37_eng4_final810.indd40 40 2008-03-13 10:29:45 AM2008-03-13 10:29:45 AM
41
English
Preferences (underlined options are the factory default settings)
Audio
Select the preferred audio language for DVDs with multiple
sound tracks.
Subtitle
Select the preferred subtitle language for DVD playback.
Disc Menu
Select the preferred disc menu language for DVD playback.
Note: If the selected audio/subtitle/disc menu language is not available on
the DVD, the disc’s default language will be used instead.
Parental
This is to prohibit viewing of discs that had exceeded the limits
you set. It works only on the DVDs with parental level assigned
to the complete disc or to certain scenes on the disc.
1) Use keys to select a rating level from 1 to 8 and press
OK.
2) Use the numeric keypad 0-9 on the remote control to
enter your six-digit password.
Notes:
– The ratings are country-dependent (‘1’ is considered material that is
least offensive and ‘8’ is most offensive). To disable parental controls and
allow all discs to play, select ‘8’.
– Some DVDs are not encoded with a rating though the movie rating
may be printed on the disc cover. The rating level feature does not
prohibit playback of such discs. VCD, SVCD and CD have no level
indication, so parental control has no effect on these type of discs.
– DVDs that are rated higher than the level you selected will not be
played unless you enter the same six-digit password.
PBC
Play Back Control feature is applicable for VCD/SVCD only. It
allows you to play Video CDs (2.0) interactively, following the
menu on the display.
{ On } – The index menu (if available) appears on the
TV when you load a VCD/SVCD.
{ Off } – The VCD/SVCD skips the index menu and
playback directly from the beginning.
Setup Menu Options (continued)
1_hts3264D_37_eng4_final810.indd41 411_hts3264D_37_eng4_final810.indd41 41 2008-03-13 10:29:45 AM2008-03-13 10:29:45 AM
42
English
Preferences (underlined options are the factory default settings)
MP3/JPEG Nav
MP3/JPEG Navigator can only be set if the disc is recorded with a
menu. It allows you to select different display menus for easy
navigation.
{ Without Menu
} – Display all the les contained in the MP3/
Picture disc.
{ With Menu } – Display the folder menu of the MP3/
Picture disc.
Note: This unit can only display 648 les in the directory.
Password
The password is used for the Disc Lock and Parental. The default
password is ‘136900’. To change the password:
1) Press OK to access the change password menu.
Old Password
New Password
Confirm PWD
Change Password
OK
2) Use the numeric keypad 0-9 on the remote control to
enter your existing six-digit password at { Old Password }.
Note: When doing this for the rst time or if you forget your existing
password, key in ‘136900’.
3) Enter the new six-digit password at { New Password }.
4) Enter the new six-digit password again at { Con rm PWD }.
5) Press OK to con rm and exit the menu.
DivX Subtitle
Select the font type that supports the recorded DivX
®
subtitle.
{ Standard } – Display a standard list of Roman subtitle
fonts provided by this unit.
{ Central Europe }– Display Central Europe fonts.
{ Cyrillic } – Display Cyrillic fonts.
{ Greek } – Display Greek subtitle fonts.
Setup Menu Options (continued)
1_hts3264D_37_eng4_final810.indd42 421_hts3264D_37_eng4_final810.indd42 42 2008-03-13 10:29:45 AM2008-03-13 10:29:45 AM
43
English
Preferences (underlined options are the factory default settings)
Default
This feature enables you to reset all the setup menu options and
your personal settings to the factory defaults, except your
password for the Disc Lock and Parental.
Press OK to con rm the default reset.
Version Info
This shows you informations about the current version of the
software installed in this unit. You may require this information
for future online rmware upgrade.
Press OK to display the software version of this unit.
Setup Menu Options (continued)
1_hts3264D_37_eng4_final810.indd43 431_hts3264D_37_eng4_final810.indd43 43 2008-03-13 10:29:45 AM2008-03-13 10:29:45 AM
44
English
Radio Operations
Before you start .....
Ensure that FM antenna is connected to
the main unit. (For some models, it has
been connected in the factory.) Extend
the FM antenna and x its ends to the
wall.
Helpful Hints:
– For better FM stereo reception, connect an
external FM antenna (not supplied.)
– Position the antenna as far away as
possible from your TV, VCR or other
radiation source to prevent any unwanted
interference.
Tuning to radio stations
A Press SOURCE repeatedly until ‘FM’
appears on the display panel (or press
RADIO on the remote control).
B Press / on the remote control to
start tuning.
The frequency indication starts to
change until a radio station with suf cient
signal strength is found.
C Repeat step B if necessary until you nd
the desired radio station
D To ne-tune the reception of a weak
station, press / brie y and
repeatedly until an optimal reception is
found.
Presetting radio stations
You can store up to 40 FM preset radio
stations in the memory. There are three
different ways to program the radio
stations:
– Using auto install (for rst time setup
only)
– Using automatic preset
– Using manual preset
Helpful Hints:
– This unit exits presetting mode if no
button is pressed within 20 seconds.
– If no stereo signal is detected or less than
5 ( ve) stations are detected during radio
installation, ‘CHECK ANTENNA’ appears.
Using auto install
When you access the ‘RADIO’ mode for
the very rst time, you will be prompted
to install the radio stations. With this
feature, you can install all the available
radio station automatically with one
touch of button.
RADIO
A Press RADIO.
‘AUTO INSTALL ... PRESS PLAY’
appears.
B Press u.
All the available radio stations with
strong signal will be stored automatically.
Once complete, the rst tuned radio
station will be played back.
1_hts3264D_37_eng4_final810.indd44 441_hts3264D_37_eng4_final810.indd44 44 2008-03-13 10:29:46 AM2008-03-13 10:29:46 AM
45
English
Using automatic preset
Use automatic presetting to store or
reinstall all the preset radio stations.
RADIO
REPEAT
PROGRAM
A Press RADIO to select ‘FM’ band.
B Press and hold REPEAT (PROGRAM)
until ‘START ...’ appears on the display
panel.
All previously stored radio stations
will be replaced.
Using manual preset
Use manual presetting to store your
favourite radio stations.
A Tune to your desired radio station (see
‘Tuning to radio stations’).
B Press REPEAT (PROGRAM).
C Press í / ë or use the numeric
keypad 0-9 to select a preset number
that you want to store the current radio
station.
D Press REPEAT (PROGRAM) to store.
Selecting a preset radio
station
A Press RADIO to select ‘FM’ band.
B Press í / ë or use the numeric
keypad 0-9 to select a preset radio
stations.
The preset number and radio
frequency appear on the display panel.
Deleting a preset radio
station
A In radio mode, press í / ë to select a
preset radio station.
B Press and hold x until ‘ ‘FM X DELETED’
appears.
‘X’ is the preset number.
The radio station continues to play
but has been deleted from the preset list.
The rest of the preset radio stations
remain unchanged.
Radio Operations (continued)
1_hts3264D_37_eng4_final810.indd45 451_hts3264D_37_eng4_final810.indd45 45 2008-03-13 10:29:46 AM2008-03-13 10:29:46 AM
46
English
Sound and Volume Controls
SURROUND
SOUND
MODES
+-
(Mute)
VOL+-
Volume control
Press VOL +
/- to increase or
decrease the volume level.
To turn off the volume temporarily
Press
.
Playback continues without sound and
‘MUTE’ appears.
To restore the volume, press again,
or increase the volume level.
Selecting surround sound
Press SURROUND to select Multi-
Channel, Stereo sound or Party sound.
The availability of the various
surround sound modes depends on the
sound available on the disc.
The available output modes for
Multi-channel include: Dolby Digital and
Dolby Pro Logic II.
Stereo broadcasts or recordings will
produce some surround channel effects
when played in a surround mode.
Party mode is ideal for party music. It
enhanced the stereo channels output by
duplicating the sound output to the
center, rear left and rear right speakers.
Selecting digital sound effects
Select a preset digital sound effect that
matches your disc’s content or that
optimizes the sound of the musical style
you are playing.
Press SOUND MODES +/- to
select the available sound effect.
Movies Music Description
CONCERT CLASSIC Flat and pure sound
mode. Ideal for
listening to classical
music and watching
live concert DVDs.
DRAMA LOUNGE Moderate sound
mode suitable for
lounge music and
watching dramas.
ACTION ROCK Enhanced low and
high range for great
sounding movie
effects and
atmosphere. Great
for action movies
and rock/pop music.
GAMING SPORTS Moderate mid range
and surround
effects for clear
vocals and the
atmosphere of a live
sports venue. Also
suitable for video
gaming.
NIGHT NIGHT Dynamically con-
trolled sound mode
suitable for watch-
ing movies at night
or for non-intrusive
background music.
1_hts3264D_37_eng4_final810.indd46 461_hts3264D_37_eng4_final810.indd46 46 2008-03-13 10:29:46 AM2008-03-13 10:29:46 AM
47
English
Other Features
Installing the latest software
Philips provides software upgrades to
make sure that this unit is compatible
with the newest formats. To check the
updates, compare the current software
version of this unit with the latest
software version available at the Philips
website.
A Press OPTIONS to select
{ Preferences } menu.
B Select { Version Info }, and press OK to
check the software version of this unit.
Press OPTIONS to exit menu
DivX Subtitle
Default
Parental
Disc Menu
PBC
MP3/JPEG Nav
Password
Preferences
Version Info
C Write down the version number, then
press OPTIONS to exit the menu.
D Go to www.philips.com/support to check
the latest software version available for
this unit.
E If the latest software version is higher
than the software version of this unit,
download it and store onto a CD-R or
USB ash drive
F Insert the CD-R or USB ash drive to
this unit and con rm upgrade operation.
Note:
Never unplug or turn off this unit
during the upgrade.
G Once complete, this unit turns off to
standby mode automatically.
1_hts3264D_37_eng4_final810.indd47 471_hts3264D_37_eng4_final810.indd47 47 2008-03-13 10:29:46 AM2008-03-13 10:29:46 AM
48
English
Troubleshooting
WARNING
Under no circumstances should you try to repair the system yourself, as this will
invalidate the warranty. Never open the system as there is a risk of electric shock.
If a fault occurs, rst check the points listed below before taking the system for repair.
If you are unable to solve a problem by following these instructions, consult your dealer or
Philips for help.
No picture.
Completely distorted picture
or black/white picture.
No sound or distorted sound.
No surround sound effect
from the speakers.
The remote control does not
function properly.
– Refer to your TVs manual for correct Video In
channel selection. Change the TV channel until you
see the DVD screen.
– Press DISC to select disc mode.
– If this happens when you turn on the progressive scan
feature, wait for 15 seconds for the auto recover or
switch to the default mode as below:
1) Press ç to open the disc tray.
2) Press on the remote control.
3) Press AUDIO SYNC on the remote control.
– Check the video connection.
– Sometimes a small amount of picture distortion may
appear. This is not a malfunction.
– The disc is dirty. Clean the disc.
– Adjust the volume.
– Check the speaker connections and settings.
– Make sure that the audio cables are connected and
press the correct source button (for example,
AUX (MP3 LINK)) to choose the device that you want
to hear through this unit.
– Press SURROUND to select a correct surround
sound setting.
– For playback of DTS track, press AUDIO SYNC to
select other audio track.
– Make sure that the source you are playing is recorded
or broadcast in surround sound (Dolby Digital, etc).
– Select the source you want to play (for example,
DISC or RADIO) before pressing the function button
(u, í / ë).
– Reduce the distance between the remote control and
this unit.
– Batteries are weak, replace the batteries.
– Point the remote control directly toward the IR sensor.
Problem (General) Solution
1_hts3264D_37_eng4_final810.indd48 481_hts3264D_37_eng4_final810.indd48 48 2008-03-13 10:29:46 AM2008-03-13 10:29:46 AM
49
English
The unit does not start
playback.
The aspect ratio of the screen
cannot be changed even
though you have set the TV
display.
Cannot activate some features
e.g. Angles, Subtitles, or
multi-language Audio.
Not able to select some items
in the setup/system menu.
Unable to play DivX
®
movies.
Radio reception is poor.
– Load a readable disc with the playback side facing
down. The DVD+R/CD-R must be nalized.
– Make sure the disc is not scratched or warped.
– Press OPTIONS to turn off the system setup menu
screen.
– You may need to enter the password in order to
unlock the disc for playback.
– Moisture may have condensed inside this unit.
Remove the disc and leave this unit turned on for
about an hour.
– The aspect ratio is xed on the DVD disc.
– Depending on the TV, it may not be possible to
change the aspect ratio.
– The features may not be available on the DVD.
– Changing the language for the sound or subtitle is
prohibited on this DVD.
– Press x twice before selecting the system setup
menu.
– Depending on the disc availability, some menu items
cannot be selected.
– Ensure that the DivX
®
le is encoded according to the
‘Home Theater Pro le’ with the DivX
®
encoder.
– Check that the DivX
®
movie download is a complete
le.
– If the signal is too weak, adjust the antenna or
connect an external antenna for better reception.
– Increase the distance between this unit and your TV
or VCR.
– Tune in to the correct frequency.
– Place the antenna further away from any equipment
that may be causing the interference.
Problem (Playback) Solution
Troubleshooting (continued)
1_hts3264D_37_eng4_final810.indd49 491_hts3264D_37_eng4_final810.indd49 49 2008-03-13 10:29:47 AM2008-03-13 10:29:47 AM
50
English
Problem (USB) Solution
Troubleshooting (continued)
The contents of the USB ash
drive cannot be read.
Slow operation of the USB
ash drive.
– The USB ash drive format is not compatible with this
unit.
– Drive is formatted with a different le system which is
not supported by this unit (e.g. NTFS).
– Large le size or high memory USB ash drive takes
longer time to read and display on the TV.
1_hts3264D_37_eng4_final810.indd50 501_hts3264D_37_eng4_final810.indd50 50 2008-03-13 10:29:47 AM2008-03-13 10:29:47 AM
51
English
Speci cations
AMPLIFIER
Total output power:
- Home Theater mode: 600 W
- FTC* output power: 420 W
Frequency Response: 180 Hz – 18 kHz / ±3 dB
Signal-to-Noise Ratio: > 60 dB (A-weighted)
Input Sensitivity
- AUX 1: 400 mV
- AUX 2: 400 mV
- MP3 LINK: 400 mV
* (1% THD 1kHz)
RADIO
Tuning Range: FM 87.5-108 MHz
(100 kHz)
26 dB Quieting
Sensitivity: FM 22 dBf
IF Rejection Ratio: FM 60 dB
Signal-to-Noise Ratio: FM 50 dB
Harmonic Distortion: FM Mono 3%
FM Stereo 3%
Frequency Response FM 180 Hz–10 kHz / ±6 dB
Stereo Separation FM 26 dB (1 kHz)
Stereo Threshold FM 29 dB
DISC
Laser Type Semiconductor
Disc Diametre 12cm / 8cm
Video Decoding MPEG-1 / MPEG-2 /
/ DivX 3/4/5/6, Ultra
Video DAC 12 Bits
Signal System NTSC / Multi
Video Format 4:3 / 16:9
Video S/N 56 dB
Composite Video
Output 1.0 Vp-p, 75Ω
Frequency Response 4 Hz–20 kHz (44.1 kHz)
4 Hz–22 kHz (48 kHz)
4 Hz–44 kHz (96 kHz)
PCM IEC 60958
Dolby Digital IEC 60958, IEC 61937
USB
Compatibility Hi-Speed USB (2.0)
Class Support UMS (USB Mass
Storage Class),
MTP (Media Transfer
Protocol)
MAIN UNIT
Power Supply Rating: 120 V; 60 Hz
Power Consumption: 100 W
Dimensions: 360 x 58 x 332 (mm)
(w x h x d)
Weight: 2.9 kg
FRONT AND REAR SPEAKERS
System: Full range satellite
Impedance: 3 Ω
Speaker drivers: 3” full range speaker
Frequency response: 150 Hz – 20 kHz
Dimensions: 103 x 203 x 71 (mm)
(w x h x d)
Weight: 0.45 kg/each
CENTRE SPEAKER
System: Full range satellite
Impedance: 6 Ω
Speaker drivers: 3” full range speaker
Frequency response: 150 Hz – 20 kHz
Dimensions: 244 x 105 x 74 (mm)
(w x h x d)
Weight: 0.78 kg
SUBWOOFER
Impedance: 6 Ω
Speaker drivers: 165mm (6.5”) woofer
Frequency response: 40 Hz – 150 Hz
Dimensions: 123 x 310 x 369 (mm)
(w x h x d)
Weight: 3.85 kg
Speci cations subject to change without prior
notice.
1_hts3264D_37_eng4_final810.indd51 511_hts3264D_37_eng4_final810.indd51 51 2008-03-13 10:29:47 AM2008-03-13 10:29:47 AM
52
English
Glossary
Analogue audio: Sound that has not been
turned into numbers. Analogue sound is
available if you use the AUDIO LEFT/RIGHT.
These red and white jacks send audio
through two channels, the left and right.
Aspect ratio: Aspect ratio refers to the
length to height ratio of TV screens. The
ratio of a standard TV is 4:3, while the ratio
of a high-de nition or wide TV is 16:9. The
letter box allows you to enjoy a picture with
a wider perspective on a standard 4:3 screen.
AUDIO IN jacks: Red and white jacks on
the back of the unit that receive audio from
another system (TV, Stereo, etc.).
Bit Rate: The amount of data used to hold
a given length of music; measured in kilobits
per second, or kbps. Or, the speed at which
you record. Generally, the higher the bit
rate, or the higher the recording speed, the
better the sound quality. However, higher bit
rates use more space on a disc.
Chapter: Sections of a picture or a music
piece on a DVD that are smaller than titles.
A title is composed of several chapters. Each
chapter is assigned a chapter number
enabling you to locate the chapter you want.
Component video: Jacks on the back of
the unit that send out high-quality video to a
TV that has component video input jacks (R/
G/B, Y/Pb/Pr, etc.).
Composite video (CVBS): A single video
signal commonly used in most consumer
video products.
Disc menu: A screen display prepared for
allowing a selection of images, sounds,
subtitles, multi-angles, etc., recorded on a
DVD.
DivX
®
: The DivX
®
code is a patent-pending,
MPEG-4 based video compression
technology, developed by DivX
®
Networks,
Inc., that can shrink digital video to sizes
small enough to be transported over the
internet, while maintaining high visual quality.
Dolby Digital: A surround sound system
developed by Dolby Laboratories containing
up to six channels of digital audio (front left
and right, surround left and right, center and
subwoofer).
Dolby Surround Pro Logic II: It is an
improved matrix decoding technology that
provides better spatiality and directionality
on Dolby Surround programme material,
provides a convincing three dimensional
sound eld on conventional stereo music
recordings and is ideally suited to bring the
surround experience to automotive sound.
While conventional surround programming
is fully compatible with Dolby Surround Pro
Logic II decoders, soundtracks will be able to
be encoded speci cally to take full advantage
of Pro Logic II playback, including separate
left and right surround channels. (Such
material is also compatible with conventional
Pro Logic decoders).
HDCP (High-bandwidth Digital Content
Protection) is a speci cation that provides a
secure transmission of digital contents
between different devices (to prevent
unauthorized copyright).
JPEG: A very common digital still picture
format. A still-picture data compression
system proposed by the Joint Photographic
Expert Group, which features small decrease
in image quality in spite of its high
compression ratio. Files are recognized by
their le extension ‘JPG or JPEG’.
1_hts3264D_37_eng4_final810.indd52 521_hts3264D_37_eng4_final810.indd52 52 2008-03-13 10:29:47 AM2008-03-13 10:29:47 AM
53
English
Glossary (continued)
MP3: A le format with a sound data
compression system. ‘MP3’ is the
abbreviation of Motion Picture Experts
Group 1 (or MPEG-1) Audio Layer3. By
using the MP3 format, one CD-R or CD-RW
can contain about 10 times more data than a
regular CD.
MPEG: Motion Picture Experts Group. A
collection of compression systems for digital
audio and video.
PBC: Playback Control. A system of
navigating a Video CD/Super VCD through
on-screen menus recorded onto the disc.
You can enjoy interactive playback and
searching.
Progressive Scan: The progressive scan
displays twice the number of frames per
second than in an ordinary TV system. It
offers higher picture resolution and quality.
Region code: A system allowing discs to be
played only in the region designated. This
unit will only play discs that have compatible
region codes. You can nd the region code
of your unit by looking at the product label.
Some discs are compatible with more than
one region (or ALL regions).
Surround: A system for creating realistic
three dimensional sound elds full of realism
by arranging multiple speakers around the
listener.
Title: The longest section of a movie or
music feature on DVD. Each title is assigned
a title number, enabling you to locate the
title you want.
WMA: Windows Media™ Audio. Refers to
an audio compression technology developed
by Microsoft Corporation. WMA data can be
encoded by using Windows Media Player
version 9 or Windows Media Player for
Windows XP. Files are recognized by their
le extension ‘WMA’.
1_hts3264D_37_eng4_final810.indd53 531_hts3264D_37_eng4_final810.indd53 53 2008-03-13 10:29:47 AM2008-03-13 10:29:47 AM
54
Philips, P.O. Box 671539, Marietta, GA. 30006-0026
PHILIPS LIMITED WARRANTY
ONE (1) YEAR
WARRANTY COVERAGE:
PHILIPS warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
Philips warrants the product to the original purchaser or the per-
son receiving the product as a gift against defects in materials and
workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
The Philips warranty covers new products if a defect in material
or workmanship occurs and a valid claim is received by Philips
within the Warranty Period. At its option, Philips will either (1)
repair the product at no charge, using new or refurbished
replacement parts, or (2) exchange the product with a product
that is new or which has been manufactured from new, or ser-
viceable used parts and is at least functionally equivalent or most
comparable to the original product in Philips current inventory,
or (3) refund the original purchase price of the product.
Philips warrants replacement products or parts provided under
this warranty against defects in materials and workmanship from
the date of the replacement or repair for ninety (90) days or for
the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes Philips’ property. When a refund
is given, your product becomes Philips’ property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMI-
TATIONS:
This Limited Warranty applies only to the new products manu-
factured by or for Philips that can be identified by the trademark,
trade name, or logo affixed to it. This Limited Warranty does not
apply to any non-Philips hardware product or any software, even
if packaged or sold with the product. Non-Philips manufacturers,
suppliers, or publishers may provide a separate warranty for their
own products packaged with the bundled product.
Philips is not liable for any damage to or loss of any programs,
data, or other information stored on any media contained within
the product, or any non-Philips product or part not covered by
this warranty. Recovery or reinstallation of programs, data or
other information is not covered under this Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product, (b)
to damage caused by service performed by anyone other than
Philips or Philips Authorized Service Location, (c) to a product or
a part that has been modified without the written permission of
Philips, or (d) if any Philips serial number has been removed or
defaced, or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished Philips
product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product to Philips.
• Labor charges for installation or setup of the product, adjust-
ment of customer controls on the product, and installation or
repair of antenna/signal source systems outside of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary con-
tent for extended periods, product cosmetic appearance items
due to normal wear and tear, unauthorized repair or other
cause not within the control of Philips.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents when
returning product to Philips.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which
it was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., PUERTO
RICO, OR U.S. VIRGIN ISLANDS…
Contact Philips Customer Care Center at:
1-888-PHILIPS (1-888-744-5477)
TO OBTAIN ASSISTANCE IN CANADA…
1-800-661-6162 (French Speaking)
1-888-PHILIPS (1-888-744-5477) - (English or Spanish
Speaking)
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-
SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-
UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
Some states do not allow the exclusions or limitation of inciden-
tal or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
3121 233 48802
1_hts3264D_37_eng4_final810.indd54 541_hts3264D_37_eng4_final810.indd54 54 2008-03-13 10:29:47 AM2008-03-13 10:29:47 AM
55
1_hts3264D_37_eng4_final810.indd55 551_hts3264D_37_eng4_final810.indd55 55 2008-03-13 10:29:48 AM2008-03-13 10:29:48 AM
